JYK ST14097-1 User manual

Instruction Manual
PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE USE
AND KEEP IT FOR FUTURE REFERENCE.
3-Speed Vintage
Bluetooth Turntable
Model: ST14097-1
JYK

CONTENTS
SAFETY INSTRUCTIONS ................................................................................ 2
SPECIFICATIONS ............................................................................................ 3
TURNTABLE LAYOUT...................................................................................... 4
TURNTABLE OPERATION ............................................................................... 5
POWER SUPPLY ........................................................................................ 5
BASIC OPERATION .................................................................................... 5
TURNTABLE NEEDLE REPLACEMENT..................................................... 5
BLUETOOTH OPERATION .............................................................................. 6
AUX-IN OPERATION........................................................................................ 6
HEADPHONE OPERATION.............................................................................. 6
FCC STATEMENT ............................................................................................ 6
CALIFORNIA PROP 65 WARNING.................................................................. 6
2
3
4
5
5
5
5
6
6
6
7
7

SAFETY INSTRUCTIONS
1. Read these instructions - All the safety and operating instructions should be
read before this product is operated.
2. Keep these instructions - The safety and operating instructions should be
retained for future reference.
3. Heed all warnings - All warnings on the appliance and in the operating
instructions should be adhered to.
4. Follow all instructions - All operating and use instructions should be followed.
5. Do not use this apparatus near water - The appliance should not be used near
water or moisture - for example, in a wet basement, near a swimming pool, or
near other wet areas.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Keep at least 5 cm around the apparatus
for sufficient ventilations. Install in accordance with the manufacturer?s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding plug. A polarized
plug has two blades with one wider than the other. A grounding plug has two
blades and a third grounding prong. The wide blade or the third prong is
provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the
plugs, convenience receptacles, and at the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart or rack is
used, use caution when moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug the apparatus during lightning storms or when unused for long periods
of time.
14. Refer all servicing to qualified personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
15. Please keep the unit in a well ventilated environment.
16. Only use attachments/accessories specified or provided by the manufacturer
17. To reduce the risk of fire or electric shock, do not expose this apparatus to rain
or moisture. The apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall not be placed on apparatus.
18. The main plug is used as disconnect device, the disconnected device shall
remain readily operable.
19. This product is not intended for commercial use. Household Use Only.
2

21. This equipment is a Class II or double insulated electrical appliance.
It has been designed in such a way that it does not require a safety
connection to electrical earth.
22.
Warning: To reduce the risk of fire or electrical shock, do not exposed the apparatus
to rain or moisture. No naked flame sources such as candles shall be
placed on top of the apparatus.
Caution: Changes or modifications not expressly approved by the manufacturer
could void the user?s authority to operate this device. Usage of controls or
adjustments or performance of procedures other than those specified
herein may result in hazardous exposure. ɼ50-60Hz
Power Supply: ............................................................ AC Adaptor: 100-240
SPECIFICATIONS
................................................................................... DC- 5V 1A
Speaker Impedance: .................................................. 4ohm, 3W
Max Power Consumption:.......................................... 6W
Included:..................................................................... Turntable, Instruction Manual,
AC Adaptor
Design and specification are subject to change without notice.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Other trademarks and trade names are those of their respective owners.
The lightning flash with arrowhead within an
equilateral triangle is intended to alert the user
to the presence of uninsulated 揹angerous
voltage?within the product?s enclosure that
may be of sufficient magnitude to constitute a
risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO PREVENT
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PROFESSIONAL.
3

4
1. TURNTABLE PLATTER
2. TURNTABLE SHAFT
3. 45 RPM ADAPTOR
4. LIFT LEVER
5. TONE ARM CLIP
6. LINE-IN JACK
7. SPEED SELECTION SWITCH
8. FUNCTION (BT (BLUETOOTH), LINE-IN, PHONO) KNOB
9. AUTO AND MANUAL STOP SELECTION SWITCH
10. TONE ARM
11. POWER ON/OFF AND VOLUME CONTROL KNOB
12. POWER/BLUETOOTH LIGHT INDICATOR
13. STYLUS CARTRIDGE
14. HEADPHONE JACK
15. BUCKLE & SNAPS
16. HANDLE
17. SPEAKERS
18. RCA OUTPUT JACK
19. POWER ADAPTOR JACK
TURNTABLE LAYOUT

