SPECIFICATION
Design & specifications are subject to change without notice.
Items Contents
AV-29JS25 AV-29WX25/G
Dimensions (W ×H ×D) 73.1cm ×62.2cm ×49.45cm 81.2cm ×58.42cm ×51.8cm
Mass 42.5kg
TV RF System B, G, I, D, K, M
Colour System TV Mode
Video Mode
PAL / SECAM / NTSC3.58 / NTSC4.43
PAL / SECAM / NTSC3.58 / NTSC4.43
Stereo System A2 (B/G) / NICAM (B/G, I, D/K) Playback
Teletext system FLOF (Fastext)
WST (World Standard Text)
Receiving Frequency VHF Low
VHF High
UHF
CATV
46.25MHz ~ 140.25MHz (AS0 ~ S6)
147.25MHz ~ 423.25MHz (S7 ~ S36)
431.25MHz ~ 863.25MHz (S37 ~ C57)
Mid : X ~ Z, S1 ~ S10
Super: S11 ~ S20
Hyper: S21 ~ S41
Intermediate
Frequency
VIF 38.0MHz
SIF D/K: 31.5MHz (6.5MHz)
[NICAM: 32.15MHz (5.85MHz)]
I: 32.0MHz (6.0MHz)
[NICAM: 31.45MHz (6.55MHz)]
B/G: 32.5MHz (5.5MHz)
[A2: 32.26MHz (5.74MHz)]
[NICAM: 32.15MHz (5.85MHz)]
M: 33.5MHz (4.5MHz)
D/K: 31.5MHz (6.5MHz)
I: 32.0MHz (6.0MHz)
B/G: 32.5MHz (5.5MHz)
M: 33.5MHz (4.5MHz)
Colour Sub Carrier Frequency 4.43MHz (PAL), 4.40MHz/4.25MHz (SECAM), 3.58MHz/4.43MHz (NTSC)
Aerial Input Terminal 75Ωunbalanced, coaxial
Power Input AC110V ~ AC240V, 50Hz / 60Hz
Power Consumption 167W (Max.) / 109W (Avg.)
Picture Tube 29-inch, aspect ratio 4:3, flat square face type, tinted
Screen Size Visible size : 67.6cm (Diagonal) / 55.4cm ×41.4cm (H ×V)
High Voltage 32.5kV (Max.) / 31.5kV (Typ.) / 30kV (Min.) (at zero beam current)
Speaker 6.5cm ×13cm, Oval type ×2
Audio Output 10W + 10W
Video / Audio Input
(1/2/3)
S-Video [1] Mini-DIN 4 pin ×1
Y: 1V(p-p), positive (negative sync provided), 75Ω
C: 0.286V(p-p) (Burst signal), 75Ω
Video [1/2/3] 1V(p-p), negative sync, 75Ω, RCA pin jack ×3
Audio [1/2/3] 500mV(rms) (-4dBs ), high impedance, RCA pin jack ×6
Component
Video [2]
RCA pin jack ×3
Y:1V(p-p), positive (negative sync), 75Ω
Cb/Cr:0.7V(p-p), 75Ω
Video / Audio Output Video 1V(p-p), 75Ω, RCA pin jack ×1
Audio 500mV(rms)(-4dBs), Low impedance (400Hz when modulated 100%), RCA pin jack ×2
Headphone 3.5mm stereo mini jack ×1
Remote Control Unit RM-C1286-1H
(AA/R06/UM-3 battery ×2)
All manuals and user guides at all-guides.com

(No.YA281)1-3
SECTION 1
PRECAUTION
1.1 SAFETY PRECAUTIONS
(1) The design of this product contains special hardware,
many circuits and components specially for safety
purposes. For continued protection, no changes should be
made to the original design unless authorized in writing by
the manufacturer. Replacement parts must be identical to
those used in the original circuits. Service should be
performed by qualified personnel only.
(2) Alterations of the design or circuitry of the products should
not be made. Any design alterations or additions will void
the manufacturer's warranty and will further relieve the
manufacturer of responsibility for personal injury or
property damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These
characteristics are often not evident from visual inspection
nor can the protection afforded by them necessarily be
obtained by using replacement components rated for
higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in
the parts list of Service manual. Electrical components
having such features are identified by shading on the
schematics and by ( ) on the parts list in Service
manual. The use of a substitute replacement which does
not have the same safety characteristics as the
recommended replacement part shown in the parts list of
Service manual may cause shock, fire, or other hazards.
(4) Don't short between the LIVE side ground and
ISOLATED (NEUTRAL) side ground or EARTH side
ground when repairing.
Some model's power circuit is partly different in the GND.
The difference of the GND is shown by the LIVE : ( ) side
GND, the ISOLATED (NEUTRAL) : ( ) side GND and
EARTH : ( ) side GND.
Don't short between the LIVE side GND and ISOLATED
(NEUTRAL) side GND or EARTH side GND and never
measure the LIVE side GND and ISOLATED (NEUTRAL)
side GND or EARTH side GND at the same time with a
measuring apparatus (oscilloscope etc.). If above note will
not be kept, a fuse or any parts will be broken.
(5) If any repair has been made to the chassis, it is
recommended that the B1 setting should be checked or
adjusted (See B1 POWER SUPPLY check).
(6) The high voltage applied to the picture tube must conform
with that specified in Service manual. Excessive high
voltage can cause an increase in X-Ray emission, arcing
and possible component damage, therefore operation
under excessive high voltage conditions should be kept to
a minimum, or should be prevented. If severe arcing
occurs, remove the AC power immediately and determine
the cause by visual inspection (incorrect installation,
cracked or melted high voltage harness, poor soldering,
etc.). To maintain the proper minimum level of soft X-Ray
emission, components in the high voltage circuitry
including the picture tube must be the exact replacements
or alternatives approved by the manufacturer of the
complete product.
(7) Do not check high voltage by drawing an arc. Use a high
voltage meter or a high voltage probe with a VTVM.
Discharge the picture tube before attempting meter
connection, by connecting a clip lead to the ground frame
and connecting the other end of the lead through a 10kΩ
2W resistor to the anode button.
(8) When service is required, observe the original lead dress.
Extra precaution should be given to assure correct lead
dress in the high voltage circuit area. Where a short circuit
has occurred, those components that indicate evidence of
overheating should be replaced. Always use the
manufacturer's replacement components.
(9) Isolation Check (Safety for Electrical Shock Hazard)
After re-assembling the product, always perform an
isolation check on the exposed metal parts of the cabinet
(antenna terminals, video/audio input and output terminals,
Control knobs, metal cabinet, screw heads, earphone jack,
control shafts, etc.) to be sure the product is safe to operate
without danger of electrical shock.
a) Dielectric Strength Test
The isolation between the AC primary circuit and all metal
parts exposed to the user, particularly any exposed metal
part having a return path to the chassis should withstand a
voltage of 3000V AC (r.m.s.) for a period of one second. (.
. . . Withstand a voltage of 1100V AC (r.m.s.) to an
appliance rated up to 120V, and 3000V AC (r.m.s.) to an
appliance rated 200V or more, for a period of one second.)
This method of test requires a test equipment not generally
found in the service trade.
b) Leakage Current Check
Plug the AC line cord directly into the AC outlet (do not use
a line isolation transformer during this check.). Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal part of the cabinet, particularly
any exposed metal part having a return path to the chassis,
to a known good earth ground (water pipe, etc.). Any
leakage current must not exceed 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.2mA AC
(r.m.s.).
Alternate Check Method
Plug the AC line cord directly into the AC outlet (do not
use a line isolation transformer during this check.). Use
an AC voltmeter having 1000Ωper volt or more
sensitivity in the following manner. Connect a 1500Ω
10W resistor paralleled by a 0.15µF AC-type capacitor
between an exposed metal part and a known good earth
ground (water pipe, etc.). Measure the AC voltage
across the resistor with the AC voltmeter. Move the
resistor connection to each exposed metal part,
particularly any exposed metal part having a return path
to the chassis, and measure the AC voltage across the
resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Any voltage measured must
not exceed 0.75V AC (r.m.s.). This corresponds to
0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.3V AC
(r.m.s.). This corresponds to 0.2mA AC (r.m.s.).
AC VOLTMETER
(HAVING 1000 /V,
OR MORE SENSITIVITY)
PLACE THIS PROBE
ON EACH EXPOSED
METAL PART
1500 10W
0.15 F AC-TYPE
GOOD EARTH GROUND
All manuals and user guides at all-guides.com

