KAMBROOK SAFETY
Welcome to Kambrook and your new Kambrook
Twin Speed Juicer.
At Kambrook, we believe that safe performance
is the first priority in any consumer product so
that you, our valued customer, can confidently
use and trust our appliances.
We ask that any electrical appliance you use
be operated in a sensible fashion with due care
and attention placed on the following important
operating instructions:
IMPORTANT SAFEGUARDS FOR YOUR
KAMBROOK TWIN SPEED JUICER
Carefully read all instructions before operation
and save for future reference.
Remove any packaging material and promotional
stickers and labels before using the Kambrook
Twin Speed Juicer for the first time.
Do not place the Kambrook Twin Speed
Juicer near the edge of a bench or table during
operation. Do not use the Kambrook Twin
Speed Juicer on a metal surface, for example,
a sink drain board. Ensure the surface is dry,
level, clean and free of other substances, as
the vibration during operation may cause the
appliance to move.
Do not place the Kambrook Twin Speed Juicer
on or near a hot gas or electric burner, or where
it could touch a heated oven.
Always ensure the Kambrook Twin Speed Juicer
is properly assembled before use. The appliance
will not operate unless properly assembled.
Any significant spillage onto the surface under or
around the appliance, or onto the appliance itself,
should be cleaned and dried before continuing
to use.
Do not leave the Kambrook Twin Speed Juicer
unattended when in use. Always ensure the
appliance is turned off by switching the speed
control to the ‘0’ position. Then switch the
appliance off at the power outlet and unplug the
cord before attempting to move the appliance,
when not in use, if left unattended and before
disassembling, cleaning or storing.
Do not operate the Kambrook Twin Speed Juicer
continuously with heavy loads for more than 1
minute. Allow the motor to rest for 10 minutes
between each use. Recipes in this instruction
book are not considered a heavy load. However,
hard fruits and vegetables will put excess strain
onto the motor if a low speed is selected.
Keep hands, fingers, hair, clothing, as well as
spatulas and other utensils away from the
Kambrook Twin Speed Juicer during operation.
Do not push food into the feed chute or clear
the feed chute with your fingers, hands or other
utensils during operation. Always use the food
pusher provided. Do not place your hand or
fingers into the food chute without unplugging
the appliance from the power outlet and
dismantling the appliance.
Be careful when handling the stainless steel
filter basket as the small cutting blades at
the base of the filter basket are very sharp.
Mishandling may cause injury.
Do not use the Kambrook Twin Speed Juicer
for anything other than food and/or beverage
preparation.
Always keep the Kambrook Twin Speed Juicer
clean. Follow the cleaning instructions provided
in this book.
IMPORTANT SAFEGUARDS FOR ALL
ELECTRICAL APPLIANCES
Fully unwind the cord before use.
To protect against electric shock, do not
immerse cord, plug or motor base in water or
any other liquid.
Do not allow the cord to hang over the edge
of a table or counter, touch hot surfaces or
become knotted.
This appliance is not intended for use by young
children or infirm persons unless they have been
adequately supervised by a responsible person
to ensure they can use the appliance safely.
Young children should be supervised to ensure
that they do not play with the appliance.
It is recommended to regularly inspect the
appliance. Do not use the appliance if the
power supply cord, plug or appliance becomes
damaged in any way. Return the entire appliance
to the nearest authorised Kambrook Service
Centre for examination, replacement and/or
repair.
Any maintenance other than cleaning should be
performed at an authorised Kambrook Service
Centre.
This appliance is for household use only. Do not
use this appliance for anything other than its
intended use. Do not use in moving vehicles or
boats. Do not use outdoors.
The installation of a residual current device
(safety switch) is recommended to provide
additional safety protection when using
electrical appliances. It is advisable that a
safety switch with a rated residual operating
current not exceeding 30mA be installed in the
electrical circuit supplying the appliance. See
your electrician for professional advice.

