Kaisai ONE User manual

INSTRUKCJA OBSŁUGI
OWNER’S MANUAL
BEDIENUNGSANLEITUNG
KLIMATYZATOR ŚCIENNY TYPU SPLIT
SPLIT TYPE ROOM AIR CONDITIONER
SPLIT-WANDKLIMAANLAGE
PL
EN
DE
ONE

INSTRUKCJA OBSŁUGI
KLIMATYZATOR ŚCIENNY TYPU SPLIT 05
PILOT ZDALNEGO STEROWANIA 23
ZESTAW SMART AC 38
NETHOME PLUS - ROZWIĄZYWANIE PROBLEMÓW 50
OWNER’S MANUAL
SPLIT TYPE ROOM AIR CONDITIONER 55
AIR CONDITIONER REMOTE CONTROLLER 73
SMART AC KIT 88
NETHOME PLUS 100
BEDIENUNGSANLEITUNG
SPLIT-WANDKLIMAANLAGE 105
FERNBEDIENUNG 123
SMART AC 138
NETHOME PLUS - PROBLEMBEHEBUNG 150

INSTRUKCJA OBSŁUGI
KLIMATYZATOR ŚCIENNY TYPU SPLIT 05
PILOT ZDALNEGO STEROWANIA 23
ZESTAW SMART AC 38
NETHOME PLUS - ROZWIĄZYWANIE PROBLEMÓW 50
OWNER’S MANUAL
SPLIT TYPE ROOM AIR CONDITIONER 55
AIR CONDITIONER REMOTE CONTROLLER 73
SMART AC KIT 88
NETHOME PLUS 100
BEDIENUNGSANLEITUNG
SPLIT-WANDKLIMAANLAGE 105
FERNBEDIENUNG 123
SMART AC 138
NETHOME PLUS - PROBLEMBEHEBUNG 150
5
55
105
PL
EN
DE

47
EN
SPLIT-TYPE ROOM
AIR CONDITIONER
Owner’s Manual
Thank you for choosing our product.
For proper operation, please read and keep this manual carefully.
If you have lost the Owner’s Manual, please contact the local agent or visit www.kaisai.com
or sent email to: [email protected], for electronic version.
Owner’s Manual
Thank you for choosing our product.
For proper operation, please read and keep this manual carefully.
If you have lost the Owner’s Manual, please contact the local agent or visit www.kaisai.com
or sent email to: [email protected], for electronic version.
EN
5554

49
EN
Safety Precautions.......................................................04
Unit Specifications and Features ..............................06
Table of Contents
Owner’s Manual
0
1
SAFETY
FIRST
Manual Operation
(Without Remote)................11
2
Care and Maintenance.....................................................60
Troubleshooting...................................................................62
3
4
Eur
5
opean Disposal Guidelines....................................66
Care and Maintenance.....................................................12
Troubleshooting...................................................................14
3
4
European Disposal Guidelines....................................18
5
WARNING: Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance
and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the
person competent in the use of flammable refrigerants. For more details ,please refer to the Information on
servicing on INSTALLATION MANUAL .
Caution: Risk of fire/
flammable materials
  

EN
57
4
PL
Środki bezpieczeństwa ......................................08
Specyfikacje i funkcje urządzenia ....10
Spis treści
Instrukcja obsługi
0
1
SAFETY
FIRST
2 Obsługa ręczna (bez pilota)..........................15
5
PL
Środki bezpieczeństwa ......................................06
Specyfikacje i funkcje urządzenia ....08
Spis treści
Instrukcja obsługi
0
1
SAFETY
FIRST
Obsługa ręczna (bez pilota)..........................13
2
Utrzymanie i konserwacja............................................................................. 16
Wykrywanie i usuwanie usterek...................................................... 18
3
4
5
Europejskie wytyczne w zakresie utylizacji................ 22
Care and Maintenance.....................................................12
Troubleshooting...................................................................14
3
4
European Disposal Guidelines....................................18
5
WARNING: Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance
and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the
person competent in the use of flammable refrigerants. For more details ,please refer to the Information on
servicing on INSTALLATION MANUAL .
Caution: Risk of fire/
flammable materials
  

OSTRZEŻENIE: Czynności serwisowe powinny być wykonywane zgodnie z zaleceniami producenta
urządzenia. Konserwacja i naprawa powinna być wykonywana przez wykwalikowanych serwisantów
kompetentnych w zakresie obsługi łatwopalnych czynników chłodniczych. Więcej informacji serwisowych
zawartych jest w instrukcji instalacyjnej „Installation Manual”.
UWAGA:Ryzyko pożaru/
materiały łatwopalne
Table of Contents
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Unit Specications and Features. . . . . . . . . . . . . . . . . . . . . . . . . 60
Manual Operation(without remote). . . . . . . . . . . . . . . . . . . . . . 65
EN
56 57

