KEBCO 7608000-4001 User manual

SERVO MOTOR
INSTRUCTIONS FOR USE | INSTALLATION PITCH SYSTEMS
Translation of the original manual
Document 20095783 EN 03

3
PREFACE
Preface
The described hard- and software are developments of the KEB Automation KG. The
enclosed documents correspond to conditions valid at printing. Misprint, mistakes and
technical changes reserved.
Signal words and symbols
Certain operations can cause hazards during the installation, operation or thereafter.
There are safety informations in the documentation in front of these operations. Security
signs are located on the device or machine. A warning contains signal words which are
explained in the following table:
DANGER Dangerous situation, which will cause death or serious injury in case of
non-observance of this safety instruction.
WARNING Dangerous situation, which may cause death or serious injury in case of
non-observance of this safety instruction.
CAUTION Dangerous situation, which may cause minor injury in case of non-ob-
servance of this safety instruction.
ATTENTION Situation, which can cause damage to property in case of non-obser-
vance.
RESTRICTION
Is used when certain conditions must meet the validity of statements or the result is
limited to a certain validity range.
Is used when the result will be better, more economic or trouble-free by following
these procedures.
More symbols
► Thisarrowstartsanactionstep.
• / - Enumerations are marked with dots or indents.
=> Cross reference to another chapter or another page.
Note to further documentation.
www.keb.de/nc/search

4
PREFACE
Laws and guidelines
KEBAutomationKGconrmswiththeCEmarkandtheECdeclarationofconformity,
that our device complies with the essential safety requirements.
The CE mark is located on the name plate. The EC declaration of conformity can be
downloaded on demand via our website. Further information is provided in chapter "Cer-
tication".
Warranty
The warranty on design, material or workmanship for the acquired device is given in the
current terms and conditions.
Hereyouwillndourcurrenttermsandconditions.
www.keb.de/terms-and-conditions
Furtheragreementsorspecicationsrequireawrittenconrmation.
Support
Through multiple applications not every imaginable case has been taken into ac-
count. If you require further information or if problems occur which are not treated de-
tailed in the documentation, you can request the necessary information via the local
KEB Automation KG agency.
The use of our units in the target products is beyond of our control and therefore
exclusively the responsibility of the machine manufacturer, system integrator or
customer.
Theinformationcontainedinthetechnicaldocumentation,aswellasanyuser-specic
advice in spoken and written and through tests, are made to best of our knowledge and
information about the application. However, they are considered for information only
without responsibility. This also applies to any violation of industrial property rights of a
third-party.
Selection of our units in view of their suitability for the intended use must be done gener-
ally by the user.
Tests can only be done within the application by the machine manufacturer. They
must be repeated, even if only parts of hardware, software or the unit adjustment
are modied.
Copyright
The customer may use the instruction manual as well as further documents or parts from
it for internal purposes. Copyrights are with KEB Automation KG and remain valid in its
entirety.
Other wordmarks or/and logos are trademarks (™) or registered trademarks (®) of their
respectiveownersandarelistedinthefootnoteontherstoccurrence.

5
TABLE OF CONTENTS
Table of Contents
Preface ....................................................................................................................................................3
Signal words and symbols .............................................................................................................3
More symbols.................................................................................................................................3
Laws and guidelines.......................................................................................................................4
Warranty .......................................................................................................................................4
Support .......................................................................................................................................4
Copyright........................................................................................................................................4
Table of Contents ...................................................................................................................................5
List of Figures.........................................................................................................................................7
List of Tables ..........................................................................................................................................8
Glossary ..................................................................................................................................................9
Standards for asynchronous and synchronous motors ..................................................................10
1 Basic Safety Instructions............................................ 13
1.1 Target group...................................................................................................................................13
1.2 Transport, storage and proper use .............................................................................................. 13
1.3 Installation......................................................................................................................................14
1.4 Connection instructions ...............................................................................................................15
1.4.1 EMC-compatible installation...............................................................................................16
1.5 Start-up and operation .................................................................................................................. 16
1.6 Maintenance...................................................................................................................................17
1.7 Repair .............................................................................................................................................17
2 Product Description .................................................... 19
2.1 Specied application.....................................................................................................................19
2.1.1 Residual risks .....................................................................................................................19
2.2 Unintended use..............................................................................................................................19
2.3 Overview of the motor...................................................................................................................19
2.4 General speed-torque characteristic ........................................................................................... 20
2.5 Construction and denition..........................................................................................................20
2.5.1 Drive end and direction of rotation .....................................................................................20
2.5.2 Winding and insulation system...........................................................................................21
2.5.3 Holding brake .....................................................................................................................21
2.5.4 Speed and shaft position measuring system......................................................................22
2.5.5 Temperature monitoring .....................................................................................................23
3 Technical Data.............................................................. 25
3.1 Product features of servo motors for pitch systems ................................................................. 25
3.2 Ambient conditions .......................................................................................................................25
3.2.1 Testangeforthermaldeterminations ...............................................................................26
3.2.2 Coolant temperature at different site altitudes....................................................................26
3.3 Degree of protection of servo motors .........................................................................................27