3
KNOW YOUR KAMBROOK TWIN SPEED JUICER
7. Cleaning brush (not shown) for easy cleaning
of the stainless steel filter basket.
8. 700mL juice jug with froth separator
(top shelf dishwasher safe).
9. 700 watt motor.
10. 2 speed control.
11. Juicer cover.
12. Filter bowl surround.
13. Non-slip feet.
1. Pulp container (top shelf dishwasher safe).
2. 75mm wide feed chute fits whole fruit and
vegetables.
3. Food pusher.
4. Safety locking handle stops the juicer
operating without the cover locked into
place.
5. Safety lock button.
6. Stainless steel filter basket.
25
4
12
11
8
10 9
6
13
1
3

4
BEFORE FIRST USE
1. Before using your Kambrook Twin Speed Juicer
for the first time, remove any packaging material
and promotional stickers and labels.
2. Ensure that the motor base is switched to the
‘0’ position at the control panel. Ensure the
appliance is switched off at the power outlet and
the power cord is unplugged.
3. Press the safety lock button and pull the safety
locking handle downwards.
4. Remove the food pusher from the feed chute of
the juicer cover.
5. Lift and remove the juicer cover.
6. Lift the filter bowl surround with the stainless
steel filter basket still in place away from the
motor base. The stainless steel filter basket will
lift off with it.
WARNING: TAKE CARE WHEN
HANDLING THE STAINLESS STEEL FILTER
BASKET AS THE SMALL CUTTING BLADES AT
THE BASE OF THE FILTER BASKET ARE VERY
SHARP. MISHANDLING MAY CAUSE INJURY.
7. Lift the pulp container away from the motor
base.
8. Wash the filter bowl surround, filter basket,
juicer cover, food pusher, pulp container and
juice jug in warm, soapy water with a soft cloth.
Rinse and dry thoroughly.The motor base can be
wiped with a damp cloth. Dry thoroughly.
ASSEMBLING YOUR KAMBROOK
TWIN SPEED JUICER
STEP 1
Place the motor base on a flat, dry surface such
as a bench top. Ensure that the motor base is
switched to the ‘0’ position at the control panel,
then switch the appliance off at the power outlet
and unplug the cord.
STEP 2
Place the pulp container into position by
aligning the slots on the pulp container with the
corresponding lugs on the motor base.
NOTE: To minimise cleaning, line the pulp
container with a plastic freezer bag to collect
the pulp.
STEP 3
Place the filter bowl surround on the motor base.
STEP 4
Push the stainless steel filter basket into the filter
bowl surround and push down firmly to connect
onto the motor drive coupling. Ensure it is fitted
securely inside the filter bowl surround and onto
the motor base.
STEP 5
Place the juicer cover over the filter bowl
surround. Slide the food pusher down the feed
chute by aligning the groove of the food pusher
with the small protrusion on the inside top of the
feed chute (facing the safety locking handle).
STEP 6
Raise the safety locking handle up and locate it
onto the latch on the juicer cover until it clicks
into place.The juicer will not operate unless the
safety locking handle is correctly locked into
position.

5
STEP 7
Place the juice jug provided under the spout on the
right-hand side of the Kambrook Twin Speed Juicer.
Alternatively, place a glass or another suitable
container underneath the spout.
OPERATING YOUR KAMBROOK
TWIN SPEED JUICER
STEP 1
Wash selection of fruit and vegetables to be juiced.
NOTE: Most fruit and vegetables such as apples,
carrots and cucumbers will not need to be cut or
trimmed to size as these will fit whole into the feed
chute. Ensure vegetables such as beetroot, carrots,
etc. have all soil removed, are well washed and
trimmed of leaves before juicing.
STEP 2
Ensure the Kambrook Twin Speed Juicer is
correctly assembled. Refer to Assembling your
Kambrook Twin Speed juicer (page 4). Ensure the
juice jug (or a glass) is placed under the spout
and the pulp container is in position before
commencing juicing.
