Ken A Vision Dual Purpose Scope 2 T-19311C User manual

Dual Purpose Scope 2
Instruction Manual
T-19311C T-19311C-230
T-19321C T-19321C-230
T-19331C T-19331C-230
T-19341C T-19341C-230

Table of Contents
Introduction 2
Packing Contents 2
Microscope Set-up Guide 3
Specifications 5
Troubleshooting 6

Introduct on
Thank you for purchasing the Dual Purpose Scope 2. This microscope
combines the features of a standard compound microscope with limited
features of a stereo microscope. This microscope features upper
(incident) and lower (transmitted) LED light to view opaque and
transparent microorganisms with high quality optics that magnify
20-400 times; a square, floating stage with spring-loaded stage clips; a
dimmer switch (rheostat) for light control; and a longer working distance
to allow for fairly thick specimens to be viewed.
Pack ng Contents
Warranty SheetInstruction
Manual
Microscope
Cover
Dual Purpose 2 Microscope Power Supply Allen Wrench
2

M croscope Set-up Gu de
The Dual Purpose Scope 2 microscope can be set up in a matter of
minutes. To get the most out of this amazing teaching tool, follow these
step-by-step instructions:
1. After unpacking the box, remove the Dual Purpose
Scope 2 from the plastic bag and remove the protective
coverings from the objective lenses and the eyepiece(s).
2. Place the microscope on a flat, firm surface.
3. Check the coarse focus knob on either side of the main
body support. The coarse focus knobs should turn
easily.
NOTE: The stage should move freely up and down the main body
support when focusing. When you release the knob, the stage should
remain stationary, and not slide down the post on its own.
4. To operate the cordless feature of this microscope,
immediately plug in the microscope to charge for eight
(8) hours.
a. Plug in the round adapter from the power
supply to the back of your microscope.
b. Connect the opposite end to a en-A-Vision
multicharger (Part # SCGN061) or an 110V
(220V international) electrical outlet.
NOTE: With one eight (8) hour charge, you can use the microscope for
up to forty (40) hours of continuous operation. The cordless microscope
can also be operated with the cord plugged into a power source.
c. When not in use, plug the microscope into a
en-A-Vision multicharger that will automatically
stop charging once the battery is fully charged to
keep it at the optimal full charge for longer
battery life. This prevents overcharging and the
users can charge up to eight (8) microscopes at
once.
d. Should you need a replacement power
supply/charger, or new specialized rechargeable
batteries (Part # VFBATBU5), contact your
nearest en-A-Vision dealer.
5. To turn on the LED lights, locate the power switch on the
right back side of each microscope base.
3

NOTE: The switch on each base is a double switch, with the middle
position being OFF.
6. Pushing the right side of the power switch controls the
bottom (transmitted) light for viewing microscopic
specimens.
7. Pushing the left side of the power switch controls the
upper (incident) light for viewing opaque,
multi-dimensional specimens.
T-19311C/T-19311C-230
The monocular Dual Purpose Scope 2 compound microscope with
COOL LIGHT™ illumination allows for viewing specimens through one
(1)-10x wide-field eyepiece with 2x, 4x, 10x, and 40x(S) DIN Plan
Achromat objective lenses on a square, floating stage with spring-loaded
stage clips, and an adjustable light dimmer (rheostat).
T-19321C/T-19321C-230
The dual viewing head Dual Purpose Scope 2 compound microscope is
the same as the T-19311C above, except that the dual viewing head
allows two people to look at the specimen through two (2)-10x
wide-field eyepieces at the same time or connect a camera to one
eyepiece to display on an interactive white board/projector/computer.
One eyepiece has a diopter, so the second user can adjust the ring to
focus his/her eye, allowing for the differences in vision between two
users.
T-19331C/T-19331C-230
The Seidentopf binocular Dual Purpose Scope 2 compound microscope
is the same as the T-19311C above, except that the binocular head
allows the user to view the specimen with both eyes and to adjust for
interpupillary distance. The eyepieces will move to exactly match the
distance between the user’s eyes. The left eyepiece has a diopter to
allow the user to focus the left eye once the right eyepiece is in focus.
Adjusting the diopter, allows for the difference in vision between the
user’s two eyes.
4

Spec f cat ons
Product Number T-19311C T-19321C T-19331C
Stand/Frame
SC12 Comp 2 Stand with 4 hole nose piece
SC12M Comp 2 Mechanical Stage
SC12DP Comp 2 4 hole NP w/ upper/lower light XXX
Standard Features
XXXtnemtrapmoCegarotSregrahC
XXX™eldnaHoGdnawotS
XXX™yrettaBneerG
XXXelbaegrahceRsseldroC
XXXnoitanimulli™THGILLOOC
XXXsucoFfoegnaRdesaercnI
XXXKLATSTHGILREPPU
Heads
SC12MH Comp 2 Monocular Head with eyepiece X
Xseceipeye2htiwdaeHweiVlauD2pmoCHD21CS
Xseceipeye2htiwdaeHraluconiB2pmoCHB21CS
SC12TH Comp 2Trinocular Head with 2 eyepieces
SC12CMH Comp 2 Monocular with 3.2MP Camera
SC12CBH Comp 2 Binocular Head with 3.2MP Camera
Stage
SC12FS Comp 2 Floating Stage with built in Condensor XX
XebbAnitliuBhtiwegatSlacinahceM2pmoCSM21CS
SC12SS Comp 2 Standard Stage w/ 5 Hole Disc Dia.
Eyepieces
SC12EP5 5X
XXXX0191-01PE001CS
SC12EP16 16X
SC12EP20 20X
Objectives
SC12O B2 XXXtamorhcANIDnalPX2
XXXtamorhcANIDnalPX44BO21CS
XXXtamorhcANIDnalPX0101BO21CS
XXXAN56.0tamorhcANIDnalPX04R04BO21CS
SC12OB100R 100X DIN Achromat
Optional
T-12UG Comp 2 Mechanical Stage w/ Abbe and
100X DIN Achromat Ob
j
.
SC12OB4P 4X Plan
SC12OB10P 10X Plan
SC12OB20P 20X Plan
SC12OB40RP 40X Plan
SC12OB60RP 60X Plan
SC12OB100RP 100X Plan
SC12CMH Monocular Camera Head
SC12CBH Binocular Camera Head
5

Troubleshoot ng
This section provides many useful tips on how to solve common problems
while setting up or using the Dual Purpose Scope 2:
I can’t see an image. I only see a partial image.
• Check to see if the power supply is plugged into an
electrical outlet or the battery is charged if using
cordless.
• Check to see if the LED lights are turned on by switching
the power button on the back of the microscope, right or
left. A red indicator light should glow if the LED lights
are on.
• Check to see if the objective lens is clicked into place.
• Adjust the amount of light controlled by the dimmer
switch (rheostat). Turn clockwise to increase the intensity
of light and counterclockwise to decrease.
It is difficult to get an image to focus.
• Adjust the coarse focus knobs slowly.
• Check to see if the objective lens is clicked into place.
• Check to see if there has been damage to the objective
lens/eyepiece. If the lens/eyepiece is dirty, use lens
paper and distilled water to rub gently clean.
NOTE: Never rub the lens/eyepiece when it’s dry. This can cause static
charge that will attract dirt.
6
