Keito K7 User manual

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page1of43
MULTIFUNCTION
K7
Technical Manual

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page2of43
A-Access totheAdvancedProgramming Mode.
Steps:
1. SwitchtheK7off.
2. Openthebackcover.
3. ConnecttheRS-232programmingterminalorthecomputerwiththeHTEprogramstartedtotheconnectorJP2
(RS-232#1) of theMainBoardP1PC.
4. SwitchtheK7on.
5. Duringautotest, press severaltimesthe"ENTER"key.
6. Whentheautotestisfinished,youwill beintheAdvancedProgrammingMode.
7. Makethenecessaryadjustments.
8. Whenfinished,switchtheK7off again.
9. Disconnecttheterminalorthecablegoingtothecomputer
10. SwitchtheK7on.Itisreadyforuse.
B-Operating intheAdvancedProgrammingMode.
B.1- Description oftheprogrammingterminal
TheterminalhasgotanLCDscreenwith4linesof 20 charactersand a45 keykeyboard.
The5keysontop(F1, F2,...F5) arethefunctionkeys, usedtoprogram specialcharacterssuchas"Ñ"inSpanishduringthe
programmingof theheaderand footerof theticket.
Theotherkeys(exceptthenumericones0,1,2...9) havegottwofunctions:
·Whenpressingthemdirectly, thecharactertobeprogrammedwillbetheoneshowedonwhitebackground.
·Whenpressingthem togetherwiththe"SHIFT"key, thecharactertobeprogrammedwill betheoneshowedon
bluebackground.
LCDscreenwith4lines
of20 characters.
Alphanumeric
keyboard.
Special function
keys

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page3of43
B.2-Generaloperation.
Duringautotest, thedisplaywill showtheversionand dateofthesoftware.Once youhaveaccessedintotheprogramming
mode, thedisplaywill showthefollowingmessage:
Textappearingontheterminalscreen
whenentering theprogrammingmode
Theadvantageof having adisplayisthat theprogrammingismoreintuitiveand allowsabetterknowledgeoftheoperation
inprogress.
·Themainmenu hasgot10 optionswhichwillappearsuccessivelyaslongasthe"SPACE"keyispressed.
·Ifinanyofthemainmenuoptionsthe"ENTER"keyispressed, youwill access thecorrespondingsub-menu.
·Whenaccessingasub-menu(aswell asinthemainmenu),ifyoupress the"SPACE"keytheoptionsof thecurrent
sub-menuwillappear.
·Ifwheninasub-menuyoupress the"ENTER"key, theprogramwillexecutetheselectedfunction.
·Ifwheninasub-menuyoupress the"Z"keyorthe"ESC"key, theterminalwillgobacktooption0of themainmenu.
(systemadjustments)).
·Ifduringatestoraselectionyoupress the"ESC"key, theterminalwillgobacktothecorrespondingoptionof the
sub-menu.
Keys Function
SPACE Usedtomoveinasub-menuand inthemainmenu.
ENTER Usedtoselectanoptionof themainmenu ortomakeanadjustmentorselectanoptioninasub-menu.
ZorESC Goesbacktooption0of themainmenuwhenyouareinamenuorasub-menu.
ESC Cancelsthecurrentexecutingoptionand get backtothemenu fromwhichthisoptionwascalled.
Thefollowingtableshowsall theoptionsof themainmenuanditscorresponding sub-menus:
MAIN MENU
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page4of43
MainMenuoptions Submenusandfunction
0 Memoryreset
1 Systemreport
2 Flags
3 Prices&coins
4 Collectionreport
5 Maintenance
6 Cointest
7 Displaytest
8 Serialnumber
0- Systemadjust.
9 Clearcounters
0 Heightsystemreset
1 Normalheightcontinuousmeasurement
2 Quickheightcontinuousmeasurement
3 Totalinnerheight
1- Heightadjust.
4 Frequencyadjustment
0 Weightsystemreset
1 Weightcontinuousmeasurement
2- Weightadjust.
2 Weightcalibration
0 Bloodpressuremeasurement
1 Pressurecalibration
2 Pressurecontinuousmeasurement
3- Pressureadjust.
3 Escapementtest
0 ImpedanceTest
1 Bodyfatcalibration
4-Body fatand heartrateadjust.
2 Heartratetest
0 Printerreset
1 Paperfeed
2 Printertestnº1
3 Printertestnº2
4 Printertestnº3
5 Cuttertest
5- Printeradjust.
6 Printingtemperature
0 Visualizetime&date
1 Programmingthetime
2 Programmingthedate
6- Time/Date
3 Programmingthedayoftheweek
0 Programmingtheticketheader
1 Programmingticketfooternº1
7- Header/footer
2 Programmingticketfooternº2
0 Smartcardpassword
1 Resetsmartcard
2 ModifytheCreditofthesmartcard
8- Smartcard
3 Listthesmartcard
0 Buzzertest
1 Voicetest
9- Voice/buzzertest
2 Music

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page5of43
0-System Adjustments. Group0ofoptions.
0.0-Memoryreset.
Thisoptionresetsthememorywiththedefaultvaluessetatthefactory:
-Thedefault ticketheaderandfootersareset.
-Thedefault originalinnerheightof theunitisset.
-Thedefault originalbloodpressureadjustmentvaluesareset.
Theotheradjustmentsandparameterswill notbemodified.Stepstofollow:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
0 Selectthesystemadjustments SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
0 Selectthememoryreset ENTER=MEMORY RESET
OTHER KEY=CANCEL
ENTER Startsthememoryreset.
RESETTING THE
MEMORY
Once theresetisfinished,theprogramgoesbacktooption0ofthe
systemadjustmentssub-menu.
SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
Thememoryresethastobemadeinthefollowingcases:
·Whenyoureplace amotherboard.
·Eachtimethatyouloadthesoftwareinthemotherboard.
0.1-Systeminformation.
Option1of thesystemsub-menu,printsaticketwiththegeneralstatusof theunit.Stepstofollow:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
0 Selectthesystemadjustments SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
1 Selecttheprinting of thesystemreport.Theprinterstartsthe
printingof theticket.
PRINTING THE
REPORT
Once thereportisprinted,theprogram goesbacktooption1of the
systemadjustmentssub-menu.
SUB-MENU SYSTEM:
0.1-SYSTEM REPORT
SPACE=NEXT
ENTER=SELECT

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page6of43
0.2-Adjustmentoftheflags
Theflagsallow, accordingtotheirprogramming,themodificationof theoperationof theunit
.
Flagnº1
0 Doesnotprintthefooterinthefulloperation.
1 Printsthefooterinthefulloperation.
Doesnotprintthefooterinthepartialoperation.
2 Doesnotprintthefooterinthefulloperation.
3 Printsthefooterinthefulloperation.
Printsthefooterinthepartialoperation.
Flagnº2
1a3 Valuewhichindicatesthenumberof collectionticketstobeprinted.
Flagnº3
0 Smartcarddisabled
1 Smartcardenabled
Doesnotlistcardsnotbelongingto
thepharmacy.
2 Smartcarddisabled
3 Smartcardenabled
Listscardseveniftheydon’t
belongtothepharmacy.
Doesnotprinttheuseswithsmart
cardinthecollectionreport.
4 Smartcarddisabled
5 Smartcardenabled
Doesnotlistcardsnotbelongingto
thepharmacy.
6 Smartcarddisabled
7 Smartcardenabled
Listscardseveniftheydon’t
belongtothepharmacy.
Printstheuseswithsmartcard in
thecollectionreport.
Flagnº4
0 Formatof thedate=DD/MM/YY (Day/Month/Year)
1 Formatof thedate=MM/DD/YY (Month/Day/Year)
2 Formatof thedate=YY/MM/DD (Year/Day/Month)
Flagnº5
0 Formatof thetime=Hours(0to24):Minutes
1 Formatof thetime=Hours(0to12) :Minutes:AM/PM
Flagnº6
0 Doesnotusethepromotionalvoice messages.
1a3 Indicatesthenumberof availablepromotionalvoice messages.
Flagnº7
0 Doesnotusethepromotionalvoice messages.
1a99 Timebetweenonepromotionalvoice messageand thenextone.
Flagnº8
YX X=Valuefrom0to3indicatingthenumberof logotobeprintedontheticket header.
IfX=0,Nologowill beprintedintheticketheader.
YX Y=Valuefrom0to3indicatingthenumberof logotobeprintedontheticket footer.
IfY=0,Nologowill beprintedintheticketfooter.
Flagnº9
0 Allowstheuseof thedisplayduringtheheightmeasurement.
1 Thedisplaycannotbeusedduringtheheightmeasurement. Showstheweightonthedisplay.
2 Allowstheuseof thedisplayduringtheheightmeasurement.
3 Thedisplaycannotbeusedduringtheheightmeasurement. Doesnotshowtheweightonthedisplay.