STEP 3
Plug the power cord into a 230/240V power
outlet.Turn the power on at the power outlet
and adjust the speed control dial to either the ‘1’
or ‘2’ position depending on the type of fruit or
vegetable being juiced. Refer to the speed selector
table to determine the correct speed for the fruits
and vegetables being juiced.
FRUIT / VEGETABLES SUGGESTED
SPEED
Apples 2
Apricots (stone removed) 1
Beetroot (cleaned, trimmed) 2
Blueberries 1
Broccoli 2
Brussel sprouts (trimmed) 2
Cabbage 2
Carrots (cleaned) 2
Cauliflower 2
Celery 2
Cucumber 1
Fennel 2
Grapes (seedless) 1
Kiwi fruit (peeled) 1
Mangoes (peeled, stone removed) 1
Melons (peeled) 1
Nectarines (stone removed) 1
Oranges (peeled) 2
Peaches (stone removed) 1
Pears hard (stalks removed) 2
Pears soft (stalks removed) 1
Pineapple (peeled) 2
Plums (stone removed) 1
Raspberries 1
Tomatoes 1
Watermelon (peeled) 1
STEP 4
With the motor running, place food into the feed
chute and use the food pusher to gently guide food
down.To extract the maximum amount of juice,
always push the food pusher down slowly. If too much
food is being processed at one time or the pieces are
not small enough the motor may stall.Try trimming
food, cutting food into smaller pieces of even size
and/or processing a smaller amount per batch.
STEP 5
As fruit and vegetables are processed, juice will
flow into the juice jug and the separated pulp will
accumulate in the pulp container.The pulp container
can be emptied during juicing by turning the
Kambrook Twin Speed Juicer to the ‘0’ position at
the control panel, tilting the juicer and then carefully
removing the pulp container.
Replace the empty pulp container into position
before continuing to juice.
NOTE: Do not allow the pulp container to overfill as this
may affect the operation of the appliance.
To minimise cleaning, line the pulp container with a
plastic freezer bag to collect the pulp. Pulp can then
be used in other dishes or as compost for the garden
or discarded.
To include the froth with your juice, simply
remove the froth separator from the juice jug before
pouring juice into a glass.

6
WARNING: NEVER USE FINGERS, HANDS
OR OTHER UTENSILS TO PUSH FOOD DOWN
THE FEED CHUTE OR TO CLEAR THE FEED
CHUTE DURING OPERATION. ALWAYS USE
THE FOOD PUSHER PROVIDED.
CARE AND CLEANING
DISASSEMBLING THE JUICER
1. Ensure that the Kambrook Twin Speed Juicer
is turned off by switching the motor base to
the ‘0’ position at the control panel. Ensure the
appliance is switched off at the power outlet
and the power cord is unplugged.
2. Press the safety lock button and pull the safety
locking handle downwards.
3. Remove the food pusher from the feed chute
of the juicer cover.
4. Lift and remove the juicer cover.
5. Lift the filter bowl surround with the stainless
steel filter basket still in place away from the
motor base. The stainless steel filter basket will
lift off with it.
6. Lift the pulp container away from the motor
base.
WARNING: TAKE CARE WHEN HANDLING
THE STAINLESS STEEL FILTER BASKET AS
THE SMALL CUTTING BLADES AT THE BASE
OF THE FILTER BASKET ARE VERY SHARP.
MISHANDLING MAY CAUSE INJURY.
NOTE (For easier cleaning): Clean as you go and avoid
dried on juice or pulp residue. Immediately after each
use, rinse removable parts in hot water to remove wet
pulp.Allow parts to air dry.To minimise cleaning, line
the pulp container with a plastic freezer bag to collect
the pulp. Pulp can then be used in other dishes or as
compost for the garden or discarded.
CLEANING THE FILTER BOWL
SURROUND, JUICER COVER, PULP
CONTAINER
1. Wash all parts in warm soapy water with a soft
cloth. Rinse and dry thoroughly.
NOTE: The pulp container is top shelf dishwasher safe
only
CLEANING THE FOOD PUSHER
The cover of the food pusher is removable to clean
residual juice that may have ingressed into the food
pusher during juicing.
