Kenway 59657 Assembly instructions

Page 1Item 59657 For technical questions, please call 1-888-866-5797.
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back
of the manual (or month and year of purchase if product has no number). Keep this manual and the receipt
in a safe and dry place for future reference. 22h
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2Item 59657 For technical questions, please call 1-888-866-5797.
IMPORTANT SAFETY INFORMATION
Assembly Precautions
1. Install only according to these
instructions. Improper installation can
create hazards.
2. Wear ANSI-approved safety goggles
and heavy-duty work gloves during
assembly.
3. Keep installation area clean and well lit.
4. Keep bystanders out of the area during
installation.
5. Do not install when tired or when under
the influence of drugs or medication.
Use Precautions
1. This product is not a toy. Do not allow
children to play with this item.
2. Use for intended purpose(s) only.
3. Inspect before use; do not use if parts
are loose or damaged.
4. Application of this product must meet
State requirements for vehicle lighting.
5. Turn vehicle off and disconnect the
battery before installation.
6. Maintain product labels and
nameplates. These carry important
safety information. If unreadable or
missing, contact Harbor Freight Tools
for a replacement.
Specifications
Mount Dimensions 17-1/4" L x 1-1/10" W x 7/10" H
Mounting Holes 3/16" diameter and 16" apart at centers
Light Amperage Draw 0.06A
Electrical Requirements 12VDC

Page 3Item 59657 For technical questions, please call 1-888-866-5797.
Installation
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
If you do not have experience doing this
type of electrical work, the job should be
done by an automotive service technician.
NOTICE: Placement of the light must
comply with FMVSS/CMVSS 108 Federal
Lighting regulations for Trailers.
WARNING! TO PREVENT SERIOUS
INJURY: Turn off vehicle’s engine, then
disconnect the power supply (battery)
before doing any maintenance or
installation.
1. Place the Light Bar on the mounting
location at the rear of the vehicle.
Use the Light Bar as a template
to mark the two mounting holes
and center hole for the wires.
Note: The planned mounting area must
provide a flush fit to the bottom of the
Light Bar.
2. Ensure that the installation
area has no hidden electrical or
stereo lines before drilling.
3. Drill one 1/4″ hole for the wires and two
1/8″ holes for the mounting screws.
4. Place the Light Bar and feed the
wires through the center hole.
5. Use a pin connector or in-line splice
connector (both sold separately) to
connect the light to your vehicle.
6. When using an in-line splice connector,
it is not necessary to strip the wires.
a. Insert the wire from your vehicle
into one channel of the in-line splice
connector.
b. Insert the wire extending from the
Light into the second channel of the
in-line splice connector.
c. Fold down the tab on the in-line
splice connector to make the
connection.
7. Connect the white wire NEGATIVE (-)
to ground and the brown wire
POSiTIVE (+) to running light circuit.
8. Once the wires are properly connected,
reconnect the power supply (battery)
and test the Light Bar before mounting
it in place.
9. Turn off ignition/battery.
10. Use two #8 x 1" Fillet Head Self Drilling
Screws (sold separately) to attach the
Light Bar to the vehicle/trailer surface.
11. Make certain the Light Bar is well
seated and the ground wire makes
proper contact with a metal surface.

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free
from defects in materials and workmanship for the period of 90 days from the date of
purchase. This warranty does not apply to damage due directly or indirectly, to misuse,
abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity,
improper installation, normal wear and tear, or to lack of maintenance. We shall in no event
be liable for death, injuries to persons or property, or for incidental, contingent, special
or consequential damages arising from the use of our product. Some states do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation
of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with
transportation charges prepaid. Proof of purchase date and an explanation of the complaint
must accompany the merchandise. If our inspection verifies the defect, we will either repair
or replace the product at our election or we may elect to refund the purchase price if we
cannot readily and quickly provide you with a replacement. We will return repaired products
at our expense, but if we determine there is no defect, or that the defect resulted from
causes not within the scope of our warranty, then you must bear the cost of returning the
product.
This warranty gives you specific legal rights and you may also have other rights which vary
from state to state.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Record Serial Number Here:
____
Note: If product has no serial number, record month and year of purchase instead.
Note: Replacement parts are not available. Reference UPC 193175477989.
