JVC LT-49C898 User manual

Instruction Manual
49" LED Smart 4K HDR TV
LT-49C898
GB
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 1 26/11/2018 15:14

Contents
1 Safety Warnings ...........................................................................................................................................................................4
2 Preparation...................................................................................................................................................................................7
Unpacking the TV ...............................................................................................................................................................................................................7
Installing / Removing the Base Stand .........................................................................................................................................................................8
− Fitting the Neck and Neck Cover Together...................................................................................................................................................8
− Fitting the Neck and Stand to the TV..............................................................................................................................................................8
Mounting the TV to a Wall...............................................................................................................................................................................................9
Front / Right Side View and Controls...........................................................................................................................................................................9
Rear View and Sockets....................................................................................................................................................................................................10
Installing Batteries in the Remote Control ..............................................................................................................................................................11
Remote Control Operation Range..............................................................................................................................................................................11
TV Stand Angle ..................................................................................................................................................................................................................11
Remote Control .................................................................................................................................................................................................................12
3 Initial Setup ................................................................................................................................................................................14
Turning the TV On for the First Time.........................................................................................................................................................................14
− Choose Region (UK only) ...................................................................................................................................................................................18
− Connecting an Analogue Device....................................................................................................................................................................19
− Channel Selection .............................................................................................................................................................................................. 20
− Display Channel Information .......................................................................................................................................................................... 20
− Volume Adjustment............................................................................................................................................................................................ 20
− Using the buttons on the back of the TV.................................................................................................................................................... 20
4 Customising TV Settings ...........................................................................................................................................................21
Adjusting the Picture Settings.....................................................................................................................................................................................21
− Common Picture Options..................................................................................................................................................................................21
Adjusting the Sound Settings..................................................................................................................................................................................... 23
− Common Sound Options.................................................................................................................................................................................. 23
Editing the Channel List ................................................................................................................................................................................................ 25
Filtering the Channel List.............................................................................................................................................................................................. 26
Viewing your Favourite Channel List........................................................................................................................................................................ 26
Home Menu ....................................................................................................................................................................................................................... 27
− Moving an item on the Home Menu bar .................................................................................................................................................... 27
− Deleting an item on the Home Menu bar .................................................................................................................................................. 27
− Adding an item to the Home Menu bar...................................................................................................................................................... 27
5 Using the Features.....................................................................................................................................................................28
Programme Guide........................................................................................................................................................................................................... 28
− Switch On / O Programme Guide ............................................................................................................................................................... 28
− Select a Programme ........................................................................................................................................................................................... 28
− Record a Programme.......................................................................................................................................................................................... 28
Time Shift Recording onto a USB Storage Device ............................................................................................................................................... 30
Recording DTV Programmes onto a USB Storage Device .................................................................................................................................31
Setting a Timer or Timed Recording ........................................................................................................................................................................ 32
− Editing a Timer...................................................................................................................................................................................................... 33
− Deleting a Timer................................................................................................................................................................................................... 33
Playing Recorded Programmes.................................................................................................................................................................................. 34
− Editing a Recording............................................................................................................................................................................................. 34
− Deleting a Recording ......................................................................................................................................................................................... 34
− Sorting a Recordings.......................................................................................................................................................................................... 35
− Recording Settings.............................................................................................................................................................................................. 35
Red Button + (Interactive services)........................................................................................................................................................................... 36
− Accessing the Information ............................................................................................................................................................................... 36
Listening to the Radio.................................................................................................................................................................................................... 36
6 Using the Smart Features..........................................................................................................................................................37
Connecting to the Internet (Wired) .......................................................................................................................................................................... 37
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 2 26/11/2018 15:14

