R&S® ZNB/ZNBT
Vector Network Analyzers
User Manual
User Manual
Version 53
1173916302
(;×éÍ2)
Sie haben Fragen oder wünschen eine Beratung? Angebotsanfrage unter 07121 / 51 50 50 oder über [email protected]
Distributed by:

This manual describes the following vector network analyzer types and their options:
●R&S® ZNB4, 9 kHz to 4.5 GHz, 2 test ports, order no. 1311.6010.22
●R&S® ZNB4, 9 kHz to 4.5 GHz, 4 test ports, order no. 1311.6010.24
●R&S® ZNB8, 9 kHz to 8.5 GHz, 2 test ports, order no. 1311.6010.42
●R&S® ZNB8, 9 kHz to 8.5 GHz, 4 test ports, order no. 1311.6010.44
●R&S® ZNB20, 100 kHz to 20 GHz, 2 test ports, order no. 1311.6010.62
●R&S® ZNB20, 100 kHz to 20 GHz, 4 test ports, order no. 1311.6010.64
●R&S® ZNB40, 10 MHz to 40 GHz, 2 test ports, order no. 1311.6010.72 (variant 72)
●R&S® ZNB40, 100 kHz to 40 GHz, 2 test ports, order no. 1311.6010.82 (variant 82)
●R&S® ZNB40, 100 kHz to 40 GHz, 4 test ports, order no. 1311.6010.84 (variant 84)
●R&S® ZNBT8, 9 kHz to 8.5 GHz, 4 test ports (up to 24 ports optional), order no. 1318.7006.24
●R&S® ZNBT20, 100 kHz to 20 GHz, 8 test ports (up to 24 ports optional), order no. 1332.9002.24
●R&S® ZNBT26, 100 kHz to 26.5 GHz, 8 test ports (up to 24 ports optional), order no. 1332.9002.34
●R&S® ZNBT40, 100 kHz to 40 GHz, 8 test ports (up to 24 ports optional), order no. 1332.9002.44
© 2020 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1173.9163.02 | Version 53 | R&S® ZNB/ZNBT
Throughout this manual, R&S® is abbreviated as R&S.

Contents
R&S® ZNB/ZNBT
3User Manual 1173.9163.02 ─ 53
Contents
1 Preface.................................................................................................. 13
1.1 Documentation Overview........................................................................................... 13
1.1.1 Getting Started Manual................................................................................................. 13
1.1.2 User Manual and Help.................................................................................................. 13
1.1.3 Service Manual............................................................................................................. 13
1.1.4 Instrument Security Procedures....................................................................................14
1.1.5 Basic Safety Instructions...............................................................................................14
1.1.6 Data Sheets and Brochures.......................................................................................... 14
1.1.7 Release Notes and Open Source Acknowledgment (OSA).......................................... 14
1.1.8 Application Notes, Application Cards, White Papers, etc..............................................14
1.2 Conventions Used in the Documentation.................................................................15
1.2.1 Typographical Conventions...........................................................................................15
1.2.2 Conventions for Procedure Descriptions.......................................................................15
1.2.3 Notes on Screenshots...................................................................................................15
2 Safety Information................................................................................16
3 Firmware V3.12.....................................................................................17
3.1 Changes in Firmware Version 3.11............................................................................ 17
3.2 Changes in Firmware Version 3.10............................................................................17
4 Getting Started..................................................................................... 19
4.1 Putting the Analyzer into Operation..........................................................................19
4.1.1 Unpacking and Checking the Instrument...................................................................... 19
4.1.2 Positioning the Instrument.............................................................................................20
4.1.3 Bench Top Operation.................................................................................................... 21
4.1.4 Operation in a 19" Rack................................................................................................ 21
4.1.5 EMI Suppression...........................................................................................................22
4.1.6 Connecting the Analyzer to the AC Supply................................................................... 22
4.1.7 Starting the Analyzer and Shutting Down..................................................................... 23
4.1.8 Standby and Ready State............................................................................................. 24
4.1.9 Connecting External Accessories................................................................................. 24
4.1.10 Minimizing the VNA Application.................................................................................... 27

