Kaba B-eco User manual

B-eco
Manual
04043988 - 02/2014 EN

© Copyright by
Kaba GmbH
Albertistraße 3
D-78056 Villingen-Schwenningen
Phone [phone]
Fax [phone]
www.kaba.com/workforce-management
All rights reserved. The document and its parts are copyrighted. Only Kaba GmbH has the right to commercialize,
market and distribute this document. This document, or any part of it, may not be copied or reproduced, adapted,
arranged, reworked or modified without the prior consent of Kaba GmbH.
All company, trademark or product names are trademarks or registered trademarks of their respective owners and are
protected.
Subject to technical changes without notice!
Order no. 04043988 - 02/2014

1About this manual ............................................................................................................................ 7
2Grouped safety messages................................................................................................................ 9
2.1 Use as directed .....................................................................................................................................................9
2.2 Mounting and Installation................................................................................................................................9
2.3 Service and Maintenance .................................................................................................................................9
2.4 Handling lithium batteries ............................................................................................................................ 10
2.5 ESD (electrostatic discharge) protective measures...............................................................................10
2.6 Environmental protection ............................................................................................................................. 11
3Product description........................................................................................................................ 12
3.1 B-eco ..................................................................................................................................................................... 12
3.2 Technical data.................................................................................................................................................... 13
3.2.1 System.................................................................................................................................................. 13
3.2.2 Inputs / Outputs ............................................................................................................................... 13
3.2.3 Interface .............................................................................................................................................. 14
3.2.4 Reader .................................................................................................................................................. 14
3.2.5 Power supply..................................................................................................................................... 15
3.2.6 Uninterruptible power supply (option).................................................................................... 15
3.2.7 Environmental conditions............................................................................................................. 15
3.2.8 Dimensions ........................................................................................................................................ 16
3.3 Conformity.......................................................................................................................................................... 19
3.4 Labeling............................................................................................................................................................... 21
4Design and Function.......................................................................................................................22
4.1 Device structure................................................................................................................................................ 22
4.1.1 Terminal front.................................................................................................................................... 23
4.1.2 Terminal rear...................................................................................................................................... 23
4.2 System connection .......................................................................................................................................... 24
4.2.1 Communication principle ............................................................................................................. 24
4.2.2 Parameterization.............................................................................................................................. 24
4.2.3 User rights........................................................................................................................................... 24
4.2.4 Terminal data..................................................................................................................................... 25
4.2.5 Operating modes ............................................................................................................................. 25
4.3 Device variants and options ......................................................................................................................... 26
4.3.1 Hardware variants............................................................................................................................ 26
4.4 Terminal software............................................................................................................................................. 29
4.4.1 Terminal software variants............................................................................................................ 29
4.4.2 Software options.............................................................................................................................. 30
4.4.3 License file.......................................................................................................................................... 31
5Installation ......................................................................................................................................32
5.1 Installation conditions .................................................................................................................................... 32
5.1.1 General ................................................................................................................................................ 32
5.1.2 Installation site.................................................................................................................................. 32
5.1.3 Connections....................................................................................................................................... 33
5.1.4 Cable entry ......................................................................................................................................... 33
5.2 Installation lines................................................................................................................................................ 34
5.2.1 Ethernet............................................................................................................................................... 34
5.2.2 Inputs - Outputs................................................................................................................................ 34
5.3 Attach mounting plate ................................................................................................................................... 35
5.4 Inserting batteries ............................................................................................................................................ 37

5.5 Connections....................................................................................................................................................... 38
5.5.1 Connecting an external reader ...................................................................................................39
5.6 Fastening the terminal housing to the mounting plate ..................................................................... 40
5.7 Fastening of devices with additional sealing (IP54 version).............................................................. 41
6Start-up ........................................................................................................................................... 42
6.1.1 Service switch.................................................................................................................................... 42
6.1.2 Cold start............................................................................................................................................. 43
6.1.3 Starting the service mode............................................................................................................. 43
6.1.4 Starting the service mode and setting the service IP address.......................................... 43
6.1.5 Starting the terminal software / warm start............................................................................ 43
6.2 Network access requirements ..................................................................................................................... 44
6.2.1 Communication................................................................................................................................ 44
6.2.2 Comparing finger templates........................................................................................................ 44
6.2.3 1-click installation............................................................................................................................ 44
6.2.4 Configuration.................................................................................................................................... 44
6.3 1-click installation ............................................................................................................................................ 45
6.3.1 Start-up procedure.......................................................................................................................... 45
6.4 Manual settings ................................................................................................................................................ 46
6.5 Configuration-specific settings ................................................................................................................... 47
6.5.1 Ethernet settings.............................................................................................................................. 47
6.5.2 Host interface.................................................................................................................................... 48
6.5.3 Reader settings................................................................................................................................. 48
6.6 Setting the screen contrast........................................................................................................................... 49
7Operation........................................................................................................................................ 50
7.1 Operating elements ........................................................................................................................................ 50
7.2 Keypad................................................................................................................................................................. 50
7.3 RFID reader......................................................................................................................................................... 51
7.4 Swipe reader...................................................................................................................................................... 51
7.4.1 Biometric reader............................................................................................................................... 52
7.4.2 Finger position.................................................................................................................................. 52
7.4.3 Operator guidance .......................................................................................................................... 53
7.4.4 Displaying error states ................................................................................................................... 53
7.5 Operating sequences...................................................................................................................................... 54
7.5.1 Basic state........................................................................................................................................... 54
7.5.2 Active function.................................................................................................................................. 54
7.5.3 Active booking.................................................................................................................................. 55
7.5.4 Booking response ............................................................................................................................ 55
7.6 Keypad entries................................................................................................................................................... 56
7.6.1 Numeric input................................................................................................................................... 56
7.6.2 Alphanumeric input........................................................................................................................ 56
7.7 Local enrollment............................................................................................................................................... 57
7.7.1 Call up and requirements.............................................................................................................. 57
7.7.2 Biometric management functions ............................................................................................. 57
8Maintenance ................................................................................................................................... 61
8.1 Buffer battery..................................................................................................................................................... 61
8.1.1 Battery change.................................................................................................................................. 62
8.2 Replacing the UPS batteries ......................................................................................................................... 63
8.3 Cleaning the housing...................................................................................................................................... 64
9Packaging / returns ........................................................................................................................ 65
9.1 Complete devices............................................................................................................................................. 65
9.2 Electronic assemblies...................................................................................................................................... 65

9.3 Labeling............................................................................................................................................................... 66
10 Disposal ...........................................................................................................................................67
11 Index ................................................................................................................................................ 68

Manual About this manual
B-eco 04043988 - 02/2014 7
1About this manual
Validity This manual describes the Kaba B-eco terminal starting from
Manufacturing date: February 2014
Serial number: 079940-000100
Service module version: 697-00-X-K07
B-Client PDC6 version: 766-01-X-K00
767-01-X-K00
This manual describes all device versions and optional equipment and functions.
Options must be purchased and are therefore only available if they were purchased.
Additional equipment and functions may not yet be available at the time of issuing
the manual and can possible only be purchased at a later stage.
Addressees This manual is written exclusively for specialists.
The descriptions in this manual are intended for personnel trained by the
manufacturer. The information in this manual cannot substitute the product
training.
The contents of this manual is intended for use by the following groups of people:
• Project manager
Project manager who is responsible for the system and entrusted with
project planning and realization.
• Fitter
Person specialized in mounting and installation.
Person who has an adequate technical training and sufficient experience and
who has been authorized by the manufacturer after completing the training
on the product.
• Service technician
Specialist for initial set-up and maintenance of the installation.
Person who has an adequate technical training and sufficient experience and
who has been authorized by the manufacturer after completing the training
on the product.
• Network administrator
Realizes the set-up of the device within the network and makes sure that the
devices are accessible within the network.
• Software partner
Specialists for connecting the system to the user software by defining
operating and booking sequences, programming the customer applications
and setting the parameters of the devices.
Important!
For reasons of device safety, some of the activities might only be carried out by the
SERVICE PERSON.
Only persons of the groups "Fitter" and "Service technician" have the status of a
SERVICE PERSON according to DIN EN 60950-1:2006.

About this manual Manual
8 04043988 - 02/2014 B-eco
Contents and purpose The contents is limited to the assembly, installation, start-up, and basic operation of
the hardware.
Additional documentation Terminal software:
• B-Client PDC6 software manual, order number 04043881.
Service functions and FTP access:
• BECO Service Module manual, order number 04106694.
Orientation in the manual This manual contains the following orientation aids to facilitate finding of specific
topics:
• The table of contents at the beginning of the manual gives an overview of all
topics.
• The header always contains the respective main chapter.
• An index in the alphabetical order is given at the end of the manual.
Danger categories Remarks with specifications or rules and restrictions to prevent injuries and property
damage are particularly marked.
Please read the danger warnings and user tips carefully. This information will help
prevent accidents and damage to your equipment.
Danger warnings are divided into the following categories.
CAUTION
Describes a possibly dangerous situation that can lead to minor injuries.
NOTICE!
Important information for proper handling of the product.
Ignoring this information can cause device malfunction and the device or something
near it can get damaged.
Symbols Depending on the source of danger, warnings are marked with symbols of the
following meaning.
General danger
Danger for electronic
components due to
electrostatic discharge
Remarks Please pay special attention to the remarks that are marked with symbols.
Tips and useful information.
This information will help you to best use the product and its functionality.

