Kaos PDR1 User manual

MDAB
FM
www.kaosproducts.com
www.kaosproducts.com
User Guide
User Guide
PDR1
PDR1

-1- KAOS
Kaos PDR1 Quick Start Guide
The Kaos PDR1 is a portable DAB and FM
receiver, which uses the headphone lead as the
antenna, so please plug in an earphone before
use.
Press and hold the Power Button for more
than 3 seconds to turn on the radio.
DAB Radio
When the DAB mode is selected for the first
time, press the M Button and enter <Region>
to select your region. The radio will
automatically search for local DAB and DAB+
radio stations. It will display all the radio
stations found and play the first radio station
automatically.
FM Radio

-2- KAOS
Press the DAB/FM Button to switch to the FM
mode.
Press the M Button to enter the FM Main Menu.
Use the ” “ Button to select <Auto
Program> and then press the Enter Button,
when some new stations will replace the
pre-stored radio stations.
MP 3
MP3 files stored on a SD Card can be played
through the radio by inserting the SD Card into
the card slot on the bottom of the radio.
Recording Function
It is possible to record FM or DAB broadcasts to
a SD Card (Please ensure the SD Card is inserted
before recording.)
System Setup

-3- KAOS
Set Power off Time to save the battery power.
Time Setup: you can set the time and date
manually or it can use the DAB broadcast as
time sync. (Default)
You can set the Brightness; Backlight Time out;
and can check the version information.

-4- KAOS
User Manual
1. Brief Introduction ................................................... 8
2. Packaging and Specification............................... 9
2.1 Packaging..................................................... 9
2.2 Specification..............................................10
2.2.1 DAB Function..............................10
2.2.2 FM Function................................11
2.2.3 MP3................................................12
2.2.4 Time...............................................13
2.2.5 Battery ..........................................13
2.2.6 General .........................................14
3. Button Instruction ................................................15
4. Display Screen .......................................................18
4.1 Playing Screen..........................................18
4.2 Menu Screen.............................................21
4.3 Information Screen.................................22
4.4 Query Screen ............................................23
5. Main Menu..............................................................24

-5- KAOS
6. Mode Switching ....................................................26
7．DAB Menu .............................................................28
7.1 Preset List...................................................28
7.2 Channel List...............................................28
7.3 Local Scan ..................................................29
7.4 Manual Tune..............................................30
7.5 Region .........................................................31
7.6 DRC...............................................................31
7.7 Record .........................................................32
7.8 Sort...............................................................33
8. DAB Mode Operation .........................................33
8.1 Basic Operation........................................33
8.1.1 Power on DAB for the First Time
...................................................................33
8.1.2 Power on DAB after the First
Time..........................................................34
8.1.3 Select Stations............................34
8.1.4 Play Stations ...............................34
8.1.5 Storing Stations .........................35

-6- KAOS
8.1.7 Display Station Information ..36
9. FM Radio Menu Introduction and Operation
.........................................................................................36
9.1 Preset List...................................................37
9.2 Channel List...............................................37
9.3 Seek Mode.................................................37
9.4 Tune Mode.................................................38
9.5 Auto Program...........................................39
9.6 Clear All List...............................................40
9.7 Region .........................................................41
9.8 Scan Setting ..............................................42
9.9 Record .........................................................43
10. MP3.........................................................................43
10.1 SD Card.....................................................44
10.2 MP3 Setting ............................................44
10.2.1 Play Mode .................................45
10.2.2 Play Range ................................46
10.3 MP3 Playing Screen .............................46
10.4 Downloading files from a PC............47
11. System Setup.......................................................48

-7- KAOS
11.1 Set Power Off Time ..............................49
11.2 Time Setup ..............................................50
11.2.1 Display Time & Date .............50
11.2.2 Set Time & Date......................50
11.3 Brightness................................................51
11.4 Backlight TimeOut................................52
11.5 Reset All....................................................52
11.6 Info.............................................................53
12. Charging the radio.............................................53
13. Safety Warning....................................................55

-8- KAOS
1. Brief Introduction
The Kaos PDR1 is a digital radio with DAB,
DAB+, FM and MP3 functions.
DAB stands for Digital Audio Broadcasting and
it is the third-generation broadcasting system
after AM and FM analogue broadcasting. This
new transmission system has great
anti-interference performance qualities and can
eliminate noise and distortion during the
transmission process, automatically correcting
errors which leads it to provide near CD-quality
sound.
DAB+ is the updated version of the DAB
standard and is used in many European
countries as well as Canada, China and South
Korea. The DAB+ standard is based on
HE-AACv2 and can deliver the same high
quality sound at a much lower bit rate.

-9- KAOS
As DAB Radio isn’t available everywhere in the
world, the Kaos PDR1 has an FM radio function
allowing analogue FM broadcasts to be
received.
In MP3 mode, it can play MP3 music files which
are stored on the SD Card.
2. Packaging and Specification
2.1 Packaging
Thank you for choosing the Kaos PDR1 radio.
Please check the accessories in the box
according to the list as below. If there is
anything missing, please contact your retailer.
1. Kaos PDR1 radio device 1pc
2. USB 2.0 cable 1pc
3. Earphone 1pc
4. User Manual 1pc
5. Adapter 1pc (optional)

-10-KAOS
2.2 Specification
2.2.1 DAB Function
The DAB radio can receive and play all the Band
III radio stations, using the DAB standard,
including DAB+ and the frequency range of DAB
band III is 174.928MHz-239.2MHz
Supports Region setting, the device will search
the appropriate band for the radio stations when
the user has set up the default Region.
Supports local searching.
Supports searching by preferred frequency
channel.
Supports DRC function.
Supports record function and the default record
format is MP2 when it is in DAB status. The

-11-KAOS
default recording format is AAC when it is in
DAB+ status. The capacity is up to the capacity of
SD Card.
Supports presets and the maximum number of
presets is 30.
2.2.2 FM Function
You can use the device to receive and play FM
radio stations, and FM frequency range is
87.5MHz-108MHz, the interval is 0.1MHz.
Supports searching and playing strong signal
radio stations only.
Supports searching and storing the radio
stations automatically. The maximum is 30 radio
stations in the <Channel list>.
Supports preset function, and maximum

-12-KAOS
number of preset stations is 30.
Supports Tune mode and Seek mode.
Supports recording function. The default
recording format is MP3, and the capacity is up to
the capacity of SD Card.
Supports clear all list, including the <preset list>
and the <channel list>.
Supports RDS function.
2.2.3 MP3
The device supports playing music files from the
SD Card.
Playing mode supports the function for <One
Time>, <Repeat> and <Shuffle> mode.
Playing range can be <Single> and <Directory>.

-13-KAOS
Supports play, pause, next, previous function.
2.2.4 Time
The time can be set up manually or can use the
DAB broadcast as time synchronization. The
default is DAB sync.
User can set 30 minutes, 45 minutes or 60
minutes to turn off the device automatically.
Note: After you set power off time, please don’t
operate any more, or the device won’t power off
automatically.
2.2.5 Battery
1. Build in 700mAh Li-polymer battery,
playing time is over 10 hours.
2. Charging time: 3-4 hours.
3. The maximum charging current:
300mA

-14-KAOS
4. Cycle times: about 500 times before
degradation.
2.2.6 General
1. 3.5-mm stereo earphone jack.
2. Dimension: 54*93.5*15.5mm (H*W*D)
3. Weight: 64grams

-15-KAOS
3. Button Instruction
RESET
M Button
Mode Button
(DAB/FM Button)
LCD display
Next/function plus
(Right Button)
Enter Button/Power Button
SD card slot
RESET
Volume+ (Up Button)
Previous/function
reduce (Left Button)
Volume- (Down Button)
Earphone Jack
USB Charging Connection

-16-KAOS
1 Item Description
2 M Button Press it to go back to the
previous menu.
3 Mode Button Short press is for
DAB/FM/MP3 mode
switching, Long press is
for storing radio stations.
4 Left / Right
Button
Select previous or next
music in MP3 mode.
Searching FM or DAB
radio stations in FM or
DAB mode.
5 Volume+/- “+” means increasing
the volume, “-” means
decreasing the volume.
6 Enter
Button/Power
Short press is to confirm
selections; long press is

-17-KAOS
Button to power on or power off
the device.
7 Reset Button If the device operation
has failed, press the
button to reset the radio.
8 Earphone Jack Connect earphones to
listen to the radio or
connect to an external
speaker system. Note
this cable is used as the
antenna for the radio.
USB Charging
Connection
Charge the internal
battery via the USB
charging connection,
either directly via a
computer, or using the
power adapter
(optional).

-18-KAOS
Use USB line to read the
information on the SD
Card in the device.
SD Card slot Plug the SD Card into
this slot.
LCD Display Display all the pictures or
characters info.
4. Display Screen
4.1 Playing Screen
There are three modes: DAB, FM and MP3.
Battery icon : Displays the battery charge
level.
VOL: Displays the current volume.
11:01: Displays the current system time.
Signal icon : Displays the signal strength.

-19-KAOS
In the DAB or FM mode, following a short press of
Enter Button, the radio information will be
displayed on the screen, (Note: only FM stations
with RDS will have information that can be
displayed on the screen).
Example as below:
