KanexPro EXT-PROCTRL User manual

VER 1.0
All Right Reserved
MPN: EXT-PROCTRL
Flexible Matrix System Controller powered
by SDVoE w/ POE & RS-232

2
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate this equipment
and before connecting the power supply. Please keep the following in mind as you unpack
and install this equipment:
• Always follow basic safety precautions to reduce the risk of fire,
• electrical shock and injury to persons.
• To prevent fire or shock hazard, do not expose the unit to rain, moisture
• or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings or empty
slots in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to be placed
upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings in the unit
housing that provide ventilation and allow for sufficient space for air to circulate
around the unit.
• Please completely disconnect the power when the unit is not in use to avoid wasting
electricity.

3
CONTENTS
1. Introduction……………………………………………......…………………………………………………….............……………………….1
2. Applications……………………………………………………..………………………………………………..............…………………….…1
3. PackageContents……………………………………………………………………………………….............…………………………..2
4. SystemRequirements………………………………………………………………………………….............…………………………2
5. Features………………………………………………………………………………………………………….............…………………………..2
6. Operation Controls and Functions…………………………………………………………...............……………………….3
6.1 Front Panel………………………………..………………………………………………………………………………………….….3
6.2 RearPanel……………………………………..……………………………………………………………………………………….…3
6.3 RemoteControl………………………………...…………………………………………………………………………..………..4
6.4 IR Cable Pinouts………………………………..………………………………………………………………………………….…5
6.5 RS-232 Pinout and Defaults……………………………………………………………………………………………....5
6.6 WebGUIControl…………………………………………………………………………………………………...…………………6
6.6.1 Monitor & Control Tab…………………………………………………………………………………………...…………....8
6.6.2 System Tab…………….…………………………………………………………………………………………………..21
6.6.3 Settings Tab………….……………………………………………………………………………………………….….24
6.6.4 Transmitter Tab………..………………………………………………………………………………………………35
6.6.5 Receiver Tab……………….………………………………………………………………………………………….…39
6.6.6 Scaling Tab……….………………………………………………………………………………………………….……43
6.6.7 Video Wall Tab…………….…………………………………………………………………………………………..44
6.6.8 Multiview Tab…………………………………………………………………………………………………...………46
6.7 TelnetControl……………………………………………………………………………………..…………………………………48
6.8 RS-232 and Telnet Commands……………………………………………………….……………………………….49
7. ConnectionDiagram…………………………………………………........……………………………..………………………………60
8. Specifications…………………………………………………………………........…………………………..……………………………….61
8.1 TechnicalSpecifications……………………………………...………………………………..…………………………….61
8.2 Video Specifications………………………………………………………………………………..………………………....62
8.3 Cable Specifications……………………………………………………………………………………..…………………....64
9. Acronyms………………………………………………………………………………………………………………..........…………..………65

4
1. INTRODUCTION
The KanexPro SDVoE powered Modular Matrix system is the most versatile flexible
video distribution solution. The system is composed of transceiver devices that can be
configured as either video transmitters or receivers with a simple click of a mouse. The
whole system is controlled and configured by a single control module which makes
setup a snap. Add the system to a 10G network and enjoy UHD 4K Lossless video with
zero latency.
The KanexPro Modular Matrix Controller (EXT-PROCTRL) is a powerful and flexible tool
for controlling multiple SDVoE (Software Defined Video over Ethernet) based extender
transceivers within same network. Install this unit onto the same local network as the
extenders to easily define and configure channel routing selections using the WebGUI. It
is also possible to define and switch routes using customized groups or presets allowing
for easy control over multiple video zones. Without the use of this controller, each
individual Transmitter and Receiver pair could only be configured in a basic point-to-
point operational mode.
Additionally, this unit supports controlling and configuring the matrix, video wall, and
multiviewer modes of connected SDVoE units. The settings of all connected transmitter/
receiver units, including IP configuration, compatibility settings, and extender status are
clearly displayed within the WebGUI. A trigger input interface is also provided to allow the
easy addition of a remote control keypad, or other trigger-supporting products, which can
be installed within a podium or table in a conference room or classroom. This interface can
allow the user to activate stored macros with the simple press of a button. Standard control
is available via WebGUI (remote or local), RS-232, Telnet and IR Remote.
2. APPLICATIONS
• Video/TV wall display and control
• Security surveillance and control
• Commercial advertising, display and control
• Home Theaters with Smart Home Controls
• Retail sales and demonstration
3. PACKAGE CONTENTS
• 1x EXT-PROCTRL IP Master Controller (SDVoE)
• 1x 5V/2.5A DC Power Adapter
• 1x Terminal Block (3-pin)
• 3x Terminal Block (5-pin)
• 1x IR Extender Cable
• 1x Remote Control (CR-183)
• 1x Shockproof Feet (Set of 4)
• 1x Operation Manual