Contents
R&S® ZNB/ZNBT
4User Manual 1173.9163.02 ─ 53
4.1.11 Changing the Screen Resolution (R&S ZNBT)............................................................. 28
4.1.12 Remote Operation in a LAN.......................................................................................... 28
4.2 Instrument Tour...........................................................................................................33
4.2.1 Front Panel R&S ZNB................................................................................................... 33
4.2.2 Front Panel R&S ZNBT.................................................................................................39
4.2.3 Rear Panel R&S ZNB....................................................................................................41
4.2.4 Rear Panel R&S ZNBT................................................................................................. 44
4.3 Operating the Instrument........................................................................................... 46
4.3.1 Manual Operation .........................................................................................................46
4.3.2 Control Elements of the Application Window................................................................ 51
4.3.3 Working with Dialogs.....................................................................................................57
4.3.4 Handling Diagrams, Traces, and Markers.....................................................................58
4.3.5 Entering Data................................................................................................................ 62
4.3.6 Scaling Diagrams.......................................................................................................... 66
4.4 Performing Measurements.........................................................................................71
4.4.1 Transmission S-Parameter Measurement.....................................................................71
4.4.2 Reflection S-Parameter Measurement..........................................................................78
5 Concepts and Features....................................................................... 80
5.1 Basic Concepts........................................................................................................... 80
5.1.1 Global (Persistent) Settings.......................................................................................... 80
5.1.2 Recall Sets.................................................................................................................... 81
5.1.3 Traces, Channels and Diagrams...................................................................................81
5.1.4 Sweep Control...............................................................................................................83
5.1.5 Data Flow...................................................................................................................... 90
5.2 Screen Elements......................................................................................................... 92
5.2.1 Display Elements of a Diagram.....................................................................................92
5.2.2 Dialogs........................................................................................................................ 103
5.2.3 Trace Formats............................................................................................................. 107
5.3 Measurement Results............................................................................................... 115
5.3.1 S-Parameters.............................................................................................................. 116
5.3.2 Reference Impedances............................................................................................... 119
5.3.3 Impedance Parameters...............................................................................................120
5.3.4 Admittance Parameters...............................................................................................124

Contents
R&S® ZNB/ZNBT
5User Manual 1173.9163.02 ─ 53
5.3.5 Wave Quantities and Ratios........................................................................................125
5.3.6 Unbalance-Balance Conversion..................................................................................128
5.3.7 Stability Factors...........................................................................................................133
5.3.8 Delay, Aperture, Electrical Length...............................................................................133
5.4 Operations on Traces............................................................................................... 134
5.4.1 Limit Check................................................................................................................. 134
5.4.2 Trace Files...................................................................................................................141
5.4.3 Memory-Mapped Trace Data Transfer........................................................................ 146
5.5 Calibration................................................................................................................. 148
5.5.1 Calibration Types........................................................................................................ 149
5.5.2 Calibration Standards and Calibration Kits................................................................. 160
5.5.3 Calibration Pool...........................................................................................................167
5.5.4 Calibration Labels....................................................................................................... 167
5.5.5 Automatic Calibration.................................................................................................. 167
5.5.6 Scalar Power Calibration.............................................................................................174
5.5.7 SMARTerCal................................................................................................................180
5.5.8 Parallel Calibration of Multiple Channels.................................................................... 182
5.6 Offset Parameters and De-/Embedding.................................................................. 183
5.6.1 Offset Parameters....................................................................................................... 183
5.6.2 Embedding and Deembedding....................................................................................189
5.7 Optional Extensions and Accessories....................................................................202
5.7.1 Additional Test Ports (R&S ZNBT only).......................................................................203
5.7.2 Time Domain Analysis.................................................................................................203
5.7.3 Distance to Fault Measurements................................................................................ 215
5.7.4 Frequency Conversion Measurements....................................................................... 217
5.7.5 Receiver Bandwidth 10 MHz.......................................................................................226
5.7.6 Frequency Resolution 1 mHz......................................................................................227
5.7.7 Bias Tees (R&S ZNB only).......................................................................................... 227
5.7.8 Internal Second Source...............................................................................................227
5.7.9 Precision Frequency Reference..................................................................................228
5.7.10 GPIB Interface.............................................................................................................228
5.7.11 Device Control.............................................................................................................229
5.7.12 Handler I/O (Universal Interface)................................................................................ 229