6
TABLE OF CONTENTS
3.4 Technical data for servo motor 7606910-40xx ........................................................................... 28
3.4.1 Dimensions of the servo motor 7606910-40xx...................................................................29
3.4.2 Shaft end for the servo motor 7606910-40xx..................................................................... 30
3.4.3 Torque / speed characteristic of the servo motor 7606910-40xx........................................31
3.5 Technical data for the servo motor 7607613-40xx......................................................................32
3.5.1 Dimensions of the servo motor 7607613-40xx...................................................................33
3.5.2 Shaft end for servo motor 7607613-40xx........................................................................... 34
3.5.3 Torque / speed characteristic of the servo motor 7607613-40xx........................................35
4 Connection................................................................... 37
4.1 Connection servo motor 7606910-40xx.......................................................................................37
4.1.1 Motor connection servo motor 7606910-40xx.................................................................... 38
4.1.2 Encoder connection servo motor 7606910-40xx................................................................39
4.1.3 Connection of the brake and temperature monitoring for servo motor 7606910-40xx....... 39
4.2 Connection servo motor 7607613-40xx.......................................................................................40
4.2.1 Motor connection servo motor 7607613-40xx.................................................................... 41
4.2.2 Encoder connection servo motor 7607613-40xx................................................................42
4.2.3 Connection of the brake and temperature monitoring for servo motor 7607613-40xx....... 42
5 Operation of the Servo Motor..................................... 43
5.1 Preparations...................................................................................................................................43
5.2 Initial start-up.................................................................................................................................43
5.3 Operation........................................................................................................................................44
5.4 Maintenance and repair ................................................................................................................44
5.5 Maintenance intervals ...................................................................................................................44
6 Certication.................................................................. 46
6.1 Certication....................................................................................................................................46
6.1.1 CE Marking.........................................................................................................................46
6.2 Further information and documentation ..................................................................................... 46
7 Revision History .......................................................... 47

7
LIST OF FIGURES
List of Figures
Figure 1: general speed-torque characteristic.................................................................................20
Figure2: examplegureofanengine.............................................................................................20
Figure 3: Varistor protective wiring..................................................................................................22
Figure 4: Dimensions of the servo motor 7606910-40xx ................................................................29
Figure 5: Shaft end of the servo motor 7606910-40xx....................................................................30
Figure 6: Torque / speed characteristic of the servo motor 7606910-40xx ..................................... 31
Figure 7: Dimensions of the servo motor 7607613-40xx ................................................................33
Figure 8: Shaft end of the servo motor 7606910-40xx....................................................................34
Figure 9: Torque / speed characteristic of the servo motor 7607613-40xx ..................................... 35
Figure 10: Connection servo motor 7606910-40xx...........................................................................37
Figure 11: Terminal assignment of the motor connection .................................................................38
Figure 12: Terminal assignment of the resolver plug for servo motor 7606910-40xx ....................... 39
Figure 13: Pin assignment of the brake connection and temperature monitoring for servo
motor 7606910-40xx........................................................................................................39
Figure 14: Connection servo motor 7607613-40xx...........................................................................40
Figure 15: Terminal assignment of the motor connection .................................................................41
Figure 16: Terminal assignment of the resolver plug for servo motor 7607613-40xx ....................... 42
Figure 17: Pin assignment of the brake connection and temperature monitoring for servo
motor 7607613-40xx........................................................................................................42

8
LIST OF TABLES
List of Tables
Table 1: Product features...............................................................................................................25
Table 2: Ambient conditions...........................................................................................................25
Table3: Testangedimensions ....................................................................................................26
Table 4: Coolant temperature ........................................................................................................26
Table 5: IP degree of protection.....................................................................................................27
Table 6: Technical data servo motor 7606910-40xx ......................................................................28
Table 7: Technical data holding brake 0728G1T-0557 ..................................................................28
Table 8: Technical data servo motor 7607613-40xx ......................................................................32
Table 9: Technical data holding brake 7607613-40xx ...................................................................32

