JVC LT-40A321 User manual

ATTENTION
ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the
required programming code.
Si vous utilisez avec cet appareil une télécommande universelle (autre que celle vendue avec ce téléviseur),
consultez la documentation accompagnant la télécommande universelle afin de connaître le code numérique cor-
respondant au téléviseur.
AIR/CABLE MODE SELECTION
SÉLECTION DU MODE AIR/CABLE
When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode.
If not using Cable TV, set this menu option to the “Air” position.
Lorsque l’appareil sort de l’usine, l’option Signal Type est en mode « Cable » (câblodistribution). Si vous
n’utilisez pas la câblodistribution, sélectionnez l’option « Air ».
Before operating the unit, please read this manual thoroughly.
Avant de faire fonctionner l’appareil, veuillez lire le présent guide attentivement.
LT-40A321
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL.
S’IL FAUT CONTACTER LE SERVICE CLIENTÈLE, PRENEZ SOIN D’ÊTRE MUNI
DU NUMÉRO DE MODÈLE AVANT D’APPELER.
CUSTOMER SERVICE – 1-800-289-0984
SERVICE/SERVICE CLIENTÈLE: 1-800-289-0984
FOR RECYCLING INFORMATION, PLEASE CONTACT CUSTOMER SERVICE.
POUR OBTENIR DES INFORMATIONS SUR RECYCLAGE, VEUILLEZ CONTACTER LE SERVICE CLIENTÈLE.
CUSTOMER SERVICE –1-800-289-0984
SERVICE/SERVICE CLIENTÈLE: 1-800-289-0984
(40” class/40.00 diagonal)
(40” classe/40,00 diagonale)
LCD TV
INSTRUCTIONS
MANUAL D’ INSTRUCTIONS
FRANÇAIS ENGLISH
Please read the important
notice for energy efficiency
on page 8.
Veuillez lire l’avis important
d’efficacité énergétique à la
page 8.
J3LF1021A_EnFr.indb 1J3LF1021A_EnFr.indb 1 2/16/12 9:31:34 AM2/16/12 9:31:34 AM

EN 2
Location of the required marking
The rating sheet and the safety caution are
on the rear of the unit.
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION:TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with the
FCC Rules could void the user's authority to operate this equipment.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY
FROM THIS PRODUCT AT TIMES.
CAUTION: TO PREVENT ELECTRIC SHOCK. DO NOT USE THIS POLARIZED PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.
The lamp(s) within this product contain
mercury.
Disposal should be in compliance with local,
state or federal laws.
Serial Number:
Model Number:
Declaration of Conformity
Model Number : LT-40A321
Trade Name : JVC
Responsible party : ORION AMERICA, INC.
Address : 1105 SOUTH MAIN STREET PRINCETON,
INDIANA 47670 U.S.A.
Telephone Number : 1-800-289-0980
This device complies with Part 15 of FCC Rules. Operation is
subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Important Note:
In the spaces below, enter the model and serial number
of your television (located at the rear of the television
cabinet). Staple your sales receipt or invoice to the inside
cover of this guide. Keep this user’s guide in a convenient
place for future reference. Keep the carton and original
packaging for future use.
J3LF1021A_EnFr.indb 2J3LF1021A_EnFr.indb 2 2/16/12 9:31:39 AM2/16/12 9:31:39 AM

3 EN
15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as
vases, should not be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits.When installing an
outside antenna system, extreme care should be taken to keep from touching such power lines or
circuits, as contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points
or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid into
the unit.
19) If an outside antenna or cable system
is connected to the unit, be sure the
antenna or cable system is grounded
to provide some protection against
voltage surges and built-up static
charges, Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides
information with respect to proper
grounding of the mast and supporting
structure, grounding of the lead-in
wire to an antenna discharge unit, size
of grounding conductors, location of
antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA LEAD IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE
IMPORTANT SAFETY INSTRUCTIONS
J3LF1021A_EnFr.indb 3J3LF1021A_EnFr.indb 3 2/16/12 9:31:40 AM2/16/12 9:31:40 AM

EN 4
IMPORTANT SAFETY INSTRUCTIONS
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and larger flat panel displays are popular
purchases. However, flat panel displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers,
chests or carts may fall over and cause injury.
THIS MANUFACTURER CARES!
The consumer electronics industry is committed to making home entertainment enjoyable and safe.
TUNE INTO SAFETY
One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of
your flat panel display.
Carefully read and understand all enclosed instructions for proper use of this product.
Don’t allow children to climb on or play with furniture and television sets.
Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.
Remember that children can become excited while watching a program, especially on a “larger than life” flat
panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or
knocked down.
Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
Use a mount that has been recommended by the display manufacturer and/or listed by an independent
laboratory (such as UL, CSA, ETL).
Follow all instructions supplied by the display and wall mount manufacturers.
If you have any doubts about your ability to safely install your flat panel display, contact your retailer about
professional installation.
Make sure that the wall where you are mounting the display is appropriate to support the weight of the unit/
product and wall mount. If you are unsure, contact a professional installer.
A minimum of two people are required for installation. Flat panel displays can be heavy.
20) When replacement parts are required, be sure the service technician uses replacement parts
specified by the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety
checks to determine that the unit is in proper operating condition.
22) When you connect the product to other equipment, turn off the power and unplug all of the
equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal
injury. Read the owner's manual of the other equipment carefully and follow the instructions when
making any connections.
23) Sudden high volume sound may cause hearing or speaker damage. When you use headphones,
(if the unit is equipped with a headphone jack) keep the volume at a moderate level. If you use
headphones continuously with high volume sound, it may cause hearing damage.
24) Do not allow the product to output distorted sound for an extended period of time. It may cause
speaker overheating and fire.
25) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the
NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close to the point of cable entry as
practical.
26) The socket-outlet must be installed near the unit and easily accessible.
J3LF1021A_EnFr.indb 4J3LF1021A_EnFr.indb 4 2/16/12 9:31:40 AM2/16/12 9:31:40 AM