Contents
R&S® ZNB/ZNBT
6User Manual 1173.9163.02 ─ 53
5.7.13 RFFE GPIO Interface..................................................................................................229
5.7.14 Additional Removable System Drive...........................................................................231
5.7.15 Extended Power Range.............................................................................................. 231
5.7.16 Extended Dynamic Range.......................................................................................... 232
5.7.17 Receiver Step Attenuators.......................................................................................... 233
5.7.18 DC Inputs.................................................................................................................... 234
5.7.19 USB-to-IEC/IEEE Adapter...........................................................................................237
5.7.20 External Power Meters................................................................................................237
5.7.21 External Generators.................................................................................................... 239
5.7.22 External Switch Matrices.............................................................................................241
6 GUI Reference.................................................................................... 249
6.1 Function Keys and Softtools................................................................................... 249
6.2 Meas Softtool.............................................................................................................251
6.2.1 S-Params Tab............................................................................................................. 252
6.2.2 Ratios Tab................................................................................................................... 261
6.2.3 Wave Tab.................................................................................................................... 264
6.2.4 Intermod. Tab.............................................................................................................. 267
6.2.5 Z←Sij Tab....................................................................................................................271
6.2.6 Y←Sij Tab................................................................................................................... 273
6.2.7 Y-Z-Params Tab.......................................................................................................... 274
6.2.8 Imbal. CMRR Tab........................................................................................................276
6.2.9 Stability Tab.................................................................................................................279
6.2.10 Power Sensor Tab.......................................................................................................280
6.2.11 DC Tab........................................................................................................................ 281
6.3 Format Softtool......................................................................................................... 284
6.4 Scale Softtool............................................................................................................ 290
6.4.1 Scale Values Tab.........................................................................................................290
6.4.2 Scale Coupling Tab..................................................................................................... 293
6.4.3 Zoom Tab.................................................................................................................... 294
6.5 Trace Config Softtool................................................................................................296
6.5.1 Traces Tab...................................................................................................................296
6.5.2 Mem............................................................................................................................ 301
6.5.3 All Mem All Data Tab...................................................................................................303

Contents
R&S® ZNB/ZNBT
7User Manual 1173.9163.02 ─ 53
6.5.4 Math Tab..................................................................................................................... 305
6.5.5 Time Domain Tab........................................................................................................ 311
6.5.6 Time Gate Tab.............................................................................................................316
6.5.7 Distance to Fault Tab.................................................................................................. 318
6.5.8 Trace Statistics Tab..................................................................................................... 326
6.5.9 Smooth Shift Hold Tab................................................................................................ 332
6.5.10 Infinite Averaging Tab..................................................................................................336
6.5.11 Trace Data Tab............................................................................................................336
6.6 Lines Softtool............................................................................................................ 343
6.6.1 Limit Test Tab.............................................................................................................. 344
6.6.2 Ripple Test Tab............................................................................................................352
6.6.3 Circle Test Tab.............................................................................................................357
6.6.4 Display Circle Tab....................................................................................................... 360
6.6.5 Horiz. Line Tab............................................................................................................ 361
6.7 Marker Softtool..........................................................................................................362
6.7.1 Markers Tab................................................................................................................ 362
6.7.2 Marker Props Tab........................................................................................................365
6.7.3 Marker Search Tab......................................................................................................368
6.7.4 Multiple Peak Tab........................................................................................................373
6.7.5 Target Search Tab....................................................................................................... 375
6.7.6 Bandfilter Tab.............................................................................................................. 376
6.7.7 Set by Marker Tab....................................................................................................... 381
6.7.8 Info Field Tab...............................................................................................................382
6.7.9 Marker Coupling Tab................................................................................................... 383
6.8 Stimulus Softtool...................................................................................................... 384
6.8.1 Stimulus Tab................................................................................................................384
6.8.2 Power Tab................................................................................................................... 386
6.8.3 Time Domain X-Axis Tab.............................................................................................388
6.9 Power Bw Avg Softtool.............................................................................................390
6.9.1 Power Tab................................................................................................................... 390
6.9.2 Bandwidth Tab.............................................................................................................390
6.9.3 Average Tab................................................................................................................ 391
6.10 Sweep Softtool.......................................................................................................... 393