5
4. SYSTEM REQUIREMENTS
• An active network connection from a switch or router for control of compatible AV
over IP devices.
5. FEATURES
• Enables the management and configuration of multiple compatible SDVoE extenders
through a single WebGUI
• Provides control over the independent routing of video, audio and control signals
between all local compatible transmitters and receivers
• Control over matrix, video wall, and multiviewer modes using WebGUI macros
• WebGUI clearly displays the status of all connected Transmitters and Receivers,
including IP address, channel selection, etc.
• Can generate serial commands to directly control an external serial-controllable device
• Can be powered by Ethernet switches supporting the IEEE 802.3af 2003 PoE
standard (Optional)
• Trigger Control Keypad support for easy, single-button, macro activation (Optional)
• Standard control is available via WebGUI (remote or local), RS-232, Telnet, and IR Remote
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
1. POWER LED: This LED will illuminate to indicate the unit is on and receiving power.
2. IR Window: Accepts IR signals from the included IR remote for control of this unit only.
6.2 Rear Panel
1. IR EXT Port: Connect to the provided IR Extender to extend the IR control range
of the unit. Ensure that the remote being used is within direct line-of-sight of the IR
Extender.
2. CONTROL 5-pin Terminal Block: Connect to a serial controllable device for the
transmission of RS-232 signals.
3. RS-232 3-pin Terminal Block: Connect to a PC, laptop or other serial control device
with a 3-pin adapter cable to control the unit via RS-232.
4. TRIGGER IN 10-pin Terminal Block: Connect to the Trigger Control Keypad
POWER
1 2
IR

6
(OPTIONAL) or any device with trigger switch functionality such as window security
alarms, motion detectors, door switches, etc. Each of the 8 trigger inputs will activate
the associated macro (1~8) when triggered.
Note: A minimum of 5V DC is required to activate each trigger.
5. HDMI OUT Port: Connect to a standard HDMI display to view the unit’s current status
information and access the WebGUI directly without a PC.
Note: HDMI output is locked to a resolution of 1080p@60Hz.
6. USB Port: Connect a USB mouse and keyboard to control the unit’s WebGUI
displayed on the HDMI output port. Firmware update via USB is also supported.
Note: Specialized USB control devices, such as a touch panel, should be connected before the unit
is powered on.
7. LAN 2 Port: Connect directly, or through a network switch, to your PC/ laptop to
control the unit via WebGUI/Telnet.
8. LAN 1(POE) Port: This port is used to connect to the SDVoE devices to be controlled.
Connect to the SDVoE units’ private network through their dedicated network switch,
to enable detection and control over those units.
Note: If the connected network switch supports the IEEE 802.3af 2003 PoE (Power over Ethernet)
standard, this unit can optionally be powered directly via this Ethernet port.
FACTORY RESET Pinhole: Press and hold for 3 seconds to reset the unit to its factory defaults,
including Ethernet settings.
Note: While the reset is in process, the LEDs on the front of the unit will flash. Once the reset is complete, the
unit will return to normal operation. DC 5V Port: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power. (Optional, not required if the unit is powered via PoE).
6.3 Remote Control
1. PRESET 1~8: Press any of the 8 buttons to activate the saved preset associated with
that number.

7
6.4 IR Cable Pinouts
6.5 RS-232 Pinout and Defaults
6.6 WebGUI Control
• Device Discovery
Please obtain the “Device Discovery” software from your authorized dealer and save it in
a directory where you can easily find it.
Connect the unit and your PC/Laptop to the same active network and execute the
“Device Discovery” software. Click on “Find Devices on Network” and a list of devices
connected to the local network will show up indicating their current IP address.
Note: This unit defaults to DHCP mode. The current IP address can be verified using the HDMI
output or RS-232 if the Device Discovery software is not available.
By clicking on one of the listed devices you will be presented with the network details of
that particular device.

