JVC TK-WD31 User manual

For Customer Use:
Enter below the Serial No. which is
located on the body. Retain this
information for future reference.
Model No. TK-WD310
Serial No.
COLOR VIDEO CAMERA
TK-WD310 INSTRUCTIONS
(A)
LWT0181-001B-H

IMPORTANT SAFEGUARDS
1. Read all of these instructions.
2. Save these instructions for later use.
3. All warnings on the product and in the operating instructions should
be adhered to.
4. Unplug this appliance system from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning.
5. Do not use attachments not recommended by the appliance manu-
facturer as they may cause hazards.
6. Do not use this appliance near water - for example, near a bathtub,
washbowl, kitchen sink, or laundry tub, in a wet basement, or near
a swimming pool, etc.
7. Do not place this appliance on an unstable cart, stand, or table. The
appliance may fall, causing serious injury to a child or adult, and
serious damage to the appliance.
Use only with a cart or stand recommended by the
manufacturer, or sold with the appliance. Wall or
shelf mounting should follow the manufacturer’s in-
structions, and should use a mounting kit approved
by the manufacturer. An appliance and cart combi-
nation should be moved with care.
Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to
overturn.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3125A
I
These are general IMPORTANT SAFEGUARDS and certain items
may not apply to all appliances.

8. Slots and openings in the cabinet and the back or bottom are pro-
vided for ventilation, and to insure reliable operation of the appli-
ance and to protect it from overheating, these openings must not be
blocked or covered. The openings should never be blocked by plac-
ing the appliance on a bed, sofa, rug, or other similar surface.
This appliance should never be placed near or over a radiator or
heat register. This appliance should not be placed in a built-in in-
stallation such as a bookcase unless proper ventilation is provided.
9. This appliance should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of
power supplied to your home, consult your dealer or local power
company. For appliance designed to operate from battery power,
refer to the operating instructions.
10. This appliance system is equipped with a 3-wire grounding type
plug (a plug having a third (grounding) pin). This plug will only fit
into a grounding-type power outlet. This is a safety feature. If you
are unable to insert the plug into the outlet, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of
the grounding plug.
11. For added protection for this product during a lightning storm, or
when it is left unattended and unused for long periods of time, un-
plug it form the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product due to lightning
and power-line surges.
12. Do not allow anything to rest on the power cord. Do not locate this
appliance where the cord will be abused by persons walking on it.
II

13. Follow all warnings and instructions marked on the appliance.
14. Do not overload wall outlets and extension cords as this can result
in fire or electric shock.
15. Never push objects of any kind into this appliance through cabinet
slots as they may touch dangerous voltage points or short out parts
that could result in a fire or electric shock. Never spill liquid of any
kind on the appliance.
16. Do not attempt to service this appliance yourself as opening or re-
moving covers may expose you to dangerous voltage or other haz-
ards. Refer all servicing to qualified service personnel.
17. Unplug this appliance from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the appliance.
c. If the appliance has been exposed to rain or water.
d. If the appliance does not operate normally by following the oper-
ating instructions. Adjust only those controls that are covered by
the operating instructions as improper adjustment of other con-
trols may result in damage and will often require extensive work
by a qualified technician to restore the appliance to normal op-
eration.
e. If the appliance has been dropped or the cabinet has been dam-
aged.
f. When the appliance exhibits a distinct change in performance -
this indicates a need for service.
III

18. When replacement parts are required, be sure the service techni-
cian has used replacement parts specified by the manufacturer that
have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
19. Upon completion of any service or repairs to this appliance, ask the
service technician to perform routine safety checks to determine
that the appliance is in safe operating condition.
IV

Safety Precautions
FOR USA AND CANADA
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE.REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash wish arrowhead symbol, within an equi-
lateral triangle is intended to alert the user to the presence
of uninsulated "dangerous voltage" within the product's en-
closure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is in-
tended to alert the user to the presence of important oper-
ating and maintenance (servicing) instructions in the litera-
ture accompanying the appliance.
Information for USA
This device complies with part 15 of the FCC Rules. Changes or modifica-
tions not approved by JVC could void the user’s authority to operate the
equipment.
V

