Kasco EJ Series Manual

MID-SIZE EJ SERIES FOUNTAIN MANUAL 1
MOVING WATER FORWARD, SINCE 1968
Operation &
Maintenance
Manual
Document number 884156
Document version 2022.1.0
EJ SERIES
FOUNTAIN
4400EJ, 8400EJ,
2.3EHJ, 3.1EHJ, 3.3EHJ
800 Deere Rd. Prescott, WI 54021 | [email protected] | kascomarine.com

MID-SIZE EJ SERIES FOUNTAIN MANUAL 1
TABLE OF CONTENTS
Unit Specications..................................................................................................................1
Safety First...............................................................................................................................2
Parts Included .........................................................................................................................3
Nozzles Included.....................................................................................................................4
Premium Nozzles (Not Included) ..........................................................................................5
Installation Instructions.......................................................................................................10
3-Phase Startup Procedure..................................................................................................11
Maintenance Recommendations........................................................................................12
Troubleshooting Tips............................................................................................................13
Warranty ................................................................................................................................14
Other Repairs ........................................................................................................................15
Repair Contact Form ............................................................................................................16
UNIT SPECIFICATIONS
Model HP Voltage / Phase / Hz Amperage Locked Rotor
Amps
Suggested Pond
Size (m²)
Min. Depth
of Operation
4400EJF 1 230 / 1 / 50 6.5 19.6 2,000 49cm
8400EJF 2 230 / 1 / 50 9.5 46.5 4,000 51cm
2.3EHJF 2 380 / 3 / 50 3.3 15.5 4,000 51cm
3.1EJF 3 230 / 1 / 50 12.6 59.7 6,000 61cm
3.3EHJF 3 380 / 3 / 50 5 20 6,000 61cm
OVERVIEW
Cord Length
10m 30m 60m 90m
4400EJF 1.5mm²1.5mm²2.5mm²4mm²
8400EJF 1.5mm²2.5mm²4mm²6mm²
2.3EHJF 2.5mm²2.5mm²2.5mm²2.5mm²
3.3EHJF 2.5mm²2.5mm²2.5mm²2.5mm²
WIRE SIZE

MID-SIZE EJ SERIES FOUNTAIN MANUAL 2
SAFETY FIRST
Moving Machinery
WARNINGS:
Shock Hazard
• NEVER enter the water with the electrical equipment connected and/or in operation.
• All electrical equipment must be Ground fault/leakage current protected. Use of a Ground fault
protective device (GFI, RCD, RCBB, or RCBO type device) is required as directed by local and national
codes.
• Stay clear of all moving parts.
• NEVER run the unit out of water. This will damage the equipment and pose a danger to the operator.
• Use extreme caution around water, especially cold water.
• NEVER lift or drag the unit by the power cord. Always use the ropes or mount to remove it from the
water.
• Do not use waders in deep water or in areas with drop-os, drastic slopes, or soft bottom material.
• Do not use boats that tip easily for unit installation (such as canoes).
• Follow all boating safety rules and regulations, including wearing a Personal Flotation Device.
• The unit is supplied with an internal grounding conductor. To reduce the risk of electrical shock, be
certain that the unit is plugged in/connected to a circuit with ground fault protection.
• Means for disconnection must be incorporated in the xed wiring, in accordance with local and national
wiring rules.
• Consult a qualied electrician for electrical installation.
TOOLS AND SUPPLIES NEEDED
• (3) Anchors or stakes for installing unit
• 9/16’’ socket with extension and ratchet (optional)
• 7/16’’ socket and ratchet or combination wrench (optional)
• (3) 12’’ pieces of 1’’ galvanized pipe for weighting ropes (optional)

MID-SIZE EJ SERIES FOUNTAIN MANUAL 3
PARTS INCLUDED
ID Description Qty Part #
A 3/8-16 hex head screw 3 820093
B 3/8” lock washer 3 566230
C 3/8” x 1.25” OD fender washer 3 840325
D Float, single piece 1 See Table below
E Interchangeable nozzles 5 See “nozzles” section
F Nozzle O-ring, Large J 1 841217
G Large JF unit assembly 1 See table below
H Bottom screen, Large J 1 284101
I 3/8”-16 x 1/2” serrated hex head screw 3 820092
J 7/16” & 9/16” wrench tool 1 284139
K Rope, 50ft (not pictured) 1 990170
L Cable tie (not pictured) 8 415038
M Dielectric grease (not pictured) 1 341300
Unit Size Voltage/Phase G (Part #) D (Part #)
1 HP 240 / 1 4400EJF 284102
2 HP 240 / 1 8400EJF 284102
380 / 3 2.3EHJF
3 HP 240 / 1 3.1EJF 284103
380 / 3 3.3EHJF
Unit Assembly Table
A
BC
D
E
F
G
H
I
J

MID-SIZE EJ SERIES FOUNTAIN MANUAL 4
NOZZLES INCLUDED
Linden (841261)
HP Height Width
1 3.4m 9.4m
2 5.2m 10.7m
3 5.5m 11.9m
841260
841255
841222
(Outlet)
841255
841270
841272
841222
(Outlet)
Balsam (841273)
HP Height Width
1 3.4m 7.3m
2 4.9m 9.4m
3 3.8m 7.9m
Spruce (841242)
HP Height Width
1 4.7m 2.1m
2 6.6m 2.7m
3 7m 2.7m
HP Height Width
1 2.6m 1.8m
2 3.5m 3m
3 4.9m 2.7m
Birch (841222) Redwood (841250)
HP Height Width
1 4.9m 1.5m
2 6.9m 1.8m
3 7.2m 1.8m
841242
(Spruce)
841250
The outlet nozzle (841222) comes installed. Add the parts listed below for Linden and Balsam
patterns; remove it before installing Birch, Spruce, or Redwood nozzles.

MID-SIZE EJ SERIES FOUNTAIN MANUAL 5
PREMIUM NOZZLES (NOT INCLUDED)
Contact Kasco Marine at [email protected]
or your local distributor for order information.
Madrone (841330) Magnolia (841325)
Palm (841320)
Mahogany (841345) Mighty Oak (841335)
841250 841250
841250
841250
841250
HP Height Width
1 3.4m 9.4m
2 5m 14.6m
3 6.1m 17.1m
HP Height Width
1 2.9m 10.1m
2 4.4m 15.2m
3 5.3m 17.1m
HP Height Width
1 2.6m 6.1m
2 3.8m 8.5m
3 4.7m 10.1m
HP Height Width
1 3.2m 9.1m
2 5m 13.4m
3 5.9m 17.1m
HP Height Width
1 3.4m 10.4m
2 5m 14.6m
3 5.9m 17.1m

MID-SIZE EJ SERIES FOUNTAIN MANUAL 6
ASSEMBLY INSTRUCTIONS
Dedicated power
cord channel
D
G
A
B
C
1
23
Repeat.

MID-SIZE EJ SERIES FOUNTAIN MANUAL 7
ASSEMBLY INSTRUCTIONS (CONT.)
I
Dedicated power
cord channel
H
4
5
Fasten loosely.

MID-SIZE EJ SERIES FOUNTAIN MANUAL 8
ASSEMBLY INSTRUCTIONS (CONT.)
Tighten all
3 screws to
secure oat
screen
Providing strain relief on the cord helps ensure that
its weight and any strain placed on it in the water will
not cause the oat to tilt or cause damage to the unit.
If your Kasco cord comes with a strain relief kit at-
tached, attach the available link to the oat-side knot
in the mooring rope, as pictured here.
Cord Strain Relief
6
7

MID-SIZE EJ SERIES FOUNTAIN MANUAL 9
NOZZLE INSTALLATION INSTRUCTIONS
Twist until snug
For Linden/Balsam Nozzles:
OUTLET (6) nozzle
installed
Balsam Linden
F
E
1
2
3
Do not over-tighten.
1
2