8
1. IP Mode: If you choose, you can alter the static IP network settings for the device,
or switch the unit into DHCP mode to automatically obtain proper network settings
from a local DHCP server. To switch to DHCP mode, please select DHCP from the IP
mode drop-down, then click “Save” followed by “Reboot”.
2. WebGUI Hotkey: Once you are satisfied with the network settings, you may use
them to connect via Telnet or WebGUI. The network information window provides a
convenient link to launch the WebGUI directly.
• WebGUI Overview
After connecting to the WebGUI’s address in a web browser, the WebGUI will load and
display the System tab. Click “Login” to open the authentication window. Please enter
the appropriate user name and password then click “Enter” to log in. If a keyboard is not
available, such as when using a touch screen, an on-screen keyboard can be activated
by clicking on the keyboard icon ( ).
Note: The default user name and password is “admin”.
After logging in, on the left side of the browser you will see the following menu tabs
where all primary functions of the unit are controllable via the built in WebGUI. The
individual functions will be introduced in the following sections.
Clicking the “Logout” button within the “System” tab will log the currently connected
user out of the WebGUI and return to login page.
Note: When not logged in, only the “Monitor & Control” and “System” tabs are available.

9
6.6.1 Monitor & Control Tab
This tab provides easy to use drag-and-drop control over all basic routing functionality
of the transmitters and receivers that have been detected within the local network. In all
sections, except for the Video section, transmitters are represented by the source icon
( ) and receivers are represented by the display icon ( ). Each of this tab’s sections
control the routing of a different type of interface that can be found on most compatible
transmitters, receivers or transceivers. These interfaces are: Video routing, Video Wall
routing, Multiview selection, HDMI Audio routing, Analog Audio routing, USB routing,
IR routing, RS-232 routing, and Macro activation. This tab’s controls are available even
when a user is not logged in, providing basic control over routing without exposing
system critical configuration areas.
Note: Units that were previously a part of the system, but are not currently detected will still be
displayed, however they will have a disconnected icon ( ) and cannot be used for routing.
1. Video Routing: Provides drag-and-drop control over the video routing between all
detected transmitters and receivers. Each transmitter and receiver box will display a
small, low framerate, video thumbnail to indicate what video is currently active.
Note: Certain operational modes (multiview, video wall) and some transmitters and receivers do
not support the video thumbnail feature.
• Video Transmitter: This section provides drag-and-drop buttons for all transmitters
detected by the system as well as a multi-option button target to stop video streams
from being transmitter.
Note: The IP Master Controller has an automatic bandwidth reduction feature to prevent situations
where a source’s streams will exceed 10Gbps, but in the unlikely event a transmitter’s streams
still require more bandwidth than is available, the video output may become visually unstable. In
these situations, it is recommended to reduce the resolution, framerate, or bit depth of the original
source.

10
• Source to Single Receiver Routing: To route a source to a receiver, click and drag
the source’s button on the left to the preferred display on the right side, then release
the mouse button. If the routing was completed successfully, the newly routed
source’s name will appear below the display’s name within the button. Clicking on
any source button will change the color of itself, and all currently routed displays.
Note: Receivers may also be drag and dropped onto sources to activate a new route.
• Source to Multiple Receiver Routing: To route a source to multiple receivers at the
same time, click and drag the source’s button on the left to a pre-defined Video Group
or “All” button on the right side, then release the mouse button. If the routing was
completed successfully, the source’s name will appear within all appropriate buttons.
• All/Native/Multiview Stream Stop: In certain situations, it may become necessary
to stop one or all of the video streams coming from a source. To do this, first select
the type of stream to stop by clicking on the cycle selection icon ( ) at the bottom
of the window until the preferred option (All Stop, Native Stop, Multiview Stop) is
displayed. Next, click and drag the source down to the chosen “Stop” button. The
chosen stream type will be immediately terminated. To stop a stream type from
ALL video streams simultaneously, drag the “All” button down to the chosen “Stop”
button. “All Stop” stops all stream types from the selected source, “Native Stop”
stops only the full resolution primary video stream, “Multiview Stop” stops only the
secondary video stream used by multiviewer layouts.
• Video Receiver: This section provides drag-and-drop buttons for all receivers
detected by the system as well as a button target to stop one or all output streams
from being displayed.
• Stop Stream: To stop the video stream on a single display, drag the display down to
the “Stop” button at the bottom of the window, then release the mouse button. To
stop ALL video outputs, drag the “All” button down to the “Stop” button.
• Status Icons: Status icons will be displayed instead of a video thumbnail image under
the following conditions:

11
1. Video Wall Routing: Provides drag-and-drop source selection for pre-defined video
wall groups.
Note: Video wall groups are defined within the Video Wall tab, please see section 6.6.7 for more
information.

