JW Fishers SeaOtter-2 User manual

1
SeaOtter-2
OPERATION MANUAL
JW FISHERS MFG INC
JW FISHERS MFG INC
1953 COUNTY ST.
E. TAUNTON, MA 02718 USA
[phone]; [phone]; FAX [phone]
Email: [email protected] WEB: www.jwfishers.com
rev 61509

2
SeaOtter-2
Remote Operated Vehicle
OPERATION
AND
MAINTENANCE
MANUAL
1953 COUNTY STREET
EAST TAUNTON, MA 02718
JW FISHERS MFG INC

3
TABLE OF CONTENTS
• SeaOtterCAUTIONS ................................................................................................................4
• SeaOtterSPECIFICATIONS ................................................................................................... 5
• SeaOtterCOMPONENTS
SeaOtter .........................................................................................................6
CABLE....................................................................................................................................7
CONTROLBOX.......................................................................................................................8
CONTROLBOXCOVER .........................................................................................................8
CONTROLBOXCONTROLPANEL.........................................................................................9
PS2CONTROLLER ..............................................................................................................15
• CABLINGTHESeaOtter .......................................................................................18
• POWERING UP THE SeaOtter...............................................................................................20
• OUT OF WATER TEST .............................................................................................................20
• INWATER BALANCING THE ROV............................................................................................23
• LAUNCHINGANDRETRIEVINGTHESeaOtter .......................................................... 24
• CONTROLBOXBLOCKDIAGRAM ...........................................................................................25
• ROV BLOCK DIAGRAM ............................................................................................................26
• MAINTENANCE.........................................................................................................................27
• WARRANTY..............................................................................................................................27
• SPARE PARTS KIT.................................................................................................................. 28

4
SeaOtter-2 Cautions
•ALWAYS PLUGTHECONTROLBOXINTOAGROUND FAULTBREAKERFORSAFETY.IF
ANELECTRICALLEAKOCCURSTOTHE WATER,THE GROUND FAULT BREAKER WILL
TRIP.
•NEVER PLUGTHECONTROLBOX POWER INTOANYVOLTAGEOTHERTHAN 120VAC
(NEVER 220 VAC). IF ONLY 220 VAC ISAVAILABLEASTEP DOWNTRANSFORMER IS
NEEDED.
• 120 VAC IS DANGEROUS - DO NOT EXPOSE CONTROLBOX OR ELECTRICALCONNEC-
TIONSTOWATER.
•AVOIDUNNECESSARYROUGHHANDLING.
•PRIORTOLAUNCH,CHECKALLFITTINGS.
•PRIORTOLAUNCH,ANDWITHPOWEROFF,ROTATEALLPROPSONETURNBYHAND.
•PROTECTTHEMONITORANDCONTROLBOXFROMTHEELEMENTS.
• KEEP HANDS AND FINGERS CLEAR OF THE PROPELLERS AT ALL TIMES.
•MAKEELECTRICALCONNECTIONSONLYASSPECIFIEDINTHISMANUAL.DONOT
BYPASSANYELECTRICALSAFETYCIRCUITS (GROUNDFAULT).
•READANDUNDERSTANDTHEMANUALBEFOREMAKINGANYREPAIRSTOTHE
SeaOtter.
•DONOT OPERATE THESeaOtter-2OUTOFTHEWATER,EXCEPTAS PROVIDED INTHIS
MANUAL.
•IFTHE LEAK DETECTORINDICATES ALEAK, REMOVEUNIT FROM THEWATER AS
QUICKLYASPOSSIBLE.
•DONOTLIFTTHEUNITBYITSUMBILICALCABLE,LIFTANDLOWERTHESeaOtter-2BY
MEANS OF THE HANDLE.
• DO NOT BEND THE UMBILICAL CABLE SHARPLY, A SHARP BEND COULD BREAK AN
INTERNALWIREINTHECABLE.
•PLUGCONTROLBOXANDMONITORINTOAGROUNDFAULTOUTLET(ONSHIP).
•BESURETOUNPLUGMONITORFROMCONTROLPANELBEFORECLOSINGCOVER.

