Kenwood CK 234 DF Series User manual

1
Before operating this cooker,
please read these instructions carefully
GB
GAS COOKER with
ELECTRIC DOUBLE
OVEN
model CK 234 DF..
Instructions for use - Installation advice

2
CONTENTS
Page Number
Introduction............................................... 3
Important Safeguards & Recommendations..................... 4-8
Cooking Hob ............................................. 9
Control Panel............................................. 10
Use of hob burners ........................................11 - 13
Top conventional electric oven ...............................14 - 16
Bottom main oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cooking guide ............................................18
Electronic programmer......................................18 - 24
Cleaning & maintenance ....................................25 - 36
Advice For The Installer ....................................37
Installation ...............................................38 - 40
Gas installation ...........................................41 - 46
Electrical section ..........................................47 - 48
Guarantee & After Sales Service .............................49

3
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT
IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EC.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority differentiated
waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain signicant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.
DECLARATION OF CE CONFORMITY
• This appliance has been designed to be used only for cooking.Any other use (such as
heating a room) is improper and dangerous.
• This appliance has been designed, constructed, and marketed in compliance with:
- Safety requirements of the “Gas” Regulation (EU) 2016/426;
- Safety requirements of the “Low voltage” Directive 2014/35/EU;
- Safety requirements of the “EMC” Directive 2014/30/EU;
- Requirements of EU Directive 93/68/EEC;
- Requirements of EU Directive 2011/65/EU.
GB
Dear Customer,
Thank you for purchasing a Kenwood CK 234 DF.. dual fuel
cooker.
The safety precautions and recommendations reported below
are for your own safety and that of others. They will also provide
a means by which to make full use of the features offered by your
appliance.
Please preserve this booklet carefully. It may be useful in
future, either to yourself or to others in the event that doubts
should arise relating to its operation.
This appliance must be used only for the task it has explicitly
been designed for, that is for cooking foodstuffs. Any other
form of usage is to be considered as inappropriate and
therefore dangerous.
The manufacturer declines all responsibility in the event of
damage caused by improper, incorrect or illogical use of the
appliance.

4
IMPORTANT SAFETY PRECAUTIONSAND RECOMMENDATIONS
IMPORTANT: This appliance is designed and manufactured
solely for the cooking of domestic (household) food and is
not suitable for any non domestic application and therefore
should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used
within a non domestic environment i.e. a semi commercial,
commercial or communal environment.
Read the instructions carefully before installing and using
the appliance.
• This appliance has been designed and manufactured in compliance
with the applicable standards for the household cooking products
and it fullls all the safety requirements shown in this manual,
including those for surface temperatures.
Some people with sensitive skin may have a more pronounced
temperature perception with some components although these
parts are within the limits allowed by the norms.
The complete safety of the appliance also depends on the correct
use, we therefore recommend to always pay a extreme attention
while using the product, especially in the presence of children.
• After having unpacked the appliance, check to ensure that it is not
damaged and that the oven door closes correctly.
In case of doubt, do not use it and consult your supplier or a
professionally qualied technician.
• Packingelements(i.e.plasticbags,polystyrenefoam,nails,packing
straps, etc.) should not be left around within easy reach of children,
as these may cause serious injuries.
• Some appliances are supplied with a protective lm on steel and
aluminium parts. This lm must be removed before using the
appliance.
• IMPORTANT: The use of suitable protective clothing/gloves is
recommended when handling or cleaning this appliance.
• Do not attempt to modify the technical characteristics of the
appliance as this may become dangerous to use. The manufacturer
declines all responsibility for any inconvenience resulting from the
inobservance of this condition.

5
• CAUTION: this appIiance must only be installed in a permanently
ventilated room in compliance with the applicable regulations.
• Do not operate your appliance by means of an external timer or
separate remote-control system.
• Do not carry out cleaning or maintenance operations on the
appliancewithout havingpreviously disconnecteditfrom theelectric
power supply.
• WARNING: Ensure that the appliance is switched off before
replacing the oven lamp to avoid the possibility of electric shock.
• Do not use a steam cleaner because the moisture can get into the
appliance therefore making it unsafe.
• Do not touch the appliance with wet or damp hands (or feet).
• Do not use the appliance whilst in bare feet.
• If you should decide not to use this appliance any longer (or
decide to substitute another model), before disposing of it, it is
recommended that it be made inoperative in an appropriate manner
in accordance to health and environmental protection regulations,
ensuring in particular that all potentially hazardous parts be made
harmless, especially in relation to children who could play with
unused appliances.
• The various components of the appliance are recyclable. Dispose
of them in accordance with the regulations in force in your country.
If the appliance is to be scrapped, remove the power cord.
• After use, ensure that the knobs are in the off position.
• Children less than 8 years of age shall be kept away unless
continuously supervised.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
• Themanufacturerdeclinesallliabilityforinjurytopersonsordamage
to property caused by incorrect or improper use of the appliance.

