Kennedy MODULAR WORK STATION Installation guide

Kennedy Manufacturing Company • 1260 Industrial Drive • Van Wert, OH 45891
Phone [phone] • FAX [phone] • www.kennedymfg.com
BEFORE ASSEMBLY OF YOUR WORK STATION
Check carefully to ensure that all parts listed below are included. If any are missing, please call 1-800-413-8665
and ask for the Sales Department. Do not discard packing material until assembly is complete.
TOOLS REQUIRED
7/16” Open End Wrench or Socket Wrench—Main Assembly
1/2” Open End or Socket Wrench—Steel Top Assembly
Drill and 3/16", 5/16” Drill Bit—Top Pilot Hole—Wood Top Assembly
24" Combination Square
Part No. 527067, Rev. 8/09
Thank you for purchasing this Kennedy product. We produce value-built products for value
conscious users. We welcome any comments or suggestions you may have. Just call or write
the address below. We hope you will continue to nd Kennedy the most complete source for
your tool storage needs.
MODULAR WORK STATION
ASSEMBLY INSTRUCTIONS
ELECTRICAL PANEL ASSEMBLY SUPPLY LIST
PARTS DESCRIPTION
Lag Screws
ASSEMBLY:
1. Remove required knock outs from electrical panel.
2. Align electrical panel to bottom front edge of work
top. Mark mounting holes pattern to the top.
Pre-drill 3/16" x 3/4" starter holes for lag screws.
3. Align electrical panel to the top and attach using
lag screws.
ELECTRICAL PANEL ASSEMBLY
SIDE/BACK RETAINER ASSEMBLY
SUPPLY LIST
PARTS DESCRIPTION
(14) 14 x 5/8" Screws
ASSEMBLY:
1. Turn wood top upside down and place side and
back retainers.
2. Fasten with 14 x 5/8" screws.
3. Attach wood top to cabinet and/or legs.
SIDE/BACK RETAINER ASSEMBLY
56607
RISER ASSEMBLY SUPPLY LIST
PARTS DESCRIPTION
(6) Hex Screws, 5/16" x 1"
(6) 5/16" x 3/4" x 5/64" Washers
(8) 1/4" x 20 Hex Nuts
(8) 1/4" Lock Washers
(8) 1/4" x 20 x 1/2" Pan Head Slotted Screws
(8) Washers
ASSEMBLY:
1. Attach riser top to sides using (2) each Pan
Head Screws, 1/4" Lock Washers and 1/4" x 20
Hex Nuts.
2. Align riser on wood top and fasten with
5/16" x 1" Hex Screws and 5/16" x 3/4" x 5/64"
Washers, (3) on each end.
RISER ASSEMBLY
56601

ASSEMBLY OF CABINET AND LEG TO WORK SURFACE
CABINET ASSEMBLY SUPPLY LIST
QTY PART DESCRIPTION
(4) Hex Head Wood Screws
(4) Washers
LEG ASSEMBLY SUPPLY LIST
QTY PART DESCRIPTION
(6) Hex Lag Screws
(6) Washers
ASSEMBLY:
NOTE: Remove drawers from cabinet before assembly. Follow listed assembly procedures for
combination of two cabinets, two legs or cabinet and leg.
1. Place a piece of cardboard on the oor and lay the bench top on it with nished surface
face down.
2. Place cabinet housing upside down on the bench top. Position cabinet housing to allow
desired overhang from front to back and sides. Recommend enough overhang at front to
allow key in unlocked position to be in alignment with front edge of the top.
3. Mark mounting hole pattern to the top. Pre-drill 3/16" x 3/4" starter hole for lag screws.
LEG ASSEMBLY:
5. Locate work bench leg approximately 2" in from end of bench top. Mark mounting hole
pattern to the top. Pre-drill 3/16" x 3/4" starter hole for lag screws. Align bench leg and
attach using (6) washers and (6) lag screws.
FOOT REST ASSEMBLY SUPPLY LIST
QTY PART DESCRIPTION
(4) 1/4-20 Screws
(4) Washers
(4) Nuts

ASSEMBLY:
NOTE: Assembly of (2) cabinets, (2) legs or combination of cabinet and leg, must be completed
before foot rest assembly.
1. Using 24" combination square measure distance from top to piercing location in leg cross
support, for foot rest attachment to cabinet side.
2. Attach foot rest to leg cross support using (2) 1/4-20 screws, washers and nuts.
3. Extend and align unattached end of foot rest to cabinet side, using 24" combination square,
place blade against cabinet side with bead on foot rest. Check for horizontal and vertical
levelness, mark mounting hole pattern to cabinet side.
Drill (2) 5/16" diameter holes. Extend foot rest to cabinet wall and align to holes. Attach
using (2) 1/4-20 screws, washers and nuts.
Note: Attaching foot rest between two legs, follow step #2.
Attaching foot rest between two cabinets, measure to desired height and complete assembly required
in step #3.
FOOT REST ASSEMBLY
