Kalamazoo 2FS User manual

INSTRUCTION
MANUAL
MODEL: 2FS
KI KALAMAZOO INDUSTRIES, INC.
6856 East K Avenue
Kalamazoo, MI 49048
[phone] PH
[phone] Fax
www.kalamazooind.com

WARNING!
TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS EQUIPMENT TO RAIN, ANY LIQUID OR
MOISTURE.
Read Operating Instructions and Precautions Before Using This Equipment
INSPECTION
If these goods are damaged in transit, the DELIVERING TRANSPORTATION COMPANY, is required by
law to make notation of damages on the freight bill. If in your opinion, there maybe concealed damage, they
are required to make an inspection after goods are unpacked. Transportation rates are made in proportion to
damage. Therefore, the carrier and NOT the shipper should be charged with any loss or damage. Any claim
should be led with the delivering Transportation Company. PLEASE DO NOT RETURN GOODS TO
USE WITHOUT OUR RGA NUMBER AND SHIPPING INSTRUCTIONS.
OPERATING INSTRUCTIONS
1. Mount bracket base #20. Mount your motor behind, below, below, etc. Connect V-belt to motor and sander
pulley and tension per your design. Loosen cap screw #25 on bracket #24 to adjust angle to sanding head.
2. Track sanding belt, loose tracking knob #11, spin sanding belt manually to see where the belt goes, grab
tracking knob and twist tension bar #5 to center or “track” the sanding belt. Re-tighten the tracking knob to
maintain tracking.
3. Keep work table as close to the belt as possible to avoid pinching work piece AND ngers between the belt
and platen.
4. See below for sanding belt changing.
Read Operating Instructions and Precautions Before Using This Equipment
Belt Changing Instructions
Loosen Tracking knob, pull down on de-tensioner
lever to depress belt tension spring, change
sanding belt. Flip lever back over to store.

1-5/16-18X1/2 H.H.C.S 1
2342-009 UMBRELLA GUARD 1
3 - 5/16-18x3/8 S.S.S 1
4 2 X 48 BELT 1
5645-008 TENSION ROD 1
6697-013 TENSION SPRING 1
7936-030 IDLER PULLEY 1
8 - 1/4-20X1/2 H.H.C.S 1
9 - 1/4 WASHER 1
10 829-004 WORK TABLE 1
11 441-011 TRACKING KNOB 1
12 123-004 TRACKING COLLAR 1
13 - 5/16-18 H.H. NUT 2
14 - 5/16-18 H.H.C.S 2
15 SOLID W/291-009 TUBE SUPPORT 1
16 - 1/4-20 H.H. NUT 1
17 550-006 PLATEN 1
18 560-004 V-BELT PULLEY 1
19 044-007 K10 BEARING 1
20 041-011 BRACKET BASE 1
21 - 5/16-18X1/4 S.S.S 1
22 701-009 SPINDLE W/FLANGE 1
23 - 1/4-20X1/4 S.S.S 2
24 041-010 BRACKET 1
25 - 5/16-18X1 S.H.C.S 1
26 936-004 DRIVE WHEEL 1
27 292-017 LOOSE FLANGE 1
28 - 5/8-18 HEX NUT 1
2FS REPLACEMENT PARTS LIST
ITEM PART NUMBER QTY
DESCRIPTION