9
GLOSSARY
Glossary
0V Earth-potential-free common point
1ph 1-phase mains
3ph 3-phase mains
AC AC current or voltage
ASCL Asynchronous sensorless closed
loop
auto motor
ident.
Automaticallymotoridentication;
calibration of resistance and induc-
tance
AWG American wire gauge
B2B Business-to-business
BiSS Open source real-time interface for
sensors and actuators (DIN 5008)
COMBIVERT KEB drive converters
COMBIVIS KEB start-up and parameterizing
software
DC DC current or voltage
DIN German Institut for standardization
EMC Electromagnetic compatibility
Emergency
stop
Shutdown of a drive in emergency
case (not de-energized)
Emergency
switching off
Switching off the voltage supply in
emergency case
EN European standard
FE Functional earth
FU Drive converter
GND Reference potential, ground
Hiperface Bidirectional encoder interface of the
company Sick-Stegmann
HTL Incremental signal with an output
voltage (up to 30V) -> TTL
I²t-monitoring Software function for thermal monito-
ring of the motor winding
IEC International standard
IP xx Degree of protection (xx for level)
KTY Silicium temperature sensor (pola-
rized)
MCM American unit for large wire cross
sections
Modulation Means in drive technology that the
power semiconductors are controlled
MTTF Mean service life to failure
NN Sea level
PA Potential equalization
PE Protective earth
PELV Protective Extra Low Voltage
PFD Term used in the safety technology
(EN 61508-1...7) for the size of error
probability
PFH Term used in the safety technology
(EN 61508-1...7) for the size of error
probability per hour
PLC Programmable logic controller
PT100 TemperaturesensorwithR0=100Ω
PT1000 TemperaturesensorwithR0=1000Ω
PTC PTC-resistor for temperature detec-
tion
PWM Pulse width modulation
RJ45 Modular connector with 8 lines
SCL Synchronous sensorless closed loop
SELV Safety Extra Low Voltage (< 60 V)
SS1 Safety function „Safe stop 1“ in ac-
cordance with IEC 61800-5-2
SSI Synchronous serial interface for
encoder
STO Safety function „Safe Torque Off“ in
accordance with IEC 61800-5-2
TTL Incremental signal with an output
voltage up to 5 V
VARAN Real-time Ethernet bus system

