Kenwood KDOI60X20 Service manual

Free-Standing Double Oven
Electric Cooker with Induction Hob
KDOI60X20
installation / instructions manual
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 1Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 1 18/01/2021 14:3618/01/2021 14:36

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 7
Product Overview......................................................................................................................... 8
Front View ...................................................................................................................................................................8
Top View.......................................................................................................................................................................8
Control Panel..............................................................................................................................................................9
Controls........................................................................................................................................................................9
Touch Control Display..........................................................................................................................................10
Hob Control Panel.................................................................................................................................................10
Setting the Clock ........................................................................................................................ 11
Before Using Your Cooker .......................................................................................................... 12
Choosing the Right Cookware................................................................................................... 12
Using Your Hob ........................................................................................................................... 13
Residual Heat Indicator .......................................................................................................................................13
Pan Missing, Unsuitable Cookware or Not Located Properly ................................................................13
Using the Boost Function ................................................................................................................................... 14
Boost Power Levels/Times..................................................................................................................................15
Safety Switch O Function................................................................................................................................. 15
Timer Function Per Hob Cooking Zone.........................................................................................................15
Hob Child Lock .......................................................................................................................................................16
Faults and Error Codes......................................................................................................................................... 16
First Time Use of the Oven ......................................................................................................... 17
Using the Oven ........................................................................................................................... 17
Using the Anti-tilting Oven Shelf .............................................................................................. 18
Using the Oven Control.............................................................................................................. 18
Energy Saving ............................................................................................................................. 18
Using the Grill/Top Oven............................................................................................................ 19
Using the Minute Minder Timer................................................................................................. 21
Using the Cooking Timer............................................................................................................ 22
Using the Automatic Cooking Timer......................................................................................... 23
Adjusting the Tone of the Timer Alarm..................................................................................... 25
Adjusting the Display Brightness.............................................................................................. 26
General Advice............................................................................................................................ 27
Cleaning the Outside of the Cooker.......................................................................................... 27
Cleaning the Hob........................................................................................................................ 27
Cleaning the Enamel Parts Inside Your Oven ........................................................................... 28
Cleaning the Cooker Door Glass................................................................................................ 28
Cleaning the Inside of Your Cooker........................................................................................... 28
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 2Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 2 18/01/2021 14:3618/01/2021 14:36

Cleaning the Catalytic liners Inside Your Oven ........................................................................ 29
Removing and replacing the catalytic liners ...............................................................................................29
Removing the Grill Door ............................................................................................................ 30
Replacing the Oven Lamp.......................................................................................................... 31
Hints and Tips ............................................................................................................................. 32
Product Fiche and Specications .............................................................................................. 34
Energy Saving Tips and Energy Label....................................................................................... 35
- Main Oven..................................................................................................................................................... 35
- Hob ..................................................................................................................................................................35
Installation .................................................................................................................................. 36
Adjusting the Feet ...................................................................................................................... 37
Moving the Cooker ..................................................................................................................... 37
Stability Bracket ......................................................................................................................... 38
Electrical Connection ................................................................................................................. 39
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 3Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 3 18/01/2021 14:3618/01/2021 14:36

4
Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
• It is recommended that this appliance is installed by a qualied
electrician. The manufacturer is not responsible for any damage caused
by incorrect installation.
• Check whether there is any damage to the appliance after you have
unpacked it. If any damage is found, do not use the appliance and
contact the store where you purchased it.
• This appliance is for indoor domestic use only.
• This appliance is for cooking purposes only. It must not be used for other
purposes, for example room heating.
• For disconnection from the mains supply you must have a switch with a
contact separation of at least 3.0 mm in all poles and rated 32 Amp that
provides full disconnection, this must be incorporated in the xed wiring
in accordance with the local wiring rules.
• If the mains cable gets damaged, it should be replaced by an authorized
service agent or qualied electrician in order to avoid a hazard.
• The oven must be used in a well ventilated location and installed on at /
level ground.
• Only operate your appliance in a dry atmosphere.
• Keep the electrical cables of your other appliances away from hot areas;
do not let them touch the appliance.
• Ensure that the appliance is switched o at the mains supply switch
and allowed to completely cool down before cleaning, replacing the
oven lamp or performing any maintenance to avoid the possibility of an
electric shock or burns.
• Use of your appliance creates moisture in the room in which it is placed,
make sure that your kitchen is well ventilated. Maintain the natural
ventilation ducts properly.
• Cleaning and user maintenance shall not be made by children without
supervision.
• To prevent the appliance tipping, the stabilizing
bracket must be installed.
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 4Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 4 18/01/2021 14:3618/01/2021 14:36

5
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Cleaning and user maintenance shall
not be made by children without supervision.
• Children should be supervised to ensure that they do not play with
the appliance.
• The appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements. Children less than 8
years of age shall be kept away unless continuously supervised.
• Unattended cooking on a hob with fat or oil can be dangerous and may
result in re. NEVER try to extinguish a re with water, but switch o the
appliance and then cover the ame e.g. with a lid or a re blanket.
• The cooking process has to be supervised. A short term cooking process
has to be supervised continuously.
• Danger of re: Do not store items on the cooking surfaces.
• When the oven is hot never touch the oven glass or any other parts that
get hot. Allow the oven to cool before touching these parts.
• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
the glass shattering.
• Before starting to use your appliance, keep curtains, tulle, paper
or ammable materials away from your appliance. Do not keep
combustible or ammable things in or on the appliance.
• Do not use steam cleaners for cleaning the appliance.
• Do not rest any items on or stand on the open door.
• If the hob surface is cracked, switch o the appliance to avoid possibility
of electric shock.
• Take care when handling parts with glass, knocks, chips, heavy handling
and dropping could cause the glass to shatter.
• The glass oven door uses toughened glass and is designed to break into
many‘nugget’ size pieces if it breaks. These pieces will still have sharp
edges, please handle broken glass with care.
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 5Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 5 18/01/2021 14:3618/01/2021 14:36

6
• The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
• Users with pacemakers tted should seek medical advice before using an
induction hob.
• Metallic objects such as knives, forks, spoons and lids should not be
placed on the hob surface since they can get hot.
• Use only hob guards designed by the manufacturer of the cooking
appliance or indicated by the manufacturer of the appliance in the
instructions for use as suitable or hob guards incorporated in the
appliance. The use of unappropriate guards can cause accidents.
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 6Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 6 18/01/2021 14:3618/01/2021 14:36

7
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according
to local regulations.
The following items are included:
Oven Shelf x 3
The Main Unit
Thank you for purchasing your new Kenwood Free Standing Electric Double Oven.
You must read this manual in order to fully understand how to operate it correctly.
This cooker must be installed by a competent engineer. Please allow the installer to view the
installation section of this manual.
Read all the safety instructions carefully before use and keep this manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Stability Bracket x 1
* All images are for indication only; please refer to your individual unit for actual item.
Grill Rack x 1
Grill Pan x 1
Grill Pan Handle x 1
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 7Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 7 18/01/2021 14:3618/01/2021 14:36

8
Product Overview
Front View
Top View
2
1
1
2
1. Large cooking zone 18cm 2. Small cooking zone 14.5cm
3. Timer controls
* All images are for indication only; please refer to your individual unit for actual item.
1
2
3
5
4
6
7
1. Induction Hob
2. Control Panel and Touch Control Display
3. Top Oven Door Handle
4. Top Oven Door
5. Oven Door Handle
6. Oven Door
7. Adjustable Feet
3
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 8Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 8 18/01/2021 14:3618/01/2021 14:36

