Instruction Manual
32” HD-Ready LED TV with DVD
LT-32C345A / LT-32C346A
GB
LT-32C345_46A_IB.indd 1 25/09/2014 11:26

Contents
1 Safety Warnings ...........................................................................................................................................................................5
2 Preparation...................................................................................................................................................................................7
Unpacking the TV ...............................................................................................................................................................................................................7
Installing / Removing the Base Stand .........................................................................................................................................................................8
Mounting the TV to a Wall...............................................................................................................................................................................................8
Front / Right Side View and Controls...........................................................................................................................................................................9
Rear View and Sockets....................................................................................................................................................................................................10
Installing Batteries in the Remote Control ..............................................................................................................................................................11
Remote Control Operation Range..............................................................................................................................................................................11
Remote Control .................................................................................................................................................................................................................12
3 Initial Setup ................................................................................................................................................................................14
Turning the TV On for the First Time .........................................................................................................................................................................14
− Choose Region.......................................................................................................................................................................................................15
− Connecting an Analogue Device....................................................................................................................................................................16
− Channel Selection ...............................................................................................................................................................................................16
− Display Channel Information ...........................................................................................................................................................................16
− Volume Adjustment.............................................................................................................................................................................................16
4 Customising TV Settings ...........................................................................................................................................................17
Adjusting the Picture Settings.....................................................................................................................................................................................17
− Aspect Ratio............................................................................................................................................................................................................18
Adjusting the Sound Settings......................................................................................................................................................................................18
Editing the Channel List .................................................................................................................................................................................................19
Creating a Favourite Channel List...............................................................................................................................................................................19
− Activate your favourite channel list...............................................................................................................................................................19
Saving a Channel/Source to the My Buttons ( / )......................................................................................................................... 20
5 Using the Features.....................................................................................................................................................................21
Programme Guide............................................................................................................................................................................................................21
− Switch On / O Programme Guide ................................................................................................................................................................21
− Select a Programme ............................................................................................................................................................................................21
Time Shift Recording onto a USB Storage Device ............................................................................................................................................... 23
Recording DTV Programmes onto a USB Storage Device ................................................................................................................................ 24
Timer Programming ....................................................................................................................................................................................................... 25
Recording Conguration .............................................................................................................................................................................................. 26
Playing Recorded Programmes.................................................................................................................................................................................. 27
Digital Teletext (DTV Mode)......................................................................................................................................................................................... 28
− Teletext within Digital Service........................................................................................................................................................................ 28
Listening to the Radio.................................................................................................................................................................................................... 28
6 Using the DVD Features ............................................................................................................................................................29
Using the Built-in DVD Player...................................................................................................................................................................................... 29
Compatible Disc Types .................................................................................................................................................................................................. 29
− Supported Formats............................................................................................................................................................................................. 29
− Region Code.......................................................................................................................................................................................................... 29
Basic DVD Playback Functions.................................................................................................................................................................................... 30
7 Other Information......................................................................................................................................................................33
CI (Common Interface) (DTV Mode).......................................................................................................................................................................... 33
Time Settings..................................................................................................................................................................................................................... 34
Other Settings................................................................................................................................................................................................................... 35
Language Settings .......................................................................................................................................................................................................... 36
Sources................................................................................................................................................................................................................................. 36
Resetting your TV ............................................................................................................................................................................................................ 37
Parental Settings.............................................................................................................................................................................................................. 38
LT-32C345_46A_IB.indd 2 25/09/2014 11:26

8 Entertainment ............................................................................................................................................................................39
Connecting a USB Storage Device............................................................................................................................................................................. 39
Viewing Videos................................................................................................................................................................................................................. 40
Viewing Photos..................................................................................................................................................................................................................41
Listening to Music............................................................................................................................................................................................................ 42
9 Technical Information and Help...............................................................................................................................................43
Maintenance...................................................................................................................................................................................................................... 43
Hints and Tips.................................................................................................................................................................................................................... 44
Remote Control Codes................................................................................................................................................................................................... 45
− Sky Codes ............................................................................................................................................................................................................... 45
− Virgin Media Codes (TiVo box) ....................................................................................................................................................................... 45
− BT Vision.................................................................................................................................................................................................................. 45
Specications .................................................................................................................................................................................................................. 46
License Information used with JVC Televisions.................................................................................................................................................... 47
LT-32C345_46A_IB.indd 3 25/09/2014 11:26

WE KNOWHOW
TO HELP YOU
WITH YOUR TV
We want you to be able to enjoy your new TV for many years. From getting it home and setting it up, to
helping you get the most out of your new purchase. And in the unlikely event your TV lets you down, we
can get it working again in no time.
