JXP LY-003BNM User manual
Many thanks for purchasing our massage items.Before
using this machine, please read this manual carefully
to make sure fully understand the exact method of
using, especially the points for attention.Please keep
this manual carefully for your reference!
Rocking Massage Chair
Model:LY-003BN
USER MANUAL
"'5&34"-&44&37*$&
1MFBTFEPOPUIFTJUBUFUPDPOUBDUVTJGZPVIBQQFOUPSVOJOUPBOZ
QSPCMFNT
&NBJMTVQQPSU!KYQNBTTBHFSDPN
8FCXXXKYQNBTTBHFSDPN
0VSDVTUPNFSTFSWJDFSFQSFTFOBUJWFTBSFBMXBZTSFBEZUPIFMQ
5IBOLZPVGPSZPVSTVQQPSU
LY-003BM LY-003BP
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
◆ NECK PART:
Adjustable pillow
◆ BACK PART:
1.Kneading&Tapping
2.Infrared Heating
◆ HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
◆ LEG PART:
Five angles to adjust differnet position for relaxing your leg.
◆ 15 mins time limited
◆ NECK PART:
Adjustable pillow
◆ BACK PART:
1.Kneading&Tapping
2.Infrared Heating
◆ HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
◆ LEG PART:
Five angles to adjust differnet position for relaxing your leg.
◆ 15 mins time limited
Model：LY-003BM
Model：LY-003BP
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
2
3
R
1.Kneading&Tapping Massage Mode
Press this button by starting kneading and tapping massage.
2.Kneading&Tapping Massage Speed
Provides 3 different massage speed: Slow,Middle,Fast
3.2 Different Modes
Press this button by starting change 2 different kneading and
tapping massage,the bidirectional massage head will
provides 2 different massage techniques to relief sore
muscles.
4.Heat Therapy
Improve metabolism rate
5.Vibration Massage
To relax your and thighs
6.Massage Intensity
Select your desired massage intensity levels.
7.Power ON/OFF and Auto Programme
Switch ON or OFF the machine.
Press this button by starting working automatically.
Model：LY-003BM
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
Notes
Before use zPlease read carefully the instruction before use.
Practice
z
Working 20 minutes every day at the beginning
stage and more time step by step; do not exceed
20 minutes for safety.
zCould place one folded towel or blanket on back
in case of too strong massage pressure.
Longer
Life
zPlease let the machine be rest for 20 minutes
after 40 minutes operation so to ensure of longer
life of machine.
After Use
zPlease turn-off power and then pull out the plug
after usage; please do pull the plug from the
socket and do not pull the wire.
Place to put
zPlease do not operate the massager where with
much dust, oil crust, fog.
zPlease do not put the massager near to electric
appliance.
zPlease do not put the massager where under
direct sunshine
zPlease do not use the massager where with
much humidity ( like hot spring, swimming pool,
bathroom etc ).
zPlease do not use the massager outdoor.
zPlease do not operate the massager where with
fog and lack of oxygen.
Notes
Suitable
for the
crowd
zThose who feel uncomfortable, been operation or
be injured on back, neck, please consult with
doctor before using.
zDo not use within one hour after lunch/dinner.
zThe following people please use the massager
after consulting with doctor or specialist :
a) with cancer b˅heart disease
zPay much attention when the massager is
running, especially for patients or those without
ability of operation.
zYou are suggested to wear baggy clothes when
using the massager; Do not use it nakedly which
might cause hurt to your skin; Too thick or thin
clothes or those with collar, belt or other hard
objects should also be avoided because they
might affect massage effects.
zProhibit using for kids and those pregnant
women
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
2
1
5
6
3
4
1.Power ON/OFF and Auto Programme
Switch ON or OFF the machine.
Press this button by starting kneading massage,vibration
and heating function.
2.2D Keading Massage for Full Body
Press this button by starting 2D kneading massage for full
body and the bidirectional massage head will provides 2
different massage techniques to relief sore muscles.
3.Kneading Massage for Top Part of Back
Press this button by starting kneading massage for top part
of back.
4.Kneading Massage for Lower Back
Press this button by starting kneading massage for lower
back.
5.Vibration Massage
Press this button by starting vibration massage to relax your
and thighs
6.Heat Therapy
Press this button by starting heating function to improve
metabolism rate
Tips:Product powered on, on/off indicator light will flash
indicating that the back massage movement is being reset.
Reset completed, the indicator light will be off, the product
will be in the standby state.
Functions
NECK PART:
Adjustable pillow.
BACK PART:
1.Eight kneading heads working .
2.Infrared heating.
HIP PART:
Two vibration intensities supply comfortable vibration on the thighs.
LEG PART:
Five angles to adjust different position for relaxing your leg.
15 mins time limited.
Controller
Auto
Auto
Hip
LMH
Vibration
Heat
Back
Mode
Strength
Speed
Kneading
1.Back Massage Programme
Change the direction kneading heads.
2.Kneading Massage Mode
Provides 2 different massage techniques
to relief sore muscles.
To relax your and thighs.
7.Power ON/OFF And Auto Programme
Switch ON or OFF the machine.
5. Vibration Massage
Press this button by starting working
automatically.
3.Kneading Massage Speed
Provides 3 different massage speed:
fast and slow.
6.Massage Intensity
Select your desired massage intensity levels.
4.Heat Therapy
Improve metabolism rate.
How to operate
1. Open the packing ,place the massage chair in a flat place &
assemable.
2. Connect the DC with the adaptor.
3. Connect the adaptor with the power.
4. Press the button on controller to start working.
Model：LY-003BP
Notes
Before use zPlease read carefully the instruction before use.
Practice
z
Working 20 minutes every day at the beginning
stage and more time step by step; do not exceed
20 minutes for safety.
zCould place one folded towel or blanket on back
in case of too strong massage pressure.
Longer
Life
zPlease let the machine be rest for 20 minutes
after 40 minutes operation so to ensure of longer
life of machine.
After Use
zPlease turn-off power and then pull out the plug
after usage; please do pull the plug from the
socket and do not pull the wire.
Place to put
zPlease do not operate the massager where with
much dust, oil crust, fog.
zPlease do not put the massager near to electric
appliance.
zPlease do not put the massager where under
direct sunshine
zPlease do not use the massager where with
much humidity ( like hot spring, swimming pool,
bathroom etc ).
zPlease do not use the massager outdoor.
zPlease do not operate the massager where with
fog and lack of oxygen.
Notes
Suitable
for the
crowd
zThose who feel uncomfortable, been operation or
be injured on back, neck, please consult with
doctor before using.
zDo not use within one hour after lunch/dinner.
zThe following people please use the massager
after consulting with doctor or specialist :
a) with cancer b˅heart disease
zPay much attention when the massager is
running, especially for patients or those without
ability of operation.
zYou are suggested to wear baggy clothes when
using the massager; Do not use it nakedly which
might cause hurt to your skin; Too thick or thin
clothes or those with collar, belt or other hard
objects should also be avoided because they
might affect massage effects.
zProhibit using for kids and those pregnant
women
Notes
Before use zPlease read carefully the instruction before use.
Practice
z
Working 20 minutes every day at the beginning
stage and more time step by step; do not exceed
20 minutes for safety.
zCould place one folded towel or blanket on back
in case of too strong massage pressure.
Longer
Life
zPlease let the machine be rest for 20 minutes
after 40 minutes operation so to ensure of longer
life of machine.
After Use
zPlease turn-off power and then pull out the plug
after usage; please do pull the plug from the
socket and do not pull the wire.
Place to put
zPlease do not operate the massager where with
much dust, oil crust, fog.
zPlease do not put the massager near to electric
appliance.
zPlease do not put the massager where under
direct sunshine
zPlease do not use the massager where with
much humidity ( like hot spring, swimming pool,
bathroom etc ).
zPlease do not use the massager outdoor.
zPlease do not operate the massager where with
fog and lack of oxygen.
