JVC MX-C55A User manual

SERVICE MANUAL
COPYRIGHT © 2006 Victor Company of Japan, Limited No.MB557
2006/8
COMPACT COMPONENT SYSTEM
MB55720068
MX-C55A
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
SP-MXC55 SP-MXC55CA-MXC55

1-2 (No.MB557)
SPECIFICATION
Amplifier section (CA-MXC55)
*1: at 1 kHz, measured at MAIN SPEAKERS
Amplifier section (CA-MXC55)
Design and specifications are subject to change without notice.
Output Power SUBWOOFERS 98 W per channel, min. RMS, driven into 3 Ωat 63 Hz with no more than 10% total har-
monic distortion (IEC 268-3)
MAIN SPEAKERS 80 W per channel, min. RMS, driven into 6 Ωat 1 kHz with no more than 10% total har-
monic distortion (IEC 268-3)
Audio input sensitivity
/Impedance*1
AUX 400 mV/47 kΩ
USB USB Version 1.1
Speakers/Impedance Subwoofers 3 Ω- 6 Ω
Main speakers 6 Ω- 16 Ω
Tuner FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range 522 kHz - 1 710 kHz
CD player CD Capacity 3 CDs
Dynamic range 85 dB
Signal-to-noise ratio 85 dB
General Power requirement AC 110 - 240 V , 50/60 Hz
Power consumption 80 W /136 VA (at operation)
7.3 W (on standby)
1 W (in ECO mode)
Dimensions (approx.) 270 mm ×317 mm ×402 mm (W/H/D) (10 11/16 in. ×12 1/2 in. ×15 7/8 in.)
Mass (approx.) 5.9 kg (13 lbs)
Type 3-way bass-reflex type
Speaker units Subwoofer 16 cm (6 5/16 in.) cone ×1
Main Woofer 10 cm (3 15/16 in.) cone ×1
Tweeter 5 cm (2 in.) cone ×1
Power handling capacity Subwoofer 170 W
Main speaker 80 W
Impedance Subwoofer 3 Ω
Main speaker 6 Ω
Frequency range Subwoofer 30 Hz - 1 000 Hz
Main speaker 100 Hz - 20 000 Hz
Sound pressure level Subwoofer 74 dB/W·m
Main speaker 81 dB/W·m
Dimensions (approx.) 220 mm ×435 mm ×316 mm (W/H/D) (8 11/16 in. ×17 13/16 in. ×12 1/2 in.)
Mass (approx.) 5.7 kg (12.6 lbs) each

(No.MB557)1-3
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

1-4 (No.MB557)
1.5 Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
REPRODUCTION AND POSITION OF LABELS and PRINT
!Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
WARNING LABEL and PRINT

(No.MB557)1-5
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

1-6 (No.MB557)
SECTION 3
DISASSEMBLY
3.1 Main body section
3.1.1 Removing the top cabinet
(See Figs.1 and 2)
(1) From the both sides of the main body, remove the six
screws Aattaching the top cabinet. (See Fig.1)
(2) From the back side of the main body, remove the three
screws Battaching the top cabinet. (See Fig.2)
(3) Take out the top cabinet from the main body while lifting the
rear section of the top cabinet in the direction of the arrow.
(See Fig.1)
3.1.2 Removing the CD mechanism assembly
(See Figs.2 to 4)
• Remove the top cabinet.
(1) From the back side of the main body, remove the two
screws Cattaching the CD mechanism assembly to the
rear cabinet. (See Fig.2)
(2) From the bottom side of the CD mechanism assembly, turn
the gear cam in the direction of the arrow and draw the tray
disc out of the CD mechanism assembly in the direction of
the arrow 1. (See Fig.3, 4)
(3) Remove the CD door from the tray disc in the direction of
the arrow 2. (See Fig.4)
(4) From the left side of the main body, disconnect the wire
from the connector CN105 on the main AMP board. (See
Fig.4)
(5) Disconnect the card wire from the connector CW105 on the
CD board. (See Fig.4)
(6) From the both sides of the main body, remove the two
screws Dand then take out the CD mechanism assembly
from the main body. (See Fig.4)
Fig.1
Fig.2
Fig.3
Fig.4
Top cabinet
A
A
A
Rear cabinet
CC
B
BB
CD deck
Gear cam
OPEN
Main AMP board D
CD mechanism
2
CD board
1
CN105
CD door
tray disc

(No.MB557)1-7
3.1.3 Removing the main AMP board
(See Figs.5 to 7)
• Remove the top cabinet and CD mechanism assembly.
(1) From the right side of the main body, remove the one screw
Eattaching the main AMP board to the main body. (See
Fig.5)
(2) From the top side of the main body, disconnect the wire
from the connector CN108 of the main AMP board. (See
Fig.6)
(3) Disconnect the card wire from the connector CN101 on the
main AMP board. (See Fig.6)
(4) Disconnect the connector wire from the connector CN102
on the main AMP board. (See Fig.6)
(5) Disconnect the wires from the connectors (SMCN01,
SMCN02) on the SMPS board. (See Fig.6)
(6) From the back side of the main body, remove the three
screws Fattaching the main AMP board to the rear cabinet.
(See Fig.7)
(7) Take out the main AMP board from the bottom cabinet.
3.1.4 Removing the SMPS board and rear cabinet
(See Figs.6 to 8)
• Remove the top cabinet, CD mechanism assembly and the
main AMP board.
(1) From the top side of the main body, remove the screw G
attaching the earth wire on the bottom cabinet. (See Fig.6)
(2) From the back side of the main body, remove the three
screws Hattaching the rear cabinet. (See Fig.7)
(3) Disengage the two hooks aand take out the rear cabinet.
(See Fig.7)
(4) From the inside of the rear cabinet, remove the four screws
Jattaching the SMPS board. (See Fig.8)
(5) Remove the one screw Kattaching the earth wire from
back side of the main body. (See Fig.7)
(6) Release the nine claws band take out the SMPS board
from the rear cabinet assembly. (See Fig.8)
3.1.5 Removing the fan assembly
(See Figs.7 and 8)
• Remove the top cabinet, CD mechanism assembly and the
main AMP board.
(1) From the back side of the main body, remove the two
screws Lattaching the fan to the rear cabinet. (See Fig.7)
(2) Take out the fan from the rear cabinet. (See Fig.8)
Fig.5
Fig.6
Fig.7
Fig.8
Main AMP board
Bottom cabinet E
CN108
SMCN01
SMCN02
SMPS board
Bottom cabinet
Main AMP board
CN101
G
CN102
Rear cabinet
F
F
H
L
H
K
H
aa
Rear cabinet
SMPS board
FAN
J
b
b
b
J
b
bJ