6
• WARNING: During use the appliance and its accessible parts
become hot; they remain hot for some time after use.
– Care should be taken to avoid touching heating elements (on
the hob and inside the oven).
– The door is hot, use the handle.
– To avoid burns and scalds, young children should be kept
away.
• Make sure that electrical cables connecting other appliances in
the proximity of the cooker cannot come into contact with the hob
or become entrapped in the oven door.
• WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in re. NEVER try to extinguish a re
with water, but switch off the appliance and then cover ame e.g.
with a lid or a re blanket.
• WARNING: Danger of re: do not store items on the cooking
surfaces.
• WARNING: When correctly installed, your product meets all
safety requirements laid down for this type of product category.
However special care should be taken around the rear or the
underneath of the appliance as these areas are not designed or
intended to be touched and may contain sharp or rough edges,
that may cause injury.
• FIRST USE OF THE OVEN - it is advised to follow these
instructions:
– Furnish the interior of the oven as described in the chapter
“CLEANING AND MAINTENANCE”.
– Switch on the empty oven on max to eliminate grease from the
heating elements.
– Disconnect the appliance from the electrical power supply, let
the oven cool down and clean the interior of the oven with a
cloth soaked in water and neutral detergent; then dry carefully.
• CAUTION: Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.

7
• Donotlinetheovenwallsorbasewithaluminiumfoil.Donotplace
baking trays or the drip tray on the base of the oven chamber.
• Do not cover the hob with aluminium foils.
• FIRE RISK! Do not store ammable material in the oven or in the
storage compartment.
• Always use oven gloves when removing the shelves and food
trays from the oven whilst hot.
• Do not hang towels, dishcloths or other items on the appliance or
its handle – as this could be a re hazard.
• Clean the oven regularly and do not allow fat or oils to build up in
the oven base or tray. Remove spillages as soon as they occur.
• Do not stand on the cooker or on the open oven door.
• Always stand back from the appliance when opening the oven
door to allow steam and hot air to escape before removing the
food.
• SAFE FOOD HANDLING: Leave food in the oven for as short
a time as possible before and after cooking. This is to avoid
contamination by organisms which may cause food poisoning.
Take particular care during warmer weather.
• WARNING: Take care NOT to lift the cooker by the door handle.
• CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
• The appliance must not be installed behind a decorative door in
order to avoid overheating.
• The oven accessories (e.g. oven wire rack) must be tted
correctly as indicated at page 28.
• If the power supply cable is damaged, it must be replaced only
by an authorized service agent in order to avoid a hazard.

8
ENERGY LABELLING/ECODESIGN
• Commission delegated regulation (EU) No 65/2014 (supplementing Directive 2010/30/EU
of the European Parliament and of the Council).
• Commission regulation (EU) No 66/2014 (implementing Directive 2009/125/EC of the
European Parliament and of the Council).
Reference to the measurement and calculation methods used to establish compliance with
the above requirements:
• Standard EN 60350-1 (electric ovens).
• Standard EN30-2-1 (hobs: gas red burners).
USE OF THE APPLIANCE, ENERGY SAVING TIPS
OVEN
• Check the oven door always closes properly and the door gasket is clean and in order.
During use, open the oven door only when strictly necessary to avoid heat losses (for
some functions it may be necessary to use the oven with the door half-closed, check
the oven operating instructions).
• Turn off the oven 5-10 minutes before the end of the theoretical cooking time to
recuperate the stored heat.
• We recommend using oven proof dishes and adjusting the oven temperature during
cooking if necessary.
HOB
GAS FIRED BURNERS
• It is important that the diameter of the pot be suitable to the size of the burner so as
not to compromise the high output of the burners and therefore energy waste. A small
pot on a large burner does not give you a boiling point in a shorter amount of time
since the capacity of heat absorption of a liquid mass depends on the volume and the
surface of the pot.
• Avoid keeping a burner on without something on it (without pot).