Connecting to the Internet using wireless............................................................................................................................................................. 38
− Wake On .................................................................................................................................................................................................................. 38
Connecting to the WPS button .................................................................................................................................................................................. 39
Using Freeview Play ........................................................................................................................................................................................................ 40
− Catch Up Services................................................................................................................................................................................................ 40
− Recommendations.............................................................................................................................................................................................. 40
− Freeview Apps Updating ...................................................................................................................................................................................41
− Freeview Play 7 day Catch Up through the Programme Guide...........................................................................................................41
Using Smart TV ................................................................................................................................................................................................................. 42
− Apps.......................................................................................................................................................................................................................... 42
− Deleting an app from Apps ............................................................................................................................................................................. 42
− Market...................................................................................................................................................................................................................... 43
− Searching for Apps.............................................................................................................................................................................................. 43
Using the Internet Browser ..........................................................................................................................................................................................44
− Adding Bookmarks .............................................................................................................................................................................................44
− Adding Tabs...........................................................................................................................................................................................................44
− Adding a Site to Speed Dial ............................................................................................................................................................................. 45
− Editing Speed Dial............................................................................................................................................................................................... 45
− Opera Menu........................................................................................................................................................................................................... 45
Casting You Tube to your TV ....................................................................................................................................................................................... 46
7 Other Information......................................................................................................................................................................47
CI (Common Interface) (DTV Mode).......................................................................................................................................................................... 47
Privacy Settings................................................................................................................................................................................................................ 48
Time Settings..................................................................................................................................................................................................................... 49
Accessibility Settings...................................................................................................................................................................................................... 49
More Settings.................................................................................................................................................................................................................... 50
− HDMI ARC (Audio Return Channel)................................................................................................................................................................51
Language Settings .......................................................................................................................................................................................................... 52
Sources................................................................................................................................................................................................................................. 52
− Editing the Source............................................................................................................................................................................................... 52
Resetting your TV ............................................................................................................................................................................................................ 53
Parental Settings.............................................................................................................................................................................................................. 54
8 Entertainment ............................................................................................................................................................................55
Connecting a USB Storage Device............................................................................................................................................................................. 55
Media Browser .................................................................................................................................................................................................................. 56
− Media Browser Settings .................................................................................................................................................................................... 56
9 Technical Information and Help...............................................................................................................................................57
Maintenance...................................................................................................................................................................................................................... 57
Hints and Tips.................................................................................................................................................................................................................... 58
Remote Control Codes................................................................................................................................................................................................... 60
− Sky Codes ............................................................................................................................................................................................................... 60
− Virgin Media Codes (TiVo box) ....................................................................................................................................................................... 60
− BT Vision.................................................................................................................................................................................................................. 60
Declaration of Conformity............................................................................................................................................................................................ 60
Product Fiche and Specications ..............................................................................................................................................................................61
License Information used with JVC Televisions.................................................................................................................................................... 62
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 3 26/11/2018 15:14

4
1 Safety Warnings
Chapter
1
10 cm 10 cm
20 cm
10 cm
• Read all the instructions carefully before using the unit
and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
• Check that the voltage marked on the rating label
matches your mains voltage.
• WARNING: Never let people (including children) with
reduced physical, sensory or mental capabilities or lack
of experience and / or knowledge use electrical devices
unsupervised.
• To avoid danger of suffocation, keep plastic bags out of
reach of babies, children and domestic animals.
• Carefully attach the stand to the TV. If the stand is
provided with screws, tighten the screws firmly to
prevent the TV from tilting. Do not over tighten the
screws and mount the stand rubbers properly.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any
doubt about it working normally, or if it is damaged
in any way - switch off, withdraw the mains plug and
consult your dealer.
Location of Unit
• The unit must be placed on a flat stable surface and
should not be subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces
as the unit may fall off or tip over causing serious
personal injury or death.
• The mains socket must be located near the unit and
should be easily accessible.
• This unit is designed for indoor, domestic use only.
• Use this TV set at an altitude of less than 2000 meters
above sea level, in dry locations and in regions with
moderate or tropical climates.
Many injuries, particularly to children, can be avoided by
taking simple precautions such as;
• Using cabinets or stands recommended by the
manufacturer of the television set.
• Only use furniture that can safely support the
television set.
• Ensuring the television set is not overhanging the edge
of the supporting furniture.
• Not placing the television set on tall furniture (for
example, cupboards or bookcases) without anchoring
both furniture and the television set to a suitable
support.
• Not standing the television set on cloth or other
materials placed between the television and
supporting furniture.
• Educating children about the dangers of climbing
on furniture to reach the television set or its controls.
If your existing television set is being retained and
relocated, the same considerations as above should be
applied.
Wall Mounting
• Read the TV and wall mount instructions before
mounting your TV on the wall.
• For TVs over 40" in size, wall mounting requires 2
people to lift and position the TV on to the wall mount.
• The wall mount bracket is not supplied, they can be
purchased from your dealer.
• Do not install the TV on a ceiling or an inclined wall.
• Only use the screws supplied with the wall mount
bracket when attaching the TV to the bracket. See your
TV instructions for screw type.
• Tighten the wall mount screw firmly to prevent the TV
from falling. Do not over tighten the screws.
• If you are in any doubt how to mount your TV, contact
a professional.
Temperature
• Avoid extreme degrees of temperature, either hot or
cold. Place the unit well away from heat sources such
as radiators or gas / electric fires.
• Avoid exposure to direct sunlight and other sources of
heat.
Naked Flames
• Never place any type of candle or naked flame on the
top of or near the unit.
Moisture
• To reduce the risk of fire, electric shock or product
damage, do not expose this unit to rain, moisture,
dripping or splashing. No objects filled with liquids,
such as vases, should be placed on the unit.
• If you spill any liquid into the unit, it can cause serious
damage. Switch it off at the mains immediately.
Withdraw the mains plug and consult your dealer.
Ventilation
• To prevent the risk of electric shock or fire hazard
due to overheating, ensure that curtains and other
materials do not obstruct the ventilation vents.
• Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure the unit is
well ventilated.
• Make sure that there is a gap of at least 10 cm on both
sides and a gap of 20 cm at the top.
Safety
• Always disconnect the unit from the mains supply
before connecting / disconnecting other devices or
moving the unit.
• Unplug the unit from the mains socket during a
lightning storm and long inactivity periods (going on
holiday).
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 4 26/11/2018 15:14

5
1
Safety Warnings
Mains Cable
• Make sure the unit or unit stand is not resting on top of
the mains cable, as the weight of the unit may damage
the mains cable and create a safety hazard.
• A damaged power cord/plug can cause fire or give
you an electric shock. Handle the power cord by the
plug, do not unplug the TV by pulling the power cord.
Never touch the power cord/plug with wet hands
as this could cause a short circuit or electric shock.
Never make a knot in the power cord or tie it with
other cords. If the mains cable is damaged it must be
replaced by the manufacturer, its service agent, or
similarly qualified persons in order to avoid a hazard.
Interference
• Do not place the unit on or near appliances which may
cause electromagnetic interference. If you do, it may
adversely affect the operating performance of the unit,
and cause a distorted picture or sound.
Optimum viewing
• View the unit in moderate light to prevent eye strain. It
is recommended to watch the unit from a distance
3-7 times that of the screen height.
LCD screen
• The LCD screen is manufactured using high-precision
technology. However, some tiny black points and /
or bright points (red, blue or green in colour) may
constantly appear on the LCD screen. These points
are generated in the manufacturing process and are
normal.
Screen Burn
• A characteristic of Plasma and TV Panels is that
displaying the same image for a long time may cause
a permanent after-image to remain on the screen. This
is called screen burn. Most pictures shown on the unit
will be constantly moving and fill the screen.
• Examples of images that you need to watch out for are
as follows (this is not an all-inclusive list):
1. Black Bars: If black bars appear at the left / right or
top / bottom of the screen, it is recommended to
change the format so that the picture fills the entire
screen.
2. TV Channel Logos: e.g. Shopping channel logos
and pricing displays - especially if they are bright
and stationary. Moving or low-contrast graphics are
less likely to cause ageing of the screen.
3. Time Displays
4. Teletext: Do not view a stationary page for long
periods of time.
5. TV Menus
6. Pause Mode: Do not leave the screen in pause
mode for long periods of time, e.g. when watching
videos.
• To prevent screen burn if viewing any of the above for
long periods of time, reduce contrast and brightness
when viewing. Once burn-in occurs it will never
disappear completely.
Country Restrictions for Wireless Internet
• This device is intended for home and office use in
all EU countries (and other countries following the
relevant EU directive) without any limitation except for
the countries mentioned below.
Country Restriction
Bulgaria (BG) General authorization required for
outdoor use and public service
France (FR) In-door use only for 2454-2483.5 MHz
Italy (IT) If used outside of own premises, general
authorization is required
Greece (GR) In-door use only for 5470 MHz to 5725
MHz band
Luxembourg
(EL)
General authorization required for
network and service supply(not for
spectrum)
Norway (NO)
Radio transmission is prohibited for the
geographical area within a radius of 20
km from the centre of Ny-Ålesund
Russian
Federation (RU) In-door use only
• The requirements for any country may change at any
time. It’s recommended that user checks with local
authorities for the current status of their national
regulations for both 2.4 GHz and 5 GHz wireless LAN’s.
Earphones
• Listening to loud sounds for prolonged periods of time
may permanently damage your hearing.
• Before putting on earphones, turn the volume down
then put the earphones on and slowly increase the
volume until you reach a comfortable listening level.
Standby
• The button on the remote control does not switch
off the unit completely. The unit will continue to draw
electricity from the mains supply while in standby. In
the interests of safety and to avoid unnecessary energy
consumption, never leave the unit in standby while
unattended for long periods of time, e.g. overnight,
while on holiday or while out of the house. Disconnect
the mains plug from the mains socket.
Batteries
• Batteries used in the remote control for this unit
are easily swallowed by young children and this is
dangerous.
• Keep loose batteries away from young children and
make sure that the battery holder tray is secure in the
remote control. Seek medical advice if you believe a
cell has been swallowed.
• Please dispose of batteries correctly by following the
guidance in this manual.
• Do not dispose of batteries in fire or with hazardous or
flammable materials.
• The batteries shall not be exposed to excessive heat
such as sunshine, fire or the like.
Supervision
• Children should be supervised to ensure that they do
not play with the unit and the remote control.
• Never let anyone especially children push anything
into the holes, slots or any other openings in the case -
this could result in a fatal electric shock.
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 5 26/11/2018 15:14

