Katana 220030 User manual

CORDLESS SWIVEL HEAD TORCH INSTRUCTION MANUAL
CORDLESS Swivel HEAD TORCH
INSTRUCTION MANUAL
220030
LITHIUM ION
18V
WARRANTY*
5 YEAR
LED LIGHT
3 WATT
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
CHARGE-ALL
CHARGE-ALL
18V
18V

CORDLESS SWIVEL HEAD TORCH INSTRUCTION MANUAL
1
GENERAL POWER TOOL SAFETY WARNINGS
Direct current, DC Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check
with your Local Authority or retailer for
recycling advice.
Refer to instruction manual/booklet
General warning Regulator compliance mark
The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use.
WARNING Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury. Save all warnings and
instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators,ranges and refrigerators. There is an increased risk
of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering
a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal
injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-
position before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your finger
on the switch or energising power tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working conditions
and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs.
Use of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a
fire.
d) Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair person using
only identical replacement parts. This will ensure that the safety of the
power tool is maintained.
SYMBOLS
220030

CORDLESS SWIVEL HEAD TORCH INSTRUCTION MANUAL
LI-ION
Ah
18V CHARGE-ALL
18V CHARGE-ALL
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
LI-ION
Ah
18V CHARGE-ALL
18V CHARGE-ALL
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
2
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
CHARGE-ALL
CHARGE-ALL
18V
18V
KNOW YOUR PRODUCT
1 - SWIVEL HEAD UNIT
4 - BELT CLIP
2 - ON/OFF SWITCH
3- HANGER/STAND
(ANY 18V CHARGE-ALL
BATTERY WILL FIT)
BATTERY
INSERTS HERE
HOW TO INSERT BATTERY ON TOOL
1. ALIGN BATTERY RIBS WITH TOOL 2. SLIDE INTO TOOL 3. STOP WHEN YOU HEAR IT CLICK IN PLACE
LI-ION
Ah
18V CHARGE-ALL
18V CHARGE-ALL
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
1 2 3
*CLICK*
220030
TOOL ASSEMBLY
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
CHARGE-ALL
CHARGE-ALL
18V
18V
INSTALLING THE BELT CLIP
Place provided belt clip (4) in the desired position
on the side of the torch. Using a Phillips head #2
screwdriver, place screw through clip into screw
hole & hand tighten until you feel resistance & clip
is adequately tight.
Voltage 18V d.c.
LED Light levels 2
Wattage 3W
Rotation 360O
Indexing 180O
SPECIFICATIONS

CORDLESS SWIVEL HEAD TORCH INSTRUCTION MANUAL
MAINTAINANCE
This power tool normally requires no maintenance; from time to time the ventilation slots on the motor
casing should be cleaned out. If the unit should become defective, repair should be performed by an
authorized service agent for electric tools.
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various
types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust,
oil, grease, etc.
Warning!
Do not at any time let brake fluids, gasoline, petroleum based products, penetrating oils, etc., come in contact with
plastic parts. Chemicals can damage, weaken or destroy plastic which may result in serious personal injury.
VERTICAL SWIVEL (180°) HORIZONTAL SWIVEL (360°)
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
CHARGE-ALL
CHARGE-ALL
18V
18V
HOW TO TURN THE TORCH ON
The hanger/stand (3) has three available positions:
Position 1: Closed
Position 2: Used as a stand to hold up the torch
Position 3: Used to hang the torch up allowing for
handsfree usage
To turn on the torch, press the on/off switch (2)
once for low light and twice for full light.
HOW TO USE THE STAND
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
CHARGE-ALL
CHARGE-ALL
18V
18V
Australia & Global
www.katanapowertools.com.au
[email protected]
[phone]
Made to Katana
specifications and
quality standards
in China.
NOT INTENDED
FOR TRADE USE
* Standard 3 year warranty with an additional 2 year warranty available subject to online registration via
katanapowertools.com.au. Warranty on this Katana product is given by Kincrome Australia Pty Ltd of 3 Lakeview
Drive, Caribbean Park, Scoresby, Victoria, Australia (Tel [phone]) If this product has materials or
workmanship defects (other than defects caused by abnormal or non warranted use) you can, at your cost, send
the product to place of purchase, an authorised Kincrome service agent or one of Kincromes addresses for repair
or replacement. Your rights under this warranty are in addition to any other rights you have under the Australian
Consumer Law or other applicable laws. Our goods come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. For further details please visit www.kincrome.com.au or call us. Due to minor changes in design
or manufacture, the product you purchase may sometimes differ from the one shown on the packaging.
HOW TO USE THE TORCH
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
CHARGE-ALL
CHARGE-ALL
18V
18V
18V CHARGE-ALL
18V CHARGE-ALL
CHARGE-ALL
CHARGE-ALL
18V
18V
CHARGE-ALL
CHARGE-ALL
18V
18V
WARRANTY*
5 YEAR
220030
