Omron K3HB-P User manual

Digital Indicators
K3HB-R/-P/-C
User's Manual
Outline
Basic Application Methods
Initial Setup
Functions and Operations
Troubleshooting
AppendicesPreparations
P
Cat. No. N136-E1-02

I
Preface
OMRON products are manufactured for use according to proper procedures by a
qualified operator and only for the purposes described in this manual.
This manual describes the functions, performance, and application methods
needed for optimum use of the K3HB.
Please observe the following items when using the K3HB.
•This product is designed for use by qualified personnel with a knowledge of
electrical systems.
•Read this manual carefully and make sure you understand it well to ensure that
you are using the K3HB correctly.
•Keep this manual in a safe location so that it is available for reference when
required.
Notice
(1) All rights reserved. No part of this manual may be reprinted or copied without the prior written permission of
OMRON.
(2) The specifications and other information contained in this manual are subject to change without notice in order
to make improvements.
(3) Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no
responsibility for errors or omissions. If you discover any problems with this manual, please notify your nearest
OMRON representative, providing them with the catalog number provided on the cover.

II
Read and Understand this Manual
Please read and understand this manual before using the product. Please consult your OMRON
representative if you have any questions or comments.
Warranty and Limitations of Liability
WARRANTY
OMRON's exclusive warranty is that the products are free from defects in materials and workmanship
for a period of one year (or other period if specified) from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING
NON-INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE
PRODUCTS. ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS
DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR
INTENDED USE. OMRON DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, LOSS OF PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE
PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR
STRICT LIABILITY.
In no event shall the responsibility of OMRON for any act exceed the individual price of the product on
which liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS
REGARDING THE PRODUCTS UNLESS OMRON'S ANALYSIS CONFIRMS THAT THE PRODUCTS
WERE PROPERLY HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO
CONTAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.
Application Considerations
SUITABILITY FOR USE
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to
the combination of products in the customer's application or use of the products.
At the customer's request, OMRON will provide applicable third party certification documents identifying
ratings and limitations of use that apply to the products. This information by itself is not sufficient for a
complete determination of the suitability of the products in combination with the end product, machine,
system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not
intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the
uses listed may be suitable for the products.
•Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions
or uses not described in this manual.
•Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical
equipment, amusement machines, vehicles, safety equipment, and installations subject to separate
industry or government regulations.
•Systems, machines, and equipment that could present a risk to life or property.
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO
ADDRESS THE RISKS, AND THAT THE OMRON PRODUCTS ARE PROPERLY RATED AND
INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user's programming of a programmable product, or any
consequence thereof.

III
Disclaimers
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other
reasons.
It is our practice to change model numbers when published ratings or features are changed, or when
significant construction changes are made. However, some specifications of the products may be
changed without any notice. When in doubt, special model numbers may be assigned to fix or establish
key specifications for your application on your request. Please consult with your OMRON representative
at any time to confirm actual specifications of purchased products.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when
tolerances are shown.
PERFORMANCE DATA
Performance data given in this manual is provided as a guide for the user in determining suitability and
does not constitute a warranty. It may represent the result of OMRON's test conditions, and the users
must correlate it to actual application requirements. Actual performance is subject to the OMRON
Warranty and Limitations of Liability.
ERRORS AND OMISSIONS
The information in this document has been carefully checked and is believed to be accurate; however,
no responsibility is assumed for clerical, typographical, or proofreading errors, or omissions.

IV
●Definition of Precautionary Information
The following notation is used in this manual to provide precautions required to
ensure safe usage of the product.
The safety precautions that are provided are extremely important to safety. Always
read and heed the information provided in all safety precautions.
The following notation is used.
●Symbols
Safety Precautions
WARNING
Indicates a potentially hazardous situation which, if not
avoided, will result in minor or moderate injury, or may result
in serious injury or death. Additionally there may be
significant property damage.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury or in property
damage.
Symbol Meaning
Caution
General Caution
Indicates non-specific general cautions, warnings,
and dangers.
Electrical Shock Caution
Indicates possibility of electric shock under specific
conditions.
Prohibition General Prohibition
Indicates non-specific general prohibitions.
Mandatory
Caution
General Caution
Indicates non-specific general cautions, warnings,
and dangers.