5
SPECIFICATIONS
DIMENSIONS/WEIGHTS:
SeaOtter......................................... 23L x 16W x 12H inches............................................ 43 lbs.
Control Box .................................... 19L x 16W x 8.5H inches............................................ 15 lbs.
Cable......................................... .5 inches Dia x 250 to 500 feet.................................. 30/60 lbs.
Monitor (built into case) .............................. 15 inches
PERFORMANCE/DESCRIPTIONS:
Cameras/Lens ..........CCD color cameras/4mm 50 deg wide angle lens, 90 degree pan and tilt,
auto iris.
Monitor.......................10.4 inches, high resolution, ultra bright, color.
Lighting......................Two 50w tungsten halogen (front).
..................................Ultra bright LED ring (rear).
Motors .......................Four DC PM type, reversible, variable speed, proportional controlled, 6+lbs.
thrust each motor, 3 knots.
Operating Depth........500 feet.
Color..........................Yellow/black.
Sealing ......................Five separate housings, O-ring sealed, a leak detector in each housing,
motors use “no maintenance” rotary seals.
Power Req ................120 vac, 5 amps, 600w max.
OPTIONS:
• Up to 500 foot cable • Scan-650 scanning sonar
• Spare parts kit •Attached metal detector (RMD-1)
• DVD recorder • PAL camera and monitor (Europe)
•Manipulator arm • 220vac (Europe)
• On screen display (time, date, heading, depth, GPS)

6
System Components
The SeaOtter-2 ROV contains two color CCD cameras (one front and one rear) with 4mm (wide
angle) lens. The viewing area is 50 degrees. The cameras can be panned and tilted 90 degrees
for a total viewing area of 140 degrees horizontal and vertical. Depending on the amount of light,
the iris will automatically open and close as required. The cameras have a wide range fixed focus
lens. A switch on the control panel selects either front or rear camera, but not both at the same time.
The cameras pan and tilt is controlled by buttons on the PS2 controller.
The SeaOtter-2 has four high performance motors that are variable speed and reversible. The
horizontal and vertical motors are controlled by joysticks on the PS2 controller. Each motor housing
is independently sealed from the main body and each of the five housings contain a leak detector
that informs the operator if any moisture enters the housing.
Front lighting is provided by two 50 watt water cooled halogen bulbs. They are fully adjustable
from 0 to 100 watts of lighting. Rear lighting is provided by a ring of Ultra Bright LEDs that are
operator controlled for on/off.
ROV:
ROV Cable
Control Box
100wof lighting
(variable0-100)
TheSeaOtter-2systemcomescompletewiththeROV,neutrallybuoyantcable,andacontrolbox
withabuilt-incolormonitorandPS2controller.
Max500’ depth
housing
ROV: 23”L x 16”W x 12”H
FourHi performancemotors
Panand Tilt
FrontCamera
Panand Tilt
RearCamera
PS2
controller
System Operation

7
Thetwoskidscontainballastweightsthatareusedtoadjustboththebalanceandbuoyancyofthe
ROVinwater.Whenproperlyadjusted,theROVshouldsitlevelinthewaterandshouldbeslightly
positive,justpositiveenoughsoitdoesnotsink(extraballastweightsareincluded.)
TheROVispressuretestedtoa1,000footdepthpriortoshipment. OperationoftheSeaOtter-2out
of water is not recommended. If the front lights are operated out of the water for more than 10-15
secondsthewatercooledhalogenlightswilloverheatandburnthereflector.Ifthemotorsareoperated
outofthewaterformorethat5-10secondsthemotorsealswilloverheatandexperienceexcessive
wear. Aftercablingupthesystemashortpretestmaybemadeofthelightsandmotors. Thecameras
andrearLEDlightscanorcoursebeoperatedoutofwater.Atalltimescautionisadvisedinhandling
thepropellers.
ROV:
(continued)
100wof lighting
(variable0-100)
Max500’ depth
housing
ROV: 23”L x 16”W x 12”H
FourHi performancemotors
Panand Tilt
FrontCamera
Panand Tilt
RearCamera
Ballast weights inside
Cable:
TheumbilicalcableconnectstheROVtothecontrolbox.Thecableisneutrallybuoyantandhasa
connectoronbothends.Thesystemcomesstandardwitha250footcable.Additionalcablecanbe
ordered up to a total length of 500 feet (do not exceed this total length.) When additional cable is
ordereditcomeswithaconnectoronbothendsandperformsasanextensioncord.Theadditional
cableinstalls betweenthe250footcableandtheROV.
Theumbilicalcableisapproximately.5inchesindiaandcontainsninewires:acoaxforthevideo
signal,twotwistedpairsfortransmittingandreceivingcontrolsignalstotheROV,atwistedpairfor
power to the ROV and a spare twisted pair for options (metal detector, scanning sonar, etc). It is
importantthatthecablebeprotectedagainst damage.

8
Control Box:
TheControlBoxisthenervecenteroftheSeaOtter-2system. The
Control Panel (lower half) contains all the necessary switches and
indicatorstocontrolandmonitortheROV.Theumbilicalcabletothe
ROV isconnectedtothecontrolpanel.Powerand controlsignalsare
passedfromthecontrolpanelthroughthiscabletotheROV.
An off-the-shelf PS2 controller (supplied), plugs into the control
panelandcontrolstheROV’s:lights,motors,andcameramovement.
WirelessPS2 controllers canalso beused.
The top half of the control panel contains the 10.4” ultra bright
monitorwhichdisplaysthelivevideofeedfromthefrontorrearROV
cameras(switchselectableonthecontrolpanel.)
Thecontrolboxcanbesplitapartatthehinge,byremovingtwo
pins,allowingthe upper andlower parts ofthe controlbox to be
separatedbyashortdistance.
Control Box
PS2
controller
Control Box Cover
Speaker
MonitorSource
switch
10.4”Ultra Bright
Monitor
Control Box Cover:
The control box cover contains the
built-in 10.4” ultra bright monitor, a
speaker,volumecontrol,andmonitor
sourceswitch.
Monitor Source Switch - A two
positionswitch(ROVorRecorder)
that selects the source of what is
displayedbythemonitor.
•IntheROVpositionthevideofrom
theROV’scamerasaredisplayed.
•IntheRecorderpositionthevideo
isfromanexternalrecorder.
Volume Control
VolumeControl-Adjuststhevolumelevelfromthespeaker(playingavideoonthemonitorfrom
anexternalrecorder.)
Speaker - Audio, during playback, from an external recorder that is playing back a video on the
monitor

9
Control Box Control Panel:
Control Box: (continued)
The Control Panel contains all the necessary
switchesandindicatorstocontrolandmonitorthe
SeaOtter-2.
115to120 vac (only)
inputpower plug
Power Area:
115-120vacinputpower-fromgeneratororshipspower.Forsafety,besuretoplugintoa“ground
faultbreaker”.Ifoperatingfromfor220vac,besuretouseastepdowntransformer(220to120vac).
•Fuse-10ampmainfuse.Allpowergoesthroughthisfuse.Whenopenremovespowerfromthe
system.
• Power on switch - Applies power to the system. All power goes through this switch.
• Power on LED - Illuminates when power is on.
• 120 vac outlets - Can be used to power a second monitor or recorder.
• 120 vac input power plug - Power cord (supplied) plugs into this connector and power is
suppliedtothesystem.
10amp fuse
Poweron switch
Poweron LED
120vac outlet
Horizontal
MotorPower
Master
MotorSwitch
Vertical
MotorPower Vertical
MotorTrim

10
Power Area: (continued)
115-120vacinputpower-fromgeneratororshipspower.Forsafety,besuretoplugintoa“ground
faultbreaker”.Ifoperatingfromfor220vac,besuretouseastepdowntransformer(220to120vac).
•HorizontalMotorPower-thisadjustmentcontrolstheamountofpowerthatthehorizontalmotor
joystickcansenddowntotheROV.Theadjustmentgoesfrom0toFullpower.Inmostcasesthis
controlissettoFull.Howevertherearetimeswhenthiscontrolshouldbesettoareducedpower
setting(operatingin a small area,training in a pool,operating very closeto a object).
• Vertical Motor Power - this adjustment controls the amount of power that the vertical motor
joystickcansenddowntotheROV.Theadjustmentgoesfrom0toFullpower.Inmostcasesthis
controlissettoFull.Howevertherearetimeswhenthiscontrolshouldbesettoareducedpower
setting(operatingin a small area,training in a pool,operating very closeto a object).
•VerticalMotorTrim-thisadjustmentprovidestrimtotheverticalmotorssoevenifthevertical
joystick is centered (not being used) the motors can be set to run (up or down slowly). The
adjustmentgoesfrom0to+/-4.Commonlyusedtoholdverticalpositionorwhensittingonthe
bottom(verticaljoysticknotneeded).
• MasterMotorPower-anon/offswitchthatwhenintheoffpositionremovesallpowerfromboth
verticalandhorizontalmotors.Normallythisswitchislefton.Whenworkingonthesystemoutof
watertheMasterMotorPowerswitchshouldbeturnedoffforsafetyreasons.
115to120 vac (only)
inputpower plug
10amp fuse
Poweron switch
Poweron LED
120vac outlet
Horizontal
MotorPower
Master
MotorSwitch
Vertical
MotorPower Vertical
MotorTrim
LCD Readout:
TheLCDreadoutdisplaysdataregardingthestatusofthesystem
including: moisture in any housing, pan and tilt angles of the
cameras, any motor overcurrent problems, and any error or
communicationproblem. LCD Readout
JW Fishers
SeaOtter-2