TURNTABLE OPERATION
POWER SUPPLY
Insert the adaptor plug into the DC IN jack on the rear of the unit, then connect the
AC/DC adaptor (5V, 1A / AC100-240V, 50-60Hz) to a AC/DC wall outlet.
BASIC OPERATION
1. Lift the BUCKLE on the front of the turntable and open the lid.
2. Power on the unit by turning the VOLUME CONTROL KNOB clockwise. The red
LED will light to show that the turntable is turned on. Turn the FUNCTION KNOB
to the PHONO position. NOTE: LED will be blue if switched on in Bluetooth mode.
3. Place a record on the TURNTABLE PLATTER and select the desired speed (33 1/3 /
45 / 78) by sliding the SPEED SELECTION SWITCH according to the record.
NOTE: When playing a 45 rpm record, use the included 45 RPM ADAPTOR
located in the holder near the tone arm.
4. Open the TONE ARM CLIP to release the TONE ARM. Push the LIFT LEVER
backwards to raise the arm. Gently move the tone arm to the desired position
over the record. The turntable will begin to spin when the arm is moved toward
the record. Push the lift lever forward and lower the arm slowly onto the desired
position on the record to begin playing.
Please Note: The record will begin to spin only when the tone arm is moved over
the record if the Auto Stop is turned ON.
5. If the AUTO AND MANUAL STOP SELECTION SWITCH is turned ON, the record
will stop automatically when finished. If this switch is OFF the record will NOT
stop automatically when finished.
NOTE: Some Records DO NOT allow AUTO STOP. In some circumstances,
even though you have AUTO STOP selected the record will continue to spin.
6. To select the volume level, turn the VOLUME CONTROL KNOB to adjust the volume.
HOW TO REPLACE THE TURNTABLE NEEDLE
Removing the Stylus from the Cartridge
1. Place a screwdriver at the tip of the stylus and push downward as shown in
direction "A" WARNING: when applying force to stylus, too much may damage
or break the stylus.
2. Remove the stylus by pulling the stylus forward and pushing downward.
Installing the Stylus
1. Hold the tip of the stylus and insert the stylus by pressing as shown in direction 揃?
2. Push the stylus upward as in direction "C" until the stylus locks into the tip position.
5
Guide Pins (Inside)

6
BLUETOOTH OPERATION
An external device with Bluetooth Connectivity can be wirelessly connected to this
apparatus using the Bluetooth function.
1. Power ON the unit by turning the VOLUME CONTROL KNOB clockwise. The red
LED will light to show that the turntable is turned ON.
2. Turn the FUNCTION KNOB to the BT (Bluetooth ) position, the blue LED light will
begin to flash.
3. Turn your external device’s Bluetooth Setting ON. Wait a moment, then look for
the Bluetooth pairing name “Vintage Turntable”
4. Select the Bluetooth pairing name, to connect the unit. Once connected, the
blue LED light will stop flashing.
5. You are now connected to your external device via Bluetooth!
6. Rotate the VOLUME CONTROL KNOB to adjust the sound level.
An external (auxiliary) audio source (i.e. personal CD/MP3 Player/Mobile phone or
AUX-IN OPERATION
computer) can be connected to this apparatus via the LINE-IN JACK.
1. Plug a detachable Aux-In Cable (not provided) into the LINE-IN socket on the
function panel of the apparatus.
2. Turn the FUNCTION KNOB to the LINE-IN position.
3. Plug the other end of the Aux Cable into the Headphone or Line Out socket of
your External Source.
4. Power ON the unit by turning the VOLUME CONTROL KNOB clockwise. The red
LED will light to show that the turntable is turned ON.
5. Rotate the VOLUME CONTROL KNOB to adjust the sound level.
HEADPHONE OPERATION
Plug the headphone jack into the headphone port on the function panel to listen to
the record. The built-in speaker will stop playing once the headphones are
plugged in.
NOTE: For best performance and product maintenance, unplug the turntable when
not in use.
R

FCC STATEMENT
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio or television reception, which can be
determined by turning the equipment OFF and ON, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
"WARNING" This product contains a chemical known to the State of California to
CALIFORNIA PROP 65 WARNING
cause birth defects or other reproductive harm. For more information on these
regulations and a list of chemicals, log on the following website address:
http://www.oehha.ca.gov/prop65.html
WARRANTY
7