Due to design modifications, data given in this instruction book are sub-
ject to possible change without prior notice.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOIS-
TURE.
AVERTISSEMENT:
POUR EVITER LES RISQUES D’INCENDIE OU
D’ELECTRO-CUTION, NE PAS EXPOSER L’APPAREIL A
L’HUMIDITE OU A LA PLUIE.
INFORMATION (FOR CANADA)
RENSEIGNEMENT (POUR CANADA)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Class B est conforme á la norme NMB-003
du Canada.
VI

2
Thank you for purchasing this product.
(These instrustions are for TK-WD310U and TK-WD310E.)
Before beginning to operate this unit, please read the instruction
manual carefully in order to make sure that the best possible per-
formance is obtained.
Features
䡵Backlight compensation over a wide area is realized by the 14-bit
Wide Dynamic Range feature.
The Wide Dynamic Range feature controls the exposure time using
a maximum of 5 sampling timing for the image within a single screen.
Even when shooting in areas with large difference in lightning, sub-
jects with difference in brightness can be viewed in a clear and natu-
ral state.
䡵1/3-inch high-resolution DPS device adopted as shooting element
to realize high picture quality with no smearing or blooming in areas
with high luminance. In addition, 1.9lx (during F1.2, 50%, AGC HIGH
setting) is realized for minimum subject brightness.
䡵Horizontal resolution of 480 lines (typ.) and vertical resolution of over
400 lines allow display of finely detailed video.
䡵New device adopted for use even under strong electric field condi-
tions.
䡵Compatible with CS mount and VIDEO auto iris/DC auto iris.
*When using the C mount lens, C mount adapter is required.
䡵Various settings in each menu screen are possible.
Menu settings can be performed easily using single button opera-
tions.
䡵3 white balance modes of ATW, AWB and MANUAL are available.
ATW mode that adjusts the white balance automatically according
to the changes in lighting conditions (color temperature) or AWB/
MANUAL mode that automatically or manually adjusts and locks the
white balance of specific lighting conditions can be selected.
䡵Camera title setting and display can be made.
䡵Compact design allows installation in narrow spaces.
INTRODUCTION

3
䡲Before starting an important recording, be sure to perform a test
recording in order to confirm that a normal recording is possible.
䡲We do not accept liability for the loss of a recording in the case of
it becoming impossible to record due to a problem in the video
camera, VCR or video tape.
䡲We do not accept liability for any damage to the camera in cases
when it is dropped because of incomplete installation due to not
observing the installation instructions correctly. Please be careful
when installing the camera.
Characters and symbols used in this instruction manual.
CAUTION : Cautionary notes concerning operation of the unit.
MEMO : Reference such as restrictions of features, etc.
墌:Reference page or item.
EASY INSTALLATION
The factory default settings are intended to give easy installation.
Please attach a lens, a power supply, a video cable and mount the
camera securely. You should now have good images.
The additional information contained in this handbook is intended to
give additional flexibility to more demanding installations.

4
Contents
INTRODUCTION
Features ............................................................................................. 2
Contents ............................................................................................. 4
Operating Precautions ....................................................................... 5
Names and Operations of Parts ......................................................... 8
CONNECTION/INSTALLATION
Basic System ................................................................................... 13
Mounting the lens ............................................................................. 14
Connections on the back ................................................................. 16
Mounting the camera ....................................................................... 18
Auto iris lens adjustment .................................................................. 20
Back focus adjustment ..................................................................... 22
MENU SETTING
Menu settings ................................................................................... 24
Menu tree ......................................................................................... 26
About menus .................................................................................... 27
FOCUS ADJUST screen .................................................................. 27
VIDEO ADJUST screen ................................................................... 28
WDR CUSTOM SETTINGS screen .............................................. 29
MANUAL WHITE BALANCE screen ............................................. 34
CAMERA SETTINGS screen ........................................................... 35
LENS ADJUST screen .................................................................. 35
CAMERA TITLE EDIT screen ....................................................... 37
FACTORY SETTINGS screen ......................................................... 39
OTHERS
Troubleshooting ............................................................................... 40
Specifications ................................................................................... 41

