Keces P14 User manual

P14
Ultra Low Noise Linear Power Supply
USER MANUAL




Warning
1. Installation and service should be performed only by qualified and
experienced technicians and comply with all local codes and rules to
maintain your warranty.
2. To reduce the risk of fire or electric shock, do not expose the product to
rain or moisture.
3. Wipe the case with a dry soft cloth. For tough stains, slightly apply with
diluted neutral detergent and wipe with a dry soft cloth.
4. Do not apply benzene or thinner to the case, which may cause the surface
of
unit to be melted or fogged.
5. Avoid operating or storing the unit in the following locations:
6. Extremely humid, dusty, or hot/cold environments (recommended
operating
temperature: 0°C to +40°C)Close to sources of powerful radio or TV
transmitters.

Get Started
This user manual is designed as a reference for the installation and
manipulations of the unit including the product’s features, functions.
Please read this manual thoroughly and save it for future use before
attempting to connect or operate the unit. The reader is supposed to be
able to get the following information in this manual.
1. Product Overview: the main functions and system requirements of
the unit.
2. Installation and Connection: instructions on unit installation and
wire connections.
3. Administration and Configuration: the main menu navigation and
controls explanations.

FCC Compliance Statement
Information to the user: This unit has been tested and found to comply with
the limits for FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that
may cause undesired operation. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This unit generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the manual, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this unit does cause harmful interference to radio or television reception,
which can be determined by turning the unit off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the unit and receiver.
3. Connect the unit to an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
<
Caution
>
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the unit.

Pack Contents
1. KECES P14
2. AC Power Cable
3. User manual
4. DC 12V Trigger Cable
5. DC Cables x 2pcs.
Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation. The manufacturer declares that the unit supplied with this guide
is compliant with the essential protection requirements of EMC
(2014/30/EU) Directive and General Product Safety (2014/35/EU)
Directive.
CE Statement

Unpacking Your P14 & Placement Guidelines
Unpacking
Carefully remove your P14 from its shipping carton and locate the enclosed
accessories:
• AC power cord
• A 12V trigger wire for auto turn on. It has a mono 3.5 mm mini plug at each
end.
While you are unpacking your P14, inspect it thoroughly for possible shipping
damage and tell your KECES dealer immediately if you find any evidence of
shipping damage. This would be a good time to make a copy of your sales
receipt to store with the P14’s original packing.
Note:
Please save and store both the inner and outer cartons and, most especially,
the foam packing inserts to protect the P14 if you have to move it or ship it. You
may wish to flatten the cardboard cartons to save room in storage after cutting
the taped seams on the bottom flaps.
--------------------------------------------------------------------------------------------------------
Placement Guidelines
The P14 will be easier to use and will last longer if you follow these simple
guidelines:
• Place the P14 on a surface that will adequately support its weight.
• Use input and output cables that are long enough to leave some slack; that will
enable you to pull the P14 out of a cabinet to check or to change connections
without inadvertently disconnecting cables.
• The P14 should never be placed in a completely enclosed cabinet.
Ventilation Requirements
• Always position the P14 horizontally.
• The P14 should never be stacked directly above another power amplifier and
power supply or directly below another component.
• Do not install the P14 in an unventilated equipment cabinet or compartment.
Pockets of stagnant hot air can build up even in a cabinet with an open front
and back. A ventilation fan is recommended to prevent “hot spots” in confined
spaces.

AC Mains Voltage
Make sure the 115V/230V Voltage Selector switch on the P14 bottom plate is set
for the correct Ac line(mains) voltage before you plug in the power cord. It can
be seriously damaged if this switch is set for the wrong AC mains voltage.
In the 115V position the P14 can safely operate with AC Line voltages between
110-125V which is correct for North America, Mexico, and Taiwan. In some
countries, such as Brazil, AC voltages differ by region. Most other countries
require setting it to 230V. With the 230V setting the P14 can operate safely with
AC line voltages between 220-250V. If the AC Voltage Selector is changed the
rear panel fuse value must also be changed. The P14 operates on 50Hz or 60Hz
AC.
Note:
An P14 that has been damaged by connection to the incorrect AC mains
voltage is not covered by the KECES warranty.
--------------------------------------------------------------------------------------------------------
AC Power Cord
The AC cord supplied with your P14 is a high quality IEC type cord. Please
connect it directly to an AC wall outlet or power conditioner that is always “live.” If
possible, plug your P14 and other components, (including a TV or video
projector) the ground potential may be higher or lower between the outlets,
resulting in audible hum.