9
GAS BURNERS
1. Auxiliary burner (A) 1,00 kW
2. Semi-rapid burner (SR) 1,75 kW
3. Triple-ring burner (TR) 4,00 kW
1 - COOKING HOB
Fig. 1.1
1
2 2
3
Notes:
• The electric ignition is incorporated in the knobs.
• The appliance has a safety valve system tted, the ow of gas will be stopped if and
when the ame should accidentally go out.
CAUTION:
If the burner is accidentally extinguished, turn the gas off at the control knob and wait at
least 1 minute before attempting to relight.
CAUTION:
Gas hobs produce heat and humidity in the environment in which they are installed.
Ensure that the cooking area is well ventilated by opening the natural ventilation grilles or
by installing an extractor hood connected to an outlet duct that vents to the outside.
CAUTION:
If the hob is used for a prolonged time it may be necessary to provide further ventilation
by opening a window or by increasing the suction power of the extractor hood if tted and
vented to the outside.

10
12345678
910
A
Controls description
1. Front right burner control knob
2. Rear right burner control knob
3. Rear left burner control knob
4. Front left burner control knob
5. Conventional oven temperature knob (Top oven)
6. Conventional oven function selector knob (Top oven)
7. Fan oven switch and temperature knob (Bottom main oven)
8. Electronic programmer (main oven only)
Pilot lamps:
9. Main oven temperature light
10. Conventional oven temperature light
2 - CONTROL PANEL
Fig. 2.1
Please note: This appliance incorporates a safety cooling fan which you will hear operating
whenever the oven or grill is being used.
The cooling fan may even run on after the appliance has been switched off.
The duration of this time is dependent on several factors, including previous cooking
temperature, duration and ambient temperature. Times in excess of 30 minutes are not
uncommon.

11
3 - USE OF THE HOB BURNERS
Caution!
The cooking hob becomes very hot
during operation.
Keep children well out of reach.
N.B. When the cooker is not being
used, set the gas knobs to their closed
positions.
GAS BURNERS
Gas ow to the burners is adjusted by
turning the knobs (illustrated in g. 3.1)
which control the safety valves.
Turning the knob, so that the indicator line
points to the symbols printed on the panel,
achieves the following functions:
- symbol closed valve
- symbol maximum
aperture or ow
- symbol minimum
aperture or ow
√The maximum aperture position
permitsrapidboilingofliquids,whereas
the minimum aperture position allows
slower warming of food or maintaining
boiling conditions of liquids.
√ To reduce the gas ow to minimum
rotate the knob further anti-clockwise
to point the indicator towards the small
ame symbol.
√Other intermediate operating
adjustments can be achieved by
positioning the indicator between the
maximum and minimum aperture
positions, and never between the
maximum aperture and closed
positions.
Fig. 3.1
Fig. 3.2
Caution!
Do not cover the hob with aluminium
foils.
NOTE:
The knob and symbols may vary.

12
DEEP FAT FRYING
For safety purposes when deep fat frying,
do not ll the pan more than one third full
of oil.
DO NOT cover the pan with a lid and DO
NOT leave the pan unattended.
In the unfortunate event of a re, leave
the pan where it is and turn off the control
knobs.
Place a damp cloth or lid over the pan to
smother the ames. Leave the pan to cool
for at least 30minutes before moving the
pan.
DO NOT USE WATER ON THE FIRE.
LIGHTING THE BURNERS
To ignite the burner, the following
instructions are to be followed:
1. Press in the corresponding knob and
turn counter-clockwise (g. 3.2) to the
full ame position marked by the
symbol (g. 3.1); hold the knob in until
the ame has been lit.
In the case of a mains failure light the
burner with a match or lighted taper.
2. Wait for a few seconds after the gas
burner has been lit before letting go of
the knob (valve activation delay).
3. Adjust the gas valve to the desired
position.
If the burner ame should go out for some
reason, the safety valve will automatically
stop the gas ow.
To re-light the burner, return the knob to the
closed position, wait for at least 1
minute and then repeat the lighting
procedure.
If your local gas supply makes it difcult
to light the burner with the knob set to
maximum, set the knob to minimum and
repeat the operation.
CHOICE OF THE BURNER
On the control panel, near every knob
there is a diagram that indicates which
burner is controlled by that knob.
The suitable burner must be chosen
according to the diameter and the capacity
used.
The burners and pans must be used in
accordance with the following instructions:
DIAMETERS OF PANS WHICH MAY
BE USED ON THE BURNERS
BURNERS MINIMUM MAXIMUM
Auxliliary 12 cm 14 cm
Semi-rapid 16 cm 24 cm
Triple-ring 26 cm 28 cm
Wok max 36 cm
do not use pans with concave or
convex bases
Fig. 3.3
It is important that the diameter of the pot
be suitable to the potentiality of the burner
so as not to compromise the high output
of the burners and therefore energy waste.
Asmall pot on a large burner does not give
you a boiling point in a shorter amount of
time since the capacity of heat absorption
of a liquid mass depends on the volume
and the surface of the pot. Too large a
pot can cause damage to the burner and
surrounding hob area.
CAUTION: Make sure the pans are central
to the burner for maximum stability and
greater efciency.
Make sure the pans are not in contact with
the control knobs, otherwise the ame
could overheat the knobs and permanently
damage them.

