Kaman Gibraltar 6600 Series Manual

Replacement Part Numbers
1 - GP-0016 Upper Pull Rod
2 - SC-4421D Hi-Hat Clutch
3 - SC-HHCF Cup Felt
4 - SC-HHFW Flat Washer
5 - GP-6069 Upper Height Adjust Tube
6a - GP-2005 3/4" Nylon Inner Sleeve
6b - GP-2002 1" Nylon Inner Sleeve
7 - GP-2080 1" Fitted Memory Lock
8 - GP-6030 Wing/Short Bolt Set 6mm
9 - GP-6070 Hi-Hat Stand Base
10 - SC-0009 Wing Bolt 8mm
11 - GP-6032 Hi-Hat Chain
12 - GP-6033 Pinned Footboard
13 - GP-0021 Radius Rod for HiHat
14 - SC-PC09 Rubber Foot
15 - GP-0020 Anchor Spur Assembly
16 - GP-6071 Snare Basket
17 - GP-6052 Wing Nut/Bolt Assembly 8mm
18 - GP-6072 Upper Height Adjust Tube
19 - GP-6073 Lower Base Assembly
20 - SC-13P2 Wing Nut 8mm
21 - SC-CFS/4 Small Cymbal felt
22 - SC-19B Cymbal Sleeve 8mm
23 - GP-6062 Cymbal Tilter Assembly
24 - GP-6055 Wing Nut / Bolt Assembly 8mm
25 - GP-6056 Knurled Boom Arm
26 - GP-6068 Hex Bolt/ Wing Nut Assembly
27 - GP-6074 3/4" Upper Height Adjust Tube
28 - GP-6075 1" Middle Tube
29 - GP-6076 Lower Base Assembly
30 - GP-6077 3/4" Upper Height Adjust Tube
31 - GP-6078 3/4" Fitted Memory Lock
Check out the entire line of
Gibraltar Hardware products at …
www.GibraltarHardware.com
G
i
b
r
a
l
ta
r
6600
Se
ri
es
H
a
r
d
w
a
r
e
1
2
3
4
5
7
6b
8
10
11
12
13
9
14
20
21
24
10
14
14
8
15
10
18
16
17
19
26
22
24
25
8
14
30
22
29
28
20
27
10
6b
8
21
8
6b
29
23 23
A)
B)
C)
D)
E)
F)
G)
Setup Instructions
6607 Series Hi-Hat Stand
Remove cardboard and plastic cover from pedal board and
attach the Radius Rod (GP-0021) to the frame.
Unfold and adjust the tripod legs to be flush to the ground and
slightly raise the middle frame.
Screw the Upper Pull Rod (GP-0016) into the lower base pull
rod stem.
Place the Upper Height Adjust Tube (GP-6069) into the base
and adjust to the desired position. Use the Fitted Memory Lock
(GP-2080) on the tube to retain this position.
Place the bottom hihat cymbal onto the hihat stand Cup Felt
(SC-HHCF) facing upwards.
Place the top hihat cymbal into the Hi-Hat Clutch (GP-4421D),
inserting it between the two small felts on the clutch, then slip it
onto the upper pull rod.
Secure the upper hihat cymbal with clutch onto the pull rod
leaving approximately 1" spacing between the upper and lower
hihat cymbals, then adjust to the desired spacing.
A)
B)
C)
D)
Setup Instructions
6606 Series Snare Stand
Open the tripod base of the
snare stand (GP-6073) and
place it in an upright position.
Insert the upper snare tube
(GP-6072) into the stand
base.
Open the snare basket
(GP-6071) to fit the snare
drum to be used.
Once the snare drum is
placed in the basket, tighten
the basket to secure the drum.
Be aware that over tightening
the basket may choke the
drum sound, limiting the
response.
A)
B)
C)
D)
Setup Instructions
6609, 6610 Series
C
y
mbal Stands
Open the tripod stand base
of the cymbal stand and
place it in an upright position.
Insert the middle and, or,
upper cymbal tube into the
stand base.
Insert the boom arm, 6609
only, into the upper tilter
assembly.
Use the tilter on the upper
height adjust tube and, or,
the boom arm to position
your cymbal to the desired
angle.
7
6b
7
831
31
7
6a
6a
28

A)
B)
C)
D)
E)
F)
G)
H)
A)
B)
C)
D)
E)
F)
G)
Remove cardboard and plastic cover
from pedal board.
Insert the beater (SC-LBDB) into the
beater holder (GP-6064) and adjust it to
your desired height.
Insert the pedal spring (SC-0052) onto
the spring cam (GP-6080) using the clip
attached to the spring.
To adjust the spring tension to your
desired response, loosen both upper
and lower finger nuts to increase or
decrease the tension, then re-tighten the
finger nuts.
Slide the pedal frame onto the bass
drum hoop then tighten the hoop clamp
(GP-6065) onto to the bass drum hoop.
To avoid pedal slippage and bass drum
movement, we recommend placing the
bass drum and pedal onto a carpeted
surface.
Lubricate metal-to-metal contact points
periodically to insure smooth operation.
We suggest #SC-GLO Gibraltar Pedal
Lubricant.
Gibraltar 6600 Series Hardware
Replacement Part Numbers
1 - SC-LBDB Light Weight BD Beater
2 - GP-6079 Double Chain Cam
3 - GP-6064 Beater Holder
4 - SC-0121 Key Screw 8mm
5 - SC-0129 Key Screw 6mm
6 - SC-0129 Fastening Screw 6mm
7 - GP-6080 Spring Cam Assembly
8 - GP-0052 Pedal Spring
9 - GP-5103 Spring Tension Assembly
10 - GP-4007 Double Chain Assembly
11 - GP-6033 Pedal Board Complete
12 - GP-0020 Anchor Spur Assembly
13 - GP-6065 Black Hoop Clamp
14 - GP-6066 Hoop Clamp Key Screw 8mm
15 - GP-6067 Fixed Rock Plate
16 - SC-0128 Fastening Screw 5mm
17 - SC-0129 Fastening Screw 6mm
18 - GP-3030R Connecting Rod w/ U-Joint
19 - GP-3030L Connecting Rod w/ U-Joint
20 - GP-3029 Center Connecting Shaft
Check out the entire line of
Gibraltar Hardware products at …
www.GibraltarHardware.com
1
3
2
5
4
6
7
8
9
11
13 12
14
10
1
3
14
2
10
2
46
7
8
9
11 11
12
15
16 17
18
19
16
Setup Instructions
6611 Series Single Pedal
Setup Instructions
6611DB Series Double Pedal
Remove cardboard and plastic cover
from pedal boards.
Insert the beaters (SC-LBDB) into the
beater holders (GP-6064) and adjust
it to your desired height.
Insert the connecting rod assembly
into the right and left axles on each
end of the pedal frames. Connect
both rods with the center connecting
shaft (GP-3029). Adjust the extension
rods to the desired length.
Insert the pedal spring (SC-0052)
onto the spring cam pivot hole
(GP-6080) using the clip attached to
the spring.
To adjust the spring tension to your
desired response, loosen both upper
and lower finger nuts to increase or
decrease the tension, then re-tighten
the finger nuts.
Slide the pedal frame onto the bass
drum hoop then tighten the hoop
clamp (GP-6065) onto the bass drum
hoop.
To avoid pedal slippage and bass
drum movement, we recommend
placing the bass drum and pedal onto
a carpeted surface.
Lubricate metal-to-metal contact
points periodically to insure smooth
operation. We suggest #SC-GLO
Gibraltar Pedal Lubricant.
15
15
20