5
Operating Precautions
●To save energy, when it is not being used turn the system’s power
off.
●This camera has been designed for indoor use.
When you use it outdoors, be sure to use an appropriate housing.
●Do not install or use the camera in the following places.
•In a place exposed to rain or moisture.
•In a place with vapor or oil soot, for example in a kitchen.
•When the ambient temperature rises above or falls below the ac-
ceptable range (from –10°C to 50°C).
•Near a source of radiation, X-rays, strong radio waves or magne-
tism.
•In a place where corrosive gasses are generated.
•In a place subject to vibration.
•In a place with excessive dirt.
●If this camera and the cables connected to this camera are used
where there are strong electromagnetic waves or where there is
magnetism present, for example near a radio or TV transmitter, power
transformer or an electric motor, the picture may produce noise and
the colours may be affected.
●This camera incorporates an AGC circuit. As a result, when it is
used under low light conditions, the camera sensitivity is automati-
cally boosted and the picture may look uneven. However, this is not
a malfunction.
●When this camera is used in the ATW mode, the recorded colours
may be slightly different from the actual colours due to the opera-
tional principles of the auto-tracking white balance circuit. However,
this is not a malfunction.
●Hunting may occur depending on the used lens. However, this is not
a malfunction of the unit.
●The screen surroundings may appear dark depending on the used
lens.
INTRODUCTION

6
Operating Precautions (continued)
●The white balance (ATW) of this device is optimally set for sunlight.
Proper white balance may not be achieved for artificial lighting such
as fluorescent lighting, etc.
●If you use this camera in locations where the camera is exposed to
fluorescent light, a slow color change may occur.
(White balance normal = 5,400 K, range is 2,500 K to 10,000 K.)
●AGC HIGH(×2) and up: in this mode, ATW white balance may be
inaccurate.
●White balance performance decreases under poor lighting condi-
tions.
●Observe the following when carrying out camera maintenance.
•Turn the power OFF before proceeding to carry out maintenance.
If it is contaminated seriously, clean the contaminated part with a
cloth (or a tissue) which has been soaked in a solution of water and
a neutral detergent.
●The unit is to be powered by a DC 12 V or an AC 24 V power supply.
The AC 24 V power supply should conform to the following:
U type : Class 2 only
E type : Isolated power supply only
●The beat may sometimes appear on the screen if gain is raised
when the line lock is in use, but the phenomenon takes place due to
the fluctuation of power frequency and is not a malfunction.
●At Low light levels, video iris lens may “Hunt”. Please adjust iris
level on lens to minimise hunting.
●Recommended range of operating temperature is 0°C to 35°C de-
grees. The camera will function outside these parameters to –10°C
to 50°C degrees. But processing errors may be apparent.
●Line-Lock is set for 50 Hz ±0.02 Hz. If line frequency is outside this
tolerance, picture may jitter and some interference may be visible in
high contrast scenes.
●At low light level, when the slow shutter functions the screen may be
tinted.
INTRODUCTION

7
●Blemishes: Small spots are normal, the camera contains compen-
sation functions for blemishes above 120 mV (p-p) in value. Please
contact your JVC authorised dealer for further information.
●For temperatures higher than the recommended temperature, the
slow shutter may not work correctly.

8
INTRODUCTION
Names and Operations of Parts
[Front and Bottom]
1Lens mount
For use with CS mount lens.
(C-mount lenses require a conversion ring.)
2Backfocus adjustment ring
Adjusting the back focus during lens installation.
Please refer to “Back focus adjustment” on 墌Page 22 for instruc-
tions on how to adjust the back focus.
3
12
4
5
6
7

9
3[BF LOCK] Back focus locking screw (×2: 2 mm)
This serves to fix the back focus-adjusting ring.
4Camera-mounting bracket
The bracket has been attached on the bottom of the camera before
shipment. It can also be attached on the top according to the cir-
cumstance.
To re-attach the bracket use the threaded holes at the top, with the
camera mounting bracket locking screws 7.
5Camera-mounting screw hole (1/4 inch)
Use this hole when mounting the camera
onto a fixer, pan/tilt unit, and the like.
(Use a screw shorter than 7 mm.)
(墌Page 18)
6Rotation prevention hole
Make use of this rotation-preventive hole to prevent any fall when
mounting the camera. Make sure that the camera is securely
mounted.
7Camera mounting bracket fixing screws (×2: M2.6 ×6 mm)
Be sure to use a 6 mm long screw.
MAX.
7mm

