JVC KY-F560 User manual

Ver1.1
1
New ImagingCameras
KY-F560/KY-F550
SalesManual(Ver1.1)

Ver1.1
2
JVC Imaging Camera Concept
JVC’s every Imaging cameras meet analog to digital transition in
each application.
capturing
Medical
Broadcast
KY-F70B
1/2”3CCD progressive SXGA
KY-F75
1/2”3CCD progressive SXGA
KY-F1030
1/2”1CCD progressive SXGA
KY-F550
1/3”3CCD C-mount NTSC/PAL
KY-F560
1/2”3CCD Bayonet NTSC/PAL
SCSI
IIDC
AV/C
SDI

Ver1.1
3
1/2”3CCD Video Camera KY-F560U/E
Features & Advantages:
?High Quality, and compact size with 12bit A/D and 24bit DSP for rich color
reproduction
?High Sensitivity, F13 at 2000lx for low light application
?Horizontal resolution 850lines, S/N 64(NTSC)/62(PAL)dB
?Cost Effective Studio System available with
optional Studio adapter (Component/SDI)
?Remote System available with optional PTZ Kit
?Expandability with Optional Boards (SDI)
?Squeezed 16:9 mode(Electronically processed)
Features & Advantages:
?High Quality, and compact size with 12bit A/D and 24bit DSP for rich color
reproduction
?High Sensitivity, F13 at 2000lx for low light application
?Horizontal resolution 850lines, S/N 64(NTSC)/62(PAL)dB
?Cost Effective Studio System available with
optional Studio adapter (Component/SDI)
?Remote System available with optional PTZ Kit
?Expandability with Optional Boards (SDI)
?Squeezed 16:9 mode(Electronically processed)

Ver1.1
4
Comparison with KY-F32
Model KY-F560 KY-F32
Dimensions(WxHxD) 70x80x164mm 70x80x164mm
Weight 800g 850g
Image size 1/2" 3CCD 1/2" 3CCD
Color separation F1.4 RGB F1.4 RGB
Lens mount 1/2" bayonet 1/2" bayonet
Sensitivity F13/ 2000lx F9.5/ 2000lx
Minimum illumination F1.4 /0.5lx F1.4/ 6lx
Horizontal resolution 850 lines 750 lines
S/N 64dB(NTSC)/62dB(PAL) 60dB(NTSC)/58dB(PAL)
Camera DSP 12bit ADC/24 bit DSP Analog
ALC Yes Yes
EEI Yes Yes
White balance Yes
Yes
Dynamic shading Manual(vertical only) Manual(vertical only)
Lens control Iris only Iris/Focus/Zoom
Random trigger No No
Genlock input Yes Yes
Composite output Yes Yes
Y/C output Yes
RGB output Yes
Component output Yes
Extension slot Yes No
16:9 mode Yes No
Possible in conjunction with
KA-F5602/F5603 and RM-
P210(selectable)
Rear panel
New
Extension slot for SDI output card
(KA-F5601) or Studio adapter
(KA-F5602/F5603)
D-Sub connector(RGB, Y/C output)
Output signal select switch
MD lens control connector
Delete
KY-F560
KY-F32
Difference between KY-F560 and KY-F32

Ver1.1
5
Notice when swapping from KY-F32 to KY-F560
Video cable
AC adapter
AA-P700
Video cable
Lens remote control unit
RM-713MD
KY-F32
Remote
cable
Connect to MD
control connector
Connect to lens connector KY-F560
Remote
cable
Connect to lens connector
Lens controller
Fujinon/Canon
1.When the only camera part of KY-F560 is swapped from KY-F32.
2.When Fujinon CPT-70F-02A PTZ system is not used.
In this case, another lens controller and extension cable is required instead of RM-713MD
Fujinon:RM-D10/D20/D30 and exclusive extension cable
Canon:TCR-101F/201F/301F and exclusive extension cable
S16x7.3BMD etc
Fujinon/Canon
MD lens
S16x7.3BMD etc
Fujinon/Canon
MD lens
Lens extension cable
Fujinon/Canon
KY-F560
AC adapter
AA-P700
Remote control unit
RM-LP57
KY-F32
Remote control unit
RM-LP57
Lens remote control unit
RM-713MD

Ver1.1
6
-128 to +127SC Fine
0, 90, 180, 270 degreeSC Coarse
-128 to +127H Phase
FAW/PRESET(3200K)/
R Gain, B Gain: 0 to 255, AUTO1/AUTO2
White Balance
-10 to +10Master Black
AGC, LIMIT(+9, +12, +15, +18dB),
LOLUX(30dB)
Gain
Normal(Field)/VMAX(Frame)V.Resolution
1/60.1(50.1) to 1/10.1688kV.SCAN
Yes(EEI)ELC
Normal, 1/100, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000
Step
Shutter
Full / Square / Spot / Normal(Top Cut) /
Circle
AE Area
Peak / Normal / AVGAE Detect
Genlock
–5 to +5AE Level
Negative/PositiveNegative
0.0IRE/7.5IRESetup(NTSC only)
OFF/MANUAL
H/V balance:–5 to +5
Level:–10 to +10
Frequency:Low/Mid/High
Detail
-3 to +3/STD/WARM/
/EXT1/EXT2/EXT3/OFF
R Gain/R Rotation/G Gain/
G Rotation/B Gain/B Rotation
Color Matrix
-5 to +5?OFF,CINEMAGamma
80% to 100%, AutoKnee
100%/108%White Clip
R/MASTER/B -10~+10Flare
Stretch/Compress/OFFBlack
A,B,CFile Manage
R/G/B –128 to +127Shading
Execute/CancelPixel Compensation
4:3/16:9(Squeeze)Aspect Ratio
KY-F560 Menu Setup Contents

