Kammok Weaver Manual

Hammock straps x16
Parts Included
Flip for Instructions
Poles (24 total)
Weaver
Community Hammock Structure Setup Instructions3.0
Designed in Austin, Texas | Made in USA
V x14
What You’ll Need
1/2” wrench 1/2” socket wrench
W x2
X x2
Y x2
Z x4
Joints x 12
Hardware
5/16” 2.5” bolts x48
(with x48 nuts and x48 washers)

All of the bolts should be assembled as
shown right. There should be a washer on
each side and the bolt should come from
the outside into the inside of the structure.
PLEASE NOTE:
Place 6 joints and 6 “V” pipes to make the base.
1 Layout Weaver base
Weaver Setup Instructions Page 1
Assemble 6 “A” frames with joints.
Ensure that two have a W and a V
pipe, two have a V and an X pipe, and
two have two V pipes.
3 Create “A” frames
V
V V
V V
V
Join the 6 joints and 6 “V” pipes with bolts.
Note: Now is the easiest time to adjust the location of the Weaver.
2 Assemble Weaver base
V V
A3
W V
A1
V X
A2
V V
A3
W V
A1
V X
A2

Arrange the “A” frames around the weaver as shown
above. Ensure that the bottom hooks on “A1” frame
and “A2” frame point at each other and that duplicate
frames face opposite one another.
4 Place the “A” frames
Weaver Setup Instructions Page 2
W
V
X
X
V
V
V
V
V
V
V
W
A2
A2
A3
A3
A1
A1
Place one “A” frame into the base as shown. This is
most easily done with 3 (or more) people, one on each
side of the “A” frame and one (or more) placing the bolts
into the joints as the “A” frame is lowered into place.
5AAssemble the “A” frames to the base
A1
W
V
X
X
V
V
V
V
V
A2
A2
A3
A3

Weaver Setup Instructions
Continue to work your way around the Weaver,
raising and installing the “A” frames.
5BRepeat process
Page 3
A1
W
V
V
X
X
V
V
V
V
W
A2
A2
A3
A1
A3
This is what the Weaver will look like once
you finish installing the “A” frames.
5CFinish assembling the “A” frames to the base
A3
W
XX
W
A1
A1
A3
A2 A2

W
X
A1
A2
A3
Z
Z
Begin with the top by placing a Y pole between a A1and A2frames.
Make sure the hooks on Y are facing towards the inside of the Weaver.
This is easily done with one or two people holding the pole and one or
more others helping align the pole into the joint, securing with a bolt.
6AAssemble the top
Next place a Z pole between the A2and A3frames with the hook
closest to the A3frame. Then place another Z pole between the
A3frame and the A1frame with the hook closest to the A3frame.
6BAssemble the top
Weaver Setup Instructions Page 4
Y
W
X
A1
A2
Y
z
Y z
z Y
z
Layout of Weaver
top poles

Weaver Setup Instructions
Repeat the previous two steps to finish the top. The
final product should look like the picture below. Ensure
that the two Y poles are across from each other.
6CAssemble the top
Z
Z
Z
Y
Y
Z
Page 5
On the bottom layer, place hammocks on the hooks facing towards each other. The bottom hooks
go together and the top hooks go together.
Using the short straps provided, loop the strap through itself on the last loop and pull through (as
shown below). Then clip in the hammock, making sure that the hammocks don’t rub the ground.
Congratulations! Now hop in a hammock. You deserve it!
7 Install the hammocks