49
EN
Safety Precautions.......................................................04
Unit Specifications and Features ..............................06
Table of Contents
Owner’s Manual
0
1
SAFETY
FIRST
Manual Operation
(Without Remote)................11
2
Care and Maintenance.....................................................60
Troubleshooting...................................................................62
3
4
Eur
5
opean Disposal Guidelines....................................66
Care and Maintenance.....................................................12
Troubleshooting...................................................................14
3
4
European Disposal Guidelines....................................18
5
WARNING: Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance
and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the
person competent in the use of flammable refrigerants. For more details ,please refer to the Information on
servicing on INSTALLATION MANUAL .
Caution: Risk of fire/
flammable materials
  

EN
57
4
PL
Środki bezpieczeństwa ......................................08
Specyfikacje i funkcje urządzenia ....10
Spis treści
Instrukcja obsługi
0
1
SAFETY
FIRST
2 Obsługa ręczna (bez pilota)..........................15
5
PL
Środki bezpieczeństwa ......................................06
Specyfikacje i funkcje urządzenia ....08
Spis treści
Instrukcja obsługi
0
1
SAFETY
FIRST
Obsługa ręczna (bez pilota)..........................13
2
Utrzymanie i konserwacja............................................................................. 16
Wykrywanie i usuwanie usterek...................................................... 18
3
4
5
Europejskie wytyczne w zakresie utylizacji................ 22
Care and Maintenance.....................................................12
Troubleshooting...................................................................14
3
4
European Disposal Guidelines....................................18
5
WARNING: Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance
and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the
person competent in the use of flammable refrigerants. For more details ,please refer to the Information on
servicing on INSTALLATION MANUAL .
Caution: Risk of fire/
flammable materials
  

OSTRZEŻENIE: Czynności serwisowe powinny być wykonywane zgodnie z zaleceniami producenta
urządzenia. Konserwacja i naprawa powinna być wykonywana przez wykwalikowanych serwisantów
kompetentnych w zakresie obsługi łatwopalnych czynników chłodniczych. Więcej informacji serwisowych
zawartych jest w instrukcji instalacyjnej „Installation Manual”.
UWAGA:Ryzyko pożaru/
materiały łatwopalne
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
European Disposal Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . 72
EN
56 57

50
EN
Safety Precautions
Read Safety Precautions Before Installation
The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION.
WARNING
This symbol indicates that ignoring instructions may cause death or serious
Incorrect installation due to ignoring instructions can cause serious damage or injury.
injury.
This symbol indicates that ignoring instructions may cause moderate injury
to your person, or damage to your appliance or other property.
CAUTION
WARNING
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
INSTALLATION WARNINGS
•
Ask an authorized dealer to install this air conditioner. Inappropriate installation may cause water
leakage, electric shock, or re.
•
All repairs, maintenance and relocation of this unit must be performed by an authorized service
technician. Inappropriate repairs can lead to serious injury or product failure.
WARNINGS FOR PRODUCT USE
•
If an abnormal situation arises (like a burning smell), immediately turn o the unit and pull the
power plug. Call your dealer for instructions to avoid electric shock, re or injury.
•
Do not
insert fingers, rods or other objects into the air inlet or outlet. This may cause injury, since
the fan may be rotating at high speeds.
•
Do not
use flammable sprays such as hair spray, lacquer or paint near the unit. This may cause
fire or combustion.
•
Do not
operate the air conditioner in places near or around combustible gases. Emitted gas may
collect around the unit and cause explosion.
•
Do not
operate the air conditioner in a wet room (e.g., bathroom or laundry room). This can
cause electrical shock and cause the product to deteriorate.
•
Do not
expose your body directly to cool air for a prolonged period of time.
Safety
Precautions
EN
58 59

51
EN
Safety Precautions
Read Safety Precautions Before Installation
The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION.
WARNING
This symbol indicates that ignoring instructions may cause death or serious
Incorrect installation due to ignoring instructions can cause serious damage or injury.
injury.
This symbol indicates that ignoring instructions may cause moderate injury
to your person, or damage to your appliance or other property.
CAUTION
WARNING
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
INSTALLATION WARNINGS
•
Ask an authorized dealer to install this air conditioner. Inappropriate installation may cause water
leakage, electric shock, or re.
•
All repairs, maintenance and relocation of this unit must be performed by an authorized service
technician. Inappropriate repairs can lead to serious injury or product failure.
WARNINGS FOR PRODUCT USE
•
If an abnormal situation arises (like a burning smell), immediately turn o the unit and pull the
power plug. Call your dealer for instructions to avoid electric shock, re or injury.
•
Do not
insert fingers, rods or other objects into the air inlet or outlet. This may cause injury, since
the fan may be rotating at high speeds.
•
Do not
use flammable sprays such as hair spray, lacquer or paint near the unit. This may cause
fire or combustion.
•
Do not
operate the air conditioner in places near or around combustible gases. Emitted gas may
collect around the unit and cause explosion.
•
Do not
operate the air conditioner in a wet room (e.g., bathroom or laundry room). This can
cause electrical shock and cause the product to deteriorate.
•
Do not
expose your body directly to cool air for a prolonged period of time.
Safety
Precautions
Safety
Precautions
ELECTRICAL WARNINGS
• Only use the specified power cord. If the power cord is damaged, it must be replaced by the
manufacturer or certified service agent.
• Keep power plug clean. Remove any dust or grime that accumulates on or around the plug. Dirty
plugs can cause re or electric shock.
• Do not pull power cord to unplug unit. Hold the plug firmly and pull it from the outlet. Pulling
directly on the cord can damage it, which can lead to fire or electric shock.
• Do not use an extension cord, manually extend the power cord, or connect other appliances to
the same outlet as the air conditioner. Poor electrical connections, poor insulation, and insufficient
voltage can cause re.
CLEANING AND MAINTENANCE WARNINGS
• Turn o the device and pull the plug before cleaning. Failure to do so can cause electrical shock.
• Do not clean the air conditioner with excessive amounts of water.
• Do not clean the air conditioner with combustible cleaning agents. Combustible cleaning agents
can cause re or deformation.
CAUTION
• If the air conditioner is used together with burners or other heating devices, thoroughly ventilate
the room to avoid oxygen deficiency.
• Turn o the air conditioner and unplug the unit if you are not going to use it for a long time.
• Turn o and unplug the unit during storms.
• Make sure that water condensation can drain unhindered from the unit.
• Do not operate the air conditioner with wet hands. This may cause electric shock.
• Do not use device for any other purpose than its intended use.
• Do not climb onto or place objects on top of the outdoor unit.
• Do not allow the air conditioner to operate for long periods of time with doors or windows open,
or if the humidity is very high.
EN
58 59