1. To remove the cover from the food pusher, insert
a flat utensil (such as a screw driver) under the
indent located at the top of the food pusher and
lift the cover up.
2. Wash the cover and food pusher in warm soapy
water with a soft cloth. Rinse and dry thoroughly.
CLEANING THE FILTER BASKET
For consistent juicing results always ensure that the
stainless steel filter basket is thoroughly cleaned
using the supplied cleaning brush.
1. Soak the stainless steel filter basket in hot
soapy water for approximately 10 minutes
immediately after juicing is completed. If pulp
is left to dry on the filter it may clog the fine
pores of the filter mesh thereby lessening
the effectiveness of the juicer.
2. Using the cleaning brush, hold the filter basket
under running water and brush from the inside
of the basket to the outer rim. Avoid touching
the small sharp blades in the centre of the filter
basket. After cleaning the filter basket, hold
it up towards a light to ensure the fine mesh
holes are not blocked. If the holes are blocked,
soak the filter basket in hot water with 10%
lemon juice to loosen the blocked holes.
NOTE: Do not place the stainless steel filter basket
in the dishwasher, soak in bleach or other abrasive
cleansers.Always treat the stainless steel filter basket
with care as it can be easily damaged.
WARNING: THE STAINLESS STEEL FILTER
BASKET CONTAINS SMALL SHARP BLADES
TO CUT AND PROCESS FRUITS AND
VEGETABLES. AVOID TOUCHING BLADES
WHEN HANDLING THE FILTER BASKET.
CLEANING THE JUICE JUG
Rinse the juice jug and froth separator under
running water.
Wash both parts in warm soapy water with a soft
cloth. Rinse and dry thoroughly.
NOTE:The juice jug and froth separator are top shelf
dishwasher safe only.
CLEANING THE MOTOR BASE
1.Wipe the motor base with a soft, damp cloth
then dry thoroughly.
2.Wipe any excess food particles from the power
cord.
NOTE: Do not use abrasive scouring pads or cleaners
when cleaning the parts or motor base as they may
scratch the surface.
REMOVING STUBBORN OR STRONG
FOOD STAINS AND ODOURS
Discolouration of the plastic may occur when using
strongly coloured fruit and vegetables.To help
prevent this, wash parts immediately after use. If
discolouration does occur, the plastic parts can be
soaked in water with 10% lemon juice or they can
be cleaned with a non abrasive cleaner.

7
HEALTH BOOSTERS
RASPBERRY, PEAR AND STRAWBERRY
The large number of seeds in raspberries makes
them a rich source of dietary fibre. They are also
rich in vitamin C.
1 cup frozen raspberries (allow to thaw until just
soft)
1 punnet strawberries, hulled
1 medium pear, stem removed
Process all ingredients through the juicer and
serve immediately.
GRAPEFRUIT, GINGER & FENNEL
BOOSTER
This booster promotes digestion while providing
a healthy dose of vitamin C.
1 medium grapefruit, peeled and segmented
1 small apple
1 small fennel bulb, trimmed and sliced
2cm piece of ginger, peeled
Process all ingredients through the juicer and
serve immediately.
JUICE REMEDIES
MELON MAGIC
This cooling juice is excellent for relieving both
dehydration and fluid retention.
1½ cups cubed cantaloupe melon, skin removed
1½ cups cubed honeydew melon, skin removed
4 strawberries, hulled
Process all ingredients through the juicer and
serve immediately.
BLACKBERRY JUICE
Blackberries are a rich source of flavonoids,
which help strengthen the structure of the veins.
Pears and oat bran assist further by providing
dietary fibre.
1 cup blackberries
1 medium pear, stem removed
3 teaspoons oat bran
Process blackberries and pear through the juicer.
Pour into a glass and whisk in the oat bran. Serve
immediately.
APPLE, CRANBERRY & RUBY
GRAPEFRUIT
The apples give this tonic a deliciously sweet
flavour.
1 medium apple
1 medium ruby grapefruit, peeled and segmented
1 cup frozen cranberries (allow to thaw until just
soft)
Process all ingredients through the juicer and
serve immediately.
RECIPES

8
WEIGHT LOSS & DETOX
CUCUMBER, CELERY & BEETROOT
Beetroot stimulates liver function and is a
powerful cleanser for the body.
1 small cucumber
¼ bunch celery, trimmed
4 small or 2 large beetroots, stalks removed and
scrubbed
Process all ingredients through the juicer and
serve immediately.
PINEAPPLE, MELON & GRAPE
The enzyme in pineapple suppresses the
appetite, while the melon and grapes provide a
tasty and nutritious base.
½ pineapple, peeled and sliced
¼ ripe cantaloupe melon, peeled and sliced
1 cup seedless green grapes
Process all ingredients through the juicer and
serve immediately.
TASTE SENSATION
WATERMELON, APRICOT &
STRAWBERRY
2 cups cubed watermelon, peeled and seeded
6 apricots, stoned
1 punnet strawberries, hulled
Process all ingredients through the juicer and
serve immediately.
PASSION JUICE
3 ruby oranges, peeled
½ lime, peeled
1 passion fruit
Process the oranges and the lime through the
juicer. Scoop out the passion fruit flesh with a
spoon and stir into the prepared juice. Serve
immediately.
TROPICAL BLEND
1 mango, halved and peeled with stone removed
1½ kiwi fruit, peeled
½ cup fresh mint leaves
¼ pineapple, trimmed and sliced
½ cup crushed ice
Process fruits and mint through the juicer.
Scoop ice into glasses. Pour juice over and serve
immediately
RECIPES

9
Notes

10
KAMBROOK 12 MONTH REPLACEMENT WARRANTY
Kambrook warrants the purchaser against
defects in workmanship and material for a
period of 12 months from the date of purchase
(3 months commercial use).
Guarantee and purchase receipt for this
product are to be retained as proof of purchase
and must be presented if making a claim under
the Kambrook guarantee.
Kambrook reserves the right to replace or
repair the appliance within the warranty period,
Warranty does not apply to any defect,
deterioration, loss, injury or damage occasioned
by, or as a result of the misuse or abuse,
negligent handling or if the product has not been
used in accordance with the instructions. The
guarantee excludes breakages and consumable
items such as kneading blades.
This warranty is void if there is evidence of the
product being tampered with by unauthorised
persons.
If the product includes one or a number of
accessories only the defective accessory
or product will be replaced. In the event of
Kambrook choosing to replace the appliance,
the guarantee will expire at the original date, i.e.
12 months from the original date of purchase.
In Australia, this KAMBROOK Guarantee is
additional to the conditions and guarantees
which are mandatory as implied by the Trade
Practises Act 1974 and State and Territory
legislation.
For service, spare parts or product information
in Australia, please call KAMBROOK on the
Customer Service Line; 1300 139 798.
For service, spare parts or product information
in New Zealand, please call KAMBROOK New
Zealand; 0800 273 845. For spare parts phone
0800 273 845.
If claiming this guarantee the product must be
returned freight prepaid.
YOUR PURCHASE RECORD (Please complete)
DATE OF PURCHASE ___________________
MODEL NUMBER ______________________
SERIAL NUMBER ______________________
PURCHASED FROM ____________________
Kambrook - Australia
461 Plummer Street, Port Melbourne, 3207, Australia
Customer Service Line 1300 139 798
Customer Service Fax [phone]
Kambrook - New Zealand
Private Bag 94411, Greenmount, Auckland, New Zealand
Customer Service Line/Spare Parts 09 271 3980
Customer Service Fax [phone]
Attach a copy of the purchase receipt here.
(Please don’t return purchase record until you
are making a claim)
Due to continual improvement in design or otherwise, the product you purchase may differ slightly from the illustration in this book. Issue 1/06