1-8 (No.MB557)
3.1.6 Removing the front cabinet assembly
(See Figs.9 and 10)
• Remove the top cabinet and CD mechanism assembly.
(1) From the top side of the main body, remove the one screw
Mattaching the earth wire on the bottom cabinet. (See
Fig.9)
(2) From the both sides of the main body, remove the two
screws Nattaching the front cabinet assembly. (See
Fig.10)
(3) From the both and bottom sides of the main body, release
the joints (c, d) and then take out the front cabinet assem-
bly from the main body in the direction of the arrow. (See
Figs.10)
Fig.9
Fig.10
Front cabinet assembly
Bottom cabinet
M
Bottom cabinet
Front cabinet assembly
N
c
d

(No.MB557)1-9
3.1.7 Removing the VFD board
(See Fig.11 and 12)
• Remove the top cabinet, the CD mechanism assembly and the
front cabinet assembly.
(1) From the front side of the front cabinet assembly, pull out
the two knobs. (See Fig.11)
(2) From the inside of the front cabinet assembly, remove the
seven screws Pattaching the VFD board. (See Fig.12)
(3) Take out the VFD board from the front cabinet assembly
and then disconnect the wires from the connectors
(UW101, UW201, FW102, FW104) on the VFD board.
(See Fig.12)
3.1.8 Removing the front board
(See Fig.12)
• Remove the top cabinet, CD mechanism assembly, front cab-
inet assembly and VFD board.
(1) From the inside of the front cabinet assembly, remove the
four screws Qattaching the front board.
(2) Take out the front board from the front cabinet assembly.
Fig.11
Fig.12
Front cabinet assembly
Preset knob
Volume knob
QQ
P
P
P
Front board
VFD board
FW104
FW102
UW201UW101
P

1-10 (No.MB557)
3.1.9 Removing the USB board
(See Fig.13)
• Remove the top cabinet, CD mechanism assembly, front cab-
inet assembly, Knobs and VFD board.
(1) From the inside of the front cabinet assembly, remove the
three screws Rattaching the USB board.
(2) Take out the USB board from the front cabinet assembly.
3.1.10 Removing the LED1 board, LED2 board and LED3
board
(See Fig.13)
• Remove the top cabinet, CD mechanism assembly, front cab-
inet assembly, knobs and VFD board.
(1) From the inside of the front cabinet assembly, release the
claws eand then take out the LED1 board from the front
cabinet assembly.
(2) Remove the screw Sattaching the LED2 board.
(3) Release the claw fand then take out the LED2 board from
the front cabinet assembly.
(4) Take out the LED3 board from the front cabinet assembly.
Fig.13
S
LED1 board
USB board
LED2 board
LED3 board
e
f
RRR

(No.MB557)1-11
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.

(No.MB557)
Audio/Video Systems Category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
Victor Company of Japan, Limited
VPT
Printed in Japan

3-1
PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Electrical parts list (Block No.01~04)
Packing materials and accessories parts list (Block No.M3)
MX-C55A
3-2
3-5
3-12
MB557

3-2
Exploded view of general assembly and parts list
VFD
Front board
VFD board
LED1 b
o
LED3 board
Block No. MM
M
1
11
43
12
1
2
10
13
45
45 25
23
42
45
20
19
46
44 41
24
46
948
8
7
6
5
4
3
21
22
45
27
28
18

3-3
SMPS board
USB board
1
board
Main AMP board
LED2 board
CD board
47
45
45
34
32
38
36
45
45
45
30
45
10
45
45
45
45
45
31
4
5
40
37
39
35
45

3-4
General Assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 AH64-03850B VFD WINDOW PMMA
2 AH64-03851B CD WINDOW PMMA
3 AH64-03848B VOLUME KNOB PMMA
4 AH67-00408A VOLUME LENS
5 AH81-01982B DECO VOLUME ABS
6 AH64-03849B PRESET KNOB ABS
7 AH81-01996B PRESET DECO ABS
8 AH67-00413A PRESET LENS PMMA
9 AH67-00409B CAP SIDE L ABS
10 AH67-00410B CAP SIDE R ABS
11 AH67-00412A USB LENS PMMA
12 AH69-20031A FOOT (x2)
13 AH64-03840B FRONT CABINET ABS
18 AH64-03846B DEMO KNOB ABS
19 AH64-03844B DISK KNOB ABS
20 AH64-03847B SOUND KNOB ABS
21 AH64-03842B CD KNOB ABS
22 AH64-03845B FUNCTION KNOB ABS
23 AH63-01150A MIRROR SHEET PC
24 AH64-03843B POWER KNOB ABS
25 AH67-00411A POWER LENS PMMA
27 AH07-00180B VFD DISPLAY BN017GNK
28 AH61-01831A VFD HOLDER ABS BLACK
30 AH64-02840A BOTTOM CABINET
 31 AH39-00257K POWER CORD
32 AH61-02134A PCB BKT ABS
34 AH61-02131A IC HOLDER
35 AH62-00152B HEATSINK
36 AH44-00124B SMPS PCB ASSY
37 AH61-02130A PCB HOLDER
38 AH31-00044A FAN ASSY
39 AH64-03841E REAR CABINET SECC
40 AH59-01647A CD MECHA ASSY AH92-02451A
41 AH69-20342A MOTOR CUSHION ABS
42 AH64-03853B CD DOOR ABS
43 AH64-03852B CD DOOR WINDOW ABS
44 AH64-30390L TOP CABINET
45 6003-000276 SCREW M3X10 YEL(x49)
46 6003-001331 SCREW (x2)
47 6003-001561 SCREW BH 2S M3X6 YEL(x5)
48 6002-000126 SCREW M3X10 BLACK(x2)