Interface

Connections
Always disconnect the AC cord to your P14 before making or changing any
input, output or trigger wire connections. Inserting or removing an input or output
cable while the P14 is turned on damage your equipment. Make sure there is no
strain or tension on any cables that could cause them to pull loose.
DC output jacks
The P14 DC jacks size is 2.5/5.5mm
Turn On Options
The setting of the rear panel Turn On Options switch determines how the P14
turns on and off. Setting the Turn On Options switch to Manual or 12 V Trigger
the P14’s front panel Power button. There are two positions for this switch:
Manual:
When the Turn On Options switch is set to Manual the P14 is turned on and off
manually only by pressing the Power button on its front panel every time you
want to listen to music or start up others equipment.
12V Trigger:
When the Turn On Options switch is set to its 12V position, the P14 is turned on
and off only with an external +9 V to +12V DC voltage. When the external
voltage ceases the P14 will turn off within a few seconds. The 12V turn on trigger
circuit in the P14 requires a mere 5mA from the 12V trigger source.

12V In Jack
The P14 12V input uses a 3.5 mm jack (mono). To use the 12V trigger, insert the
trigger wire plug into this jack and the plug at the wire’s other end into your
preamplifier’s 12 V output jack. For your convenience we have included a 12V
trigger wire with mono 3.5 mm plugs at both ends. The P14 12V trigger circuit
draws a negligible 5 mA.
Note:
If your preamplifier’s 12V trigger output is terminal with + and – screws terminal,
you can cut the 3.5 mm plug off one end of the included trigger wire and attach
the bare wires to these terminals. The lead with the white stripe on it
corresponds to the plug’s tip and the unmarked lead corresponds to the sleeve
of the plug. The trigger plug tip is + (positive) and its sleeve – (negative).
12V Loop Out Jack
The Trigger Out jack lets you loop or “daisy-chain” the incoming trigger voltage
to an additional P14 or other component(s). The total load on your triggering
device’s 12 V output is the sum of the trigger current drawn by each of the
components you plan to loop together. Check the maximum capacity of your
preamplifier’s trigger output so you do not overload it by connecting too many
power amplifiers. Typical triggering devices are rated to handle 50 mA to 100
mA.
3.5 mm vs. 2.5 mm jacks
Some other KECES power amplifiers and preamplifiers might use a 2.5 mm
“sub-mini” (mono) trigger jack. To use the P14 trigger with products that use a
2.5mm jack you will need a 3.5 mm to 2.5 mm mono adapter for one of the plugs
on the included trigger wire.

Front Panel Operation
On-Off Button
Push once to turn on the P14. When the P14 is turned on the dim blue LED
indicator will become brighter and each channel indicators will illuminate.
Push the button again to turn off the P14. The front panel On-Off button will be
disabled when the Turn On Options switch is set to12 V.
The P14 protects itself from external conditions such as excessive heat and over
load. After you correct the fault, the P14 will resume operation. If the P14
remains in “protection mode” after it has cooled down and you’ve confirmed
there are no
external faults, it could indicate an internal problem. Please contact KECES’s
Technical Service Department.
Channel Indicators
When the four orange channel indicators are lit, please switch the DC output
voltage. When confirmed the DC output voltage, please press the Engage
button. When the blue channel indicators are lit, it means the DC voltage is
outputting. If the red channel indicators lit, it means OCP (Over Current
Protection).
OTP Indicator
It will glow red if any channel overheats. The On-Off button will also glow red if
the P14 overheats. If such a condition occurs you must provide for better
ventilation around the P14.
Problems and Remedies
Unit will not turn on
• Check the setting of the Turn On Options switch. (The front panel On-Off button
will be disabled if this switch is set to 12V).
• Check that the rear panel power switch is on and that the AC power is live.
Overheating
• Remove any nearby external sources of heat such other audio equipment or
heaters.
• Increase ventilation around the P14.

