KanexPro SW-4X1SL18G User manual

SW-4X1SL18G
USER MANUAL
Switch with 4K UHD, ARC, IR, RS-232
All Rights Reserved
Version: SW-4X1SL18G_2016V1.0

KANEXPRO SW-4X1SL18G
2 | Page
Preface
Read this user manual carefully before using this product. Pictures displayed in this
manual are for reference only. Different models and specifications are subject to the
actual product.
This manual is only for operational instruction, not for any maintenance usage. The
functions described in this version are updated till December 14, 2016. Any changes of
functions and parameters since then will be informed separately. Please refer to the
dealers for the latest details.
Trademarks
Product model and logo are trademarks. Any other trademarks mentioned in this
manual are acknowledged as the properties of the trademark owner. No part of this
publication may be copied or reproduced without the prior written consent.
FCC Statement
This equipment can generate, use, and radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits of a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

KANEXPRO SW-4X1SL18G
3 | Page
SAFETY PRECAUTIONS
To ensure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
Using supplies or parts not meeting the products’ specifications may cause
damage, deterioration or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain or moisture. Do not
install this product near water.
Do not place any heavy items on the extension cable in case of extrusion.
Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
Install the device in a place with fine ventilation to avoid damage caused by
overheating.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage.
If an object or liquid falls or spills on to the housing, unplug the module immediately.
Do not twist/pull by force the ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power
cord to the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: Do not burn or mix with general
household waste; please treat the devices as normal electrical waste.

KANEXPRO SW-4X1SL18G
4 | Page
Table of Contents
1. Introduction..................................................................................................................5
1.1 Introduction to SW-4X1SL18G...........................................................................5
1.2 Features .............................................................................................................5
1.3 Package List.......................................................................................................6
2. Panel Description ........................................................................................................6
2.1 Front Panel.........................................................................................................6
2.2 Rear Panel .........................................................................................................7
3. System Connection .....................................................................................................8
3.1 Usage Precautions.............................................................................................8
3.2 System Diagram.................................................................................................8
3.3 Connection Procedure .......................................................................................9
3.4 Application..........................................................................................................9
4. Panel Control.............................................................................................................10
4.1 Input source switching......................................................................................10
4.1.1 Manual switching mode..........................................................................10
4.1.2 Auto-switching mode..............................................................................10
4.2 Embedded EDID invoking ................................................................................11
5. IR Control ..................................................................................................................12
6. RS232 Control...........................................................................................................13
6.1 Installation/uninstallation of RS232 Control Software ......................................13
6.2 Basic Settings ..................................................................................................13
6.3 RS232 Commands...........................................................................................14
6.3.1 Switching Commands ............................................................................14
6.3.2 EDID Customizing..................................................................................15
6.3.3 Source Device Control ...........................................................................15
6.3.4 Display Device Control...........................................................................16
6.3.5 Baud Rate Setting ..................................................................................16
7. Firmware Upgrade.....................................................................................................17
8. Specification ..............................................................................................................18
9. Panel Drawing ...........................................................................................................19
10. Troubleshooting & Maintenance ..............................................................................20
11. After-sales Service...................................................................................................21

KANEXPRO SW-4X1SL18G
5 | Page
1. Introduction
1.1 Introduction to SW-4X1SL18G
The KanexPro SW-4X1SL18G is an UltraSlim auto-switcher with 4–input and
1-output which auto-identifies input resolutions of up to four HDMI devices to
one 4K display supporting full 4:4:4 YUV color space and 18 Gbps of
bandwidth. This switcher can be controlled from the front panel, IR Remote, or
by sending RS-232 commands, the corresponding indicator will illuminate to
show real-time switching status. It can transmit uncompressed 4Kx2K@60Hz
4:4:4 (at max) signal and supports HDMI 2.0 and HDCP2.2 compliant.
1.2 Features
UltraSlim 4K HDMI 4x1 switcher with ARC
Supports YUC 4:4:4 color space w/ HDR
Incredibly thin design – only 0.4” (11 mm) thick
Supports UHD 4K/60Hz resolutions
High-bandwidth 18 Gbps
Transmits 4K up to 10m (32ft.)
HDMI supports ARC (Audio Return Channel)
HDCP 2.2 compliant
Auto-identifies input resolutions to match displays
Supports EDID management
LED status for connection and HDCP
Firmware update via micro USB
Control via RS-232, IR & front panel buttons
Remote control included

