TM-123U
14-Inch B&W Video Monitor
FEATURES
14" B&W Video Monitor
High Resolution Pictures
With 700 lines of horizontal resolution, the
monitor provides sharp reproduction of
every detail.
Looped-through Output
Convenient looped-through connection is
available.
Flexible Mounting
Two TM-123Us can be mounted together in
a standard EIA 19" rack using the optional
UC-P1027U Rack Mount Adapter.
ARCHITECTS’ AND ENGINEERS’ BID SPECIFICATION
The black-and-white video monitor shall be a JVC Model TM-123U or equivalent. It shall
have a 14" diagonal screen with horizontal resolution of 700 lines center, with an actual
visual size of 12-3/16" H x 12-1/2" W. The monitor shall feature manual controls for on/off,
brightness, contrast, vertical hold, horizontal hold, audio level, height, vertical linearity, scan
size (underscanning or normal), and loopthrough type (75 ohm termination switch or Hi-Z).
Terminals on the monitor shall be 1 video input and 1 video output, each 1.0Vp-p 75 ohm
composite via BNC connector. The monitor shall be UL listed. The dimensions shall be 12-
3/16" H x 12-1/2" W x 12-1/4" D and it shall weigh 23.1 lbs.

R
TM-123U
Specifications
CRT 14", 90° deflection
Scanning frequency H: 15.75 kHz
V: 60 Hz
Horizontal resolution More than 700 TV lines ( at center)
Input Video x 1: VS, 1 V(p-p), 75 ohms (BNC)
Output (looped-through) Video x 1: VS, 1 V(p-p), 75 ohms (BNC)
S/N ratio More than 55 dB
Video frequency response 15 kHz to 9 MHz
Sweep lineanty Less than 7%
Power requirement 120 V AC
Power consumption Approx. 27 W
Operating temperature range 14°F to 122°F (-10°C to 50°C)
Weight Approx. 23.1 lbs (10.5 kg)
Dimensions
(Unit: inches)
12-1/412-1/2
12-3/16
TM-123 VIDEO MONITOR
POWER
??????
????