5 EN
Notes when mounting the LCD TV on a wall
If the unit is to be mounted on the wall, contact the retailer where
you purchased the LCD TV for advice, and have the equipment
professionally installed. Incomplete or improper installation may
cause injury to you, and/or damage to the LCD TV.
Bracket holes:To attach a wall mounting bracket (not supplied) attach
where indicated in the drawing right.
This manufacturer recommends professional installation.
Utilize an appropriate bracket and fasteners, sufficient to
accommodate the size and weight of the unit.
Assure the wall to which the unit is to be mounted will safely support
the size and weight of the unit, using the bracket and fasteners you
have selected.
Keep cords and cables connected to this flat panel display out of
reach of children.
To hang the television on a wall, remove these screws and then
remove a stand. Before performing work spread cushioning over the
base area to lay the TV on.
•
•
•
•
•
•
•
IMPORTANT SAFETY INSTRUCTIONS
CONDENSATION
Moisture will form in the operating section of the unit if the unit is brought from cool surroundings into a warm
room or if the temperature of the room rises suddenly. When this happens, unit's performance will be impaired.
To prevent this, let the unit stand in its new surroundings for about an hour before switching it on, or make sure
that the room temperature rises gradually.
Condensation may also form during the summer if the unit is exposed to the breeze from an air conditioner. In
such cases, change the location of the unit.
HOW TO HANDLE THE LCD PANEL
Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.
If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel.This may cause
skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your
eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.
Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for
long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but
permanent ghost images.This type of damage is NOT COVERED BYYOUR WARRANTY. Never leave your
LCD Panel on for long periods of time while it is displaying the following formats or images:
Fixed images, such as stock tickers, video game patterns, TV station logos, and websites.
Special formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a
widescreen (16:9) display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any
responsibility for these symptoms.
LCD Panels are manufactured using an extremely high level of precision technology, however sometimes
parts of the screen may be missing picture elements or have luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that produces electromagnetic waves. Some
equipment placed too near this unit may cause interference.
Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless
headphones.
•
•
•
•
•
•
•
SAFETY PRECAUTIONS
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating.
Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine.When placing on a shelf leave 4 inches
(10 cm) free space around the entire unit.
Bracket holes
20 cm
(8 inches)
M6 × 10
20 cm
(8 inches)
10 cm
(4 inches)
10 cm (4 inches)
Screws
J3LF1021A_EnFr.indb 5J3LF1021A_EnFr.indb 5 2/16/12 9:31:40 AM2/16/12 9:31:40 AM

EN 6
How to attach the stand
LCD PANEL SIDE
NOTE:
• Unplug the AC cord from the AC INPUT terminal.
• Before beginning this process, assure that the TV is laid on a clean, safe, and cushioned surface to avoid
any damage to the unit.
• Do not touch or press the TV-screen, glass might break under pressure.
Place the TV on its front onto a table.
Align the stand’s bottom-plate (supplied) as seen here.
It will fit in only one direction.
Hold the unit and attach the stand frame (a) slowly and secure the stand frame (a) with the 3 screws
(supplied) (4x35mm(5/32x1-23/64 inches)), as shown in figure 1.
Finally secure the bottom-plate (b) with 3 screws (supplied) (4x12mm(5/32 x 15/32 inches)) as indicated by the
arrows in figure 2.
Be sure to follow the instructions. Insufficient tightening or incorrect installation of the stand will not support
your unit correctly, and could result in damage or injury from tip-over.
•
How to remove the stand
When you transport this product, remove the stand and pack flat against the back of the unit in the carton. To
remove the stand, perform these steps in reverse order.
For wall mounting, the base must be removed.To disconnect the base/stand remove the 3 screws from the back
(see page 5).
Figure 1
Figure 2
(a)
(b)
(b)
J3LF1021A_EnFr.indb 6J3LF1021A_EnFr.indb 6 2/16/12 9:31:43 AM2/16/12 9:31:43 AM

7 EN
Features
Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box.
Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for
hearing impaired viewers.
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control
adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Programmable TV Sleep Timer - Operable from the remote control, the LCD TV can be programmed for up
to 120 minutes to turn off automatically.
Digital Audio Jack (Coaxial) - When a component with a built-in Dolby Digital decoder is connected, Dolby
Digital sound can produce the effect of being in a movie theater or a concert hall.
HDMI/Component Video Jacks - A VCR, DVD player, satellite receiver or other audio/video component can
be connected to this unit.
On-Screen 3 Languages Display - You can select one of 3 languages, English, French or Spanish for on-
screen programming.
•
•
•
•
•
•
•
NOTE:
Please make sure to insert the cord securely at both the LCD TV and the wall outlet.
The AC cord has a polarized type AC line plug. If the supplied AC cord does not match your AC outlet, contact
a qualified electrician.
WARNING:
DO NOT CONNECT THIS UNIT TO THE POWER USING ANY DEVICE OTHER THAN THE SUPPLIED AC
CORD.THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE.
DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE SPECIFIED.THIS COULD CAUSE
FIRE, ELECTRICAL SHOCK, OR DAMAGE.
CAUTION:
WHEN THIS UNIT IS NOT USED FOR A LONG TIME, (E.G., AWAY ON A TRIP) IN THE INTEREST OF
SAFETY, BE SURE TO UNPLUG IT FROM THE AC OUTLET.
DO NOT PLUG/UNPLUG THE AC CORD WHEN YOUR HANDS ARE WET.THIS MAY CAUSE ELECTRICAL
SHOCK.
IF YOU NEED TO REPLACE THE SUPPLIED AC ADAPTER OR AC CORD, THE SPECIFIED ONE IS
RECOMMENDED. CONTACT CUSTOMER SERVICE AT 1-800-289-0984.
•
•
•
•
•
•
•
Power source
TO USE AC POWER
Connect the AC cord plug into this unit’s AC INPUT jack.
Connect the AC cord into an AC outlet.
1.
2.
AC cord (supplied)
AC 120V, 60Hz
Wider Hole
and Blade
AC outlet
J3LF1021A_EnFr.indb 7J3LF1021A_EnFr.indb 7 2/16/12 9:31:44 AM2/16/12 9:31:44 AM

