JVC Reference DLA-RS6710U User manual

DLA-RS6710U
*The supplied 3D Synchro Emitter and 3D glasses are required to view 3D images.
4K Precision
Premium Home Theater Projector
• Industry’s highest 150,000:1 native contrast ratio
•Intelligent Lens Aperture increases dynamic contrast
ratio to industry highest 1,500,000:1
• 1080p three chip 3D enabled D-ILA projector built
from hand selected components
• New 6th generation 0.7-inch D-ILA devices
• New e-shift3 4K Precision (3840 x 2160) Projected Image
•Native 4K inputs
3840 x 2160 (24-30p, 60p at 4:2:0*)
4096 x 2160 (24p)
•Clear Black processing
• Real Color Imaging Technology supports x.v.Color space
and Xenon mode for authentic cinema color reproduction
• 1.4 to 2.8:1 motorized zoom lens with Horizontal
and Vertical offset
• Highly customizable built-in 2D to 3D converter
creates dynamic 3D images from 2D video content
• THX®and ISFccc Certified
• Control: LAN / RS-232C / IR / 12 V Screen Trigger
Output / 3D Synchro Control
• New Remote Control App for smartphones and tablets
•Includes these exclusive features:
Two pair of RF 3D glasses (PK-AG3)
One RF 3D Signal Emitter* (PK-EM2)
One spare replacement lamp (PK-L2312U)
5 Year warranty
The DLA-RS6710 delivers the most dramatic master-quality images ever produced
on a JVC projector. Built with hand selected, perfectly matched components, it boasts
the industry’s highest native and dynamic contrast ratios.

DISTRIBUTED BY referenceseries.com
Printed in the U.S.A.
"JVC" is the trademark or registered trademark of JVC KENWOOD Corporation.
4K Precision JVC e-shift3 Technology
Optimized for the new
D-ILA device, new 4K e-shift3 shifts
sub-frames by 0.5 pixel both
vertically and horizontally to achieve
4-times the pixel density of the
original content—boosting definition
to the highest level yet.
D-ILA 3D Projection*
There's nothing like 3D to pull you into the scene. JVC’s employs an original Frame
Addressing method to reproduce 3D images with vivid colors, and the optical engine
featuring the new D-ILA devices achieves more brightness than ever. Furthermore,
3D image adjustment functions such as Crosstalk Canceling are featured to offer the
kind of realistic and exciting 3D images that only D-ILA can provide.
*The supplied 3D Synchro Emitter and 3D glasses are required to view 3D images.
Smart-phone Remote Control App
Now, JVC D-ILA projectors can be controlled from your smartphone
or tablet with a free remote control app. This app features an intuitive
graphical UI and exclusive controls that make operations even easier.
Additionally, there are built-in help functions for smoother operation.
Conventional Projector DLA-RS6710
Specifications
• The projector is equipped with a new super-high pressure mercury lamp, which may break, emitting a loud noise, when it is subjected to shock or after it has been used for some length of time. • Please note that, depending on how the
projector is used, there can be considerable difference between individual lamps regarding how many hours they will operate before requiring replacement. • An additional payment is required for installation of a new lamp, if necessary.
• The projector lamp requires periodic replacement and is not covered by warranty. • Please be aware that, because the D-ILA device is manufactured using highly advanced technologies, 0.01% or fewer of the pixels may be non-performing
(always on or off).
Design and specifications are subject to change without notice. All pictures on this brochure are simulated. Adobe is a trademark or registered trademark of Adobe Systems Incorporated in the U.S. and/or other countries. ISF is a registered
trademark of Imaging Science Foundation, Inc. THX and THX logo are trademarks of THX Ltd., which may be registered in some jurisdictions. HDMI, the HDMI logo and High-Definition Multimedia Interface are registered trademarks of
HDMI Licensing LLC. All other brand or product names may be trademarks and/or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved.
Copyright © 2014, JVC KENWOOD Corporation. All Rights Reserved.
Notes about viewing 3D video content
• The supplied 3D Synchro Emitter and 3D glasses are required to view 3D images from the D-ILA projectors. 3D video
software (3D media or output of 3D broadcasts) and a 3D-compatible video player are also required. • Perception of 3D
images will vary with individual viewers. • Stop viewing 3D images immediately if any discomfort such as headaches,
dizziness, eye fatigue, etc. occurs. • Viewing of 3D images by children under the age of ve is not recommended. • Read
the Safety Precautions in the User Manual carefully before viewing any 3D source.