Contents
R&S® ZNB/ZNBT
8User Manual 1173.9163.02 ─ 53
6.10.1 Sweep Params Tab..................................................................................................... 393
6.10.2 Sweep Type Tab..........................................................................................................396
6.10.3 Trigger Tab.................................................................................................................. 407
6.10.4 Sweep Control Tab......................................................................................................412
6.11 Cal Softtool................................................................................................................ 415
6.11.1 Start Cal Tab............................................................................................................... 416
6.11.2 Cal Devices Tab.......................................................................................................... 478
6.11.3 Pwr Cal Settings Tab...................................................................................................490
6.11.4 Use Cal Tab.................................................................................................................497
6.12 Channel Config Softtool........................................................................................... 503
6.12.1 Channels Tab.............................................................................................................. 503
6.12.2 Port Config Tab........................................................................................................... 517
6.12.3 Mode Tab.................................................................................................................... 534
6.12.4 Intermod. Tab.............................................................................................................. 539
6.12.5 Pwr Cal Settings Tab...................................................................................................551
6.12.6 Mixer Mode Tab...........................................................................................................551
6.13 Offset Embed Softtool.............................................................................................. 562
6.13.1 Offset Embed Dock Widget.........................................................................................563
6.13.2 Offset Tab.................................................................................................................... 571
6.13.3 One Way Loss Tab...................................................................................................... 577
6.13.4 Single Ended Tab........................................................................................................ 579
6.13.5 Fixture Modeling Dialog.............................................................................................. 582
6.13.6 Port Sets Tab...............................................................................................................593
6.13.7 Balanced Tab.............................................................................................................. 595
6.13.8 Ground Loop Tab........................................................................................................ 598
6.13.9 Differential Match Tab..................................................................................................600
6.13.10 Config Tab................................................................................................................... 602
6.14 File Softtool............................................................................................................... 603
6.14.1 Recall Sets Tab........................................................................................................... 604
6.14.2 Favorites Tab...............................................................................................................608
6.14.3 Print Tab...................................................................................................................... 609
6.14.4 Printer Setup Dialog.................................................................................................... 609
6.14.5 Trace Data Tab............................................................................................................ 611

Contents
R&S® ZNB/ZNBT
9User Manual 1173.9163.02 ─ 53
6.14.6 More Tab......................................................................................................................611
6.15 Applic Softtool...........................................................................................................612
6.15.1 External Tools Application........................................................................................... 612
6.15.2 TDR Application (R&S ZNB/ZNBT-K20)..................................................................... 614
6.15.3 DUT Centric Application..............................................................................................641
6.16 Display Softtool.........................................................................................................656
6.16.1 Diagram Tab................................................................................................................656
6.16.2 Split Tab...................................................................................................................... 659
6.16.3 Config Tab................................................................................................................... 662
6.16.4 View Bar Tab............................................................................................................... 669
6.16.5 Touchscreen Tab......................................................................................................... 670
6.17 Setup Softtool............................................................................................................670
6.17.1 Setup Tab.................................................................................................................... 671
6.17.2 Freq. Ref. Tab............................................................................................................. 687
6.17.3 Remote Settings Tab...................................................................................................687
6.17.4 External Devices Tab.................................................................................................. 690
6.17.5 External Ports Tab.......................................................................................................700
6.18 Help Softtool..............................................................................................................710
6.19 Additional Function Keys......................................................................................... 711
7 Remote Control.................................................................................. 713
7.1 Introduction to Remote Control...............................................................................713
7.1.1 Remote Control via USB............................................................................................. 714
7.1.2 Starting a Remote Control Session.............................................................................714
7.1.3 GPIB Explorer............................................................................................................. 715
7.1.4 Switchover to Remote Control.................................................................................... 716
7.1.5 Combining Manual and Remote Control..................................................................... 719
7.2 Messages................................................................................................................... 720
7.2.1 Device Messages (Commands and Device Responses)............................................ 720
7.2.2 SCPI Command Structure and Syntax........................................................................720
7.2.3 SCPI Parameters........................................................................................................ 724
7.3 Basic Remote Control Concepts............................................................................. 726
7.3.1 Traces, Channels, and Diagram Areas....................................................................... 726
7.3.2 Active Traces in Remote Control.................................................................................727

