JVC TK-C553U - Fixed Color Dome Camera User manual

SECTION 6
PACKING
Camera
Carton Box
Carton
Carton
Carton
Instructions
SC96896 (U/E)
SC96897 (E only)
Note: Accessories above are subject to change without notice.
6.1 PACKING
COPYRIGHT © 1999 VICTOR COMPANY OF JAPAN, LTD.
TK-C553U/TK-C553E No. 6687
SERVICE MANUAL
TK-C553U/TK-C553E
COLOR DOME CAMERA
No. 6687
November 1999
COPYRIGHT © 1999 VICTOR COMPANY OF JAPAN, LTD.
Printed in Japan
(S)
VICTOR COMPANY OF JAPAN, LIMITED
100% recycled paper

TABLE OF CONTENTS
Section Title Page Section Title Page
INSTRUCTIONS
1. DISASSEMBLY
1.1 REPLACING THE FUSE ............................................... 1-1
1.2 REMOVING THE MAIN BODY .................................... 1-1
1.3 REMOVING THE DOME COVER ................................ 1-1
1.4 REMOVING THE LENS ASSEMBLY ............................ 1-1
1.5 REPLACING THE CCD IMAGE SENSOR .................... 1-2
1.5.1 Removing the CCD image sensor ....................... 1-2
1.5.2 Installing the CCD image sensor ......................... 1-3
1.6 REMOVING MAJOR CIRCUIT BOARD ....................... 1-3
1.6.1 Removing the SW board ..................................... 1-3
1.6.2 Removing the CPU board .................................... 1-3
1.6.3 Removing the POW board .................................. 1-4
1.7 REPLACEMENT OF IC223 ON THE SW-CPU
BOARD ................................................................ 1-4
1.8 EEPROM ..................................................................... 1-4
1.9 SERVICE MENU .......................................................... 1-5
2. ELECTRICAL ADJUSTMENTS
2.1 EQUIPMENT NECESSARY FOR ADJUSTMENT ........ 2-1
2.2 SPECIAL IMPLEMENTS FOR
ELECTRICAL ADJUSTMENT .............................. 2-1
2.3 STANDARD SETUP ..................................................... 2-1
2.4 SWITCH SETTINGS FOR ADJUSTMENT AND
TEST POINTS ...................................................... 2-2
2.5 ADJUST MODE ........................................................... 2-2
2.5.1 How to use the ADJUST Mode .......................... 2-2
2.5.2 How to use the ADJUST Mode with
the RM-P2580 ..................................................... 2-2
2.6 ADJUSTMENT OF THE WIDE-ANGLE LIMIT
POSITION ............................................................ 2-3
2.7 ADJUSTMENT OF VIDEO SIGNALS ........................... 2-4
3. DIAGRAMS AND CIRCUIT BOARDS
3.1 OVERALL WIRING DIAGRAM .................................... 3-2
3.2 BLOCK DIAGRAM ....................................................... 3-3
3.3 CCD BOARD SCHEMATIC DIAGRAM ........................ 3-4
3.4 CCD CIRCUIT BOARD ................................................ 3-4
3.5 SW BOARD SCHEMATIC DIAGRAM .......................... 3-5
3.6 SW CIRCUIT BOARD .................................................. 3-6
3.7 CPU/RCA BOARDS SCHEMATIC DIAGRAM .............. 3-7
3.8 CPU CIRCUIT BOARD ................................................. 3-8
3.9 RCA CIRCUIT BOARD ................................................. 3-8
3.10 POW BOARD SCHEMATIC DIAGRAM ....................... 3-9
3.11 POW CIRCUIT BOARD ............................................... 3-9
3.12 TERMINAL BOARD SCHEMATIC DIAGRAM ............. 3-9
3.13 TERMINAL CIRCUIT BOARD ...................................... 3-9
3.14 BLOCK DIAGRAMS of IC’s ....................................... 3-10
4. EXPLODED VIEW AND PARTS LIST
4.1 EXPLODED VIEW ....................................................... 4-1
5. ELECTRICAL PARTS LIST
5.1 CCD BOARD ASSEMBLY PARTS LIST 01 ............. 5-2
5.2 SW BOARD ASSEMBLY PARTS LIST 02............... 5-2
5.3 CPU BOARD ASSEMBLY PARTS LIST 03.............. 5-3
5.4 POW BOARD ASSEMBLY PARTS LIST 04............ 5-6
5.5 RCA BOARD ASSEMBLY PARTS LIST 05.............. 5-6
5.6 TERMINAL BOARD ASSEMBLY PARTS LIST 06.... 5-6
6. PACKING........................................................... Back cover