9
Control Panel
1. Back Left Hob Control
2. Front Left Hob Control
3. Bottom Oven Thermostat Indicator
4. Bottom Oven Control
5. Top Oven Thermostat Indicator
6. Top Oven Control
7. Front Right Hob Control
8. Back Right Hob Control
* All images are for indication only; please refer to your individual unit for actual item.
1 2 4 6 7 9
53
P 9 8 7 6 5 4 3 2 1 0
P 9 8 7 6 5 4 3 2 1 0
P 9 8 7 6 5 4 3 2 1 0
P 9 8 7 6 5 4 3 2 1 0
Controls
• = OFF
O
O
O
O
O
O
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 9Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 9 18/01/2021 14:3618/01/2021 14:36

10
Touch Control Display
1 2
4
3
5
8
7
1. - Auto Cooking Symbol
2. Manual Cooking Symbol
3. Clock / Timer Count down
4. - Minute Minder Symbol - Shows a
timer is active
5. + control - Press to increase the time
6. Mode - Press to scroll Timer modes or
press and hold for 2 seconds to unlock
the display
7. - control - Press to decrease the time
8. Symbol - Shows the display is
currently locked
6
1. Timer zone indicators
2. Timer Display
3. Power Level display
4. Timer adjustment controls
5. Timer Activation control
Hob Control Panel
1
2
1
3 34
5
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 10Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 10 18/01/2021 14:3618/01/2021 14:36

11
Setting the Clock
Before using your new cooker you must set the clock to the correct time.
1. When the power is first switched on the clock display will be
flashing, the display will show and the time will show as 12:00.
2. Press the ‘+’ and ‘-” buttons at the same time, the number will stop
flashing but the dot will flash and the Manual cooking symbol
will appear.
3. While the dot is still flashing press the ‘+” or ‘-’ buttons to adjust the
time. Pressing and holding the buttons will quickly adjust the time.
4. Once you have set the correct time just wait for a few seconds.
When the dot stops flashing the time is then set. The Symbol will
appear after 30 second.
Press +and -together
Press +or -to adjust the time
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 11Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 11 18/01/2021 14:3618/01/2021 14:36

12
Before Using Your Cooker
Before using your new cooker, please:
• Make sure all the controls are turned off.
• Read this Instruction/Installation Manual, taking special note of the 'Safety Warnings' section.
• Turn the mains power on.
Choosing the Right Cookware
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking
zone. Always centre your pan on the cooking zone.
Always lift pans off the hob – do not slide, or they may scratch the glass.
• To improve performance, and reduce energy, always use pans with close fitting lids.
• If the hob glass surface is cracked, switch of the appliance to avoid the possibility of electric shock.
Contact an authorised repair agent.
An easy way to check if your existing cookware is suitable you use with your induction
hob, is to touch the base with a magnet. If the magnet sticks to the bottom of the pan
and your pan is a minimum of 3mm thick at the base, then it is safe to use. The thicker
the base of the pan and the higher the iron content of the pan the better.
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 12Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 12 18/01/2021 14:3618/01/2021 14:36

13
* All images are for indication only; please refer to your individual unit for actual item.
Using Your Hob
1. Rotate the control to the heat level (1-9) you wish to use for the selected cooking zone.
LEVEL 0 LEVEL 1-3 LEVEL 4-5 LEVEL 6-7 LEVEL 8 LEVEL 9 P
OFF Delicate
warming
Gentle
simmering,
slow
warming
Reheating
and rapid
simmering
Boiling, saute
and searing
Maximum
heat
Boost
function
2. When the a cooking zone is in use the power level of the zone will be displayed on the hob.
3. When you are finished cooking rotate the control back to the “0” position, the cooking zone indicator will
display ‘H’ for a few minutes indicating the zone if off but still hot. The cooking zones will remain hot for
some time. Do not touch the hobs until they have completely cooled down.
Residual Heat Indicator
When the cooking zones have just been switched off, if its still hot the ‘H’ will be displayed to show the zone is
still hot. This will automatically switch off when the zone cools down.
Pan Missing, Unsuitable Cookware or Not Located Properly
If your pan is not placed on the hob or its not seated in the correct place you will see this symbol . When the pan
is correctly positioned your chosen power setting will be displayed. You may also see this symbol if your pan is
not the correct type for induction cooking.
• Do not place or leave metal objects (e.g cutlery or fish slice) on the hob, they may become very hot.
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 13Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 13 18/01/2021 14:3618/01/2021 14:36

14
Using the Boost Function
Your hob has a Power Boost function which, when selected will boost the power to a cooking zone to get to your
desired level as quickly as possible.
1. Turn your desired cooking zone knob to P for 2 seconds. The letter P will start to flash in the display.
2. Now turn the cooking zone knob to your required level. The number you selected and the letter P will flash
and the boost function is now active. The amount of time the Boost function is active for will depend on the
cooking level you have selected.
3. Once the boost time expires (see table on page 14) the Boost functions will automatically switch off. The
display will stop flashing and only the level you selected will remain lit.
The power boost feature can only be used on two zone at a time one zone each, left and right.
Its not possible to use Power Boost for all 4
zones or front and back both left or right.
When you are using Power Boost the power level to the other zone (front or back) will be reduced
from 9 to 8.
Power
Boost
Power
Boost
Power
Boost
Power
Boost
Max
Power
8
Max
Power
8
Power
Boost
Max
Power
8
Power
Boost
Power
Boost
Max
Power
8
Max
Power
8
Max
Power
8
Power
Boost
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 14Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 14 18/01/2021 14:3618/01/2021 14:36

15
Timer Function Per Hob Cooking Zone
When the hob is switched on, an independent timer can be programmed for each cooking zone. This means you
can set a timer for each individual zone for up to 99 minutes on each zone. When the allotted timer expires the
cooking zone will automatically switch off, and a beeping sound will be heard.
1. Switch on a cooking zone by turning one of the hob control knobs to your desired setting.
2. Press the Timer Activation Control on the hob a Timer Zone indicator light will switch on indicating which
timer zone is active. Continue to press the Timer Activation Control until your desired zone is selected.
3. Press the + / - Timer Adjustment controls to select your desired timer time.
4. Repeat this process to set timers for other zone.
5. Once the timer has expired and reached 00, the cooking zone will switch off and your hob will beep for 2
minutes, the Timer Zone indicator light will also flash. The cooking zone power lever will now indicate ‘H’ to
show the zone is off but still HOT. To cancel the beep, press the timer button on the hob.
Safety Switch O Function
Your hob has a built-in safety feature which will automatically switch the cooking zones off if the power settings
haven’t been modified for a set time. The time taken for the safety switch to activate depends on the current
power level of the cooking zone, the higher the power level the quicker the safety switch will activate.
Heat Setting Safety Switch active after
1-2 6 hours
3-4 5 hours
54 hours
6-9 1.5 hours
When setting multiple timers, after 10 seconds of inactivity the display will show the next timer to
expire.
Boost Power Levels/Times
The table below shows the boost activation time pre power level.
Power Level Boost time
11 minute
22 minutes
33 minutes
44 minutes
55 minutes
66 minutes
77 minutes
88 minutes
9
(Large zone 2100 W, Small zone 1400 W)
8 minutes
P
(Large zone 2500 W, Small zone 1800 W)
N/A
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 15Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 15 18/01/2021 14:3618/01/2021 14:36

16
Faults and Error Codes
If you spill liquid onto the control panel your hob will display flashing ‘F’s” and will beep. Don’t worry your hob
hasn’t developed a fault it just thinks all the controls are being press. Wipe off the liquid and dry the control panel
and the display will go back to normal and the beeping will stop.
If your hob develops an error it will display an error code from E1 to E9 depending on the error. Follow the advice
in the table below if an error code is displayed.
Error Code Advice
E1 Cooling fan is disabled. Call an authorised service agent.
E3 The supply voltage is different to the rated value for the hob. Press the POWER control to switch
the hob off. Wait for it to cool down (the ‘H’ have disappeared from the display). The switch the
hob back on. If the error code is still displayed call an authorised service agent.
E4 The supply frequence is different to the rated value for the hob. Press the POWER control to
switch the hob off. Wait for it to cool down (the ‘H’ have disappeared from the display). The
switch the hob back on. If the error code is still displayed try switching the hob off at the mains.
Then switch it back on again, this should reset the hob. If the error code is still displayed call an
authorised service agent.
E5 The internal temperature of the hob is to high. Switch the hob off and allow it to cool down.
E6 Communication error between the control panel and the heater. Call an authorised service
agent.
E7 Coil temperature sensor is disabled. Call an authorised service agent.
E8 Cooler temperature sensor is disabled. Call an authorised service agent.
E9 Calibration error. Call an authorised service agent.
Hob Child Lock
Once you have selected a power level for a cooking zone you can lock the hob so if the control knobs are
adjusted the hob level won’t change.
1. Select a hob cooking zone and choose your desired power level.
2. Press and hold the + and - Timer buttons until the hob beeps and the display flashes. You will see followed
by a power level e.g. flashing in the display. Now you won’t be able to select or change any hob cooking
zone.
3. To deactivate the Child lock either switch off the hob cooking zones, or press and hold the + and - Timer
buttons until you hear a beep sound.
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 16Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 16 18/01/2021 14:3618/01/2021 14:36

17
Using the Oven
1. On the wall of the inner cavity there are 11
different rack guide slots. You can place the
rack at different heights to achieve the best
cooking performance depending on the heat
of the heating element and the size of the food.
It is recommended to preheat the oven for
10 minutes.
2. Always monitor the food during operation to
ensure that you are not overcooking it.
3. For heavy food,
use a baking pan
rather than the
oven shelf.
4. During cooking,
do not open
the door
unnecessarily as
you will lose heat
and your cooking
results may
cooking times
will be longer and
energy use will
be higher.
5. Using cake tins when cooking cakes will give better results.
First Time Use of the Oven
Ensure that nothing has been left in the top and bottom oven. Remove any insert cards or plastic bags. Before
connecting the power, use a damp cloth to carefully wipe the inner cavity wall and housing. Clean all the
detachable parts in hot, soapy water before using.
Cycle through all the elements on both ovens on maximum for 10 minutes. There may be a little smoke and
odour upon initial start up. This is normal. It is due to the protective substance on the heating elements which
protects the cooker from the effects of corrosion during shipping from the factory.
Accessible parts may become hot during use. Young children
should be kept away.
• Under no circumstances should the oven be lined with aluminium foil as overheating may occur.
• Do not place dishes or baking trays directly onto the base of the oven as it becomes very hot and
damage may occur.
• Bread may catch fire if the toasting time is too long. Close supervision is necessary during toasting.
• During use, this appliance becomes hot. Care should be taken to avoid touching hot surfaces,
e.g., oven door, heating elements.
• Accessible parts may become hot when in use. Children should be kept away.
• Do not leave the handle in position when grilling. If the handle is left in position when grilling,
it will get very hot.
* All images are for indication only; please refer to your individual unit for actual item.
Guide 5
Guide 6
Guide 7
Guide 8
Guide 9
Guide 10
Guide 11
Guide 3
Guide 4
Guide 2
Guide 1
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 17Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 17 18/01/2021 14:3618/01/2021 14:36

18
Using the Anti-tilting Oven Shelf
• Insert the shelf, slide it along the runners.
• To remove, slide the shelf towards you, it will hit the stop point, then lift
the shelf slightly over the stop point and slide it out of the runners.
Using the Oven Control
Function Description
Defrost Function
Defrost function can be started by placing the frozen food into
your oven and turning the oven control to the defrost sign or
below. Ensure the oven light does not illuminate as this will activate
the elements and start the cooking process. This function will not
cook the food as only the fan operates, this will help to defrost the
food in a very short time. Put the food to be defrosted on the shelf
in the third guide slot position and place a tray onto a shelf on
the bottom guide slot position to collect the water during defrost.
50
100
150
200
250
Adjusting the temperature
This design spreads the heated air equally in the oven and it is
suitable for cooking with one or more trays.
Turn the oven control to the desired temperature. It is recommended
to preheat the oven for 10 minutes. Place the tray on the shelf.
At the end of cooking time, as in all other cooking processes;
turn the oven control to off. Take the cooking tray out and put it
onto a safe place as it will be hot. Keep children away from the hot
oven during and after cooking, until it has completely cooled down.
Energy Saving
To save energy and to help protect the environment, we recommend these hints:
• Preheat the oven only if expressly required by the recipe or guidelines.
• Use dark baking tins because they have a higher degree of heat absorption.
• In the case of longer baking times, you can switch off the oven 5–10 minutes before the full
baking time and use the residual heat. This will reduce energy usage.
• Use the oven efficiently, by cooking many trays of food at the same time.
• Select the correct shelf location for the food being cooked.
• Do not open the oven door more than necessary.
100
150
200
250
50
0
* All images are for indication only; please refer to your individual unit for actual item.
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 18Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 18 18/01/2021 14:3618/01/2021 14:36

19
Using the Grill/Top Oven
Before using the Grill for the first time, heat the grill on maximum for 15 ~ 20 minutes. There may be a little
smoke and odour upon initial start up (for about 10 mins). This is normal. It is due to the protective substance on
the heating elements which protects the cooker from the effects of corrosion during shipping from the factory.
Function Description
Top and Bottom Element
Turn the oven control to the desired temperature 50°C - MAX. It is recommended to preheat the
oven for 10 minutes. Place the tray on the shelf.
At the end of cooking time, as in all other cooking processes; turn the oven control to off. Take
the cooking tray out and put it onto a safe place as it will be hot. Keep children away from the
hot oven during and after cooking, until it has completely cooled down.
Top Element
The top element will be full on in this mode, to control cooking temperatures use different shelf
positions.
Small Grill
This function is used for grilling. In order to grill, please use the grill pan supplied with your
product. Turn your grill’s control to the required setting.
At the end of grilling, as in all other cooking processes; turn the control to the “0” position (off ).
Take the grill pan out by using the supplied handle and put the pan onto a safe place. Keep
children away from the hot oven during and after grilling, until it has completely cooled down.
Large Grill
This function is used for grilling. It uses the Top Element and Grill to cook over a larger area. In
order to grill, please use the grill pan supplied with your product. Turn your grill’s control to the
required setting.
At the end of grilling, as in all other cooking processes; turn the control to the “0” position (off ).
Take the grill pan out by using the supplied handle and put the pan onto a safe place. Keep
children away from the hot oven during and after grilling, until it has completely cooled down.
• The Grill door must be kept open during this function. The door has a position in which the door
is open at 30°. This is the minimum the door can be closed during use.
• During use the appliance becomes hot. Care should be taken to avoid touching the heating
elements inside the grill.
* All images are for indication only; please refer to your individual unit for actual item.
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 19Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 19 18/01/2021 14:3618/01/2021 14:36

20
Place an oven shelf in one of the 4 guide slot
positions. There must be at least 30 mm between the
food and the element.
Using the handle, insert the grill rack and tray onto
the shelf in guide slot 1, 2, 3 or 4. The food to be
cooked must be placed on the grill rack in the grill
tray. The handle can be removed once the grill rack
tray is in position. Check the food regularly to ensure
you do not overcook it.
The grill pan has a detachable handle. Ensure when
using the grill pan handle that it is centralised and
secure as shown below.
Preheat the grill element for approximately 5-10 minutes before cooking the food.
Ensure a minimum distance of 30 mm exists between the food and the elements. If necessary use a lower guide slot.
Check the food regularly to ensure you do not overcook the food. If slower cooking is required use a lower guide
slot or lower grill setting.
Do not leave the handle in position when
grilling. If the handle is left in position
when grilling, it will get very hot.
Bread may catch fire if the toasting time is too long. Close supervision is necessary during toasting.
Guide 3
Guide 4
Guide 2
Guide 1
Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 20Kenwood Free Standing Electric Double Oven KDOI60X20 Manual.indd 20 18/01/2021 14:3618/01/2021 14:36