Notes
Suitable
for the
crowd
zThose who feel uncomfortable, been operation or
be injured on back, neck, please consult with
doctor before using.
zDo not use within one hour after lunch/dinner.
zThe following people please use the massager
after consulting with doctor or specialist :
a) with cancer b˅heart disease
zPay much attention when the massager is
running, especially for patients or those without
ability of operation.
zYou are suggested to wear baggy clothes when
using the massager; Do not use it nakedly which
might cause hurt to your skin; Too thick or thin
clothes or those with collar, belt or other hard
objects should also be avoided because they
might affect massage effects.
zProhibit using for kids and those pregnant
women
03 04
Notes
Before use zPlease read carefully the instruction before use.
Practice
z
Working 20 minutes every day at the beginning
stage and more time step by step; do not exceed
20 minutes for safety.
zCould place one folded towel or blanket on back
in case of too strong massage pressure.
Longer
Life
zPlease let the machine be rest for 20 minutes
after 40 minutes operation so to ensure of longer
life of machine.
After Use
zPlease turn-off power and then pull out the plug
after usage; please do pull the plug from the
socket and do not pull the wire.
Place to put
zPlease do not operate the massager where with
much dust, oil crust, fog.
zPlease do not put the massager near to electric
appliance.
zPlease do not put the massager where under
direct sunshine
zPlease do not use the massager where with
much humidity ( like hot spring, swimming pool,
bathroom etc ).
zPlease do not use the massager outdoor.
zPlease do not operate the massager where with
fog and lack of oxygen.
Notes
Suitable
for the
crowd
zThose who feel uncomfortable, been operation or
be injured on back, neck, please consult with
doctor before using.
zDo not use within one hour after lunch/dinner.
zThe following people please use the massager
after consulting with doctor or specialist :
a) with cancer b˅heart disease
zPay much attention when the massager is
running, especially for patients or those without
ability of operation.
zYou are suggested to wear baggy clothes when
using the massager; Do not use it nakedly which
might cause hurt to your skin; Too thick or thin
clothes or those with collar, belt or other hard
objects should also be avoided because they
might affect massage effects.
zProhibit using for kids and those pregnant
women
Notes
Before use zPlease read carefully the instruction before use.
Practice
z
Working 20 minutes every day at the beginning
stage and more time step by step; do not exceed
20 minutes for safety.
zCould place one folded towel or blanket on back
in case of too strong massage pressure.
Longer
Life
zPlease let the machine be rest for 20 minutes
after 40 minutes operation so to ensure of longer
life of machine.
After Use
zPlease turn-off power and then pull out the plug
after usage; please do pull the plug from the
socket and do not pull the wire.
Place to put
zPlease do not operate the massager where with
much dust, oil crust, fog.
zPlease do not put the massager near to electric
appliance.
zPlease do not put the massager where under
direct sunshine
zPlease do not use the massager where with
much humidity ( like hot spring, swimming pool,
bathroom etc ).
zPlease do not use the massager outdoor.
zPlease do not operate the massager where with
fog and lack of oxygen.
Notes
Suitable
for the
crowd
zThose who feel uncomfortable, been operation or
be injured on back, neck, please consult with
doctor before using.
zDo not use within one hour after lunch/dinner.
zThe following people please use the massager
after consulting with doctor or specialist :
a) with cancer b˅heart disease
zPay much attention when the massager is
running, especially for patients or those without
ability of operation.
zYou are suggested to wear baggy clothes when
using the massager; Do not use it nakedly which
might cause hurt to your skin; Too thick or thin
clothes or those with collar, belt or other hard
objects should also be avoided because they
might affect massage effects.
zProhibit using for kids and those pregnant
women
FAQ
Phenomenon How to check How to handle
Sounds like
squeak, ping,
click,
Sound is caused by
motor; normal; no
need to check
N/A
Noise during
massager
Has it been working
for a long time or
continue?
Please turn off power
and be rest over one
hour
Feeling hot on
the surface
Has the working
time exceed time
limit?
Please operate within
time limit
No working or
stop suddenly
during running
1. Power off
2. Temperature
protection
devise
1. insert the plug and
turn on the power
2. turn off power and be
rest over one hour
Please consult the distributor if no use after the above
handling
DANGER
To reduce the risk of electric shock
1. Always unplug the appliance from the electrical outlet innediately
after use and before cleaning.
2. Never use pins or other metallic fasteners with this appliance.
3. Keep dry-Do not opperate in a water or moist condition.
Specifications
Product Name Rocking Massage Chair
Model No. LY-003BN
Voltage 12V 3A
Rated Power 36 W
Time Limited 15 min
Product Size 890(L) X 410(W) X 605(H)
N.W. 22 KG
G.W. 24 KG
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,DO NOT REMOVE
COVER,THERE ARE NO SERVICEABLE PARTS INSIDE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS ITEM TO RAIN OR MOISTURE.
The lightning flash with arriw-head symbol within an equilateral
triangle isintended to alert the user to the presence of uninsul-
ated “dangerous voltage” within the unit’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alertthe use to the presence of important operating and maintenance
(servicing)instructions in the literature accompanying the unit
FAQ
Phenomenon How to check How to handle
Sounds like
squeak, ping,
click,
Sound is caused by
motor; normal; no
need to check
N/A
Noise during
massager
Has it been working
for a long time or
continue?
Please turn off power
and be rest over one
hour
Feeling hot on
the surface
Has the working
time exceed time
limit?
Please operate within
time limit
No working or
stop suddenly
during running
1. Power off
2. Temperature
protection
devise
1. insert the plug and
turn on the power
2. turn off power and be
rest over one hour
Please consult the distributor if no use after the above
handling
DANGER
To reduce the risk of electric shock
1. Always unplug the appliance from the electrical outlet innediately
after use and before cleaning.
2. Never use pins or other metallic fasteners with this appliance.
3. Keep dry-Do not opperate in a water or moist condition.
Specifications
Product Name Rocking Massage Chair
Model No. LY-003BN
Voltage 12V 3A
Rated Power 36 W
Time Limited 15 min
Product Size 890(L) X 410(W) X 605(H)
N.W. 22 KG
G.W. 24 KG
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,DO NOT REMOVE
COVER,THERE ARE NO SERVICEABLE PARTS INSIDE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS ITEM TO RAIN OR MOISTURE.
The lightning flash with arriw-head symbol within an equilateral
triangle isintended to alert the user to the presence of uninsul-
ated “dangerous voltage” within the unit’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alertthe use to the presence of important operating and maintenance
(servicing)instructions in the literature accompanying the unit
05 06
FAQ
Phenomenon How to check How to handle
Sounds like
squeak, ping,
click,
Sound is caused by
motor; normal; no
need to check
N/A
Noise during
massager
Has it been working
for a long time or
continue?
Please turn off power
and be rest over one
hour
Feeling hot on
the surface
Has the working
time exceed time
limit?
Please operate within
time limit
No working or
stop suddenly
during running
1. Power off
2. Temperature
protection
devise
1. insert the plug and
turn on the power
2. turn off power and be
rest over one hour
Please consult the distributor if no use after the above
handling
DANGER
To reduce the risk of electric shock
1. Always unplug the appliance from the electrical outlet innediately
after use and before cleaning.
2. Never use pins or other metallic fasteners with this appliance.
3. Keep dry-Do not opperate in a water or moist condition.
Specifications
Product Name Rocking Massage Chair
Model No. LY-003BN
Voltage 12V 3A
Rated Power 36 W
Time Limited 15 min
Product Size 890(L) X 410(W) X 605(H)
N.W. 22 KG
G.W. 24 KG
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,DO NOT REMOVE
COVER,THERE ARE NO SERVICEABLE PARTS INSIDE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS ITEM TO RAIN OR MOISTURE.
The lightning flash with arriw-head symbol within an equilateral
triangle isintended to alert the user to the presence of uninsul-
ated “dangerous voltage” within the unit’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alertthe use to the presence of important operating and maintenance
(servicing)instructions in the literature accompanying the unit
FAQ
Phenomenon How to check How to handle
Sounds like
squeak, ping,
click,
Sound is caused by
motor; normal; no
need to check
N/A
Noise during
massager
Has it been working
for a long time or
continue?
