Kelvinator KSV26CRE User manual

Inverter Room Air Conditioner
Installation Manual
KSV26CRE, KSV26HRE, KSV35CRE,
KSV35HRE, KSV53HRE, KSV62HRE,
KSV70CRE, KSV70HRE, KSV80HRE
Refrigerant R32

Congratulations and thank you for choosing our Inverter
air conditioner. We are sure you will find your new air
conditioner a pleasure to use. Before you use the air
conditioner, we recommend that you read through
the entire user manual, which provides the description
of the air conditioner and its functions.
To avoid the risks that are always present when you use an
electrical appliance, it is important that the air conditioner
is installed correctly and that you read the safety instructions
carefully to avoid misuse and hazards.
We recommend that you keep this instruction booklet
for future reference and pass it on to any future owners.
After unpacking the air conditioner please check it is not
damaged. If in doubt, do not use the air conditioner but
contact your local Electrolux Customer Care Centre.
Meanings of symbols used in this manual are shown below:
warning
This symbol indicates information concerning your
personal safety
caution
This symbol indicates information on how to avoid
damaging the appliance
tips and information
This symbol indicates tips and information about
use of the appliance
environmental tip
This symbol indicates tips and information about
economical and ecological use of the appliance
This symbol indicates never to do this
This symbol indicates always do this
Important safety instructions ........................................... 3
Notice for installation ....................................................... 3
Minimum floor areas ......................................................... 4
Components...................................................................... 4
Product description .......................................................... 5
Installation checklist.......................................................... 6
Installation site instructions.............................................. 7
Rooftop installation .......................................................... 8
Outdoor unit installation................................................... 9
Indoor unit installation.................................................... 10
Installation....................................................................... 20
Testing the air conditioner.............................................. 24
Post installation checks................................................... 25
Warranty.......................................................................... 27
Congratulations Contents
2 Contents Kelvinator Air Conditioning

Kelvinator Air Conditioning Important safety instructions 3
caution
1 The unit must only be installed by a qualified refrigeration
mechanic and electrical work carried out by a qualified
electrician according to local or government regulations
and in compliance with this manual.
2 Before installation, please contact a qualified air
conditioner installer. If the unit is not installed by a
qualified air conditioner installer, the malfunction may
not be solved due to faulty installation.
3 If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
4 The appliance must be positioned so that the plug
is accessible.
5 The temperature of the refrigerant circuit will be high,
please keep the interconnection cable away from the
copper tube.
6 This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
7 For appliances with type Y attachment, the instructions
shall contain the substance of the following. If the
supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
warning
Before obtaining access to terminals, all supply circuits
must be disconnected.
Please read this installation manual and the user manual
before installation and carefully store in a handy place for
later reference. Inside you will find many helpful hints on how
to install and test the air conditioner properly.
Electrical work must be installed by a licensed electrician.
Be sure to use the correct rating of the power plug and main
circuit for the model to be installed.
Incorrect installation due to ignoring this instruction will
cause harm or damage, and the seriousness is classified by
the use of the 'warning' and 'caution' symbols.
refrigerant warning
Warning Refrigerant R32, mildly flammable. This product
uses Refrigerant R32, Difluoromethane which is a mildly
flammable gas class 2.2, based on AS1677 and must be
handled by a Refrigeration Mechanic with an appropriate
Australian Refrigerant Gas handling license
caution
• The air conditioner is not intended for use by young
children or infirm persons without supervision.
• Young children should be supervised to ensure that
they do not play with the air conditioner.
• Contact an authorised installer for installation of this unit.
• Contact an authorised service technician for repair or
maintenance of this unit.
• If the power cord is to be replaced, replacement work
shall be performed by authorised personnel only.
• Installation work must be performed in accordance
with the national wiring Standards by authorised
personnel only.
environmental tip
Information on disposal for users
• Most of the packing materials are recyclable.
Please dispose of those materials through your local
recycling depot or by placing them in appropriate
collection containers.
• If you wish to discard this air conditioner, please contact
your local authorities and ask for the correct method
of disposal.
Important safety instructions Notice for installation

4 Installation instructions Kelvinator Air Conditioning
Minimum floor areas
Your air conditioner is designed to condition the air for a
certain range of room sizes, please ensure the selection of
your air conditioner complies with the Kelvinator selection
tool available from www.kelvinator.com.au
This product uses refrigerant R32. Certain levels of
refrigerant require minimum room sizes. Please ensure that
these minimum room sizes are adhered to for standard
installations (7.5m pipe length). If larger refrigerant charges
than standard are used then please consult AS60335.2.40 to
determine the safe minimum floor area for the installation.
Model no. Charge of R32 (g) Minimum floor area (m2)
KSV26HRE 710 n/a*
KSV26CRE 710 n/a*
KSV35HRE 970 n/a*
KSV35CRE 970 n/a*
KSV53HRE 950 n/a*
KSV62HRE 1400 1.87
KSV70HRE 1400 1.87
KSV70CRE 1300 1.61
KSV80HRE 1700 2.76
*no minimum floor area required for this product
Items required for installation
• Level gauge
• Screw driver
• Electric drill
• Hole core drill ( 55mm / 70mm)
• Flaring tool specically designed for R32 or
R410a refrigerant
• Specied torque wrenches
• Spanner (half union)
• A glass of water
• Hexagonal wrench (6mm)
• Gas-leak detector
• Vacuum pump
• Gauge manifold
• Users manual
• Thermometer
• Multimeter
• Pipe cutter
• Measuring tape
Number Description Quantity
1Indoor unit mounting plate 1 fan
2Clip anchor not supplied
3
Self-tapping screw ST4 x 25
- for KSV70CRE, KSV70HRE & KSV80HRE
- for all other models
10
5
4Remote control 1
5Remote control holder 1
6Screw for remote holder 2
7Battery (AAA 1.5V) 2
8Insulation material not supplied
9Connection piping assembly
(refer to page 5) varies by country
10 Insulation hose for refrigerant piping not supplied
11 Wall clamp not supplied
12 Drain hose not supplied
13 Connection power cable not supplied
14 Drain connector (heat pump
model only) 1
15 Drain plug (heat pump with capacity
of over 4500W) 3
16 Thermal insulating pipe for extending
drain hose 1
17 Flare nut (for suction pipe) 1
Note: Other parts necessary for installation besides those
mentioned above must be supplied by the customer/installer.
Components

Kelvinator Air Conditioning Installation drawing 5
Product description
Light
Turbo Healthy
Timer-On Temp
Timer-Off
Swing I feel Eco
Fan
Clock
Mode
2
3
Indoor unit
Outdoor unit
space to obstruction
air inlet side
space to the wall
space to the wall
space to the ceiling
space to the floor
air outlet side
15cm or more
200cm or more
15cm or more
250cm or more
15cm or more
space to the wall
air outlet side
30cm or more
50cm or more
space to the wall
50cm or more
20cm or more
150cm or more
1
8
9
10
11
12
13
14
15
16
17
7
6
5
4

6 Checklist Kelvinator Air Conditioning
Important
• If your appliance is damaged due to improper installation your warranty may be void.
• Proper installation requires the use of a licensed installer.
• You must keep full details of the installer including the license number and provide those details whenever you
request a service for your appliance.
Installation checklist
Question
Does the unit have adequate clearance from walls and ceiling in accordance to installation instructions?
Is the unit mounted to allow condensate to flow freely toward the outside?
Does outdoor section have adequate clearance in accordance to installation instructions?
Is the unit securely mounted?
Is the unit readily accessible without special equipment?
Has the appropriate size circuit and fuse/circuit breaker been fitted?
Has the unit been tested and confirmed to operate correctly?
Has the user of the air conditioner been shown how to use the air conditioner?
CUSTOMER: PLEASE RETAIN WITH YOUR PURCHASE DOCUMENTS IN A SAFE PLACE
Model Number__________________________________________________________________________________________________
Serial Number __________________________________________________________________________________________________
Installers name ____________________________________________Refrigerant handling license no._________________________
Installers address__________________________________________Phone________________________________________________
Installers signature_________________________________________ Date of installation ____________________________________

Kelvinator Air Conditioning Installation instructions 7
15 Note low temperature soldering alloys are not acceptable.
16 Minimum room space requirements as advised on the
rating plate must be complied with.
17 Reusable mechanical connectors may not be used within
indoors or within wall or ceiling cavities where a refrigerant
leak can gather.
18 All refrigerant tubing shall be protected or enclosed to
prevent damage.
Outdoor unit
1 Select a site where noise and outflow air emitted by unit will
not annoy neighbours.
2 Select a site where there is sufficient ventilation.
3 Select a site where there is no obstruction blocking the inlet
and outlet.
4 The site should be able to withstand the full weight and
vibration of the unit.
5 Select a dry place, but do not expose the unit to direct
sunlight or strong wind.
6 Make sure that the outdoor unit is installed in accordance
with the installation instructions, and is convenient for
maintenance and repair.
7 Select a place where it is out of reach of children and far
from animals or plants.
8 Select a place where the unit keeps the horizontal and
aligned position.
9 Select at a place that respects the minimum distances
around the outdoor unit as below:
more than 20cm
more than
50cm
more than
30cm
more than 1.5m
10 Note low temperature soldering alloys are not acceptable.
11 Reusable mechanical connectors may not be used within
indoors or within wall or ceiling cavities where a refrigerant
leak can gather.
Installation site instructions
A proper installation site is vital for correct and efficient
operation of the unit.
Avoid the following sites where:
• strong heat sources, vapour, flammable gas or volatile
liquids are emitted.
• high-frequency electro-magnetic waves are generated by
radio equipment, welders or medical equipment.
• salt-laden air prevails (such as close to coastal areas).
• the air is contaminated with industrial vapours and oils.
• the air contains sulphurous gas such as in hot
spring zones.
• corrosion or poor air quality exists.
Indoor unit
1 The air inlet and outlet should be kept clear of obstructions.
Ensure the air can be blown through the whole room.
2 Select a site where the condensing water can be easily
drained out, and where it is easily connected to the
outdoor unit.
3 Select a place where it is out of reach of children.
4 Select the place where the wall is strong enough to
withstand the full weight and vibration of the unit.
5 Be sure to leave enough space to allow access for routine
maintenance.
6 For optimum performance, the indoor unit should be
installed on the wall at a height of 2 metres or more above
the floor and at least 2.5 metres from the opposing wall.
7 Make sure that the indoor unit is installed in accordance with
installation dimension as below:
more than 15cm from
the ceiling
more than
15cm
more than
15cm
more than 2m from the floor
more than 2.5m from the
opposing wall
8 Select place about 1m or more away from a TV set or any
other electric appliance.
9 Select a place where the filter can be easily taken out.
10 Do not use the unit in the laundry or by swimming pool etc.
11 A minimum pipe run of 3 metres is required to minimise
vibration and noise.
12 Use a stud finder to locate studs to prevent unnecessary
damage to the wall.
13 Any variations in pipe length may require adjustment to
refrigerant charge.
14 Do not install near a doorway.

8 Installation instructions Kelvinator Air Conditioning
Rooftop installation
If the outdoor unit is installed on a roof structure, be sure to level
the unit.
Ensure the roof structure and anchoring method are adequate for
the unit location.
If the outdoor unit is installed on roof structures or external walls,
this may result in excessive noise and vibration, and may also be
classed as non-serviceable installation.
caution
• The outdoor unit is charged with the refrigerant for standard
pipe length of 7.5m.
• When the connecting pipe length is longer than the standard
length, additional refrigerant should be added into the unit
according to the above table through the service port on
3-way service valve on the outdoor unit.
• Please maintain the shortest distance (3 to 5 metres) and
shortest misalignment possible between the indoor and
outdoor units.
• The maximum allowance length and height is based
on reliability. Exceeding the maximum may cause poor
performance or malfunction.
• When the level difference between indoor and outdoor units
is greater than the maximum height of 10 metres, or when
the outdoor unit is installed above the indoor unit, an oil trap
should be installed every 5-7 metres.
Pipe Length Elevation and Additional Quantity of Gas
Model Number Suction Pipe Diameter Discharge Pipe
Diameter
Standard
Length (m)
Maximum
Length (m)
Maximum
Height (m)
Additional
Refrigerant (g/m)
KSV26HRE Ø6.35 mm (1/4”) Ø9.52 mm (3/8”) 7.5 15 10 16
KSV35HRE Ø6.35 mm (1/4”) Ø9.52 mm (3/8”) 7.5 20 10 16
KSV53HRE Ø6.35 mm (1/4”) Ø12.70 mm (1/2”) 7.5 25 10 16
KSV62HRE Ø6.35 mm (1/4”) Ø15.88mm (5/8”) 7.5 25 10 40
KSV70HRE Ø6.35 mm (1/4”) Ø15.88mm (5/8”) 7.5 25 10 40
KSV80HRE Ø6.35 mm (1/4”) Ø15.88mm (5/8”) 7.5 30 10 40
KSV26CRE Ø6.35 mm (1/4”) Ø9.52 mm (3/8”) 7.5 15 10 12
KSV35CRE Ø6.35 mm (1/4”) Ø9.52 mm (3/8”) 7.5 20 10 12
KSV70CRE Ø6.35 mm (1/4”) Ø15.88mm (5/8”) 7.5 15 10 12
maximum length
maximum length
oil trap
maximum height
maximum height
piping length under 7.5m
piping length 7.5m or more
A
A
B
B
indoor unit
indoor unit
outdoor unit
outdoor unit

Kelvinator Air Conditioning Installation instructions 9
Outdoor unit installation
Outdoor condensate drainage
• During heating operation, the condensate and
defrosting water should be drained out reliably through
the drain hose.
• The drain-water hole must be plugged. Whether to plug
other holes will be determined by the installer according
to actual conditions.
• Install the outdoor drain connector in the drain-water
hole on the chassis of the outdoor unit, and attach the
drain hose to the connector so that the waste water
formed in the outdoor unit can be drained out.
• In case of a drain hose, the unit must be installed on a
base more than 3cm in height.
Securing the outdoor unit
Anchor the outdoor unit by fixing the 4 holes existent in its
base with 4 bolts and nuts of φ10 mm tightly (not included).
Place the outdoor unit over a horizontal concrete or rigid
surface (never directly over grass or earth).
A
B
air inlet
air inlet
air outlet
Model
Outdoor unit
dimensions
W x D x H (mm)
Dimension A
(mm)
Dimension B
(mm)
KSV26HRE/CRE 776 x 320 x 540 510 286
KSV35HRE/CRE 842 x 320 x 596 540 286
KSV53HRE,
KSV62HRE,
KSV70CRE/HRE
KSV80HRE
955 x 396 x 700
560 364
caution
• If a suspended installation is needed, the installation
bracket must allow the fixation according to dimensions
on the figure above.
• The wall where the unit will be installed must be of solid
brick, concrete or provided with other reinforcement
ways to fix the bracket. The fixation of the bracket to the
wall and the bracket to the air conditioner must be firm,
steady and levelled.
drain-water hole
chassis
drain connector
hose of inner diameter 16mm
(not supplied)

10 Installation instructions Kelvinator Air Conditioning
Indoor unit installation
Installing the mounting plate
1 Fit the mounting plate horizontally on the wall with five or
more self-tapping screws (type ST4x25, item 3 on page 3).
2 Be sure that the mounting plate has been fixed firmly
enough to withstand about 60kg. The weight should be
evenly shared by every screw.
3 If the wall is made of brick, concrete or the like, drill five
(5) or more holes of 5mm diameter in the wall. Insert
clip anchor (item 2 on page 3) for appropriate mounting
screws.
4 The water tray’s outlet for the indoor unit has two-way
drainage design. During installation, the indoor unit
should slightly slant to water tray’s outlet for smooth
drainage of condensate water.
Fit the mounting plate and drill holes in the wall according to
the wall structure and corresponding mounting points
on the mounting plate. (dimensions are in mm unless
otherwise stated)
Model no. Indoor unit dimension
W x D x H (mm)
Mounting
plate type
KSV26CRE 912 x 188 x 290 A
KSV26HRE 912 x 188 x 290 A
KSV35CRE 912 x 188 x 290 A
KSV35HRE 912 x 188 x 290 A
KSV53HRE 1000 x 219 x 326 B
KSV62HRE 1073 x 260 x 338 C
KSV70CRE 1178 x 253 x 326 D
KSV70HRE 1178 x 253 x 326 D
KSV80HRE 1178 x 253 x 326 D
Mounting plate type A
Mounting plate type B
55mm 55mm
143
135
80
542 235
55
55
31
87
1000
219
694
98
78
256
78

Kelvinator Air Conditioning Installation instructions 11
Mounting plate type C
Mounting plate type D
Indoor unit installation
70 70
36
67 67
36
146
90 65
575
left right
indoor
unit
indoor
unit
172
253 179746
1073
183
685
149326
337
65 65
50
163 90
6
74 105

12 Installation instructions Kelvinator Air Conditioning
Indoor unit installation
Drill piping hole
1. Determine hole positions according to the diagram. Drill one (1)
hole (Ф55 or Ф70 mm) in the wall at a slight downward slant to
the outdoor side.
Piping hole Model
55 KSV26CRE, KSV35CRE, KSV26HRE,
KSV35HRE, KSV53HRE,
70 KSV70CRE, KSV62HRE, KSV70HRE, KSV80HRE
2. The inclination must be between 5mm and 10mm in order to
ensure a good drain of condensed water generated by the
indoor unit.
indoor
wall pipe
seal putty
5-10mm
outdoor
55mm or
70mm
3. Insert the wall pipe into the hole to prevent any wiring from being
damaged when passing through the hole.
4. Always use a wall hole conduit when drilling metal grids, metal
plates or the like.
5. For models with a cooling capacity greater than 4500W, remove
and dispose the two polystyrene lateral rear supports from the
indoor unit before the installation.
remove both supports
Installation of drain hose
1. Connect the drain hose to the outlet pipe of the indoor unit.
Bind the joint with vinyl tape.
outlet pipe of
indoor unit
vinyl tape
drain
hose
outlet pipe of
indoor unit
2. Put the drain hose into insulating pipe.
outlet pipe of
indoor unit
vinyl tape
drain hose (narrow)
insulating pipe
3. Wrap the insulating pipe with wide vinyl tape to prevent the
shift of insulating pipe. Slant the drain hose downward slightly
for smooth drainage of condensed water.
outlet pipe of
indoor unit
vinyl tape
insulating pipe
connected