1-1
2
2
Ç
2
3
ı
Å
F1
POW board
1.1 REPLACING THE FUSE
(1) Set the power switch to OFF.
(2) Remove the POW board. (See section 1.6.3)
(3) Fuse F1 is located on the POW board.
(For the part No. of fuse, see Symbol No. 29 on page 4-2.)
CAUTION
Before replacing a fuse and in order to prevent a recur-
rence of the same trouble, investigate what caused the
fuse to blow, repair it and confirm normal operation. To
protect the equipment and provide safety, be sure to
replace with a fuse having the specified part number.
SECTION 1
DISASSEMBLY
Fig. 1-2
Fig. 1-4
1.3 REMOVING THE DOME COVER
(1) Rotate the dome cover Åin the direction of and re-
move it from the MAIN body.
Fig. 1-3
1.2 REMOVING THE MAIN BODY
(1) Loosen screw 1then rotate the Main Body in the direction
of the arrow to remove the Main Body from the ceiling.
Fig. 1-1
1.4 REMOVING THE LENS ASSEMBLY
(1) Remove the dome cover as described in section 1.3.
(2) Remove the three screws 2and the screw 3.
1

1-2
1.5 REPLACING THE CCD IMAGE SENSOR
䡵The image sensor is interchangeable only with a specified
image sensor.
䡵New image sensors and crystal filters should be handled so
as not to leave fingerprints or grease on their glass surfaces.
To remove attached dirt or grease, blow on the glass surface
until it becomes misted then wipe it gently with a cotton
swab. (Do not use alcohol or other similar substances.)
䡵After replacement, all of the adjustments should be performed
from the beginning.
䡵Note that the image sensor is susceptible to static damage.
Be sure to take anti-static measures before replacing it.
䡵After an image sensor has been removed, an electrical charge
may remain on the terminals of the camera circuit for a cer-
tain period of time.
If a new image sensor is inserted into the socket in this con-
dition, the image sensor may be instantly damaged by the
remaining electric charge. To prevent this happening, wait a
while (2 to 3 minutes) after removing an image sensor until
inserting another one in the socket.
䡵After the CCD board has been removed from the lens as-
sembly, the back-focus adjustment should be performed
again.
Fig. 1-7
Fig. 1-6
(4) Disconnect CN201, CN202, CN203, CN204 and CN303.
Fig. 1-8
1.5.1 Removing the CCD image sensor
(1) Remove the lens assembly as described in section 1.4.
(2) Remove the two screws 5and remove the wire guard ´,
and then remove CCD board.
(5) Remove the two screws 4and out the lens assembly Îin
the direction of the arrow.
(3) Pull up the upper plate ıand the ring Ç.
Fig. 1-5
ı
Ç
CN202
CN203
CN201
CN204
CN303
4
4
Î
5
´
5
CCD board

1-3
6
SW board
CN301
(3) Press the sensor holder extremity Ïthen remove the sen-
sor holder ˝to remove the CCD.
Fig. 1-9
Fig. 1-12
1.6 REMOVING MAJOR CIRCUIT BOARD
1.6.1 Removing the SW board
(1) Remove the upper plate and the ring as described in section
1.4.
(2) Remove the screw 6and disconnect CN301, and then re-
move the SW board.
Fig. 1-11
1.5.2 Installing the CCD image sensor
(1) Install the CCD image sensor in the reverse order to the
removal procedure.
Note : • Install the CCD slowly on the guide pin. (If placed in
the wrong direction, it cannot be installed.)
• For the low-pass filter installation position, see page
4-1 on [TK-C553 EXPLODED VIEW] $.
Fig. 1-10
1.6.2 Removing the CPU board
(1) Remove the SW board as described in section 1.6.1.
(2) Remove the three screws 7and remove the chassis cover
Ó.
Ï
˝Sensor holder
CCD
77
Ó
7

1-4
ˆ
1.7 REPLACEMENT OF IC223 ON THE SW-CPU BOARD
(1) A special tool is available for use in removing IC223 (please
purchase SUN HAYATO Model GY-X8 or similar tool
separetely). Two small screwdrivers can also be used in place
of the special tool.
(3) When inserting the IC, align the IC orientation and fit it into
position with a finger, taking care that the attached IC is not
tilted.
(2) When using the special tool, fit sections A of the tool into
grooves B on the opposite corners of the IC socket and re-
move the IC as if pinching it up.
When using small screwdrivers, fit their tips into the grooves
ay the opposite corners of the IC socket and remove the IC
as if pulling it up.
Fig. 1-17
A
B
B
Fig. 1-18
1.8 EEPROM
IC220 on the CPU board is an EEPROM which can erase and
write electrically and stores the following data.
1. SETUP MENU setting data
2. SERVICE MENU setting data
3. POSITION SETUP setting data
Fig. 1-16
Fig. 1-13
(3) Remove the three screws 8and remove CN205, and then
remove the CPU board.
Fig. 1-14
(3) Remove the two screws 9and remove the POW board.
Fig. 1-15
1.6.3 Removing the POW board
(1) Remove the CPU board as described in section 1.6.2.
(2) Remove the S. INSULATOR ˆ.
8
8
CPU board
CN205
9
POW board