Ver1.1
7
KY-F560 Menu Setup by Remote Controller
YesYesYesSC FINE
Yes(0°/90°/180°/270°)Yes(0°/90°/180°/270°)YesSC COARSE
YesYes(LEVEL)YesH.PHASE
Yes(AUTO1/AUTO2)Yes(AUTO1/AUTO2)YesWHITE PAINT
NoNoYesWHITE SHADING
NoYesYesHI-RESO(Note 1)
NoNoNoFOCUS
NoNoNoZOOM
NoYesYesFILE
Yes(NORMAL/ 1/100(120)/ 1/250 / 1/500/ 1/1000/
1/2000/ EE)
Yes(NORMAL/ 1/100(120)/ 1/250 / 1/500/ 1/1000/
1/2000/ V.SCAN/ EEI)
YesSHUTTER
Yes(0/ 6/ 9/ 12/ 18dB/ ALC/ALC+EEI)Yes(-3/ 0/ 6/ 9/ 12/ 18dB/ ALC/ALC+EEI/ LOLUX)YesGAIN
Yes(AUTO1/AUTO2/FAW)Yes(AUTO1/AUTO2/FAW/
MANUAL/PRESET)
YesWHITE BALANCE
NoYes(NORMAL/PEAK/AVG)YesIRIS DETECT
Yes(AUTO(LEVEL)/MANU)Yes(AUTO(LEVEL)/MANU)YesIRIS
YesYes(LEVEL)YesMASTER BLACK
NoNoYesGAMMA
Yes(ON(LEVEL)/OFF)Yes(ON(LEVEL)/OFF)YesCONTOUR
NoYesYesNEGA
Yes(CAM/BARS)Yes(CAM/BARS/NEGA)YesMODE
By RM-LP57By RM-LP55LocalFunction
Note1:Equivalent to V.RESOLUTION NORMAL:HI-RESO OFF, V.MAX:HI-RESO ON

Ver1.1
8
KY-F560 16:9 Squeeze mode
Squeezed 16:9
(KY-F560)
Letter box 16:9
(GY-DV5000)
16:9 aspect ratio is available for KY-
F560 selected by menu.(Squeezed
16:9)
Letter box system implemented into
GY-DV5000 is simply masking the
upper and lower part of 4:3 picture
by black signal.
The DSP implemented into KY-F560
allows to convert 4:3 picture to 16:9
ratio electronically.
But, the vertical resolution of
squeezed 16:9 picture deteriorates
compared to the original 4:3 picture.
Original
Removed Masked
Stretched
View on 16:9 monitor
Recorded image

Ver1.1
9
Color Video Camera
KY-F560U/E
Camera Remote
Control Unit
RM-LP55U
Camera Remote
Control Unit
RM-LP57U
Optical Accessories
RS-232C PC Camera Control
Camera Controls
VC-P893U
AC Power Adapter
AA-P700U/E
Fujinon Professional
Zoom Lens
S16x7.3BMD-DSD
KY-F560 System Configuration
CPT-70F-02A
EOP-102J-60B
Operation unit
Control Les, Pan Tilt &Camera
Shut,Gain,Bar,AWB,Power
PS-470A-01A
AC Adapter
Tally IN
UTI-422D-01A
Tally Unit
UHD-344A-030
RS-485 cable
ESC-103K-04A
System controller
PTZ Remote System by FUJINON
PTZ Remote System by FUJINON

Ver1.1
10
Fujinon PTZ Controller
EOP-102J-60B

Ver1.1
11
Fujinon PTZ Head with tally lamp
CPT-70F-02A/UTU-427D-01A

Ver1.1
12
Fujinon PTZ System Controller
ESC-103K-04A

Ver1.1
13
KY-F560 PTZ System Configuration

Ver1.1
14
KY-F560 PTZ System Configuration with tally unit

Ver1.1
15
KY-F560 PTZ System Configuration(4 camera control)

