JW Speaker 6045 User manual
Thank you for purchasing one of our quality products. From product conception to
the moment we packaged this product our focus has been on providing you with
the very best. A great deal of effort is spent making sure you receive a quality
part that will hold up to years of abuse. If for any reason you are unsatisfied with
anything purchased from Nemesis Industries Inc. it may be returned within 10 days
in unused condition for your choice of an exchange or a full refund (less shipping
charges). Thank you for your purchase and we hope to see you on the trail soon.
Pre-Install Notes:
- Before you start it is imperative that you read these instructions. Failure to do
so may result in an unsatisfactory installation or personal injury.
- It is the purchasers / installers responsibility to inspect the package for any missing or damaged
pieces prior to beginning installation. If any discrepancies are discovered pease contact us
immediately so we may rectify the situation.
- Carefully read the Product Warranty and Assumption of Risk Agreement at the end of this
document.
- This document is also available on our website in .pdf format with images that can be enlarged for
greater clarity www.nem-ind.com/tech
- Your personal safety is of the utmost importance. Please, exercise caution when working around
and under your vehicle.
- Wear personal protective equipment such as safety glasses, hearing protection and gloves when
working on your vehicle.
Installation Instructions
JW Speaker 6045
Universal Fog Light Mount
Page 1
4 –1/8” Front Plates 4 – 1/2” Spacers 4 –3/16” Back Plates
Phillips Head Screwdriver Small
11/32” Open-end Wrench or Socket
Part
Size
Length
Quantity
Machine Screw Z
8-32
1.5
8
SAE Flat Washer ZP
8
N/A
16
Nylock Nut (Steel)
8-32
N/A
8
Box Contents:
Hardware Pack Contents:
Tools Required:
Page 2
Due to the variations between bumpers we are only providing instructions on
how to assemble the mount to the light. You will need to refer to the install
instructions for your bumper to complete the install.
This adapter is intended to be used on bumpers that use the factory fog light
bolt pattern.
This adapter is not intended to work in the factory bumper.
Slight modifications to the adapters may be required to fit your bumper.
Note: If modifications are made to the adapter it cannot be returned.
Please see our return policy for further information.
1. Make sure the vehicle is parked on a level, sturdy surface and properly
secured to prevent movement while working on it.
2. Make sure the Jeep is in park or 1st gear with the emergency brake set.
3. Disconnect the battery cables from both terminals with caution, and
ensure that they do not touch.
Precautions:
Page 3
1. Pre-assemble the four (4) individual adapters using the supplied hardware and
components.
HDW: 8 - #8-32 x 1.5 machine screws
8 - #8 flat washers
8 - #8-32 nylock nuts
Tip: The washer goes behind the head of the machine screw.
Depending on the bumper the machine screws may need to come in from the
back side of the adapter.
Note: Do not tighten hardware.
Front View Back View
Install Procedure:
3/16” Back Plate
1/2” Spacer
1/8” Front Plate
Page 4
2. Locate one (1) of the adapters on the notch on the fog light.
Tip: Only 1 of the adapters will locate on the fog light even though all of the back
plates have the notch cut out.
Page 5
3. Tighten one of the machine screws to clamp the light into the adapter.
Tools: Philips head screwdriver (small), 11/32” open end wrench or socket
4. Place the other adapter onto the fog light.
Tip: The second adapter can be rotated, clearance, or modified to accommodate the
needs of your particular bumper.
Optics on light
need to be
mounted vertical.
Page 6
5. Repeat procedure on opposite side fog light.
6. Reconnect battery cables.
Thank you for your purchase. If you have any questions or comments about these
instructions please contact us at:
303-974-2440
Page 7
1. Please check our technical support page for additional resources pertaining to the
install of this product.
Troubleshooting:
Page 8
The goal of all of us at Nemesis Industries, Inc.™ is to ensure you are delighted not only
with this purchase, but also with any additional purchases and to that end Nemesis offers a
ten (10) day from the ship date no questions asked return policy if products are returned in
an "unused" condition, this excludes custom parts or parts with custom paint or
powdercoat. In addition, Nemesis warrants your product for two (2) years from the date of
sale to be free from defects in material and workmanship under normal installation and
use. This warranty is limited to the costs of repair and replacement. Therefore, no type of
labor or shipping allowance is available in connection with a customer's repair, removal,
reinstallation or return of a damaged product. Should any questions arise, please call
Nemesis at (303) 974-2440. We remind you that all finishes, painted or powder coated,
must be cleaned and waxed regularly and the portion of the warranty concerning the
products' finish does not apply to products that have been chipped, scratched or damaged
in any way. All warranty claims are subject to inspection by Nemesis. Following such
inspection, the product in question may either be repaired or replaced when found
defective. Prior to any replacement or repair, written authorization as to the action to be
taken shall be issued by Nemesis. Failure to contact Nemesis prior to having warranty work
performed shall immediately void all applicable warranties.
THE WARRANTY EXPRESSED ABOVE IS THE SOLE WARRANTY OF
NEMESIS AND ANY OTHER EXPRESSED OR IMPLIED WARRANTIES ARE
HEREBY SPECIFICALLY EXCLUDED AND DISCLAIMED, INCLUDING, BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. EXCEPT FOR THE LIMITED
WARRANTY DESCRIBED HEREIN, NEMESIS SHALL NOT BE LIABLE TO
ANYONE FOR INCIDENTAL, CONSEQUENTIAL, PUNITIVE, SPECIAL OR
EXEMPLARY DAMAGES OR OTHER DIRECT OR INDIRECT DAMAGES OF
ANY TYPE OR KIND ARISING FROM ANY BREACH OF WARRANTY ARISING
FROM OR IN CONNECTION WITH THE PURCHASE OF NEMESIS
PRODUCTS.