Contents
R&S® ZNB/ZNBT
10User Manual 1173.9163.02 ─ 53
7.3.3 Initiating Measurements, Speed Considerations.........................................................728
7.3.4 Addressing Traces and Channels............................................................................... 729
7.4 Command Processing.............................................................................................. 730
7.4.1 Input Unit.....................................................................................................................730
7.4.2 Command Recognition................................................................................................731
7.4.3 Data Base and Instrument Hardware..........................................................................731
7.4.4 Status Reporting System............................................................................................ 732
7.4.5 Output Unit.................................................................................................................. 732
7.4.6 Command Sequence and Command Synchronization............................................... 732
7.5 Status Reporting System......................................................................................... 734
7.5.1 Overview of Status Registers......................................................................................735
7.5.2 Structure of an SCPI Status Register..........................................................................735
7.5.3 Contents of the Status Registers................................................................................ 737
7.5.4 Application of the Status Reporting System................................................................744
7.5.5 Reset Values of the Status Reporting System............................................................ 747
8 Command Reference......................................................................... 748
8.1 Special Terms and Notation..................................................................................... 748
8.1.1 Upper/Lower Case...................................................................................................... 749
8.1.2 Special Characters......................................................................................................749
8.1.3 Parameters..................................................................................................................749
8.1.4 Numeric Suffixes......................................................................................................... 749
8.2 Common Commands................................................................................................ 750
8.3 SCPI Command Reference.......................................................................................751
8.3.1 CALCulate Commands............................................................................................... 752
8.3.2 CONFigure Commands...............................................................................................948
8.3.3 CONTrol Commands...................................................................................................956
8.3.4 DIAGnostic Commands...............................................................................................980
8.3.5 DISPlay Commands....................................................................................................982
8.3.6 FORMat Commands................................................................................................. 1008
8.3.7 HCOPy Commands...................................................................................................1010
8.3.8 INITiate Commands.................................................................................................. 1015
8.3.9 INSTrument Commands............................................................................................1017
8.3.10 MEMory.....................................................................................................................1019

Contents
R&S® ZNB/ZNBT
11User Manual 1173.9163.02 ─ 53
8.3.11 MMEMory Commands.............................................................................................. 1020
8.3.12 OUTPut Commands..................................................................................................1062
8.3.13 PROGram Commands.............................................................................................. 1067
8.3.14 [SENSe:] Commands................................................................................................ 1070
8.3.15 SOURce Commands.................................................................................................1205
8.3.16 STATus Commands...................................................................................................1253
8.3.17 SYSTem Commands.................................................................................................1256
8.3.18 TRACe Commands................................................................................................... 1298
8.3.19 TRIGger Commands................................................................................................. 1301
8.4 R&S ZVR/ZVABT Compatible Commands.............................................................1308
9 Programming Examples..................................................................1335
9.1 Basic Tasks..............................................................................................................1335
9.1.1 Typical Stages of a Remote Control Program...........................................................1335
9.1.2 Channel, Trace and Diagram Handling..................................................................... 1338
9.2 Condensed Programming Examples.................................................................... 1344
9.2.1 Path Independent RC Programs............................................................................... 1345
9.2.2 Trace and Diagram Handling.................................................................................... 1345
9.2.3 Using Markers........................................................................................................... 1354
9.2.4 Data Handling........................................................................................................... 1356
9.2.5 Calibration................................................................................................................. 1360
9.2.6 Mixer Measurement.................................................................................................. 1366
9.2.7 RFFE/GPIO Interface Programming......................................................................... 1369
9.2.8 Fixture Modeling........................................................................................................1371
10 Error Messages and Troubleshooting............................................1373
10.1 Errors during Firmware Operation........................................................................ 1373
10.1.1 Asynchronous Errors.................................................................................................1374
10.1.2 Errors during Measurement...................................................................................... 1374
10.2 Errors during Firmware Installation/Update......................................................... 1375
10.3 Collecting Information for Technical Support...................................................... 1377
10.4 Contacting Customer Support...............................................................................1378
11 Annexes............................................................................................ 1379
11.1 Administrative Tasks.............................................................................................. 1379

Contents
R&S® ZNB/ZNBT
12User Manual 1173.9163.02 ─ 53
11.1.1 Windows Operating System......................................................................................1379
11.1.2 Firmware Installation................................................................................................. 1380
11.2 System Recovery.................................................................................................... 1381
11.3 Interfaces and Connectors.....................................................................................1381
11.3.1 Rear Panel Connectors.............................................................................................1381
11.3.2 LAN Interface............................................................................................................ 1383
11.3.3 GPIB Interface...........................................................................................................1384
11.3.4 Handler I/O (Universal Interface).............................................................................. 1387
11.3.5 RFFE - GPIO Interface .............................................................................................1395
11.4 Maintenance............................................................................................................ 1397
11.4.1 Cleaning.................................................................................................................... 1397
11.4.2 Storing and Packing the Instrument.......................................................................... 1398
11.4.3 Replacing Fuses....................................................................................................... 1398
11.5 Showroom Mode..................................................................................................... 1399
11.6 ENA Emulation Commands....................................................................................1399
Glossary: Frequently Used Terms..................................................1407
List of Commands............................................................................1413
Index..................................................................................................1436

