Kaiser Baas HD Media Hub User manual

HD Media Hub User Guide

CONTENTS
Safety precautions
What’s in the box
Remote diagram
Product diagram
Setup HD Media Hub
Using your HD Media Hub
Alternative operation method
Adjusting your settings
Product specifications
Hardware specifications
Frequently Asked Questions
Contact us
2
3
4
6
7
8
9
9
10
10
11
12

HD Game Recorder User Guide
23
WHAT’S IN THE BOX
Please ensure the product package has all the following contents:
HD Media Hub
Remote control
Power supply
A
A
B
B
C
C
D
D
E
E
F
F
SAFETY PRECAUTIONS
Before using the HD Media Hub, please ensure you read and understand all the safety
precautions below.
Do not attempt to open the case or modify it in any way, as this will void your warranty.
Maintenance and repairs should only be performed by Kaiser Baas.
Keep the HD Media Hub away from water and other liquids. Do not use wet hands,
when using the HD Media Hub as this may cause the unit to malfunction.
Keep the HD Media Hub away from direct sunlight and heat sources.
HD Media Hub may become slightly warm during use. This does not indicate
a malfunction.
Do not place heavy objects on the HD Media Hub, as this may cause
it to malfunction.
Do not dispose of the unit via conventional domestic waste.
Use the provided power cable, do not substitute another cable.
AV cable
User guide
Warranty card

5
4
REMOTE DIAGRAMREMOTE DIAGRAM
POWER
Turn the HD Media Hub on and off
MUTE
Mute the volume
SETUP
Adjust the settings on your
HD Media Hub
OSD
The On-Screen Display, for adjusting
several different functions
SOURCE
The source connecting the HD Media
Hub to the television
MOVIE, MUSIC, PHOTO, FILE
Changes HD Media Hub’s play/display
mode
AV, HDMI, YPbPr, VGA
Change between different sources
16:9
Adjust the screen size
HOME, RETURN, ARROW KEYS, OK
Select options on the menu screen
VOL-, VOL+
Adjust the volume
PLAY/PAUSE, STOP, REPEAT, PREV,
NEXT, FFWD, FRWD
Video controls
GOTO, INFO, SUBTITLE, AUDIO
Video options
ROTATE, SLIDESHOW, ZOOM -,
ZOOM +
Photo options
RESET
Return to start screen
ZZ
Adjust sleep mode
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
12
345
6
7
8
9
10
11
12
13
14 15

6
PRODUCT DIAGRAM
USB inputs
SD/MMC input
Power socket
AV output
HDMI output
S/PDIF output
1
2
3
4
5
6
1
2
34 5 6
Left
Right
Back
7
SETUP HD MEDIA HUB
Step One: Plugging Into Mains Power
Connect the power supply from the back
of the HD Media Hub into a power point.
Step Two: Connect Media Source
You can connect most USB flash drives (also
known as memory sticks), SD memory cards
or portable hard drives to the HD Media Hub.
Connect your USB or SD card to the
appropriate input socket on the HD
Media Hub.
Step Three: Connecting To Television
AV cables: with the supplied AV cable, connect
from your HD Media Hub AV port to the correct
television AV inputs and then turn the HD Media
Hub on.
HDMI*: with a HDMI cable connect from your
HD Media Hub HDMI port to the correct television
HDMI input and then turn the HD Media Hub on.
HARD DRIVE
*HDMI cable not provided.
AV cable
HDMI
cable
OR