Room
Temperature
17°-32°C (63°-90°F) 0°-30°C (32°-86°F) 10°-32°C (50°-90°F)
Outdoor
Temperature
18°-43°C (64°-109°F)
-7°-24°C (19°-75°F)
11°-43°C (52°-109°F)
18°-43°C (64°-109°F)
-7°-43°C (19°-109°F)
(For models with low-temp cooling systems)
18°-52°C (64°-126°F)
(For special tropical models)
18°-52°C (64°-126°F)
(For special tropical models)
Cool mode Heat mode DRY mode
Cool mode Heat mode DRY mode
Room Temperature 17°C - 32°C
(63°F - 90°F)
0°C - 30°C
(32°F - 86°F)
10°C - 32°C
(50°F - 90°F)
Outdoor
Temperature
0°C - 50°C
(32°F - 122°F)
0°C - 50°C
(32°F - 122°F)
(For models with
-15°C - 50°C
(5°F - 122°F)
low temp. cooling
systems)
0°C - 52°C
(32°F - 126°F)
(For special
tropical models)
0°C - 52°C
(32°F - 126°F)
(For special
tropical models)
Achieving Optimal Performance
Inverter Spit Type
Fixed-speed Type
-25°C - 30°C
(-13°F - 86°F)
NOTE:
Room relative humidity less than 80%. If the air conditioner operates in excess of this gure, the surface
of the air conditioner may attract condensation. Please sets the vertical air ow louver to its maximum
angle (vertically to the oor), and set HIGH fan mode.
Optimal performance for the COOL, HEAT, and DRY modes can be achieved in the following temperature
ranges. When your air conditioner is used outside of these ranges, certain safety protection features will
activate and cause the unit to perform less than optimally.
When outside temperature
is below 0°C (32°F ), we
strongly recommend
keeping theunit plugged
in at all time to ensure
smoothongoing
performance.
FOR OUTDOOR UNITS
WITH AUXILIARY
ELECTRIC HEATER
To further optimize the performance of your unit, do the following:
• Keep doors and windows closed.
• Limit energy usage by using TIMER ON and TIMER OFF functions.
• Do not block air inlets or outlets.
• Regularly inspect and clean air ters.
” when Wireless Control feature is activated(some units)“
” Displays temperature, operation feature and Error codes:
“ ” for 3 seconds when:
• TIMER ON is set
• FRESH, SWING, TURBO, SILENCE or SOLAR PV ECO feature is turned on
NOTE: Dierent models have dierent front panel and display window. Not all the indicators
describing below are available for the air conditioner you purchased. Please check the indoor display
window of the unit you purchased.
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit
may be slightly dierent. The actual shape shall prevail.
” for 3 seconds when:“
• TIMER OFF is set
• FRESH, SWING, TURBO, SILENCE or SOLAR PV ECO feature is turned o
” when anti-cold air feature is turned on
” when defrosting(cooling & heating units)
” when unit is self-cleaning
” when 8 C heating feature is turned on
“
“
“
“
“
Power Cable (Some Units)
Remote Control
Remote Control
Holder (Some Units)
Louver
Front Panel
Air Filter
(pull out)
Display window
Display Code
Meanings
illuminates gradually one by one as
,
,
When ECO function(some units) is activated, the
set temperature -- ...... in one second interval.
Unit Specifications and Features
Indoor unit display
-- -- --
EN
60 61

