COLOR CCD CAMERA
CU-V801U
INSTRUCTIONS
CAUTIONS:
nTo prevent shock, do not open the cabinet. No user
serviceable parts inside. Refer servicing to qualified
personnel.
nWhen you are not using the AC Power Adapter for a long
period of time, it is recommended that you disconnect the
power cord from AC outlet.
LYT0008-045A
PRECAUTIONS WHEN USING OR STORING CCD
CAMERA
●Keep your camera free from oil vapour or steam.
Never put your camera at a place exposed to oil vapour or
steam.
This may cause trouble in your camera.
●Keep your camera away from a heater or direct sunlight.
Leaving your camera in the direct sunlight or near a heater
may damage the cabinet and the parts of your camera.
●Keep your camera free from water and moisture.
Do not use this product near water for example, near a bath
tub, wash bowl, kitchen sink, or laundry tub; in a wet
basement; or near swimming pool; and the like.
●Never use your camera outdoors.
You can use this camera only indoors.
●Be sure to use the appropriate power adapter (see back) at
rated voltage.
Using a wrong power adapter or wrong voltage may cause fire
or serious damage that cannot be restored.
Do not overload wall outlet, extension cords, or integral
convenience receptacles as this can result in a risk of fire or
electric shock.
●Never use your camera under high temperatures.
Be sure to use your camera in ambient temperatures of
0°C – 40°C.
Using your camera under high temperatures may deform the
cabinet as well as cause other troubles.
●Never direct the lens of your camera to the sun.
Irrespective of using or not using your camera, never allow the
light of the sun to directly come into the lens of your camera.
●Keep your camera free from moisture and dust.
Never leave your camera in such a place as is too moist and
dusty.
This may cause trouble in your camera.
IMPORTANT SAFETY INSTRUCTIONS
When using the color CCD camera, basic precautions should always be followed including following.
WARNING/ To reduce the risk of fire, electric shock, or injury, read all instructions carefully before using this color CCD camera.
Dear Customer,
Thank you for purchasing the JVC color CCD camera. Before
use, please read the safety information and precautions to
ensure safe use of your new color CCD camera.
This unit is for consumer use only and cannot be used as a
professional product.
ENGLISH
SAFETY PRECAUTIONS
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
This color CCD camera is designed to be used with
NTSC-type color television signals. It cannot be used with a
television of a different standard. Use the optional multi-
voltage AC Power Adapter as described on the other side of
this sheet. (An appropriate conversion adapter may be
necessary to accommodate different designs of AC outlets in
different countries.)
NOTE:
The rating plate (serial number plate) is located near the pivot
joint of the lens barrel of the unit.
PRECAUTIONS FOR HANDLING
●Handle your camera carefully.
Be careful not to drop your camera or give it strong shock or
vibration.
Enough care should be taken when carrying it too.
Shock and vibration may cause damage to your camera.
A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause
the product and cart combination to overturn.
●Keep lighting equipment away from your camera.
If you have lighting equipment near your camera, the heat
emitted from the lighting equipment may cause deformation or
failure to your camera.
Be sure to use any lighting equipment away from your camera.
●Dirt on the cabinet should be wiped out lightly with a soft
cloth.
If these parts become badly dirty, wipe out the dirt with a cloth
wrung out well after being submerged in a water-thinned
detergent and finish with a dry cloth.
●Most surface of the cabinet is made of plastics.
Wiping it with benzine and thinner may cause the painted film
to deteriorate or come off.
●Never use disinfectant.
Never use disinfectant of other volatile components near your
camera.
Or, never leave rubber or vinyl products in contact with your
camera for a long time.
This may deteriorate the surface of the cabinet.

POWER SOURCE CONNECTION
Use the provided AC Adapter.
AV CABLE CONNECTION
●Use the provided 1.5 m AV cable.
●For longer distance connections, use the optional AV extension
cable (JVC No. VC-V3731J/20 m) as well.
ATTACHING THE CAMERA TO THE
CEILING
●Use the optional ceiling mount kit (JVC No. CU-V602J).
●Be sure to refer to its instruction manual during installation.
©1997 VICTOR COMPANY OF JAPAN, LTD.
SPECIFICATIONS
TV system : NTSC
Total pixels : 537 (H) x 505 (V)
Effective pixels : 510 (H) x 492 (V)
Horizontal resolution : 310 TV Lines
S/N raito :46 dB
Minimum illumination : 12 lx
Video output signal : 1.0 Vp-p/75 Ω(composite video
signal)
Output connector : RCA pin jack
Focus range : Manual adjustment 5 cm —
AC adapter input voltage : DC 9 – 12 V
Power consumption : Approx. 2 W
Microphone : Non-directional electret condenser
Dimensions : 100 (W) x 61 (H) x 100 (D) mm
Weight : Approx. 150 g
Provided Accessories
AC Adapter, AV Cable (1.5 m)
Optional Accessories
AV Cable : VC-V3731J (20 m)
Installation Adapter : CU-V602J
E. & O. E. Design and specifications subject to change without notice.
OPERATION
ON
• •
I
POWER
OFF
nVideo and audio output terminal
Connect to video and audio input
terminal of your TV set or system.
nFocus adjust ring
Adjust the focus by turning the
ring left/right (5 cm – infinity)
nMicrophone
nPower LED indicator
nTripod mounting socket
nLens
nAC adapter connecting terminal
Connect to AC adapter.
nPower switch
