Kenroy Home OSWEGO Installation guide

Care and Instruction Manual
OSWEGO SOLAR FOUNTAIN

51026WDGCOPSOL ASSEMBLY INSTRUCTIONS
Thank you for purchasing a Kenroy Home
water feature, you are now only minutes
away from filling your home or outdoor living
space with peaceful displ ays. Our guarantee
backs all of our water features, please do
not hesitate to contact our
Customer Support Team for
resolutions to any parts or
installation concerns.
CUSTOMER SUPPORT TEAM
For any additional questions or concerns please contact our
Customer Support Team:
904-642-4340
@KenroyHome
[e-mail]

51026WDGCOPSOL ASSEMBLY INSTRUCTIONS
Please reference the separate parts listand ensure that
all pieces are included inthe package prior to assembly.
More than one person may be required to
complete the assembly of this product.
To protect the finish, place all parts
on a soft surface when unpacking.
When assembling ensure that all parts are firmly tightened.
Make sure solar panel is not in shadow and receiving direct sunlight.
Choose a location:
is freestanding water feature is attractive from
all sides and can be used to highlight any area
where the solar panel can receive direct sunlight.
is water feature is designed for outdoor use
only. It cannot be used indoors.
Also consider the location of the solar panel.
e pump and light cord reach 13’ from the
base to the solar panel.
For best results the water feature should be placed
on a rm, level surface.

Please carefully open on a so surface to avoid damage.
Place reservoir (B) onto top of the base (A).
51026WDGCOPSOL ASSEMBLY INSTRUCTIONS
Feed pump power cord (D) and light cord through
plastic tube. Cords should exit through notch in base (A).
Attach the pump (D) to the rubber hose.
Plastic
tube
Light
cord
A
D
B
A
D
Rubber
hose

Slot
JB
C
Plastic
tube
51026WDGCOPSOL ASSEMBLY INSTRUCTIONS
Place the column assembly (C) into reservoir (B).
Insert the cords into the slots in hole plug (J), and then
insert the hole plug (J) into the plastic tube.
Join the bracket (E), tube (F) and stake (G) together, then
attach bracket (E) to back of the solar panel (H) as shown.
Insert the stake (G) into the ground where the panel
can receive direct sunlight.
E
F
G
H
E
G

51026WDGCOPSOL ASSEMBLY INSTRUCTIONS
Switch
Fill reservoir (B) with 3.3 gallons of
distilled water a little above the
min. ll line.
Insert pump plug (larger plug) into
the hole for pump (D) on back of the
solar panel (H), then insert light cord
plug (smaller plug) into the hole
for light on back of the solar panel
(H).
Solar battery may have discharged
during transit. Leave panel in direct
sunlight for 2 hours to recharge
before turning on the fountain.
Press the switch on back of the solar
panel (H) to turn on the fountain.
Use shims (I) to level fountain as
necessary.
FINAL STEPS
Note: The LED light only illuminates at night.

51026WDGCOPSOL ASSEMBLY INSTRUCTIONS
If the pump fails to run:
With low ow rate, the pump will spew or “burp”:
• Make sure the solar panel is receiving direct sunlight. Performance
is directly related to the amount and strength of sunlight received.
• See solar panel troubleshooting. You may need to boost charge
or replace the battery.
• Check tubing for kinks and obstructions.
• Check connections between pump and panel and battery.
• Clean pump as described below.
• Check the water level to make sure the pump is completely
submerged, water should always be above the min ll line (not
all water features include min ll line).
If abnormal noise is heard during operation (with water):
• Disconnect the power supply and then remove the pump front
cover and impeller cover.
• Use hand to grip the impeller, gently pull the impeller/rotor
assembly out of the pump housing.
• Rinse the impeller/rotor assembly and the cavity with clean water.
You may also use a soft brush to clean pump surfaces.
If breakage or surface damage is found in the assembly contact
Customer Support for a part replacement.
PUMPSAFETY & TROUBLESHOOTING
To keep water clean
• Periodically change water to prevent algae buildup.
Filter sponge
Filter/ Front cover
Impeller cover
Rotor/Impeller
Pump housing