Here are some of our TV services but if you want to know more look us up at www.knowhow.com or call
us on: 0344 561 1234
TV SET UP & DEMO
We’ll assemble the stand and connect your new TV to the existing equipment. We’ll tune your TV so it’s
ready to watch. We'll also give you a demonstration of your new TV's functions.
TV WALLMOUNT & DEMO
We’ll fix your TV to a suitable position on the wall and connect your existing equipment, so it’s all ready
to go. We’ll use neat wire management so you don't have to look at any untidy cabling and to complete
your fuss-free installation, we'll test and demonstrate your TV's functions.
FREESAT INSTALLATION
We’ll set up the Freesat receiver and connect it to your existing dish, TV and cabling. We'll then tune in
all available channels.
AERIAL INSTALLATION
We'll supply, install and align a new, high quality aerial and connect it to your Freeview receiver and TV.
Then we'll scan and tune in all available digital channels.
HOME CINEMA OR SOUNDBAR INSTALLATION
We’ll un-box, connect and set up your new and existing equipment. We’ll then configure, calibrate and
optimise the equipment. To avoid ugly trailing cables, we’ll clip them to your skirting board, if you’d like
us to. Then we’ll give you a demonstration.
FAULT & FIX SERVICES
With our Fault & Fix services we can repair a wide range of products at our new state-of-the-art repair
lab. This service is available for:
• Computer desktops • Laptops
• Netbooks • TVs
LT-32C345_46A_IB.indd 4 25/09/2014 11:26

5
1 Safety Warnings
• Read all the instructions carefully before using the unit
and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
• Check that the voltage marked on the rating label
matches your mains voltage.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any
doubt about it working normally, or if it is damaged
in any way - switch off, withdraw the mains plug and
consult your dealer.
Location of Unit
• The unit must be placed on a flat stable surface and
should not be subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces as
the unit may fall off or tip over.
• The mains socket must be located near the unit and
should be easily accessible.
• This unit is designed for indoor, domestic use only.
Temperature
• Avoid extreme degrees of temperature, either hot or
cold. Place the unit well away from heat sources such
as radiators or gas / electric fires.
• Avoid exposure to direct sunlight and other sources of
heat.
Naked Flames
• Never place any type of candle or naked flame on the
top of or near the unit.
Moisture
• To reduce the risk of fire, electric shock or product
damage, do not expose this unit to rain, moisture,
dripping or splashing. No objects filled with liquids,
such as vases, should be placed on the unit.
• If you spill any liquid into the unit, it can cause serious
damage. Switch it off at the mains immediately.
Withdraw the mains plug and consult your dealer.
Ventilation
• To prevent the risk of electric shock or fire hazard
due to overheating, ensure that curtains and other
materials do not obstruct the ventilation vents.
• Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure the unit is
well ventilated.
• Make sure that there is a gap of at least 10 cm on both
sides and a gap of 20 cm at the top.
• Unplug the unit from the mains socket during a
lightning storm.
Mains Cable
• Make sure the unit or unit stand is not resting on top of
the mains cable, as the weight of the unit may damage
the mains cable and create a safety hazard.
• If the mains cable is damaged it must be replaced
by the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard.
Interference
• Do not place the unit on or near appliances which may
cause electromagnetic interference. If you do, it may
adversely affect the operating performance of the unit,
and cause a distorted picture or sound.
Optimum viewing
• View the unit in moderate light to prevent eye strain. It
is recommended to watch the unit from a distance
3-7 times that of the screen height.
LCD screen
• The LCD screen is manufactured using high-precision
technology. However, some tiny black points and /
or bright points (red, blue or green in colour) may
constantly appear on the LCD screen. These points
are generated in the manufacturing process and are
normal.