3-5
Electrical parts list
Front board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
UIC01 0903-001273 IC LC87F67C8A
UIC02 1205-002635 IC LC709004A
UIC03 1205-002894 IC PCM2704DBR
FD201 1N4002 DIODE 0402-000127
FD204 1N4002 DIODE 0402-000127
FD205 1N4002 DIODE 0402-000127
FD301 1N4002 DIODE 0402-000127
LD201 0601-001739 LED RED
LD202 0601-001739 LED RED
LD301 0601-001739 LED RED
LD302 0601-001739 LED RED
LD304 0601-001739 LED RED
LD305 0601-001739 LED RED
LD306 0601-001739 LED RED
LD307 0601-001739 LED RED
LD308 0601-001739 LED RED
LD309 0601-001739 LED RED
LD310 0601-001490 LED INVERTER BLUE
UD03 1N4148 DIODE 0401-000005
UD101 1N4148 DIODE 0401-000005
UD102 1N4148 DIODE 0401-000005
UD103 1N4002 DIODE 0402-000127
UD104 1N4002 DIODE 0402-000127
FC01L 2202-000806 C CAPACITOR 220pF 50V
FC01R 2202-000806 C CAPACITOR 220pF 50V
FC02L 2202-000216 C CAPACITOR 0.027NF 50V
FC02R 2202-000216 C CAPACITOR 0.027NF 50V
FC03L 2202-000806 C CAPACITOR 220pF 50V
FC03R 2202-000806 C CAPACITOR 220pF 50V
FC201 2201-000982 C CAPACITOR 10nF
FC204 2201-000565 C CAPACITOR 47nF 50V
FC301 2202-000121 C CAPACITOR 0.1nF 50V
FC302 2202-000121 C CAPACITOR 0.1nF 50V
FC303 2202-000849 C CAPACITOR 0.018nF 50V
FC304 2202-000849 C CAPACITOR 0.018nF 50V
FC305 2202-000173 C CAPACITOR 1nF 50V
FC800 2202-000807 C CAPACITOR 22nF 25V
FC800L 2202-000263 C CAPACITOR 470pF 50V
FC800R 2202-000263 C CAPACITOR 470pF 50V
FE200 2401-000240 E CAPACITOR 100uF 10V
FE301 2401-000598 E CAPACITOR 1uF 50V
FE302 2401-000598 E CAPACITOR 1uF 50V
FE303 2401-000598 E CAPACITOR 1uF 50V
FE304 2401-000414 E CAPACITOR 10uF 16V
FE305 2401-000598 E CAPACITOR 1uF 50V
FE306 2401-000598 E CAPACITOR 1uF 50V
FE30L 2401-000303 E CAPACITOR 100uF 25V
FE30R 2401-000303 E CAPACITOR 100uF 25V
UC101 2201-000982 C CAPACITOR 10nF
UC102 2201-000565 C CAPACITOR 47nF 50V
UC103 2201-000389 C CAPACITOR 0.022nF
UC104 2201-000389 C CAPACITOR 0.022nF
UC105 2201-000565 C CAPACITOR 47nF 50V
UC106 2201-000565 C CAPACITOR 47nF 50V
UC107 2201-000021 C CAPACITOR 100nF 50V
UC108 2201-000281 C CAPACITOR 1NF50V
UE101 2401-000651 E CAPACITOR 2.2uF 50V
UE102 2401-000759 E CAPACITOR 220nF 50V
UE103 2401-000118 E CAPACITOR 1000uF 10V
UE104 2401-000240 E CAPACITOR 100uF 10V
UE105 2401-000480 E CAPACITOR 10uF 50V
UE106 2401-000480 E CAPACITOR 10uF 50V
UE107 2401-001020 E CAPACITOR 3.3UF 50V
FR01L 2001-000411 C RESISTOR 18K Ω 1/8W
FR01R 2001-000411 C RESISTOR 18K Ω 1/8W
FR100 2001-000995 C RESISTOR 820
Ω 1/8W
FR101 2001-000429 C RESISTOR 1K
Ω 1/8W
FR102 2001-000221 C RESISTOR 1.2K Ω 1/8W
FR103 2001-000241 C RESISTOR 1.5K
Ω 1/8W
FR104 2001-000258 C RESISTOR 1.8K Ω 1/8W
FR105 2001-000449 C RESISTOR 2.2K Ω 1/8W
FR106 2001-000591 C RESISTOR 3.3K Ω 1/8W
FR107 2001-000734 C RESISTOR 4.7K Ω 1/8W
FR108 2001-000890 C RESISTOR 6.8K
Ω 1/8W
FR111 2001-000734 C RESISTOR 4.7K
Ω 1/8W
FR201 2001-000995 C RESISTOR 820 Ω 1/8W
FR202 2001-000429 C RESISTOR 1K Ω 1/8W
FR203 2001-000221 C RESISTOR 1.2K Ω 1/8W
FR204 2001-000241 C RESISTOR 1.5K Ω 1/8W
FR205 2001-000258 C RESISTOR 1.8K Ω 1/8W
FR218 2001-000034 C RESISTOR 220 Ω 1/4W
FR222 2001-000855 C RESISTOR 560 Ω 1/4W
FR301 2001-000034 C RESISTOR 220 Ω 1/4W
FR302 2001-000034 C RESISTOR 220 Ω 1/4W
FR304 2001-000034 C RESISTOR 220 Ω 1/4W
FR305 2001-000034 C RESISTOR 220 Ω 1/4W
FR306 2001-000034 C RESISTOR 220 Ω 1/4W
FR307 2001-000034 C RESISTOR 220 Ω 1/4W
FR308 2001-000034 C RESISTOR 220
Ω 1/4W
FR309 2001-000034 C RESISTOR 220
Ω 1/4W
FR30L 2001-000411 C RESISTOR 18K Ω 1/8W
FR30R 2001-000411 C RESISTOR 18K Ω 1/8W
FR310 2001-000034 C RESISTOR 220 Ω 1/4W
FR311 2001-000995 C RESISTOR 820 Ω 1/8W
FR312 2001-000429 C RESISTOR 1K Ω 1/8W
FR313 2001-000221 C RESISTOR 1.2K Ω 1/8W
FR317 2001-000734 C RESISTOR 4.7K Ω 1/8W
FR318 2001-000734 C RESISTOR 4.7K Ω 1/8W
FR31L 2001-000734 C RESISTOR 4.7K Ω 1/8W
FR31R 2001-000734 C RESISTOR 4.7K Ω 1/8W
FR320 2001-000241 C RESISTOR 1.5K Ω 1/8W
FR321 2001-000527 C RESISTOR 22 Ω 1/8W
FR322 2001-000527 C RESISTOR 22 Ω 1/8W
FR323 2001-000435 C RESISTOR 1M Ω 1/8W
FR324 2001-000241 C RESISTOR 1.5K Ω 1/8W
FR325 2001-000295 C RESISTOR 10M Ω 1/8W
FR32L 2001-000415 C RESISTOR 18 Ω 1/4W
FR32R 2001-000415 C RESISTOR 18 Ω 1/4W
FR33L 2001-000290 C RESISTOR 10K Ω 1/8W
FR33R 2001-000290 C RESISTOR 10K Ω 1/8W
FR800 2001-000290 C RESISTOR 10K Ω 1/8W
FR800L 2001-000411 C RESISTOR 18K Ω 1/8W
FR800R 2001-000411 C RESISTOR 18K Ω 1/8W
UR101 2001-000290 C RESISTOR 10K Ω 1/8W
UR102 2001-000281 C RESISTOR 100 Ω 1/8W
UR103 2001-000734 C RESISTOR 4.7K
Ω 1/8W
UR104 2001-000734 C RESISTOR 4.7K
Ω 1/8W
UR105 2001-000734 C RESISTOR 4.7K
Ω 1/8W
UR106 2001-000734 C RESISTOR 4.7K Ω 1/8W
UR107 2001-000734 C RESISTOR 4.7K
Ω 1/8W
UR108 2001-000734 C RESISTOR 4.7K
Ω 1/8W
UR109 2001-000734 C RESISTOR 4.7K Ω 1/8W
UR110 2001-000734 C RESISTOR 4.7K
Ω 1/8W
UR111 2001-000734 C RESISTOR 4.7K Ω 1/8W
UR112 2001-000734 C RESISTOR 4.7K
Ω 1/8W
UR113 2001-000734 C RESISTOR 4.7K
Ω 1/8W
UR114 2001-000734 C RESISTOR 4.7K Ω 1/8W
UR115 2001-000786 C RESISTOR 47K
Ω 1/8W
UR116 2001-000786 C RESISTOR 47K
Ω 1/8W
UR117 2001-000786 C RESISTOR 47K Ω 1/8W
UR118 2001-000786 C RESISTOR 47K
Ω 1/8W
UR119 2001-000786 C RESISTOR 47K
Ω 1/8W
UR120 2001-000786 C RESISTOR 47K Ω 1/8W
UR121 2001-000786 C RESISTOR 47K
Ω 1/8W
UR122 2001-000786 C RESISTOR 47K
Ω 1/8W
UR123 2001-000786 C RESISTOR 47K
Ω 1/8W
UR124 2001-000786 C RESISTOR 47K
Ω 1/8W
UR125 2001-000786 C RESISTOR 47K Ω 1/8W
UR126 2001-000786 C RESISTOR 47K
Ω 1/8W
UR127 2001-000786 C RESISTOR 47K
Ω 1/8W
UR128 2001-000786 C RESISTOR 47K Ω 1/8W
UR129 2001-000786 C RESISTOR 47K
Ω 1/8W
UR130 2001-000786 C RESISTOR 47K
Ω 1/8W
UR131 2001-000786 C RESISTOR 47K Ω 1/8W
UR132 2001-000786 C RESISTOR 47K
Ω 1/8W
 Symbol No. Part No. Part Name Description Local