11
Left Blank

12
Control Box: (continued)
Control Box Control Panel: (continued)
The Control Panel contains all the necessary
switchesandindicators tocontrolandmonitorthe
SeaOtter-2.
2connectors for
accessories
Connectorfor
controlbox
monitor
Connectorfor
ROVumbilical
Camera
Selection VideoAudio in/out
(foradditional monitorand
recorder)
GPS
Connector
MikeGain/Audio Distortion/Microphone
VideoGain
Cabling and Video Area:
•Monitor-ashortcableconnectingthecontrolpaneltothebuiltinmonitorinthecover.Thecable
carriesthevideosignalandmonitorpower.
• ROV - the umbilicalcable fromthe ROV.
•Accessories-manydifferentaccessoriescanbeaddedtotheROV.Theaccessoryconnectors
enabletheoperatortointerfacewiththeadd-onaccessory.Theremotemetaldetector(RMD-1)
andscanningsonar(Scan-650)aretwoexamples.
•CameraSelection-afourpositionswitchwhichselectswhichcameraistobedisplayedonthe
monitorandcontrolledbythejoysticks.
-Front...Turnsonthefrontcamera.
- Rear...Turnsontherearcamera.
•VideoGain -beforethevideosignalissenttothemonitor(s)itgoesthroughavideoamplifier.
Thegainisadjustable.Whenthewaterclarityispoor,adjustingthegainofthesignalcanhavea
significantimpact onthequalityofthedisplayedimage.
•MikeGain/AudioDistortion/Microphone-IfyouarerecordingthevideofromtheROVyoucan
alsorecordaudiowiththevideo.TheloudnessoftherecordedaudioiscontrolledbytheMikeGain
knob.Ifthemike gainissettoohightheaudioDistortionledwillflashwhileyouaretalkingintothe
microphone.Themicrophone(notsupplied)plugsintothemicrophoneconnector.

13
Cabling and Video Area: (continued)
•AudioandVideo in/out -Theseconnectorsarenot usedunlessyouarerecording (recorder
notsupplied)orhaveanadditionalmonitor.
- Videoandaudioout....usethesetwoconnectorstocabletoanexternalrecorderortoasecond
monitor.
- Videoandaudioin...usethesetwoconnectorsto cable to an external recorder to playbacka
previouslyrecordedvideo.ThevideowillbedisplayedontheSeaOtters’smonitor.
•GPS-Theboat’sGPSconnectstotheconnectoriftheOnScreenDisplayoptionwaspurchased.
The boat’s GPS position will be overlaid on the video.
Control Box: (continued)
Control Box Control Panel: (continued)
The Control Panel contains all the necessary
switchesandindicators tocontrolandmonitorthe
SeaOtter-2.
2connectors for
accessories
Connectorfor
controlbox
monitor
Connectorfor
ROVumbilical
Camera
Selection VideoAudio in/out
(foradditional monitorand
recorder)
GPS
Connector
MikeGain/Audio Distortion/Microphone
VideoGain

14
Control Box: (continued)
Control Box Control Panel: (continued)
The Control Panel contains all the necessary
switchesandindicators tocontrolandmonitorthe
Seaotter-2.
Option Area:
The optionareacontains switches andindicatorsfor someoptions.
•OnScreenDisplay-Whentheswitchisturnedon;time,date,watertemperatureatROV,depth,
andcompassheadingisoverlaidonvideo.Ifthevideoisbeingrecordedtheoverlayisrecorded
withthevideo.Asecondswitch“setup”isusedtocustomizetheoverlay.
Note: how much of the above information is displayed depends on the optionpurchased.
•Arm-amanipulatorarm isavailable.Theswitchcontrolstheopenorclosepositionofthearm.
•Option -spareswitchforfutureoption.
PS2Controller
Connector
PS2 Controller Connector:
An off-the-shelf PS2 controller (supplied) plugs into the control
panel and controls many of the operations of the ROV including:
motors,lights,andcameramovement.WirelessPS2controllersare
availableand can also beused.