Preface
R&S® ZNB/ZNBT
13User Manual 1173.9163.02 ─ 53
1 Preface
This chapter provides safety-related information, an overview of the user documenta-
tion and the conventions used in the documentation.
1.1 Documentation Overview
This section provides an overview of the R&S ZNB/ZNBT user documentation. Unless
specified otherwise, you find the documents on the R&S ZNB/ZNBT product page at:
●https://www.rohde-schwarz.com/manual/ZNB
●https://www.rohde-schwarz.com/manual/ZNBT
1.1.1 Getting Started Manual
Introduces the R&S ZNB/ZNBT and describes how to set up and start working with the
product. Includes basic operations, typical measurement examples, and general infor-
mation, e.g. safety instructions, etc.
A printed version is delivered with the instrument. A PDF version is available for down-
load on the Internet.
1.1.2 User Manual and Help
The user manual contains the description of all instrument modes and functions. It also
provides an introduction to remote control, a complete description of the remote control
commands with programming examples, and information on maintenance, instrument
interfaces and error messages. Includes the contents of the getting started manual.
The contents of the user manual are available as help in the R&S ZNB/ZNBT. The help
offers quick, context-sensitive access to the complete information for the instrument
and its firmware.
The user manual is also available for download or for immediate display on the Inter-
net.
1.1.3 Service Manual
Describes the performance test for checking the rated specifications, module replace-
ment and repair, firmware update, troubleshooting and fault elimination, and contains
mechanical drawings and spare part lists.
The service manual is available for registered users on the global Rohde & Schwarz
information system (GLORIS):
●R&S ZNB Service Manual
Documentation Overview

Preface
R&S® ZNB/ZNBT
14User Manual 1173.9163.02 ─ 53
●R&S ZNBT Service Manual
1.1.4 Instrument Security Procedures
Deals with security issues when working with the R&S ZNB/ZNBT in secure areas. It is
available for download on the Internet.
1.1.5 Basic Safety Instructions
Contains safety instructions, operating conditions and further important information.
The printed document is delivered with the instrument.
1.1.6 Data Sheets and Brochures
The data sheet contains the technical specifications of the R&S ZNB/ZNBT. It also lists
the firmware applications and their order numbers, and optional accessories.
The brochure provides an overview of the instrument and deals with the specific char-
acteristics.
See
●https://www.rohde-schwarz.com/brochure-datasheet/ZNB
●https://www.rohde-schwarz.com/brochure-datasheet/ZNBT
1.1.7 Release Notes and Open Source Acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current
firmware version, and describe the firmware installation.
The open-source acknowledgment document provides verbatim license texts of the
used open source software.
See
●https://www.rohde-schwarz.com/firmware/ZNB
●https://www.rohde-schwarz.com/firmware/ZNBT
1.1.8 Application Notes, Application Cards, White Papers, etc.
These documents deal with special applications or background information on particu-
lar topics.
See
●https://www.rohde-schwarz.com/application/ZNB
●https://www.rohde-schwarz.com/application/ZNBT
Documentation Overview