1-4 (No.YA281)
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 FEATURES
• New chassis design enables use of an interactive on-screen control.
• Pure flat CRT produces fine textured picture in every detail.
• Wide range voltage (110V ~ 240V) for AC power input.
• With AUDIO/VIDEO/S-VIDEO/COMPONENT input terminals.
•I
2C bus control utilizes single chip ICs.
• By means of AUTO PROGRAM, the TV stations can be selected automatically and the TV channels can also be rearranged
automatically.
• Built-in DIGITAL ECO MODE (ECONOMY, ECOLOGY).
In accordance with the brightness in a room, the brightness and/or contrast of the picture can be adjusted automatically to make the
optimum picture which is easy on the eye.
• Built-in OFF TIMER & RETURN +.
2.2 MAIN DIFFERENCE LIST
Items AV-29JS25 AV-29WX25/G
STEREO SYSTEM A2 / NICAM Playback
All manuals and user guides at all-guides.com

(No.YA281)1-5
2.3 MAIN CPU [MAIN PWB : IC701] PIN FUNCTION
Pin
No. Pin name I/O Function
1VssP2 -GND
2 VssC4 - GND
3 V1.8C4 I 1.8V (Digital)
4 V3.3A3 I 3.3V
5 VrefP_Sdac I 3.3V (Positive)
6 VrefN_Sdac - GND
7 VrefP_Sdac I 3.3V (Negative)
8 VrefN_Sdac - GND
9 VrefP_Sdac I 3.3V (Positive)
10 XtalIn I 24.576MHz for system clock
11 XtalOut O 24.576MHz for system clock
12 VssA1 - GND
13 NECK I V-guard input/ I/O switch
14 CONT I 1.8V regulator control
15 V5P1 I +5V
16 Ph2 - Phase-2 filter
17 Ph1 - Phase-1 filter
18 Gnd1 - GND
19 SecPll - SECAM PLL decoupling
20 Dec8G - Bandgap decoupling
21 EW O East-West drive output
22 VDRB- O Vertical drive B output
23 VDRA+ O Vertical drive A output
24 Vif1 I Video IF input 1
25 Vif2 I Video IF input 2
26 Vsc - Vertical sawtooth capacitor
27 Iref I Reference current input
28 GndIF - GND
29 Sif1 I Sound IF input 1
30 Sif2 I Sound IF input 2
31 AGC O Tuner AGC output
32 EHT I EHT/overvoltage protection input
33 Ssif/RefIn/Avl/RefOut O
Automatic Volume Levelling/ sound IF input /
subcarrier reference output / external reference
signal input for I signalmixer for DVB operation
34 L3 I Audio-L3 input (left signal)
35 R3 I Audio-R3 input (right signal)
36 L-OUT O Audio L output
37 R-OUT O Audio R output
38 DecsDem - Decoupling sound demodulator
39
QssO/AmO/AudeEm O QSS intercarrier output / AM output /
deemphasis / (front-end audio out)
40 Gnd2 - GND
41 PllIf - IF-PLL loop filter
42 SifAgc - AGC sound IF
43 IfVo/FmRo/DvbO O Not used
44 NC O Not used
45 V8AudioSwitches I 8V
46 AgcSsif - AGC capacitor second sound IF
47 V5P2 I 5V
48 V-OUT O Video output
49 L1 I Audio-L1 input
50 R1 I Audio-R1 input
51 V3 I Video V3 input
52 C4 I Not used
53 Audio2InL I Not used
54 Audio2InR I Not used
55 V2/Y I Video V2 input
56 L2 I Audio L2 input (Left signal)
57 R2 I Audio R2 input (right signal)
58 Y3/Cvbs I S-Video Y1 input
59 C1 I S-Video C1 input
60 AudioLsL O Audio L output for audio power amplifier
61 AudioLsR O Audio R output for audio power amplifier
62 HP-L O Not used
63 HP-R O Not used
64 CVBSO/PIP O CVBS / PIP output
65 SVM O Not used
66 FbiSo I Flyback input/sandcastle output
67 Hout O Horizontal output
68 VssComb - GND
69 V5Comb I 5V
70 Vin/R2/Pr I PIP R input
71 Uin/B2/Pb I PIP B input
72 Yin/G2/Y I PIP G input
73 Ysync I Not used
74 Yout O Not used
75 Uout/INSSW2 I YUV insertion input
76 NC O Not used
77 INSSW3 I YUV insertion input
78 R3/Pr I Component PR input (Video-2)
79 G3/Y I Component Y input (Video-2)
80 B3/Pb I Component PB input (Video-2)
81 Gnd3 - GND
82 V5P3 I 5V
83 BCL I Beam current limiter input
84 BLKIN I Black current input
85 Rout O R output
86 Gout O G output
87 Bout O B output
88 V3.3A1 I 3.3V
89 RefAdN - GND
90 V3.3RefAdP I 3.3V (Positive)
91 RefAd I 3.3/2V
92 GndA - GND
93 V1.8A I 1.8V
94 V3.3A2 I 3.3V
95 VssADC - GND
96 V1.8ADC I 1.8V
97 REMOTE I Remote control
98 PW_LED I POWER LED control
99 PW_LED I POWER LED control
100 V1.8C2 I 1.8V
101 VssC2 - GND
102 TIMER - Not used
103 TIMER - Not used
104 VER_PROTECT O X-ray protect
105 S_REDUCE O Sound control
106 P00/I2SDI1 O Not used
107 POWER O SUB POWER control
108 SCL1 I I2C bus clock
109 SDA1 I/O I2C bus data
110 V3.3P I 3.3V
111 ROTATION O Rotation
112 3.58/OTHER O NTSC 3.58 detection
113 A_MUTE O Audio muting
114 4.5/OTHER O NTSC 4.43 detection
115 PROT I Protect
116 ECO_IN I ECO sensor level detection
117 V1.8C1 I 1.8V (Digital)
118 DecV1V8 I 1.8V
119 KEY_IN I Key scan data
120 VDO-DET I Video DET input
121 VSSC1+P1 - Digital GND
122 S_V_DET I S-Video DET input
123 P25/PWM4 O GTVA_reset
124 V1.8C3 I 1.8V (Digital)
125 VssC3 - GND
126 P12/Int2 I External interrupt
127 SDA0 I/O I2C bus data (for memory)
128 SCL0 I I2C bus clock (for memory)
Pin
No. Pin name I/O Function
All manuals and user guides at all-guides.com

1-6 (No.YA281)
SECTION 3
DISASSEMBLY
3.1 DISASSEMBLY PROCEDURE [AV-29JS25]
3.1.1 REMOVING THE REAR COVER
• Unplug the power cord.
(1) Remove the 16 screws [A] as shown in Fig.1.
(2) Withdraw the REAR COVER toward you.
CAUTION:
When reinstalling the rear cover, carefully push it inward after
inserting the MAIN PWB into the REAR COVER groove.
3.1.2 REMOVING THE CHASSIS (CHASSIS BASE AND
CONTROL BASE)
• Remove the REAR COVER.
(1) Slightly raise the both sides of the CHASSIS by hand and
remove the 2 claws [B] under the CHASSIS from the front
cabinet as shown in Fig.1.
(2) Withdraw the CHASSIS backward.
(If necessary, take off the wire clamp, connectors etc.)
NOTE:
When conducting a check with power supplied, be sure to
confirm that the CRT earth wire is connected to the CRT
SOCKET PWB and the MAIN PWB.
3.1.3 REMOVING THE AV TERMINAL BOARD
• Remove the REAR COVER.
(1) Remove the 4 screws [C] as shown in Fig.1.
(2) When you pull out the AV TERMINAL BOARD in the
direction of arrow [D] as shown in Fig.1, it can be removed.
3.1.4 REMOVING THE CONTROL BASE
• Remove the REAR COVER.
• Remove the CHASSIS.
(1) While pushing down the 2 claws [E] as shown in Fig. 2 and
pull out the CONTROL BASE in the direction of arrow [F]
as shown in Fig. 2, the control base can be removed.
(If necessary, take off the wire, connectors etc.)
3.1.5 REMOVING THE SPEAKER
• Remove the REAR COVER.
(1) Remove the 2 screws [G], and remove the SPEAKER
HOLDER.
(2) Remove the 4 screws [H] as shown in Fig.1.
(3) Withdraw the SPEAKER backward.
(4) Follow the same steps when removing the other hand
SPEAKER.
3.1.6 CHECKING THE MAIN PW BOARD
• To check the back side of the MAIN PWB.
(1) Pull out the CHASSIS and CONTROL BASE. (Refer to the
procedure described in REMOVING THE CHASSIS)
(2) Put the CHASSIS in upright position with the MAIN PWB's
solderside faced to the right. The FBT must be positioned
on top. (Viewed from the rear)
(3) Put the CONTROL PWBs in an appropriate position, taking
care not giving tension to the ribbon cables that connect to
the MAIN PWB.
CAUTIONS:
• Use insulating materials, if necessary, to avoid possible
electrical contacts between PWBs and expose terminals,
etc.
• Before turning on power, make sure that the CRT earth wire
and other connectors are properly connected.
• When repairing, connect the DEG. COIL to the DEG.
connector on the MAIN PWB.
3.1.7 WIRE CLAMPING AND CABLE TYING
(1) Be sure to clamp the wire.
(2) Never remove the cable tie used for tying the wires
together.
Should it be inadvertently removed, be sure to tie the wires
with a new cable tie.
All manuals and user guides at all-guides.com
all-guides.com

(No.YA281)1-7
Fig.1
A
REAR COVER
SPEAKER H
SPEAKER HOLDER
GAV TERMINAL
BOARD
C
SPEAKER
H
FRONT PWB
CONTROL BASE
G
SPEAKER
HOLDER
CHASSIS BASE
MAIN PWB
D
FBT
CLAW B
CLAW B
(under side)
(under side)
CHASSIS
BASE
CONTROL BASE
[FRONT SIDE]
E
F
Fig.2
Fig.2
(⋅4)
(⋅2)
(⋅2)
(⋅2) (⋅2)
(⋅16)
CRT SOCKET PWB
All manuals and user guides at all-guides.com