1-5
1.9 SERVICE MENU
The SERVICE MENU mode is used during servicing. It is configured as shown below.
LEFT RIGHT SET
UP
DOWN
>MON I TOR . .
––SERVICE MENU––
A D J U S T . .
FACTORY SETT INGS
SPEC I AL SETT I NGS
END
FIX MODE PLSC1258 V0–06
IRIS Av Data 183
––MONITOR––
I R I S P k D a t a 6 5 0
IRIS TOTAL Data 127
DC I R I S L ENS 1 1 9
AGC Ga i n 0
W .BAL R–B Data –20
W .BAL Mg–G Data –11
RGain 470
BGain 872
FH 160
>FSC 62
––ADJUST––
YGAIN 66
ALC LEVEL 136
BURST 8 4
RGAIN 174
BGAIN 147
CGAIN 58
END MEMORY
> D I G I T A L Z O O M M A X X 2
––SPCAL SETTINGS––
END
MONITOR
Fig. 1-19
Fig. 1-20
SPECIAL
SETTING
ADJUST
UPPER PLATE
Fig. 1-21
Fig. 1-22
Fig. 1-19 is the SERVICE MENU default screen.
Select the item by using the "UP" and "DOWN" button. When an item is selected, press the "SET"
button. Items selected that contain the ".." display are entered to the menu as indicated below.
The setting contents on the right and left can be changed with the "LEFT" and "RIGHT" buttons.
When the setting contents of an item are changed, an "*" is displayed between the ">" and the
item name. When the setting contents are saved, the "*" will disappear.
FACTORY SETTING - When this is selected, all of the user setting items resume to the factory-set
default values. However the adjustment values are not changed.
END - to quit the SERVICE MENU.
FIX MODE PLSCD58 VO-06 - The ROM (CPU board IC223) parts no. and the version description
are displayed.
[Monitor Screen]
The camera status is displayed. The data displayed in the brackets ( ) indicates
the range. When the "SET" button is pressed, it resumes to the default screen.
Iris Av Data - The average value data of the luminance level within the
photometry area. (0 to 752)
Iris Pk Data - The luminance level peak data within the photometry area.
(0 to 752).
Iris Total Data - The luminance level data within the photometry area.
When all adjustments are carried out, the ALC is 128 and the
AGC is 115 as indicated (0 to 1962)
DC Iris Lens- This is the DC iris lens voltage data. 255 is indicated at 5 V.
(0 to 255 range)
AGC Gain - This is the AGC mode data. When the AGC mode is OFF, "0" is
displayed. 274 is displayed during 10dB and 589 during 20dB.
(0 to 675).
W. BAL R-B Data - The axis data of (R-B) and average value data of the
(Mg-G) on the vectorscope. (-1024 to 1023)
R Gain - This is the G gain against the R and B gain. (128 to 32640)
[Adjust Screen]
This is the adjustment menu. For details, see section 2.
[Special Setting Screen]
The maximum magnification of the digital zoom is set.
Values of x1, x2, x4 or x8 can be selected.
The default value is x2.
When the END is selected the unit returns to the initial screen.
While pressing the "SET" button, turn the power ON.

Instrument Condition
Oscilloscope Capable of measuring 100MHz or higher bands and calibrated.
Vectorscope Must be calibrated.
Frequency counter Readable in 8 or more digits. Constancy of 0.1 ppm/1 × 10–7 or more at 0°C to 40°C and calibrated.
Multimeter Input impedance of 10 MΩor higher and calibrated.
TV monitor Color type instrument with a 75 Ωvideo input.
SECTION 2
ELECTRICAL ADJUSTMENTS
2.2 SPECIAL IMPLEMENTS FOR ELECTRICAL ADJUSTMENT
2.1 EQUIPMENT NECESSARY FOR ADJUSTMENT
2-1
2.3 STANDARD SETUP
• For convenient adjustment of the lens to the proper angle, remove the dome cover.
• Set the dip switch on the (SW board S306) L/L to OFF and TERMINATION also to OFF.
1
Gray scale chart <Part No. : GS2L> 2 Color bars chart <Part No. : GC-2A>
Reflective type Reflective type Transmissive type
WYLCy G Mg R B
3 Color bars chart <Part No. : CC-2T>
WYLCy G Mg R B
Terminal base
assembly
AC 24 V
TK-C553
Color monitorWFMVectorscope
75 Ω
terminator
75 Ω
terminator
Oscilloscope
Test pattern
3200K halogen lamps

2.4 SWITCH SETTINGS FOR ADJUSTMENT AND TEST POINTS
2.5 ADJUST MODE
To make electrical adjustments, select the ADJUST mode from
the SERVICE MENU. (See page 1-5 “1.9 SERVICE MENU”)
2.5.1 How to use the ADJUST Mode
(1) Start-up
1) From the SERVICE MENU, select the “DOWN” button
and move the “>” cursor to “ADJUST”.
2) Press the “SET” button to set the ADJUST mode (Fig. 2-5-1).
(2) Adjustments
1) Press the “UP” or “DOWN” button to move the cursor
to the item you wish to adjust.
2) Press the “LEFT” or “RIGHT” button to adjust to a specified
value. For the items of which settings are changed, “*” will
appear between the cursor and the item name. When these
changes have been saved, the “*” will disappear.
(3) Saving the Settings
1) Press the “UP” or “DOWN” button to move the cursor
to “END”.
2) Press the “LEFT” or “RIGHT” button to set the END
setting to “MEMORY”.
3) Press the “SET” button to save the adjusted values.
NOTE : If the END setting is cleared and if the “SET” button
is pressed, the initial screen of the SERVICE MENU
will be resumed without saving the adjusted values.
2-2
2.5.2 How to use the ADJUST Mode with the RM-P2580
An adjustment can be executed by triggering the SERVICE
MENU from the RM-2580 when this is used.
(1) Start-up
1) Press the “MENU” button on the RM-P2580 for three
seconds to open the SETUP screen (see fig.2-5-2).
2) Use the “PAN/TILT” control lever to move the cursor to
“CAMERA”.
3) If the “SET” button is pressed on the RM-P2580 and
then the “ENTER” button is pressed four times within
four seconds, the SERVICE MENU will appear.
4) Use the “PAN/TILT” control lever to move the cursor to
“ADJUST”.
5) Press the “SET” button on the RM-P2580 to enter the
ADJUST mode (Fig. 2-5-1).
(2) Adjustment and Saving the Settings
Follow the same steps as described in 2.5.1 (2) and (3) ex-
cept that the ”PAN/TILT control lever is used in place of the
“UP”, ”DOWN”, ”LEFT”, ”RIGHT” buttons, and the “SET
button on the RM-P2580 is used in place of the “SET” but-
ton. To exit from the SETUP screen, press the “MENU”
button on the RM-P2580.
Fig. 2-5-1
Fig. 2-5-2
FH 168
> F S C 1 0 9
––ADJUST––
YGAIN 121
ALC LEVEL 131
BURST 7 1
RGAIN 139
BGAIN 124
CGAIN 68
END MEMORY
*
POS I T I ON SETUP . .
––S E T U P ––
>CAMERA..
CONTROL UN I T . .
L/L OFF
TERMINAL OFF
TP305 fsc
TP305 FH
Adjustment button

2-3
Item Mode Adjustment steps
Measuring
instrument &
Input signals
No.
Measuring point ( *)
Adjustment points ( -)
Adjustment level ( +)
2.6 ADJUSTMENT OF THE WIDE-ANGLE LIMIT POSITION
• This is to adjust the wide-angle limit position for the zoom ring. This instrument is delivered after the camera has been adjusted.
Thus, there are no adjustment needs except for the replacement of the lens assemblies.
• This unit uses a variable-focal lens, if the wide-angle limit position is not in the right position, the correct focus may not be
obtained depending on the zoom position. Thus, the following adjustment must be performed when replacing the lens assem-
bly.
(1) Loosen the wide-angle limit setting screw Å
of the lens.
1 Wide-angle
limit position
adjustment
AGC MODE
↓
OFF
(4) While aligning the wide-angle limit setting
screw Åto the edge of the zoom ring to set
the limit position, tighten the screw.
(2) Turn the focus ring of the lens to the ıposi-
tion as shown in the left diagram.
(3) Bring a subject at a distance of 3 meters into
focus (A distance of over 3 m can be consid-
ered as infinity (∞)).
N∞
TW
Å
Å
ı
Align the screw and
the ring edge.
Focus ring
Zoom ring

2-4
Item Mode Adjustment steps
Measuring
instrument &
Input signals
No.
Measuring point ( *)
Adjustment points ( -)
Adjustment level ( +)
2.7 ADJUSTMENT OF VIDEO SIGNALS
(1) Move the ADJUST Menu cursor to “FSC”.
(2) Press the “LEFT” or “RIGHT” button to ad-
just FSC to the specified value.
1 FSC
adjustment
Frequency
indicator
(1) Move the ADJUST Menu cursor to “FH”.
(2) By using the left and right buttons, adjust the
voltage to 3.5V.
2FH
adjustment
Digital Voltmeter
(1) Move the ADJUST Menu cursor to “ALC
LEVEL”.
(2) Press the “LEFT” or “RIGHT” button to set
the maximum value.
(3) Move the ADJUST Menu cursor to “Y GAIN”.
(4) Press the “LEFT” or “RIGHT” button to ad-
just the level to the specified value.
3 Y GAIN
adjustment
Oscilloscope
*
TP305 [SW]
- LEFT or RIGHT button
+ 3.579545 MHz
<U model>
+ 4.433618 MHz
<E model>
ADJUST
mode FSC
*
TP301 [SW]
- LEFT or RIGHT button
+ 3.5 V
ADJUST
mode FH
ADJUST
mode
Y GAIN
(1) Attach the ND50 filter over the lens.
(2) Move the ADJUST Menu cursor to the “ALC
LEVEL”.
(3) Press the “LEFT” or “RIGHT” button to ad-
just the level to the specified value.
4 ALC LEVEL
Adjustment
Oscilloscope
(H-rate 10 : 1) or
W, F, M grayscale
chart
*
VIDEO OUT
75 Ωresistor
terminated
- LEFT or RIGHT button
+ 714 mVp-p (100 IRE)
<U model>
700 mVp-p (100 %)
<E model>
ADJUST
mode
ALC LEVEL
* VIDEO OUT
75 Ωresistor
terminated
- LEFT or RIGHT button
+ 790 mVp-p (111 IRE)
<U model>
780 mVp-p (111 %)
<E model>