13
CORRECT USE OF THE TRIPLE-RING BURNER
Only at bottom pans of the correct size are to be placed on the pan support above the
Triple-ring burner.
When using a WOK, the supplied wok stand must be placed onto the pan stand to avoid
any faulty operation of the triple-ring burner (g. 3.4a). The wok should not be placed
directly onto the pan support without the use of the supplied wok stand (g. 3.4b).
IMPORTANT:
When using the wok stand it MUST ONLY BE PLACED over the pan support for the triple-
ring burner (g.3.4a). Under no circumstances should the wok stand be placed under
the pan supports (gs 3.5a - 3.5b). Incorrect placement of the wok stand in this manner
may impinge the ame resulting in incomplete combustion and give rise to harmful levels
of Carbon Monoxide (CO).
WRONG
Fig. 3.4b
Fig. 3.5a Fig. 3.5b
WRONG WRONG
CORRECT
Fig. 3.4a

14
OPERATING PRINCIPLES
Heating and cooking in the conventional
oven are obtained:
a. by natural convection
The heat is produced by the upper and
lower heating elements.
b. by radiation
The heat is irradiated by the infra red grill
element.
Before introducing the food, preheat the
oven to the desired temperature.
For a correct preheating operation, it is
advisable to remove the tray from the oven
and introduce it together with the food,
when the oven has reached the desired
temperature.
Check the cooking time and turn off the
oven 5 minutes before the theoretical time
to recuperate the stored heat.
GENERAL FEATURES
2differentthermostatic controlfunctions are
availabletosatisfyallcookingrequirements,
provided by 3 heating elements:
• Top element
• Bottom element
• Grill element
NOTE: Upon rst use, it is advisable
to operate the oven at the maximum
temperature (thermostat knob on position
250) for 60 minutes in the position and
for another 15 minutes in the , mode
in order to eliminate any traces of grease
from the electrical elements.
Clean the oven and accessories with warm
water and washing-up liquid.
Smells and fumes produced during this
burn off process are not a cause of alarm.
Adequate ventilation should however be
provided in the room where the appliance
is installed, e.g. by opening a window.
Attention: The oven door becomes
very hot during operation.
Keep children away.
ATTENTION - MOST IMPORTANT
Pay special attention not to touch the
hot heating element inside the oven
cavity.
WARNING:
The door is hot, use the handle.
During use the appliance becomes hot. Care should be taken to avoid touching
heating elements inside the oven.
Do not line the oven walls or base with aluminium foil. Do not place baking trays
or the drip tray on the base of the oven chamber.
4 - TOP CONVENTIONAL ELECTRIC OVEN

15
Fig. 4.1 Fig. 4.2
TEMPERATURE KNOB (g. 4.2)
This only sets the cooking temperature but does not switch the oven on.
Rotate clockwise until the required temperature is reached (from 50°C to the maximum
position, 250°C).
The light above the knob will illuminate when the oven is switched on and turns off when
the oven reaches the correct temperature.
The light will cycle on and off during cooking in line with the oven temperature.
FUNCTION SELECTOR KNOB (g. 4.1)
Rotate the knob clockwise to set the oven for one of the following functions:
OVEN LIGHT
By setting the knob to this position, only the oven light comes on.
The light remains on whilst any of the cooking modes are selected.