6
1Safety Warnings
Earthing
• Apparatus connected to the protective earthing of the
building installation through the MAINS connection
or through other apparatus with a connection to
protective earthing - and to a television distribution
system using coaxial cable, may in some circumstances
create a fire hazard. Connection to a television
distribution system has therefore to be provided
through a device providing electrical isolation below a
certain frequency range (galvanic isolator,
see EN 60728-11)
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the unit’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
manual accompanying the unit.
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-serviceable
parts. Please leave all maintenance work to qualified
personnel.
• Do not open any fixed covers as this may expose
dangerous voltages.
Maintenance
• Ensure to unplug the unit from the mains socket before
cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
• The wall socket plug is used as a disconnect device, the
disconnect device should be readily accessible.
• This equipment is a Class II or double insulated
electrical appliance. It has been designed in such
a way that it does not require a safety connection
to electrical earth.
To prevent the spread of fire,
keep candles or other open
flames away from this product
at all times.
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 6 26/11/2018 15:14

7
2 Preparation
Thank you for purchasing your new JVC TV.
Your new TV has many features and incorporates the latest technology to enhance your viewing
experience. We recommend that you spend some time reading this instruction manual so that you fully
understand these features. You will also find some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future reference.
Chapter
2
Unpacking the TV
Remove all packaging from the TV. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
Instruction Manual Quick Start Guide
Instruction Manual
49" LED Smart 4K HDR TV
LT-49C898
GB
Quick Start Guide
49" LED Smart 4K HDR TV
LT-49C898
Thank you for purchasingyour new JVC TV.
Yournew TV incorporates the latest technology to enhance your viewing
experience.We would suggest that you allow about 15 mins for initial setup.
Pleasefollow this guide for a successful rst time installation.
Thelatest eco-friendly power-saving technology will switch o the TV if
itis left on and idle for 4 hours. Please refer to “AutoStandby” under the
“TimeSettings” section of the instruction manual for more detail.
Removeall packaging from the unit. Retain the packaging. If you dispose of it please do so according to any local regulations.
TV
TVStand Neck
TVStand Neck cover
TVStand Base
RemoteControl/
AAABatteries x2
Screws(A) x 5
Screws(B) x 6
InstructionManual
QuickStart Guide Pleaseinspect your TV for damage after unpacking. If
youdo notice any damage please consult your dealer.
1. Slideopen the batter y compartment on the back of the remotecontrol.
2. Insert two AAA size batteries.M ake sureto match the (+) and ( - ) ends of
thebatteries with the (+) and ( - ) ends indicated in the batterycompartment.
3. Slidethe batter y compartment coverback into place. Make sure itclicks into place.
Forextra safety use the screw supplied to screw the battery compartment closed.
Fitting the Neck and Neck CoverTogether
1. Fitthe neck cover over the neck.
2. Using2 of the supplied screws (A), screw the neck and neck cover together.
TheLCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object, or
anythingthat could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure on the front of theT V at any time because the
screencould crack.
• Donot connect the TV to the mains supply until you have completed all the connections.
• Alwaysdisconnect the TV from the mains socket when not in use for a long period of time.
• The buttonon the remote control is only used for switching the TV into standby, it does not disconnect the TV from the mains power.
Tocompletely disconnect the mains power, please remove the mains plug from the mains socket.
1. Connect one end of the RF coaxial cable to the aerial socket on the wall and theother end of the cableto the ANT socket on the back of your TV.
2. Plug the TV into a mains socket and switch on at the mains.
3. In standby mode, press the button on the remote control to turn the TV on. TheLED indicator will ash for a few seconds then the TV will switch on.
RFcoaxial cable
(notincluded)
Router
(notincluded)
LANVGA ANT.HDMI1Optic.OUT
Optional
Ifyou want to connect to the internet via a wired connection
thenconnect your ethernet cable to the LAN socket.
Setup in
15mins
3
2
What’sin the Box?
Operating YourRemote Control
Installing the Base Stand
1
4Connecting the Aerial and Turningon the TV
Fitting the Neck and Stand tothe TV
3. Ensurethe TV is switched off and not connected to
themains power supply.
4. Laythe TV down on a flat surface ideally on the
edgeof a table so the base of the TV slightly
overhangsthe edge of the table, with the back
sidefacing up. Please make sure a soft cushioned
material(such as a dr y bath towelor thick piece of
foam)is placed beneath the screen. You can leave
theprotective bag on to protect the TV at this point.
5. Slidethe Neck and Neck cover under the lip, the
neckwill fit snugly over the screw holes. Then screw
theNeck to the TV using the 6 screws (B) supplied.
6. Oncethe Neck is secure screw the base to the neck
usingthe 3 screws (A) supplied. Be careful not the
dropthe base, its heavy.
A
A
A
B
Protective
Bag
Cushioned
material
Table
JVC49' LED Smart 4K HDR TV LT-49C898 Quick Start.indd 1-3 26/11/2018 11:44
Remote Control /
AAA Batteries x 2
LANG.
EXIT
LANG.
G
BACK
Screws x5
A B
Screws x6
TV Stand Neck Cover and
Neck
TV Stand Base
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 7 26/11/2018 15:14