KANEXPRO SW-4X1SL18G
6 | Page
1.3 Package List
4x1 HDMI Switcher
5V power supply
IR remote
3.5mm IR receiver
Operation Manual
NOTE: If there are defective parts or parts are missing, please contact your local
dealer(s).
2. Panel Description
2.1 Front Panel
No.
Name
Description
①
SOURCE/
MODE/3s
Video source selection button, press to switch among the 4
inputs source circularly.
Switch mode selection button, press and hold for 3 seconds
or more to switch between auto-switch mode and manual
switch mode.
②
Power
indicator
Illuminate red once powered on.
③
AUTO
Bi-colored indicator for present switching mode.
Green when in auto-switching mode.
OFF when in manual mode.
④
1~4
Total 4 bi-colored LED indicators:
The indicator of the present input source illuminates green.
The indicator of the connected input source illuminates
orange.
13
24
AUTO
SOURCE
MODE/3s
1234

KANEXPRO SW-4X1SL18G
7 | Page
NOTE: Output HDCP compliant status depends on input signal. When the input signal
is with HDCP, then output signal is with HDCP and vice versa.
2.2 Rear Panel
No.
Name
Description
①
OUT
HDMI output port, connect to HDMI display
②
IN1~IN4
Total 4 HDMI input ports, connect with HDMI source devices.
③
RS232
Serial control port, connect with control device (e.g. a PC) to
control this switcher.
④
IR IN
Connect with IR receiver to collect IR signal from IR Remote.
⑤
EDID
4-pin DIP switcher to invoke built-in EDID data. Please refer to
4.2 Embedded EDID invoking for more details.
⑥
FW/DC 5V
Micro-USB connector, connect with power adaptor for
powering the switcher, or used for updating firmware.
Connect to PC with USB cable to update firmware. Please
refer to 7 Firmware Upgrade for more details.
RS232
IN 3
IN 2
IN 1 FW/DC 5VIR IN EDID
IN 4
OUT
123456

KANEXPRO SW-4X1SL18G
8 | Page
3. System Connection
3.1 Usage Precautions
1. System should be installed in a clean environment, which should have a
proper temperature and humidity.
2. All the power switches, plugs, sockets and power cords should be insulated
and safe.
3. All devices should be connected before powered on.
4. System Diagram shown in this manual is for reference only; more specific
schemes depend on real-time applications.
3.2 Connection Procedures
Step1.Connect HDMI source device(s) (e.g. Blue-Ray DVD) to the “IN1” ~ “IN4” ports
of the SW-4X1SL18G via HDMI cable(s).
Step2.Connect HDMI display (e.g. HDTV) to “OUT” port of this switcher with HDMI
cable.
Step3.Connect an IR Receiver to the “IR IN” to control the switcher via IR Remote.
Step4.Connect the control device (e.g. PC) to the “RS232” port to control the switcher
via RS232 commands.
Step5.Plug a DC 5V power adapter to the “FW/DC 5V” port.
NOTE: All the ports support hot-plug.
3.3 Application
The SW-4X1SL18G is ideal for residential AV and corporate applications, such
as under the conference room table. From here, you can run up to four HDMI
cables to different points on the table, and then connect your devices (e.g.
laptops, tablets, and phones). The switcher handles user signal switching and
distribution. You can even connect secondary audio-video inputs, such as Blu-
Ray devices, computers, and cable boxes.

KANEXPRO SW-4X1SL18G
9 | Page
4. Panel Control
4.1 Input source switching
The “Auto Source” button on the front panel can be used to select input source and
switch mode.
4.1.1 Manual switching mode
Press the “Auto Source” button to switch among inputs 1~4, the corresponding
indicator will illuminate green for easy recognition.
4.1.2 Auto-switching mode
Press and hold the button “Auto Source” for 3 seconds or more to switch between
manual mode and auto mode. (Default: Manual switch.). Once enter auto-switching
mode, the “MODE” LED will light up.
The auto-switching mode abides by the following principles:
New input
Once a new input signal is connected, the SW-4X1SL18G will switch to the
new signal automatically.
Power Rebooting
The SW-4X1SL18G supports “power off” memory function. If the last
selected signal is still available, the switcher will output said signal. If not, the
switcher will detect all the input signals with priority from “IN 1” to “IN 4”
ports. When the first signal is detected, it will transfer to the output.
Signal removing
Once the current input signal is removed, the SW-4X1SL18G will detect all
input signals with priority directed towards the succeeding input port. It will
transfer the first available input source to the output device.
For example, the selected input signal is “IN 2”. If you disconnect the current
input source, SW-4X1SL18G will detect all input signals per the following
order: “IN 3”, “IN 4”, “IN 1”. Then the first available source will be switched as
the input.

KANEXPRO SW-4X1SL18G
10 | Page
4.2 Embedded EDID invoking
The rear panel contains a 4-pin DIP switcher to invoke embedded EDID. The
embedded EDID data and their corresponding DIP switcher status are shown in the
below list.
DIP Switcher
The location “ON” is “0”.
ID
Status
EDID
00
0000
Pass through (default)
01
0001
1080p 3D 2CH
02
0010
1080p 3D Multichannel
03
0011
1080P 2D 2CH
04
0100
1080P 2D Multichannel
05
0101
840x2160 2D(30Hz)
06
0110
3840x2160 2D(60Hz)

KANEXPRO SW-4X1SL18G
11 | Page
5. IR Control
Connect an IR receiver to the IR IN port. The SW-4X1SL18G can be controlled via the
included IR Remote. As CEC function, it is able to use the IR Remote to control the
source or display device. Here is a brief introduction about the IR Remote:
NOTE: The source and display devices should support CEC when the IR Remote is
used for controlling them.
INPUTS:
1~4: Select video source via pressing corresponding
button.
MANUAL/AUTO: Select Manual switching mode or
auto-switching mode.
SOURCE:
These buttons are designed to control input source
device (e.g. Blu-Ray DVD).
DISPLAY:
These buttons are designed to control output display
device (e.g. HDTV).

KANEXPRO SW-4X1SL18G
12 | Page
6. RS232 Control
The SW-4X1SL18G provides an RS232 port for serial port control. Connect the
switcher to the control device (e.g. PC) with an RS232 cable and set the parameters in
the right manner. The control device can control the switcher via designed software.
6.1 Installation/uninstallation of RS232 Control Software
Installation: Copy the control software file to the computer connected with this
switcher.
Uninstallation: Delete all the control software files in corresponding file path.
6.2 Basic Settings
Connect this switcher with an input device and an output device. Then connect it with a
computer, which is installed with the RS232 control software. Double-click the software
icon to run this software.
Here we take the software CommWatch.exe as example. The icon is shown below:
The interface of the control software is shown below:
Please set the parameters of COM number, bound rate, data bit, stop bit and the parity
bit correctly. Only then will you be able to send command in the Command Sending
Area.
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none

KANEXPRO SW-4X1SL18G
13 | Page
6.3 RS232 Commands
6.3.1 Switching Commands
Function
Command
Feedback Example
Switch to HDMI input 1.
HDMI1%
[CMD]: switch to HDMI1.
Switch to HDMI input 2.
HDMI2%
[CMD]: switch to HDMI2.
Switch to HDMI input 3.
HDMI3%
[CMD]: switch to HDMI3.
Switch to HDMI input 4.
HDMI4%
[CMD]: switch to HDMI4.
Enable auto-switching mode.
AUTO%
[CMD]: switch to AUTO
Mode.
Enable manual switching mode.
MANUAL%
[CMD]: switch to MANUAL
Mode.
NOTE: The source and display devices should support CEC.
Parameter Configuration area
Monitoring area, indicates
whether the command
sent works.
Command Sending area
Monitoring area, indicates
whether the command
sent works.
Command Sending area

KANEXPRO SW-4X1SL18G
14 | Page
6.3.2 EDID Customizing
Function
Command
Feedback Example
Query the current EDID
EDIDInfo%
Customize EDID.
EDIDSxx%
Remove all customized EDID.
EDIDR%
Besides the 6 embedded EDID, there are 9 EDIDs that can be customized as needed.
Firstly, send the command “EDIDSxx%” (XX=ID=07~15), and then click “Load File” on
the RS232 control software to load the customized EDID file (.bin).
After customizing EDID data, you can invoke the new EDID via DIP switcher, and the
EDID ID and their corresponding DIP switcher status are shown in the below list.
DIP Switcher
The location “ON” is “0”.
ID
Switcher
Status
ID
Switcher
Status
ID
Switcher
Status
07
0111
08
1000
09
1001
10
1010
11
1011
12
1100
13
1101
14
1110
15
1111
6.3.3 Source Device Control
Function
Command
Feedback Example
Turn on the input source
device, e.g. Blue-ray DVD.
SRCOn%
[CMD]: blue ray power on.
Turn off the input source
device, e.g. Blue-ray DVD.
SRCOff%
[CMD]: blue ray power off.
Play
SRCPlay%
[CMD]: blue ray play.
Pause
SRCPause%
[CMD]: blue ray pause.
Stop
SRCStop%
[CMD]: blue ray stop.
Fast Forward x1
SRCForward%
[CMD]: blue ray forward.
Fast Rewind
SRCBackward%
[CMD]: blue ray backward.
Next Section
SRCSkipForward%
[CMD]: blue ray skid
forward.
Previous Section
SRCSkipBackward%
[CMD]: blue ray skid
backward.
Open the MENU
SRCMenu%
[CMD]: blue ray menu.

KANEXPRO SW-4X1SL18G
15 | Page
Back
SRCBack%
[CMD]: blue ray back.
Confirm (OK)
SRCOk%
[CMD]: blue ray OK.
Exit
SRCExit%
[CMD]: blue ray Exit.
Up direction
SRCUp%
[CMD]: blue ray up.
Down direction
SRCDown%
[CMD]: blue ray down.
Left direction
SRCLeft%
[CMD]: blue ray left.
Right direction
SRCRight%
[CMD]: blue ray right.
Next
SRCNext%
[CMD]: blue ray next.
Enter
SRCEnter%
[CMD]: blue ray Enter.
6.3.4 Display Device Control
Function
Command
Feedback Example
Turn on the display device, e.g.
HDTV.
TVOn%
[CMD]: TV Power on.
Turn off the display device, e.g.
HDTV.
TVOff%
[CMD]: TV Power off.
Select input source.
TVINSel%
[CMD]: TV input select.
Volume up.
TVVOL+%
[CMD]: TV VOL +.
Volume down.
TVVOL-%
[CMD]: TV VOL -.
Mute.
TVMUTE%
[CMD]: TV VOL Mute.
6.3.5 Baud Rate Setting
Function
Command
Feedback Example
Set the baud rate as 9600.
UART9600%
[CMD]: Baud 9600.
Set the baud rate as 19200.
UART19200%
[CMD]: Baud 19200.
Set the baud rate as 38400.
UART38400%
[CMD]: Baud 38400.
Set the baud rate as 57600.
UART57600%
[CMD]: Baud 57600.
Set the baud rate as 115200.
UART115200%
[CMD]: Baud 115200.

KANEXPRO SW-4X1SL18G
16 | Page
7. Firmware Upgrade
This switcher contains a USB port for online firmware upgrade on the rear panel.
Follow these steps to upgrade firmware:
Step1. Connect control PC to the USB port of this switcher with USB cable.
Step2. Open “My Computer”, and then find the new disk named BOOTDISK.
Step3. Copy the latest upgrade file (.bin) to this disk.
Step4. The switcher will restart automatically, and then the software update will
complete after the USB port is connected successfully.
NOTE: The USB port can also be used to energize the device.

KANEXPRO SW-4X1SL18G
17 | Page
8. Specification
Input Signal
4 HDMI
Input Connector
Female Type-A HDMI
Output Signal
1 HDMI
Output Connector
Female Type-A HDMI
Control Signal
1 IR IN; 1 RS232
Control Connector
2 3.5mm mini jacks
Video Signal
HDMI2.0& HDCP2.2
Audio Signal
Dolby Digital, DTS, DTS-HD
General
EDID Management
Embedded EDID data and manual EDID management.
Resolution Range
640x480@60Hz ~ 4Kx2K@60Hz 4:4:4.
HDMI Cable Length
≤3m
Power Supply
5VDC, 2A
Power Consumption
5W (Max)
Dimension (W*H*D)
194.0mm × 12.0mm × 81.5mm
Weight
200g
Temperature
-10℃~ 55℃
Reference Humidity
10% ~ 90%
NOTE: Please adopt qualified HDMI cables compliant with HDMI2.0 for reliable
transmission when connecting.

KANEXPRO SW-4X1SL18G
18 | Page
9. Troubleshooting & Maintenance
Problems
Causes
Solutions
Color losing or no video
signal output in HDMI
display
The connecting cables
may not be connected
correctly or it may be
broken.
Check whether the cables
are connected correctly
and in working condition.
No HDMI signal output in
this switcher while local
HDMI input is in normal
working state
Splash screen in output
devices
Poor quality of the
connecting cable
Change for another cable
of good quality.
Cannot control this
switcher by control device
(e.g. a PC) through
RS232 port
Wrong RS232
communication
parameters
Make sure the RS232
communication
parameters are correct.
This switcher is defective
Send it to authorized
dealer for repairing.
Static becomes stronger
when connecting the
video connectors
Bad grounding
Check the grounding and
make sure it is connected
well.
If your problem persists after following the above troubleshooting steps, seek further
help from authorized dealer or our technical support.

KANEXPRO SW-4X1SL18G
19 | Page
10. After-sales Service
If problems arise when operating the device, please refer to this user manual. Any
transport costs are borne by the users during the warranty.
1. Product Limited Warranty: We warrant that products will be free from defects in
materials and workmanship for three years, which starts from the first day the
product exits warehouse. (Make note of the serial number on the product)
Proof of purchase in the form of a bill of sale or receipted invoice MUST be
presented to obtain warranty service.
2. What the warranty does not cover:
Warranty expiration.
Factory applied serial number has been altered or removed from the product.
Damage, deterioration or malfunction caused by:
Normal wear and tear
Use of supplies or parts not meeting our specifications
No certificate or invoice as the proof of warranty.
The product model showed on the warranty card does not match with the
model of the product for repairing or had been altered.
Damage caused by force majeure.
Servicing not authorized
Any other causes which does not relate to a product defect
Delivery, installation or labor charges for installation or setup of the product
3. Technical Support: Email or call our after-sales department if there are any
problems or any unanswered questions. Please inform us the following information
about your cases:
Product version and name.
Detailed failure situations.
The formation of the cases.
Remarks: For any questions or problems, please try to get help from your local
distributor or contact kanexpro.com or call us at 888-975-1368 for further support.

KANEXPRO SW-4X1SL18G
22 | Page
11. Warranty
A. LIMITED WARRANTY
KanexPro ™ warrants that (a) its products (the “Product”) will perform greatly in
agreement with the accompanying written materials for a period of 36 months (3 full
years) from the date of receipt and (b) that the product will be free from defects in
materials and workmanship under normal use and service for a period of 3 years.
B. CUSTOMER REMEDIES
KanexPro’s entire liability and Customer’s exclusive remedy shall be, at KanexPro
option, either return of the price paid for the product, or repair or replacement of the
Product that does not meet this Limited Warranty and which is returned to KanexPro
with a copy of customers’ receipt. This Limited Warranty is void if failure of the Product
has resulted from accident, abuse, or misapplication. Any replacement Product will be
warranted for the remainder of the original warranty period of 3 years, whichever is
longer.
C. NO OTHER WARRANTIES
To the maximum extent permitted by applicable law, KanexPro disclaims all other
warranties, either express or implied, including, but not limited to implied warranties of
merchantability and fitness for a purpose, regarding the product and any related written
materials. This limited warranty gives customers specific legal rights. Customers may
have other rights depending on the jurisdiction. 
D. NO LIABILITY FOR DAMAGES
To the maximum extent permitted by applicable law, in no event shall KanexPro be
liable for any damages whatsoever (including without limitation, special, incidental,
consequential, or indirect damages for personal injury, loss of business profits,
business interruption, loss of business information, or any other pecuniary loss) arising
out of the use of or inability to use this product, even if KanexPro has been advised of
the possibility of such damages.