Please turn off power
and be rest over one
hour
Feeling hot on
the surface
Has the working
time exceed time
limit?
Please operate within
time limit
No working or
stop suddenly
during running
1. Power off
2. Temperature
protection
devise
1. insert the plug and
turn on the power
2. turn off power and be
rest over one hour
Please consult the distributor if no use after the above
handling
DANGER
To reduce the risk of electric shock
1. Always unplug the appliance from the electrical outlet innediately
after use and before cleaning.
2. Never use pins or other metallic fasteners with this appliance.
3. Keep dry-Do not opperate in a water or moist condition.
Specifications
Product Name Rocking Massage Chair
Model No. LY-003BN
Voltage 12V 3A
Rated Power 36 W
Time Limited 15 min
Product Size 890(L) X 410(W) X 605(H)
N.W. 22 KG
G.W. 24 KG
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,DO NOT REMOVE
COVER,THERE ARE NO SERVICEABLE PARTS INSIDE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS ITEM TO RAIN OR MOISTURE.
The lightning flash with arriw-head symbol within an equilateral
triangle isintended to alert the user to the presence of uninsul-
ated “dangerous voltage” within the unit’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alertthe use to the presence of important operating and maintenance
(servicing)instructions in the literature accompanying the unit
FAQ
Phenomenon How to check How to handle
Sounds like
squeak, ping,
click,
Sound is caused by
motor; normal; no
need to check
N/A
Noise during
massager
Has it been working
for a long time or
continue?
Please turn off power
and be rest over one
hour
Feeling hot on
the surface
Has the working
time exceed time
limit?
Please operate within
time limit
No working or
stop suddenly
during running
1. Power off
2. Temperature
protection
devise
1. insert the plug and
turn on the power
2. turn off power and be
rest over one hour
Please consult the distributor if no use after the above
handling
DANGER
To reduce the risk of electric shock
1. Always unplug the appliance from the electrical outlet innediately
after use and before cleaning.
2. Never use pins or other metallic fasteners with this appliance.
3. Keep dry-Do not opperate in a water or moist condition.
Specifications
Product Name Rocking Massage Chair
Model No. LY-003BN
Voltage 12V 3A
Rated Power 36 W
Time Limited 15 min
Product Size 890(L) X 410(W) X 605(H)
N.W. 22 KG
G.W. 24 KG
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,DO NOT REMOVE
COVER,THERE ARE NO SERVICEABLE PARTS INSIDE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS ITEM TO RAIN OR MOISTURE.
The lightning flash with arriw-head symbol within an equilateral
triangle isintended to alert the user to the presence of uninsul-
ated “dangerous voltage” within the unit’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alertthe use to the presence of important operating and maintenance
(servicing)instructions in the literature accompanying the unit
18
20
LY-003BM LY-003BP
07 08
SIZE
65
105
100
65
105
100
Foot Support Unfold Size 100x105x65cm
09 10
Foot Support Fold Size 100x123x65cm
65
100
123
11 12
13 14
ASSEMBLY INSTRUCTIONS
Step 1:Check the accessories bag Step 2: Lay chair back seat sideways on the floor
Tips:The back seat should be placed on the floor at a certain Angle,
otherwise it is easy to roll over.
1 pcs Socket head screw wrench
6 pcs Short screw
2 pcs Long screw
2 pcs Hammer head nut
4 pcs Wooden pin
Adjustable Angle by rotation
Back seat
floor
15 16
Step 3: Tips1: When locking in, the wooden handrail L needs to be properly raised, and the end of the
screw and the LA1 hole that can be seen through the wooden handrail L shall prevail, so
that the short screw can be inserted into the LA1 hole visually.
Tips2: Only be rotated 3-5 circles, otherwise the subsequent screws will not be easily locked in
Socket head screw wrench
wooden handrail L
Short screw
LA hole
LA1 hole
Socket head screw wrench
End of short screw
LA hole
LA1 hole
Place the wooden handrail L on the back seat, insert the
short screw into the LA1 hole, use an Allen wrench to lock it
into the thread in the LA1 hole clockwise and rotate 3-5 turns
Socket head screw wrenchSocket head screw wrenchSocket head screw wrench
17 18
Tips1: When locked in, because the screw in the LA1 hole is not locked, the wooden handrail L can be
properly raised, and the short screw can be inserted into the LB1 hole visually.
