Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
0
Kelly KDZ Series / PM
Motor Controller User’s Manual
KDZ24200
KDZ48300
KDZ72200
KDZ72650E
KDZ24201
KDZ48301
KDZ72201
KDZ72651E
KDZ24300
KDZ48400
KDZ72300
KDZ72800E
KDZ24301
KDZ48401
KDZ72301
KDZ72801E
KDZ24400
KDZ48550
KDZ72400
KDZ12400
KDZ24401
KDZ48551
KDZ72401
KDZ12401
KDZ48200
KDZ48650E
KDZ72550
KDZ48201
KDZ48651E
KDZ72551
Rev.3.5
July, 2022

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
1
Contents
Chapter 1 Introduction.......................................................................................2
1.1 Overview..................................................................................................... 2
Chapter 2 Main Features and Specifications.....................................................3
2.1 General functions.................................................................................... 3
2.2 Features....................................................................................................... 4
2.3 Specifications.............................................................................................. 4
2.4 Naming Regulations ................................................................................... 5
Chapter 3 Wiring and Installation ........................................................................6
3.1 Mounting the Controller............................................................................. 6
3.2 Connections ................................................................................................ 9
3.2.1 Front Panel of KDZ Series or PM Motor Controller:....................... 9
3.2.2 Standard Wiring of KDZ/KDZ-E Series or PM Motor Controller. 12
3.2.3 Communication Port ....................................................................... 16
3.3 Installation Checklist................................................................................ 16
Chapter 4 Maintenance....................................................................................17
4.1 Cleaning.................................................................................................... 17
4.2 Configuration............................................................................................ 17
Table 1: LED CODES ........................................................................................18
Contact Us: .........................................................................................................19

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
2
Chapter 1 Introduction
1.1 Overview
This manual introduces the Kelly KDZ Series/PM Motor controllers’ features, their installation
and their maintenance. Read the manual carefully and thoroughly before using the controller. If
you have any questions, please contact the support center of Kelly Controls.
Kelly’s programmable motor controllers provide efficient, smooth and quiet controls for
electric vehicles like golf carts, go-carts, electric motorcycles, forklifts and hybrid vehicles, as well
as electric boats and industrial motor speed control. It uses high power MOSFET’s and, fast PWM
to achieve efficiencies of up to 99% in most cases. A powerful microprocessor brings in
comprehensive and precise control to the controllers. It also allows users to adjust parameters,
conduct tests, and obtain diagnostic information quickly and easily.

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
3
Chapter 2 Main Features and Specifications
2.1General functions
(1) Extended fault detection and protection. The LED flashing pattern indicates the fault sources.
(2) Monitoring battery voltage. It will stop driving if the battery voltage is too high and it will
progressively cut back motor drive power as battery voltage drops until it cuts out altogether at
the preset “Low Battery Voltage”setting.
(3) Built-in current loop and over current protection.
(4) Configurable motor temperature protection range.
(5) Current cutback at low temperature and high temperature to protect battery and controller. The
current begins to ramp down at 90ﹾＣ(controller case temperature), shutting down at 100ﹾＣ.
(6) The controller keeps monitoring battery recharging voltage during regenerative braking,
progressively cutting back current as battery voltage rises then cutting off regen altogether
when voltage goes too high.
(7) Maximum reverse speed is configurable to half of the maximum forward speed.
(8) Configurable and programmable with a host computer though RS232 or USB. Provide free
GUI which can run on Windows XP/2000, Windows 7 and Vista(recommend using Kelly
Standard USB To RS232 Converter).
(9) Provision of a +5 volt output to supply various kinds of sensors, including Hall effect type.
(10) Multifunctional and configurable 3 switch inputs: brake switch, reversing switch, throttle or
forward switch. Active low.
(11) 3 analog 0-5V inputs that default to throttle input, brake input and motor temperature input.
(12) Pulsed reverse alarm output.
(13) Maximum reverse power is configurable to half power.
(14) Configurable motor over-temperature detection and protection with the recommended
thermistor KTY84-130/150 or KTY83-122.
(15) Optional 12V output power which can only be applied for Switch signals or LED. Any heavy
load is inhibited.
Caution! Regeneration has braking effect but does not replace the function of a mechanical brake.
A mechanical brake is required to stop your vehicle. Regen IS NOT a safety feature! Controller
may stop regen, without warning, to protect itself or the battery(it won’t protect you!).