15
Control Box: (continued)
PS2Controller
Control Box Control Panel: (continued)
The Control Panel contains all the necessary
switchesandindicators tocontrolandmonitorthe
SeaOtter-2.
PS2 Controller:
An off-the-shelf PS2 controller (supplied), plugs into the
controlpanelandcontrolstheROV’s:lights,motors,andcam-
eramovement. WirelessPS2controllerscanalsobeused.
HorizontalMotors
Joystick
Vertical Motors
Joystick
CameraPan Left/Right
CameraTilt Up
CameraTiltDown
LightsOn
LightsOff
PS2 Back View
HorizontalMotors
LowPower VerticalMotors
LowPower

16
Control Box: (continued)
HorizontalMotors
Joystick
Vertical Motors
Joystick
CameraPan Left/Right
CameraTilt Up
CameraTiltDown
LightsOn
LightsOff
PS2 Controller: (continued)
An off-the-shelf PS2 controller (supplied), plugs into the control panel and controls the ROV’s:
lights,motors,andcameramovement.WirelessPS2controllerscanalsobeused
• Camera Pan and Tilt - twobuttonscontrolthe cameras up/down movementand two buttons
controltheleftrightmovement.Ifthebuttonishelddownthecamerawillcontinuetomoveuntil
itreaches its limit inthat direction.
•Lights-twobuttonscontrolthelights.Thetopbuttonturnsonthelightsandthebottombuttonturns
offthelight. (caution-donotleavefrontlightsonoutofwater,aquicktestisok). Iftherearcamera
hasbeenselected,thebuttonsturntheLEDlightclusteron/off.
• Horizontal Motor Joystick - controls the horizontal motors. Push straight forward and both
motorsdrivetheROVforward(proportionaltotheamountofforwardmovementofthejoystick.)
ThemaximumdriveavailableiscontrolledbytheHorizontalMotorControlknobsettingonthe
controlpanel.Ifthejoystickismovedforwardandtotheleftorrightthenmotorpowerisreduced
inone motorsothattheROVwillturninthedirectionofthejoystickmovement.
Ifthejoystickispulledback,thenthemotorsgoinreverseandtheROVgoesbackwardsand
can go left or right as it is backing up.
Ifthejoystickismoveddirectlyleftorright,thehorizontalmotorsgoinoppositedirectionswhich
causestheROVrotateleftorright.
•VerticalMotorJoystick- controlstheverticalmotors.Pushstraightforwardandbothmotors
driveforward(proportionaltotheamountofforwardmovementofthejoystick.)Themaximum
driveavailableiscontrolledbytheVerticalMotorControlknobsettingonthecontrolpanel.Ifthe
joystickismovedforwardandtotheleftorrightthenmotorpowerisreducedinone motorsothat
theROVwillcontinueup,butwillalsomovesidewardinthedirectionofthejoystickmovement.
Ifthejoystickispulledback,thenthemotorsgoinreverseandtheROVgoesdownandcango
left or right as it is going down.
Ifthejoystickismoveddirectlyleftorright,theverticalmotorsgoinoppositedirectionswhich
causestheROVtomoveleftorrightwithlittlechangeindepth.

17
Control Box: (continued)
HorizontalMotors
Joystick
Vertical Motors
Joystick
CameraPan Left/Right
CameraTilt Up
CameraTiltDown
LightsOn
LightsOff
PS2 Controller: (continued)
An off-the-shelf PS2 controller (supplied), plugs into the control panel and controls the ROV’s:
lights,motors,andcameramovement.WirelessPS2controllerscanalsobeused
•HorizontalandVerticalMotorLowPowerButtons-whendepressed,andhelddepressed,
reducesthepoweravailabletothemotorsby50%.VeryusefulwhentheROVisworkingclose
to an object. If the power was already reduced by the control panel knob, then these buttons
reducethepoweravailableevenfurther.
PS2 Back View
HorizontalMotors
LowPower VerticalMotors
LowPower
We are ready to cable up the system

18
Cabling the SeaOtter-2
The drawing below shows the cable connections for the SeaOtter-2.
Step 1.
Afteropeningthecontrol box cover, plugthe cable fromthe cover intothe Video Display connector
onthecontrolpanel. Be careful thecover does not fallforward (closed) after thecables have been
pluggedintothecontrolpanel. The cover can be removedby removing (pull out) thetwo pins in the
hinge.
Step 2.
Attachtheumbilical cable tothe ROV andtothe control box. Becareful while handlingthe con-
nectors.The pins orinternal wiring can bebroken if twistedor bent sharply.An umbilicalextension
cablecanbe ordered ifneeded, thetotal length cannot exceed500.Abuoyancycollar goes over
theconnectors.
Step 3.
Ifthe video isgoing tobe recorded,then connecttherecorder(not supplied byJWF)tothe Video
Outconnectoronthe control panel.Also include a cable betweenthe recorder andAudio Out
connectoronthe control panelif a microphone(not suppliedby JWF)is being used.The micro-
phonehasit’sownconnectoronthecontrolpanel.
Step 4.
Ifaremote monitor isbeing used, connectthe monitors cableto theVideo Out connectoron the
controlpanel.Monitorpower can be plugged intocontrol panel outlet (120vac).
Ifbotha recorder anda remotemonitor isbeing used, thenconnect therecorder cableto the
VideoOut connector (use boththe videoand audiocables) andconnect themonitor tothe DVD
outputconnectors.Monitorand recorder power can beplugged into control paneloutlet (120 vac).
SeaOtter-2
Microphone
120vac
(only)
220vac
to
120vac
transformer
GroundFault
PowerSource
if120vac
if220vac
250ft
Umbilical
cable
Umbilical
cable
extension
12vdc
to
120vac
inverter
if12vdc
Buoyancy collars
(overin-lineconnectors)
Remote
Monitor
DVDRecorder

19
Cabling the SeaOtter-2 (continued)
The drawing below shows the cable connections for the SeaOtter-2.
Step 5.
Connectingpower(be sure Main PowerSwitch on controlpanel is turnedoff) :
•Neverconnect any voltage other than115 -120 vacto the controlbox.
• The best source of 120 vac is a generator (1,000 watt or higher).
•If only 220is availableusea220 to 120vacstep downtransformer(1,000watt, JWF cansupply).
•If only 12vdc isavailableusean 12 vdcto 120vac inverter(1,000watt,JWF can supply).
•Forsafety reasons, a groundfault outlet shouldbe used.
SeaOtter-2
Microphone
120vac
(only)
220vac
to
120vac
transformer
GroundFault
PowerSource
if120vac
if220vac
250ft
Umbilical
cable
Umbilical
cable
extension
12vdc
to
120vac
inverter
if12 vdc
We are ready to power up the system
Buoyancy collars
(overin-lineconnectors)
Remote
Monitor
DVDRecorder

20
Powering up the SeaOtter-2
The first power up and checkout will be done out of water (do not turn on front lights or
run motors for more than a second or two.)
SeaOtter-2
250ft
Umbilical
cable
Umbilical
cable
extension
First test run (out of water):
1) Turn offtheMasterMotorSwitchonthecontrolpanel.
2) Rockeach propeller backand fourth(1/4 turn) afew timesto insure motorsare free toturn (if
theROV has beenin storagethe sealscan stick,this rockingfrees theseals.)
3)TurnonthePowerOnSwitchonthecontrolpanel.
4)The monitor willbeblank andthe controlpanelreadout will display: JW Fishers
SeaOtter-2
5) After5-10sec delay (internalself check), themonitor will displaythe video from theselected
camera.TheSystem in readyto go.
Note:ifthevideo does not display,checkthe Monitor Source switch onthe control boxcover.It
shouldhaveROVselectedas the source.
HorizontalMotors
Joystick
Vertical Motors
Joystick
CameraPan Left/Right
CameraTilt Up
CameraTiltDown
LightsOn
LightsOff
120vac
(only)
Buoyancy collars
(overin-lineconnectors)