3-6
AMP board
Block No. [0][2]
UR133 2001-000786 C RESISTOR 47K Ω 1/8W
UR134 2001-000786 C RESISTOR 47K Ω 1/8W
UR135 2001-000786 C RESISTOR 47K Ω 1/8W
UR136 2001-000786 C RESISTOR 47K Ω 1/8W
UR137 2001-000786 C RESISTOR 47K Ω 1/8W
UR138 2001-000786 C RESISTOR 47K
Ω 1/8W
UR139 2001-000786 C RESISTOR 47K
Ω 1/8W
UR140 2001-000786 C RESISTOR 47K Ω 1/8W
UR141 2001-000786 C RESISTOR 47K Ω 1/8W
UR142 2001-000786 C RESISTOR 47K Ω 1/8W
UR143 2001-000786 C RESISTOR 47K Ω 1/8W
UR144 2001-000786 C RESISTOR 47K Ω 1/8W
UR145 2001-000786 C RESISTOR 47K Ω 1/8W
UR146 2001-000786 C RESISTOR 47K Ω 1/8W
UR147 2001-000786 C RESISTOR 47K Ω 1/8W
UR148 2001-000786 C RESISTOR 47K Ω 1/8W
UR149 2001-000786 C RESISTOR 47K Ω 1/8W
UR150 2001-000429 C RESISTOR 1K Ω 1/8W
UR151 2001-000290 C RESISTOR 10K Ω 1/8W
UR152 2001-000290 C RESISTOR 10K Ω 1/8W
UR153 2001-000290 C RESISTOR 10K
Ω 1/8W
UR154 2001-000290 C RESISTOR 10K
Ω 1/8W
UR155 2001-000290 C RESISTOR 10K Ω 1/8W
UR156 2001-000290 C RESISTOR 10K Ω 1/8W
UR157 2001-000290 C RESISTOR 10K Ω 1/8W
UR158 2001-000290 C RESISTOR 10K Ω 1/8W
UR159 2001-000290 C RESISTOR 10K Ω 1/8W
UR160 2001-000281 C RESISTOR 100 Ω 1/8W
UR161 2001-000429 C RESISTOR 1K Ω 1/8W
UR162 2001-000429 C RESISTOR 1K Ω 1/8W
UR163 2001-000429 C RESISTOR 1K Ω 1/8W
UR164 2001-000429 C RESISTOR 1K Ω 1/8W
UR165 2001-000281 C RESISTOR 100 Ω 1/8W
UR166 2001-000281 C RESISTOR 100 Ω 1/8W
UR167 2001-000281 C RESISTOR 100 Ω 1/8W
UR168 2001-000281 C RESISTOR 100 Ω 1/8W
UR169 2001-000281 C RESISTOR 100 Ω 1/8W
UR170 2001-000281 C RESISTOR 100 Ω 1/8W
UR171 2001-000281 C RESISTOR 100 Ω 1/8W
UR172 2001-000281 C RESISTOR 100 Ω 1/8W
UR173 2001-000281 C RESISTOR 100 Ω 1/8W
UR174 2001-000281 C RESISTOR 100 Ω 1/8W
UR175 2001-000281 C RESISTOR 100 Ω 1/8W
UR176 2001-000281 C RESISTOR 100 Ω 1/8W
UR177 2001-000295 C RESISTOR 10M Ω 1/8W
UR178 2001-000850 C RESISTOR 560K Ω 1/8W
UR179 2001-000435 C RESISTOR 1M Ω 1/8W
UR180 2001-000449 C RESISTOR 2.2K Ω 1/8W
UR181 2001-000734 C RESISTOR 4.7K Ω 1/8W
UR182 2001-000508 C RESISTOR 220K
Ω 1/8W
UR183 2001-000793 C RESISTOR 47 Ω 1/8W
UR184 2001-000734 C RESISTOR 4.7K
Ω 1/8W
UR185 2001-000281 C RESISTOR 100
Ω 1/8W
UR186 2001-000780 C RESISTOR 470K Ω 1/8W
UR187 2001-000281 C RESISTOR 100
Ω 1/8W
UR188 2001-000890 C RESISTOR 6.8K
Ω 1/8W
UR189 2001-000281 C RESISTOR 100 Ω 1/8W
UR190 2001-000281 C RESISTOR 100
Ω 1/8W
UR191 2001-000281 C RESISTOR 100 Ω 1/8W
UR192 2001-000281 C RESISTOR 100
Ω 1/8W
UR193 2001-000786 C RESISTOR 47K
Ω 1/8W
UR800 2001-000281 C RESISTOR 100 Ω 1/8W
UR801 2001-000281 C RESISTOR 100
Ω 1/8W
UR803 2001-000429 C RESISTOR 1K
Ω 1/8W
VR101 3406-001047 ROTARY SWITCH 5V DC 0.5mA
FL301 2702-000112 COIL 10uH
AJACK1 3722-001588 PHONE JACK 7P 3.6PI AG BLK
BEAD1 3301-000297 FERRITE BEADS
BEAD2 3301-000297 FERRITE BEADS
BZ101 3002-001134 BUZZER 85DB 12V
FL302 3301-000297 FERRITE BEADS
FQ301 KTC8050 TRANSISTOR 0501-002375
FQ302 KTC8050 TRANSISTOR 0501-002375
FQ303 KTC8050 TRANSISTOR 0501-002375
FW101 3708-000454 CONNECTOR 22P 1.25mm
FW102 3711-001136 CONNECTOR 8P
 Symbol No. Part No. Part Name Description Local
FW103 3708-001696 CONNECTOR 24P
FW104 3711-000967 CONNECTOR 4P 1R 2mm
FW201 AH39-00719A LEAD CONNECTOR 8P
FW301 AH39-00862A LEAD CONNECTOR 15P
FW305 3722-002292 USB JACK 4P/1P
FW401 AH39-00738A LEAD CONNECTOR 4P
GND1 AH39-50001K HARNESS WIRE 140mm BLK
HJACK1 3722-001588 PHONE JACK 7P 3.6PI AG BLK
PS102 3406-001050 ROTARY SWITCH 5V DC 0.5mA
12mm
REYE1 0609-001189 REMOCON MODULE HORIZONTAL
16.4mm
SW201 3404-000165 TACT SWITCH 12V 50mA
SW204 3404-000165 TACT SWITCH 12V 50mA
SW205 3404-000165 TACT SWITCH 12V 50mA
SW206 3404-000165 TACT SWITCH 12V 50mA
SW207 3404-000165 TACT SWITCH 12V 50mA
SW208 3404-000165 TACT SWITCH 12V 50mA
SW211 3404-000165 TACT SWITCH 12V 50mA
SW212 3404-000165 TACT SWITCH 12V 50mA
SW213 3404-000165 TACT SWITCH 12V 50mA
SW214 3404-000165 TACT SWITCH 12V 50mA
SW215 3404-000165 TACT SWITCH 12V 50mA
SW216 3404-000165 TACT SWITCH 12V 50mA
SW217 3404-000165 TACT SWITCH 12V 50mA
SW218 3404-000165 TACT SWITCH 12V 50mA
SW219 3404-000165 TACT SWITCH 12V 50mA
SW220 3404-000165 TACT SWITCH 12V 50mA
SW310 3404-000165 TACT SWITCH 12V 50mA
SW311 3404-000165 TACT SWITCH 12V 50mA
SW312 3404-000165 TACT SWITCH 12V 50mA
SW313 3404-000165 TACT SWITCH 12V 50mA
UQ101 KTC945B TRANSISTOR 0501-002409
UW001 3708-000448 CONNECTOR 6P 1.25mm
UW101 3711-000826 CONNECTOR 2P
UW102 AH39-00109A LEAD CONNECTOR 2P
UW201 3711-000906 CONNECTOR 3P 1R 2mm
UW202 AH39-00712A LEAD CONNECTOR 3P
UX101 2801-001394 CRYSTAL 32.768KHz
UX102 2802-001198 C RESONATOR 10MHz
UX103 2801-004396 CRYSTAL UNIT 12.0MHz 30ppm
VFD1 AH07-00180B VFD DISPLAY BN017GNK
 Symbol No. Part No. Part Name Description Local
AIC01 1204-002519 IC STA308A
AIC02 1203-003526 IC KIA7029AP
EIC02 1002-001448 IC AK5358ET
FIC01 1204-002518 IC R2S15904SP
FIC02 1201-002414 IC STA508
HIC01 1201-000163 IC BA4560
WIC01 1201-002414 IC STA508
WIC02 1201-002414 IC STA508
XIC01 AH14-10004R IC M74HCU04
CD101 1SS355 DIODE 0401-001090
CD102 1SS355 DIODE 0401-001090
ED102 1SS355 DIODE 0401-001090
SD101 1SS355 DIODE 0401-001090
SD102 1SS355 DIODE 0401-001090
SZ102 RLZ5.6A Z DIODE 0403-001008
SZ103 RLZ5.6A Z DIODE 0403-001008
SZ104 RLZ7.5B Z DIODE 0403-000622
SZ105 1N4739A Z DIODE 0403-000145
SZ106 UZP33B Z DIODE 0403-000390
AE101 2401-001508 E CAPACITOR 47uF 16V
AE102 2401-000048 E CAPACITOR 47uF 25V
CE101 2401-000243 E CAPACITOR 100uF 10V
CE102 2401-000243 E CAPACITOR 100uF 10V
EC01L 2203-000575 CHIP CAPACITOR 220nF 25V
EC01R 2203-000575 CHIP CAPACITOR 220nF 25V
 Symbol No. Part No. Part Name Description Local