Room
Temperature
17°-32°C (63°-90°F) 0°-30°C (32°-86°F) 10°-32°C (50°-90°F)
Outdoor
Temperature
18°-43°C (64°-109°F)
-7°-24°C (19°-75°F)
11°-43°C (52°-109°F)
18°-43°C (64°-109°F)
-7°-43°C (19°-109°F)
(For models with low-temp cooling systems)
18°-52°C (64°-126°F)
(For special tropical models)
18°-52°C (64°-126°F)
(For special tropical models)
Cool mode Heat mode DRY mode
Cool mode Heat mode DRY mode
Room Temperature 17°C - 32°C
(63°F - 90°F)
0°C - 30°C
(32°F - 86°F)
10°C - 32°C
(50°F - 90°F)
Outdoor
Temperature
0°C - 50°C
(32°F - 122°F)
0°C - 50°C
(32°F - 122°F)
(For models with
-15°C - 50°C
(5°F - 122°F)
low temp. cooling
systems)
0°C - 52°C
(32°F - 126°F)
(For special
tropical models)
0°C - 52°C
(32°F - 126°F)
(For special
tropical models)
Achieving Optimal Performance
Inverter Spit Type
Fixed-speed Type
-25°C - 30°C
(-13°F - 86°F)
NOTE:
Room relative humidity less than 80%. If the air conditioner operates in excess of this gure, the surface
of the air conditioner may attract condensation. Please sets the vertical air ow louver to its maximum
angle (vertically to the oor), and set HIGH fan mode.
Optimal performance for the COOL, HEAT, and DRY modes can be achieved in the following temperature
ranges. When your air conditioner is used outside of these ranges, certain safety protection features will
activate and cause the unit to perform less than optimally.
When outside temperature
is below 0°C (32°F ), we
strongly recommend
keeping theunit plugged
in at all time to ensure
smoothongoing
performance.
FOR OUTDOOR UNITS
WITH AUXILIARY
ELECTRIC HEATER
To further optimize the performance of your unit, do the following:
• Keep doors and windows closed.
• Limit energy usage by using TIMER ON and TIMER OFF functions.
• Do not block air inlets or outlets.
• Regularly inspect and clean air ters.
” when Wireless Control feature is activated(some units)“
” Displays temperature, operation feature and Error codes:
“ ” for 3 seconds when:
• TIMER ON is set
• FRESH, SWING, TURBO, SILENCE or SOLAR PV ECO feature is turned on
NOTE: Dierent models have dierent front panel and display window. Not all the indicators
describing below are available for the air conditioner you purchased. Please check the indoor display
window of the unit you purchased.
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit
may be slightly dierent. The actual shape shall prevail.
” for 3 seconds when:“
• TIMER OFF is set
• FRESH, SWING, TURBO, SILENCE or SOLAR PV ECO feature is turned o
” when anti-cold air feature is turned on
” when defrosting(cooling & heating units)
” when unit is self-cleaning
” when 8 C heating feature is turned on
“
“
“
“
“
Power Cable (Some Units)
Remote Control
Remote Control
Holder (Some Units)
Louver
Front Panel
Air Filter
(pull out)
Display window
Display Code
Meanings
illuminates gradually one by one as
,
,
When ECO function(some units) is activated, the
set temperature -- ...... in one second interval.
Unit Specifications and Features
Indoor unit display
-- -- --
EN
60 61

54
EN
Unit
Specifications
and Features
For a detailed explanation of each function,
refer to the Remote Control Manual.
Other Features
•
•
Auto-Restart
If the unit loses power, it will automatically
restart with the prior settings once power has
been restored.
• Anti-mildew (some units)
When turning o the unit from COOL, AUTO
(COOL), or DRY modes, the air conditioner will
continue operate at very low power to dry up
condensed water and prevent mildew growth.
• Wireless Control (some units)
Wireless control allows you to control your air
conditioner using your mobile phone and a
Wireless connection.
• Louver Angle Memory(some units)
When turning on your unit, the louver will
automatically resume its former angle.
• Refrigerant Leakage Detection (some
units)
The indoor unit will automatically display “EC”
For a detailed explanation of your unit’s
advanced functionality (such as TURBO
mode and its self-cleaning functions),
refer to the Remote Control Manual.
Air Filter Reminders (some units)
The “timer” indicator light turns o and
the “run” indicator light ashes 7 times
when the unit detects refrigerant leakage.
Air Filter Cleaning Reminder
Air Filter Replacement Reminder
After 240 hours of use, the “run” &
“timer” indicator lamps on the indoor
unit will ash simultaneously and the
display window on the indoor unit will
ash “CL” (if applicable). This is a
reminder to clean your lter. After 15
seconds, the unit will revert to its
previous display.
To reset the reminder, press the LED
button on your remote control 4 times,
or press the MANUAL CONTROL botton
3 times. If you don’t reset the reminder,
the “CL”, “run” & “timer” indicator
lamps will ash again when you restart
the unit.
After 2,880 hours of use, the “run” &
“timer” indicator lamps will ash
simultaneously for 10 times, then
remain on for ve seconds,and the
display window on the indoor unit will
ash “nF”(if applicable)
. This is a reminder
to replace your lter. After that, the unit
will revert to its previous display.
To reset the reminder, press the LED
button on
your remote control 4 times,
or press the
MANUAL CONTROL botton
3 times. If you don’t reset the reminder,
the “nF”, “run” & “timer” indicator
lamps will ash again when you restart
the unit.
For the USB device access, replacement,
maintenance operations must be carried
out by professional sta.
NOTE ON ILLUSTRATIONS
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be
slightly dierent. The actual shape shall prevail.
EN
62 63