2
8
Preparation
A
B
Installing / Removing the Base Stand
The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that
no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert
pressure on the front of the TV at any time because the screen could crack.
3. Ensure the TV is switched off and not connected to the mains power supply.
4. Lay the TV down on a flat surface ideally on the edge of a table so the base of the TV slightly overhangs the edge of the table,
with the back side facing up. Please make sure a soft cushioned material (such as a dry bath towel or thick piece of foam) is
placed beneath the screen. You can leave the protective bag on to protect the TV at this point.
5. Slide the Neck and Neck cover under the lip, the neck will fit snugly over the screw holes. Then screw the Neck to the TV using
the 6 screws (B) supplied.
6. Once the Neck is secure screw the base to the neck using the 3 screws (A) supplied. Be careful not the drop the base, its heavy.
Fitting the Neck and Neck Cover
Together
1. Fit the neck cover over the neck.
2. Using 2 of the supplied screws (A), screw the neck
and neck cover together.
Fitting the Neck and Stand to the TV
A
A
Protective
bag
Table Cushioned
material
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 8 26/11/2018 15:14

2
Preparation
9
Front / Right Side View and Controls
COMMON INTERFACE
5Vdc
Max. 500mA
5Vdc
Max. 500mA
SubW.OUT
AUDIO IN
SCART
LAN
USB
5V DC max 500mA
Pr
Pb
Y / Video
R
L
VGA ANT.
HDMI 3
ARC
HDMI 4HDMI 2
HDMI 1
USB
Optic.OUT
USB 3.0
Item Description
1 MULTI FUNCTION SWITCH Switches the TV into standby and on. Selects modes (channel,volume, and source).
2POWER LED Illuminates when the TV is in standby mode. The LED will blink confirming that a timer
recording programme has started in the standby mode.
3 IR (Infrared Receiver) Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
2
1
3
Remove the stand assembly before mounting the TV onto the wall.
• If you are wall mounting your TV you may wish to buy a 90° HDMI adapter. This will help with your cable management.
• Please read this instruction manual carefully while setting up your TV.
• If you require additional assistance please call our Call Centre on (UK) 0344 561 1234 or (Ireland) 1 890 818 575.
Our Customer Contact Centre is open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
1. Remove the 6 screws (B) from the neck of the stand and detach the
stand.
Mounting the TV to a Wall
2. This TV is designed to be wall-mounted
with a standard 200 mm x 200 mm
mounting kit (sold separately) designed
for flat-panel TVs. Mount this TV according
to the instructions included in the
mounting kit. Due to space restrictions, we
recommend that you make all connections
before mounting on to
the wall.
x6
B
200mm
Four mounting holes
(size M6 screw)
200mm
10-13mm
M6
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 9 26/11/2018 15:14

2
10
Preparation
Rear View and Sockets
1
3
42
9
9
9
10
2
2
11
Item Description
1 AUDIO IN AUDIO (L/R) output sockets on external video devices.
2 USB Allows the insertion of a USB storage device to play video, audio, photo and text files
(USB mode) and record DTV programmes on to a USB storage device.
3 SubW.OUT Connects to an external subwoofer.
4 YPbPr Connects to a DVD player, Digital Set-Top-Box, or other AV devices with component
(YPbPr) video and audio output sockets.
5 VGA Connects to a computer or other devices with a VGA interface.
6 LAN Connect to a router via a LAN cable for smart TV services.
7 Optic OUT Optical audio out (Digital) - Connects to an audio device via an optical cable.
8 ANT Connects to the aerial socket on the wall with the RF coaxial cable.
9 HDMI 1,2,3(ARC) & 4 Connects to a High-Definition (HD) signal output device, such as a set-top box, blu-ray
disc player or AV receiver.
10 Connects to the headphones.
11 COMMON INTERFACE Allows the insertion of a Common Access Module.
COMMON INTERFACE
5Vdc
Max. 500mA
5Vdc
Max. 500mA
SubW.OUT
AUDIO IN
LAN
USB
5V DC max 500mA
Pr
Pb
Y / Video
R
L
VGA ANT.
HDMI 3
ARC
HDMI 4HDMI 2
HDMI 1
USB
Optic.OUT
USB
COMMON INTERFACE
5Vdc
Max. 500mA
5Vdc
Max. 500mA
SubW.OUT
AUDIO IN
LAN
USB
5V DC max 500mA
Pr
Pb
Y / Video
R
L
VGA ANT.
HDMI 3
ARC
HDMI 4HDMI 2
HDMI 1
USB
Optic.OUT
USB
COMMON INTERFACE
5Vdc
Max. 500mA
5Vdc
Max. 500mA
SubW.OUT
AUDIO IN
SCART
LAN
USB
5V DC max 500mA
Pr
Pb
Y / Video
R
L
VGA ANT.
HDMI 3
ARC
HDMI 4HDMI 2
HDMI 1
USB
Optic.OUT
USB 3.0
6 7 8 9
5
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 10 26/11/2018 15:14

2
Preparation
11
Handling the Batteries
• Improper or incorrect use of batteries may cause
corrosion or battery leakage, which could cause
fire, personal injury or damage to property.
• Only use the battery type indicated in this manual.
• When the batteries are exhausted, the remote will
not function. Replace both batteries at the same
time with new ones.
• Do not install new batteries with used ones and do
not mix different types of batteries.
• Do not dispose of used batteries as domestic
waste. Dispose of them in accordance with local
regulations.
Handling the Remote Control
• Take care of your fingernails when you press and
hold the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote
control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct
sunlight or near sources of excessive heat.
• Remove the battery from the remote control
when not in use for a long period of time, as it
could cause corrosion or battery leakage and may
result in physical injury and/or property damage
including fire.
Installing Batteries in the Remote Control
1. Slide open the battery compartment on the back
of the remote control.
2. Insert two AAA size batteries. Make sure to match the (+)
and ( - ) ends of the batteries with the (+) and ( - ) ends
indicated in the battery compartment.
3. Replace the battery compartment cover. Make sure it clicks
into place. For extra safety use the screw supplied to screw
the battery compartment closed.
Remote Control Operation Range
Point the remote control at the TV no more than 5 metres from the
remote control sensor on the TV and within 60° in front of the TV.
The operating distance may vary depending on the brightness of
the room.
30° 30°
5M
LANG.
EXIT
LANG.
G
BACK
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 11 26/11/2018 15:14

2
12
Preparation
LANG.
EXIT
LANG.
G
BACK
Remote Control
1.
Switch the TV between on and standby mode.
2. SOURCE
Press to change the source you are viewing.
TV - BACK AV - HDMI 1 - HDMI 2 - HDMI 3 - HDMI 4 -
YPbPr - VGA/PC.
3. 0-9 Number Button
• Press to select a programme. (TV / RADIO mode)
4. LANG.
Selects the Current Language menu.
• Select Audio language or Subtitle language.
5. TXT
Press to enter teletext if available.
6. MUTE
Mute and restore the sound.
7. V + / –
Adjust the volume.
8. P+ / P-
Press to select the next channel up or down the channel list.
9. HOME
Display the main menu.
10. G(Programme Guide)
Press to view the Programme Guide.
11. i (info)
Press to see programme information in TV mode.
12. OK /
• Press OK to select or save a setting in menus.
• Press OK to select the Channel list while watching TV.
• Allows you to navigate the OSD menus and adjust
the system settings to your preference.
13. BACK
Press to move backwards through menus.
14. EXIT
Press to exit a menu.
15.
Press to enter Freeview Play (internet connection required).
16.
Press to enter prime video (internet connection required).
4
3
1
6
9
2
8
11
14
15
10
13
16
7
12
5
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 12 26/11/2018 15:14

2
Preparation
13
LANG.
EXIT
LANG.
G
BACK
18
19
20
17
17. NETFLIX Button
Connects to Netix for viewing online TV shows and lms
(internet connection required).
18.
Press to enter YouTube (internet connection required).
19. PLAYBACK and RECORD buttons
• starts a recording, continue to press will add more
recordings.
• plays a recording.
pauses a recording and starts timeshifting in TV mode
if you have a hard drive attached to the USB port.
• stops a recording.
• searches forwards and backwards when
viewing a recording.
20. COLOURED BUTTONS
Access the TELETEXT items (TV mode) or menu options.
TELETEXT (RED)
Accesses TELETEXT.
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 13 26/11/2018 15:14