3-7
EC02L 2203-000575 CHIP CAPACITOR 220nF 25V
EC02R 2203-000575 CHIP CAPACITOR 220nF 25V
EC03L 2203-001036 CHIP CAPACITOR 5.6nF 50V
EC03R 2203-001036 CHIP CAPACITOR 5.6nF 50V
EC101 2203-000206 CHIP CAPACITOR 100nF 50V
EC102 2203-000206 CHIP CAPACITOR 100nF 50V
EC103 2203-000206 CHIP CAPACITOR 100nF 50V
EC105 2203-000206 CHIP CAPACITOR 100nF 50V
EC106 2203-001596 CHIP CAPACITOR 2200nF 50V
EC107 2203-000206 CHIP CAPACITOR 100nF 50V
EE005 2401-000414 E CAPACITOR 10uF 16V
EE006 2401-000414 E CAPACITOR 10uF 16V
EE007 2401-002042 E CAPACITOR 220uF 10V
EE009 2401-001952 E CAPACITOR 4.7uF 50V
EE010 2401-001952 E CAPACITOR 4.7uF 50V
EE011 2401-001931 E CAPACITOR 220nF 50V
EE01L 2401-000650 E CAPACITOR 2.2uF 50V
EE01R 2401-000650 E CAPACITOR 2.2uF 50V
EE02L 2401-000598 E CAPACITOR 1uF 50V
EE02R 2401-000598 E CAPACITOR 1uF 50V
EE03L 2401-000598 E CAPACITOR 1uF 50V
EE03R 2401-000598 E CAPACITOR 1uF 50V
EE04L 2401-000598 E CAPACITOR 1uF 50V
EE04R 2401-000598 E CAPACITOR 1uF 50V
EE06L 2401-000588 E CAPACITOR 1uF 50V
EE06R 2401-000588 E CAPACITOR 1uF 50V
EE07L 2401-000598 E CAPACITOR 1uF 50V
EE07R 2401-000598 E CAPACITOR 1uF 50V
EE10L 2401-000414 E CAPACITOR 10uF 16V
EE10R 2401-000414 E CAPACITOR 10uF 16V
EE110 2401-001975 E CAPACITOR 47uF 16V
EMC01 2203-000206 CHIP CAPACITOR 100nF 50V
EMC02 2203-000206 CHIP CAPACITOR 100nF 50V
FC010 2203-000206 CHIP CAPACITOR 100nF 50V
FC011 2203-000206 CHIP CAPACITOR 100nF 50V
FC012 2203-000206 CHIP CAPACITOR 100nF 50V
FC013 2203-001596 CHIP CAPACITOR 2200nF 50V
FC014 2203-000206 CHIP CAPACITOR 100nF 50V
FC015 2203-000206 CHIP CAPACITOR 100nF 50V
FC01L 2203-000787 CHIP CAPACITOR 0.33nF 50V
FC01R 2203-000787 CHIP CAPACITOR 0.33nF 50V
FC02L 2203-000206 CHIP CAPACITOR 100nF 50V
FC02R 2203-000206 CHIP CAPACITOR 100nF 50V
FC03L 2203-000206 CHIP CAPACITOR 100nF 50V
FC03R 2203-000206 CHIP CAPACITOR 100nF 50V
FC04L 2203-000206 CHIP CAPACITOR 100nF 50V
FC04R 2203-000206 CHIP CAPACITOR 100nF 50V
FC05L 2203-000206 CHIP CAPACITOR 100nF 50V
FC05R 2203-000206 CHIP CAPACITOR 100nF 50V
FC06L 2305-000412 M CAPACITOR 470nF
FC06R 2305-000412 M CAPACITOR 470nF
FC07L 2203-000260 CHIP CAPACITOR 10nF 50V
FC07R 2203-000260 CHIP CAPACITOR 10nF 50V
FC08L 2203-000260 CHIP CAPACITOR 10nF 50V
FC08R 2203-000260 CHIP CAPACITOR 10nF 50V
FC09L 2203-000260 CHIP CAPACITOR 10nF 50V
FC09R 2203-000260 CHIP CAPACITOR 10nF 50V
FC10L 2203-001596 CHIP CAPACITOR 2200nF 50V
FC10R 2203-001596 CHIP CAPACITOR 2200nF 50V
FC11L 2203-001596 CHIP CAPACITOR 2200nF 50V
FC11R 2203-001596 CHIP CAPACITOR 2200nF 50V
FC12L 2303-000312 M CAPACITOR 100nF 63V
FC13L 2203-000787 CHIP CAPACITOR 0.33nF 50V
FC13R 2203-000787 CHIP CAPACITOR 0.33nF 50V
FC14L 2203-000206 CHIP CAPACITOR 100nF 50V
FC14R 2203-000206 CHIP CAPACITOR 100nF 50V
FE101 2401-003850 E CAPACITOR 1000uF 50V
FL12R 2303-000312 M CAPACITOR 100nF 63V
HC006 2203-000206 CHIP CAPACITOR 100nF 50V
HC01L 2203-000661 CHIP CAPACITOR 0.27nF 50V
HC01R 2203-000661 CHIP CAPACITOR 0.27nF 50V
HC02L 2203-000595 CHIP CAPACITOR 0.22nF 50V
HC02R 2203-000595 CHIP CAPACITOR 0.22nF 50V
HC03L 2203-000595 CHIP CAPACITOR 0.22nF 50V
HC03R 2203-000595 CHIP CAPACITOR 0.22nF 50V
HC04L 2203-000239 CHIP CAPACITOR 0.1nF 50V
HC04R 2203-000239 CHIP CAPACITOR 0.1nF 50V
HC05L 2203-000595 CHIP CAPACITOR 0.22nF 50V
 Symbol No. Part No. Part Name Description Local
HC05R 2203-000595 CHIP CAPACITOR 0.22nF 50V