USING YOUR HD MEDIA HUB
You can browse your files by selecting any of the icons on the home screen
8 9
ALTERNATIVE OPERATION METHOD
You can play/display any type of file on the HD Media Hub by just selecting the File
icon:
1. Select File icon on the home screen. To select, press OK.
2. Select memory source – you should see all files stored on memory source here.
To select, press OK.
3. On the remote, select either Music, Movie or Photo to put the HD Media Player
in the correct mode. To select, press OK. The current mode will be displayed on the
top left of your screen.
4. Select the file you wish to play/display by pressing OK.
ADJUSTING YOUR SETTINGS
You can adjust the settings on your HD Media Hub by pressing SETUP on your remote
control.
Alternatively, you can select SETUP on the home screen, by highlighting it and
pressing OK.
The next screen will display options from which memory source you want
to display/play your files. Select which memory source you have inserted.
Now, search for the desired file by scrolling through the list.
TIP! You can do this from anywhere. For example, if you’re browsing in the Movie section
and you’re actually looking for music, you can press the Music button on the remote
control to find music files, rather than going back to the home screen.
The rest of the remote control’s mode buttons – Movie, Photo, etc – work like this, too.
File:
browse files of any type
Movie:
search for video files
Music:
search for audio files
Photo:
search for pictures
Setup:
HD Media Hub settings

10 11
PRODUCT SPECIFICATIONS
HARDWARE SPECIFICATIONS
FREQUENTLY ASKED QUESTIONS
Q. The HD Media Hub is not responding. Why?
A. It could be loading data from your media source, which can take a few moments.
If it continues to not respond, disconnect the power cable, reconnect the HD Media
Hub and it switch back on.
Q. There is no picture on screen. Why?
A. Ensure the power cable, AV or HDMI cable is connected correctly. Remove the
and reinsert the SD card, drive or USB stick. Check the television source option
is correct to display the HD Media Hub.
Q. Why can’t I play my movie file?
A. Some codecs or file formats are not supported. Double check the list of supported
video formats on page 10.
Q. How can I adjust the subtitles?
A. You can adjust subtitles by pressing OSD on your remote. In some cases, videos
downloaded from the internet come with in-built subtitles that cannot be changed.
Q. How do I play a photo slideshow?
A: Pressing the photo-options remote buttons will allow you to rotate photos, zoom
in or out, or view them as a slideshow.
Q: I cannot play/display the selected file. Why?
A: Check, on the top left of your screen, that you have the HD Media Hub in the correct
mode for playing/displaying your file. After selecting your memory source, you can
change the mode by selecting either the Music, Movie or Photo buttons on the
remote control.
Video MPEG1 DAT, MPG, MPEG (up to 720*576)
MPEG2 MPG, AV, VOB, TS/TP, M2TS (up to 1080p)
MPEG4 (Xvid) MKV, AVI, MP4, M2TS (up to 1080p)
H.264 MKV, AVI, MP4, MOV, M2TS, TS/TP (up to 1080p)
WMV9/VC-1 MKV, AVI, MP4, MOV, M2TS, TS/TP(up to 1080p)
Real Video RM/RMVB (up to 720p)
MJPEG AVI (up to 1080p)
FLV FLV (up to 1080p)
Audio MP3 / WMA / WAV / OGG / AAC / APE / FLAC / AC3 / DTS
Picture JPEG / BMP / PNG / GIF
Subtitles SRT / SMI / SSA
Product Code KBA03038
APN 9 326903 003629
Video output AV/ (PAL/NTSC)/HDMI (480P, 720P, 1080i, 1080P)
Audio output Audio L/R HDMI (Stereo)/S/PDIF
Hard disk FAT/FAT32/NTFs/exFAT
LED HDMI/AV output
IR Receive signals from remote control
Size 120 x 90 x 25 mm
USB OTG 2* USB2.0 host
Memory card SD/MMC
Power DC 5.6V/2A

12
FREQUENTLY ASKED QUESTIONS
Q: Why don’t my File, Music, Movie, Photo and Setup buttons work on my
remote control?
A: These buttons will work to change modes only after you have entered one of these
options from the home screen via the arrow buttons on the remote control.
Q: The HD Media Hub is on, but I can’t see any display on my TV.
A: Unplug the power cable, wait a few seconds, and plug it back in.
CONTACT US
Need further assistance? Please visit:
www.kaiserbaas.com
Or email:
[email protected]om