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page7of43
Flagnº10
0 Doesnotprintthenumberof ticket
1 Printsthenumberof ticket Doesnotprinttheprice paidontheticket
2 Doesnotprintthenumberof ticket
3 Printsthenumberof ticket Printstheprice paidontheticket
Doesnotcounttheuseswhen
theunitsissettofree use.
4 Doesnotprintthenumberof ticket
5 Printsthenumberof ticket Doesnotprinttheprice paidontheticket
6 Doesnotprintthenumberof ticket
7 Printsthenumberof ticket Printstheprice paidontheticket
Countstheuseswhentheunits
issettofree use.
Flagnº11
0 Coinlampdisabled
1 Coinlampenabled
2 Coinlampdisabled
3 Coinlampenabled
Duringthepaymentprocess, asksifyou
wishtomeasurethebloodpressure
4 Coinlampdisabled
5 Coinlampenabled
6 Coinlampdisabled
7 Coinlampenabled
Duringthepaymentprocess, asksifyou
wishtomeasurethebloodpressure
Duringthebloodpressuretheunit
warnsthatthemeasuringprocess in
inprogress.
Flagnº12
0 Alwaysmeasuresthebodyfat
1 Bodyfat onlyinfull operation
Theusermustconfirmthesexon
thebodyfat measurement
2 Alwaysmeasuresthebodyfat
3 Bodyfat onlyinfull operation
Nosexconfirmationonthebodyfat
measurement
Printsthegraphicof theheartrate
analysishorizontally
4 Alwaysmeasuresthebodyfat
5 Bodyfat onlyinfull operation
Theusermustconfirmthesexon
thebodyfat measurement
6 Alwaysmeasuresthebodyfat
7 Bodyfat onlyinfull operation
Nosexconfirmationonthebodyfat
measurement
Printsthegraphicof theheartrate
analysisvertically
Flagnº13
0 Pricescanbeprogrammed
1 Pricescannotbeprogrammed
Itisnotpossibletoprogramprice 0
withthefrontbuttons
2 Pricescanbeprogrammed
3 Pricescannotbeprogrammed
Itispossibletoprogram price 0
withthefrontbuttons
Collectionthroughthefrontbuttons
enabled
4 Pricescanbeprogrammed
5 Pricescannotbeprogrammed
Itisnotpossibletoprogramprice 0
withthefrontbuttons
6 Pricescanbeprogrammed
7 Pricescannotbeprogrammed
Itispossibletoprogram price 0
withthefrontbuttons
Collectionthroughthefrontbuttons
disabled
Flagnº14
0 Ideal data forweightenabled
1 Ideal data forweightdisabled
Ideal data forbloodpressure
enabled
2 Ideal data forweightenabled
3 Ideal data forweightdisabled
Ideal data forbloodpressure
disabled
Ideal data forbodyfat enabled
4 Ideal data forweightenabled
5 Ideal data forweightdisabled
Ideal data forbloodpressure
enabled
6 Ideal data forweightenabled
7 Ideal data forweightdisabled
Ideal data forbloodpressure
disabled
Ideal data forbodyfat disabled

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page8of43
Flagnº15
0
Once theminimumamountforuse
isreached,theunitdoesnotaskto
insertmorecoins.
1
Eveniftheminimumamountfor
usehasbeenreached,theunitasks
once more“Insertanothercoin”.
2
Once theminimumamountis
reached,theunitdoesnotaskto
insertmorecoins.
3
Eveniftheminimumamountfor
usehasbeenreached,theunitasks
once more“Insertanothercoin”.
In caseof nonfatalerrorduringthe
autotest,youdon’thavetopress the
greenkey.
4
Once theminimumamountis
reached,theunitdoesnotaskto
insertmorecoins.
5
Eveniftheminimumamountfor
usehasbeenreached,theunitasks
once more“Insertanothercoin”.
6
Once theminimumamountis
reached,theunitdoesnotaskto
insertmorecoins.
7
Eveniftheminimumamountfor
usehasbeenreached,theunitasks
once more“Insertanothercoin”.
In caseof nonfatalerrorduringthe
autotest,youdon’thavetopress the
greenkey.
In casoof FATALERRORduring
theautotest,theunitwillre-start
automatically.
Flagnº16
0
1
Repeatsthemessage“Relax,don’t
talk.Ifyouwish...”rightafterthe
cuffhasbeeninflated.
2
3
Repeatsthemessage“Relax,don’t
talk.Ifyouwish...”rightafterthe
cuffhasbeeninflated.
Blockstheunit
4
5
Repeatsthemessage“Relax,don’t
talk.Ifyouwish...”rightafterthe
cuffhasbeeninflated.
6
7
Repeatsthemessage“Relax,don’t
talk.Ifyouwish...”rightafterthe
cuffhasbeeninflated.
Blockstheunit
Onlyforversions withGSM.
SendsanSMSwiththecollections
whenamanualcollectionismade
ontheunit.

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page9of43
Flagnº17
0 Themeasureof thebodyfat iscancellediftheuser
stepsofftheplatformwithoutindicating thesex.
1
Waitsfortheusertoindicatethesexafterthefat
measure(doesnotabortthecalculationwhen
steppingoff theplatformwithoutindicatingthesex).
OnlyforArabicversions
Special voice messageat
thebeginningof measuring
cycledisabled.
2 Themeasureof thebodyfat iscancellediftheuser
stepsofftheplatformwithoutindicating thesex.
3
Waitsfortheusertoindicatethesexafterthefat
measure(doesnotabortthecalculationwhen
steppingoff theplatformwithoutindicatingthesex).
OnlyforArabicversions
Special voice messageat
thebeginningof measuring
cycleenabled.
OlddisplayboardP1DS-A
(Motorola 68HC705J1A).
4 Themeasureof thebodyfat iscancellediftheuser
stepsofftheplatformwithoutindicating thesex.
5
Waitsfortheusertoindicatethesexafterthefat
measure(doesnotabortthecalculationwhen
steppingoff theplatformwithoutindicatingthesex).
OnlyforArabicversions
Special voice messageat
thebeginningof measuring
cycledisabled.
6 Themeasureof thebodyfat iscancellediftheuser
stepsofftheplatformwithoutindicating thesex.
7
Waitsfortheusertoindicatethesexafterthefat
measure(doesnotabortthecalculationwhen
steppingoff theplatformwithoutindicatingthesex).
OnlyforArabicversions
Special voice messageat
thebeginningof measuring
cycleenabled.
NewdisplayboardP1DS-B
(RenesasR8C).
Flagnº18
0 Reserved. Donotmodify
Flagnº19
0 Weightforfree disabled
1 Weightforfree enabled.Itdisplaystheweightup to2kg
2 Weightforfree disabled
3 Weightforfree enabled.Itdisplaysanyweightplacedontheplatformweight
Flagnº20
0 Showstheweightinkg onthedisplay
1 Showstheweightinlbonthedisplay Showstheheightincmonthedisplay
2 Showstheweightinkg onthedisplay
3 Showstheweightinlbonthedisplay Showstheheightinft&inchesonthedisplay.
Flagnº21
0 Printweightinkg
1 Printweightinimperialformatandkg Printheightincm
2 Printweightinkg
3 Printweightinimperialformatandkg
Printheightinimperial
formatandcm
Americanimperialformat(for
weight)
4 Printweightinkg
5 Printweightinimperialformatandkg Printheightincm
6 Printweightinkg
7 Printweightinimperialformatandkg
Printheightinimperial
formatandcm
Englishimperialformat
Atention:smartcardrepports
will beprintedin lb only.