HE002 2401-001508 E CAPACITOR 47uF 16V
HE01L 2401-000042 E CAPACITOR 100uF 16V
HE01R 2401-000042 E CAPACITOR 100uF 16V
MC101 2203-000206 CHIP CAPACITOR 100nF 50V
MC102 2203-000206 CHIP CAPACITOR 100nF 50V
MC103 2203-000206 CHIP CAPACITOR 100nF 50V
MC104 2203-000634 CHIP CAPACITOR 0.022nF 50V
MC105 2203-001524 CHIP CAPACITOR 0.047nF 50V
MC106 2203-000206 CHIP CAPACITOR 100nF 50V
MC107 2203-000239 CHIP CAPACITOR 0.1nF 50V
MC108 2203-000239 CHIP CAPACITOR 0.1nF 50V
MC109 2203-000206 CHIP CAPACITOR 100nF 50V
MC110 2203-000206 CHIP CAPACITOR 100nF 50V
MC111 2203-000206 CHIP CAPACITOR 100nF 50V
MC112 2203-000206 CHIP CAPACITOR 100nF 50V
MC113 2203-000206 CHIP CAPACITOR 100nF 50V
MC114 2203-000206 CHIP CAPACITOR 100nF 50V
MC115 2203-000206 CHIP CAPACITOR 100nF 50V
MC118 2203-000206 CHIP CAPACITOR 100nF 50V
ME101 2401-000918 E CAPACITOR 22uF 16V
ME102 2401-000651 E CAPACITOR 2.2uF 50V
SE102 2401-000970 E CAPACITOR 22uF 50V
SE103 2401-000804 E CAPACITOR 220uF 16V
TE101 2401-001508 E CAPACITOR 47uF 16V
WC01L 2203-000575 CHIP CAPACITOR 220nF 25V
WC01R 2203-000575 CHIP CAPACITOR 220nF 25V
WC02L 2203-000575 CHIP CAPACITOR 220nF 25V
WC02R 2203-000575 CHIP CAPACITOR 220nF 25V
WC03L 2203-000575 CHIP CAPACITOR 220nF 25V
WC03R 2203-000575 CHIP CAPACITOR 220nF 25V
WC04L 2203-000575 CHIP CAPACITOR 220nF 25V
WC04R 2203-000575 CHIP CAPACITOR 220nF 25V
WC05L 2305-000412 M CAPACITOR 470nF
WC05R 2305-000412 M CAPACITOR 470nF
WC06L 2203-000206 CHIP CAPACITOR 100nF 50V
WC06R 2203-000206 CHIP CAPACITOR 100nF 50V
WC07L 2203-000206 CHIP CAPACITOR 100nF 50V
WC07R 2203-000206 CHIP CAPACITOR 100nF 50V
WC08L 2203-000260 CHIP CAPACITOR 10nF 50V
WC08R 2203-000260 CHIP CAPACITOR 10nF 50V
WC09L 2203-001596 CHIP CAPACITOR 2200nF 50V
WC09R 2203-001596 CHIP CAPACITOR 2200nF 50V
WC10L 2203-000206 CHIP CAPACITOR 100nF 50V
WC10R 2203-001596 CHIP CAPACITOR 2200nF 50V
WC11L 2203-001596 CHIP CAPACITOR 2200nF 50V
WC11R 2203-001596 CHIP CAPACITOR 2200nF 50V
WC12L 2203-001596 CHIP CAPACITOR 2200nF 50V
WC12R 2203-001596 CHIP CAPACITOR 2200nF 50V
WC13L 2203-001128 CHIP CAPACITOR 0.68nF 50V
WC13R 2203-001128 CHIP CAPACITOR 0.68nF 50V
WC14L 2203-001596 CHIP CAPACITOR 2200nF 50V
WC14R 2203-000206 CHIP CAPACITOR 100nF 50V
WC15L 2203-000206 CHIP CAPACITOR 100nF 50V
WC15R 2203-000206 CHIP CAPACITOR 100nF 50V
WC16L 2203-000206 CHIP CAPACITOR 100nF 50V
WC16R 2203-000206 CHIP CAPACITOR 100nF 50V
WC17L 2203-001596 CHIP CAPACITOR 2200nF 50V
WC17R 2203-001596 CHIP CAPACITOR 2200nF 50V
WC18L 2203-000206 CHIP CAPACITOR 100nF 50V
WC18R 2203-000206 CHIP CAPACITOR 100nF 50V
WC19L 2203-000206 CHIP CAPACITOR 100nF 50V
WC19R 2203-000206 CHIP CAPACITOR 100nF 50V
WC20L 2305-000412 M CAPACITOR 470nF
WC20R 2305-000412 M CAPACITOR 470nF
WC21L 2203-001128 CHIP CAPACITOR 0.68nF 50V
WC21R 2203-001128 CHIP CAPACITOR 0.68nF 50V
WC22L 2203-001128 CHIP CAPACITOR 0.68nF 50V
WC22R 2203-001128 CHIP CAPACITOR 0.68nF 50V
WC23L 2203-001128 CHIP CAPACITOR 0.68nF 50V
WC23R 2203-001128 CHIP CAPACITOR 0.68nF 50V
WC24L 2203-000206 CHIP CAPACITOR 100nF 50V
WC24R 2203-000206 CHIP CAPACITOR 100nF 50V
WC25L 2203-000206 CHIP CAPACITOR 100nF 50V
WC25R 2203-000206 CHIP CAPACITOR 100nF 50V
WE01L 2401-003850 E CAPACITOR 1000uF 50V
WE01R 2401-003850 E CAPACITOR 1000uF 50V
XC101 2203-000634 CHIP CAPACITOR 0.022nF 50V
 Symbol No. Part No. Part Name Description Local