Accessories Connectors
PK-EM2
RF 3D Synchro
Emitter
PK-L2312U
User replaceable Lamp
PK-AG3
RF 3D Glasses
Battery-operated
150,000:1 Native Contrast Ratio
The combination of JVC’s D-ILA device and the optical engine equipped with a new
wire grid that improves polarization performance enables the DLA-RS6710 to achieve
the industry’s highest native contrast ratio of
150,000:1*. The newly developed Intelligent
Lens Aperture optimally adjusts black levels
and Clear Black boosts contrast between light
and dark to achieve the industry’s highest
dynamic range of 1,500:000:1.
Equipped with improved high-performance 4K scaling engine
Multiple Pixel Control (Scaler/Processor for 4K e-shift3)
The newest derivation of Multiple Pixel Control is a high-performance image processor
that enables precise reproduction of Full HD sources on this 4K projector. New, Auto
Mode performs frame adaptive filtering and picture generation to achieve an HD image
optimized for a variety of scenes thereby enabling an immersive 4K experience without
complicated picture adjustments.
4K e-shift3 Technology's Image Processor: Multiple Pixel Control
Input
2K image
Multiple Pixel
Control in action
Output
4-K resolution
The video signal is
automatically analyzed
frame by frame using
8-band filtering
JVC’s advanced Multiple Pixel
Control reproduces 4K images
that look more natural and
dimensional
Based on detection and
filtering results, dynamic
controls are applied to the
background and foreground
separately for a rich 4K image
Each pixel is analyzed with
wide-range (21x21) precise
signal detection
18
1
/2" | 472
3
/16" | 5
17
7
/8" | 455
13
1
/4" | 337
11
7
/16" | 290
3
9
/16"
91
4
9
/16"
117
2
1
/4" | 58
3
1
/8" | 79
1
7
/8" | 48
1
9
/16" | 41 1
1
/2" | 37
2
1
/
8
" | 55
1
1
/4"
45 1
1
/4"
45
7
/
16
" | 11 5" | 128
3
1
/
2
"
80
18
9
/16" | 472
ø60
1"
24
7" | 179
Top
Front
Bottom
Side
External Dimensions (unit: inches | mm)
Conventional device
0.5µ
New D-ILA device
0.3µ
a 40% narrower
pixel gap from
0.5µ to 0.3µ
achieves much
brighter, higher
contrast images
New 6th generation
0.7-in. D-ILA device
Newly Developed D-ILA Device
The exceptional picture quality achieved by JVC projectors
is a result of the precision technology behind the D-ILA device. The new 6th generation
device, with a 40% narrower pixel gap, achieves a 10% improvement in light efficiency
for a brighter image with higher contrast and incredibly rich detail.
* As of Nov. 1, 2013, JVC data
New D-ILA devices
e-shift device
Projection lens
Resolution doubles
in both directions
Enhanced e-shift3 Technology
D-ILA optical unit
Conventional
Original
Multiple Pixel
Control
In this example of Multiple
Pixel Control at work, the
facial texture is smooth and
natural, and each strand of
hair is precisely reproduced
DLA-RS6710
Imaging device
e-shift3 Technology
0.7 inch Full HD D-ILA (1920 x 1080) x3
Resolution 3840 x 2160 (1920 x 1080 in 3D mode)
Yes
Lens 1.4 - 2.8:1 Motorized Zoom & Focus
f2 @ 1.4 f3 @ 2.8
Lens Shift ±80% Vertical and ±34% Horizontal (motorized)
Light Source NSH 230W Lamp
(lamp life: approx. 4000 hours when the lamp is in Low mode)
Contrast Ratio Native: 150,000:1 | Dynamic: 1,500,000:1
Connectors
HDMI
3D Sync
2 (3D/Deep Color/CEC compatible)
LAN (RJ-45) 1
RS-232C 1 (D-sub 9pin)
1 (Mini DIN 3pin)
Trigger 1 (Mini jack, DC12V/100mA)
Video Input
Signal Format
Digital 480p, 576p, 720p/60/50 Hz,1080i/60/50 Hz,
1080p/60/50/24Hz, 3840×2160/24-30 Hz,
3840×2160/60/50 Hz(4:2:0), 4096×2160/24 Hz*
Frame Packing
Side-by-Side
Top-and-Bottom
3D Signal 720p/50 Hz, 720p/60 Hz, 1080p/24 Hz
1080i/60 Hz, 1080p/60 Hz, 1080i/50 Hz,
1080p/50 Hz, 1080p/24 Hz, 720p/50 Hz, 720p/60 Hz
720p/50 Hz, 720p/60 Hz, 1080p/24 Hz
Dimensions (WxHxD-inches) 17 7/8x 7 x 18 9/16
33.07
PC Input Signal
Format
HDMI VGA 60, VGA 59.94, SVGA 60, XGA 60, WXGA 60,
WXGA+ 60, SXGA 60, WSXGA+ 60, WUXGA 60
Weight (net) (lbs)
*4096x2160 Signal will be cropped equally on left and right side and image will be displayed 3840x2160.