14
3 Initial Setup
Turning the TV On for the First Time
1. Connect one end of the RF coaxial cable to the aerial socket on the wall and the other end of the cable to the ANT socket on
the back of your TV.
2. Plug the TV into a mains socket and switch on at the mains.
3. In standby mode, press the button on the remote control to turn the TV on. The LED indicator will flash for a few seconds
then the TV will switch on.
• Always disconnect the TV from the mains socket when not in use for a long period of time.
• The button on the remote control is only used for switching the TV into standby, it does not disconnect the TV from the
mains power. To completely disconnect the mains power, please remove the mains plug from the mains socket.
Chapter
3
The first time you turn the TV on, it will go straight into the First Time
Installation menu. Most of the settings are pre-set so you can just press OK.
Please ensure the aerial is plugged in.
4. Press the buttons to highlight your LANGUAGE then press OK.
5. Press the buttons to highlight your COUNTRY then press OK.
6. Select Home Mode by pressing the OK button.
7. Press the buttons to highlight your desired picture mode. Its set to Natural
as this is the most energy efficient mode. Then press OK.
Do not connect
the TV to the
mains supply
until you have
completed all the
connections.
RF coaxial cable
(not included)
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 14 26/11/2018 15:14

15
3
Initial Setup
Select Individual Settings
If you don’t want to accept all the setting you can choose to activate settings individually.
11. First make sure Accept All is
deactivated.
12. Press the button to highlight
your desired setting then press
OK to activate it.
13. Press the button to highlight
NEXT then press OK, a list will
appear highlighting the settings
that you haven't accepted. Select
YES to continue.
Choosing to Activate No Settings
14. If you don't wish to accept any of the settings press the button to highlight
NEXT then press OK. You will be informed that you haven't enabled HbbTV
and Portal and Applications. Select YES and press OK.
15. You're TV will now skip section 6 'Connecting to the Internet' and start to
tuning.
You will NOT have any smart functionality once your TV has tuned in. Select
Yes and Press OK.
Before you are able to connect to the internet and use the smart features of your TV, you MUST make sure that some Privacy
Settings are activated. This is part of the Initial Setup process or if you skip it, you can select them later by either pressing the
SMART button where you'll be directed to the Privacy Settings menu or you can select the Privacy settings directly from Settings
menu.
To use Smart functions the minimum settings that you will need to activate are Portal and Applications and Internet
connection . For Red Button services you must activate HbbTV.
By activating these settings you are allowing the TV Manufacturer to store data to help improve the performance and user
experience of your TV.
Each setting has a description, if you press the P / button when the setting is highlighted you will be able to scroll up and
down the text to read the description. To access all the features of your Smart TV you must be connected to the internet. If you do
not wish to set up your network connection you can skip this section by pressing , however we recommend you set up your
network connection now.
Press OK to Accept Terms of Use
Reminder of setting not selected
Press OK to Accept All
To enjoy Freeview Play and Smart functionality your TV must have enabled ‘Portal and Applications’ and‘Internet
Connection’ in the Privacy Setting and then connect to the internet.
To Accept ALL (recommended)
8. To accept all the setting press
the OK button.
9. The 'Terms of Use' screen will
appear. Press OK to accept the
terms.
10. All of the boxed will now
be ticked and NEXT will be
highlighted, press OK.
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 15 26/11/2018 15:14

16
3Initial Setup
WIRED Connection
• If you have connected your ethernet cable to the LAN socket on the back of
your TV, press the button to highlight NEXT then press OK.
WIRELESS Connection
You can connect using a wireless connection via your router.
16. Press the buttons to select WIRELESS DEVICE then press the button to
highlight NEXT then press OK.
17. Press the buttons to select your wireless network then press OK.
Make sure your TV is as close to your router as possible, within 5m and ideally in the same room as the TV
18. You now need to enter your password, a keyboard will appear. Press the
buttons to select a letter/number/symbol and press OK to enter
each one. Once you have typed your password highlight OK and press OK.
19. The network will now show Connected and NEXT will be highlighted press the
OK button to continue.
Best connection
speed
Maximum distance
5m
Wireless Router Wireless Router
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 16 26/11/2018 15:14

17
3
Initial Setup
WPS Connection
Rather than having to enter your Wireless password, you can select the WPS option. This will allow you to connect to your router
without a password once the WPS button is pressed on your router.
20. Select WIRELESS DEVICE.
21. Press the button to highlight 'Press WPS on your wifi router' then press OK.
Now press the WPS button on your router and your TV will connect to your
router, without the use of a password.
22. To make sure you activate Freeview Play select YES and press OK.
23. To tune in your TV using the aerial connection press OK.
24. Your TV will now start automatic channel scan. It will tune in all available TV
channels.
If you View TV Through a Set Top Box
If you have attached a Set top box such as Sky/Virgin or BT via a HDMI
cable then un-tick Digital Aerial and select NEXT. This will mean your TV will
not try to tune any channels in. To view your set top box press the HOME
button, scroll to SOURCE and select the HDMI socket you have attached
your set top box to.
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 17 26/11/2018 15:14

18
3Initial Setup
Choose Region (UK only)
During tuning, your TV may have received signals from more than one transmitter. If this has occurred the Choose Region screen
will be displayed. This will enable you to select the correct regional transmission for the local news service that you require.
• Press the button to highlight Primary region, then press the
buttons to select your Primary Region e.g. England.
• Press the button to highlight Secondary region, then press the
buttons to select your Secondary Region e.g. London.
• Press the button to highlight Tertiary region, then press the
buttons to select your Tertiary Region e.g. Greater London.
• Press the button to highlight Save then press OK.
Your TV is now fully tuned in.
Country Code This will be shown as UK.
Primary Region This will show the regional country (England, Wales,
Scotland, NI).
Secondary Region
This will allow you to set the region for your local
news service on BBC and ITV (London, Beds and
Cambs etc).
Tertiary Region
You may receive signals from more than one
transmitter within the Secondary Region, (e.g Beds
and Cambs may have Luton or Sandy Heath).
25. The Scan statistics screen will now be displayed. This shows the amount of TV
and Radio channels that have been tuned in. Press OK to exit.
26. The Edit Channel list will appear, press the EXIT button to remove this. Your TV
is now fully tuned in and ready to use.
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 18 26/11/2018 15:14

19
3
Initial Setup
Connecting an Analogue Device
If you have connected an analogue device such as a video recorder via the
aerial socket on your TV you will have to tune it in using Analogue mode. Ensure
the device is switched on before you start the tuning process.
1. Press the MENU button, press the buttons to select INSTALL AND
RETUNE and press OK.
2. Select AUTOMATIC CHANNEL SCAN (RETUNE) and press OK.
3. Press the buttons to select ANALOGUE and press OK.
4. Press the buttons to select YES then press OK. The search will
automatically start, this will not delete your Digital channels, so don't worry!
5. When the search has finished the EDIT CHANNEL LIST will appear. Your
analogue channel will be at the end of the channel list.
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 19 26/11/2018 15:14

20
3Initial Setup
• If a locked channel is selected, the password screen will be displayed. Press the 0-9 buttons to enter the password, the
channel will then be unlocked (refer to Locking Channel for details).
Display Channel Information
• Press the INFO button to view the current channel.
• Press the INFO button
a second time to see
information about the current
programme you're viewing.
• Press the button to see
programme information for
the next programme.
• Press INFO to remove the
information.
Channel Selection
• Press the P+ / – buttons on the remote control repeatedly or the 0-9 buttons to select the channel.
Alternative
Press the OK button to enter the Channel List. Then use the buttons to highlight and select the channel.
Press the OK button to view the selected channel.
OR
Press the i (info) button then the buttons to search for a channel you wish to watch then press OK.
Volume Adjustment
• Press the V + or –button on the remote control or rotate the multi-function
switch up or down on the back of the TV.
• If you wish to switch the sound off, press the button. You can turn the volume
down while your TV is in mute mode. Press the VOL – button, you will see the
volume level reduce, but you won't hear anything at the moment. To listen to
your TV at the new lower level, press the button again or VOL + button.
Current Programme Information Next Programme Information
Using the buttons on the back of the TV
The button on the back of the TV is like a joystick you can push the centre and
move it reft, right, up and down.
• Press and hold the button the switch the TV in and out of STANDBY.
• Press the button to access the SOURCE menu, press the / buttons
to move up and down the menu. Press to select a source.
• Press the / buttons to change channel.
• Press the +/- buttons to adjust the volume.
COMMON INTERFACE
5Vdc
Max. 500mA
5Vdc
Max. 500mA
SubW.OUT
AUDIO IN
SCART
LAN
USB
5V DC max 500mA
Pr
Pb
Y / Video
R
L
VGA ANT.
HDMI 3
ARC
HDMI 4HDMI 2
HDMI 1
USB
Optic.OUT
USB 3.0
JVC 49' LED Smart 4K HDR TV LT-49C898 Manual.indd 20 26/11/2018 15:14