2-5
Item Mode Adjustment steps
Measuring
instrument &
Input signals
No.
Measuring point ( *)
Adjustment points ( -)
Adjustment level ( +)
(1) Move the ADJUST Menu cursor to “R GAIN”
or “B GAIN”.
(2) Press the “LEFT” or “RIGHT” button to ad-
just the R GAIN or B GAIN so that the carrier
leak is reduced to the minimum.
If a vector scope is used to perform this step,
raise the vector scope gain and adjust it to
bring the noise to the center.
6 White
Balance
Adjustment
Oscilloscope
(H-rate 10 : 1) or
W, F, M grayscale
chart (Just Scan)
(1) Move the ADJUST Menu cursor to “BURST”.
(2) Press the “LEFT” or “RIGHT” button to ad-
just it to the specified value.
5 BURST
Adjustment
Oscilloscope
(H-rate 10 : 1)
*
VIDEO OUT
75 Ωresistor
terminated
- LEFT or RIGHT button
+ 286 mVp-p (40 IRE)
<U model>
+ 300 mVp-p
<E model>
ADJUST
mode
BURST
ADJUST
mode
R GAIN
B GAIN
*
VIDEO OUT
75 Ωresistor
terminated
- LEFT or RIGHT button
+ Minimum carrier leak
< U model > < E model >
+ Noise in the center

2-6
(1) Move the ADJUST Menu cursor to “END”.
(2) Press the “LEFT” or “RIGHT” button to set
the END setting to “MEMORY”.
(3) Press the “SET” button to save the adjust-
ment, and the SERVICE MENU will be dis-
played.
(4) Move the SERVICE MENU cursor to “END”
and press the “SET” button to exit the menu
screen.
* Set the END setting to “CLEAR” and press
the “SET” button, the adjustment will then
not be put into the memory and a return will
be made to the value that was in place be-
fore the adjustment was made.
8 Adjustment
Memory
Mode
Item Mode Adjustment steps
Measuring
instrument &
Input signals
No.
When the color bar chart is of the Reflective Type:
(1) Move the ADJUST menu cursor to the ALC
LEVEL, then adjust the white level to 100%
by using the LEFT and RIGHT buttons. (Later
on the adjustment values will be returned to
the original values, so write down the adjust-
ment values).
(2) Move the ADJUST menu cursor to C GAIN,
then adjust the red level of the color bar to
300 mVp-p.
(3) Move the ADJUST menu cursor to the ALC
LEVEL, then return the ALC LEVEL to its origi-
nal value.
7 C GAIN
Adjustment
Measuring point ( *)
Adjustment points ( -)
Adjustment level ( +)
Oscilloscope
Color-bar chart
(Reflective Type)
ADJUST
mode
C GAIN
*
VIDEO OUT
75Ωresistor terminated
- LEFT or RIGHT button
+ 300mVp-p
R
< U model > < E model >
––ADJUST ––
FH 128
YGAIN 105
A L C L E V E L 1 2 8
BURST 1 0 5
RGAIN 128
BGAIN 128
C G A I N 1 0 5
> E N D M E M O R Y
ADJUST
mode
END
When the color bar chart is of the Transmissive
Type:
(1) Move the ADJUST menu cursor to the ALC
LEVEL, then adjust the white level to 100%
by using the LEFT and RIGHT buttons. (Later
on the adjustment values will be returned to
the original values, so write down the adjust-
ment values).
(2) Move the ADJUST menu cursor to “C GAIN”.
(3) Press the “LEFT”or “RIGHT”button to bring
the R (Red) of the vectorscope into the center
of .
(4) Move the ADJUST menu cursor to the ALC
LEVEL, then return the ALC LEVEL to its origi-
nal value.
Vectorscope
Color-bar chart
(
Transmissive Type )
*
VIDEO OUT
75Ωresistor terminated
- LEFT or RIGHT button
+ Bring the R (Red) of
the vectorscope to the
center of .
ADJUST
mode
C GAIN
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

