SERVICE MANUAL
COPYRIGHT © 2014 JVC KENWOOD Corporation No.RA019<Rev.001>
2014/11
B5B-7170-00
CONTROL HEAD KIT
RA019<Rev.001>201411SERVICE MANUALB5B-7170-00
KCH-19
COPYRIGHT © 2014 JVC KENWOOD Corporation
Note :
Lead free solder used in the board (material : Sn, Ag, In, Bi, melting point : 227 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
T
his product complies with the RoHS directive for the European market. This product uses Lead Free solder.

1-2 (No.RA019<Rev.001>)
Document Copyrights
Copyright 2014 by JVC KENWOOD Corporation. All rights reserved.
No part of this manual may be reproduced, translated, distributed, or transmitted in any form or by any means, electronic, mechan-
ical, photocopying, recording, or otherwise, for any purpose without the prior written permission of JVC KENWOOD Corporation.
Disclaimer
While every precaution has been taken in the preparation of this manual, JVC KENWOOD Corporation assumes no responsibility
for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein.
JVC KENWOOD Corporation reserves the right to make changes to any products herein at any time for improvement purposes.

(No.RA019<Rev.001>)1-3
SECTION 1
PRECAUTION
This service manual does not describe PRECAUTION.
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 CIRCUIT DESCRIPTION
LCD Circuit
The LCD module is connected to the connector (CN4) of the Sub (Display) unit. The LCD module is controlled using parallel interface
(EMIF) from the MPU (IC706) of the transceiver main unit. The backlight of the LCD is controlled by the backlight driver (IC8). The
backlight driver (BD1754HFN) has a single-line digital control interface (UPIC) that can control the power ON/OFF and LED current
value through the EN pin. The backlight driver is controlled by I/O Expander (IC10).
Indicator LED Circuit and Key Backlight
Indicator LED and key backlight LED are controlled by I/O Expander (IC10). Indicator LED is consist of 3 color (Red, Green, Blue).
Key Detection Circuit
IC10 is I/O port expander with keypad matrix decoder. It handles key scanning and flag the MPU (IC706) of the transceiver main
unit via an interrupt line when key events have occurred. It communicates with the MPU via I2C serial communication.
Light Sensor Circuit
Light sensor (IC6) senses intensity of ambient light. The intensity value of ambient light is converted to digital signal and provided
to the MPU (IC706) of the transceiver main unit via I2C serial communication.
Power Supply Circuit
The battery voltage (SB) is provided from the transceiver main unit via SB and SP interface connector (CN2). The battery voltage
(SB) goes to 8 pin interface connector (J1). Other power supply (54M, 18M, 33M) is provided from the transceiver main unit via 50
pin interface connector (CN6). 54M outputs 5.36V and goes to illumination circuit, AVR_IC (IC1). IC1 (50M) outputs 5.0V. 18M out-
puts 1.8V and goes to LCD module. 33M outputs 3.3V and goes to AVR_IC (IC2). IC2 (30LCD) outputs 3.0V.
Fig.1 Power supply circuit
54M
illumination circuit
IC1
50M Level Shift (3.3V >> 5.0V),
Analog SW
CN6
LCD Module I/O
18M
I/O Expander For 3.3V,
Light Sensor,
Level Shift (5.0V >> 3.3V)
33M
LCD Module VDD
IC2
30LCD
CN2
SB
8pin_interface_connector

1-4 (No.RA019<Rev.001>)
2.2 COMPONENTS DESCRIPTION
2.2.1 SUB (Display) unit (XC3-0020-20)
2.3 TERMINAL FUNCTION
2.3.1 Sub (Display) unit (XC3-0020-20)
Ref.No Part Name Description
IC1 IC Voltage regulator (50M)
IC2 IC Voltage regulator (30LCD)
IC3 IC Logic control
IC4 IC Analog SW
IC6 IC Illuminance sensor
IC8 IC LED driver
IC9 IC Logic control
IC10 IC I/O expander
IC12 IC Logic control
Q2 FET DC SW
Q3, 4 Transistor DC SW
Q6 Transistor DC SW
D1, 2 Zener diode Overvoltage protection
D4~7 LED LED
D9~12 LED LED
D14~16 LED LED
D20 Zener diode Overvoltage protection
D21 LED LED
D22 Diode Overvoltage protection
D23, 24 Zener diode Overvoltage protection
D25 Varistor Surge protector
D26~32 Zener diode Overvoltage protection
Pin No. Name I/O Function
CN2 (to Main unit A/2 CN900 of transceiver)
1 SP+ I Speaker output
2 SPG - Speaker ground
3 GND - Ground
4 SB I Switched power supply
CN4 (LCD)
1 VSSA - Ground
2 VSSA - Ground
3 VSSA - Ground
4VCC O3Voutput
5VCC O3Voutput
6 VSSD - Ground
7 VSSD - Ground
8 VSSD - Ground
9 IOVCC O 1.8V output
10 IOVCC O 1.8V output
11 RDX O LCD driver RD signal
12 WRX O LCD driver WR signal
13 DCX O LCD driver data/command switch
signal
14 CSX O LCD driver chip-serect signal
15 DB1 I/O LCD driver data output
16 DB2 I/O LCD driver data output
17 DB3 I/O LCD driver data output
18 DB4 I/O LCD driver data output
19 DB5 I/O LCD driver data output
20 DB6 I/O LCD driver data output
21 DB7 I/O LCD driver data output
22 DB8 I/O LCD driver data output
23 DB10 I/O LCD driver data output
24 DB11 I/O LCD driver data output
25 DB12 I/O LCD driver data output
26 DB13 I/O LCD driver data output
27 DB14 I/O LCD driver data output
28 DB15 I/O LCD driver data output
29 DB16 I/O LCD driver data output
30 DB17 I/O LCD driver data output
31 CABC - No connection
32 RESX O LCD driver reset signal
33 IM0 O Interface mode select
34 LEDA O 54M output (LED light anode)
35 LED1 I LED light cathode 1
36 LED2 I LED light cathode 2
37 LED3 I LED light cathode 3
38 LED4 - No connection
CN5 (Internal speaker)
1 SPG - Speaker ground
2 SP+ O Speaker output
CN6 (to Main unit A/2 CN749 of transceiver)
1 GND - Ground
2 R_SET0 O Radio setting signal 0
3 R_SET1 O Radio setting signal 1
4 R_SET2 O Radio setting signal 2
5 ME - MIC ground
6 MIC O MIC signal output
7 AFO- I AF signal input minus
8 AFO+ I AF signal input plus
9 /PSW O Detection signal input of power
switch
10 /PTT O PTT output
11 TXD I Serial data input
12 RXD O Serial data output
13 GND - Ground
14 DM/KVL I/O MIC data detection
15 33M I 3.3V input
Pin No. Name I/O Function

(No.RA019<Rev.001>)1-5
16 GND - Ground
17 USB_D+ I/O USB0 PHY data plus
18 USB_D- I/O USB0 PHY data minus
19 GND - Ground
20 I2CDT I/O I2C serial data
21 I2CCK I I2C serial clock
22 /KEYINT O Key state change signal
23 PRST I LCD driver reset signal
24 /RD_LCD I LCD driver Read signal
25 /WR_LCD I LCD driver Write signal
26 DC I LCD driver data/command switch
signal
27 /CS_LCD I LCD driver chip-serect signal
28 D[0] I/O LCD driver data input
29 D[1] I/O LCD driver data input
30 D[2] I/O LCD driver data input
31 D[3] I/O LCD driver data input
32 D[4] I/O LCD driver data input
33 D[5] I/O LCD driver data input
34 D[6] I/O LCD driver data input
35 D[7] I/O LCD driver data input
36 D[8] I/O LCD driver data input
37 D[9] I/O LCD driver data input
38 D[10] I/O LCD driver data input
39 D[11] I/O LCD driver data input
40 D[12] I/O LCD driver data input
41 D[13] I/O LCD driver data input
42 D[14] I/O LCD driver data input
43 D[15] I/O LCD driver data input
44 18M I 1.8V input
45 GND - Ground
46 GND - Ground
47 54M I 5.4V input
48 GND - Ground
49 NC - No connection
50 NC (IGN) - No connection (Ignition sense in-
put)
J1 (MIC jack)
1 DM/KVL_3 I/O MIC data detection
2 HOOK/RXD/D-2 I/O Hook detection / Serial data input
/ USB PHY data minus
3 MIC_3 I MIC signal input
4 ME_3 - MIC ground
5 PTT/TXD_3 I/O PTT input / Serial data output
6GND -Ground
7 SB_2 O Switched power supply
Pin No. Name I/O Function
8 BLC_4/D+2 I/O Back light control signal / USB
PHY data plus
Pin No. Name I/O Function

1-6 (No.RA019<Rev.001>)
SECTION 3
DISASSEMBLY
3.1 Precautions for Disassembly
3.1.1 Removing the speaker hardware fixture (J2B-0023-
00) and holder (J1K-0019-00)
(1) Remove the speaker lead from the holder hook. <1>
(2) Remove the speaker connector from the display unit con-
nector (CN5). <2>
(3) When removing the speaker hardware fixture, insert a flat-
head screwdriver at the position shown in Figure 1-1 and
tilt it in the direction shown by the arrow. <3>
(4) To remove the holder, insert a flat-head screwdriver into
tab of the holder and tilt it in the direction shown by the ar-
row. <4>
Fig.1-1
Fig.1-2
3.2 Precautions for Reassembly
3.2.1 Installing the holder (J1K-0019-00) and speaker hard-
ware fixture (J2B-0023-00)
(1) Insert two tabs of the holder (J1K-0019-00) into the hollows
in the top of the panel. <1>
(2) Push the two tabs of the holder in on the opposite side of
those in step 1 above and fit them into the hollow in the bot-
tom of the panel. <2>
Note:
Push in the holder until it snaps in place.
(3) Install the speaker holder onto the panel. <3>
Note:
To improve water resistance, fit the panel into the groove
of the holder.
(4) Place the speaker into the speaker holder.
Note:
The speaker must not ride on the holder rib.
(5) Place the spacer on the speaker.
(6) Insert the hardware fixture (J2B-0023-00) into the hollow of
the panel as shown in Figure 2-3, then push two parts of
the hardware fixture and fit it into the hollow of the top of the
panel. (Fig. 2-3 <4>)
Note:
Push in the hardware fixture until it snaps in place.
(7) Insert the speaker connector into the display unit connector
(CN5).
(8) Place the speaker lead on the holder hook.
Fig.2-1
Fig.2-2
Fig.2-3
<2>
<1>
<3>
CN5
<4>
<1>
<1> <2>
Spacer
Speaker
Speaker holde
r
<3>
<4>

(No.RA019<Rev.001>)1-7
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
(There is no adjustment item on KCH-19.)
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.