55
EN
Unit
Specifications
and Features
For a detailed explanation of each function,
refer to the Remote Control Manual.
Other Features
•
•
Auto-Restart
If the unit loses power, it will automatically
restart with the prior settings once power has
been restored.
• Anti-mildew (some units)
When turning o the unit from COOL, AUTO
(COOL), or DRY modes, the air conditioner will
continue operate at very low power to dry up
condensed water and prevent mildew growth.
• Wireless Control (some units)
Wireless control allows you to control your air
conditioner using your mobile phone and a
Wireless connection.
• Louver Angle Memory(some units)
When turning on your unit, the louver will
automatically resume its former angle.
• Refrigerant Leakage Detection (some
units)
The indoor unit will automatically display “EC”
For a detailed explanation of your unit’s
advanced functionality (such as TURBO
mode and its self-cleaning functions),
refer to the Remote Control Manual.
Air Filter Reminders (some units)
The “timer” indicator light turns o and
the “run” indicator light ashes 7 times
when the unit detects refrigerant leakage.
Air Filter Cleaning Reminder
Air Filter Replacement Reminder
After 240 hours of use, the “run” &
“timer” indicator lamps on the indoor
unit will ash simultaneously and the
display window on the indoor unit will
ash “CL” (if applicable). This is a
reminder to clean your lter. After 15
seconds, the unit will revert to its
previous display.
To reset the reminder, press the LED
button on your remote control 4 times,
or press the MANUAL CONTROL botton
3 times. If you don’t reset the reminder,
the “CL”, “run” & “timer” indicator
lamps will ash again when you restart
the unit.
After 2,880 hours of use, the “run” &
“timer” indicator lamps will ash
simultaneously for 10 times, then
remain on for ve seconds,and the
display window on the indoor unit will
ash “nF”(if applicable). This is a reminder
to replace your lter. After that, the unit
will revert to its previous display.
To reset the reminder, press the LED
button on
your remote control 4 times,
or press the
MANUAL CONTROL botton
3 times. If you don’t reset the reminder,
the “nF”, “run” & “timer” indicator
lamps will ash again when you restart
the unit.
For the USB device access, replacement,
maintenance operations must be carried
out by professional sta.
NOTE ON ILLUSTRATIONS
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be
slightly dierent. The actual shape shall prevail.
Setting vertical angle of air ow
While the unit is on, use the SWING/DIRECT
button to set the direction (vertical angle) of
airflow.
1. Press the SWING/DIRECT button once to
activate the louver. Each time you press
the button, it will adjust the louver by 6°.
Press the button until the direction you
prefer is reached.
2. To make the louver swing up and down
continuously, press and hold the SWING/
DIRECT button for 3 seconds. Press it
again to stop the automatic function.
The horizontal angle of the airow must be set
manually. Grip the deector rod (See Fig.B)
and manually adjust it to your preferred direction.
For some units, the horizontal angle of the airow
can be set by remote control. Please refer to the
Remote Control Manual.
NOTE ON LOUVER ANGLES
When using COOL or DRY mode, do not set
louver at too vertical an angle for long periods
of time. This can cause water to condense on
the louver blade, which will drop on your floor
or furnishings. (See Fig.A)
When using COOL or HEAT mode, setting the
louver at too vertical an angle can reduce the
performance of the unit due to restricted air
flow.
Do not move louver by hand. This will cause the
louver to become out of sync. If this occurs, turn
o the unit and unplug it for a few seconds,
then restart the unit. This will reset the louver.
Fig. A
CAUTION
Do not put your ngers in or near the blower
and suction side of the unit. The high-speed
fan inside the unit may cause injury.
Fig. B
Setting Angle of Air Flow
Setting horizontal angle of air ow
•
Unit
Specifications
and Features
Range
Caution: Do not keep louver at too
vertical an angle for long periods of
time. This can cause water condensation
to drip on your furnishings.
Deector rod
EN
62 63

How to operate your unit without
the remote control
To operate your unit manually:
BEFORE MANUAL OPERATION
Unit must be turned o before manual operation.
Manual Operation(without remote) 2
CAUTION
11. Locate the MANUAL CONTROL button on
the right-hand side panel of the unit.
2. Press the MANUAL CONTROL button one
time to activate FORCED AUTO mode.
3. Press the MANUAL CONTROL button again
to activate FORCED COOLING mode.
4. Press the MANUAL CONTROL button a third
time to turn the unit o.
Manual control
button
The manual button is intended for testing
purposes and emergency operation only. Please
do not use this function unless the remote
control is lost and it is absolutely necessary. To
restore regular operation, use the remote control
to activate the unit. Unit must be turned o
before manual operation.
In the event that your remote control fails to
work, your unit can be operated manually
with the MANUAL CONTROL button located
on the indoor unit. Note that manual opera-
tion is not a long-term solution, and that
operating the unit with your remote control
is strongly recommended.
56
EN
The SLEEP function is used to decrease energy
use while you sleep (and don’t need the same
temperature settings to stay comfortable). This
function can only be activated via remote control.
Press the SLEEP button when you are ready to
go to sleep. When in COOL mode, the unit will
increase the temperature by 1°C (2°F) after 1
hour, and will increase an additional 1°C (2°F)
after another hour. When in HEAT mode, the unit
will decrease the temperature by 1°C (2°F) after
1 hour, and will decrease an additional 1°C (2°F)
after another hour.
It will hold the new temperature for 5 hours, then
the unit will turn o automatically.
Note: The SLEEP function is not available in
FAN or DRY mode.
Sleep Operation
Set
temperature
Saving energy during sleep
1hr 1hr
7 hours
timer o
+/- 1 C/2 F
SLEEP Operation
+/- 1 C/2 F
•
Unit
Specifications
and Features
The SLEEP function is used to decrease energy
use while you sleep (and don’t need the same
temperature settings to stay comfortable). This
function can only be activated via remote control.
Press the SLEEP button when you are ready to
go to sleep. When in COOL mode, the unit will
increase the temperature by 1°C (2°F) after 1
hour, and will increase an additional 1°C (2°F)
after another hour. When in HEAT mode, the unit
will decrease the temperature by 1°C (2°F) after
1 hour, and will decrease an additional 1°C (2°F)
after another hour.
The SLEEP function ends after 8 hours and then the
air conditioner will change to the normal operating
mode.
The device will
keep running
until turned o
by the user.
EN
64 65

How to operate your unit without
the remote control
To operate your unit manually:
BEFORE MANUAL OPERATION
Unit must be turned o before manual operation.
Manual Operation(without remote) 2
CAUTION
11. Locate the MANUAL CONTROL button on
the right-hand side panel of the unit.
2. Press the MANUAL CONTROL button one
time to activate FORCED AUTO mode.
3. Press the MANUAL CONTROL button again
to activate FORCED COOLING mode.
4. Press the MANUAL CONTROL button a third
time to turn the unit o.
Manual control
button
The manual button is intended for testing
purposes and emergency operation only. Please
do not use this function unless the remote
control is lost and it is absolutely necessary. To
restore regular operation, use the remote control
to activate the unit. Unit must be turned o
before manual operation.
In the event that your remote control fails to
work, your unit can be operated manually
with the MANUAL CONTROL button located
on the indoor unit. Note that manual opera-
tion is not a long-term solution, and that
operating the unit with your remote control
is strongly recommended.
EN
64 65

58
EN
Cleaning Your Indoor Unit
BEFORE CLEANING OR
MAINTENANCE
ALWAYS TURN OFF YOUR AIR CONDITIONER
SYSTEM AND DISCONNECT ITS POWER SUPPLY
BEFORE CLEANING OR MAINTENANCE.
CAUTION
Only use a soft, dry cloth to wipe the unit clean.
If the unit is especially dirty, you can use a cloth
soaked in warm water to wipe it clean.
• Do not use chemicals or chemically treated
cloths to clean the unit
• Do not use benzene, paint thinner,
polishing powder or other solvents to clean
the unit. They can cause the plastic surface
to crack or deform.
• Do not use water hotter than 40°C (104°F)
to clean the front panel. This can cause the
panel to deform or become discolored.
Cleaning Your Air Filter
A clogged air filter can reduce the cooling
efficiency of your unit, can also make the air flow
irregular and too much noisy, so please clean
the air filter as often as necessary. Once the
abnormal noise of air flow is heard, please clean
the air filter immediately.
1. The air filter is under the top air inlet grill.
2. Grip the tab on the end of the filter, lift it
up,then pull it towards yourself.
3. If your filter has a small air freshening filter, unclip
it from the larger filter. Clean this air freshening
filter with a hand-held vacuum.
4. Clean the large air filter with warm, soapy
water. Be sure to use a mild detergent.
5. Rinse the filter with fresh water, then shake off
excess water.
6. Dry it in a cool, dry place, and refrain from
exposing it to direct sunlight.
7. When dry, re-clip the air freshening filter to the
larger filter, then slide it back into the indoor unit.
Care and Maintenance
3
CAUTION
Do not touch air freshening (Plasma) lter for
at least 10 minutes after turning o the unit.
Care and
Maintenance
Remove air freshening filter from back of
larger filter (some units)
Filter Tab
Filter Tab
Air freshening lter
(some units)
EN
66 67

59
EN
Cleaning Your Indoor Unit
BEFORE CLEANING OR
MAINTENANCE
ALWAYS TURN OFF YOUR AIR CONDITIONER
SYSTEM AND DISCONNECT ITS POWER SUPPLY
BEFORE CLEANING OR MAINTENANCE.
CAUTION
Only use a soft, dry cloth to wipe the unit clean.
If the unit is especially dirty, you can use a cloth
soaked in warm water to wipe it clean.
• Do not use chemicals or chemically treated
cloths to clean the unit
• Do not use benzene, paint thinner,
polishing powder or other solvents to clean
the unit. They can cause the plastic surface
to crack or deform.
• Do not use water hotter than 40°C (104°F)
to clean the front panel. This can cause the
panel to deform or become discolored.
Cleaning Your Air Filter
A clogged air conditioner can reduce the cooling
efficiency of your unit, and can also be bad for
your health. Make sure to clean the filter once
every two weeks.
1. Lift the front panel of the indoor unit.
2. First press the tab on the end of lter to
loosen the buckle, lift it up, then pull it
towards yourself.
3. Now pull the lter out.
4. If your lter has a small air freshening lter,
unclip it from the larger lter. Clean this air
freshening lter with a hand-held vacuum.
5. Clean the large air lter with warm, soapy
water. Be sure to use a mild detergent.
Care and Maintenance 3
6. Rinse the lter with fresh water, then shake
o excess water.
7. Dry it in a cool, dry place, and refrain from
exposing it to direct sunlight.
8. When dry, re-clip the air freshening lter to
the larger lter, then slide it back into the
indoor unit.
9. Close the front panel of the indoor unit.
CAUTION
Do not touch air freshening (Plasma) lter for
at least 10 minutes after turning o the unit.
Care and
Maintenance
Remove air freshening filter from back of
larger filter (some units)
Filter Tab
CAUTION
• Before changing the lter or cleaning,
turn o the unit and disconnect its power
supply.
• When removing lter, do not touch metal
parts in the unit. The sharp metal edges can
cut you.
• Do not use water to clean the inside of the
indoor unit. This can destroy insulation and
cause electrical shock.
• Do not expose lter to direct sunlight when
drying. This can shrink the lter.
Air Filter Reminders (Optional)
Air Filter Cleaning Reminder
After 240 hours of use, the display window on
the indoor unit will ash “CL.” This is a reminder
to clean your lter. After 15 seconds, the unit will
revert to its previous display.
To reset the reminder, press the LED button
on your remote control 4 times, or press the
MANUAL CONTROL button 3 times. If you don’t
reset the reminder, the “CL” indicator will ash
again when you restart the unit.
Air Filter Replacement Reminder
After 2,880 hours of use, the display window on
the indoor unit will ash “nF.” This is a reminder
to replace your lter. After 15 seconds, the unit
will revert to its previous display.
To reset the reminder, press the LED button
on your remote control 4 times, or press the
MANUAL CONTROL button 3 times. If you don’t
reset the reminder, the “nF” indicator will ash
again when you restart the unit.
CAUTION
• Any maintenance and cleaning of outdoor
unit should be performed by an authorized
dealer or licensed service provider.
• Any unit repairs should be performed
by authorized dealer or licensed servic
e
provider.
Maintenance –
Long Periods of Non-Use
If you plan not to use your air conditioner for an
extended period of time, do the following:
Clean all lters Turn on FAN function until
unit dries out completely
Turn o the unit and
disconnect the power
Remove batteries
from remote control
Maintenance –
Pre-Season Inspection
After long periods of non-use, or before periods
of frequent use, do the following:
Check for damaged wires Clean all lters
Check for leaks Replace batteries
Make sure nothing is blocking all air inlets and outlets
Care and
Maintenance
3
EN
66 67

60
EN
SAFETY PRECAUTIONS
If ANY of the following conditions occurs, turn o your unit immediately!
• The power cord is damaged or abnormally warm
• You smell a burning odor
• The unit emits loud or abnormal sounds
• A power fuse blows or the circuit breaker frequently trips
• Water or other objects fall into or out of the unit
DO NOT ATTEMPT TO FIX THESE YOURSELF! CONTACT AUTHORIZED SERVICE PROVIDER
IMMEDIATELY!
Common Issues
The following problems are not a malfunction and in most situations will not require repairs.
Issue Possible Causes
Unit does not turn
on when pressing
ON/OFF button
The Unit has a 3-minute protection feature that prevents the
unit from overloading. The unit cannot be restarted within
three minutes of being turned o.
The unit may change its setting to prevent frost from forming
on the unit. Once the temperature increases, the unit will start
operating in the previously selected mode again.
The set temperature has been reached, at which point the
unit turns o the compressor. The unit will continue operating
when the temperature fluctuates again.
The indoor unit
emits white mist
In humid regions, a large temperature dierence between the
room’s air and the conditioned air can cause white mist.
Both the indoor
and outdoor units
emit white mist
When the unit restarts in HEAT mode after defrosting, white
mist may be emitted due to moisture generated from the
defrosting process.
Troubleshooting
4
Troubleshooting
The unit changes
from COOL/HEAT
mode to FAN
mode
EN
68 69

61
EN
Issue Possible Causes
The indoor unit
makes noises
A rushing air sound may occur when the louver resets its
position.
A squeaking sound may occur after running the unit in HEAT
mode due to expansion and contraction of the unit’s plastic
parts.
Both the indoor
unit and outdoor
unit make noises
Low hissing sound during operation: This is normal and is
caused by refrigerant gas flowing through both indoor and
outdoor units.
Low hissing sound when the system starts, has just stopped
running, or is defrosting: This noise is normal and is caused by
the refrigerant gas stopping or changing direction.
Squeaking sound: Normal expansion and contraction of
plastic and metal parts caused by temperature changes during
operation can cause squeaking noises.
The outdoor unit
makes noises
The unit will make dierent sounds based on its current
operating mode.
Dust is emitted
from either the
indoor or outdoor
unit
The unit may accumulate dust during extended periods of
non-use, which will be emitted when the unit is turned on.
This can be mitigated by covering the unit during long periods
of inactivity.
The unit emits a
bad odor
The unit may absorb odors from the environment (such as
furniture, cooking, cigarettes, etc.) which will be emitted
during operations.
The unit’s filters have become moldy and should be cleaned.
The fan of the
outdoor unit does
not operate
During operation, the fan speed is controlled to optimize
product operation.
Operation
is erratic,
unpredictable,
or unit is
unresponsive
Interference from cell phone towers and remote boosters may
cause the unit to malfunction.
In this case, try the following:
• Disconnect the power, then reconnect.
• Press ON/OFF button on remote control to restart operation.
NOTE: If problem persists, contact a local dealer or your nearest customer service
center. Provide them with a detailed description of the unit malfunction as
well as your model number.
Troubleshooting
4
EN
68 69

62
EN
Troubleshooting
When troubles occur, please check the following points before contacting a repair company.
Problem Possible Causes Solution
Poor Cooling
Performance
Temperature setting may
be higher than ambient
room temperature
Lower the temperature setting
The heat exchanger on the
indoor or outdoor unit is
dirty
Clean the aected heat exchanger
The air lter is dirty Remove the filter and clean it
according to instructions
The air inlet or outlet of
either unit is blocked
Turn the unit o, remove the
obstruction and turn it back on
Doors and windows are
open
Make sure that all doors and
windows are closed while
operating the unit
Excessive heat is generated
by sunlight
Close windows and curtains
during periods of high heat or
bright sunshine
Too many sources of heat
in the room (people,
computers, electronics,
etc.)
Reduce amount of heat sources
Low refrigerant due to leak
or long-term use
Check for leaks, re-seal if
necessary and top o refrigerant
SILENCE function is
activated(optional function)
SILENCE function can lower
product performance by reducing
operating frequency. Turn o
SILENCE function.
Troubleshooting
EN
70 71

63
EN
Troubleshooting
When troubles occur, please check the following points before contacting a repair company.
Problem Possible Causes Solution
Poor Cooling
Performance
Temperature setting may
be higher than ambient
room temperature
Lower the temperature setting
The heat exchanger on the
indoor or outdoor unit is
dirty
Clean the aected heat exchanger
The air lter is dirty Remove the filter and clean it
according to instructions
The air inlet or outlet of
either unit is blocked
Turn the unit o, remove the
obstruction and turn it back on
Doors and windows are
open
Make sure that all doors and
windows are closed while
operating the unit
Excessive heat is generated
by sunlight
Close windows and curtains
during periods of high heat or
bright sunshine
Too many sources of heat
in the room (people,
computers, electronics,
etc.)
Reduce amount of heat sources
Low refrigerant due to leak
or long-term use
Check for leaks, re-seal if
necessary and top o refrigerant
SILENCE function is
activated(optional function)
SILENCE function can lower
product performance by reducing
operating frequency. Turn o
SILENCE function.
Troubleshooting
Problem Possible Causes Solution
The unit is not
working
Power failure Wait for the power to be
restored
The power is turned o Turn on the power
The fuse is burned out Replace the fuse
Remote control batteries are
dead
Replace batteries
The Unit’s 3-minute protection
has been activated
Wait three minutes after
restarting the unit
Timer is activated Turn timer o
The unit starts and
stops frequently
There’s too much or too little
refrigerant in the system
Check for leaks and
recharge the system with
refrigerant.
Incompressible gas or
moisture has entered the
system.
Evacuate and recharge the
system with refrigerant
The compressor is broken Replace the compressor
The voltage is too high or
too low
Install a manostat to
regulate the voltage
Poor heating
performance
The outdoor temperature is
exetremtly low
Use auxiliary heating
device
Cold air is entering through
doors and windows
Make sure that all doors
and windows are closed
during use
Low refrigerant due to leak or
long-term use
Check for leaks, re-seal
if necessary and top o
refrigerant
Indicator lamps
continue flashing The unit may stop operation or continue to run safely. If
the indicator lamps continue to flash or error codes appear,
wait for about 10 minutes. The problem may resolve itself.
If not, disconnect the power, then connect it again. Turn
the unit on.
If the problem persists, disconnect the power and contact
your nearest customer service center.
Error code appears in
the window display
of indoor unit:
• E0, E1, E2…
• P1, P2, P3…
• F1, F2, F3…
NOTE: If your problem persists after performing the checks and diagnostics above, turn o your
unit immediately and contact an authorized service center.
Troubleshooting
EN
70 71