51026WDGCOPSOL ASSEMBLY INSTRUCTIONS
protect surrounding surfaces as needed. Do not place the water
Splashing may occur when the fountain is rst turned on,
feature on or near any surface that can be damaged by water.
• Keep small children and pets away from the water feature; they
can fall into the water feature and drown.
moisture build-up and clean as necessary. This is especially
Once a week inspect water feature, oor and adjacent wall for
important for humid environments.
• Use water or glass cleaner to clean the surface of the solar panel.
maximum charge to the battery. We suggest you do this
Rechargeable battery packs become less ecient with repeated
charge/discharge cycles. If you nd that the battery appears less
ecient we rst suggest you try to boost charge it. To do this
leave the panel switched o for 2 to 3 sunny days to allow the
occasionally anyway to help prolong the battery life. If problems
persist please contact customer support for a replacement battery
(Replacement part BATTERY2300).
• To replace the battery remove from back of the solar panel by
unscrewing six screws, disconnect the wire connectors, then replace
with new battery (Replacement part BATTERY2300) and reconnect.
Dispose of battery according to local regulations.
• This water feature is designed for outdoor use only. It cannot be
used indoors.
More information about water features can be found at
youtube.com/kenroyhomefountains.
WATER FEATURE WARNINGS & SOLAR
PANEL TROUBLESHOOTING
• Distilled water is recommended to reduce mineral
deposits, bacteria build up and algae that may damage
the water feature basin and pump.

What should I consider when selecting a water feature?
In addition to your personal style tastes, be sure you have an area for your
water feature that can be safely exposed to water, as splashing can occur.
Also take into consideration what a water feature can add to your
Can my water feature be left outside over winter?
This water feature is rated for outdoor use; however certain weather
conditions may adversely aect your water feature. If the temperature in
your region is at risk of dropping below 33° F, your water feature should
be “winterized” before the cold weather arrives. To winterize:
1. Fully drain your water feature of all water.
2. Disconnect the hoses, pumps, solar panel and lights.
3. Clean all components thoroughly, paying special attention to the
pump to prevent residue build-up.
4. Allow all parts to dry.
5. Store parts and water feature in a safe, weather-free environment.
What kind of water should I use in my water feature?
The best water for your water feature is distilled water. This can help
prevent and reduce bacteria and algae buildup. If you do not use distilled
water, more maintenance will be necessary to keep the water feature clean.
How do I clean my water feature?
Oils, dirts, and algae can all build up on the water feature over time. The
best way to restore your water feature to its original state is to empty all
the water from the water feature and use a mild soap (like dish detergent)
and an acrylic brush to clean all the parts.
FREQUENTLY ASKED QUESTIONS
51026WDGCOPSOL ASSEMBLY INSTRUCTIONS

51026WDGCOPSOL ASSEMBLY INSTRUCTIONS
How much water do I need to keep in the water feature?
How often will I need to ll my water feature?
I cannot nd my installation instructions. Where can I nd another
My pump is making a loud noise. How do I x that?
Where possible in our water features, we have included ll lines to help
you visualize the water level required for proper function. If your water
feature does not include ll lines, please check the instruction manual for
water capacity. The most important aspect to keeping your water feature
functioning is to insure the pump is submerged in water at all times to
prevent damage to the pump.
Over time, the water level in your water feature will recede. This is due to
evaporation, and the speed at which your water feature will need to be
lled depends greatly on your environment- the humidity, if your water
feature is in the sun, how often you run the water feature, etc. We
recommend checking the water level before running the water feature to
insure the pump is submerged in water.
copy? Installation and assembly instructions can be found online at
www.kenroyhome.com
1. Be sure the pump is fully submerged in water. If it is not, and pulling
in air, it will make unwanted noise.
2. Check to make sure the pump is not touching the water feature
anywhere other than the bottom. If it is up against the side wall or
another part, the vibration from the pump can cause unwanted noise.
If moving the pump away from other parts does not work, try placing a
sponge or other soft material between these areas to pad the pump.
How do I change my pump speed?
You cannot adjust the pump speed.
FREQUENTLY ASKED QUESTIONSCONTINUED

51026WDGCOPSOL ASSEMBLY INSTRUCTIONS
FREQUENTLY ASKED QUESTIONSCONTINUED
How do I level the water feature?
My tube is too long. What can be done to x this?
For the water to ow properly, it is critical the water feature is level. If
your water feature will be placed in an area with uneven ground, use a
level and leveling shims to help level the water feature. Shims are
wedge-shaped plastic parts that can be placed between the water feature
and the ground to create a level surface.
The hose can be cut with a sharp blade or pair of scissors to the desired
length.
SOLAR:
How long should I expect the water feature to run o of the solar
panel?
The rechargeable battery should last up to six hours with a full charge.
Performance is directly related to the amount and strength of sunlight
received. Solar fountains will perform best in the summer months.
Does the solar panel have to be attached to the pump to charge?
No. Placing the solar panel anywhere in the sun will allow for charge.
Can lights be turned o separately from the water feature?
The lights on solar fountains cannot be turned o separately.

www.kenroyhome.com