EN 8
Contents
Before using your unit
IMPORTANT SAFETY INSTRUCTIONS...........3
SAFETY PRECAUTIONS .................................5
How to attach the stand ....................................6
How to remove the stand ..................................6
Features............................................................7
Power source ....................................................7
Contents ...........................................................8
Logos & Licenses .............................................8
Parts and functions ...........................................9
Remote control ...............................................10
Antenna connections ......................................11
Cable TV connections.....................................11
Connections to other equipment.....................12
TV operation
Starting setup .................................................15
TV operation ...................................................15
Quick guide for menu operation......................16
Convenience functions ...................................17
Memorizing channels......................................18
Checking the digital signal strength ................19
Labeling channels...........................................19
Labeling video inputs......................................19
Closed Caption...............................................20
CC advanced..................................................20
Setting the picture size....................................21
Time Shift........................................................22
Additional information
Reception disturbances ..................................23
Troubleshooting ..............................................24
Specifications ................................................25
limited WARRANTY ........................................26
Logos & Licenses
Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
Enabling certain features and functionality in this TV (e.g., Reset, DBC)
may increase its energy consumption, possibly beyond the limits required
for ENERGY STAR®qualification.
J3LF1021A_EnFr.indb 8J3LF1021A_EnFr.indb 8 2/16/12 9:31:45 AM2/16/12 9:31:45 AM

9 EN
Parts and functions
Left sideFront
Remote sensor
POWER ()button
INPUT/ENTER button
VOL (VOLUME) +/–buttons
CH (CHANNEL)
/ buttons
MENU button
Rear
Press MENU button to display the menu screen.
CH (CHANNEL) / buttons,
VOL (VOLUME)
+/– buttons and INPUT/ENTER button can be used
to select the desired setting during the menu screen
operations.
PC/DVI AUDIO IN jack
VIDEO1 IN jacks (VIDEO/AUDIO (R/L(MONO)))
HDMI2 IN jack
PC MONITOR IN jack
AC INPUT jack
ANT. (RF)IN jack
Power Indicator
Red : Standby
Green : On
HDMI1/DVI IN jack
DIGITAL AUDIO
COAXIAL OUT jack
VIDEO2 IN jacks
(VIDEO/AUDIO (L (MONO)/R))
VAR.(VARIABLE)AUDIO (R/L)OUT jacks
HDMI3 IN jack
USB input
COMPONENT IN jacks
Left side
J3LF1021A_EnFr.indb 9J3LF1021A_EnFr.indb 9 2/16/12 9:31:46 AM2/16/12 9:31:46 AM

EN 10
Remote control
3
12
6
1
5
4
HOW TO INSTALL BATTERIES
1. Open the battery compartment cover.
2. Install two “AAA” batteries (supplied).
3. Replace the battery compartment cover.
Before using the remote control, batteries must first be installed.
Use two “AAA” size batteries.The batteries may last
approximately one year depending on how much the
remote control is used. For best performance, it is
recommended that batteries should be replaced on a
yearly basis, or when the remote operation becomes
erratic. Do not mix old and new batteries or different
types.
BATTERY PRECAUTIONS
These precautions should be followed when using
batteries in this device:
Use only the size and type of batteries specified.
Be sure to follow the correct polarity when
installing the batteries as indicated in the battery
compartment. Reversed batteries may cause
damage to the device.
Do not mix different types of batteries together
(e.g. Alkaline, Carbon-zinc or Rechargeable) or old
batteries with fresh ones.
If the device is not to be used for a long period of
time, remove the batteries to prevent damage or
injury from possible battery leakage.
Do not try to recharge batteries not intended to be
recharged; they can overheat and rupture. (Follow
battery manufacturer’s directions.)
•
•
•
•
•
1.POWER Button - Use to turn the power on/off to
the LCD TV.
2.DISPLAY Button - When you press this button,
the current information will be displayed on a
screen.To remove the display from the screen,
press this button again.
3.Direct Channel Selection Buttons (0-9) - Allows
direct access to any channel of the LCD TV.
4.–Button -This button is used when selecting
digital channels.
5.MENU Button - Use to display the On-Screen
menu function.
6.
CURSOR ▲/▼/◀/▶ Buttons -Use to operate the
menu functions of the LCD TV.
7.ENTER Button - Use to enter or select
information for On-Screen operations.
8.MUTING Button - To turn off the sound, press
this button once.The LCD TV will be silenced and
the symbol “Muting” will appear on the screen.
The muting feature can be released by pressing
the MUTING button again or one of the VOL
(VOLUME) +or –buttons.
9.VOL (VOLUME) + / –Buttons - Press the +
button to increase, or the –button to decrease the
sound level.
10.INPUT SELECT Button - Use to change the
external input.
11.CCD Button - Use to display the Closed Caption
menu screen.
12.SLEEP Button - To set the LCD TV to turn off
after a preset amount of time, use the SLEEP
button on the remote control.
13.PICTURE SIZE Button - Use to change the
picture size.
14.RECALL Button - This button allows you to go
back to the previous channel selected by just
pressing the RECALL button. Press this button
again to return to the channel you were watching.
15.EXIT Button - Press to remove setup menu.
16.AUDIO Button - Change soundtrack language.
17.CH (CHANNEL) / Buttons - To change the
channels of the LCD TV.
18.Time Shift control Buttons - See page 22.
8
9
7 16
17
2
10
11
13
14
15
18
If this symbol is shown, it is only
valid in the European union.
J3LF1021A_EnFr.indb 10J3LF1021A_EnFr.indb 10 2/16/12 9:31:47 AM2/16/12 9:31:47 AM