3-1
SECTION 3
DIAGRAMS AND CIRCUIT BOARDS
 SCHEMATIC DIAGRAM NOTES
• Schematic safety precaution
!Parts are safety related parts.
When replacing them, be sure to use the specified parts.
• Voltage and waveform measurements
Voltage: Measured with digital voltmeter in DC range;
lens closed.
Waveform: Gray scale illuminated at more than 4000 lux at
3200K lighting.
• Unit of value
Unless otherwise specified
1) Resistance is in Ω(1/6 W)
2) Capacitance is in µF
3) Inductance is in µH
 REPLACING SURFACE MOUNT “CHIP” COMPONENTS
• Some resistors, shorting jumpers (0 Ωresistance), ceramic
capacitors, transistors, and diodes are chip parts. These chip
parts cannot be reused after they are once removed.
• Chip resistors used in some circuits are of high precision
type having little error in resistance.
To demonstrate the full capacity of this set, place an order
for proper parts referring to the diagrams and parts lists in
the section 5.
• Soldering cautions:
1) Do not apply heat for more than 3 seconds.
2) Avoid using a rubbing stroke when soldering.
3) Discard removed chips; do not reuse them.
4) Supplementary cementing is not required.
5) Use care not to scratch or otherwise damage the chips.
[3] Chip diodes
 CHIP PARTS PIN ARRANGEMENT
[1] Digital transistors
R1
R2
C
BE
R1
R2
C
BE
DTC 1
1 2 3
DTB 1
DTA 1
1 2 3
(Top view) (Top view)
1Two digits show resistance of R1 in abbreviation.
43 : 4.7 kΩ
14 : 10 kΩ
24 : 22 kΩ
44 : 47 kΩ
2Roman letter show the resistive ratio between R1 and R2
in abbreviation.
E : R2/R1 = 1/1
Y : R2/R1 = 5/1
W : R2/R1 = 2/1
X : R2/R1 = 1/2
T : R2 is opened.
3Symbol the shape of resistor in abbreviation.
[2] Chip transistors and chip F.E.T.s
(Top view) (Top view)
(Top view) (Top view)
MA143A/MA742 MA142WA MA142A
(Top view)(Top view) (Top view)
C
BE
G
SD
C
BE
2SD
2SC
2SB
2SJ2SK
2SA
G
SD

3.1 OVERALL WIRNING DIAGRAM
RCA
SW
CCD
CPU POW
TERMINAL
CN701
CN700 CN2
CN600
CN204
CN1CN205
CN301 CN206
CN202
CN2
CN201
CN203
CN1
7.0V 7.0V
15V15V
TXH
TXC
RXC
SI
SO
EX
GND
LEFT
RIGHT
DOWN
GND
RXH
UP
SET
fsc CONT
SHUTTER
HD
GND
VBS
FH DEC
IRIS
GND
CCU
VD
GND
V RESET
L/L
DVD
fsc
GND
9V
3.3V
9V 5V 5V
3.3V
SI SO EX DOWN RIGHT RXH GND LEFT GND RXC TXC TXH UP HD VD L/L fsc
fsc CONT
V RESET
FH DEC
SHUTTER GND DVD GND CCU GND IRIS VBS GND SET
5V 5V 9V 3.3V 9V 3.3V
7.5V
15V
GND
GND
5V
9V
9V
GND(RXC)
GND(RXH)
GND(TXH)
GND(TXC)
GND(L/L)
CCU(VBS)
5V
GND
5.7V
15V
7.5V
GND
GND
5V
9V
GND(RXC)
9V
GND(RXH)
GND(TXH)
CCU(VBS)
GND(L/L)
GND(TXC)
5V
5.7V
GND
AC24V/DC12V()
AC24V/DC12V()
8
7
6
5
4
3
2
1
VIDEO GND
TXC
TXH
RXH
RXC
VBS
AC24V/DC12V()
AC24V/DC12V()AC24V/DC12V( )
AC24V/DC12V()
GND GND VBS GND TXC RXH RXC TXH
RXC
RXH
TXH
TXC
GND
VBS
GND GND
1 2 3 4 5 6 7 8 9
10
1 2 3 4 5 6 7 8 9
10
M.OUT
GND
M.OUT
GND
22
1
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
GND
GND
V SUB
GND
GND
H2
H1
RG
GND
H2
GND
H1
GND
RG
GND
V SUB
GND
GND
10
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
9
10
GND
GND
V4
V3
V2
V1
NC
GND
CCD OUT
GND
GND
V4
V3
V2
V1
GND
CCD OUT
1
2
3
4
5
6
7
3
2
1
9
8
7
6
5
4
3
2
1
1
1C
3-2 3-2

SLICE
IC206
IC206
TP21
TP22
VD
DVD
TP301
IC305
T1
L1
IC2
IC3
IC4
IC5
IC6
-7.5V
+15V
+5V
+8.5V
VBS
RXC
RXH
TXH
TXC
AC24V/DC12V()
AC24V/DC12V()
POW BOARD
TERMINAL BOARD
3.2 BLOCK DIAGRAM
1C
TP1
3-3 3-3