10
STANDARDS FOR ASYNCHRONOUS AND SYNCHRONOUS MOTORS
Standards for asynchronous and synchronous motors
DGUV regulation 3 Electrical installations and equipment
DIN 46228-1 Tubular end-sleeves without plastic sleeve
DIN 46228-4 Tubular end-sleeves with plastic sleeve
DIN IEC 60364-5-54 Low-voltage electrical installations - Part 5-54: Selection and erection of
electrical equipment - Earthing arrangements, protective conductors and protec-
tive bonding conductors
EN 60204-1 Safety of machinery - Electrical equipment of machines - Part 1: General requi-
rements (IEC 44/709/CDV)
EN 60439-1 Low-voltage switchgear and controlgear assemblies - Part 1: Type-tested and
partially type-tested assemblies (IEC 60439-1)
EN 60529 Degrees of protection provided by enclosures (IP Code) (IEC 60529)
EN 60664-1 Insulation coordination for equipment within low-voltage systems - Part 1:
Principles, requirements and tests (IEC 60664-1)
EN60721-3-1 Classicationofenvironmentalconditions-Part3:Classicationofgroupsof
environmental parameters and their severities - Section 1: Storage (IEC 104/648/CD)
EN60721-3-2 Classicationofenvironmentalconditions-Part3:Classicationofgroupsof
environmental parameters and their severities - Section 2: Transportation and
handling (IEC 104/670/CD)
EN60721-3-3 Classicationofenvironmentalconditions-Part3:Classicationofgroupsof
environmentalparametersandtheirseverities;section3:Stationaryuseat
weatherprotected locations (IEC 60721-3-3)
EN 61800-2 Adjustable speed electrical power drive systems - Part 2: General requirements
-Ratingspecicationsforlowvoltageadjustablespeeda.c.powerdrivesystems
(IEC 61800-2)
EN 61800-3 Adjustable speed electrical power drive systems - Part 3: EMC requirements
andspecictestmethods(IEC22G/297A/CD)
EN 61800-5-1 Adjustable speed electrical power drive systems - Part 5-1: Safety requirements
- Electrical, thermal and energy (IEC 61800-5-1)
UL61800-5-1 American version of the EN 61800-5-1 with „National Deviations“
EN 60034-1 Rotating electrical machines - Part 1: Rating and performance (IEC 2/1768/CD)
EN60034-2-3 Rotatingelectricalmachines-Part2-3:Specictestmethodsfordetermining
lossesandefciencyofconverter-fedACmotors(IEC2/1841/CD)
EN 60034-5 Rotating electrical machines - Part 5: Degrees of protection provided by integral
designofrotatingelectricalmachines(IPcode)-Classication(IEC60034-5)
EN 60034-6 Rotating electrical machines - Part 6: Methods of cooling (IC-Code) (IEC 60034-6)
EN60034-7 Rotatingelectricalmachines-Part7:Classicationoftypesofconstruction,
mounting arrangements and terminal box position (IM code) (IEC 60034-7)
EN 60034-8 Rotating electrical machines - Part 8: Terminal markings and direction of rotation
(IEC 60034-8)
EN 60034-9 Rotating electrical machines - Part 9: Noise limits (IEC 60034-9)
EN 60034-11 Rotating electrical machines - Part 11: Thermal protection (IEC 60034-11)
EN 60034-14 Rotating electrical machines - Part 14: Mechanical vibration of certain machines
with shaft heights 56 mm and higher - Measurement, evaluation and limits of
vibration severity (IEC 60034-14)
IEC/TS 60034-17 Rotating electrical machines - Part 17: Cage induction motors when fed from
converters - Application guide (IEC/TS 60034-17)
EN 60034-18-41 Rotating electrical machines - Part 18-41: Partial discharge free electrical

11
STANDARDS FOR ASYNCHRONOUS AND SYNCHRONOUS MOTORS
insulation systems (Type I) used in rotating electrical machines fed from voltage
converters-Qualicationandqualitycontroltests(IEC60034-18-41)
EN 60034-18-42 Rotating electrical machines - Part 18-42: Partial discharge resistant electrical
insulation systems (Type II) used in rotating electrical machines fed from voltage
converters-Qualicationtests(IEC2/1798/CDV)
IEC/TS 60034-24 Rotating electrical machines - Part 24: Online detection and diagnosis of
potential failures at the active parts of rotating electrical machines and of bearing
currents - Application guide (IEC/TS 60034-24)
IEC 2/1689/CD Rotating electrical machines - Part 25: AC machines when used in power drive
systems - Application guide (IEC 2/1689/CD)
DINEN60034-30-1 Rotatingelectricalmachines-Part30-1:EfciencyclassesoflineoperatedAC
motors (IE code) (IEC 60034-30-1)
DIN CLC/TS 60034-31  Rotatingelectricalmachines-Part31:Selectionofenergy-efcientmotors
including variable speed applications - Application guide (IEC/TS 60034-31)
DIN 748-3 Cylindrical shaft ends - Part 3: For rotating electrical machinery
DINSPEC42955 Shaftextensionrunoutandofmountingangesforrotatingelectricalmachinery,
frame size larger then 315 - Tolerances, test
DIN EN 50347 General purpose three-phase induction motors having standard dimensions and
outputs-Framenumbers56to315andangenumbers65to740
DIN6885-1 DriveTypeFasteningswithoutTaperAction;ParallelKeys,Keyways,DeepPattern
DIN 332-2 Center holes 60° with thread for shaft ends for rotating electrical machines