11 EN
Antenna connections
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your
antenna system. If you are using a Cable TV service, see “Cable TV connections”.
Combination VHF/UHF Antenna (Single 75 ohms cable)
Antenna
Jack
75 ohms
Coaxial
Cable
Connect the 75 ohms cable from the combination
VHF/UHF antenna to the Antenna Jack.
Cable TV connections
For basic Cable TV service not requiring a Converter/
Descrambler box, connect the 75 ohms Coaxial Cable directly
to the Antenna Jack on the back of the TV.
For subscribers to scrambled Cable TV service
If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect
the incoming 75 ohms Coaxial Cable to the Converter/Descrambler box. Using another 75 ohms Coaxial
Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the
connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel
3 or 4) and use the Converter/Descrambler box to select channels.
For subscribers to unscrambled Cable TV service with scrambled premium channels
If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require
the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available
from the Cable TV company or an electronics supply store). Follow the connections shown below.With the
switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the
“A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the
Converter/Descrambler box to tune scrambled channels.
This TV has an extended tuning range and can tune most cable channels without using a Cable TV
Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled.
Descrambling these signals for normal viewing requires the use of a descrambler device which is
generally provided by the Cable TV company.
For subscribers to basic Cable TV service
Incoming
75 ohms
Cable TV
Cable 75 ohms Cable to TV
Antenna
Jack
Converter/
Descrambler
Splitter B
A
Incoming
75 ohms
Cable TV
Cable A/B Switch 75 ohms Cable to TV
Converter/
Descrambler Antenna
Jack
Antenna
Jack
75 ohms
Coaxial
Cable
J3LF1021A_EnFr.indb 11J3LF1021A_EnFr.indb 11 2/16/12 9:31:48 AM2/16/12 9:31:48 AM

EN 12
The exact arrangement you use to interconnect various video and audio components to this unit is dependent
on the model and features of each component. Check the Owner’s Manual provided with each component for
the location of video and audio inputs and outputs.
To connect the TV to a VCR
Connections to other equipment
To connect the TV to a DVD player with Component Video Input
You can enjoy a high quality picture by connecting the unit’s COMPONENT VIDEO OUT jacks of your DVD
player with the component video cables (not supplied).
NOTE:
Component Video input of the unit are for use with a device which output 480i/1080i interlaced signals and
480p/720p progressive signals.
•
To connect the TV to a camcorder, or a game console
To playback from a camcorder, connect the camcorder to the unit as shown.
This unit can also be used as a display device for many video games. However, due to the wide variety of
signals generated by these devices and subsequent hook-up variations required, they have not all been
included in the suggested connection diagrams.You’ll need to consult each component’s Owner’s Manual for
additional information.
GAME CONSOLE
or
Y
Pb
Pr
Y
Pb
Pr
Rear of the unit
To Video/Audio OUT
Video/Audio cord (not supplied)
To VIDEO/AUDIO IN
To Component OUT
Audio cord (not supplied)
Component video cord
(not supplied)
To AUDIO IN
Left of the unit
To COMPONENT IN
To Audio OUT
VCR
DVD
Rear of the unit
Video/Audio cord (not supplied)
To VIDEO/AUDIO IN
To Video/Audio OUT
J3LF1021A_EnFr.indb 12J3LF1021A_EnFr.indb 12 2/16/12 9:31:49 AM2/16/12 9:31:49 AM

13 EN
Connections to other equipment
Using an AV Amplifier with built-in digital surround
If you are using an AV Amplifier with built-in digital surround sound, you can enjoy various audio systems including
Dolby Digital Surround audio that sounds just like the movie.
Connect an AV amplifier with built-in Dolby Digital decoder, etc. as shown below.
NOTE:
When you are viewing digital broadcast, this unit will not work in conjunction with DTS audio or MPEG audio.
There will be no sound output if connected to an AV amplifier with a built-in DTS decoder or MPEG decoder.
•
Coaxial digital cable
(not supplied)
AV Amplifier with built-in digital surround
decoder as listed above
Center Speaker
To DIGITAL AUDIO
COAXIAL OUT
To Coaxial
Digital Audio Input
Rear of the unit
Front
Speaker
(Left)
Front
Speaker
(Right)
Subwoofer
Surround
Speaker (Left) Surround
Speaker
(Right)
TV
To connect the TV to a PC (Personal Computer)
BEFORE YOU CONNECT THIS TV TO YOUR PC, CHANGE THE ADJUSTMENT OF YOUR PC’S
RESOLUTION AND REFRESH RATE (60 HZ).
Connect one end of a (male to male) VGA cable to the video cord of the computer and the other end to the
VGA
connector PC MONITOR IN on the rear of the TV . Attach the connectors firmly with the screws on the plug. In
case of a Multimedia computer, connect the audio cord to the audio output of your Multimedia computer and to
the AUDIO IN connector of the PC/DVI AUDIO IN jack of the TV.You can also connect the PC with HDMI cable.
If you use HDMI cable, you don’t have to connect the audio cord. If you use DVI-to-HDMI cable, please connect
audio cord as same way as VGA cable.
Press INPUT SELECT on the remote control to select PC mode.
Switch on the computer. The TV can operate as the computer monitor. Monitor Display modes
Mode Resolution Refresh rate
VGA 640x480 60/ 72/ 75 Hz
VGA 720x400 70Hz
SVGA 800x600 56/ 60/ 72/ 75 Hz
XGA 1024x768 60/ 70/ 75 Hz
WXGA 1280x768 60Hz
WXGA 1360x768 60Hz
SXGA 1280x1024 60Hz
WXGA+ 1440x900 60Hz
FHD 1920x1080 60Hz
To return to normal mode
Press INPUT SELECT again.
NOTE:
The on-screen displays will have a different appearance in PC mode than in TV mode.
If there is no video signal from the PC when the unit is in PC mode, “No signal” will appear on the TV-screen.
When the PC connected to the HDMI terminal and 1920x1080 resolution (FHD) is selected, the top and bottom,
right and left edges of the picture may be hidden on all picture sizes. In this case, use the PC MONITOR IN jack
(VGA cable) is recommended to connect.
When the PC’s resolution is set to 1920 x 1080/60 Hz (FHD mode), a signal that differs from the FHD signal,
which has been confirmed operational on this TV, may appear depending on the PC used. In this case, “Auto
Adjust” or other Position Adjustment functions may fail to correct the image position.
To solve this problem, change the PC settings to select another resolution.
•
•
•
•
VGA cable (not supplied)
HDMI cable (not supplied)
Rear and Left of the unit
Audio cord (not supplied)
To HDMI IN
To
PC/DVI
AUDIO
IN
To PC
MONITOR
IN
J3LF1021A_EnFr.indb 13J3LF1021A_EnFr.indb 13 2/16/12 9:31:49 AM2/16/12 9:31:49 AM