3-8
XC102 2203-000634 CHIP CAPACITOR 0.022nF 50V
XC103 2203-000206 CHIP CAPACITOR 100nF 50V
XE101 2401-000414 E CAPACITOR 10uF 16V
AR101 2007-000300 CHIP RESISTOR 10K Ω
AR102 2007-000493 CHIP RESISTOR 2.2K Ω
AR103 2007-000586 CHIP RESISTOR 22K Ω
AR104 2007-001168 CHIP RESISTOR 75 Ω 1/4W
AR105 2007-000598 CHIP RESISTOR 22 Ω 1/4W
CR101 2007-001039 CHIP RESISTOR 56K Ω
CR102 2007-001039 CHIP RESISTOR 56K Ω
CR103 2007-000457 CHIP RESISTOR 18K Ω
CR104 2007-000457 CHIP RESISTOR 18K Ω
CR105 2007-000468 CHIP RESISTOR 1K Ω
EC104 2203-000126 CHIP RESISTOR 1.2nF 50V
ER01L 2007-000686 CHIP RESISTOR 3.3K Ω
ER01R 2007-000686 CHIP RESISTOR 3.3K Ω
ER02L 2007-000572 CHIP RESISTOR 220 Ω
ER02R 2007-000572 CHIP RESISTOR 220 Ω
ER03L 2007-000941 CHIP RESISTOR 47K Ω
ER03R 2007-000941 CHIP RESISTOR 47K Ω
ER08L 2007-000468 CHIP RESISTOR 1K Ω
ER08R 2007-000468 CHIP RESISTOR 1K Ω
ER101 2007-000395 CHIP RESISTOR 150K Ω 1/10W
ER102 2007-000395 CHIP RESISTOR 150K Ω 1/10W
ER103 2007-000947 CHIP RESISTOR 47 Ω 1/8W
ER104 2007-000947 CHIP RESISTOR 47 Ω 1/8W
ER105 2007-000950 CHIP RESISTOR 47 Ω 1/4W
ER106 2007-000766 CHIP RESISTOR 330 Ω
ER108 2007-000068 CHIP RESISTOR 470K Ω 1/8W
ER109 2007-000023 CHIP RESISTOR 120 Ω 1/10W
ER110 2007-000300 CHIP RESISTOR 10K Ω
ER111 2007-000778 CHIP RESISTOR 330K Ω 1/10W
ER112 2007-001195 CHIP RESISTOR 820K Ω
FR004 2007-000300 CHIP RESISTOR 10K Ω
FR005 2007-000468 CHIP RESISTOR 1K Ω
FR01L 2007-000598 CHIP RESISTOR 22 Ω 1/4W
FR01R 2007-000598 CHIP RESISTOR 22 Ω 1/4W
FR02L 2007-000883 CHIP RESISTOR 4.7 Ω 1/4W
FR02R 2007-000883 CHIP RESISTOR 4.7 Ω 1/4W
FR03L 2007-000883 CHIP RESISTOR 4.7 Ω 1/4W
FR03R 2007-000883 CHIP RESISTOR 4.7 Ω 1/4W
FR04L 2007-000598 CHIP RESISTOR 22 Ω 1/4W
FR04R 2007-000598 CHIP RESISTOR 22 Ω 1/4W
HR001 2007-000950 CHIP RESISTOR 47 Ω 1/4W
HR013 2007-000941 CHIP RESISTOR 47K Ω
HR014 2007-000300 CHIP RESISTOR 10K Ω
HR01L 2007-000872 CHIP RESISTOR 4.7K Ω
HR01R 2007-000872 CHIP RESISTOR 4.7K Ω
HR02L 2007-000872 CHIP RESISTOR 4.7K Ω
HR02R 2007-000872 CHIP RESISTOR 4.7K Ω
HR03L 2007-000872 CHIP RESISTOR 4.7K Ω
HR03R 2007-000872 CHIP RESISTOR 4.7K Ω
HR04L 2007-000872 CHIP RESISTOR 4.7K Ω
HR04R 2007-000872 CHIP RESISTOR 4.7K Ω
HR05L 2007-000872 CHIP RESISTOR 4.7K Ω
HR05R 2007-000872 CHIP RESISTOR 4.7K Ω
HR06L 2007-000872 CHIP RESISTOR 4.7K Ω
HR06R 2007-000872 CHIP RESISTOR 4.7K Ω
HR07L 2007-000872 CHIP RESISTOR 4.7K Ω
HR07R 2007-000872 CHIP RESISTOR 4.7K Ω
HR08L 2007-000308 CHIP RESISTOR 10 Ω
HR08R 2007-000308 CHIP RESISTOR 10 Ω
HR09L 2007-000300 CHIP RESISTOR 10K Ω
HR09R 2007-000300 CHIP RESISTOR 10K Ω
HR10L 2007-000300 CHIP RESISTOR 10K Ω
HR10R 2007-000300 CHIP RESISTOR 10K Ω
HR11L 2007-000300 CHIP RESISTOR 10K Ω
HR11R 2007-000300 CHIP RESISTOR 10K Ω
HR12L 2007-000468 CHIP RESISTOR 1K Ω
HR12R 2007-000468 CHIP RESISTOR 1K Ω
MC116 2203-000126 CHIP RESISTOR 1.2nF 50V
MC117 2203-000126 CHIP RESISTOR 1.2nF 50V
MR001 2007-000947 CHIP RESISTOR 47
Ω 1/8W
MR002 2007-000468 CHIP RESISTOR 1K
Ω
MR101 2007-000300 CHIP RESISTOR 10K Ω
MR102 2007-000290 CHIP RESISTOR 100 Ω
MR103 2007-000947 CHIP RESISTOR 47 Ω 1/8W