12
STANDARDS FOR ASYNCHRONOUS AND SYNCHRONOUS MOTORS

13
BASIC SAFETY INSTRUCTIONS
1 Basic Safety Instructions
The following safety instructions have been created by the manufacturer for the area of
electric drive technology. They can be supplemented by local, country- or application-
specicsafetyinstructions.Thislistisnotexhaustive.Non-observancewillleadtothe
loss of any liability claims.
ATTENTION Hazards and risks through ignorance.
►Read the instructions for use!
►Observe the safety and warning instructions!
►If anything is unclear, please contact KEB!
1.1 Target group
This instruction manual is determined exclusively for electrical personnel. Electrical per-
sonnelforthepurposeofthisinstructionmanualmusthavethefollowingqualications:
• Knowledge and understanding of the safety instructions.
• Skills for installation and assembly.
• Start-up and operation of the product.
• Understanding of the function in the used machine.
• Detection of hazards and risks of the electrical drive technology.
• Knowledge of DIN IEC 60364-5-54.
• Knowledge of national safety regulations (e.g. DGUV regulation 3).
1.2 Transport, storage and proper use
Thetransportiscarriedoutbyqualiedpersonsinaccordancewiththeenvironmental
conditionsspeciedinthismanual.Motorsshallbeprotectedagainstexcessivestrains.
ESD
Damage due to improper transport
► Transportonlyonsuitabledevices(foldingboxes,transportframes,at
pallets, usw) !
►Avoid any impacts, sharp sudden movements and strong vibrations!
►Motors must only be lifted and placed at creeping speed to prevent dam-
age to the bearings !
Do not store Motors
• in the environment of aggressive and/or conductive liquids or gases.
• with direct sunlight.
• outsidethespeciedenvironmentalconditions.

14
BASIC SAFETY INSTRUCTIONS
To prevent damage to the motor:
• Checkifnecessaryanddonotremoveanti-corrosivecoatattheshaftends,ange
surfaces etc.
• No vibrations may occur in the storage location.
• In case of storage longer than 3 months, rotate the motor in both directions at a slow
speed (< 100 rpm) to allow the grease to distribute evenly in the bearings.
• If necessary, rotate the rotor at least once a year several times, in order to avoid
corrosion on the bearings.
1.3 Installation
DANGER Do not operate in an explosive environment!
EX
►The motors are not intended for the use in potentially explosive
environment.
CAUTION Maximum design edges and high weight!
Contusions and bruises!
►Never stand under suspended loads.
►Wear safety shoes.
►Secure motor accordingly when using lifting gear.
To prevent damages to the motor:
• Make sure that isolation distances will be respested in the terminal box.
• Before commissioning motors with a shaft key, secure the key to ensure that it can-
not be thrown out if this is not already prevented by driving elements such as a belt
pulley, coupling, etc.
• The motor must not be put into operation in case of mechanical defects. Non-
compliance with the applicable standards.
• Do not allow moisture or mist to penetrate the motor.
• Avoid dust permeating the device.
• Note installation position and minimum distances to surrounding elements. Do not
cover the ventilation openings.
• Make sure that no small parts fall into the motor during assembly and wiring (drilling
chips, screws etc.). This also applies to mechanical components, which can lose
small parts during operation.
• Check the reliable t of the terminals in order to avoid contact resistances and
sparking.
• Do not climb on the motor housing.
• The safety instructions are to be kept!

15
BASIC SAFETY INSTRUCTIONS
1.4 Connection instructions
DANGER Voltage at the terminals and in the motor!
Danger to life due to electric shock!
►Never work on the open motor or never touch exposed parts.During
the operation (even at zero speed) the motors posses dangerous
live parts.
►For any work on the motor switch off the supply voltage and secure
it against switching on.
►Wait until the drive has stopped in order that no regenerative energy
can be generated.
►Never bridge upstream protective devices (also not for test pur-
poses).
►Connect the protective earth conductor to drive converter and motor.
►Install all required covers and protective devices for operation.
For a trouble-free and safe operation, please pay attention to the following instructions:
• The electrical installation shall be carried out in accordance with the relevant re-
quirements.
• The motors are not designed for direct connection to the three-phase system but are
to be operated via an electronic power inverter.
• Connect the temperature sensor to protect the motor against slow thermal chang-
es. Temperature sensors do not represent an all-around protection of the winding.
Measures must be taken in the parameterisation of the inverter for the protection
against fast thermal changes (e.g. I2´t-monitoring) !
• Check the proper functioning of the brake (optional).
• An optional holding brake is only designed for a limited number of emergency brak-
ings. Never use it as a working brake.On motors with plug connector and built-in
brake, it is the user's responsibility to install the varistor provided to control the
brake.
Installations which include drive converter shall be equipped with additional control and
protective devices in accordance with the relevant applicable safety requirements, e.g.
act respecting technical equipment, accident prevention rules etc. They must always be
complied with, also for drive converter bearing a CE marking.