Warranty:
Page 9
Customer’s Acknowledgments. Customer understands and acknowledges that products purchased from
Nemesis Industries, Inc.TM (“Nemesis”) are designed to protect against certain types of property damage from
minor impacts, but are not designed as a crash safety device, or as an impact resistant product designed for
the protection of occupants, but instead are cosmetic enhancements to assist in protecting against minor
impact damage with certain stationary obstacles. As a result, Customer also understands and acknowledges
that the installation of Nemesis products on a Vehicle and the voluntary use of that Vehicle for off-road
activities (each, hereinafter, and “an Off-Road Activity”) is inherently dangerous and hazardous and can result
in damage to the Vehicle, to others, to the property of others and in the serious bodily injury or death to
Customer or others.
Use in an Off-Road Activity. By accepting a Nemesis product and using such product in any Off-Road
Activity, Customer accepts and agrees to all of the terms described below (the “Release”); provided that
Customer may in lieu of accepting the terms of this Release and prior to installation, elect to return any
Nemesis product and receive a full refund. Such return may be initiated by contacting a Nemesis sales
representative or by directly contacting Nemesis at (303) 974-2440 or at www.nem-ind.com for the issuance
of a call tag for the product in question. Once the product being returned has been received by Nemesis in
good condition, a full refund will be issued minus shipping charges.
Assumption of Risk and Release. Customer assumes all risk and responsibility of engaging in an Off-Road
Activity which is acknowledged as being inherently dangerous. Customer understands that persons par-
ticipating in an Off-Road Activity must possess specialized knowledge and skills, and in voluntarily deciding
to do so, Customer assumes all risks inherent therein which may be encountered at any time in connection
with an Off- Road Activity. With full knowledge of the above and all risks inherent therein, Customer and
others who may voluntarily choose to engage in an Off-Road Activity accepts full responsibility for and
assumes all risks associated with engaging in an Off-Road Activity, whether known, unknown, or inherent,
and acknowledge and agree that such persons are assuming all responsibility for any and all consequences
resulting from the participation in an Off-Road Activity, including, but not limited to, injury and/or death to
Customer or others and damage to the Vehicle and other property. Customer and each other participant in
any Off-Road Activity hereby release, and forever discharge and shall hold harmless each other and Nemesis,
including all of their respective predecessors, affiliates, successors, assigns, partners, venturers, principals,
officers, directors, managers, shareholders, attorneys and agents and their respective insurance carriers (the
“Released Parties”)and hereby release and forever discharge, indemnify and hold harmless the Released
Parties, and any and all persons claiming under them, however involved, of and from any and all liability for
any and all claims, demands, damages and costs, liabilities, losses, expenses, obligations, compensations,
reimbursements, actions, rights, loss of profits, and rights and causes of action, of every kind and nature
whatsoever, including court costs and attorney fees, whether known or unknown, which Customer and any
other participant may now have, or claim at any future time to have, arising from or growing out of, or by
reason of, or based in whole or in part upon, any act, omission, event, transaction, matter or thing involved,
alleged or referred to, whether direct or indirect, involving an Off-Road Activity.
Release of Unknown Claims. Customer and any other participant fully realize that in participating in an Off-
Road Activity they may sustain unknown and unforeseen losses, costs, expenses, damages, liabilities, and
claims, and the consequences thereof, which may be at this time, and hereafter unknown, unrecognized and
not contemplated by them. By participating in an Off-Road Activity, Customer and any other participant
intend to release the Released Parties from any and all liability for any and all such unknown and unforeseen
losses, expenses, damages, costs, liabilities, and the consequences thereof, not known, recognized nor
contemplated at any time by them, which result or may result from an Off-Road Activity. Customer and any
other participant expressly and forever waive any right to assert that this Release was the result of a mistake
of any kind, waiving all claims based upon the doctrine of mistake.
Assumption of Risk, Indemnity and Release:
Page 10
Covenant Not to Sue. Customer and any other participant specifically covenant and agree, each with the
other, never to institute or participate in any suit or action, including class actions, at law or in equity,
whether sounding in tort or contract, against the Released Parties and all persons claiming under them or any
of them by reason of any claim, demand, action, or cause of action described in this Release.
Miscellaneous Provisions. This Release shall be binding in all respects upon, and shall inure to the benefit of
the Released Parties and their heirs, successors and assigns. This Release shall be governed by the laws of the
State of Colorado, and the sole and exclusive jurisdiction for the determination of any controversy or claim
arising out of the purchase of any Nemesis product shall be in the District Court of Arapahoe County,
Colorado. In the event that a court of competent jurisdiction enters judgment declaring any material
provision of this Release invalid or unenforceable, the remainder of this Release shall remain in full force and
effect and such provision shall be limited or eliminated to the minimum extent necessary so that such invalid
or unenforceable provision shall otherwise remain in force or effect. Neither Customer nor any other
participant shall be entitled to any favorable construction of any provision of this Release because the Release
was drafted by Nemesis or by an attorney for Nemesis. The acceptance of a Nemesis product constitutes
Customer’s voluntary acceptance of this Release, Customer’s acknowledgement that no oral statements or
inducements have been made and that full and adequate consideration has been received for this Release.
Nemesis Industries, Inc.
2820 South Zuni Street Englewood,
Colorado 80110
Phone: 303-974-2440
Fax: 303-952-5212
www.nem-ind.com