Specifications
Output Voltage and Current:
Zone I: 5V/7V/9V/12V, 4A.
Zone II: 12V/15V/19V/24V, 6A.
Zone III: 5V/9V, 2A.
Zone IV: USB 5V, 2A.
USB Isolator:
Support low and full speed data rate
for 1.5 Mbps and 12 Mbps.
Applications:
1. Audiophile grad systems.
2. Machine protection.
3. Measurement devices, test gear.
4. Medical environment.
Ripple Noise
<100uV at full power
<10uV at 60% load
Power Requirment
Standby: 0.5 Watt
Maximum: 500 Watts
Casing
All Aluminum
Dimension (WxDxH)
300x279x66mm
Weight
Net Weight 7 KG
Shipping Weight 9 KG

P14
Ultra Low Noise Linear Power Supply
Bedienungsanleitung



! Das Gerät ist ausnahmslos nur in trockenen Innenräumen zu betreiben.
! Niemals mit Feuchtigkeit in Verbindung bringen
! Niemals das Gerät öffnen. STROMSCHLAGGEFAHR ! Dies ist nur Fachpersonal
gestattet.
! Schließen Sie das Gerät nur an eine vorschriftsmäßig installierte und geerdete
Netzsteckdose an. Die Netzspannung muss mit den Angaben auf dem Typenschild
des Gerätes übereinstimmen.
! Achten Sie darauf, dass im Betrieb das Netzkabel niemals nass oder feucht wird.
Das
Netzkabel darf nicht eingeklemmt oder anderweitig beschädigt werden.
! Lassen Sie beschädigte Netzstecker oder Netzkabel sofort von dem Kundenservice
austauschen.
! Bei Gewitter den Netzstecker sofort aus der Steckdose entfernen.
! Das Gerät sollte nur mit einem trockenen Tuch gereinigt werden.
KEINE REINIGUNGSMITTEL oder TÜCHER mit RAUEN Material verwenden!
! Stellen Sie das Gerät so auf, dass kein Hitzestau entstehen kann. Auf eine
ausreichende Luftzufuhr ist zu achten.
! Es dürfen keine mit Flüssigkeit befüllten Behälter (z.B. Vasen) auf oder in die Nähe
des Gerätes stehen
! Decken Sie niemals die Belüftungsöffnungen zu!
! Sie dürfen das Gehäuse nicht öffnen und reparieren. In diesem Falle ist die
Sicherheit nicht gegeben. Stromschlaggefahr.
Elektrische und elektronische Geräte dürfen nach der europäischen WEEE Richtlinie
nicht mit dem Hausmüll entsorgt werden. Deren Bestandteile müssen getrennt der
Wiederverwertung oder Entsorgung zugeführt werden, weil giftige und gefährliche
Bestandteile bei unsachgemäßer Entsorgung die Umwelt nachhaltig schädigen
können. Sie sind als Verbraucher nach dem Elektrogesetz (ElektroG) verpflichtet,
elektrische und elektronische Geräte am Ende ihrer Lebensdauer an den Hersteller, die
Verkaufsstelle oder an dafür eingerichtete, öffentliche Sammelstellen kostenlos
zurückzugeben. Einzelheiten dazu regelt das jeweilige Landesrecht. Das Symbol auf
dem Produkt, der Betriebsanleitung oder/und der Verpackung weist auf diese
Bestimmungen hin. Mit dieser Art der Stofftrennung, Verwertung und Entsorgung von
Altgeräten leisten Sie einen wichtigen Beitrag zum Schutz unserer Umwelt. WEEE
Richtlinie: 2002/96/EG WEEE Nr.: DE84907860

Fangen wir an:
Diese Bedienungsanleitung eine Hilfe für Sie als Nutzer, um Ihnen alle
Funktionsmöglichkeiten und technische Möglichkeiten dieses Gerätes zu
erklären. Bitte lesen Sie vor Gebrauch des P-14 diese Anleitung gründlich
und bewahren Sie die Anleitung gut auf. Für eine spätere Verwendung oder
eine andere Nutzung lesen Sie diese Bedienungsanleitung erneut.
! Produkt Übersicht: Die wichtigsten Funktionen und Grundlagen für das
Gerät.
! Installation und Anschluss: Anleitung bei der Aufstellung und Anschluss des
Gerätes.
! Einstellungen: Erklärt die Bedienung und die Einstellmöglichkeiten.
CE Statement
Dieses Produkt ist mit der nach Richtlinie 2014/30/EU und 2014/35/EU
vorgeschriebenen Kennzeichnung versehen: Mit dem CE Zeichen erklärt
KECES, dass das Produkt die grundlegenden Anforderungen und Richtlinien
der europäischen Bestimmungen erfüllt.
Table of contents
Languages:
Other Keces Power Supply manuals