Preface
R&S® ZNB/ZNBT
15User Manual 1173.9163.02 ─ 53
1.2 Conventions Used in the Documentation
1.2.1 Typographical Conventions
The following text markers are used throughout this documentation:
Convention Description
[Keys] Key and knob names are enclosed by square brackets.
"Graphical user interface ele-
ments"
All names of graphical user interface elements on the screen, such as
dialog boxes, menus, options, buttons, and softkeys are enclosed by
quotation marks.
File names, commands,
program code
File names, commands, coding samples and screen output are distin-
guished by their font.
Input Input to be entered by the user is displayed in italics.
Links Links that you can click are displayed in blue font.
"References" References to other parts of the documentation are enclosed by quota-
tion marks.
1.2.2 Conventions for Procedure Descriptions
When operating the instrument, several alternative methods may be available to per-
form the same task. In this case, the procedure using the touchscreen is described.
Any elements that can be activated by touching can also be clicked using an addition-
ally connected mouse. The alternative procedure using the keys on the instrument or
the on-screen keyboard is only described if it deviates from the standard operating pro-
cedures.
The term "select" may refer to any of the described methods, i.e. using a finger on the
touchscreen, a mouse pointer in the display, or a key on the instrument or on a key-
board.
1.2.3 Notes on Screenshots
When describing the functions of the product, we use sample screenshots. These
screenshots are meant to illustrate as many as possible of the provided functions and
possible interdependencies between parameters. The shown values may not represent
realistic usage scenarios.
The screenshots usually show a fully equipped product, that is: with all options instal-
led. Thus, some functions shown in the screenshots may not be available in your par-
ticular product configuration.
Conventions Used in the Documentation

Safety Information
R&S® ZNB/ZNBT
16User Manual 1173.9163.02 ─ 53
2 Safety Information
The product documentation helps you use the R&S ZNB/ZNBT safely and efficiently.
Follow the instructions provided here and in the printed "Basic Safety Instructions".
Keep the product documentation nearby and offer it to other users.
Intended use
The R&S ZNB/ZNBT is intended for the development, production and verification of
electronic components and devices in industrial, administrative, and laboratory environ-
ments. Use the R&S ZNB/ZNBT only for its designated purpose. Observe the operat-
ing conditions and performance limits stated in the data sheet.
Where do I find safety information?
Safety information is part of the product documentation. It warns you about the poten-
tial dangers and gives instructions how to prevent personal injuries or damage caused
by dangerous situations. Safety information is provided as follows:
●The printed "Basic Safety Instructions" provide safety information in many lan-
guages and are delivered with the R&S ZNB/ZNBT.
●Throughout the documentation, safety instructions are provided when you need to
take care during setup or operation.

Firmware V3.12
R&S® ZNB/ZNBT
17User Manual 1173.9163.02 ─ 53
3 Firmware V3.12
Version 3.12 of the R&S ZNB/ZNBT firmware provides the following changes:
Solved issues
●Firmware versions 3.x created incompatible *.calkit files
(*.calkit files containing snp data could not be used with previous FW versions)
●R&S ZNBT8 with CPU board "LPW10" and image version "1.0 (64 Bit)": update to
firmware versions 3.x failed
CPU board and image version can be found in the "Image Information" section of
the setup info.
●PC firmware simulation failed to run due to missing Microsoft Visual C++ redistrib-
utable
Firmware version
► To check your R&S ZNB/ZNBT firmware version, select "Help" > "About..." from the
main menu.
3.1 Changes in Firmware Version 3.11
Solved issues
●Problems with fan control
●Impedance normalization failed for some special balanced port configurations
●User characterization of R&S ZN-Z154 did not work
●Firmware simulation: trace noise could not be disabled in Simulation Config tool
3.2 Changes in Firmware Version 3.10
New functionality
●Ground loop de-/embedding per port group (i.e. per DUT)
See "Ground Loop per Port Group" on page 600
●New "Distance to Fault Measurements" software option R&S ZNB-K3/R&S ZNBT-
K3
See Chapter 5.7.3, "Distance to Fault Measurements", on page 215
New remote control features
●Memory-mapped trace data transfer
See Chapter 5.4.3, "Memory-Mapped Trace Data Transfer", on page 146
Improvements
●Limit line enhancements:
– Formula-defined limit lines
See "Response Dialog" on page 351
Changes in Firmware Version 3.10