16
BASIC SAFETY INSTRUCTIONS
1.4.1 EMC-compatible installation
Observance of the limit values required by EMC law is the responsibility of the manufac-
turer of the installation or machine.
Notes on EMC-compatible installation can be found here.
0000ndb0000.pdf
1.5 Start-up and operation
The drive converter must not be started until it is determined that the installation com-
plieswiththemachinedirective;AccountistobetakenofEN 60204-1.
WARNING Software protection and programming!
Hazards caused by unintentional behavior of the drive!
►Check especially during initial start-up or replacement of the drive
converter if parameterization is compatible to application.
►Securing a unit solely with software-supported functions is not suf-
cient.Itisimperativetoinstallexternalprotectivemeasures(e.g.
limit switch) that are independent of the drive converter.
►Secure motors against automatic restart.
CAUTION High temperatures at heat sink and coolant!
Burning of the skin!
►Cover hot surfaces safe-to-touch.
►Before working let the motor cool down.
►Before touching, check the surface and cooling water lines.
►If necessary, attach warning signs on the system.

17
BASIC SAFETY INSTRUCTIONS
Switching at the output
Switching between motor and drive converter is prohibited for single drives during op-
eration as this may trigger the protection gear of the device. Function speed search must
be activated if switching can not be avoided. Control release may only be triggered after
closing the motor contactor (e.g. by switching the control release).
Connecting and disconnecting is permissible with multiple motor drives if at least 1 mo-
tor is running during the switch-over process. The drive converter must be dimensioned
to the occurring starting currents.
The speed search function must be activated if the motor is still running during a restart
of the drive converter (mains on) (e.g. due to large rotating masses).
1.6 Maintenance
Die folgenden Wartungsarbeiten sind nach Bedarf, mindestens jedoch einmal pro Jahr,
durch autorisiertes und eingewiesenes Personal durchzuführen.
►Check unit for loose screws and plugs and tighten if necessary.
► Cleanmotorfromdirtanddustdeposits.Payattentionespeciallytocoolingnsand
protective grid of the fans.
►Check the function of the fans of the drive converter. The fan must be replaced in
case of audible vibrations or squeak.
1.7 Repair
In case of malfunction, unusual noises or smells inform a person in charge!
DANGER Unauthorized exchange, repair and modications!
Unpredictable malfunctions!
► ModicationorrepairispermittedonlybyKEBAutomationKGau-
thorized personnel.
►Only use original manufacturer parts.
►Infringement will annul the liability for resulting consequences.
In case of failure, please contact the machine manufacturer. Only the manufactor can
provide an appropriate replacement or induce the maintenance.

18

2 Product Description
Theservomotorforpitchsystemsisan8-polepermanent-eldsynchronousmotorwith
sine-wave inducted voltage and extremely high power density.
2.1 Specied application
The KEB synchronous servo motors are exclusively designed for the operation at digital
servo controllers. They are intended for industrial systems only. They comply with the
harmonized standards of the series VDE 0530/EN 60034-1
The technical data and information for connection conditions can be found on the type
plate and the instructions for use and must be complied with.
2.1.1 Residual risks
Despite intended use, the motor can reach unexpected operating conditions in case of
error, with wrong parameterization of the inverter, by faulty wiring or non-professional
interventions and repairs. This can be:
• wrong direction of rotation
• motor speed too high
• motor is running into limitation
• motor can be under voltage even in standstill
• automatic start
• motor coasts to standstill
2.2 Unintended use
The operation of our products outside the indicated limit values of the technical data
leads to the loss of any liability claims!
2.3 Overview of the motor
Name Material numbers
Servo motor for pitch systems size 10 7606910-40xx
Servo motor for pitch systems size 13 7607613-40xx
19
PRODUCT DESCRIPTION

2.4 General speed-torque characteristic
Denition View
Md0 Stall torque (n=0)
nNnmax
MdN
Mmax
M
Md0
UDC
n
S1-105K
Mmax max. torque
MdN Rated torque
nNRated speed
nmax max. speed
UDC DC link voltage
Figure 1: general speed-torque characteristic
2.5 Construction and denition
2.5.1 Drive end and direction of rotation
Drive end of the motor View
In DIN EN 60034-7, the two ends of a motor are
denedasfollows:
D
N
D (Drive End):
Drive end (AS) of the motor.
N (Non-Drive End):
Non-drive end (BS) of the motor.
Direction of rotation of the motor
When the motor terminals U1, V1, W1 are connect-
ed to the inverter output with U, V, W (with this same
phase order) the motor rotates clockwise when
viewed facing the D-end.
Figure 2: example gure of an engine
20
PRODUCT DESCRIPTION