1-8 (No.YA281)
3.2 DISASSEMBLY PROCEDURE [AV-29WX25/G]
3.2.1 REMOVING THE REAR COVER
• Unplug the power cord.
(1) Remove the 16 screws [A] as shown in Fig.3.
(2) Withdraw the REAR COVER toward you.
CAUTION:
When reinstalling the rear cover, carefully push it inward after
inserting the MAIN PWB into the REAR COVER groove.
3.2.2 REMOVING THE CHASSIS (CHASSIS BASE AND
CONTROL BASE)
• Remove the REAR COVER.
(1) Slightly raise the both sides of the CHASSIS by hand and
remove the 2 claws [B] under the CHASSIS from the front
cabinet as shown in Fig.3.
(2) Withdraw the CHASSIS backward.
(If necessary, take off the wire clamp, connectors etc.)
NOTE:
When conducting a check with power supplied, be sure to
confirm that the CRT earth wire is connected to the CRT
SOCKET PWB and the MAIN PWB.
3.2.3 REMOVING THE AV TERMINAL BOARD
• Remove the REAR COVER.
(1) Remove the 4 screws [C] as shown in Fig.3.
(2) When you pull out the AV TERMINAL BOARD in the
direction of arrow [D] as shown in Fig.3, it can be removed.
3.2.4 REMOVING THE CONTROL BASE
• Remove the REAR COVER.
• Remove the CHASSIS.
(1) While pushing down the 2 claws [E] as shown in Fig. 4 and
pull out the CONTROL BASE in the direction of arrow [F]
as shown in Fig. 4, the control base can be removed.
(If necessary, take off the wire, connectors etc.)
3.2.5 REMOVING THE SPEAKER
• Remove the REAR COVER.
(1) Remove the 2 screws [G] as shown in Fig.3.
(2) Withdraw the SPEAKER backward.
(3) Follow the same steps when removing the other hand
SPEAKER.
3.2.6 CHECKING THE MAIN PW BOARD
• To check the back side of the MAIN PWB.
(1) Pull out the CHASSIS and CONTROL BASE. (Refer to the
procedure described in REMOVING THE CHASSIS)
(2) Put the CHASSIS in upright position with the MAIN PWB's
solderside faced to the right. The FBT must be positioned
on top. (Viewed from the rear)
(3) Put the CONTROL PWBs in an appropriate position, taking
care not giving tension to the ribbon cables that connect to
the MAIN PWB.
CAUTIONS:
• Use insulating materials, if necessary, to avoid possible
electrical contacts between PWBs and expose terminals,
etc.
• Before turning on power, make sure that the CRT earth wire
and other connectors are properly connected.
• When repairing, connect the DEG. COIL to the DEG.
connector on the MAIN PWB.
3.2.7 WIRE CLAMPING AND CABLE TYING
(1) Be sure to clamp the wire.
(2) Never remove the cable tie used for tying the wires
together.
Should it be inadvertently removed, be sure to tie the wires
with a new cable tie.
All manuals and user guides at all-guides.com

(No.YA281)1-9
Fig.3
CRT
SOCKET PWB
FRONT CONTROL
PWB (1/2)
FRONT CONTROL PWB (2/2)
MAIN PWB
FBT
CHASSIS
BASE
CONTROL BASE
(X4)
(X16)
A
PICTURE TUBE
D
C
AV TERMINAL
BOARD
FRONT CABINET
CHASSIS
BASE
CONTROL BASE
[FRONT SIDE]
E
F
(X2)
G
SPEAKER
(X2)
G
SPEAKER
Fig.2
Fig.4
CLAW B
CLAW B
(under side)
(under side)
REAR COVER
All manuals and user guides at all-guides.com

1-10 (No.YA281)
3.3 REPLACEMENT OF MEMORY IC
3.3.1 MEMORY IC
This TV uses the following memory IC.
Memory IC: IC702 on MAIN PWB
The memory IC memorizes data for correctly operating the video
and deflection circuits. When replacing the memory IC, be sure
to use the same type IC written with the initial values of data. In
other words, use the specific IC listed in "PRINTED WIRING
BOARD PARTS LIST". For its mounting location, refer to
"ADJUSTMENT LOCATIONS".
3.3.2 PROCEDURE FOR REPLACING MEMORY IC
1. Power off
Switch the power off and unplug the power cord from the wall
outlet.
2. Replacing the memory IC
Replace the memory IC with new one. Be sure to use the
memory IC written with the initial data values.
3. Power on
Plug the power cord into the wall outlet and switch the power on.
4. Check and setting of SYSTEM CONSTANT SET:
(1) Press the [DISPLAY] key and the [PICTURE MODE] key
on the remote control unit simultaneously.
The SERVICE MENU screen will be displayed.(See
Fig.1.)
(2) In the SERVICE MENU, press the [DISPLAY] key and
[PICTURE MODE] key simultaneously. Then, the
SYSTEM CONSTANT SET screen will be
displayed.(See Fig.2.)
(3) Check whether the setting values of the SYSTEM
CONSTANT SET are the same as those indicated in
Table 1.
If the value is different, select the setting item with the
MENU [] / [] key, and set the correct value with the
MENU [] / [] key.
(4) Press the [DISPLAY] key twice to return to the normal
screen.
5. Receive channel setting
Refer to the OPERATING INSTRUCTIONS and set the
receive channels (channels preset).
6. User setting
Check the user setting values in Table 2 and Table 3. If setting
value is different, set the correct value.
For setting, refer to the OPERATING INSTRUCTIONS.
7. Setting of SERVICE MENU
Verify the setting for each setting item in the SERVICE
MENU.(See Table 4.) If readjustment is necessary, perform
adjustment referring to "ADJUSTMENTS PROCEDURE".
Fig.1
Fig.2
EXIT
MENU
MENU
MENU
DISPLAY / BACK
MENU
MODE
NAME OF REMOTE CONTROL KEYS
1. IF
3. AUDIO
5. VSM W/B
7. PLUG & PLAY (ON)
2. V/C
4. DEF
6. S TATUS
SERVICE MENU
1-7 : SELECT DISPLAY : EXIT
SERVICE MENU
******* **** ***** *****
**** **** *** ***
SYSTEM CONSTANT-1
: SEL  : OPE
COMB
TILT
: MULTI
YES
YES
TEXT PAT
SUPER BASS NO
LANGUAGE ERCMI
SYSTEM CONSTANT SET 1
SYSTEM
DISP : EXIT
SYSTEM CONSTANT-2
: SEL  : OPE
BLUE BACK MUTE
STEREO
NO
ECO SENSOR YES
COLOUR AUTO NO
BILINGUAL NO
SYSTEM CONSTANT SET 2
SOUND
DISP : EXIT
SYSTEM CONSTANT-3
: SEL  : OPE
YES
SYSTEM CONSTANT SET 3
SURROUND
NOPICTURE BOOSTER
YESCOMPONENT
NOPIP
YESS INPUT
DISP : EXIT
All manuals and user guides at all-guides.com

(No.YA281)1-11
3.3.3 FACTORY SETTING VALUE
SETTING OF SYSTEM CONSTANT SET
Table 1
SYSTEM
COMB
TILT
SUPER BASS
TEXT
LANGUAGE
SOUND
BILINGUAL
BLUE BACK MUTE
COLOUR AUTO
ECO SENSOR
SURROUND
PICTURE BOOSTER
COMPONENT
PIP
S INPUT
Setting item Setting content
Setting value
MULTI
YES
YES
NO
PAT
E/R/C/M/I
---
STEREO
NO
NO
NO
YES
YES
NO
YES
NO
YES
---
E/R/A/P/F
PB
YES
AV-29JS25 AV-29WX25/G
MULTI TRIPLE PAL THAI
YES NO
YES NO
YES NO
SINGLE NO PAT
STEREO PB MONO
E/R/A/P/F
E/R/C/M/I E/C
YES NO
YES NO
YES NO
YES NO
YES NO
YES NO
YES NO
YES NO
YES NO
All manuals and user guides at all-guides.com
all-guides.com

1-12 (No.YA281)
SETTING OF BASIC FUNCTIONS
Table 2
SETTING OF MENU SCREEN
Table 3
SERVICE MENU SETTING ITEMS
Table 4
Setting item Setting value
POWER Off
SUB POWER On
VOLUME 15
INPUT TV
COLOR SYSTEM PAL
SOUND SYSTEM B/G
PICTURE MODE (VSM) BRIGHT
CINEMA SURROUND (RF) OFF
OFF TIMER OFF
CHANNEL POSITION PR01
Setting item Setting value
VNR AUTO
COMPRESS (16:9) OFF
CHILD LOCK OFF
BLUE BACK ON
VIDEO-2 SET COMPONENT
AUTO PROGRAM
Refer to OPERATING INSTRUCTIONS
EDIT / MANUAL Refer to OPERATING INSTRUCTIONS
LANGUAGE ENG
TEXT LANGUAGE GROUP-1 [AV-29JS25]
GROUP-4 [AV-29WX25/G]
WHITE BALANCE (RF) COOL
BALANCE Centre
SOUND MODE (RF) MUSIC
AI VOLUME OFF
FAVORITE CH RED PR01
FAVORITE CH GREEN PR02
FAVORITE CH YELLOW PR03
FAVORITE CH BLUE PR04
AI ECO SENSOR OFF
AUTO SIGNAL DETECT ON
DVD PICTURE MODE OFF
TINT COLOR Centre
WHITE BALANCE (DVD) COOL
SOUND MODE (DVD) MUSIC
CINEMA SURROUND (DVD) OFF
Setting item Setting value
1. IF 1. VCO
2. DELAY POINT
2. V/C 1. SCREEN
2. CUTOFF(B/G)
3. WDR(R/G/B)
4. BRIGHT(TV/VDO 1/2/3)
5. CONT(TV/VDO 1/2/3/TV 16:9/VDO 16:9)
6. COLOUR(TV/VDO1/2/3/DVD)
7. TINT(TV/VDO 1/2/3)
8. SHARP [Do not adjust]
9. Y DELAY [Do not adjust]
10. TINT DVD [Do not adjust]
11. AMP T. SHARP
12. TWIN CONT.
3. AUDIO
[Do not adjust]
1. DCXO ADJ
2. NICAM lower ERRLIM
3. NICAM upper ERRLIM
4. A2 ID THR
5. MENU EQUALIZER
4. DEF 1. V-SHIFT
2. V-SLOPE
3. V-SIZE
4. H-CENT
5. H-SIZE
6. TRAPEZ
7. EW-PIN
8. COR-UP
9. COR-LO
10. ANGLE
11. BOW
12. V-S.CR
13. V-LIN
14. V-ZOOM
15. V-SCROLL
5. VSM W/B
(BRIGHT/STANDARD/SOFT)
(COOL/WARM/NORMAL)
1. BRIGHT
2. CONT
3. COLOUR
4. SHARP
5. HUE
1. R DRIVE
2. G DRIVE
3. B DRIVE
6. STATUS
[Display only]
7. PLUG & PLAY(ON)
[Display only]
All manuals and user guides at all-guides.com

(No.YA281)1-13
3.4 REPLACEMENT OF CHIP COMPONENT
3.4.1 CAUTIONS
(1) Avoid heating for more than 3 seconds.
(2) Do not rub the electrodes and the resist parts of the pattern.
(3) When removing a chip part, melt the solder adequately.
(4) Do not reuse a chip part after removing it.
3.4.2 SOLDERING IRON
(1) Use a high insulation soldering iron with a thin pointed end of it.
(2) A 30w soldering iron is recommended for easily removing parts.
3.4.3 REPLACEMENT STEPS
1. How to remove Chip parts
[Resistors, capacitors, etc.]
(1) As shown in the figure, push the part with tweezers and
alternately melt the solder at each end.
(2) Shift with the tweezers and remove the chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply extra solder to each lead.
(2) As shown in the figure, push the part with tweezers and
alternately melt the solder at each lead. Shift and remove
the chip part.
NOTE :
After removing the part, remove remaining solder from the
pattern.
2. How to install Chip parts
[Resistors, capacitors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder. Then heat and melt the solder at both ends of the
chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder.
(3) First solder lead Aas indicated in the figure.
(4) Then solder leads Band C.
SOLDER SOLDER
A
B
C
A
B
C
All manuals and user guides at all-guides.com

1-14 (No.YA281)
SECTION 4
ADJUSTMENT
4.1 ADJUSTMENT PREPARATION
(1) You can make the necessary adjustments for this unit with either the remote control unit or with the adjustment
equipment and parts as given below.
(2) Adjustment with the remote control unit is made on the basis of the initial setting values, however, the new setting
values used for setting the screen to its optimum condition may differ from the initial settings.
(3) Make sure that AC power is turned on correctly.
(4) Turn on the power for the set and test equipment before use, and start the adjustment procedures after waiting at least 30
minutes.
(5) Unless otherwise specified, prepare the most suitable reception or input signal for adjustment.
(6) Never touch any adjustment parts, which are not specified in the list for this variable resistors, transformers, trimmer capacitors,
etc.
4.2 PRESETTING BEFORE ADJUSTMENT
Unless otherwise specified in the adjustment instructions, preset the following functions with the remote control unit.
User mode setting position
4.3 MEASURING INSTRUMENT AND FIXTURES
(1) DC voltmeter (or Digital voltmeter)
(2) Oscilloscope
(3) Signal generator (Pattern generator) [PAL/SECAM/NTSC]
(4) Remote control unit
4.4 ADJUSTMENT ITEMS
B1 VOLTAGE
FOCUS ADJUSTMENT
IF CIRCUIT ADJUSTMENTS
• IF VCO adjustment
• DELAY POINT (AGC TAKE-OVER) adjustment
VIDEO CIRCUIT ADJUSTMENTS
• WHITE BALANCE (Low light) adjustment
• WHITE BALANCE (High light) adjustment
• SUB BRIGHT adjustment
• SUB CONTRAST adjustment
• SUB COLOUR 1 adjustment
• SUB COLOUR 2 adjustment
• SUB TINT 1 adjustment
• SUB TINT 2 adjustment
AUDIO SETTING
DEFLECTION CIRCUIT ADJUSTMENTS
• V.SLOPE adjustment
• V.POSITION adjustment
• V.HEIGHT adjustment
• H.POSITION adjustment
• H.WIDTH adjustment
• SIDE PIN adjustment
• TRAPEZIUM adjustment
• V. LINEARITY adjustment
• CORNER adjustment
• H. PARALLEL adjustment
• H.BOW adjustment
VSM PRESET SETTING
PURITY AND CONVERGENCE ADJUSTMENTS
• PURITY adjustment
• STATIC CONVERGENCE adjustment
• DYNAMIC CONVERGENCE adjustment
Setting item Setting value
PICTURE MODE (VSM) BRIGHT
VNR OFF
AI ECO SENSOR OFF
BALANCE Centre
CINEMA SURROUND OFF
COMPRESS (16:9) OFF
All manuals and user guides at all-guides.com

(No.YA281)1-15
4.5 ADJUSTMENT LOCATIONS
E1
TOP
CRT EARTH
(BRAIDED ASS'Y)
CRT EARTH
(BRAIDED ASS'Y)
U
TP-47B
TP-47G
TP-47R
E2
HV
UPPER : FOCUS
IC702
CRT SOCKET PWB ASS’Y (SOLDER SIDE)
T
18
16
FRONT
FRONT
FRONT
POWER
CORD
SPEAKER (L)
DEG COIL
HVT
MAIN PWB ASS’Y
FRONT CONTROL PWB ASS’Y (1/2) FRONT CONTROL PWB ASS’Y (2/2)
J804 J803 J802
S804
S805
S806 S802
S803S801 J801
CN00S
CN002
R
CN001
CNDEG
PW
W
S901
1
8
16
LOWER : SCREEN
61
16
U
TU001
J804J801J805 J802 J803
IC701
CN001
CN00W CN002
T
TP-E
SPEAKER (R)
ROTATION COIL
DEF YOKE
CN00X
1. B1
2. NC
3. X-RAY2
4. X-RAY1
5. GND
CN00C
1. 5V
2. SCL0
3. SDA0
4. SCL1
5. SDA1
6. GND
GND 5V
15
GND
B1
All manuals and user guides at all-guides.com

1-16 (No.YA281)
4.6 BASIC OPERATION IN SERVICE MENU
Operate the SERVICE MENU with the remote control unit.
4.6.1 SERVICE MENU ITEMS
With the SERVICE MENU, various settings (adjustments) can be made, and they are broadly classified in the following items of settings:
4.6.2 BASIC OPERATION IN SERVICE MENU
1. HOW TO ENTER SERVICE MENU
Press the [DISPLAY] key and the [PICTURE MODE] key on the remote control unit simultaneously.
The SERVICE MENU screen will be displayed. (See Fig. 1 on the next page.)
2. SELECTION OF SUB MENU SCREEN
Press one of the keys 1 to 6 on the remote control unit, and select the SUB MENU SCREEN from the SERVICE MENU. (See Fig. 1 on the next page.)
SERVICE MENU →SUB MENU
3. METHOD OF SETTING
NOTES:
• Once the setting values are set, they are memorized automatically.
• It must not be adjusted without inputting a signal.
(1) 1. IF
[1.VCO ] : Under normal conditions, no adjustment is required.
[2.DELAY POINT ]
(2) 2. V/C, 3. AUDIO and 4. DEF
(3) 5. VSM W/B
(4) 6. STATUS
This is for display only.
(5) 7. PLUG & PLAY (ON)
This is not used for service.
4. Release of SERVICE MENU
After completing the setting, return to the SERVICE MENU by pressing the [DISPLAY] key, then again press the [DISPLAY] key to
return to the normal screen.
1. IF For entering/adjusting the setting values (adjustment values) of the IF circuit.
2. V/C For entering/adjusting the setting values (adjustment values) of the VIDEO circuit.
3. AUDIO For entering/adjusting the setting values (adjustment values) of the AUDIO circuit.
4. DEF For entering/adjusting the setting values (adjustment values) of the DEFLECTION circuit.
5. VSM W/B For setting the values of STANDARD, SOFT, BRIGHT and COOL, NORMAL, WARM.
6. STATUS This is not used for service.
7. PLUG & PLAY (ON) This is not used for service.
1. IF 5. VSM W/B
2. V/C 6. STATUS
3. AUDIO 7. PLUG & PLAY (ON)
4. DEF
(a) [1] key Select 1. IF.
(b) [1] key Select 1. VCO.
(c) [DISPLAY] key When this is pressed twice, you will return to the SERVICE MENU.
(a) [1] key Select 1. IF.
(b) [2] key Select 2. DELAY POINT.
(c) MENU [] / [] key Adjust the setting value.
(d) [DISPLAY] key When this is pressed twice, you will return to the SERVICE MENU.
(a) [2] ~[4] keys Select one from 2. V/C, 3. AUDIO and 4. DEF
(b) MENU [] / [] key Select setting items.
(c) MENU [] / [] key Adjust the setting values of the setting items.
Use the number keys on the remote control unit for setting the WHITE BALANCE.
For the setting, refer to each item concerned.
(d) [DISPLAY] key When this is pressed, you will return to the SERVICE MENU.
(a) [5] keys Select 5. VSM W/B.
(b) MENU [OK] key Select preset items.
(c) MENU [] / [] key Adjust setting items.
(d) MENU [] / [] key Adjust the setting values of the setting items.
(e) [DISPLAY] key When this is pressed, you will return to the SERVICE MENU.
All manuals and user guides at all-guides.com
all-guides.com

(No.YA281)1-17
4.6.3 SERVICE MENU FLOW CHART
Fig.1
1. IF
SERVICE MENU
1. VCO
2. DELAY POINT
IF SERVICE MENU VCO (CW) *****MHz
TOO HIGH
ABOVE REFERENCE
JUST REFERENCE
BELOW REFERENCE
TOO LOW
DELAY POINT
AGC TAKEOVER **
2. V/C
Setting item
1. SCREEN (READ DATA)
2. CUTOFF (B/G)
3. WDR (R/G/B)
4. BRIGHT (TV/VDO1/2/3)
5. CONT (TV/VDO1/2/3/TV
16:9/VDO16:9)
6. COLOUR (TV/VDO1/2/3/
DVD)
7. TINT (TV/VDO1/2/3)
1. DCXO ADJ
2. NICAM lower ERRLIM
3. NICAM upper ERRLIM
4. A2 ID THR
Setting item
8. SHARP (TV/VDO1/2/3)
9.
Y DELAY (TV/VDO1/2/3
/S-VDO)
10. TINT DVD (DVD)
11. AMP T.SHARP
12. TWIN CONT.
3. AUDIO
PAL
1. SCREEN HBC
WBC
BRI
**
**
**
V/C
000A
0002
0009
5. VSM W/B
1. BRIGHT ***
VSM PRESET BRIGHT
4. DEF
1. V-SHIFT ***
(**)
DEF FULL 50Hz
1. BRIGHT
2. CONT
3. COLOUR
4. SHARP
5.HUE
1. R-DRIVE
2. G-DRIVE
3. B-DRIVE
Setting item
4 : 3 / 16 : 9
1. V-SHIFT
2. V-SLOPE
3. V-SIZE
4. H-CENT
5. H-SIZE
6. TRAPEZ
7. EW-PIN
8. COR-UP
9. COR-LO
10. ANGLE
11. BOW
12. V-S. CR
13. V-LIN
14. V-ZOOM
15. V-SCROLL
Setting item
1. IF
3. AUDIO
5. VSM W/B
7. PLUG & PLAY (ON)
2. V/C
4. DEF
6. STATUS
SERVICE MENU
1-7 : SELECT DISPLAY : EXIT
******* **** ***** *****
**** **** *** ***
6. STATUS
ECO EOF NOL VNR
ADC ECO =
COSMIC STATUS
STATUS 1. DCXO ADJ. = ***
NOT NICAM
AUDIO
*******
*******
*******
*******
**
****
** ** ** ** ** ** ** **
V/C STATUS
MENU EQUALIZER
EQUALIZER RF
Setting value (Hexadecimal)
Setting value
Sereen size
FULL
COMPRESS
USER
SOUND TURBO
THEATER
MUSIC
NEWS
EQUALIZER VIDEO EQUALIZER DVD
USER
SOUND TURBO
THEATER
MUSIC
NEWS
USER
SOUND TURBO
THEATER
MUSIC
NEWS
All manuals and user guides at all-guides.com

1-18 (No.YA281)
4.7 ADJUSTMENT PROCEDURE
4.7.1 B1 VOLTAGE
4.7.2 FOCUS ADJUSTMENT
4.7.3 IF CIRCUIT ADJUSTMENTS
Item Measuring
instrument Test point Adjustment part Description
B1 VOLTAGE
check
Signal
generator
DC voltmeter
B1 (pin 1)
GND (pin 5)
[CN00X
connector in
MAIN PWB]
(1) Receive a PAL black and white signal.
(2) Connect a DC voltmeter between B1 and GND
(between pins 1 and 5 of the connector CN00X).
(3) Make sure that the voltage is DC134.5V ±2V.
Item Measuring
instrument Test point Adjustment part Description
FOCUS
adjustment
Signal
generator
FOCUS VR
[In HVT]
Notes:
• Set PICTURE MODE (VSM) to "BRIGHT".
• The final adjustment of CONVERGENCE must be
done after the FOCUS adjustment. (CONVERGENCE
is affected by the FOCUS adjustment.)
If any aeviation in CONVERGENCE is found, PURITY
must be adjusted to restore the convergence.
(1) Receive a PAL crosshatch signal.
(2) Adjust the FOCUS VR so that the vertical and
horizontal lines will be clear and in fine detail on the
screen.
(3) Make sure that the picture is in focus even when the
screen gets darkened.
Item Measuring
instrument Test point Adjustment part Description
IF VCO
check
Remote
control unit
[1. IF]
1. VCO (CW)
Note:
• Under normal conditions, no adjustment is required.
(1) Receive a PAL broadcast signal.
(2) Select 1. IF from the SERVICE MENU.
(3) Select 1. VCO.
(4)
Check the characters colour of the JUST REFERENCE
displayed to yellow .
(5) Press the [DISPLAY] key three times to return to
normal screen.
DELAY POINT
(AGC
TAKE-OVER)
adjustment
Remote
control unit
[1. IF]
2. DELAY POINT
(1)
Receive a PAL black and white broadcast signal (colour off).
(2) Select 1. IF from the SERVICE MENU.
(3) Select 2. DELAY POINT.
(4) Adjust in order to eliminate any noise or beat from
the image. Any increase above the initial value
produces the noise and any decrease below it
produces the beat.
(5) Press the [DISPLAY] key three times to return to the
normal screen.
(6) Turn to other channels and make sure that there are
no irregularities.
TOO HIGH
ABOVE REFERENCE
JUST REFERENCE
BELOW REFERENCE
TOO LOW
VCO (CW) . MHz
DISPLAY : EXIT
Receiving frequency
YELLOW
Initial setting value
Adjustment item
NTSC 3.58 OTHERS
VHF UHF VHF UHF
2. DELAY POINT
(AGC TAKE-OVER) 33
33 33 33
All manuals and user guides at all-guides.com

(No.YA281)1-19
4.7.4 VIDEO CIRCUIT ADJUSTMENTS
• The setting (adjustment) using the remote control unit is made on the basis of the initial setting values.
• The setting values which adjust the screen to the optimum condition can be different from the initial setting values.
• Do not change the initial setting values of the setting (adjustment) items not listed in "ADJUSTMENT PROCEDURE".
• The initial setting values in parenthesis ( ) are fixed offset values, needing no further adjustment.
[AV-29JS25]
[AV-29WX25/G]
Adjustment item Variable range
Initial setting value
PAL SECAM
NTSC3.58 NTSC4.43
COMPONENT (V-2)
525i 625i
1. SCREEN BRI 0 ~ 63 32 32 32 32 32 32
2. CUTOFF B 0 ~ 63(-32 ~ [phone] (-3) (-3)
G 0 ~ 63(-32 ~ +31) 7 7 7 7 (-5) (-5)
3. WDR R 0 ~ 63(-32 ~ [phone] (0) (0)
G 0 ~ 63(-32 ~ [phone] (0) (0)
B 0 ~ 63(-32 ~ [phone] (0) (0)
4. BRIGHT RF 0 ~ 63 39 39 39 39 --- ---
VIDEO 1(COMPOSITE/S) (-32 ~ +31) (0) (0) (0) (0) --- ---
VIDEO 2(COMPONENT) (-32 ~ +31) (-1) (-1) (-1) (-1) (+0) (+0)
VIDEO 3(COMPOSITE) (-32 ~ +31) (+2) (+2) (+2) (+2) --- ---
5. CONT. RF 0 ~ 63 32 32 32 32 --- ---
VIDEO (-32 ~ +31) (-3) (-3) (-3) (-3) (-6) (-6)
6. COLOUR RF 0 ~ 63(-32 ~ [phone] +1 --- ---
VIDEO (-32 ~ +31) (+2) (+1) (+4) (+1) (+3) (+5)
7. TINT RF 0 ~ 63(-32 ~ +31) --- --- 27 (+3) --- ---
VIDEO (-32 ~ +31) --- --- (+2) (+4) --- ---
8. SHARP RF 0 ~ 63 23 23 23 23 --- ---
VIDEO 0 ~ 63 35 35 35 35 15 15
9. Y DELAY RF 0 ~ 15 12 9 12 4 --- ---
VIDEO 0 ~ 15 11 7 9 8 --- ---
S-VIDEO 0 ~ 15 7 7 7 7 --- ---
10. TINT DVD RF 0 ~ 63(-32 ~ +31) 34 (-7) (+0) (+0) --- ---
VIDEO (-32 ~ +31) (-1) (-7) (+0) (+0) (+3) (-2)
11. AMP T.SHARP RF, VIDEO 0 ~ 63 0 0 0 0 0 0
12. TWIN CONT. TWIN (RF) -15 -15 -15 -15 --- ---
TWIN (VIDEO) --- --- --- --- --- ---
Adjustment item Variable range
Initial setting value
PAL SECAM
NTSC3.58 NTSC4.43
COMPONENT (V-2)
525i 625i
1. SCREEN BRI 0 ~ 63 32 32 32 32 32 32
2. CUTOFF B 0 ~ 63(-32 ~ [phone] (-3) (-3)
G 0 ~ 63(-32 ~ +31) 7 7 7 7 (-5) (-5)
3. WDR R 0 ~ 63(-32 ~ [phone] (0) (0)
G 0 ~ 63(-32 ~ [phone] (0) (0)
B 0 ~ 63(-32 ~ [phone] (0) (0)
4. BRIGHT RF 0 ~ 63 39 39 39 39 --- ---
VIDEO 1(COMPOSITE/S) (-32 ~ +31) (-1) (-1) (-1) (-1) --- ---
VIDEO 2(COMPONENT) (-32 ~ +31) (+1) (+1) (+1) (+1) (-1) (-1)
VIDEO 3(COMPOSITE) (-32 ~ +31) (+1) (+1) (+1) (+1) --- ---
5. CONT. RF 0 ~ 63 32 32 32 32 --- ---
VIDEO (-32 ~ +31) (0) (0) (0) (0) (0) (0)
6. COLOUR RF 0 ~ 63(-32 ~ [phone] +1 --- ---
VIDEO (-32 ~ +31) (+4) (+1) (+2) (+1) (+5) (+5)
7. TINT RF 0 ~ 63(-32 ~ +31) --- --- 27 (+3) --- ---
VIDEO (-32 ~ +31) --- --- (+3) (+4) --- ---
8. SHARP RF 0 ~ 63 23 23 23 23 --- ---
VIDEO 0 ~ 63 35 35 35 35 15 15
9. Y DELAY RF 0 ~ 15 11 9 10 4 --- ---
VIDEO 0 ~ 15 9 8 3 10 --- ---
S-VIDEO 0 ~ 15 7 7 7 7 --- ---
10. TINT DVD RF 0 ~ 63(-32 ~ +31) 34 (-7) (+0) (+0) --- ---
VIDEO (-32 ~ +31) (-3) (-7) (+0) (+0) (+3) (-2)
11. AMP T.SHARP RF, VIDEO 0 ~ 63 0 0 0 0 0 0
12. TWIN CONT. TWIN (RF) -15 -15 -15 -15 --- ---
TWIN (VIDEO) --- --- --- --- --- ---
All manuals and user guides at all-guides.com

1-20 (No.YA281)
Item Measuring
instrument Test point Adjustment part Description
WHITE
BALANCE
(Low light)
adjustment
Signal
generator
Remote
control unit
[2. V/C]
2. CUTOFF (B)
2. CUTOFF (G)
SCREEN VR
[In HVT]
Note:
• Set PICTURE MODE (VSM) to "BRIGHT".
- COMPOSITE WHITE BALANCE -
(1) Receive a PAL black and white signal (colour off).
(2) Select 2. V/C from the SERVICE MENU.
(3) Select 2. CUTOFF (B) and (G).
(4) Set each value to initial setting value with the [4] / [7]
keys and [5] / [8] keys.
(5) Turn the SCREEN VR fully counterclockwise, then
slowly turn it clockwise to where a red, blue or green
colour is faintly visible.
(6) Use the [4] / [7] and [5] / [8] keys to adjust so that
the other 2 colours appear white.
(7) Turn the SCREEN VR to where the single horizontal
line glows faintly.
(8) Press the [DISPLAY] key twice to return to the normal
screen.
- COMPONENT WHITE BALANCE -
(1) Receive a PAL component black and white signal
(colour off).
(2) Select VIDEO-2 SET from the MENU and set
VIDEO-2 SET to COMPONENT.
(3) Adjust COMPONENT WHITE BALANCE in the
same way as "COMPOSITE WHITE BALANCE".
WHITE
BALANCE
(High light)
adjustment
Signal
generator
Remote
control unit
[2. V/C]
3. WDR (R)
3. WDR (G)
3. WDR (B)
Notes:
• Proceed to the following adjustment after having
completed the WHITE BALANCE (Low light) adjustment.
• Set PICTURE MODE (VSM) to "BRIGHT".
(1) Receive a PAL black and white signal (colour off).
(2) Select 2. V/C from the SERVICE MENU.
(3) Select 3. WDR (R), (G) and (B).
(4) Set each value to initial setting value with the [4] to
[9] keys.
(5) Use the [4] to [9] keys to produce a white screen.
(6) Press the [DISPLAY] key twice to return to the normal
screen.
Adjustment
Item
Initial setting valueVariable
range
COMPOSITE COMPONENT
2. CUT OFF B 0 ~ 63 (-32~+31)
0 ~ 63 (-32~+31)
11
G7
(-3)
(-5)
PAL
2. CUTOFF (B)
(G) **
**
(**)
(**)
V/C
G CUTOFF (

)
12 3
4
789
56
B CUTOFF (

)
B CUTOFF (

)
G CUTOFF (

)
REMOTE CONTROL UNIT
0 ~ 63
0 ~ 63
0 ~ 63
Adjustment Item Variable Initial setting
range value
R
3. WDR G
B
32
32
45
G DRIVE (

)
12 3
4
789
56
R DRIVE (

)B DRIVE (

)
B DRIVE (

)
R DRIVE (

)
G DRIVE (

)
REMOTE CONTROL UNIT
PAL
3. WDR (R)
(G) **
**
(**)
(**)
(B) ** (**)
V/C
All manuals and user guides at all-guides.com