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
4
2.2 Features
•Intelligence with powerful microprocessor.
•Synchronous rectification, ultra low drop, and fast PWM to achieve very high efficiency.
•Voltage monitoring on voltage source 12V and 5V.
•Hardware over current protection.
•Hardware over voltage protection.
•Current limit and torque control.
•Low EMC.
•LED fault code.
•Battery protection: current cutback, warning and shutdown at configurable high and low
battery voltage.
•Rugged aluminum housing for maximum heat dissipation and harsh environment.
•Rugged high current terminals, and rugged aviation connectors for small signal.
•Thermal protection: current cut back, warning and shutdown at high temperature.
•Configurable Current-Mode or Voltage-Mode when Field Switch is enabled, to achieve higher
safety and reliability.
•Configurable high pedal protection: the controller will not work if high throttle is detected at power
on.
•Brake switch is used to start regen.
•0-5V or 0-5K brake signal is used to command regen current.
•Capable of detecting short-circuit fault in the main contactor at power on.
•Easy installation: 1-4V "HallActive" throttle, or 0-5K or 0-5V potentiometer(<100K) can work.
•Standard PC/Laptop computer is used to do programming. No special tools needed.
•User program provided. Easy to use. No cost to customers.
2.3 Specifications
•Frequency of Operation: 16.6kHz.
•Standby Battery Current: < 0.5mA.
•Controller power supply current, PWR, <150mA.
•Configurable battery voltage range, B+.
•Standard Throttle Input: 0-5K(2-wire resistive pot), 0-5V (3-wire resistive pot), 1-4V (hall active
throttle).
•Analog Brake and Throttle Input: 0-5V or 0-5K.
•Reverse Alarm, Main Contactor Coil Driver, Meter.
•Full Power Temperature Range: 0ﹾＣto 50ﹾＣ(controller case temperature).
•Operating Temperature Range: -30ﹾＣto 90ﹾＣ, 100ﹾＣshutdown (controller case temperature).
•Motor Current Limit, 1 minutes: 200A-800A, depending on the model.
•Motor Current Limit, continuous:80A-320A, depending on the model.

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
5
2.4 Naming Regulations

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
6
Kelly KDZ Brushed DC Series/PM Motor Controller
Model
Peak Current
1 minute (Amp)
Continuous
Current (Amp)
Nominal
Voltage (Volt)
Max Operating
Voltage(Volt)
Regen
KDZ24201
200
80
12-24
30
*
KDZ24301
300
120
12-24
30
*
KDZ24401
400
160
12-24
30
*
KDZ48201
200
80
24-48
60
*
KDZ48301
300
120
24-48
60
*
KDZ48401
400
160
24-48
60
*
KDZ48551
550
220
24-48
60
*
KDZ48651E
650
260
24-48
60
*
KDZ72201
200
80
24-72
86
*
KDZ72301
300
120
24-72
86
*
KDZ72401
400
160
24-72
86
*
KDZ72551
550
220
24-72
86
*
KDZ72651E
650
260
24-72
86
*
KDZ72801E
800
320
24-72
86
*
KDZ12401
400
160
24-120
136
*
Chapter 3 Wiring and Installation
3.1 Mounting the Controller
The controller can be oriented in any position which should be as clean and dry as possible,
and if necessary, shielded with a cover to protect it from water and contaminants.
To ensure full rated output power, the controller should be fastened to a clean, flat metal
surface with four screws. A thermal joint compound can be used to improve heat conduction from
the case to the mounting surface. The case outline and mounting holes’ dimensions are shown in
Figure 1 and 2.
Caution:
• RUNAWAYS —Some conditions could cause the vehicle to run out of control. Disconnect
the motor, or jack up the vehicle, and get the drive wheels off the ground before
attempting any work on the motor control circuitry.
• HIGH CURRENT ARCS —Electric vehicle batteries can supply very high power, and arcs
can occur if they are short circuit. Always turn off the battery circuit before working on the
motor control circuit. Wear safety glasses, and use properly insulated tools to prevent
short circuit.

