Chapter
1
1
INTRODUCTION
1.1 Product escription
Keetouch’s 12.1" LCD touch monitors have a long-lasting pro uct cycle because the
enclosure is controlle by Keetouch’s specifications. Future panel improvements are therefore
possible without external changes. The KOT-0121US-SA6BP integrate with the Keetouch’s
SAW technology touchscreen.
1.2 About the Product
Your LCD openframe touchmonitor is a 12.1” SXGA TFT color isplay with the
following features:
•
Long lasting pro uct cycle-enclosure controlle by Keetouch specifications
•
Future generation panels phase -in without external changes
•
High quality panel with high brightness,high contrast ratio an broa viewing angle
•
Multiple mounting options inclu ing rear-mount ,VESA mount, horizontal or vertical
bracket-mount
•
Keetouch’s SAW technology on pure glass for the ultimate in image quality
•
Dual USB an RS232 touch interface
•
Worl wi e agency approvals
For full Pro uct Specifications refer to Appen ix A.
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 4 -
Chapter
2
2
INSTALLATION AND SETUP
This chapter iscusses how to install your LCD touchmonitor an how to install the river software.
2.1 Unpacking Your Touchmonitor
Check that the following 9 items are present an in goo con ition:
One Touchmonitor Two L-brackets
One Vi eo cable One Brick power supply One Driver software CD
One Serial cable One USB cable Eight M4 Screws an Washers
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 5 -
OR
One Power cable US/Cana a One European power cable
2.2 Product Overview
Main Unit Rear View
Side View Bottom View
2.3 Attaching the L-Brackets
NOTE: You will need a screwdriver to attach the L-brackets.
To attach the L-brackets:
1 Lay the monitor face own.
2 Place the long en of the L-bracket against the si e of touchmonitor. Line up the two
holes of the L-bracket with the two holes of the touchmonitor.
3 Place two M4 screws in the holes an with the screw river, screw them in to secure the
bracket.
4 Repeat steps 2 an 3 to attach the other L-bracket to the other si e of the touchmonitor.
NOTE: The way to attach the L-brackets has two options,See the illustration below:
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 6 -
Option 1
(L-brackets to the left and right sides)
Option 2
(L-brackets to the up and down sides)
2.4 VESA Mounting Interface
Your touchmonitor conforms to the VESA Flat Panel Monitor Physical Mounting
Interface (FPMPMITM) Stan ar which efines a physical mounting interface for flat panel
monitors, an correspon ing stan ar s for flat panel monitor mounting evices, such as wall
an table arms.
Your monitor has stan ar VESA mounting holes on the rear of the unit. The holes are
space at 75mm an 100mm stan ar .
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 7 -
NOTE:Do not penitrate the M4 screw into the monitor more than 5mm.
2.5 Interface Connection
Note: Before connecting the cables to your touchmonitor and PC, be sure that the
computer and touchmonitor are turned off.
1. Connect one en of either the serial (RS232) cable or the USB cable(but not both) to the
rear si e of the computer an the other en to the LCD monitor. Tighten by turning the two
thumb screws clockwise to ensure proper groun ing ( USB cable oes not have thumb
screws).
2. Connect one en of the video cable to the rear si e of computer an the other to the LCD
monitor. Tighten by turning the two thumb screws clockwise to ensure proper groun ing.
3. Connect one en of the power adapter to the monitor an the other en to the connector of
the power cor .
4. Press the power button on the rear panel to turn the monitor power on.
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 8 -
NOTE：
：：
：The touchmonitor should be integrated according to the above process, if not
may result in the touchmonitor working abnormally。
2.6 Installing the river Software and Calibration
Keetouch TouchSystems provi es river software that allows your touchmonitor to work
with your computer. Drivers are locate on the enclose CD-ROM for the following operating
systems:
• Win ows XP
• Win ows 2000
• Linux
The latest versions of rivers an river information for other operating systems are
available on the Keetouch TouchSystems web site at www.Keetouchtouch.com.
Your Keetouch touchmonitor is Plug-an -Play compliant. Information on the vi eo
capabilities of your touchmonitor is sent to your vi eo isplay a apter when Win ows starts.
If Win ows etects your touchmonitor, follow the instructions on the screen to install a
generic Plug-an -Play monitor.
2.6.1 Installing the river Software
ouble click the file of “Setup.exe” in the fol er , the Win ows will flip Dialog Box as
follow:
NOTE:Your touchmonitor have dual USB and Serial(RS232) touch interface port,
Depending upon whether you connected the USB communication cable or the
Serial(RS232) communication cable, you should install only the USB driver or the
Serial(RS232) driver. Install the USB driver, please chose the “KeeTouch, KCA USB
Series, USB”;Install the Serial(RS232) driver, please chose “theKeeTouch,KCA RS232
Series,Serial”.
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 9 -
After selecting the proper interface, click the Install button to start installing the river as
following.
Installation successfully as following:
2.6.2 Calibration
Click at the right si e in the own corner of the Desk-Top,then choose “calibrate”in
the pop-out of the menu ,an choose the “RS232” or “USB” at the submenu, as follow：
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 10 -
Win ows will pop-out the calibration interface, then click “+” with finger one by one,
as follow:
After clicking the “+” on by one, the calibration is complete .
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 11 -
Appendix
A
A
TECHNICAL SPECIFICATIONS
Specification
Model No. KOT-0121US-SA6BP
Series OT
，
Dust-proof
Structure Metal-cased Openframe and Black medal Dust-proof Front Bezel
LC Type Active matrix TFT-LCD
isplay Size 12.1
＂（
diagonal
）
Active Area 246mm×184.5mm
Suggested Resolution 800×600
Support Colors 262K
Pure LCD Panel 370cd/m
2
Brightness(Typ.) With SAW Glass Sensor 333cd/m
2
Response Time(Typ.) 45ms
Horizontal(left/right) 70°/70°
Viewing Angle
(Typ.at CR
＞
＞＞
＞
10)
）
））
）
Vertical(up/down) 50°/60°
Contrast Ratio(Typ.) 450:1
Video Input Analog RGB
Signal Input H/V Separate Sync. (TTL)
Video Signal Input
Connector Mini D-Sub 15-pin VGA
Frequency
（
（（
（
H/V
）
））
）
30
～
80KHz / 60
～
75Hz
Power Supply
Type: External brick
Input (line) voltage: 100-240 VAC 50-60 Hz
Output voltage/current: 12 volts at 4 amps max
Operating Temp. 0
～
50°C
Storage Temp. -20
～
60°C
Operating RH: 20%
～
80%
Environment
Storage RH: 10%
～
90%
MTBF 50 000 Hours
LC Back light Life(Typ.)
50 000 Hours
Weight
（
（（
（
N.W/G.W
）
））
）
4.3Kg /5.8 Kg (Approx.)
Power Consumption 25W Max.
Mount Interface 1)VESA 75mm and 100mm
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 12 -
2)Mount bracket horizontal or vertical
(Standard mount brackets are supplied)
Buttons AUTO + POWER - MENU
OS Control Function Brightness Contrast Ratio Auto-adjust Phase
Clock H/V Location Languages Function Reset
Touch screen Type 12.1” SAW 6MM thickness of touch screen sensor;
(Available Options: Anti-glare/Tempered)
Touch System Interface
USB and RS232
Certificates ETL FCC CE RoHS
Mechanical Drawing
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 13 -
Accessories
Power Cable
Power CablePower Cable
Power Cable: A North American power cable or an European power cable is included
according to the end user
’
s area.
Power Supply Brick
Power Supply BrickPower Supply Brick
Power Supply Brick:A power supply brick is included.
Touch/Video Cables
Touch/Video CablesTouch/Video Cables
Touch/Video Cables: Detachable serial or US touch cable，and video cables are
included
L
LL
L-
--
-brackets
bracketsbrackets
brackets：Two standard L-brackets are included.
Appendix
B
B
Typical Application
Gaming/Casino Systems
Outdoor and indoor Kiosks
Entertainment
Transport and Ticketing
Hospitality
Banking
Customizsed Solutions
12.1" LCD Open frame SAW TM
（
the Dust-proof Type
）
User Gui e (Rev2.0)
- 14 -
How to contact us
www.keetouch.com
Add：1-4th Floor，Building 9
Luck-King Science & Industry ark
Gongyedong Road，Longhua
Baoan, Shenzhen 518109，.R.China
Tel：+86-755-82599299
Fax：+86-755-82599968
Technical Support：
：：