EN 14
Rear and Left of the unit
HDMI - to - DVI adapter cable
(HDMI type A connector)
(not supplied)
Audio cord (not supplied)
HDMI cable (type A connector)
(not supplied)
To DVI output
To HDMI output
HDMI device
DVI device
To HDMI IN
To PC/DVI AUDIO IN
or
To connect a HDMI or a DVI device to the unit
The HDMI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital
video from a DVI device.
When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate
analog audio cords required.
Connections to other equipment
NOTE:
When using HDMI1/DVI IN to connect your HDMI or DVI devices, you must select the corresponding
audio input source (HDMI or DVI) on the menu screen (see page 17). Otherwise you will only see the
image with no sound.
•
To connect an audio system
This connection allows you to use an audio amplifier and external speakers, and adjust the audio level using the
TV’s remote control.
To control the audio, turn on the TV and the stereo amplifier, and turn off the TV’s built-in speakers (see page 17).
NOTE:
To hear sound when using an external audio amplifier, the volume of both the TV and the amplifier must be set
above 0 (zero).
For example, if the volume of the TV is set to 0, you will not be able to hear any sound, even if the volume of the
amplifier is at its highest level.
•
•
To Audio (L) Input To Audio (R) Input
Audio cord (not supplied)
Amplifier
Rear of the unit
To VAR. (VARIABLE)
AUDIO (R/L) OUT
The audio output from the devices connected by HDMI may not output the sound from the audio output jacks
of this unit for copyright protection.
In details, please check the table below.
•
Audio Out
Content Digital Analog
SACD/DVD-Audio Prohibited Available*
Others
Available* Prohibited
* Depening on devices, the sound may not be output.
J3LF1021A_EnFr.indb 14J3LF1021A_EnFr.indb 14 2/16/12 9:31:50 AM2/16/12 9:31:50 AM

15 EN
Starting setup
The Auto Setup menu appears the first time you
turn on the TV, and assists you to specify the
Air/Cable setting, and program your channels
automatically.
IMPORTANT: Make sure that the antenna or cable
TV system connection is made!
1To turn on the TV, press (POWER). (POWER
indicator on the front of the unit changes green.
It may take approx. 10 seconds for a picture to
appear on screen.).The Auto Setup function
begins.
Auto Setup
Automatic Search Start
E-POP Demo Off
TV Location Store
Signal Type Cable
2Press ▲or ▼to select “TV Location”, then press
◀or ▶to select “Store” or “Home”.This product
qualifies for ENERGY STAR in Home mode
default setting.
NOTE:
This unit has been preset to STORE brightness.
This setting does not qualify under ENERGY
STAR. To reduce brightness and energy
consumption, change setting to ‘HOME’. This
setting does qualify under ENERGY STAR.
The device may not conform to the ENERGY
STAR standard after Reset is performed or the
DBC is adjusted.
•
•
3Press ▲or ▼to select “E-POP Demo”, then press
◀or ▶to select “On” or “Off”.
On: A TV feature introduction will be popped up
at the bottom of the screen.
Off: Turn off the E-POP Demo feature.
4Press ▲or ▼to select “Signal Type”, then press
◀or ▶to select “Cable” or “Air”.
5Press ▲or ▼to select “Automatic Search”, then
press ▶or ENTER.
6“Auto Setup” will begin. After the Auto Setup
is completed, the TV channel appears on the
screen.
Depending on the reception condition, it may
take up to 30 minutes to complete memorizing
digital cable channels. Please allow the
process to complete without interruption.
•
NOTE:
If you press EXIT in the process of “Auto Setup”, the Auto
Setup stops and changes to the normal screen.
When you make a menu selection, your changes occur
immediately.You do not have to press EXIT to see your
changes.
TV operation
1To turn on the TV, press (POWER).
(POWER indicator on the front of the unit
changes green. It may take approx. 10 seconds
for a picture to appear on screen.)
•
•
2Adjust the volume level by pressing VOL + or –.
The volume level will be indicated on the screen
by green bars. As the volume level increases, so
do the number of bars. If the volume decreases,
the number of green bars also decreases.
3Set the Signal Type option to the appropriate
position (see “Air/Cable selection” on page 18).
4Press the Direct Channel Selection (0-9, –)
buttons to select the channel.
(If you press only channel number, channel
selection will be delayed for a few seconds.)
TO SELECT ANALOG CHANNELS
1-9: Press 1-9 as needed. Example, to
select channel 2, press 2, then press
ENTER.
10-99: Press the 2 digits in order. Example,
to select channel 12, press 1, 2, then
press ENTER.
100-135: Press the 3 digits in order. Example, to
select channel 120, press 1, 2, 0, then
press ENTER.
TO SELECT DIGITAL CHANNELS
Press the first 1-3 digits, then press the –button,
followed by the remaining number.
Example, to select channel 15-1, press 1,5,–, 1,
then press ENTER.
If a channel is selected with only audio content,
“Audio only” will be displayed on the screen.
If a channel is selected with a weak digital
signal, “Digital channel signal strength is low”
will be displayed on the screen.
The same program may be available on either
an analog channel or a digital channel.You may
choose to watch either format.
If a channel is selected to which you have not
subscribed,
“Digital channel is encrypted” will
be displayed on the screen.
•
•
•
VHF/UHF/CABLE CHANNELS
Air Cable
VHF
2-13 VHF 2-13
UHF
14-69 STD/HRC/IRC 14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-135 (100) (135)
01 (4A)
NOTE:
If a channel with no broadcast is selected, the sound will
automatically be muted.
It may take a few seconds for a digital channel picture to
appear on screen after being selected.
To select the video input source
To view a signal from another device connected to
your LCD TV, such as a VCR player, press INPUT
SELECT, then press ▲or ▼or corresponding
Number buttons (0-7), then press ENTER.
Input Select
0.TV
1.Video1
3.Component
2.Video2
4.HDMI1
[0-7]:Select
5.HDMI2
6.HDMI3
7.PC
•
•
J3LF1021A_EnFr.indb 15J3LF1021A_EnFr.indb 15 2/16/12 9:31:50 AM2/16/12 9:31:50 AM