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
7
Height: 62 millimeters
Figure 1: KDZ mounting holes’ dimensions (dimensions in millimeters)

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
8
Height: 62 millimeters
Figure 2: KDZ-E mounting holes’ dimensions (dimensions in millimeters)

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
9
3.2 Connections
3.2.1 Front Panel of KDZ Series or PM Motor Controller:
Three metal bars and two plugs (J1, J2) are provided for connecting to the battery, motor and
control signals in the front of the controller shown as Figure 3 and 4.
Figure 3: Front panel of KDZ motor controller
Figure 4: Front panel of KDZ-E motor controller

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
10
B+: battery positive and armature positive
B-: battery negative
M-: armature negative
J1 Pin Definition
1- 12V output, <40mA（Optional）
2- Kelly Current meter. <200mA
3- Main contactor driver. <2A
4- Alarm: To drive reverse beeper. <200mA
5- RTN: Signal return
6- Green LED: Running indication
7- RTN: Signal return
8- Reserved
Figure 5: The connecting 9- Reserved
diagram of J1 and J2 10-Reserved
11-Reserved
12-Reserved
13-RTN: Signal return, or power supply ground
14- Red LED: Fault code.
J2 Pin Definition
1- PWR: Controller power supply (input)
2- RTN: Signal return, or power supply ground
3- RTN: Signal return
4- 12V high-level brake and motor temperature input. Demand use KTY84-130 Silicon
temperature sensors.
5- Throttle analog input, 0-5V or 0-5K
6- Brake analog input, 0-5V or 0-5K
7- 5V: 5V supply output. <40mA
8- Forward switch input
9- Reversing switch input
10-Brake switch input
11-Throttle switch
12-Reserved
13-Reserved
14-RTN: Signal return
Notes: 1. All RTN pins are internally connected.
2. Kelly Ammeter positive connect to 5V power supply of controller, negative to J1-2.
3. Switch to ground is active. Open switch is inactive.

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
11
Caution:
•Do not apply power until you are certain the controller wiring is correct and has been
double checked. Wiring faults will damage the controller.
•Ensure that the B- wiring is securely and properly connected before applying power.
•The preferred connection of the system contactor or circuit breaker is in series with the B+
line.
•All contactors or circuit breakers in the B+ line must have precharge resistors across their
contacts. Lack of even one of these precharge resistors may severely damage the controller
at switch-on.

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
12
3.2.2 Standard Wiring of KDZ/KDZ-E Series or PM Motor Controller
Figure 6: KDZ/KDZ-E series motor controller standard wiring

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
13
Figure 7: KDZ/KDZ-E Series motor controller standard wiring without Reversing Contactor

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
14
Figure 8: KDZ/KDZ-E PM motor controller standard wiring

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
15
Figure 9: KDZ/KDZ-E PM motor controller standard wiring without Reversing Contactor

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
16
3.2.3 Communication Port
A RS232 port of controller is provided to communicate with host computer for calibration and configuration.
Figure 10: standard RS232 interface
3.3 Installation Checklist
Before operating the vehicle, complete the following checkout procedures. Use LED code as
a reference as listed in Table 1.
Caution:
•Put the vehicle up on blocks to get the drive wheels off the ground before beginning these
tests.
•Do not allow anyone to stand directly in front of or behind the vehicle during the checkout.
•Make sure the PWR switch and the brake is off
•Use well-insulated tools.
•Make sure the wire is connected correctly.
•Turn the PWR switch on. The Green LED stay on steadily and Red LED turns off when the
controller operates normally. If this does not happen, check continuity of the PWR and
controller ground.
•The fault code will be detected automatically at restart.
•With the brake switch open, select a direction and operate the throttle. The motor should spin
in the selected direction. Verify wiring or voltage and the fuse if it does not. The motor should
run faster with increasing throttle. If not, refer to the Table 1 LED code, and correct the fault as
determined by the fault code.
•Take the vehicle off the blocks and drive it in a clear area. It should have smooth acceleration
and good top speed.

