Kabel PLUS User manual

Alindair Soğutma Sistemleri San. ve Tic. A.Ş.
reserves the right to change visuals, technical
properties, and all other information about this
product without giving notice.
User Manual
ISTANBUL CENTRAL OFFICE
Oruç Reis Mah. Tekstilkent Cad.
Tekstilkent Ticaret Mrk. No: 10-
H/109
Esenler/Istanbul/TURKEY
Tel: [phone]
www.kabelair.com
www.kabelfan.com
DENİZLİ FACTORY
Pınarkent Mah. 210 Sk.
No:3 Pamukkale/
Denizli/TURKEY
Tel: [phone]
www.kabelair.com
www.kabelfan.com
GAZİANTEP FACTORY
3. OSB Kamil Şerbetçi Blv.
No: 25/27 Şehitkamil/
Gaziantep/TURKEY
Tel: [phone]
www.kabelair.com
www.kabelfan.com
Kabel
Kabel Plus
Evaporative Cooler
100% FRESH AIR
COMFORT

KABEL
100% FRESH AIR
COMFORT
Energy efficiency and environmental
protection
Environment-friendly product that does not
create noise or pollution and does not have a
compressor.
Low operating costs
Its power consumption is 1/10’th of
conventional compression type air
conditioners.
Sensible cooling effect
Its direct cooling effect quickly lowers
temperature.
Easy maintenance
Does not require professional maintenance
equipment.
Maintenance easily carried out with a simple
system.
Fresh air at home
Increases level of oxygen indoors, lowers
temperature, and expels bad odor.
KABEL
TABLE OF CONTENTS
Foreword 1
Cooling Principle 1
Function of Every Part 2
Installation and Use 3
Manual Panel 4
Precautions for Use 5
Cleaning 6
General Problems and Solutions 7
Warranty Attachment 8

KABEL
FOREWORD
Thank you for your trust and support by
choosing our evaporative cooler product.
Please read the instructions for a better use.
Our company reserves the right to make
unannounced changes in appearance and
content of the product covered by these
instructions and in the content.
We hope that our product will bring in more
convenience and comfort to your life.
COOLING PRINCIPLE
KABEL Plus is a high-tech product developed
by our company. The principle of evaporative
cooling has many advantages. Wet pads are
used as evaporator. Wet pads do not just
optimize cooling; they also increase air quality
by filtering dust in the air.
.KABEL
Function of Every Part
Cooling principle: Water pulled from the
pump wets pads with help of separators while
air is pulled inside the appliance with fan. Wet
pads stand at special angles which take in air
current directly while absorbing the large part
of heat to cool down filtered air. Cool, damp,
and fresh air is sent inside. Water that does
not evaporate is sent back to tank to ensure
circulation.

KABEL
Installation and Use
1. Open the box and take out the cooler
2. Adding water: Open water inlet on
the left side of cooler and fill tank
with water. Control level and amount
of water from water level indicator.
Please be careful of the following
while adding water.
Avoid contact of motor and its
surrounding area with water to keep
electrical parts undamaged.
Do not add water above “MAX” level.
Otherwise water would spill out of
appliance.
Make sure you use clean tap water
3. For standby mode plug in and operate
the cooler by pressing on/off button.
Rate of blowing, motion of diffuser
blades, cooling and timing functions
can be set on need.
4. When on/off button is pressed in
operating mode the appliance stops
working and enters standby.
KABEL
Manual Panel
Power
When the appliance is turned on power light
is on and signal sounds once after which the
cooler enters standby.
When ON/OFF button is pressed while
the appliance is plugged in, the cooler starts
working. If the appliance is restarted, it
returns to operating conditions it has while
ON/OFF button is pressed. In any working
mode, the cooler can be turned off by
pressing this button.
When COOL button is pressed the
appliance enters to cooling mode. Button light
is on and fan starts working on low speed.
When SWING L/R button is pressed
ventilation blades start moving and button
light is on. Button is pressed again to stop
diverting air.
When this button is pressed one of the
3 different velocity stages is chosen. (High,
medium, low speed)
With timer button requested operating
time of appliance operation is set.
Can charge 2.0A USB
Using mode button one of the modes
among natural breeze, sleep, and standard is
chosen
Light button turns screen light on and
off

KABEL
Precautions for Use
Pay attention to the following instructions while using this product. Our company
is not liable for damages caused by user errors.
1. Water level must never exceed “MAX” point on display and must not fall
below “MIN” point during cooling.
2. When rate of humidity increases, humidity can be adjusted according to
room temperature.
3. When water is added avoid tilting and/or hitting the appliance while
relocating it to prevent overflowing. In order to prevent accidents do
not turn the appliance upside down.
4. Do not place anything in front of cooler. Do not cover air throw diffuser.
Make sure there are no obstacles closer than one meter to the
appliance while it is operating.
5. If water tank is empty pump would not function when cooling function
is turned on.
6. Cut off the power before cleaning and maintenance.
7. While cleaning outer parts of the appliance use a damp cloth (or with
some detergent) and avoid using corrosive detergents, solvents and
water.
8. If the appliance gets toppled with water inside, pull off the plug
immediately and do not restart before the appliance is completely dry.
9. Air flow openings must not be near walls, curtains, and the like material.
Otherwise will decrease air flow effect.
10. While in use this appliance must not be exposed to impact or shaking.
This might cause automatic shutdown that can be fixed with rebooting.
11. Unplug the appliance from power source when not in use.
Note: No part of the control panel must get wet. Due to high pressure
inside the appliance, it must be unplugged from power source before
cleaning.
12. In case power chord is damaged, it must be replaced by qualified staff of
producer company or maintenance department to avoid accidents.
13. This appliance is not intended for use by persons (including children)
with reduced physical, sensory, or mental capabilities.
14. Do not allow children to play with the appliance.
KABEL
Cleaning
Dust Filter
Unplug the appliance, unbolt, press and pull back tabs of dust filter to
remove the filter. Clean the dust filter with soapy water and a soft brush.
Dry and properly reinstall.
Wet Pad
Unplug the appliance, remove dust filter and pads to rinse with water and
reinstall.
Note: Water pressure must not be high during cleaning. Do not use acidic
or alkali detergent while cleaning the pads.
Water Tank
Unplug the appliance. Open water outlet cap on rear section to discharge
waste water and add clean water.
Advice: Change water daily to avoid bad odor.

