KAT VR KAT Ioco LC01 User manual

Thank you for purchasing our product!
Please read this instruction manual carefully and keep it safely stored for
future use.
KAT Ioco
OWNER'S MANUAL
This product is for home use ONLY and NOT for the commercial use.

INDEX
First & Foremost
Declaration
Safety Instructions
04
05
07
08
Health Warnings
Laws and regulations
Windows Based Software Description
Software Description
Software Download
16
16
Product Introduction
Product Description
Product Appearance
Product Parameters
11
11
12
List of Items 15
Contact Information 27
Product Warranty 27
First Use Instructions 17

03
First & Foremost
This owner's manual contains all the information you need to
install and use KAT loco.
This product is for home use ONLY and NOT for the commercial use.
The following symbols are used to indicate useful and import-
ant information:
This symbol is a precaution: It usually provides additional
information to help with a task, as well as information that
only applies to a certain situation.
This symbol is a hint, letting you know what might be helpful
at that particular point.
This symbol is important: You must complete one or more of
hardware or software installations or settings as described
in the manual.

04
For the latest information, please feel free to check out our official
website:www.katvr.com
Declaration
It is the trademark of Hangzhou Virtual and Reality
Technology Co., Ltd. All trademarks, product identification and trade
names of other companies appearing in this manual belong to their
respective owners. No parts or content of this manual may be copied
or reproduced without the written permission of the company, and
may not be shared in any form or used for any commercial or
profitable purpose.
The contents of this manual are subject to change due to product
upgrades or other reasons. Our company reserves the right to modify
the contents of this manual without any notice or prompt. This
manual is intended as a guide only. We do our best to provide
accurate information in this manual but we do not guarantee that the
contents of this manual are completely error free. Statements,
information, and recommendations provided in this manual do not
constitute any warranty, express or implied.

05
Safety Instructions
Suitable users: The device is intended for use by healthy people aged 14 to 60. During
the use of this device by minors, a guardian should always be present to ensure that they
follow all safety instructions and do not experience any discomfort.
VR headset: Make sure to read and follow all product instructions and warnings of the VR
headset of your choice.
To avoid personal injuries or damage to the product, read and follow all product safety
and operation instructions before using KAT loco. Pay special attention to safety warnings.
If you allow others to use the product, you are responsible for ensuring that each user
knows and follows all product safety and operation instructions.
To avoid injuries, read and follow all instructions before using the product.
Spatial safety: Remember, when using this product with a VR headset on, you can't see
your actual surroundings. Images and events displayed in your VR Headset do not match
the real world. Make sure to only use this product in a safe area with no obstacles. Do not
use it near stairs, wide windows, heat sources, reservoirs and water tanks, outdoors
or nearby any other objects that might pose a threat to your safety. Please, make sure
that there are no people, furniture or any other things that hinder your movement in the
selected play area. Pay special attention to children and pets.
objects that might pose a threat to your safety: Please, make sure that there are no
people, furniture or any other things that hinder your movement in the selected play
area. Pay special attention to children and pets.
Repetitive strain injuries: Please use this product in your comfortable position. When
using this product, a single action might be repeated for a long time, what might result in
nerves, tendon or muscle damage. If you experience pain, numbness, weakness, swelling,
burning or stiffness, stop using the product and consult your doctor.
Choking hazard: Do not leave small components that pose a suffocation hazard to
children or pets in easily accessible places where they can reach.

06
Product use: Keep the product safely away from liquids or containers holding liquids.
Do not place the product near fire or heat sources, nor leave it directly exposed to the sun.
Do not insert items into any openings of the product.
Do not disassemble or modify this product or its accessories.
To avoid mechanical damage, do not throw this product or its accessories.
If the product overheats, gets damaged or cannot be used according to the safety
instructions of this user's manual, please contact our technicians or your local distributor.
Avoid using this product after a rapid temperature change.
If the product is moved between environments with widely varying temperature or
humidity level, condensation might cause water to form on the surface or inside the
product. To avoid damage, please wait till the water evaporates before using the product.
Turn it on, only after the product adapts to the room temperature.
Before using the product, check if it's in a normal state without cracks, scratches or other
abnormalities. Before connecting the product to the charger, please confirm that the
actual voltage and current are the same as these mentioned in the product parameters in
this manual. If the two do not match, do not connect it.
Any disassembly or modification of this product without permission will result in instant
termination of the product warranty.
Cleaning: Using a damp cloth or water to clean the sensor surface is forbidden. Only a
dry cloth can be used for that purpose. The straps can be cleaned with a damp cloth and
dried before use. If symptoms such as itching, irritation, etc. appear, stop using the
product and consult your doctor.
Radio Frequency Interference: This product might emit radio waves that might
interfere with the operation of nearby electronic equipment. If you are wearing a
pacemaker or any other implantable medical device, consult your doctor or your medical
device manufacturer before using the product. In order to minimize radio frequency
interference, use only accessories approved by the original manufacturer. Do not use at
the same location, or together with any other antenna or transmitter.