CCD BOARD SCHEMATIC DIAGRAM
CCD CIRCUIT BOARD
FROM/TO CPU
CN201,CN203 FROM/TO CPU CN202
CCD
10.2 10.2
-0.2
-0.3
-7.8
-7.9
-8.5
4.6
5.0
SIDE B SIDE A
3.3
3.4
2C(両面)
3-4 3-4
3-4
NC : OPEN SC94298

SW BOARD SCHEMATIC DIAGRAM
FROM/TO CPU CN206
SC93501
The components shown in are not actually mounted on the board.
PHASE
COMP
AUDIO
3.5
00
4.8
0
0.4
3.3
0.4
5.6
3.3
2.8
2.8 4.1
2.8
2.8 1.4
4.9
0
4.9
4.4
0.1
2.3
2C
R317
OPEN
R318
0
R335
390k
C400
OPEN
OPEN 0
R336
820k
R415 OPEN
OPEN
3.3k
C330
0.027
R378
OPEN
R379
0
R375
0R400
0
R396
OPEN
R397
OPEN
3-5 3-5
3-5
R401
OPEN
R408
OPEN
R409
OPEN

1234
A
B
C
D
4321
A
B
C
D
2C(両面)
14
8
17
169
18
ADDRESS TABLE OF BOARD PARTS
Each address may have an address error by one interval.
Side Y axis
X axis
A-1C
IC300
IC302
IC303
IC304
IC305
IC306
IC307
Q300
Q301
Q302
Q303
Q304
Q305
Q310
Q311
Q312
Q313
D300
D301
D302
D303
D304
D305
D306
D307
B-2C
B-4C
B-4B
B-3D
B-4A
B-1A
B-4A
B-1B
B-1C
B-2C
B-2C
B-3C
B-4B
B-2C
B-3C
B-1A
B-1A
B-1C
B-2D
A-2D
B-3C
B-1A
B-1A
B-1A
B-1A
D308
D309
D310
D311
R300
R301
R302
R303
R304
R305
R306
R307
R308
R309
R310
R311
R312
R313
R314
R315
R316
R317
R318
R320
R321
R322
B-1B
B-1B
B-1C
B-1B
B-1B
B-1B
B-1B
B-1C
B-1B
B-1B
B-1C
B-1C
B-2C
B-2C
B-2C
B-2C
B-2C
B-2C
B-2C
B-2C
B-1C
B-2C
B-2C
B-3C
B-3C
B-3C
R323
R324
R325
R326
R327
R328
R329
R330
R331
R332
R333
R334
R335
R336
R337
R338
R339
R340
R341
R342
R343
R344
R345
R346
R347
R348
R349
B-3C
A-3C
B-4C
A-4C
A-4B
A-4C
A-4C
A-4C
A-4B
A-4C
A-4C
A-4B
B-4B
B-4B
B-4B
B-1B
B-3B
B-2C
B-2C
B-3C
B-3C
B-3D
B-3D
A-3D
B-3D
B-3D
B-3D
R350
R351
R352
R353
R354
R355
R356
R357
R358
R359
R360
R361
R362
R363
R364
R365
R366
R367
R368
R369
R370
R371
R372
R373
R374
R375
R376
B-3D
B-3D
B-2D
B-2D
B-2C
B-2D
B-2C
B-2D
B-4D
B-3D
B-3D
B-3C
B-3D
B-3C
B-3C
B-4B
B-4B
B-4C
B-4C
B-4C
B-4C
B-4C
B-4C
B-1B
B-1C
B-4A
B-4B
R378
R379
R380
R381
R382
R383
R384
R385
R386
R387
R388
R389
R390
R391
R396
R397
R398
R400
R401
R402
R403
R404
R405
R406
R407
R408
R409
B-4B
B-4B
B-3A
B-4A
B-4A
B-4A
B-4A
B-3A
B-4A
A-4A
B-4A
B-4A
B-4A
B-4A
B-2C
A-3C
B-3B
A-4D
A-1B
B-1B
B-1B
B-1B
A-1A
A-1A
B-1A
B-1A
A-1A
R410
R411
R412
R413
R414
R415
R416
VR300
C300
C301
C302
C303
C304
C305
C306
C307
C308
C309
C310
C311
C312
C313
C320
C321
C322
B-1A
B-1A
B-1A
B-1A
B-1A
B-4A
B-4A
A-3D
B-1B
B-1C
A-1C
A-1C
B-2C
B-2C
B-2C
B-2C
B-1C
B-1C
A-2C
A-1B
B-1B
A-1B
B-3C
A-4B
B-3C
C323
C324
C325
C326
C327
C328
C329
C330
C331
C332
C333
C340
C341
C342
C343
C344
C345
C346
C347
C348
C349
C350
C351
C352
C353
C354
C355
B-4C
A-4C
A-4C
A-4C
A-4B
A-4B
B-4B
B-4B
B-1C
A-1C
B-4B
B-2D
B-3D
B-3C
A-3D
B-3C
A-3D
A-3D
B-3D
B-2D
B-2D
B-2D
B-2C
B-2C
B-4C
B-3C
B-3D
C356
C357
C358
C359
C360
C361
C362
C370
C371
C372
C373
C374
C375
C376
C377
C378
C379
C380
C381
C400
L300
L301
L302
L303
L304
L305
B-3C
B-3C
B-4C
B-4B
B-4B
B-4B
B-3C
B-3A
B-4A
B-4A
A-4A
B-4A
B-4A
B-4A
B-4A
B-4A
B-4A
B-1A
B-1A
B-4B
B-1B
A-2C
B-4D
B-3D
B-3D
B-3C
L306
L307
L308
TP301
TP302
TP304
TP305
LC300
CN300
CN301
CN302
CN303
S301
S302
S303
S304
S305
S306
X300
B-4B
B-4A
A-1A
A-2D
A-2D
A-1D
A-1D
A-4A
A-1A
A-1B
A-3C
A-4A
A-4A
A-4B
A-4B
A-4B
A-4C
A-3C
A-2D
SW CIRCUIT BOARD
SIDE B
SIDE A
3.6
3-6
3-6
SET
UP
RIGHT
DOWN
LEFT