V
●Precautions
WARNING
Do not touch the terminals while power is being supplied. Doing
so may possibly result in electric shock. Make sure that the
terminal cover is installed before using the product.
Always provide protective circuits in the network. Without
protective circuits, malfunctions may possibly result in accidents
that cause serious injury or significant property damage.
Provide double or triple safety measures in external control
circuits, such as emergency stop circuits, interlock circuits, or limit
circuits, to ensure safety in the system if an abnormality occurs
due to malfunction of the product or another external factor
affecting the product's operation.
CAUTION
Do not allow pieces of metal, wire clippings, or fine metallic
shavings or filings from installation to enter the product. Doing so
may occasionally result in electric shock, fire, or malfunction.
Do not use the product in locations where flammable or explosive
gases are present. Doing so may occasionally result in minor or
moderate explosion, causing minor or moderate injury, or property
damage.
Do not attempt to disassemble, repair, or modify the product.
Doing so may occasionally result in minor or moderate injury due
to electric shock.
Do not use the equipment for measurements within Measurement
Categories II, III, and IV for K3HB-R, K3HB-P, and K3HB-C
(according to IEC61010-1). Doing so may occasionally cause
unexpected operation, resulting in minor or moderate injury, or
damage to the equipment. Use the equipment for measurements
only within the Measurement Category for which the product is
designed.
Perform correct setting of the product according to the application.
Failure to do so may occasionally cause unexpected operation,
resulting in minor or moderate injury, or damage to the equipment.
Ensure safety in the event of product failure by taking safety
measures, such as installing a separate monitoring system.
Product failure may occasionally prevent operation of comparative
outputs, resulting in damage to the connected facilities and
equipment.
Tighten the screws on the terminal block and the connector
locking screws securely using a tightening torque within the
following ranges. Loose screws may occasionally cause fire,
resulting in minor or moderate injury, or damage to the equipment.
Terminal block screws: 0.43 to 0.58 N·m
Connector locking screws: 0.18 to 0.22 N·m

VI
Make sure that the product will not be adversely affected if the
DeviceNet cycle time is lengthened as a result of changing the
program with online editing. Extending the cycle time may cause
unexpected operation, occasionally resulting in minor or moderate
injury, or damage to the equipment.
Before transferring programs to other nodes or changing I/O
memory of other nodes, check the nodes to confirm safety.
Changing the program or I/O memory of other nodes may
occasionally cause unexpected operation, resulting in minor or
moderate injury, or damage to the equipment.
CAUTION

VII
(1) Do not use the product in the following locations.
• Locations subject to direct radiant heat from heating equipment
• Locations where the product may come into contact with water or oil
• Locations subject to direct sunlight
• Locations where dust or corrosive gases (in particular, sulfuric or ammonia gas) are
present
• Locations subject to extreme temperature changes
• Locations where icing or condensation may occur
• Locations subject to excessive shocks or vibration
(2) Do not use the product in locations subject to temperatures or humidity levels outside
the specified ranges or in locations prone to condensation. If the product is installed in a
panel, ensure that the temperature around the product (not the temperature around the
panel) does not go outside the specified range.
(3) Provide sufficient space around the product for heat dissipation.
(4) Use and store the product within the specified temperature and humidity ranges. If
several products are mounted side-by-side or arranged in a vertical line, the heat
dissipation will cause the internal temperature of the products to rise, shortening the
service life. If necessary, cool the products using a fan or other cooling method.
(5) The service life of the output relays depends on the switching capacity and switching
conditions. Consider the actual application conditions and use the product within the
rated load and electrical service life. Using the product beyond its service life may result
in contact welding or burning.
(6) Install the product horizontally.
(7) Mount to a panel between 1 and 8-mm thick.
(8) Use the specified size of crimp terminals (M3, width: 5.8 mm max.) for wiring. To
connect bare wires, use AWG22 (cross section: 0.326 mm2) to AWG14 (cross section:
2.081 mm2) to wire the power supply terminals and AWG28 (cross section: 0.081 mm2)
to AWG16 (cross section: 1.309 mm2) for other terminals. (Length of exposed wire: 6 to
8 mm)
(9) In order to prevent inductive noise, wire the lines connected to the product separately
from power lines carrying high voltages or currents. Do not wire in parallel with or in the
same cable as power lines. Other measures for reducing noise include running lines
along separate ducts and using shield lines.
(10) Ensure that the rated voltage is achieved no longer than 2 s after turning the power ON.
(11) Allow the product to operate without load for at least 15 minutes after the power is
turned ON.
(12) Do not install the product near devices generating strong high-frequency waves or
surges. When using a noise filter, check the voltage and current and install it as close to
the product as possible.
(13) Do not use thinner to clean the product. Use commercially available alcohol.
(14) Be sure to confirm the name and polarity for each terminal before wiring the terminal
block and connectors.
(15) Use the product within the noted supply voltage and rated load.
Precautions for Safe Use