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page10 of43
Exampleofprogramming:
Supposethat youwanttoconfiguretheunitsothatitprints2collectionticketswhenyoumakethecollectionreport. For
thispurposemyoumustmodifythestatusof flagnr. 2.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
0 Selectthesystemadjustments SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
2 Selecttheadjustmentof theflags. Thedisplayshowtheuccrent
valueof thefirstflag
INDICATE THE VALUE OF
FLAG 1: 3
AND PRESS ENTER
ENTER Press ENTERuntilyougettheflagnumberthatyouwishtomodify
(inthisexamplewewishtomodifyflagnumber2)
INDICATE THE VALUE OF
FLAG 2: 1
AND PRESS ENTER
2 Setflagnr.2to2. INDICATE THE VALUE OF
FLAG 2: 2
AND PRESS ENTER
ENTER Nowthedisplayshowthevalueof thefollowingflag(inthiscase
flagnr. 2,whichhasbeenset to1)
INDICATE THE VALUE OF
FLAG 3: 1
AND PRESS ENTER
ENTER Press ENTERuntilyougetthemessage"WAITAMOMENT...".
Theunitissaving thenewadjustmentof theflagsintothememory.
ONE MOMENT...
Once theflagshavebeensaved,theprogramgoesbacktooption2
ofthesystemadjustmentssub-menu.
SUB-MENU SYSTEM:
0.2-FLAGS
SPACE=NEXT
ENTER=SELECT

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page11 of43
0.3-Programmingoftheprices andcoins
Thisoptiónallowsthechangementof thedefaultpricesofusesetinthesoftwareof theunit,aswell asthevalueof each
coinslot.Firstof all, youmustprogram thepricesof useandafteryouindicatethevalueforeachoneof theslotsinstalled
intheunit. Whenyouchangethepricesof use,remembertochangealsothestickersabovethecoinentrieswhichindicate
theprice topay.
Importantnote:
Toactivatetheuseof theunit,youcanuseanyof thecoinsaccceptedbythecoinsalots.Forexample, youcanprogramthe
fuloperationat1,20€(supposingthattheslotspresentintheunitareof 1€ and0,2€). Inthiscase,theusermustinserta
coinof eachtype, orsixcoinsof 0,2€, untilcompletingtheamountforthefulloperation.
In thefollowingexample,theunitisset to1€forthefull operation,0,40€forthepartialoperation,andtheslotspresentin
theunitareof 1€forslot1and 0,20€forslot2:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
0 Selectthesystemadjustments SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
3 Selecttheprogramming of theprice. Thedisplayshowstheprice for
thefull operationcurrentlyprogrammed.Thisprice iscorrectinour
example,soyoupress “ENTER”togotothenextscreen.
INDICATE PRICE 1 IN
EUROS
AND PRESS ENTER: 01,00
ENTER Thedisplayshowsnowtheprice forthepartialoperationcurrently
programmed.
INDICATE PRICE 2 IN
EUROS
AND PRESS ENTER: 00,20
0040 Program0,40€. INDICATE PRICE 2 IN
EUROS
AND PRESS ENTER: 00,40
ENTER Nowtheunitasksthevalueforthecoinof slot1(slotontheright
handside,firstchannel forcoins)
INDICATE THE VALUE OF
CHANEL 1 IN EUROS
AND PRESS ENTER: 1,00
ENTER WhenpressingENTER,thescreenshowsthevalueforthecoinof
slot2(slotonthelefthanside, secondchanel forcoins).
INDICATE THE VALUE OF
CHANEL 2 IN EUROS
AND PRESS ENTER: 0,10
020 Indicatethatchanel2forcoinsisof 0,2€ INDICATE THE VALUE OF
CHANEL 2 IN EUROS
AND PRESS ENTER: 0,20
ENTER WhenpressingENTER,thescreenshowsthevalueforthecoinof
slot3(third chanel forcoins).Iftheunithasgotanelectronic coin
validator,repeattheprocess depictedabovetoindicatethevalueof
eachchanelforcoins.Ifnot, press “ENTER”untilquit theoptionof
price andcoinsprogramming.
INDICATE THE VALUE OF
CHANEL 3 IN EUROS
AND PRESS ENTER: 0,00
ENTER ...
ENTER Once theprocessisfinished,theprogramgoesbacktooption3of
thesystemadjustmentssub-menu.
SUB-MENU SYSTEM:
0.3-PRICES
SPACE=NEXT
ENTER=SELECT

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page12 of43
0.4-Collection
Thisoptionallowstheprintingof acollectionticket.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
0 Selectthesystemadjustments SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
4 Option4printsacollectionreport
PRESS ENTER TO CONFIRM OR
ANY OTHER KEY TO CANCEL
ENTER WhenpressingENTERtheprinterstarts
PRESS ENTER TO CONFIRM OR
ANY OTHER KEY TO CANCEL
Once thereportisprinted,theprogram goesbacktooption4of the
systemadjustmentssub-menu.
SUBMENU SISTEMA:
0.4-RECAUDACION
SPACE=SIGUIENTE
ENTER=SELECCIONAR
COLLECTION REPORT
10/06/04,Thursday.......12:34:00
Motherboard number...........123
Report number...............3452
Last ticket.................1438
Uses of the periode:
-Weight and height...........10
-Weight, height & B. press....5
Value in €uros..............9,0
Contabilized €uros..........9,4
════════════════════════════════
Cummulated:
- Weight and height..........15
- Weight, height & B. press..10
Value in €uros.............16,0
Contabilized €uros.........16,4
════════════════════════════════
Example of a collection ticket of a
unit programmed to 0,4€ for the
partial operation and to 1,0
€ for the
full operation.
←Indicates the number of partial op.
←Indicates the number of full oper.
←See comment *1
←See comment *2
←The same as above, but contabilized
from the day when the unit was
installed. These cummulated are not
cleared when making a collection
report.
1- Valuecalculatedaccording tothenumberof usesandtheproce programmedforeachuse:
10 usesx0,4€/use+5usesx1,0€/use=9,0€
2- Dependingonthecombinationof coinsandprices,andbecausetheunitdoesnotgivechange,itmayhappenthatthe
userinsertamountshighertotheindicatedones, butthatdonotreachthevalueof morethanoneuse.Inthesecasesthere
isadiscrepancybetweenthecalculatedamountfortheusesandtherealnumberof coinsdetected.Therefore, the
“Contabilized”indicatesthemoneythattheunithasvalidated.Thisamounthastobeequal orhighertothe“Valuein
Euros”amount.

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page13 of43
0.5-Maintenance
Withthisoptiontheunitmakesacompletemeasuringcyclethatallowstheverificationof themeasuring systems.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
Place astandardweightontheplatform,raisethebabyscaleand
connectareference resistor(forexample470 ohms)inthebodyfat
measuringcontacts.
0 Selectthesystemadjustments SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
5 Option5startsthemaintenance process. Theunitsmakesa
measureof weight,ameasureof height(willmeasuretheheightof
thebabyscalecraddle), willinflateanddeflatethepneumatic
systemandwillmeasuretheimpedance.
ONE MOMENT ...
Attheendof theprocess, theunitprintsareportandtheprogram
goesbacktothesystemadjustmentssub-menu
SUB-MENU SYSTEM:
0.5-MAINTENANCE
SPACE=NEXT
ENTER=SELECT
0.6 -Coinselectortest
Thisoptionallowsthecorrectdetectionandoperationof thecoinselectorwithoutalteringthecontensof thecollection
report.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
0 Selectthesystemadjustments SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
6 Selectoption6=coinselectortest. Thedisplayshowsthenumber
ofcoinsof eachtypedetectedduring thetest.
INSERT COINS...
Insert
coins...
As longasthecoinsareinserted(andifthecoinselectoroperates
correctly)thecounterinthedisplayreflectsthenumberof detected
coins.
INSERT COINS...
ENTER WhenpressingENTERthetestendsand theprogramgoesbackto
option6of systemadjustmentssub-menu.
SUB-MENU SYSTEM:
0.6-COIN SEL. TEST
SPACE=NEXT
ENTER=SELECT
0.7 -Displaytest
Thisoptionallowstheverificationof thecorrectooperationofthedisplays.
Proceedasfollows:

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page14 of43
Key Functiontoexecuteorselect TerminalDisplay
'Z' o'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
0 Selectthesystemadjustments SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
7 Selectoption7=displaytest. SUB-MENU SYSTEM:
0.7- DISPLAY TEST
SPACE=NEXT
ENTER=SELECT
SPACE As longasyoupress SPACEthedisplayswill litandyoucan
verifythatallsegmentswork.
SUB-MENU SYSTEM:
0.7- DISPLAY TEST
SPACE=NEXT
ENTER=SELECT
0,1,2,3,4...Ifyoupress thenumerickeys, thelampsnexttothedisplayswill
beswitchedon/off.
SUB-MENU SYSTEM:
0.7- DISPLAY TEST
SPACE=NEXT
ENTER=SELECT
'Z' o'ESC'Press ESCtoendthetest.Theprogramgoesbacktooption7of
systemadjustmentssub-menu.
SUB-MENU SYSTEM:
0.7- DISPLAY TEST
SPACE=NEXT
ENTER=SELECT
0.8 -Serialnumber
Thisoptionisnotaccessible.
0.9-Clearthecounters
Thecollectionreporthasgottwocounters:oneissettozeroeverytimethatareportisprinted,buttheotherone,the
cumulated,keepsthetotalnumberof coins.Theonlywaytosettozerobothcountersisusingthisoption.Toaccess tothis
functinitisnecessaytohaveasmartcardwiththecorrectaccess passwords.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
0 Selectthesystemadjustments SUB-MENU SYSTEM:
0.0-MEMORY RESET
SPACE=NEXT
ENTER=SELECT
9 Option9erasesthecumulatedvalues.Toaccess tothisfunction
youneedasmartcardwiththeaccess codes.
INSERT THE CARD
Insertthe
smart
card
Wheninsertingthesmartcard,thedisplaywill showthefollowing
message:
ENTER......:CLEAR
OTHER KEY.:CANCEL
ENTER WhenpressingENTER,thecumulatedcounterswillbecleared
andthereportnumbercounterwillbesettozero.
ENTER......:CLEAR
OTHER KEY.:CANCEL
Whenfinished,theprogramgoesbacktooption9of system
adjustmentssub-menu.
SUB-MENU SYSTEM:
0.9-CLEAR COUNTERS
SPACE=NEXT
ENTER=SELECT

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page15 of43
1-Adjustments oftheheightsystem. Option1ofthemainmenu.
Themeasurementof heightisbasedonasystemofcalculationof distance bymeansof ultrasounds.Themaincomponents
ofthesystemaretheacoustictransducer(locatedatthetopof theunit)andtheelectronicmeasurementcircuit,whichis
controlledbytheMainBoardP1PC.Thischapterdepictstheproceduretoadjusttheheightsystem.
1.0-Resetoftheheightsystem
Duringtheautotestprocess,theunitmakesanauto-zerooftheheightsystem.Withthisoptionof themenu,thisprocess
canbemadewithouthavingtoswitchtheunitoff andonagain.
Whenmakinganauto-zeroof theheightsystem, theunitunderstandsthatthereisnothingontheplatform.Thevalueof the
measuredsignalatthismomentistakenasthezerovalue(0cm)of theheightsystem. Thisiswhyit isso importantto
checkthatthereisnothingontheplatformbeforedoingthisprocess.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
1 Selecttheheightsystemadjustments SUB-MENU HEIGHT:
1.0-RESET
SPACE=NEXT
ENTER=SELECT
0 Option0resets(autozero)theheightsystem.
WAIT A MOMENT...
Whenitisfinishedtheprogramgoesbacktooption0of theheight
adjustmentsub-menu.
SUB-MENU HEIGHT:
1.0-RESET
SPACE=NEXT
ENTER=SELECT
1.1 -Continuousheightnormal measurement
Thisactionallowsyoutomakedifferentmeasurementsof heightwiththenormalfrequencyofmeasurement,andshow
theminthedisplay. Thisisthewaythatthesystemmeasurestheheightduringnormaloperation.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
1 Selecttheheightsystemadjustments SUB-MENU HEIGHT:
1.0-RESET
SPACE=NEXT
ENTER=SELECT
1 Theunitmeasurestheheightcontinuouslyand showsresultonthe
display. Ignoretheotherdata showninthedisplay.
Hei.: 0cm Amx:208cm.
Zero: 24278 Cnt:24274
NumP: 1000 Blk:21200
Tout: 32767 CodErr: 0
ENTER Whenpressinganykey(ENTERforexample)theprocess ends
andtheprogram goesbacktooption1of theheightsystemsub-
menu.
SUB-MENU HEIGHT:
1.1- NORMAL MEASURE
SPACE=NEXT
ENTER=SELECT

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page16 of43
1.2-Continuousheightquickmeasurement
Thisactionallowsyoutomakedifferentmeasurementsof heightwiththequickfrequencyofmeasurement, andshowthem
inthedisplay. Italsoallowsyoutomovetheobjectandverifydifferentheights.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
1 Selecttheheightsystemadjustments SUB-MENU HEIGHT:
1.0-RESET
SPACE=NEXT
ENTER=SELECT
2 Theunitmeasurestheheightcontinuouslyand showstheresulton
thedisplays. Ignoretheotherdatashowninthedisplay.
Hei.: 0cm Amx:208cm.
Zero: 24278 Cnt:24274
NumP: 1000 Blk:21200
Tout: 32767 CodErr: 0
ENTER Whenpressinganykey(ENTERforexample)theprocess ends
andtheprogram goesbacktooption2of theheightsystemsub-
menu.
SUB-MENU HEIGHT:
1.2- QUICK MEASURE
SPACE=NEXT
ENTER=SELECT
1.3 -Indicationoftheinnerheightoftheunit
Theaverageinnerheightof theunit(distance fromtheheightsensortotheplatform)isof 210cm.Duetothemouldingof
thebody, thisvaluecanvary, anditissetwhentheunitismanufactured,sothatitwill beautomaticallystoredinthe
memorywhenmakingamemoryreset.Thisadjustmentwillonlybenecessaryifforanyreasontheinnerheightof theunit
needstobechanged.
Duringtheautotestprocess,theunit makesanautozeroof theheightsystem.Theautozeroandheightmeasuringsystems
arebasedonaknowndistance whichistheinnerheightof theunit.Therefore,ifthisdistance isdifferentfromthevalue
storedinthememory,therewill beaconstantcalculationerrorwhichwillleadtoawrongresultof themeasurement.The
talleristheuser,thegreaterthiserrorwillbe.
Let'ssupposethat wehavemeasuredaninnerheightof 210cmonaunitsetto208 cm.Herearethestepstofollowto
indicateanewinnerheight:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
1 Selecttheheightsystemadjustments SUB-MENU HEIGHT:
1.0-RESET
SPACE=NEXT
ENTER=SELECT
3 Option3allowsthemodificationof theinnerheightof theunit.
Thedisplayshowstheheight(incm)thatiscurrentlysetinthe
memory. Nowyoucanindicatethenewheight.
INDICATE THE INNER HEIGHT
AND PRESS THE ENTER KEY:
208
210 Indicatethenewinnerheightwiththenumerickeys(210 inthis
case)
INDICATE THE INNER HEIGHT
AND PRESS THE ENTER KEY:
210
ENTER WhenpressingENTERthenewvalueissavedandtheprogram
goesbacktooption3of theheightadjustmentsub-menu.
SUB-MENU HEIGHT:
1.3-MACHINE HEIGHT
SPACE=NEXT
ENTER=SELECT

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page17 of43
1.4-Frequencyadjustment
Withthisoptiontheoperatingfrequencyoftheheightsystem canbechangedtoimprovethemeasuring system.Once in
thisoption,youcanchangethefrequencywiththekeys Aand Fof theterminal. Pressing Athefrequencywill beincreased
andpressing Fwillbedecreased.Thedefaultfrequencyis50,00kHz.
Importantnotes:
·Thisadjustmentcan onlybe done withthe consent of Keito’stechnicalDepartment.
·Thisadjustmentmustbe done withthe helpof an oscilloscope sothat you can see howthe qualityofthe
systemsignalchangesaslong asthe frequency ismodified.
Letussupposethatwewanttosetthefrequencyto52,29kHz.:Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
1 Selecttheheightsystemadjustments SUB-MENU HEIGHT:
1.0-RESET
SPACE=NEXT
ENTER=SELECT
4 Option4allowsthemodificationof thefrequencyofthesystem. FREQUENCY: 50,00 kHz
DIVISOR: 160
COUNTER: 0
Cod.Err..: 3
A...A...A WiththekeyAoftheterminal,increasethefrequencyuntilyou
getthedesiredone.As longasthefrequencyisincreased,the
divisorcounterwill decrease.
FREQUENCY: 50,31 kHz
DIVISOR: 159
COUNTER: 0
Cod.Err..: 3
ENTER WhenpressingENTERthenewvalueissavedandtheprogram
goesbacktooption4of theheightadjustmentsub-menu.
SUB-MENU HEIGHT:
1.4-FREQUENCY ADJUST
SPACE=NEXT
ENTER=SELECT

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page18 of43
2-Adjustments oftheweightsystem. Option2ofthemainmenu
Themeasuringof theweightismadethroughtheelectricalsignalssentbyaloadcell locatedundertheplatformof theunit.
Thesesignalsarethenconvertedand processedbytheMainBoardP1PC.
Thischapterdescribesthestepstofollowforacorrectadjustmentof thecomponentsassociatedtotheweightsystem.
2.0-Auto-zeroorreset oftheweightsystem.
Similarlytowhat happenstotheheightsystem, during theinitial autotesttheunit makesanauto-zeroof theweightsystem.
Withthisoptionof theAdvancedProgrammingMode,thisprocess canbemadewithouthavingtoswitchtheunit offand
onagain.
Whenmakinganauto-zerooftheweightsystem,theunit understandsthatthereisnothingontheplatform.Thevalueof
thesignal sentbytheloadcell at thismomentistakenasthezerovalue(0 kg) oftheweightsystem.Thisiswhyit isso
importanttocheckthatthereisnothingontheplatformbefore doingthisprocess.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
2 Selecttheweightsystemadjustments SUB-MENU WEIGHT:
2.0-RESET
SPACE=NEXT
ENTER=SELECT
0 Option0resets(autozero)theweightsystem.Thisprocess takes
about5secondsanditisveryimportanttoavoidthehitsorsudden
movementsorvibrationsneartheunitduringthisprocess.
WAIT A MOMENT...
Whentheprocess isfinished,theprogramgoesbacktooption 0of
theweightadjustmentssub-menu
SUB-MENU WEIGHT:
2.0-RESET
SPACE=NEXT
ENTER=SELECT
2.1 -Continuousweightmeasurement
Thisactionallowsyoutomakedifferentmeasurementsof weightandshowthem inthedisplay.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu. MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
2 Selecttheweightsystemadjustments SUB-MENU WEIGHT:
2.0-RESET
SPACE=NEXT
ENTER=SELECT
1 Theunitmeasurestheweightcontinuouslyandshowstheweight
ofthecurrentobject/persononboththeterminalanddisplays. On
theTerminalyoucansee 2counters:Theoneontheright
measuresinstepsof 10 g,andtheoneontheleftinstepsof 100 g,
inthesamewayastheunitdoesduring thenormalmeasuring
preocess. Therestsof countingsconcern theauto-zerosystem of
theunit.
WEIGHT kg WEIGHT kg
0,00 0,0
(0..1..zero track)
STABLE

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page19 of43
Place astandardweightandverifythecorrectmeasure
WEIGHT kg WEIGHT kg
5,00 5,00
(0..1..zero track)
STABLE
ENTER Whenpressinganykey(ENTERforexample)theprocess ends
andtheprogram goesbacktooption1of theweightsystemsub-
menu.
SUB-MENU WEIGHT:
2.1-MEASURE
SPACE=NEXT
ENTER=SELECT
2.2 -Calibrationoftheweightsystem.
Important Note:
Theweightadjustmentismadeautomaticallybytheunit,by meansof internal calculations.Toavoiderrorswhichwould
leadtoawrongcalibration,takethefollowingintoaccount:
·Itisimportantthattheunitiswell stabilized.
·Useweightsinperfectcondition.Ifit ispossible,usehomologatedorcertifiedweights.Acorrectcalibrationcanbe
ensuredonlyiftheweightsarecorrect.Donotusebottlesofwaterorotherobjectsthatyouthink that youknowtheir
exactweight.
·Whenplacingaweightontheplatform,makesurethatitlaysstable.
·Avoidvibrationsduringthecalibration(walkneartheunit,etc.)since theycancausewrongmeasurementstothe
system.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu.
Makesure thatthereisn'tanyobjectontheplatform.
MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
2 Selecttheweightsystemadjustments SUB-MENU WEIGHT:
2.0-RESET
SPACE=NEXT
ENTER=SELECT
2 Thezeroweightcalibrationstarts.Theunitmakesmeasurements
ofthezeroweight(countingthat thereisnothingonthe
platform) andshowsthecountingsintheterminaldisplay.
ZERO COUNTING: 3348
ENTER Whenpressinganykey(ENTERforexemple),theunitasksforthe
valueof thestandardweightforcalibration.
INDICATE THE CALIBRATION
WEIGHT AND PRESS
ENTER: 00,00
20 Indicatethecalibrationweightwiththenumerickeys(20 kg for
example).
INDICATE THE CALIBRATION
WEIGHT AND PRESS THE
ENTER KEY: 20,00
ENTER WhenpressingENTERtheprocess will start.Thedisplaywill read
'CALIBRATING’blinking.Thisprocess takesabout25 seconds.
CALIBRATING ...
Attheendof thecalibration,theprogramgoesbacktooption3of
theweightsub-menu.Theweightisalreadyadjustedandthe
calibrationvaluesaresavedinmemory.
SUB-MENU WEIGHT:
2.3-WEIGHT CALIBRATION
SPACE=NEXT
ENTER=SELECT

KeitoK7
Technicalandmaintenance
Manual
INT.022EN.02
Revision “I”
24/09/2010
Page20 of43
3-Pressureadjustments. Option3ofthemainmenu.
3.0-Measuringtheblood pressure.
Thisoptionletsyoumakeasmanybloodpressuremeasurementsasyouwish.
It isessentialtomeasuretheheight beforetheblood pressuremeasurement. Otherwise, the
readingsof the blood preSsurewill not be correct.
Proceedasfollows:
Key Functiontoexecuteorselect TerminalDisplay
'Z' or'ESC'Goestooption0of themainmenu.
MAIN MENU:
0-SYSTEM ADJUSTMENTS
SPACE=NEXT
ENTER=SELECT
3 Selectthebloodpressureadjustments. SUB-MENU PRESSURE :
3.0-BLOOD PRESSURE
SPACE=NEXT
ENTER=SELECT
0 Bloodpressuremeasurement.Theresultsappearonthedisplays. SUB-MENU PRESSURE :
3.0- BLOOD PRESSURE
SPACE=NEXT
ENTER=SELECT
Attheendof themeasurement,theprogramgoesbacktooption0
ofthebloodpressureadjustmentsub-menu.
SUB-MENU PRESSURE :
3.0- BLOOD PRESSURE
SPACE=NEXT
ENTER=SELECT
3.1 -Calibrationofthebloodpressure.
Thecalibrationismadeintwosteps:
·Theunitmeasuresthevalueof theatmosphericpressure.Inthismoment,youmustnotapplyanypressuretothe
sensor,and thevalveof therubberbulbmustbeopen.
·Apressureof 200 mmHgisappliedtothecolumnandtheunit measuresitsvalue.
ImportantNote:
Thepressureadjustmentismadeautomaticallybytheunit,bymeansof internalcalculations,basedontheindicateddata.
Toobtainacorrectcalibration,takethefollowingintoaccount:
·Useamercurialcolumnoramanometerdulycalibratedandcertified.
·Makesurethatbeforeinflatingthemercurialcolumnormanometer,theindicationof thescaleis0mmHg.
·Makesurethatthereisnoleakageinthetubing.Itisalsoimportant(duringthesecondstep,whenapplying
pressuretothesensor)thatthepressureisconstantandstableduring theprocess ofadjustment.
·Ifnecessary,add asupplementaryreservoirtothetubing sothat thecapacityoftheaircircuitisbiggerandthe
leakageisminimized.
Before, youmustconnect themanometer,withthevalveopen,tothepressuresensorsothatthevalveandthe
compressorareoutof thecircuit. Theresultingpneumaticsystemmustbecomposedofthepressuresensor,thecuff
(usedasreservoir)and themanometer.