EN 16
CH /
Press and release CH / .The channel
automatically stops at the next channel set into
memory.For proper operation, before selecting
channels, they should be set into the memory. See
“Memorizing channels” on page 18.
DISPLAY
Press DISPLAY to display the current information on
the screen.
When the TV receives a digital signal, the digital
information will appear.
62-1 HDTV_Moving_Picture...
CH-1
Digital Air
No Program Information is available
Sleep Timer
Off
English
Full
1080i
USB Memory Information
Play Time
Message : Now LiveView
USB Memory is unplugged
: --:--:--
Channel number• Broadcast program name •
Channel label (if preset)• Signal type•
Sleep timer• Audio language•
Program guide• Picture size•
Resolution• Time Shift display•
Station name•
When the TV receives an analog signal, the analog
information will appear.
14
Analog Cable
Sleep Timer
Off
Mono
Full
480i
Channel number• Signal type•
Sleep timer• Picture size•
Audio information
(Stereo, SAP or Mono)
• Resolution•
Channel label (if preset)•
Press DISPLAY again to clear the call display.
NOTE:
After a few seconds, DISPLAY screen will return to
normal TV operation automatically.
SLEEP
To set the TV to turn off after a preset amount of time,
press SLEEP on the remote control.The clock will
count up 10 minutes for each press of the SLEEP
button (Off, 0h 10m, 0h 20m, ..., 2h 0m). After the sleep
time is programmed, the display will appear briefly
every ten minutes to remind you that the sleep timer
is operating.To confirm the sleep timer setting, press
SLEEP and the remaining time will be displayed for a
few seconds.To cancel the sleep timer, press SLEEP
repeatedly until the display turns to Off.
•
Quick guide for menu
operation
Call menu and for example: Select Language.
1Press INPUT SELECT to select TV mode.
2Press MENU.The TV menu screen will appear.
Audio
Channel
Setup
Main Menu
Picture >>
ENTER :Set:Select
CH
3Press ▲or ▼to select “Setup”, then press ▶or
ENTER.
4Press ▲or ▼to select “Language”, then press ◀
or ▶to select the desired language.
…on the following pages the menu can be called
in the same way as here.
5Press EXIT to return to the normal screen.
NOTE:
If no buttons are pressed for more than about 60
seconds, the menu screen will return to normal
operation automatically.
•
J3LF1021A_EnFr.indb 16J3LF1021A_EnFr.indb 16 2/16/12 9:31:51 AM2/16/12 9:31:51 AM