KABEL
General Problems and Solutions
Problem
Cause
Solution
1. Indicator light
not working
1. No power source;
2. MPU fault;
3. Circuit breaker
fault;
4. Panel fault.
1. Check power source circuit;
2. Change mainboard;
3. Change circuit breaker;
4. Change panel.
2. Appliance not
working
1. Being exposed to
impact;
2. Environmental
obstacles;
3. Panel fault.
1. Turn appliance off and on;
2. Clean or remove source of
environmental obstacle;
3. Replace panel.
3. Inexistence or
very low speed of
blowing
1. Fan fault;
2. Pads or air filter
being obstructed;
3. Fan deformation;
4. Mainboard fault.
1. Check if there is engine
failure and if there are pulley
and fan based deformations;
2. Clean or replace pads or air
filter;
3. Replace fan;
4. Replace mainboard.
4. Motor not
working
1. Mainboard fault;
2. Panel fault.
1. Replace mainboard;
2. Replace panel.
5. Appliance
making strange
sounds
1. Foreign object in
appliance;
2. Fan getting loose;
3. Motor fault.
1. Take out filter and pads and
remove foreign object;
2. Tighten fan connections;
3. Replace motor.
Note: This table can only be a reference.
OUR DEALERS AND SERVICES
Please contact our service for technical support.
WARRANTY CONDITIONS
Subject to adhering to principles, warnings, and standards given in user manual,
products with KABEL brand are under Alindair Soğutma Sistemleri ve Tic. A.Ş.
warranty against production faults for 2 (two) years.
Warranty Certificate must be filled out and stamped by authorized KABEL dealer
where you purchased the appliance.
Warranty is only valid for procedures that Alindair approved services shall
undertake. Producer and dealer companies are not responsible for interventions
by inexpert, unauthorized persons to appliance.
Time to repair is at most 30 working days. This period starts from the date
appliance arrives at our authorized service workshops and in case there are no
authorized service workshops to our authorized dealers or our company. In case
the failure is not repaired in 20 working days, Alindair Soğutma Sistemleri ve Tic.
A.Ş. shall allocate to customer another appliance with similar features until the
completion of repair.
Which technical methods shall be used to remove failure and which parts shall
be replaced are exclusively determined by producer company. Failure can be
removed on location of appliance, at authorized service workshops or our
production facility. Customer’s approval is required.
oFollowing delivery date of appliance and remaining in warranty period;
oIn case the same failure is repeated more than twice or more than
four different failures manifest in 1 (one) year resulting in continuous
inability to use appliance,
oIn case maximum period required for repair is exceeded,
oIn case report written by our authorized service workshops or where
they do not exist Authorized Dealer and a member of our regional
representation together with representative of the closest service to
the region notes inability to repair failure, free replacement procedure
shall begin.
Time spent during repairs in warranty period is added to warranty.
Warranty period of the appliance replaced during warranty application is limited
to the remaining warranty of the purchased product.
Warranty period starts from delivery date of the product and is 2 (two) years
from date of delivery.
Time spent during repairs in warranty period is added to warranty.
Note: This certificate will remain with the customer. Customer shall keep this certificate
throughout warranty period and display to service if required.

NON-WARRANTY SITUATIONS
The following cases together with failures, problems and damages that arise and/or may
thus arise will remain outside warranty.
Damage or loss of Capacity Label and Warranty Certificate,
Damage and failure resulting from misuse or use contrary to user manual of
appliance,
Failure to conduct maintenance using equipment in line with installation visual
in user manual,
Using water that does not meet tap or drinkable water values given in user
manual
Continuous inability to use appliance due to brownout or high voltage; using
ungrounded outlets, damages and malfunctions from electric wiring failures,
Failures and damages resulting from maintenance and repairs done by services
not approved by KABEL,
All failures due to floater damage from changing pressure of water supply,
Damages and failures due to shipping, loading, unloading, storing, external
physical (impact, breaking, collapsing) and chemical factors,
Damages and failures due to environmental factors (earthquake, fire, flood,
strong wind, lightning, lime, limey/muddy/dirty fittings, humidity, moisture,
dust, frost, operating without water).
PRODUCER
Company Name: Alindair Soğutma
Sistemleri ve Tic. A.Ş.
Address: Pınarkent Mahallesi 210
Sk. No: 3 Pamukkale/ Denizli
Telephone: [phone]
Fax: [phone]
APPLIANCE INFORMATION
Brand: KABEL
Model: KABEL PLUS
Capacity: 7000 m3/h 280 W
Serial Number:
Maximum Repair Period: 30
Working Days
COMPANY REPRESENTATIVE
Name and Stamp
DEALER INFORMATION
Name:
Address:
Telephone:
Invoice and Date No:
Dealer Signature and Stamp:
