Karlsson KA5768 User manual

INSTRUCTION MANUAL | CUCKOO CLOCK | KA5768
User's Manual
• Thank you for your purchase.
• Read this User's Manual before using this product.
• Keep this User's Manual for future reference.
Steps for use:
（1）Open the battery cover (no battery inside) and turn the hands knob in the direction of
the arrow and set time to 05:45 as below :
Do not touch the clock hands directly to set time.
（2）Insert 3xAA batteries (not included) as illustrated.
1
Karlsson is a trademark of Present Time
Present Time/ Almere/ Holland
www.karlsson-clocks.com

（3）Continue to turn the hands knob in the direction of the arrow to set the current time.
The time can be set even when the bird
is singing.
The cuckoo will stop singing from 10 p.m. (22:00) to 5 a.m. (05:00), so the current time
needs to be set correctly according to 24-hour mode.
For example:
Set time for 9:25 a.m. ( 09:25 )
05:45
05:45 12:00 21:25
09:25
Set time for 9:25 p.m. ( 21:25 )
2

（4）Close the battery cover after the time is set correctly. Do not press “SET” button during the
process. Otherwise, please take out the batteries and re-set the time by following
steps (1)~(4) above.
（5）Release the pendulum driver and hang the pendulum to it.
3

Cuckoo singing function:
About the song volume
The song volume can be adjusted in 3 levels by the volume
adjust switch.
After pressing the “SET” button, please take out the batteries and re-set the
time by following “Step for use” steps (1)~(4) above.
Cuckoo silence period: 10 p.m. (22:00) to 5 a.m. (05:00).
During this period, the cuckoo will NOT move nor sing.
Testing the cuckoo singing: “SET” button
By pressing the “SET” button, the cuckoo will come out and sing. But if the current time is in
silence period, the cuckoo might not come out and sing even by pressing “SET” button. In this
situation, please press more times of “SET” button until the cuckoo come out and sing.
Caution Changing batteries:
When changing batteries, please set the time by referring to the "Steps
for Use".
To avoid battery leakage or explosion, please follow the below.
• If the clock stops, either replace the battery with a new one or remove the battery.
• Even when the clock is still working, change the battery regularly once per year.
Types of battery
• As a general rechargeable battery has low voltage, please do not use with this
product.
• Dry manganese batteries have a shorter life compared to dry alkaline batteries.
4

Troubleshooting:
The time is slow or fast. Time accuracy is affected by temperature
which may cause the time to speed up or
slow down. (Usable temperature : 0 - 40
°C) If the time inaccuracy builds up, make
sure to turn the hands knob in the direc-
tion of the arrow to fix the correct time. Or
to change batteries.
Check these points first if the product does not appear to be working properly.
Problem Cause & Solution
The sound of the song slows down. Or
the clock is loose time.
When the cuckoo comes out and sings,
there are noises other than the cuckoo
sound.
This is the sound of the cuckoo or bird
moving. It is not a malfunction.
The cuckoo does not move back to the
house.
Cuckoo silence period is not from 10 p.m.
(22:00) to 5 a.m. (05:00).
Please take out the batteries and re-set
the time by following “Step for use” steps
(1)~(4) above.
The cuckoo might not move back to the
house during time setting process,
because the current time is in silent
period. Please leave it as it is, and the
cuckoo will resume to move and sing after
the silent period.
Or you can move back the cuckoo by
pressing “SET” button. But please take
out the batteries and re-set the time by
following “Step for use” steps (1)~(4)
above.
Please change batteries.
5