17 EN
Convenience functions
You can change the default settings by pressing the MENU button on your remote, then select the one of the icons at the left
of the menu - follow the On-Screen prompts to set your preferences.
Icon Selected Items Setup hint
Picture Picture
Preference Sports Bright and dynamic picture (factory-set)
Standard Standard picture quality (factory-set)
Movie Movie-like picture setting (factory-set)
Memory Your personal preferences (set by you; see “Picture Setting”)
Picture Setting Brightness /Contrast /
Sharpness / Color / Tint You can adjust the picture quality to your preference.
Color Temperature Cool (Bluish) / Standard (Neutral) / Warm (Reddish)
DBC*2On/Eco/Off
Use this feature to change the Black level automatically according to the
brightness of an image.The Black level will become dark in a dark scene. If “Eco”
is selected, the power consumption is reduced and “Backlight” will be skipped.
Backlight The Backlight feature adjusts the screen brightness for improved
picture clarity.
Picture Size See page 21.
Film Mode On/Off
A smoother motion may be obtained by setting the Film Mode to “On” (480i only).
PC Setting Hor Position /
Ver Position
To adjust the horizontal / vertical position of the image on the PC monitor
screen. Each video standard will require a different value for this setting.
Clock To minimize any vertical bars or stripes visible on the screen background.
Phase This must be adjusted after the frequency has been set optimize picture quality.
Auto Adjust To adjust the all PC settings automatically.
DNR On/Off DNR (Digital Noise Reduction) can reduce the roughness of the picture.
Audio
Equalizer Mode Standard/Music/Movie/
News/Memory/Flat You can adjust the Equalizer Mode to your preference.
Audio Setting Bass/Treble You can adjust the sound quality to your preference. (Flat mode only)
Equalizer Setting 100Hz/250Hz/500Hz/1kHz/2kHz/4kHz/10kHz (Not available in Flat mode)
Balance You can adjust the sound quality to your preference.
MTS Stereo / SAP / Mono The multi-channel TV sound (MTS) feature provides high-fidelity
stereo sound. MTS also can transmit a second audio program (SAP)
containing a second language or other audio information.
Surround On/Off The dynamic presence and sound created offers a thoroughly
enjoyable listening experience.
Auto Volume On/Off Volume level can be adjusted automatically by the sound level.
Audio Language
When two or more audio languages are included in a digital signal, you can select
one of the audio languages.(This function is available only for digital broadcast.)
HDMI1 Audio HDMI When you connect the HDMI device to the TV, select this setting.
DVI When you connect the DVI device to the TV with analog audio cords,
select this setting.
Speakers On/Off
Use this feature to turn theTV speakers off when you connect an audio system.
Channel Add / Delete See page 18.
DTV Signal See page 19.
Auto Ch Memory See page 18.
Ch Label See page 19.
Setup Closed Caption See page 20.
Language
You can choose from three different languages (English, Français (French) and
Español (Spanish)) for the on-screen displays.
Select the language you prefer first, then proceed with the other menu options.
Video Label See page 19.
On Timer Off / 0h30m / 1h00m
/ 1h30m / 2h00m /
3h00m⋅⋅⋅12h00m
You can set the On Timer to automatically turn on the TV.To cancel the
On Timer select “Off”.
Auto Shut
Off*1On/Off If the Auto Shut Off feature is On, a station being viewed stops
broadcasting and the TV is not operated, the TV will automatically shut
itself off after 15 minutes.
Auto Setup See page 15.
PC Standby On/Off
In PC mode, if no signal is received or no operation performed for 1
minute, the TV will turn to standby mode automatically (LED light will
flash red).When an input signal is received or an operation performed
on the PC, the TV will return to the On mode.
Reset The Reset function returns your Picture/Audio settings to the factory settings.
“Picture Size”, “MTS” , “Audio Language”, “HDMI1 Audio” and “Speakers”
cannot be reset by this function.
NOTE:
*
1
If there is no input signal in the PC mode, after 1 minute Auto Shut Off will be activated. In PC mode the “PC Standby”
setting takes precedence.
*
2
The device may not conform to the Energy Star standard after Reset is performed or the DBC is adjusted.
J3LF1021A_EnFr.indb 17J3LF1021A_EnFr.indb 17 2/16/12 9:31:52 AM2/16/12 9:31:52 AM

EN 18
Memorizing channels
This TV is equipped with a channel memory
feature which allows channels to skip up or down
to the next channel set into memory, skipping
over unwanted channels. Before selecting
channels, they must be programmed into the
TV’s memory. To use this TV with an antenna, set
the Signal Type option to the Air mode. When
shipped from the factory, this menu option is in
the Cable mode.
Air/Cable selection
1Select “Channel ⇒Auto Ch Memory ⇒Signal
Type”.
2Press ◀or ▶to select “Air” or “Cable”.
Air - VHF/UHF channels
Cable - CABLE TV channels
Automatic Search Start
Auto Ch Memory
Signal Type Cable
CH
NOTE:
It may take a few seconds for a digital channel
picture to appear on screen after being selected.
Automatic Search
1Select “Channel ⇒
Auto Ch Memory ⇒Automatic
Search”, then press ▶or ENTER.
Auto Ch Memory
Signal Type Cable
Automatic Search Stop
CH
2The TV will begin memorizing all the channels
available in your area.
It may take from 15 minutes to 30 minutes to
complete memorizing digital cable channels.
Depending on the reception condition, a bar
display may not advance for several minutes,
please be patient.
•
NOTE:
Memorizing channels is best accomplished during
evening “PRIMETIME” hours, as more stations are
broadcasting digital signals. Memorizing channels can
only be accomplished while a station is broadcasting
a digital signal to set that channel into memory.
If you are unsure of the digital channels available
in your area, you may visit www.antennaweb.org to
receive a list based on your address or zip code.
Should you require further assistance you may call
our toll-free customer service line at 1-800-289-0984.
New digital channels may be added to your area
periodically, it is recommended to perform the
“Automatic Search” procedure regularly.
•
•
•
•
Adding Channel
If you find a new digital channel unregistered, you can
add the new channel into the channel memory.
1Tune in the new channel.
2Select “Channel ⇒Add/Delete ⇒Adding
Channel”, then press ▶or ENTER.
Add/Delete
Adding Channel >>
Clear All >>
Add/Delete >>
CH
3The new channel will be added into the channel
memory.
Add/Delete channel
You can select the channel that you want to skip.
1Select “Channel ⇒Add/Delete ⇒Add/Delete”,
then press ▶or ENTER.
2Press ▲or ▼to select the channel that you want
to skip.
CH Signal
2 Analog
3
3-1
3-2
Analog Add
Digital Delete
Digital Add
4 Analog Delete
Add/Delete
Add
CH
3Press ◀or ▶to select “Add” or “Delete”,
whichever function you want to perform.
4Repeat steps 2 - 3 for other channels you want to
add or delete.
Clear All
All channels are deleted from the channel memory.
Select “Channel ⇒Add/Delete ⇒Clear All”, then
press ▶or ENTER.
Add/Delete
Adding Channel >>
Clear All >>
Add/Delete >>
CH
J3LF1021A_EnFr.indb 18J3LF1021A_EnFr.indb 18 2/16/12 9:31:52 AM2/16/12 9:31:52 AM

19 EN
Checking the digital
signal strength
This TV will allow you to view the digital signal
meter for digital channels.
1Select “Channel ⇒DTV Signal”, then press ▶or
ENTER.
2The digital signal strength screen will appear.
If necessary, adjust the direction of the antenna to
obtain the maximum signal strength.
Signal Level
0 50 100
DTV Signal
CH
NOTE:
Signal meter feature is not available for analog
channels.
After 240 seconds, DTV Signal screen will return to
normal TV operation automatically.
•
•
Labeling channels
Channel label appear with the channel number
display each time you turn on the TV, select a
channel, or press DISPLAY.
You can choose any four characters to identify a
channel.
To create channel labels
1Select “Channel ⇒Ch Label”, then press ▶or
ENTER.
2Press ◀or ▶to select a channel you want to
label, then press ▼.
Ch Label
Label Clear
>>
Ch Label
Channel Number
15-1
CH-1
CH
3Press ◀or ▶repeatedly until the character you
want appears in the first space.
Label Clear >>
Ch Label
Channel Number 15-1
Ch Label CH-1
CH
The characters rotation as follows:
SPACE
-
, () @ / + = -
If the character which you desire appears, press
ENTER.
Repeat this step to enter the rest of the characters.
If you would like a blank space in the label name,
you must choose the empty space from the list of
characters.
4Repeat steps 2-3 for other channel.You can
assign a label to each channel.
5When you finish inputting the label name, press
EXIT to return to the normal screen.
To clear a Ch Label
After step 2 above, press ▲or ▼to select “Label
Clear”, then press ▶or ENTER.
NOTE:
The channel labels will be reset after “Automatic
Search” on page 18.
Labeling video inputs
The Video Label feature allows you to label each
input source for your TV.
1Select “Setup ⇒Video Label”, then press ▶or
ENTER.
2Press ▲or ▼to select an input which you want to
label.
3Press ◀or ▶to select the desired label for that
input source.
Video 2 -
Component -
HDMI 1 -
Video Label
Video 1
HDMI 2 -
HDMI 3 -
PC -
-
–/ VCR / DVD / STB / Cable / Satellite / Receiver /
Game / Camcorder / PC / DVI PC / Blu-ray
•
J3LF1021A_EnFr.indb 19J3LF1021A_EnFr.indb 19 2/16/12 9:31:53 AM2/16/12 9:31:53 AM

EN 20
Closed Caption
WHAT IS CLOSED CAPTIONING?
This television has the capability to decode and
display Closed Captioned television programs. Closed
Captioning will display text on the screen for hearing
impaired viewers or it will translate and display text in
another language.
Captions: This Closed Caption mode will display
text on the screen in English or another language.
Generally, Closed Captions in English are transmitted
on C1 and Closed Captions in other languages are
transmitted on C2.
Text: The Text Closed Caption mode will usually fill
1/2 of the screen with a programming schedule or
other information.
1
Select “Setup ⇒Closed Caption”, then press ▶or ENTER.
2Press ◀or ▶to set “CC Setting” to “On”.
On: Captions will be displayed on the screen.
Off: Captions will not be displayed on the screen.
3Press ▲or ▼to select “Analog Caption” or “Digital
Caption”.
When you select “Analog Caption”, you can
choose from C1, C2, C3, C4, T1, T2, T3 and T4.
When you select “Digital Caption”, you can
choose from CS1, CS2, CS3, CS4, CS5 and CS6.
4Press ◀or ▶to select the desired Closed
Caption mode for both Digital and Analog Caption.
5Press ▲or ▼to select “CC Priority”, then press
◀or ▶to select “Digital CC” or “Analog CC”.
NOTE:
Depending on the broadcast signal, some
Analog Captions will function with a Digital
broadcast signal.This step prevent that two
kind of captions are overlapping.
•
NOTE:
If the program or video you selected is not closed-
captioned, no captions will display on-screen.
If text is not available in your viewing area, a black
rectangle may appear on-screen. If this happens,
set the CC Setting to “Off”.
When selecting Closed Captions, the captioning will
be delayed approx. 10 seconds.
If no caption signal is received, no captions will appear,
but the television will remain in the Caption mode.
Misspellings or unusual characters may
occasionally appear during Closed Captioning.
This is normal with Closed Captioning, especially
with live programs.This is because during live
programs, captions are also entered live.These
transmissions do not allow time for editing.
When Captions are being displayed, on-screen
displays, such as volume and mute may be seen
but may interfere with Closed Captions.
Some cable systems and copy protection systems
may interfere with the Closed Captioned signal.
If using an indoor antenna or if TV reception is very
poor, the closed caption decoder may not appear or
may appear with strange characters or misspelled
words. In this case, adjust the antenna for better
reception or use an outdoor antenna.
Closed Caption menu also can be displayed by
pressing CCD on the remote control.
•
•
•
•
•
•
•
•
•
CC advanced
When you have selected “Custom” as the display
method, you can adjust the various setting listed
below as follows:
This feature is designed to customize Digital Caption
only.
1Select “Setup ⇒Closed Caption”, then press ▶or
ENTER.
2Press ◀or ▶to set “CC Setting” to “On”.
3Press ▲or ▼to select “Digital CC Preset”, then
press ◀or ▶to select “Custom”.
4Press ▲or ▼to select “CC Advanced”, then
press ▶or ENTER.
The CC Advanced menu will appear.
5Press ▲or ▼to select the desired item, then
press ◀or ▶to change the setting.
CC Advanced
Te x t S i z e A u t o
Text Type Auto
Text Edge Auto
Text Color Auto
Text Opacity Auto
Background Color Auto
Background Opacity Auto
You can select from among the following items
and parameters.
Text Size: Auto, Small, Standard, Large
Text Type: Auto, Style1, Style2, Style3, Style4,
Style5, Style6, Style7
Text Edge: Auto, None, Raised, Depressed,
Uniform, Left Shadow, Right
Shadow
Text Color: Auto, Black, White, Red, Green,
Blue,Yellow, Magenta, Cyan
Text Opacity: Auto, Solid, Transparent,
Translucent, Flashing
Background
Color: Auto, Black, White, Red, Green, Blue,Yellow, Magenta, Cyan
Background
Opacity: Auto, Solid, Transparent, Translucent, Flashing
NOTE:
You cannot set both “Text Color” and “Background
Color” as a same color.
You cannot set both “Text Opacity” and
“Background Opacity” to “Transparent”.
•
•
J3LF1021A_EnFr.indb 20J3LF1021A_EnFr.indb 20 2/16/12 9:31:54 AM2/16/12 9:31:54 AM