Manual Grouped safety messages
B-eco 04043988 - 02/2014 9
2Grouped safety messages
The device has been built in accordance with state-of-the-art standards and the
recognized safety rules. Nevertheless, its use may constitute a risk to persons and
cause damage to material property.
Read and observe the following safety instructions, before using the product.
2.1 Use as directed
The device or system is only intended for usage as described in chapter ”Product
description.”
Any use beyond the designated use is not according to rules. The manufacturer is not
responsible for damages resulting from improper use. The user/operator is
responsible for any risks associated with non-duly use.
2.2 Mounting and Installation
Mounting and installation may only be carried out by the SERVICE PERSON (see
chapter 1 / Addressees).
Installation may only be carried out in places that fulfill climatic and technical
conditions stated by the manufacturer.
Kaba GmbH is not liable for damages resulting from improper handling or incorrect
installation.
2.3 Service and Maintenance
Maintenance work / troubleshooting
Only the SERVICE PERSON (see chapter 1 / Addressees) is entitled to remove faults
and carry out the maintenance work.
Reconstruction and modification
Any reconstruction and modification of the device may only be realized by the
SERVICE PERSON (see chapter 1 / Addressees). All reconstructions and modifications
carried out by unauthorized personnel shall render void any liability.

Grouped safety messages Manual
10 04043988 - 02/2014 B-eco
2.4 Handling lithium batteries
The device has a lithium manganese dioxide battery, type CR2032, to buffer the
memory. The battery is on the rear of the terminal housing.
CAUTION
Lithium batteries can rupture or burst like an explosive.
Improper handling of lithium batteries can cause fire and explosions.
• Lithium batteries may only be replaced by the SERVICE PERSON.
• They may only be replaced by batteries of the same type.
• Do not open, bore through, or crush lithium batteries.
• Do not burn lithium batteries or expose them to high temperatures.
• Do not short-circuit lithium batteries.
• Do not recharge the lithium batteries.
2.5 ESD (electrostatic discharge) protective measures
NOTICE!
Danger for electronic components due to electrostatic discharge.
Improper handling of printed circuit boards or components can cause damages that
lead to complete failures or sporadic errors.
• During installation and repair of the device, the ESD protective measures must
be considered.
The following rules must be considered:
• Wear an ESD wristband when handling electronic components.
Connect the end of the wristband to a discharge socket or an unvarnished
grounded metal component. This way, static charges are discharged from
your body securely and effectively.
• Touch only the edges of circuit boards. Do not touch the circuit board nor the
connector.
• Place all dismantled components on an antistatic surface or in an antistatic
container.
• Avoid contact between circuit boards and clothing. The wristband only
protects the printed circuit boards against electrostatic discharge from your
body, but there is still a risk of damage through electrostatic discharge from
your clothing.
• Transport and dispatch dismantled modules only in electrostatically shielded
protective bags.

Manual Grouped safety messages
B-eco 04043988 - 02/2014 11
2.6 Environmental protection
Please do not dispose of the device in your domestic waste.
Used devices contain valuable materials that should be recycled. Properly dispose of
used devices.
Used-up batteries must be disposed of according to state and local regulations.
Please store the batteries to be disposed of carefully in order to avoid short-circuits,
crushing, or damage to the battery housing.

Product description Manual
12 04043988 - 02/2014 B-eco
3Product description
3.1 B-eco
The terminal has been designed for shop floor data collection (SFDC) functions and
can also perform time and attendance functions or can be used for project time
recording.
The B-Client PDC6 terminal software is used on the terminal. Data records of the
B-Net and B-web terminal series are compatible with the data records used in this
device.
The terminal software can be updated any time via a software update.
In combination with the B-COMM communication software, the device offers a new
and comfortable concept for start-up, subsequent functional upgrades and device
analysis.
To display time data and information, the terminal has a graphic monochrome
display with a resolution of 240 x 128 pixels.
The device has capacitive key fields that are operated by touching the glass front.
The function keys are designed for time and attendance and SFDC.
Time data are entered via a contactless RFID reader, a biometric reader or a swipe
card reader, depending on the version.
An external reader (e.g. CCD scanner) can optionally be connected.
Communication is established via the Ethernet network and power supply via PoE
(Power over Ethernet).
Optionally, the terminal has 1 output (relay) and 2 digital inputs for control functions.

Manual Product description
B-eco 04043988 - 02/2014 13
3.2 Technical data
3.2.1 System
Kaba BECO330 CPU unit with ARM7TDMI processor core
Memory
• 8 MByte Flash
• 16 MByte SDRAM.
• 2 MByte SRAM, buffered
Modified parameters, master records, and data records are retained approximately 6
months without power supply.
Graphic monochrome display
• 240 x 128 pixels resolution.
• Background illumination by white LED.
Capacitive keypad
SFDC version:
• 5 function keys (F1 to F5).
• 4 special keys (grey).
• Numeric keypad with C and E keys.
XML version:
• 5 function keys (F1 to F5).
• 8 special keys (gray).
• Alphanumeric keypad (multiple assignment) with C and E keys.
3.2.2 Inputs / Outputs
1 relay output (optional)
• One potential-free changeover contact.
• Contact rating: 30 V AC / DC; max. 2 A
Only voltages from limited power sources according to EN 60950-1 may be
applied.
2 digital inputs (optional)
• Controllable against GND via dry contact.
• Controllable via external direct voltage, switching level:
− Active input: 0 V to 0.8 V
− Inactive input: 2.5 V to 24 V

Product description Manual
14 04043988 - 02/2014 B-eco
3.2.3 Interface
Ethernet interface
• IEEE802.3 compatible 10BASE-T/100BASE-TX Auto sensing, Auto MDIX.
3.2.4 Reader
Supported RFID technologies (depending on design):
• LEGIC prime/advant
• MIFARE Classic/DESFire
• HID iCLASS
• HID Prox
Biometric reader (optional add on reader)
• Compact Biometric Module (CBM) with integrated database for fingerprints.
Depending on the version, the reader has a storage capacity of 500, 3000 or
5000 persons (2 fingers per person).
The reader is available in 2 versions:
− CBM
− CBM-E with enhanced approvals (PIV-IQS with FBI certification and
FIPS 201-approved template evaluation)
• Supported authentication methods:
− Biometric identification
Swipe card reader (optional add on reader)
• Magnetic stripe track 1, 2, 3
• Barcode redlight
• Barcode infrared
RJ45 connection for external reader
• Interface: RS-232C.
• Communication parameters: 9600, 8, N, 1.
• Power supply for the reader: 5 V DC, max. 300 mA over RJ45 connection.

Manual Product description
B-eco 04043988 - 02/2014 15
3.2.5 Power supply
PoE (Power over Ethernet)
Power supply of the terminal via the 8-wire Ethernet cable (max. 100 m).
• Corresponds to IEEE 802.3 af
• Power consumption class 3, max. power consumption 12.95 W
• Supported powering processes:
− Spare pair powering
over (Fast Ethernet free) wire pairs 4/5 and 7/8
− Phantom powering
over RX wires (1/2) and TX wires (3/6)
Power supply is superimposed to the data signal
3.2.6 Uninterruptible power supply (option)
The optional uninterruptible power supply (UPS) guarantees operation for up to
15 minutes or approx. 200 bookings in case of power failure. Whatever occurs first.
Requirement: New battery, 90% charged, temperature 20 - 25 °C.
The battery is completely charged after 10 hours.
3.2.7 Environmental conditions
• Ingress protection according to IEC 60529:
− IP30
− IP54 (Option for devices with RFID reader)
• Relative humidity:
− 5% to 95%, non-condensing
• Environmental temperature:
− 0 °C – +40 °C (operation)
− -25 °C – +70 °C (storage)

Product description Manual
16 04043988 - 02/2014 B-eco
3.2.8 Dimensions
Terminal housing and mounting plate
All dimensions in mm.
200 11
11
24
43*
150 140
75,5
136,5
109
170,4
6
17,5 24,5
* Deep housing for unit with optional UPS

Manual Product description
B-eco 04043988 - 02/2014 17
Terminal housing with biometric reader and mounting plate
85
200
212
109
4,5
32
78
142
32

Product description Manual
18 04043988 - 02/2014 B-eco
Terminal housing with swipe card reader and mounting plate
200
180
44
41
MagBCD
61,5
188
109
4,5
100
136,5
24,5
33,5
USV

Manual Product description
B-eco 04043988 - 02/2014 19
Konf
3.3 Conformity
This device complies with the following standards:
EN 60950-1/A12:2011
EN 300 330-1 V1.7.1
EN 300 330-2 V1.5.1
EN 301 489-1 V1.4.3
EN 301 489-3 V1.9.2
according to the regulations of the EU Directives
1999/5/EC
R&TTE Directive

Product description Manual
20 04043988 - 02/2014 B-eco
DECLARATION OF CONFORMITY
according to FCC Part 15
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference
• This device must accept any interference received, including interference
that may cause undesired operation.
Please Note:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Device variants
• B-eco with LEGIC FCC ID: NVI-B-ECOL1
• B-eco with MIFARE FCC ID: NVI-B-ECOM1
• B-eco with HID Prox FCC ID: NVI-B-ECOH1
• B-eco with HID iCLASS FCC ID: NVI-B-ECOH2