Screen Burn
• A characteristic of Plasma and TV Panels is that
displaying the same image for a long time may cause
a permanent after-image to remain on the screen. This
is called screen burn. Most pictures shown on the unit
will be constantly moving and fill the screen.
• Examples of images that you need to watch out for are
as follows (this is not an all-inclusive list):
1. Black Bars: If black bars appear at the left / right or
top / bottom of the screen, it is recommended to
change the format so that the picture fills the entire
screen.
2. TV Channel Logos: e.g. Shopping channel logos
and pricing displays - especially if they are bright
and stationary. Moving or low-contrast graphics are
less likely to cause ageing of the screen.
3. Time Displays
4. Teletext: Do not view a stationary page for long
periods of time.
5. TV Menus
6. Pause Mode: Do not leave the screen in pause
mode for long periods of time, e.g. when watching
videos.
• To prevent screen burn if viewing any of the above for
long periods of time, reduce contrast and brightness
when viewing. Once burn-in occurs it will never
disappear completely.
Earphones
• Listening to loud sounds for prolonged periods of time
may permanently damage your hearing.
• Before putting on earphones, turn the volume down
then put the earphones on and slowly increase the
volume until you reach a comfortable listening level.
10 cm 10 cm
20 cm
10 cm
Chapter
1
Safety
• Always disconnect the unit from the mains supply
before connecting / disconnecting other devices or
moving the unit.
WE KNOWHOW
TO HELP YOU
WITH YOUR TV
We want you to be able to enjoy your new TV for many years. From getting it home and setting it up, to
helping you get the most out of your new purchase. And in the unlikely event your TV lets you down, we
can get it working again in no time.
Here are some of our TV services but if you want to know more look us up at www.knowhow.com or call
us on: 0344 561 1234
TV SET UP & DEMO
We’ll assemble the stand and connect your new TV to the existing equipment. We’ll tune your TV so it’s
ready to watch. We'll also give you a demonstration of your new TV's functions.
TV WALLMOUNT & DEMO
We’ll fix your TV to a suitable position on the wall and connect your existing equipment, so it’s all ready
to go. We’ll use neat wire management so you don't have to look at any untidy cabling and to complete
your fuss-free installation, we'll test and demonstrate your TV's functions.
FREESAT INSTALLATION
We’ll set up the Freesat receiver and connect it to your existing dish, TV and cabling. We'll then tune in
all available channels.
AERIAL INSTALLATION
We'll supply, install and align a new, high quality aerial and connect it to your Freeview receiver and TV.
Then we'll scan and tune in all available digital channels.
HOME CINEMA OR SOUNDBAR INSTALLATION
We’ll un-box, connect and set up your new and existing equipment. We’ll then configure, calibrate and
optimise the equipment. To avoid ugly trailing cables, we’ll clip them to your skirting board, if you’d like
us to. Then we’ll give you a demonstration.
FAULT & FIX SERVICES
With our Fault & Fix services we can repair a wide range of products at our new state-of-the-art repair
lab. This service is available for:
• Computer desktops • Laptops
• Netbooks • TVs
LT-32C345_46A_IB.indd 5 25/09/2014 11:26

6
1Safety Warnings
Standby
• The button on the remote control does not switch
off the unit completely. The unit will continue to draw
electricity from the mains supply while in standby. In
the interests of safety and to avoid unnecessary energy
consumption, never leave the unit in standby while
unattended for long periods of time, e.g. overnight,
while on holiday or while out of the house. Disconnect
the mains plug from the mains socket.
Batteries
• Batteries used in the remote control for this unit
are easily swallowed by young children and this is
dangerous.
• Keep loose batteries away from young children and
make sure that the battery holder tray is secure in the
remote control. Seek medical advice if you believe a
cell has been swallowed.
• Please dispose of batteries correctly by following the
guidance in this manual.
• The batteries shall not be exposed to excessive heat
such as sunshine, fire or the like.
Supervision
• Children should be supervised to ensure that they do
not play with the unit and the remote control.
• Never let anyone especially children push anything
into the holes, slots or any other openings in the case -
this could result in a fatal electric shock.
DVD
• Class 1 Laser Product
This unit utilises a laser. Use
of controls, adjustments or
performance of procedures other
than those specified herein may
result in hazardous radiation
exposure.
• Before moving the unit, ensure the disc tray is empty.