10
Names and Operations of Parts
[Rear Panel]
SEE INST-
RUCTION
MANUAL
DC12V
AC24V
1
2
CLASS 2 ONLY (U TYPE)
ISOLATED POWER ONLY
(E TYPE)
POWER VIDEO OUT
INT
LL
SET SELECTOR
8[DC 12V, AC 24V] Power input terminals
To input DC 12V or AC 24V power.
9[VIDEO OUT] Video signal output connector
This BNC connector outputs a composite video signal. Connect this
to the video input connector of a video monitor, switcher, etc.
0[POWER] Power indicator lamp
This lamp lights when power is supplied to the camera.
INTRODUCTION
A
B
8
9
C
0

11
A[SET] button
During normal screen display, pressing and holding this button for
more than 2 seconds will display the MENU screen.
(墌Page 24)
During MENU screen display, this button is pressed to display or
enable the selected menu item. The input digit will change when
entering the camera title.
When selecting EXIT in the TOP MENU screen, pressing this button
will return to the normal screen.
B[SELECTOR] button
Used when performing menu settings.
This button is a multidirectional switch.
䡵Pressing in a vertical direction (6or 7) will select the menu item.
䡵Pressing in a horizontal direction (8or t) will change the set
value of the item. When entering the camera title, the input char-
acter will change.
C[INT/ LL] Selector Switch for Synchronizing System
This switch can set a synchronizing system of the camera.
INT:
This is set for internal synchronization (INT) .
LL (Line Lock): U type: 60Hz power region only
E type: 50Hz power region only
The camera’s vertical synchronization is locked to the AC 24V power
line frequency.
When switching between multiple cameras using a switcher, select-
ing this mode and adjusting the vertical phase can reduce the moni-
tor sync disturbances occurring when the camera image is switched.
(INT: At time of factory shipment)

12
Names and Operations of Parts
[Side Panel]
COLOR VIDEO CAMERA
IRIS
DC
VIDEO
D[VIDEO/DC] Iris Selector Switch
This should be set according to the type of lens if an automatic iris
control lens is used.
VIDEO : In case of lens with EE amp built-in.
(墌Page 20)
DC : In case of lens without EE amp built-in.
(墌Page 14)
(DC : At time of factory shipment)
E[IRIS] Iris Terminal
This is connected to an automatic iris control lens.
(墌Page 15)
INTRODUCTION
DE

13
Basic System
䡵System with up to 8 cameras
REC
PLAY
FFREW
REVERSE
PAUSE/
STILL
REC
CHECK
STOP/EJECT
COUNT/
CLOCK
TIME
MODE
TIMER
REC
AL/PL
RESET
MENU
VIDEOCASSETTE RECORDER
SHIFT/TRACKING
SET/V.LOCK
RESET
/CANCEL
OPERATE
SR-L910
OPE.LOCK
••••••
COLOR VIDEO CAMERA
ALC LEVEL
Av Pk L H
COLOR VIDEO CAMERA
ALC LEVEL
Av Pk L H
COLOR VIDEO CAMERA
ALC LEVEL
Av Pk L H
Switcher
Video signal cable
Power
cable
AC24V or
DC12V
AC24V or
DC12V
AC24V or
DC12V
Camera 1
Camera 2
Camera 8
Monitor
Monitor
DVR, etc.
CONNECTION/INSTALLATION

14
Mounting the lens
Mount the lens according to the procedures described below.
(b)
(c)
F
COLOR VIDEO CAMERA
IRIS
DC
VIDEO
3
42
1
IRIS
DC
VIDEO
CONNECTION/INSTALLATION
1.
Lens mount
3.
4.
Ferrite core
2.
5.
13
2
4