12
• Group: All currently defined video wall groups will be listed under the “Group”
heading. Clicking on a group’s icon will display a simplified graphical representation
of the video wall on the right side of the page in the Group View.
• Transmitter: All sources will be listed under the “Transmitter” heading. To assign a
source to a video wall group, drag the transmitter to the preferred group.
Note: Dragging a source to a previously inactive video wall group will automatically activate the
video wall on all associated displays.
• Group View: Shows a simplified graphical representation of the currently selected
video wall group. If the video wall is active the windows will be green and display a
faded video thumbnail of the currently selected source. If one or more of the displays
in the group is not currently active, those windows will be blue.
2. Multiview Selection: Provides drag-and-drop output selection and window source
selection for pre-defined multiviewer presets.
Note: Multiviewer presets are defined within the Multiviewer tab, please see section 6.6.8 for more
information.
• Preset: All currently defined multiviewer presets will be listed under the “Preset”
heading. To display a multiviewer preset on a specific output, drag the preset onto
the preferred receiver.
• Receiver: All displays will be listed under the “Receiver” heading. Clicking on a
display that currently has a multiviewer preset assigned to it will display a simplified
graphical representation of the preset on the right side of the page in the Multiviewer
View.
• Multiviewer View: Shows a simplified graphical representation of the currently
selected multiviewer preset. If the preset is active the windows will be green and

13
display a faded video thumbnail of each window’s currently selected source.
• Transmitter: All sources are listed here with any currently unavailable sources
displayed in red. To assign a new source to an existing Multiview layout’s window,
drag the source to the preferred window within the Multiviewer View.
Note: A single source cannot be simultaneously displayed in differently sized windows or in
multiple presets at different output resolutions.
3. HDMI Audio Routing: Provides drag-and-drop control over the independent HDMI
audio routing of all detected transmitters and receivers.
Note: Bitstream audio is only supported when the receiver’s HDMI audio device setting is set to
“HDMI Audio (Follow Video in Genlock Mode)”.
• HDMI Audio Transmitter: This section provides drag-and-drop buttons for all
transmitters detected by the system as well as a button target to stop one or all
independent HDMI audio streams from being transmitted.
• Source to Single Receiver Routing: To route an HDMI audio source to a receiver,
click and drag the source’s button on the left to the preferred display on the right
side, then release the mouse button. If the routing was completed successfully, the
newly routed source’s name will appear below the display’s name within the button.
Clicking on any source button will change the color of itself, and all currently routed
displays.
Note: Receivers may also be drag and dropped onto sources to activate a new route.

14
• Source to Multiple Receiver Routing: To route an HDMI audio source to multiple
receivers at the same time, click and drag the source’s button on the left to a
Group button or the “All” button on the right side, then release the mouse button.
If the routing was completed successfully, the source’s name will appear within all
appropriate buttons.
• Stop Stream: To stop the independent HDMI audio stream from a single source, drag
the source down to the “Stop” button at the bottom of the window, then release the
mouse button. To stop ALL independent HDMI audio streams drag the “All” button
down to the “Stop” button.
Note: When a receiver’s HDMI Audio is set to “Follow Video in Genlock Mode” and scaling on that
output has been disabled (Bypass), the audio output on that receiver cannot be stopped by using
this control.
• HDMI Audio Receiver: This section provides drag-and-drop buttons for all receivers
detected by the system as well as a button target to stop one or all independent
HDMI audio streams.
Note: When a receiver’s HDMI Audio is set to “Follow Video in Genlock Mode” and scaling on
that output has been disabled (Bypass), the HDMI audio routing selection is ignored, and the
audio embedded with the HDMI source will always be output. In these instances a (!) mark will be
displayed.
• Stop Stream: To stop the HDMI audio stream on a single display, drag the display
down to the “Stop” button at the bottom of the window, then release the mouse
button. To stop HDMI audio on ALL video outputs, drag the “All” button down to the
“Stop” button.
Note: When a receiver’s HDMI Audio is set to “Follow Video in Genlock Mode” and scaling on that
output has been disabled (Bypass), the independent audio route will be stopped, however the
HDMI embedded audio will continue to be output normally.