• Always remove the disc when the unit is not in use.
• Failure to do so will risk severely damaging the disc
and the unit.
• Do not stack devices, heat from other devices may
aect the performance of the unit.
CLASS 1
LASER PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the unit’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
manual accompanying the unit.
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-serviceable
parts. Please leave all maintenance work to qualified
personnel.
• Do not open any fixed covers as this may expose
dangerous voltages.
Maintenance
• Ensure to unplug the unit from the mains socket before
cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
• The wall socket plug is used as a disconnect device, the
disconnect device should be readily accessible.
• This equipment is a Class II or double insulated
electrical appliance. It has been designed in such
a way that it does not require a safety connection
to electrical earth.
To prevent the spread of
fire, keep candles or other
open flames away from this
product at all times.
LT-32C345_46A_IB.indd 6 25/09/2014 11:26

7
2 Preparation
Unpacking the TV
Remove all packaging from the TV. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
Thank you for purchasing your new JVC TV.
Your new TV has many features and incorporates the latest technology to enhance your viewing
experience. We recommend that you spend some time reading this instruction manual so that you fully
understand these features. You will also find some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future reference.
Chapter
2
Remote Control /
AAA Batteries x 2
Stand screws x4
Instruction Manual Quick Start Guide
Instruction Manual
32” HD-Ready LED TV with DVD
LT-32C345A / LT-32C346A
GB
• Donot connect the TV to the mains supply until you have completed all the connections.
• Alwaysdisconnect the TV from the mains socket when not in use for a long period of time.
• The buttonon the remote control is only used for switching the TV into standby, it does not disconnect the TV from the mains power.
Tocompletely disconnect the mains power, please remove the mains plug from the mains socket.
TheLCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object,
oranything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure on the front of theT V at any time because
thescreen could crack.
Removeall packaging from the unit. Retain the packaging.
Ifyou dispose of it please do so according to any local regulations.
TV
TVStand
RemoteControl/
AAABatteries x2
Screwsx 4
InstructionManual
QuickStart Guide
Unpacking
1
1. Connect one end of the RF coaxial cable to the aerial socket on the wall and the
otherend of the cable to the ANT socket on the back of your TV.
2. Plug the TV into a mains socket and switch on at the mains.
3. In standby mode, press the button on the remote controlto turn the TV on.
Thered LED indicator will ash for a few seconds then the TV will switch on.
1. The rst time you turn the TV on, it will go
straightinto the First Time Installation
menu.Please ensure the aerial is plugged in.
Pressthe buttonsto highlight your
languagethen press OK.
2. Press the buttonsto select your country.
3. Press the buttonto highlight Search Type,
thenpress the buttonsto select Digital
Only.This will only search for the digital
channels.
4. Press the buttonto highlight Teletext
Language,then press the buttonsto
selectyour language. The majority of people
willwant this set to West.
5. Press the buttonto highlight Scan
EncryptedChannel (pay-per-view channels),
thenpress the buttonsto select Yes
orNo.
6. Conrm these settings by pressing OK.
7. Press the buttonsto highlight Home
Modethen press OK.
8. You will now be asked if youwant to start
theautomatic channel scan. Press the
buttonsto highlight Yes and press OK.
Choose Region
Duringtuning, your TV may have received
signalsfrom more than one transmitter. If this
hasoccurred the Choose Region screen will be
displayed.This will enable you to select the
correctregional transmission for the local news
servicethat you require.
1. Press the buttonto highlight Primary
region,then press the buttonsto select
yourPrimary Region e.g. England.
2. Press the buttonto highlight Secondary
region,then press the buttonsto select
yourSecondary Region e.g. London.
3. Press the buttonto highlight Tertiary
region,then press the buttonsto select
yourTertiary Region e.g. Greater London.
4. Press the buttonto highlight OK then
pressOK. Your TV is now fully tuned in.
5. The Edit Channel list will appear, press the
EXITbutton to remove this. YourT V is now
fullytuned in and ready to use.
Connecting the Aerial and Turningon the TV
Tuning in theT V
4
5
1. Ensure the TV is switched o and not connected to
themains power supply.
2. Lay the TV down on a at surface ideally on the edge
ofa table so the base of the TV slightly overhangs
theedge of the table, with the back side facing up.