 Symbol No. Part No. Part Name Description Local
MR104 2007-000947 CHIP RESISTOR 47 Ω 1/8W
MR105 2007-000290 CHIP RESISTOR 100 Ω
MR106 2007-000290 CHIP RESISTOR 100 Ω
MR107 2007-000300 CHIP RESISTOR 10K Ω
MR108 2007-000300 CHIP RESISTOR 10K Ω
MR110 2007-000766 CHIP RESISTOR 330 Ω
MR111 2007-000686 CHIP RESISTOR 3.3K Ω
MR112 2007-000300 CHIP RESISTOR 10K Ω
SR001 2007-000518 CHIP RESISTOR 2.7K Ω
SR002 2007-000300 CHIP RESISTOR 10K Ω
SR003 2007-000030 CHIP RESISTOR 560 Ω 1/8W
SR004 2007-000300 CHIP RESISTOR 10K Ω
SR005 2007-000653 CHIP RESISTOR 27K Ω
SR103 2007-001216 CHIP RESISTOR 82 Ω
SR104 2007-000778 CHIP RESISTOR 330K Ω 1/10W
SR105 2007-000778 CHIP RESISTOR 330K Ω 1/10W
SR106 2007-000586 CHIP RESISTOR 22K Ω
TR01L 2007-000457 CHIP RESISTOR 18K Ω
TR01R 2007-000457 CHIP RESISTOR 18K Ω
TR02L 2007-000300 CHIP RESISTOR 10K Ω
TR02R 2007-000300 CHIP RESISTOR 10K Ω
WR01L 2007-000312 CHIP RESISTOR 10 Ω 1/4W
WR01R 2007-000312 CHIP RESISTOR 10 Ω 1/4W
WR02L 2007-001074 CHIP RESISTOR 6.8 Ω 1/8W
WR02R 2007-001074 CHIP RESISTOR 6.8 Ω 1/8W
WR03L 2007-001074 CHIP RESISTOR 6.8 Ω 1/8W
WR03R 2007-001074 CHIP RESISTOR 6.8 Ω 1/8W
WR04L 2007-001074 CHIP RESISTOR 6.8 Ω 1/8W
WR04R 2007-001074 CHIP RESISTOR 6.8 Ω 1/8W
WR05L 2007-001074 CHIP RESISTOR 6.8 Ω 1/8W
WR05R 2007-001074 CHIP RESISTOR 6.8 Ω 1/8W
WR07L 2007-000300 CHIP RESISTOR 10K Ω
WR07R 2007-000300 CHIP RESISTOR 10K Ω
WR08L 2007-000312 CHIP RESISTOR 10 Ω 1/4W
WR08R 2007-000312 CHIP RESISTOR 10 Ω 1/4W
WR09L 2007-000312 CHIP RESISTOR 10 Ω 1/4W
WR09R 2007-000312 CHIP RESISTOR 10 Ω 1/4W
WR10L 2007-000312 CHIP RESISTOR 10 Ω 1/4W
WR10R 2007-000312 CHIP RESISTOR 10 Ω 1/4W
XR101 2007-000477 CHIP RESISTOR 1M Ω
XR102 2007-000931 CHIP RESISTOR 470 Ω
FL01L AH27-00061A COIL FILTER 45m Ω
FL01R AH27-00061A COIL FILTER 45m Ω
FL02L AH27-00061A COIL FILTER 45m Ω
FL02R AH27-00061A COIL FILTER 45m Ω
WL01L AH27-00062A COIL FILTER 45m Ω
WL01R AH27-00062A COIL FILTER 45m Ω
WL02L AH27-00062A COIL FILTER 45m Ω
WL02R AH27-00062A COIL FILTER 45m Ω
WL03L AH27-00062A COIL FILTER 45m Ω
WL03R AH27-00062A COIL FILTER 45m Ω
WL04L AH27-00062A COIL FILTER 45m Ω
WL04R AH27-00062A COIL FILTER 45m Ω
AQ101 KSC2331 TRANSISTOR 0501-000369
AQ102 KTA1273 TRANSISTOR 0501-000422
CN101 3708-001696 CONNECTOR 24P
CN102 3711-000724 CONNECTOR 15P
CN105 3711-002809 CONNECTOR BOX 8P 1R 2mm
CN106 AH39-00904A CONNECT WIRE 9P for SMPS
SMCN01
CN107 AH39-00903A CONNECT WIRE 15P for SMPS-
SMCN02
CN108 3711-000820 CONNECTOR 2P 1R 2.5mm
CQ101 KSR2101 TRANSISTOR 0504-000152
CQ102 KTD1304 TRANSISTOR 0501-002184
CQ103 KTD1304 TRANSISTOR 0501-002184
EL101 3301-001345 FERRITE BEADS 600
Ω 300mA
EL102 3301-001345 FERRITE BEADS 600
Ω 300mA
EQ101 KTD1304 TRANSISTOR 0501-002184
FL003 3301-001345 FERRITE BEADS 600
Ω 300mA
FL03L AH29-00014A LINE FILTER PLF1109-002
FL03R AH29-00014A LINE FILTER PLF1109-002
HL01L 3301-001345 FERRITE BEADS 600 Ω 300mA
HL01R 3301-001345 FERRITE BEADS 600
Ω 300mA
HQ002 KTD1304 TRANSISTOR 0501-002184
HQ01L KTD1304 TRANSISTOR 0501-002184
 Symbol No. Part No. Part Name Description Local