VIII
(16) Do not connect anything to unused terminals.
(17) Output turns OFF when the mode is changed or settings are initialized. Take this into
consideration when setting up the control system.
(18) Install an external switch or circuit breaker that complies with applicable IEC60947-1
and IEC60947-3 requirements and label them clearly so that the operator can quickly
turn OFF the power.
(19) Use the specified cables for the communications lines and stay within the specified
DeviceNet communications distances. Refer to the User's Manual (Cat. No. N129) for
details on communications distance specifications and cables.
(20) Do not pull the DeviceNet communications cables with excessive force or bend them
past their natural bending radius.
(21) Do not connect or remove connectors while the DeviceNet power is being supplied.
Doing so will cause product failure or malfunction.
(22) Use cables with a heat resistance specification of 70ºC min.

IX
●Noise Countermeasures
Do not install the product near devices generating strong high-frequency waves or
surges, such as high-frequency welding and sewing machines.
(1) Mount a surge suppressor or noise filter to peripheral devices generating noise, in
particular, motors, transformers, solenoids, and magnet coils.
(2) In order to prevent inductive noise, wire the lines connected to the terminal block
separately from power lines carrying high voltages or currents. Do not wire in parallel
with or in the same cable as power lines. Other measures for reducing noise include
running lines along separate ducts and using shield lines.
Example of Countermeasures for Inductive Noise on Input Lines
(3) If a noise filter is used for the power supply, check the voltage and current, and install
the noise filter as close to the product as possible.
(4) Reception interference may occur if the product is used close to a radio, television, or
wireless.
+
-
Power supply input
Power supply input
Signal input
Digital Indicator
Line filter
Surge suppressor
Digital
Indicator
+
-
Signal input
2 conductors with shield
Digital Indicator

X
●Revision History
The revision code of this manual is given at the end of the catalog number at the
bottom left of the back cover.
Cat. No. N136-E1-02
Revision code Date Pages and changes
01 October 2004 Original production
01A March 2005 Page 2-4: Changed “B4” to “BCD,” and changed
diagrams.
Page A-4 and A-5: Changed “Meter” to
“Indicator” in tables.
Page A-7: Changed “meter” to “indicator,” and
“B4” to “BCD” in table, and added note.
Page A-17 to A-22: Changed “B4” to “BCD” in
table.
01B October 2007 Page 2-4: Changed figure in upper left corner and
at bottom of page.
Page 2-9: Added table.
Pages 2-10 to 2-12: Changed figures and added
notes.
Page 5-23: Added “prescale value B” and added
note.
Page 5-27: Changed left column of top four rows
of table.
Page 5-28: Changed sentence under first table.
Page 5-71: Changed text in bottom table
(including present values under figures).
Page INDEX-1: Added and corrected index
entries.
02 November 2010 Page 3-2: Correct end of formula for prescale
value.
Page 5-57: Changed figures and removed
paragraph from below second figure.
Page 5-58: Added material to note.
Page A-4: Change description of measurement
ranges.
INDEX-2: Removed “Operation at input error.”

XI
About this Manual
Manual Structure
Preface
Provides precautionary information, a manual revision history, an
overview of the manual contents, information on using this manual,
and other general information.
Section 1 Outline
Provides an overview and describes the features of the product.
Section 2 Preparations
Describes the mounting and wiring required before using the product.
Section 3 Basic Application Methods
Shows typical applications for the product. Also shows wiring and
parameter settings which enables the user to understand how to use
the product from practical examples.
Section 4 Initial Setup
Describes the initial setup process when using this product.
Section 5 Functions and Operations
Describes the functions and settings methods for more effective use of
functions, displays, outputs, and settings for each application.
Section 6 Troubleshooting
Describes how to check and possible countermeasures for errors.
Appendices
Provides specifications and settings lists.

XII
●Settings Data Notation
The letters of the alphabet in settings data are displayed as shown below.
●Applicable Model Notation
The following symbols are used to indicate the applicable models for specific
functions.
abcdefghijklm
ABCDEFGHI J KLM
nopqrstuvwxyz
NOPQRSTUVWXYZ
R
P
C
K3HB-R@@-@@@
K3HB-P@@-@@@
K3HB-C@@-@@@

Contents
CONTENTS-1
CONTENTS
Section 1 Outline
1.1 Main Functions and Features of the K3HB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2 Component Names and Functions of the K3HB-R/P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.3 Component Names and Functions of the K3HB-C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1.4 Internal Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Section 2 Preparations
2.1 Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2 Using I/O. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Section 3 Basic Application Methods
3.1 Monitoring Roller Speed: K3HB-R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.2 Monitoring Conveyor Speed Difference: K3HB-R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3.3 Monitoring Conveyor Line Passing Time: K3HB-R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3.4 Measuring the Operation Time of a Press: K3HB-P. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
3.5 Measuring Workpiece Passing Time between Points A and B: K3HB-P . . . . . . . . . . . . . . 3-11
3.6 Measuring the Feed Length of a Sheet: K3HB-C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
3.7 Counting the Number of Workpieces: K3HB-C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Section 4 Initial Setup
4.1 Initial Setup Example for the K3HB-R. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2 Initial Setup Example for the K3HB-P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.3 Initial Setup Example for the K3HB-C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Section 5 Functions and Operations
Section 5Knowledge Required for Setting Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.1 Setting the Function for the K3HB-R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
5.2 Setting the Function for the K3HB-P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
5.3 Setting the Function for the K3HB-C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-23
5.4 Setting Input Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-27
5.5 Setting Prescale Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-28
5.6 Setting the Auto-zero Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-31
5.7 Resetting Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
5.8 Not Performing Measurements for Set Intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-34
5.9 Averaging Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-36
5.10 Changing Comparative Output Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-39
5.11 Preventing Output Chattering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-42
5.12 Outputting for a Set Interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-44
5.13 Delaying Output OFF Timing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-46
5.14 Holding Measurement Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-48

Contents
CONTENTS-2
5.15 Holding Comparative Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-49
5.16 Allocating Another Output to PASS Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-51
5.17 Reversing Output Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-53
5.18 No Output before PASS Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-55
5.19 Performing Linear Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-57
5.20 Changing the Display Refresh Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-60
5.21 Setting a Compensation Value for the Measurement Value . . . . . . . . . . . . . . . . . . . . . . . . . 5-61
5.22 Holding Measurement Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-63
5.23 Holding Maximum and Minimum Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-65
5.24 Changing Normal Display Values to Maximum and Minimum Values . . . . . . . . . . . . . . . . 5-67
5.25 Displaying/Not Displaying Comparative Set Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-68
5.26 Changing Display Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-69
5.27 Using the Position Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-71
5.28 Automatic Return to Normal Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-73
5.29 Performing Output Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-74
5.30 Using Prescale/Comparative Set Value Banks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-75
5.31 Copying Bank Prescale Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-81
5.32 Copying Bank Comparative Set Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-82
5.33 Initializing All Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-83
5.34 Limiting Key Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-84
Section 6 Troubleshooting
6.1 Error Displays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6.2 Countermeasures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Appendices
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Model Number Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7
Parameter List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8
Parameter Display Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-17
About Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-23
“No-Measurement” Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-29
Forecasted Cycle Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-30

Outline
1-1
Section 1 Outline
1.1 Main Functions and Features of the K3HB ................................ 1-2
1.2 Component Names and Functions of the K3HB-R/P................. 1-5
1.3 Component Names and Functions of the K3HB-C .................... 1-6
1.4 Internal Block Diagram .............................................................. 1-7