Pleasemake sure a soft cushioned materi al (such as
adry bath towel or thick piece of foam) is placed
beneaththe screen.
3. Slide the stand under the lip, the neck will t snuggly
overthe screw holes. Then screw the stand to the TV
usingthe 4 screws supplied.
Installing the Base Stand
3
Welldone, your new TV is now ready to use. You will nd that there aremany exciting features available. To get to know all these features,please take
sometime to read the instruction manual provided with your TV.
(QSG-LT-32C345/46A-140923V1)
1. Open the battery
compartmenton the back
ofthe remote control.
2. Insert two AAA size
batteries.Make sure to
matchthe (+) and ( - ) ends
ofthe batteries with the
(+)and ( - ) ends indicated
inthe battery compartment.
3. Replace the battery
compartment cover. Make sure it clicks into place.
Operating YourRemote Control
2
Thank you for purchasingyour new JVC TV.
Yournew TV incorporates the latest technology to enhance your viewing
experience.We would suggest that you allow about 20 mins for initial setup.
Pleasefollow this guide for a successful rst time installation.
Thelatest eco-friendly power-saving technology will switch o the TV if
deviceis left on and idle for 4 hours. Please refer to “AutoStandby” under
the“Time Settings” section of the instruction manual for more detail.
Quick Start Guide
32" HD-Ready LED TV
with DVD
LT-32C345A / LT-32C346A
Slideunder
thelip
Slideunder
thelip
Table
Cushioned
material
SCART
SPDIF
VGA
ANT.
HDMI1 HDMI2
RFcoaxial cable
(notincluded)
Firsttimeinstallation
Welcomepleaseselectyour language! English
Bienvenue!Veuillezchoisir une langue. Francais
Willkommen,WahlenSiebitte lhre Sprache aus! Deutsch
Benvenuti,Selezionatelavostra lingua! Italiano
Bienvenido,seleccioneunidioma Espanol
Hosgeldiniz,lutfen dil secimini yapiniz! Turkce
Dobrodosli,izberitevasjezik! Slovenski
Valkommen,valjdittsprak! Svenska
Udvozoljuk,kerjukvalasszaki a nyelvet! Magyar
Bem-vendo,favorselectionarseu idioma Portugues
Tervetuloa,valitsekielesi! Suomi
SelectLanguage SetLanguage
OK
Firsttimeinstallation
Welcome!
Country
SearchType
TeletextLanguage
ScanEncryptedChannels
UK
Digitalonly
West
Yes
< >
SelectLanguage Startsearch
OK
Chooseyourcountry OK
Pleaseensureyouraerial is plugged in before tuning in your TV
IftheTVis to be used in a store, please select the Store Mode. For domestic use,
HomeModeis recommended.
StoreModeHomeMode
Doyouwant tostar t an automatic
channel
NoYes
Automaticchannelscan (Retune)
Cambs&Beds: BBCTWO HD
Cambs&Beds: Channel 4 HD
Cambs&Beds: BBC ONE HD
Cambs&Beds: ITV HD
Cambs&Beds: BBCTHREE HD
Cambs&Beds: CBBC HD
Pleasewait.Thiswill take a few minutes. Scanning digital channels: UHF 22
ChannelsFound: 6
Cancelscan
MENU
Automaticchannelscan (Retune)
Cambs&Beds: BBCTWO HD
Cambs&Beds: Channel 4 HD
Cambs&Beds: BBC ONE HD
Cambs&Beds: ITV HD
Cambs&Beds: BBCTHREE HD
Cambs&Beds: CBBC HD
Pleasewait.Thiswill take a few minutes. Scanning digital channels: UHF 22
ChannelsFound: 6
Cancelscan
MENU
Country
Primaryregion
Secondaryregion
Tertiaryregion
Chooseregion
UK
Any
Any
Any
OK
Multipleregionalvariantshave been detected.
Pleasechooseyour preferredregion.
EditChannelList
1.BBCONE Lon
2.BBCTWO
3.ITV
4.Channel4
5.Channel5
6.ITV2
7.BBCTHREE
9.BBCFOUR
10.ITV3
Cancelscan
MENU
DTV TV
DTV TV
DTV TV
DTV TV
DTV TV
DTV TV
DTV TV
DTV TV
DTV TV
OK Move Delete Editname Lock
Function
Back
RET.BACK
Navigate
Jump
0....9 P+
OK
P-
Filter
PageUP/DOWN
Watch
LT-32C345_46AQSG.indd 1 23/09/2014 16:22
SOURCE
TV TV Stand
LT-32C345_46A_IB.indd 7 25/09/2014 11:26

2
8
Preparation
Installing / Removing the Base Stand
Remove the stand assembly before mounting the TV onto the wall.
The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that
no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert
pressure on the front of the TV at any time because the screen could crack.
• Please read this instruction manual carefully while setting up your TV.
• If you require additional assistance please call our UK Call Centre on 0344 561 1234. Our UK Customer Contact Centre is
open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
1. Press the button in the middle of the stand neck and gently pull
the stand away from the TV.
1. Ensure the TV is switched off and not connected to the mains power supply.
2. Lay the TV down on a flat surface ideally on the edge of a table so the base of the TV slightly overhangs the edge of the table,
with the back side facing up. Please make sure a soft cushioned material (such as a dry bath towel or thick piece of foam) is
placed beneath the screen.
3. Slide the stand under the lip, the neck will fit snugly over the screw holes. Then screw the stand to the TV using the 4 screws
supplied.
Slide under
the lip
Table Cushioned
material
Mounting the TV to a Wall
2. This TV is designed to be wall-mounted with
a standard 200 mm x 100 mm mounting kit
(sold separately) designed for flat-panel TVs.
Mount this TV according to the instructions
included in the mounting kit. Due to space
restrictions, we recommend that you make all
connections before mounting on to
the wall.
x4
200mm
Four mounting holes
(size M4 screw)
100mm
LT-32C345_46A_IB.indd 8 25/09/2014 11:26

2
Preparation
9
Front / Right Side View and Controls
Item Description
1POWER LED Illuminates when the TV is in standby mode. The LED will blink confirming that a timer
recording programme has started in the standby mode.
2 IR (Infrared Receiver) Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 Disc Slot Insert the disc with the label side facing the rear of the TV. (12 cm discs only. Don't
insert 8 cm discs.)
4 Press to start playback or pause. (DVD mode)
5
Press once to stop playback and leave in resume state. (DVD mode)
Press twice to stop playback completely. (DVD mode)
Press to eject disc. (DVD mode)
1 2
4
3
5
LT-32C345_46A_IB.indd 9 25/09/2014 11:26

2
10
Preparation
Rear View and Sockets
2
3
4
1
5
6
7
8
9
10
Item Description
1 HDMI 1 & 2 Connects to a High-Definition (HD) signal output device, such as a set-top box, blu-ray
disc player or AV receiver.
2 SPDIF COAX audio out (Digital) - Connects to an audio device via a coax cable.
3 VGA/YPbPr
Connects to a computer or other devices with a VGA interface.
The VGA input is also used for component input via a VGA to component cable (not
supplied).
4 SCART (S-Video) Connects to a VCR, DVD Player, or other AV device with a SCART output socket.
Select SCART 1 (S-VIDEO) when connecting to a device using S-VIDEO.
5 ANT Connects to the aerial socket on the wall with the RF coaxial cable.
6 COMMON INTERFACE Allows the insertion of a Common Access Module.
7 USB Allows the insertion of a USB storage device to play video, audio, photo and text files
(USB mode) and record DTV programmes on to a USB storage device.
8 CVBS/AUDIO IN (L/R)
(audio L/R also used for YPbPr and VGA)
Connects to the Composite VIDEO and AUDIO (L/R) output sockets on external video
devices.
9 Connects to the headphones.
10 MULTI FUNCTION SWITCH Switches the TV into standby and on. Selects modes (channel,volume, and source).
SCART
SPDIF
COMMON INTERFACE
USB
5Vdc
Max. 500mA
VGA
ANT.
HDMI 1
HDMI 2
LR
MODE - / I
- +
SCART
SPDIF
COMMON INTERFACE
USB
5Vdc
Max. 500mA
VGA
ANT.
HDMI 1
HDMI 2
LR
MODE - / I
- +
LT-32C345_46A_IB.indd 10 25/09/2014 11:26