Kelvinator Air Conditioning Installation instructions 13
caution
1. The insulating tube should be connected reliably with the
sleeve outside the outlet pipe.
2. The drain hose should be slanted downward slightly, without
distortion, bulge or fluctuation.
do not block water
flow with a rise
do not put the end
of the hose in water
3. Do not put the outlet in the water.
bulge flooded
The piping can be output from right, rear right, left or
rear left of the indoor unit body.
1. When routing the piping and wiring from the left or right
side of indoor unit, cut off the tailings from the chassis when
necessary (see figure below).
tailing 2
tailing 1
• Cut off the tailings 1 when routing the wiring only.
• Cut off the tailings 1 and tailings 2 when routing both the wiring
and piping.
indoor unit outline
connection piping
43
2. The drain hose can be connected at two different positions.
Use the most convenient position and, if necessary, exchange
the position of drain cap and drain hose.
• The drain hose is connected at the rear left side of the indoor
unit when you receive the product.
drain hose
(connected at the
rear left side)
refrigerant
piping
drain hole
drain cap
Follow the instructions below for exchanging the position of the
drain cap and drain hose from the left to the right side.
a. Pull out the drain cap at the rear right of the
indoor unit.
drain cap
b. Pull out the drain hose at the rear left of the
indoor unit.
drain hose
c. Put the drain cap into the drain hole at the rear left of the
indoor unit.
drain cap
Indoor unit installation

14 Installation instructions Kelvinator Air Conditioning
d. Insert the drain hose into the drain hole at the rear right of the
indoor unit.
drain hose
3. Arrange the pipe in the most convenient direction
and position.
piping on the rear
right side
drain hose from
the left side
piping on the rear
right side
drain hose from
the right side
piping on the
right side
drain hose from
the left side
piping on the
right side
drain hose from
the right side
piping on the left
rear side
drain hose from
the left side
piping on the
left side
drain hose from
the left side
caution
When refrigerant pipes and the drain pipe are fitted to the same
side, ensure that the bulk does not push the unit away from the wall
when in its final position.
drain hose from
the right side
Piping and cable
from the right side
Indoor unit installation

Kelvinator Air Conditioning Installation instructions 15
4. Take out the piping from body case, wrap the piping, power
cords, drain hose with the tape and then make them pass
through the piping hose.
Do not put any object in the drain pan located in the rear of
the indoor unit, as the condensed water is gathered there and
piped out of the room.
indoor unit
piping
insulation
liquid pipe
connecting
cable
drain hose gas pipe
caution
• Connect the indoor unit first, then the outdoor unit.
• Do not plug the cable to the indoor unit. That must be done at
a later stage.
• Turn the cable lightly to make the connection easier.
• Be careful not to let the drain hose become slack.
• Heat insulate the connecting pipe.
• Be sure that the drain hose is located at the lowest side of the
bundle. Locating at the upper side can cause drain pan to
overflow inside the unit.
• Never cross connect or interwind the power wire with any
other wiring.
• Do not allow the piping to be exposed out from the back of
the indoor unit.
• If part of the drain hose is positioned inside the room, wrap
it with insulating materials so as to prevent condensed water
from dropping.
5. Hang the mounting slots of the indoor unit on the upper hooks
of the mounting plate and check if it is firm enough .
To ease the piping installation, put a spacer between the
indoor unit and the wall. Remove the spacer once finished.
upper hook
mounting plate
spacer
6. Press the lower left and right sides of the unit against the
mounting plate until the lower hooks engage into their slots.
Ensure the unit is firmly fitted.
upper hook
fixing lower hook
connecting
cable
drain hose
mounting plate
7. The installation site should be 2 metres or more above the floor.
Indoor unit installation

16 Installation instructions Kelvinator Air Conditioning
Refrigerant pipe connection
The main cause of refrigerant leakage is due to defects in the
flaring work. Carry out flaring work using the following procedure:
Note: When using refrigerant R32, a reusable flared connection is
the only allowed pipework on the outside of any building.
Hence the supplied "once only" flare fitting must be used unless all
welded connections are used. If welded connections are used, no
low temperature solder is permitted.
a. Cut the pipes and the cable
Use the piping kit accessory (if applicable) or pipes purchased
locally. Measure the distance between the indoor and the
outdoor unit. Cut the pipes a little longer than the measured
distance. Cut the cable 1.5m longer than the pipe length.
pipe
oblique roughness burr
90°
b. Burr removal
Completely remove all burrs from the cut cross section of pipe/
tube. Face the end of the copper pipe/tube in a downward
direction as you remove burrs in order to avoid burrs dropping
into the tubing.
pipe
reamer
face down
c. Put the flare nut on
Remove flare nuts attached to indoor and outdoor unit, then
put them on pipe/tube having completed burr removal.
flare nut
copper tube
caution
It is not possible to put them on after flaring work.
d. Flaring work
Carry out flaring work using flaring tool as shown below.
bar
copper pipe
clamp handle
cone
yoke
handle
bar
A
Firmly hold copper pipe in a die according to the dimension shown
in the table below.
Outer diameter (mm)
A (mm)
Max. Min.
6.35 (1/4”) 1.3 0.7
9.52 (3/8”) 1.6 1.0
12.70 (1/2”) 1.8 1.0
15.88 (5/8”) 2.4 2.2
e. Check
Compare the flare work with the adjacent diagram.
If the pipe has any defect, cut off the enlarged section and
redo the work.
smooth all around
even length all
around
incorrect flaring
inclined
damaged
surface
uneven
thickness
cracked
Make an independent covering for each pipe with the
appropriate tubular isolation.
Indoor unit installation

Piping connection - indoor unit
a. Connecting the indoor unit tubing to the connection piping:
Align the centres of the pipes and sufficiently tighten the flare
nut with your hands first.
indoor unit tubing flare nut piping
torque
wrench
spanner (fixed)
flare nut
piping
indoor unit piping
Then tighten the flare nut with spanner and torque wrench
referring to the following:
Outer diameter (mm) Torque (N.m)
6.35 (1/4”) 15-16
9.52 (3/8”) 31-32
12.70 (1/2”) 40-41
15.88 (5/8”) 45-46
caution
Excessive torque can break the nut depending on installation
conditions.
b. Wrap the insulation material around the connecting portion:
Cover the indoor unit pipe and the connection pipe with the
heat insulation material. Bind them together with vinyl tape so
that there is no gap.
insulating material
Isolate the suction pipe from the liquid pipe.
heat insulation
suction line pipe liquid line pipe
Wrap the insulated pipes with vinyl tape in the rear section for
pipe housing. Fasten the power cable to the pipes with vinyl
tape.
connection pipe
vinyl tape (wide) wrap with vinyl tape
indoor unit pipe
vinyl tape (narrow)
pipe
connection
cable
Wrap the piping, drain hose and power cable tightly with vinyl
tape so that they can fit into the rear piping housing section.
wrap with vinyl
tape (wide)
vinyl tape (narrow)
pipe
drain hose
connection
power cable
Indoor unit installation
Kelvinator Air Conditioning Installation instructions 17

c. Positioning the indoor unit:
Remove the spacer.
Hook the indoor unit onto the upper portion of the mounting
plate (engage the hooks of the mounting plate into the
openings at the rear top of the indoor unit). Ensure that the
hooks are properly seated on the mounting plate by moving
the indoor unit in all directions.
upper hook
mounting plate
spacer
Press the lower left and right sides of the unit against the
mounting plate until the hooks engage into their slots
(clicking sound).
upper hook
connecting
cable
fixing lower hook
mounting plate
Piping connection - outdoor unit
a. Align the centres of the pipes and sufficiently tighten the flare
nut with your hands.
b. Then, tighten the flare nut with torque wrench until the
wrench clicks.
outdoor unit
2-way
valve
3-way
valve
discharge pipe
(suction pipe for
KSV53HRE and
KSV62HRE)
suction pipe
(discharge pipe
for KSV53HRE
and KSV62HRE)
Make sure to follow the torque table value as below:
Outer diameter (mm) Torque (N.m)
6.35 (1/4”) 15-16
9.52 (3/8”) 31-32
12.70 (1/2”) 40-41
15.88 (5/8”) 45-46
Piping formation
a. Form the piping by wrapping the connecting portion of the
indoor unit with insulation material and secure it with narrow
vinyl tape and wide vinyl tape.
If you want to connect an additional drain hose, the end of the
drain hose outlet should be routed above the ground. Secure
the drain hose appropriately.
b. In cases where the outdoor unit is installed below the indoor
unit level:
Wrap the piping, drain hose and connecting cable from the
bottom to the top. Secure the wrapped piping along the
exterior wall using saddle or equivalent.
seal small openings
around piping with
a gum type sealer
wrapping
pipe
drain hose
trap is required to prevent water
from entering electrical parts
drain hose
connection cable
Note: all piping must be protected against mechanical damage.
18 Installation instructions Kelvinator Air Conditioning
Indoor unit installation

Indoor unit installation Safety precautions
Kelvinator Air Conditioning Safety precautions 19
c. In cases where the outdoor unit is installed above the indoor
unit level:
Wrap the piping and connecting cable from bottom to top.
Form a trap to prevent water from entering the room.
Secure the wrapped piping along the exterior wall using saddle
or equivalent.
seal small openings
around piping with
a gum type sealer
trap
trap
drain hose
Note: all refrigerant piping must be protected against
mechanical damage
Electrical safety rules before starting the installation:
1. A dedicated power supply circuit and breaker should be
provided for the products which are not supplied with a
service cord and plug in accordance with local electrical safety
regulations.
2. The circuit breaker must have the functions of magnetic tripping
and heat tripping to prevent short circuit and overload.
3. The appliance shall be installed in accordance with national
wiring regulations.
4. A circuit breaker with proper capacity must be installed
according to AS3000 and applicable local electrical safety
regulations.
5. In case of problems in power supply, the air conditioner must not
be installed before the customer fixes the problem.
6. Be sure the power supply matches the air conditioner.
7. Ensure the live wire, neutral wire and earth wire in the power
socket are properly connected.
8. Inadequate or incorrect electrical connections may cause electric
shock, fire or some electrical parts to malfunction.
9. Before performing any electrical work, turn off the main power to
the system.
Earthing requirements
1. Air conditioners are type 1 electric appliances. The unit must be
reliably earthed and connected by a qualified electrician.
2. The yellow-green wire in the air conditioner is the earthing wire
which cannot be used for any other purposes. Improper earthing
may cause electric shock.
3. The earth resistance must comply to national wiring regulations.
4. The user’s power must have reliable earthing terminal. Do not
connect the earthing wire with the following:
• Water pipe
• Gas pipe
• Contamination pipe

Indoor electric wiring
Note: for correct operation of the air conditioner and standby
power modes the mains power should be supplied to the
indoor unit.
1. Open the front panel and remove the wiring cover by
loosening the screw.
wiring cover
N(1) 2 4 5
N(1) 2 3
N(1) 2
2. Route the power connection cable from back of the indoor
unit and pull it toward the front through the wiring hole for
connection.
3. Connect and screw the wires onto the terminal block as
identified by their colours.
KSV26CRE, KSV35CRE models
blue black brown
to outdoor unit
cable clamp
earthing wire
(green & yellow)
KSV26HRE, KSV35HRE models
blue black brown
earthing wire
(green and yellow)
4. Wrap wires that are not connected with insulating tape so that
they do not touch any electrical or metal parts.
5. Secure the wires firmly with the cable clamp.
6. Put the wiring cover back and screw it.
7. Reinstall the front panel.
warning
All wires between indoor and outdoor units must be connected by
a qualified electric contractor.
If the length of the power cord is not enough, please contact your
installer for new a power cord. Lengthening the power cord by
yourself is dangerous and illegal.
Note: Powered accessories cannot be connected to these wiring
points
After tightening the screws, pull the wire slightly to confirm whether
it’s firm or not.
Do not connect two power cables together to supply power to the
air conditioner.
Do not extend the power cable conductor by cutting or splicing.
Installation
20 I nstallation instructions Kelvinator Air Conditioning