AGC 10bit
ADC
OUTPUT LATCH
CDS/AGC
AD
V.DRIVE
CHARACTER
GEN
DA
CPU
EEPROM
ROM
Y/C MIX
2C
CDS
CC y
yBLK
BLK
MTRX D/A
D/AMOD
1/4
1/n
1/2
1/m
BUF
F.F.
C GMIX
C GMIX
MTRX
GAIN
MTRX
MLTPLX
BUF
P/C
1H
DL
MLTPLX.
OB
CLAMP
PRE-
KNEE
DECODE
TIME-DIV.
FROM/TO CCD CN1
FROM/TO CCD CN2
FROM/TO CCD CN1
FROM/TO SW CN301
FROM/TO POW CN1
SC92659
3.7
3.0
0.1
0.1
3.0
2.9
3.0
2.9
7.1
7.1
0.3
0.2
6.7
6.7
3.3
0
1.3
1.3
1.3
1.3
0
2.1
0
0
0
0
3.31.6
0.11.0
1.0
3.3
1.5
1.8
5.0
2.7
2.9
4.7
2.5
4.6
4.6
4.0
4.6
4.9
2.5
0
0
4.6
4.8
00
0
2.6
5.0
0
4.2
4.2
00
1.5
2.5
4.8 2.9
1.6
3.0
1.0
1.0
0
2.7
2.3
5.0
1.7
0.1
0.1
2.9
2.9
2.9
3.0
3.0
3.0
0
2.9 3.1 02.9 1.4 2.6 0.1
1.4
2.9
0.2
0.7
2.8 0.2 0
1.5 3.1
3.1
0.9
0.9 0
1.5 1.6
1.5
0
3.3
0
3.3
0
0.5
1.8
0.5
0.5
0
0
3.3
0
3.0
0
1.8
0
0
3.0
0
1.5
2.6
2.2
3.3
2.4
0
1.4
2.5
0.8
4.9
4.9
0
2.5
3.2
3.2
3.1
3.2
3.2
4.9
4.8
2.9
0
4.9
0
4.9
4.8
4.6
4.9
4.9
4.9
0
4.9
4.9
4.9
0.9
4.9
4.9
4.9
4.9
4.6
4.6
4.0
4.9
0
4.9
0
0
4.9
4.9
2.5
2.2 2.6 2.2 2.6 1.9 1.6 2.5 2.5 2.7 1.8 4.9
4.9
4.9
4.9
4.9 4.9
4.9
4.9
4.9
4.9
5.0
4.8
4.7
4.9
2.5
5.0
0
0
4.9
0
0
0
5.6
4.9
4.9
4.9
2.6
4.9
0
4.9
0
0
0
0
5.0
2.6
1.4
2.2
4.2
3.0
4.8
0.1 0.8
2.7
2.2
2.7
2.5
0
2.1
5.1
0
3.0
2.6
2.4
3.1 2.9
2.8
0.5 1.2
2.2 3.1
1.5
3.8
2.7 2.2
0.1
4.5 0
1.4
0.1
2.2 2.7
2.6
2.8
0.2 5.0
0.7
0.7
3.9
2.1
2.1
2.0 04.1
0.9
3.1
1.2
1.4
1.4 3.3
2.0 2.2 2.1 04.2
0.3
1.2 05.0 0
0
0
2.2
1.3
2.1
2.5
2.1
0.9
1.8
2.8
2.6
2.5
1.70
1.92.6
2.3
2.5
2.3
2.5
2.3
2.6
3.0
3.0
3.5
5.6
3.3
3.3
1.7
1.3
1.7
2.0
1.3
3.1 3.1 3.1
1.1 1.8
1.4
JK600
RCA BOARD
3-7
3-7
CPU/RCA BOARDS SCHEMATIC DIAGRAM
+5V(A)
R354
0
IC223
PLSC1258
Symbol No.
NC : OPEN
+5V(D)