Outline
Section 1 Outline
1-2
1.1 Main Functions and Features of the K3HB
Measurement
Filter
Input compensation
Key operations
Functions of the K3HB-R Functions of the K3HB-P Functions of the K3HB-C
The K3HB-R has the following
six functions for reading and
displaying input pulses.
F1: Rpm/circumferential
speed
F2: Absolute ratio
F3: Error ratio
F4: Rotational difference
F5: Flow rate ratio
F6: Passing time
→P. 5 - 9
The K3HB-P has the following
six functions for reading and
displaying input pulses.
F1: Passing speed
F2: Cycle
F3: Time difference
F4: Time band
F5: Measuring length
F6: Interval
→P.5-16
The K3HB-C has the following
three functions for reading
and displaying input pulses.
F1: Individual inputs
F2: Phase differential inputs
F3: Pulse counting input
→P.5-23
Average processing Input types
Average processing of input
signals with extreme changes
or noise smooths out the
display and makes control
stable.
→P. 5 - 3 6
Specifies the sensor types
connected to input A and input
B.
→P.5-27
Input compensation Auto-zero time
The compensation input
changes the display to the
preset compensation value.
→P. 5 - 6 1
Enables forced zeroing of the
frequency when no pulse has
been input for a specific period
of time.
→P.5-31
Teaching Key protection
During scaling, the input value
during measurement can be
set, as is, as the scaling input
value.
→P. 5 - 3 0
(Setting Scaling)
Limits key-operated level and
parameter changes to prevent
inadvertent key operations and
malfunctions.
→P.5-84
R PC
R R PC
C R
R C R PC

Outline
1.1 Main Functions and Features of the K3HB
1-3
Outputs
Display
Comparative output pattern Hysteresis Output refresh stop
The comparative output
pattern can be selected as
standard output, zone output,
and level output.
→P.5-39
Prevents comparative output
chattering when the
measurement value fluctuates
slightly near the set value.
→P.5-42
Holds the output status when
comparative results outputs
other than PASS turn ON.
→P.5-49
PASS output change Output OFF delay Shot output
Comparative results other
than PASS and error signals
can be output from the PASS
output terminal.
→P.5-51
Connects the comparative output
OFF timing for a set interval.
Comparative output ON times can
be held when comparative results
change quickly.
→P.5-46
Produces a constant
comparative output ON time.
→P.5-44
Output logic Startup compensation timer Output test
Reverses the output logic of
comparative outputs for
comparative results.
→P.5-53
Constant-time measurements
can be stopped by an external
signal input.
→P.5-34
Output operation can be
confirmed without actual input
signals, by setting test
measurement values using
the keys.
→P.5-74
Linear output Standby sequence
Outputs currents or voltages
proportional to measurement
values as they change.
→P.5-57
Turns the comparative output
OFF until the measurement
value enters the PASS range.
→P.5-55
Display value selection Display color selection Display refresh period
The current display value can
be selected from the present
value, the maximum value,
and the minimum value.
→P.5-67
The PV display color can be
set to either green or red. The
present value color can be
switched according to the
status of comparative outputs.
→P.5-69
When inputs change quickly,
the display refresh period can
be delayed to reduce
flickering and make the
display easier to read.
→P.5-60
Position meter Scaling Comparative set value display
Displays the current
measurement value as a position
in relation to the scaling width on
a meter with 20 sections.
→P.5-71
Can convert the input signal to
any display value.
→P.5-28
The comparative set value
can be set to not display
during operation.
→P.5-68
R PC R R P
R PR PC R PC
R PC R R PC
R PC R P
R PC R PC R PC
R PC R PC R PC

Outline
Section 1 Outline
1-4
Other
Max/Min hold Bank selection Bank copy
Holds the maximum and
minimum measurement
values.
→P. 5 - 6 5
Eight comparative set value
banks can be selected using
the keys on the front of the
Unit or by external inputs.
Groups of comparative set
values can be set and can be
selected as groups.
→P.5-75
Any bank setting can be
copied to all banks.
→P.5-81
Interruption memory
The measured value can be
recorded when the power
supply is interrupted.
→P. 5 - 6 3
R PC R PC R PC
C