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
17
Chapter 4 Maintenance
There are no user-serviceable parts inside the controllers. Do not attempt to open the
controller as this will void your warranty. However, periodic, exterior cleaning of the controller
should be carried out.
The controller is a high powered device. When working with any battery powered vehicle,
proper safety precautions should be taken that include, but are not limited to, proper training,
wearing eye protection, avoidance of loose clothing, hair and jewelry. Always use insulated tools.
4.1 Cleaning
Although the controller requires virtually no maintenance after properly installation, the
following minor maintenance is recommended in certain applications.
•Remove power by disconnecting the battery, starting with battery positive.
•Discharge the capacitors in the controller by connecting a load (such as a contactor coil or a
horn) across the controller’s B+ and B- terminals.
•Remove any dirt or corrosion from the bus bar area. The controller should be wiped down with
a moist rag. Make sure it is dry before reconnecting the battery.
•Make sure the connections to the bus bars, if fitted, are tight. To avoid physically stressing the
bus bars use two, well-insulated wrenches.
4.2 Configuration
You can configure the controller with a host computer through either an RS232 USB port.
•Disconnect motor wiring from controller.
•Do not connect B+, throttle and so on. The controller may display fault code in some
conditions, but it doesn't affect programming or configuration.
•Use a straight through RS232 cable or USB Converter provided by Kelly to connect to a host
computer.
•Provide >+18V to PWR (either J2 pin1). Wire power supply return to any RTN pin.
Download the free configuration software from：
http://www.kellycontroller.com/support.php
Caution:
•Make certain that the motor is disconnected before trying to run the Configuration
Software!
•Configuration software will be regularly updated and published on the website. Please
Update your Configuration Software regularly. You must uninstall the older version
before updating.

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
18
Table 1: LED CODES
LED Code
Explanation
Solution
Green
Off
No power or
switched off
1. Check if all wires are correct.
2. Check fuse and power supply.
Green
On
Normal operation
That’s great! You got solution!
1,2
¤¤¤
Over voltage error
1. Battery voltage is too high for the controller.
Check battery volts and configuration.
2. Regeneration over-voltage. Controller will have
cut back or stopped regen.
3. This only accurate to ±2% upon Overvoltage
setting.
1,3
¤¤¤¤
Low voltage error
1. The controller will clear after 5 seconds if battery
volts returns to normal.
2. Check battery volts & recharge if required.
1,4
¤¤¤¤¤
Over temperature
warning
1. Controller case temperature is above 90℃.
Current will be limited. Reduce controller
loading or switch Off until controller cools down.
2. Clean or improve heatsink or fan.
2,2
¤¤ ¤¤
Internal volts fault
1. Measure that B+ & PWR are correct when
measured to B- or RTN.
2. There may be excessive load on the +5V supply
caused by too low a value of Regen or throttle
potentiometers or incorrect wiring.
3. Controller is damaged. Contact Kelly about a
warranty repair.
2,3
¤¤ ¤¤¤
Over temperature
The controller temperature has exceeded 100℃.
The controller will be stopped but will restart when
temperature falls below 80℃.
2,4
¤¤ ¤¤¤¤
Throttle error at
power up
1. The throttle got effective signal at key-on. Cycle
throttle can remove the error. You may
reconfigure throttle effective range or foot switch
2. The acceleration throttle must be turned from
zero up to high when the brake is released.
Otherwise the controller will report this fault.
3,1
¤¤¤ ¤
Frequent reset
May be caused by over-voltage, bad motor
intermittent earthing problem, bad wiring, etc.
3,2
¤¤¤ ¤¤
Internal reset
May be caused by some transient fault condition like
a temporary over-current, momentarily high or low
battery voltage. This can happen during normal
operation.

Kelly KDZ Series/PM Motor Controller User’s Manual V 3.5
19
3,3
¤¤¤ ¤¤¤
Wrong connection
of throttle
Valid throttle signal is between 1V-4V. Fault report
because signal is less than 0.5V or greater than
4.5V.
3,4
¤¤¤ ¤¤¤¤
Non-zero throttle
on direction
change
Controller won’t allow a direction change unless the
throttle or speed is at zero. Fault clears when
throttle is released.
4,1
¤¤¤¤ ¤
Regen
over-voltage
Motor drive is disabled if an over-voltage is detected
during regen. The voltage threshold detection level
is set during configuration.
4,2
¤¤¤¤ ¤¤
Field error
1. Field did not reach the configured current.
2. Field circuit open. Please check field wiring.
4, 3
¤¤¤¤ ¤¤¤
Motor
over-temperature
Motor temperature has exceeded the configured
maximum. The controller will shut down until the
motor temperature cools down.
The Red LED flashes once at power on as a confidence check and then normally
stays Off. “1, 2”means the Red flashes once and after a second pause, flashes twice. The
time between two flashes is 0.5 second. The pause time between multiple flash code
groups is two seconds.
Contact Us:
Kelly Controls, LLC
Home Page:
http://www.kellycontroller.com
E-mail:
[e-mail]
Phone:
[phone] 5092