Ver1.1
16
Comparison of PTZ system between KY-F560 & AW-E600
Configuration JVC Pana
Camera KY-F560 AW-E600
Lens YH19x6.7KTS YH19x6.7KTS
PTZ housing CPT-70F-02A/UTB-219A-02A
UTU-427D-01 AW-PH300A
Controller E0P-102J-60B AW-RP501
JVC Pana
Power supply
Power is supplied via exclusive multi core cable from
AC adapter. The connector of this cable is reliable with
lock mechanism and easy to connect and disconnect.
Power is supplied via simple twist pair cable from AC
adapter. But, this cable looks cheap and is unreliable
without any connector and is recommended to be fixed
by soldering.
Zoom, Focus
and PT levers
The style of levers for Zoom, Focus and Pan/Tilt are
different each other and is easy to operate
ergonomically.
The style of levers for Zoom, Focus and Pan/Tilt is
completely identical and easy to misoperate.
Menu setting
Menu cannot be adjusted from remote controller, but it
is possible to set locally without any restriction. Menu cannot be adjusted from remote controller. Moreover, if remote interface cable is connected, it
also does not work. In order to set menu locally, it is
necessary to provide power from another AC adapter.
It is very incovenient.
Tally
indication
Optional tally is located at the top of PTZ and is large
and visible from every direction regardless of the
position of camera. Tally signal line is included in the
multi core cable and no necessary to connect another
line.
Provided tallies are located at the front and back of
PTZ. But, both are too small and may not be visible
when the camera covers it. And, it is required to
connect another lines.
Shutter mode Shutter modes can be selected from controller except
1/100(120) mode. Shutter select items are 1/100(120) and EEL only from controller.
Genlock
Genlock can be adjusted locally only.
Genlock can be adjusted from controller.
Speed
override Manual operation is only possible to adjust the speed
of each levers. Speed select switch is useful to control each levers at lower or higher speed smoothly.
Iris
adjustment
Manual iris can be adjusted by button step by step. Manual Iris can be adjusted by volume variably and
smoothly.
Cable clamp
No cable clamp adjustment
Cable clamp adjustment is possible.
Scene file No scene file on conreoller. 4 scene file memories are available on controller.
ABC
No ABC function.
ABC can be controlled from controller.
ATW memory No ATW memory 2 ATW memories are available on controller.
Tally
indication on
controller
No tally indication on controller. Tally indication can be confirmed on controller.

Ver1.1
17
KY-F560 Options
Color Video Camera
KY-F560U/E
Studio adapter
Analogue Component + SDI output
KA-F5603U
Studio adapter
Analogue Component
KA-F5602U
Remote Control Unit
RM-P210U/E
SDI output Card
KA-F5601U

Ver1.1
18
Incom Connector
for KA-310
Incom Level Volume
Call Button
Mic Select
DC12V Input
26P Camera Connector
Mount for VF-P400
Prompter Output
Studio Adapter KA-F5602(Analog)/F5603(Analog +
SDI)
SDI Output
(KA-F5603 only)

Ver1.1
19
S16x7.3BMD etc
Fujinon MD lens
Video cable
Lens controller
RM-D20etc
Fujinon
Up to 5m
Lens extension cable ECM-***
Fujinon(max 100m)
When the only camera part of KY-F560 is swapped from KY-F32 and Fujinon CPT-70F-02A PTZ system is
not used, another lens controller and extension cable is required instead of RM-713MD
Fujinon:RM-D10/D20/D30 and exclusive extension cable
Canon:TCR-101F/201F/301F and exclusive extension cable
*When camera control is required
*When camera position is fixed
Note:
DV Recorder
BR-DV3000
BR-DV6000
KY-F560
17“ monitor
TM-H1750CG
AC adapter
AA-P700 Remote control unit
RM-LP57
Model Description
KY-F560 3CCD color video camera 1
BR-DV6000 DV video cassette recorder 1
TM-H1750CG 17" monitor 1
AA-P700 AC power adapter 1
RM-LP57 Camera control unit 1
S16×7.3BMD-DSD 16x MD lens 1
RM-D20 Lens remote controller 1
ECM-020M Lens extension cable(20m) 1
High picture quality generated by KY-F560 can be captured up to 4.5 hours onto DV recorder.
Camera parameter can be adjusted by RM-LP57 camera control unit.
MD lens can be controlled by exclusive lens control unit separately.
KY-F560 System Configuration 1

Ver1.1
20
S16x7.3BMD etc
Fujinon MD lens
Video cable
Lens controller
RM-D20etc
Fujinon
Lens extension cable ECM-***
Fujinon(max 100m)
When the only camera part of KY-F560 is swapped from KY-F32 and Fujinon CPT-70F-02A PTZ system is
not used, another lens controller and extension cable is required instead of RM-713MD
Fujinon:RM-D10/D20/D30 and exclusive extension cable
Canon:TCR-101F/201F/301F and exclusive extension cable
*When camera control is not required
*When camera position is fixed
Note:
DV Recorder
BR-DV3000
BR-DV6000
KY-F560
AC adapter
AA-P700
Model Description
KY-F560 3CCD color video camera 1
BR-DV6000 DV video cassette recorder 1
TM-H1750CG 17" monitor 1
AA-P700 AC power adapter 2
S16×7.3BMD-DSD 16x MD lens 1
RM-D20 Lens remote controller 1
ECM-020M Lens extension cable(20m) 1
High picture quality generated by KY-F560 can be captured up to 4.5 hours onto DV recorder.
MD lens can be controlled by exclusive lens control unit separately.
KY-F560 System Configuration 2