07
interfere with the operation of nearby electronic equipment. If you are wearing a
pacemaker or any other implantable medical device, consult your doctor or your medical
device manufacturer before using the product. In order to minimize radio frequency
interference, use only accessories approved by the original manufacturer. Do not use at
the same location, or together with any other antenna or transmitter.
Avoid overuse: Avoid using the product for long periods of time without rest. It might
have a negative impact on body coordination and balance which causes other negative
effects. Frequent use of this product for extended periods of time may cause fatigue or
pain of your muscles, joints or other parts of your body. Please take regular breaks during
the use of this product. The amount of required rest and its frequency may vary from
person to person.
Use by children: This product is not designed for children. Please, keep it stored in a safe
place where minors cannot reach it. Do not allow young children to use this product.
Children might harm themselves or others, or accidentally damage the product.
Battery warning: Your product contains built-in rechargeable batteries that cannot be
replaced. Battery life will vary depending on frequency and method of use. Disposal of
waste batteries that reached their product life should be carried out in accordance with
local laws. If the local law does not regulate this matter, please discard your product in
the trash can for electronics. Improper use of the batteries might pose a risk of fire or
chemical burns. Do not disassemble or expose the batteries to temperatures above 50 ° C
( 122 ° F). Keep them away from children.
Health Warnings
The following health warnings will be updated occasionally to ensure accuracy and
completeness.
Pregnant women or those with epilepsy, cardiopulmonary diseases, history of mental
illness (such as anxiety disorder, post-traumatic stress disorder etc), anemia or other
serious health problems such as heart diseases, and those undergoing postoperative

recovery or physical activity difficulties are strictly prohibited from using the product.
Because of physical limitations of human body, we do not recommend using this product
for too long time without rest in order to avoid discomfort such as dazzling, dizziness or
headache. Remember to take regular breaks, especially during the first use to gradually
adapt to virtual reality environment and increase the length of your gaming sessions step
by step. It is recommended to use the product for no longer than 1 hour without rest.
If you feel any discomfort when using the product, stop using it immediately and do not
engage in any physical activities that pose safety hazards until the symptoms completely
disappear. In case they persist, do not use the product until you consult the problem with
your doctor.
In case of fatigue, illness, hangover, alcohol or drugs intoxication, or any other discomfort, it
is strictly forbidden to use this product, otherwise the symptoms might be aggravated.
08
Anyone who uses this product is considered to have full civil capacity of conduct
and must comply with the aforementioned matters. If you violate the above safety
instructions or carry out other violations, it may cause personal injury or adverse
consequences for which KAT VR will not be held responsible.
Radiation Exposure Statement
FCC Radiation Exposure Statement
Laws and Regulations
(1). This product must not be co-located or used together with any other antenna or
transmitter.
FCC Warnings
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference.

09
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
IC Warnings
This device complies with Industry Canada license-exempt RSS standard(s).Operation is
FCC RF Warning Statement

10
subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence.L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et.
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d'en compromettre le fonctionne-ment.
This device complies with the 2014/53/EU Directive issued for wireless electronics by
the European Electronic Communications Committee. This equipment operates in the
following frequency range and the highest radio frequency power.
This equipment should not be disposed in a landfill. Improper disposal of electronic
products or their components may harm the environment. For more information on
disposal and recycling of electronic equipment, please contact your local Civic Center,
your Household Waste Disposal Center, the shop where you purchased the equipment
or your local dealer.
EU Directives Compliance Statement
Electronic Waste and RoHS compliance

11
Product Appearance
Product Introduction
Product Description
KAT loco is a foot-based VR locomotion system that gives
complete physical control over lower-body actions, allowing
the user to freely walk, run, and carry out just any other
movement in virtual reality.
Left Ankle sensor Righ Ankle sensorWaist sensor Receiver
W Signal Light
2
L Signal Light
1
R Signal Light
3
Calibration Button
4
Antennae
7
Micro USB Port
5
USB Port
6

12
Product Parameters
1.Please check our official website for the latest information.
Suitable age 14-60
Model LC01
Connection
Signal range
Bluetooth 4.2
3m
Accepted humidity level
Operating temperature
Storage temperature
0-40℃(32℉-104℉)
-5℃ - 50℃(23℉-122℉)
Package size
Software KAT Gateway
230*123*60mm
(L*W*H, 9.06*4.84*2.36in)
Certificates CB, CE, FCC, WEEE, RCM, IC, MIC
- 5%-95% in non-condensing state
Gross weight 400g(14.11oz)
1
KAT Ioco

13
Model
Weight
LC011
Ankle sensor
35g(1.23oz)
Diameter
Total thickness
50mm(1.97in)
24mm(0.94in)
Charging voltage
and current
Charging time About 1 hour
Battery
Battery capacity
Lithium-ion polymer battery
370mAh
Lighting LED
Battery life ≥10hrs
Housing material ABS
5V 0.5A(2A MAX)
Velcro Straps length 20cm-35cm(7.87in-13.78in)
Adjustable length for
Velcro Strap 330mm±10mm(Optional accessary)
Performance of the battery might vary depending on the frequency and method
of use. Excessive use will reduce the product life.

14
Model
Weight
LC012
Waist sensor
35g(1.23oz)
Battery capacity 370mAh
Total thickness
Lithium Battery
24mm(0.94in)
Lithium-ion Polymer Battery
Charging voltage
and current
Charging time 1 hour
Lighting LED
Battery life ≥10hrs
Housing material ABS
5V 0.5A(2A MAX)
Model
Weight
LC013
Receiver
80g(2.82oz)
Size 112*99*74mm (4.41*3.90*2.91in)
Port USB2.0 or above
Rated Voltage USB2.0 or above
Housing material ABS
5V

15
Complete list of items in a KAT loco package
2. The difference between the three micro USB endings of the multifuctional USB
wire is that the white one serves for charging as well as for data transferring, while
the other two can be only used for charging.
3. For KAT Gateway, the dedicated software, please refer to www.katvr.com for
more information.
List of Items
Name
Waist Sensor
Ankle Sensor
Receiver
Velcro Strap
USB Cable
A Notification Card for
Owner's Manual Download
Multifunctional USB Wire
KAT Gateway
Quantity
1
2
1
2
1
1
1
1
Look
3
2

Software Download
Please use your browser to log in to the following website and
download necessary software：
https://www.katvr.com/pages/download
16
Windows Based Software Description
Software Description
KAT Gateway is our comprehensive software solution dedicated to
users of KAT loco for the device management, and VR games
support. With Gateway you can quickly connect KAT loco to your
computer to view current connection status of the device and run
available VR content. Thanks to its inSteam Turbo Mode, each
compatible game will be automatically launched with an optimal
settings configuration.
You can also get access to KAT loco's control panel from either your
computer screen or VR headset at any time to adjust multiple
parameters to your liking, and make KAT loco a perfect VR input
device for your needs.
KAT Gateway can automatically detect compatible VR games in your Steam
library, and compatible VR files with .exe extension.
VR-integrated version of Gateway's control panel is only available when using
SteamVR.

Electrical parameters: Voltage: 5V±10%, current: at least 500mA (Computer USB 2.0 port,
5V Adapter)
Charging status indication: Recharging: diming light; Fully charged: Long bright signal
(Picture shown below)
Charging time: up to 2h
Charging steps:
a. KAT loco comes with a triple-ended Micro-USB wire. Connect it to a DC5V Power Supply
and to all three of the KAT loco sensors.
b. Watch the status of the LED lights: When it's charging, there will be a diming light; when it's
fully charged, there will be a long bright signal. If lights out, it's a signal of broken.
c. Disconnect the sensors once they are fully charged. It will be indicated by the continuous
light signal.
Note: Once you receive the KAT loco, you may need this step to charge your KAT
loco. Here is the instruction:
17
First Use Instructions
L Signal Light R Signal Light W Signal Light
Micro-USB
Left Ankle sensor Righ Ankle sensorWaist sensor
Micro-USBMicro-USB

18
02.Pairing: Launch KAT Gateway, click 'Device Manager', and select
'Pair Sensor'. Then, follow the instructions on the screen and connect
the sensors to your PC one by one according to the prompts to
complete the pairing.
Notice about the receiver location:
It is recommended for the receiver to
be placed on a table in the open space,
without any metal objects or any other
large items blocking the connection
with the sensors.
01
01. Connecting: Take out the USB cable and the receiver, then
connect it to your PC. Verify that the receiver is in good technical
condition and launch the software.
Receiver
02

04. Putting on the waist sensor:
I. Gently pry open the sensor clip;
19
The lighting signals described below signalize different
operation modes of your KAT loco:
Recharging: Diming light
Fully charged: Long bright signal
Low power: Flashing with a long break
Pairing/Firmware updating: Quick flashing
Unpairing: Slow flashing
Sleep Mode/Power-off: Light off
03. Waist Sensor Mag Calibration: When used for the first time,
the waist sensor requires to collect the location data to complete the
calibration process. Select 'Waist Mag Calibration' in KAT Gateway
and follow the instructions on the screen.
Note: 1. Magnetic calibration should be carried out at the actual location of use.
2. If you change your location, please re-calibrate the device.
I

20
II. Clip the waist sensor in front, right in the center of your waist to
ensure the correct operation of the device;
II
Skewed placement Upside down placement
The pictures below show improper placement of the sensor.
III