15
4. Analog Audio Routing: Provides drag-and-drop control over the routing of analog
audio input streams between all detected transmitters and receivers.
• Analog Audio Transmitter: This section provides drag-and-drop buttons for all
analog input sources detected by the system as well as a button target to stop one
or all analog audio streams from being transmitted.
• Source to Single Receiver Routing: To route an analog audio source to a receiver, click
and drag the source’s button on the left to the preferred receiver on the right side, then
release the mouse button. If the routing was completed successfully, the newly routed
source’s name will appear below the receiver’s name within the button. Clicking on any
source button will change the color of itself, and all currently routed receivers.
Note: Receivers may also be drag and dropped onto sources to activate a new route
• Source to Multiple Receiver Routing: To route an analog audio source to multiple
receivers at the same time, click and drag the source’s button on the left to a
Group button or the “All” button on the right side, then release the mouse button.
If the routing was completed successfully, the source’s name will appear within all
appropriate buttons.
• Stop Stream: To stop the analog audio stream from a single source, drag the source
down to the “Stop” button at the bottom of the window, then release the mouse
button. To stop ALL analog audio streams, drag the “All” button down to the “Stop”
button.
• Analog Audio Receiver: This section provides drag-and-drop buttons for all analog
audio outputs detected by the system as well as a button target to stop the output
of one or all analog audio streams.
Note: If the selected audio source for an analog output has been set to “HDMI Audio (Stereo

16
Downmix)” that output will be marked with a (!) and the audio output will mirror the source set on
the HDMI Audio routing page.
• Stop Stream: To stop the analog audio output on a single receiver, drag the receiver
down to the “Stop” button at the bottom of the window, then release the mouse
button. To stop ALL video outputs, drag the “All” button down to the “Stop” button.
Note: If the selected audio source for an analog output has been set to “HDMI Audio (Stereo
Downmix)” the audio output can only be stopped from the HDMI Audio page.
5. USB Pairing: Provides drag-and-drop control over the pairing of USB hosts (PC,
laptop, etc.) and USB devices (keyboard, mouse, webcam, etc.) between the ports
detected on all transmitters and receivers.
Note: When a USB host port has enabled “Simultaneous Mode”, it can be paired with up to 7
device endpoints. If “Simultaneous Mode” is disabled, a USB host port can only be paired with a
single USB device endpoint.
• USB Host: This section provides drag-and-drop buttons for detected USB host ports
as well as a button target to stop communication from a host.
• Host to Device Pairing: To pair a USB host with a USB device, click and drag the USB
host’s button on the left to the preferred USB device on the right side, then release
the mouse button. If the pairing was completed successfully, the active USB host’s
name will appear below the USB device’s name within the button. Clicking on any USB
host button will change the color of itself, and all currently paired USB device endpoints.
Note: USB devices may also be drag and dropped onto USB hosts to activate a new pairing.

17
• Stop Host: To stop communication from a USB host, drag the USB host down to the
“Stop” button at the bottom of the window, then release the mouse button.
• USB Device: This section provides drag-and-drop buttons for all detected USB
device endpoints as well as a button target to stop communication from a device.
• Stop Device: To stop communication from a USB device, drag the USB device down
to the “Stop” button at the bottom of the window, then release the mouse button.
6. IR Routing: Provides drag-and-drop control over the routing of the IR inputs and
outputs detected on all transmitters and receivers.
Note: An IR output can be routed to by multiple IR inputs, however each IR input may only be
directly routed to a single IR output. If an IR input needs to be sent to more than one output, the
Global Broadcast option must be used.
• IR Input: This section provides drag-and-drop buttons for all IR input ports detected by the
system as well as a button target to stop one or all IR streams from being transmitted.
• IR Input Global Broadcast: To broadcast an IR input to all available IR outputs,
click and drag the IR input’s button on the left to the “All” button on the right side,
then release the mouse button. If the routing was completed successfully, the word
“Broadcast” will appear within the appropriate IR input’s button.
• Stop Stream: To stop the broadcast of an IR signal from a single IR input, drag the
IR input down to the “Stop” button at the bottom of the window, then release the
mouse button. To stop the transmission of ALL IR signals, drag the “All” button down
to the “Stop” button.
• IR Output: This section provides drag-and-drop buttons for all IR output ports
detected by the system.

18
• IR Output to IR Input Routing: To connect an IR output to an IR input, click and
drag the IR output’s button on the right to the preferred IR input on the left side,
then release the mouse button. If the routing was completed successfully, the newly
routed IR output’s name will appear below the IR input’s name within its button.
Clicking on any IR output button will change the color of itself, and all IR inputs
currently routed to it.
Note: IR inputs may also be drag and dropped onto IR outputs to activate a new route.
7. RS-232 Routing: Provides drag-and-drop control over the routing of the RS-232
senders and receivers detected on all transmitters and receivers. The RS-232 port on
a standard extension unit contains one sender (Rx pin) and one receiver (Tx pin).
Note: An RS-232 receiver can be routed to by multiple RS-232 senders, however each RS-232
sender may only be directly routed to a single RS-232 receiver. If an RS-232 sender needs to be
sent to more than one receiver, the Global Broadcast option must be used.
• RS-232 Sender: This section provides drag-and-drop buttons for all RS-232 senders
detected by the system as well as a button target to stop one or all RS-232 streams
from being transmitted.
• RS-232 Sender Global Broadcast: To broadcast an RS-232 sender to all available RS-
232 receivers, click and drag the RS-232 sender’s button on the left to the “All” button on
the right side, then release the mouse button. If the routing was completed successfully,
the word “Broadcast” will appear within the appropriate RS-232 sender’s button.
• Stop Stream: To stop the broadcast of an RS-232 signal from a single RS-232 sender,
drag the RS-232 sender down to the “Stop” button at the bottom of the window,
then release the mouse button. To stop the transmission of ALL RS-232 signals, drag
the “All” button down to the “Stop” button.

19
• RS-232 Receiver: This section provides drag-and-drop buttons for all RS-232
receivers detected by the system.
• RS-232 Receiver to RS-232 Sender Routing: To connect an RS-232 receiver to an RS-
232 sender, click and drag the RS-232 receiver’s button on the right to the preferred RS-
232 sender on the left side, then release the mouse button. If the routing was completed
successfully, the newly routed RS-232 receiver’s name will appear below the RS-232
sender’s name within its button. Clicking on any RS-232 receiver button will change the
color of itself, and all RS-232 senders currently routed to it.
Note: RS-232 senders may also be drag and dropped onto RS-232 receivers to activate a new route.
8. Macro Activation: Provides a simple interface to activate macros that have been pre-
defined and stored within the IP Master Controller
Note: Only one macro can be executed at a time.
• Macro: All available macros will be listed in this section. To activate a macro, simply click
on its button. The button will remain blue until the macro has completed executing.

20
6.6.2 System Tab
This tab provides access to system configuration options including IP configuration for
both LAN ports, interface language, login and user management, and firmware update
functionality.
1. LAN 1 & LAN 2: The IP mode for each LAN port (DHCP or Static IP), IP address,
netmask, and gateway can be set here. When a LAN port is set to “DHCP” mode, it
will automatically attempt to obtain proper configuration information from the local
DHCP server. If no DHCP server is available, it will automatically assign itself an APIPA
address from the 169.254.xxx.xxx range. To configure the network settings manually,
please set the LAN port to “Static IP” mode and enter the information as appropriate
for the connected network. Press “Save” to activate the changes.
Note: Both LAN ports default to “DHCP” mode. The current IP address can be verified using the
HDMI output or RS-232 if the Device Discovery software is not available.
2. System Commands:
• Login/Logout: Click these buttons to log into or out of the WebGUI interface.
Note: When not logged in, only the “Monitor & Control” and “System” tabs are available.
• Change Password: Click this button to change the WebGUI’s administrator login
password.
• Language: Use this dropdown to select the preferred display language for the unit’s
WebGUI interface.
• Save Config: The current system configuration may be saved as a *.bin file to the
local PC. Click the “Save Config” button to save the current system configuration to
your local PC.
• Upload Config: The system configuration may be restored from a previously saved