Firmware V3.12
R&S® ZNB/ZNBT
18User Manual 1173.9163.02 ─ 53
– Logarithmic interpolation
See "Interpolation" column in Chapter 6.6.1.2, "Define Limit Lines Dialog",
on page 348
●Cal kit data added:
–N 50 Ω
Keysight 85032B, 85032F, 85515A
R&S ZN-Z170 typical
Spinner BN533843, BN533844, BN533863, BN533864
–3.5 mm
R&S ZN‑Z135 typical
–2.92 mm
R&S ZN-Z129 typical, R&S ZN-Z129E typical
–7-16
Keysight 85038A
Spinner BN533845, BN533846, BN533865, BN533866
●Faster ground loop de-/embedding
●Cal kit standards: loss limit increased to 100,000 GΩ/s
●Menu bar: optimized submenu structure for trace math ("Trace" > "Trace Config" >
"Trace Math")
●Remote control: reduced number of ACQuire commands in Multiple Calibration
Types Mode
See the example in [SENSe:]CORRection:COLLect:CHANnels:MCTYpes
on page 1096.
Solved issues
●Marker disappeared in zoom mode
●Calibrated imbalance and CMRR traces did not show "Cal" label
●Incorrect length offset calculation, if a Short was connected when the "Auto Length"
or "Auto Length and Loss" function was called
●Discrete markers did not always snap to sweep points
●Trace math on formatted data: for source data traces, an active "Min Hold" or "Max
Hold" was ignored
●Loading an unsuitable snp file (e.g. a s3p file on a 2 port instrument), caused a
firmware exception and made the VNA stop sweeping
●"Load Simulation Data" from snp files with n > 9 did not work reliably
●Marker values not displayed for Y and Z parameter traces in "dB Mag" format
●Firmware simulation: when switching between simulated instruments, the fixture
de-/embedding tool support sometimes got confused about the number of available
ports
Changes in Firmware Version 3.10

Getting Started
R&S® ZNB/ZNBT
19User Manual 1173.9163.02 ─ 53
4 Getting Started
4.1 Putting the Analyzer into Operation
This section describes the basic steps to be taken when setting up the analyzer for the
first time.
Simple measurement examples are provided in Chapter 4.4, "Performing Measure-
ments", on page 71; for a description of the operating concept refer to Chapter 4.3,
"Operating the Instrument", on page 46. For all background and reference informa-
tion concerning manual and remote control of the instrument, refer to your analyzer's
help system or user manual. A more detailed description of the hardware connectors
and interfaces is also part of the help system or user manual.
Risk of injury due to disregarding safety information
Observe the information on appropriate operating conditions provided in the data sheet
to prevent personal injury or damage to the instrument. Read and observe the basic
safety instructions provided with the instrument, in addition to the safety instructions in
the following sections. In particular:
●Do not open the instrument casing.
4.1.1 Unpacking and Checking the Instrument
Check the equipment for completeness using the delivery note and the accessory lists
for the various items. If you notice any damage, immediately contact the carrier who
delivered the instrument.
Packing material
Retain the original packing material. If the instrument needs to be transported or ship-
ped later, you can use the material to protect the control elements and connectors.
Putting the Analyzer into Operation

Getting Started
R&S® ZNB/ZNBT
20User Manual 1173.9163.02 ─ 53
Risk of injury during transportation
The carrying handles at the front and side of the casing are designed to lift or carry the
instrument. Do not apply excessive force to the handles. If a handle is ripped off, the
falling instrument can cause injury.
As the R&S ZNBT is very heavy (over 35 kg fully equipped), it must always be carried
by two people using both carrying handles to avoid personal injury or damage to the
instrument.
4.1.2 Positioning the Instrument
The network analyzer is designed for use under laboratory conditions, either on a
bench top or in a rack.
Risk of instrument damage due to inappropriate operating conditions
An unsuitable operating site or test setup can damage the instrument and connected
devices. Before switching on the instrument, observe the information on appropriate
operating conditions provided in the data sheet. In particular, ensure the following:
●All fan openings are unobstructed and the airflow perforations are unimpeded. A
minimum distance of 10 cm to other objects is recommended.
●The instrument is dry and shows no sign of condensation.
●The instrument is positioned as described in the following sections.
●The ambient temperature does not exceed the range specified in the data sheet.
●Signal levels at the input connectors are all within the specified ranges.
●Signal outputs are connected correctly and are not overloaded.
Instrument damage caused by electrostatic discharge
Electrostatic discharge (ESD) can damage the electronic components of the instrument
and the device under test (DUT). Electrostatic discharge is most likely to occur when
you connect or disconnect a DUT or test fixture to the instrument's test ports. To pre-
vent electrostatic discharge, use a wrist strap and cord and connect yourself to the
ground, or use a conductive floor mat and heel strap combination.
During operation, if the firmware observes a serious unexpected disturbance (e.g. due
to ESD), it resets all hardware components to ensure proper instrument functioning. It
then restores the user settings to the state before the disturbance and indicates the
foregone hardware reset by an "Hardware communication problem [...]" information
popup.
Putting the Analyzer into Operation