Tips2: It must be installed according to the specified holes, and the order cannot be wrong, otherwise
the subsequent screws will not be easily locked;
Tips3: Only be rotated 3-5 circles, otherwise the subsequent screws will not be easily locked in
Step 4: Manually adjust the angle of the back seat, adjust the posi-
tion of the wooden armrest L, insert the short screw into the
LB1 hole, use the Allen wrench to lock the thread in the LB1
hole clockwise, and rotate 3-5 turns
Tips: When locked in, since the screws in the LA1 hole and the LB1 hole are not locked, the wooden
handrail L can be properly raised, and the short screw can be inserted into the LC1 hole visually;
Step 5: Manually adjust the angle of the back seat, adjust the posi-
tion of the wooden armrest L, insert the short screw into the
LC1 hole, use the Allen wrench to lock the thread in the LC1
hole clockwise, and rotate 3-5 turns
Socket head screw wrench
End of short screw
LB hole
LB1 hole
Adjustable Angle by rotation
Socket head screw wrench
End of short screw
LC hole
LC1 hole
Adjustable Angle by rotation
19 20
Tips: When locking, it is necessary to make the 1-shaped groove of the hammer nut and the long screw
in the same direction, so that the long screw can be smoothly locked into the hammer nut
Step 6: 1.Insert the wooden pin into the wooden pin hole of the
crosspiece and insert the hammer nut into the hammer nut
hole of the crosspiece
2.Connect the rung to the handrail L by means of two
wooden dowels
3.Insert the long screw through the LD hole, insert it into the
LD1 hole, and use an Allen wrench to lock it into the hammer
nut clockwise
Long screw
Long screw
Hammer head nut
keep the 1-shaped hammer head nut and
long screw in the same direction
LD1 hole
Hammer head nut hole
Wooden pin
Wooden pin hole
rung
LD1 hole
Hammer head nut
Socket head screw wrench
LD hole
LD1 hole
1-shaped hammer head nut
21 22
Tips1: When locking, it is necessary to make the 1-shaped groove of the hammer nut and the long
screw in the same direction, so that the long screw can be smoothly locked into the hammer
nut
Tips2: Only be rotated 3-5 circles,cannot be locked, otherwise the subsequent screws will not be
easily locked in
Step 7: Tighten the short screw in the LA hole, LB hole, LC hole, LD
hole in sequence
Step 8: 1.Turn the chair over 180°, place it on the floor, and place the
wooden armrest R on the back seat
2.Refer to the installation step 6, insert the long screw
through the RD hole and insert it into the RD1 hole, use the
Allen wrench to lock the hammer nut clockwise, and rotate
3-5 turns
LD void long screw
LA void short screw
LB void short screw
LC void short screw
Back seat
wooden handrail R Socket head screw wrench
RD hole
Long screw
RD1 hole
24
Tips1: The short screws only be rotated 3-5 circles cannot be locked and need in order , otherwise
the subsequent screws will be difficult to lock in
Tips2: After all the screws are locked and rotated 3-5 turns, then tighten all the screws in turn
Step 9: 1.Referring to installation steps 3, 4 and 5, insert the short
screw through the RA hole, insert it into the RA1 hole, and
rotate 3-5 turns clockwise; insert the short screw through the
RB hole, insert it into the RB1 hole, and rotate clockwise 3-5
turns; Insert the short screw through the RC hole, insert it
into the RC1 hole, and turn it clockwise for 3-5 turns
2.Referring to installation step 7, tighten the short screws in
the RA hole, the short screws in the RB holes, the short
screws in the RC holes, and the long screws in the RD holes
in sequence.
Step 10: Check all screws make sure are all locked
RC hole
RC1 hole
RB1 hole RA1 hole
RB hole RA hole
23
This manual suits for next models
1
Table of contents