16
TRADITIONAL CONVECTION COOKING
The upper and lower heating elements are switched on.
The heat is diffused by natural convection and the temperature must be set between 50°C
and 250° C.
It is necessary to preheat the oven before adding the foods to be cooked.
Recommended for:
For foods which require the same cooking temperature both internally and externally, i. e.
roasts, spare ribs, meringue, etc.
ECO FUNCTION (ENERGY SAVING)
The upper and lower heating elements are switched on.
The heat is diffused by natural convection.
This function reduces the appliance’s energy consumption, it is therefore particularly
benecial for the gentle cooking of small quantities of food on a single shelf.
It is not necessary to preheat the oven and use with the oven door closed.
Cooking times may be longer than standard functions.
Do not use this function to preheat the oven.
Recommended for:
Foods that require gentle cooking. To keep foods hot after cooking. To slowly heat already
cooked foods.
GRILLING
The infra-red heating element is switched on.
The heat is diffused by radiation.
Use with the oven door closed and the temperature knob to 200°C maximum.
Leave to warm up for approximately 5 minutes with the door closed.
Place the food inside positioning the rack as near as possible to the grill.
Insert the drip pan under the rack to collect the cooking juices.
Recommended for:
Intense grilling, browning, cooking au gratin and toasting etc.
Grill with the oven door closed.
Do not grill for longer than 30 minutes at any one time (Grilling for longer than
the reccomended time may mean the appliance overheats).
Caution: The oven door becomes very hot during operation. Keep children well
out of reach.

17
5 - BOTTOM MAIN OVEN
Attention: The oven door becomes
very hot during operation.
Keep children away.
SWITCH AND TEMPERATURE
SELECTOR
Turn the selector knob (g. 5.1) to the
required function.
0OFF - as per g. 5.1
The oven light is switched on.
The fan operates without the
heating element, this function
can be used for defrosting.
50-250°C The oven light is switched on.
The oven temperature can be
set between 50°C - 250°C.
The set temperature has been
reachedwhenthetemperature
indicator light goes out.
Several different meals may
be cooked simultaneously
on various shelves, as the
heated air circulates evenly
throughout the oven.
Thehot airsystemcooks more
quickly than conventional
static system, therefore the
temperature should be set
10°C - 20°C below the values
recommended in your recipe
books.
The oven door may be opened
briey while cooking to check
on the food, as any heat
losses are quickly recovered
when the door is closed.
WARNING:
The door is hot, use the handle.
During use the appliance becomes hot.
Care should be taken to avoid touching
heating elements inside the oven.
Fig. 5.1
COOKING WITH FORCED AIR
Preheat the oven at the desired
temperature, the set value is reached
when the temperature indicator light
goes off.
For a correct preheating it is advisable
to remove the shelves from the oven
and reintroduce then, with the food,
when the oven has reached the desired
temperature.
Fan cooking is more economical and
quicker than cooking in a conventional
oven.
The moving hot air surrounds the food
and penetrates it more quickly than in a
conventional oven.
Cooking yeast based dishes is also
speeded up this way. If the oven door has
been opened, the oven quickly regains its
temperature once the door is closed.

18
6 - OVEN TEMPERATURE GUIDE
Cooking process Oven heat Gas mark Electric oven temperature
°C °F
Keeping food hot,
milk puddings very cool ½120 250
Egg custards cool 1 140 275
Rich fruit cakes,
braising cool 2 150 300
Low temperature
roasting, shortbread moderate 3 160 325
Victoria sandwich,
plain fruit cake,
baked sh moderate 4 180 350
Small cakes, choux
pastry fairly hot 5 190 375
Short pastry, Swiss
rolls, soufés fairly hot 6 200 400
High temperature
roasting, aky
pastry, scones hot 7 220 425
Puff pastry, bread very hot 8 230 450
Small puff pastries,
browning cooked
foods very hot 9 240 475
These temperatures relate to the centre oven temperature.
Remember to use ovenproof dishes and to adjust the oven temperature during cooking if
necessary.
NOTE: Reduce the oven temperature by 10 – 20°C for fan assisted ovens.
For dishes that take over an hour to cook, reduce the cooking time by 10 minutes per
hour.

19
The electronic programmer is a device which groups together the following functions:
• 24 hours clock with illuminated display
• Timer (up to 23 hours and 59 minutes)
• Program for automatic oven cooking (bottom main oven only)
• Program for semi-automatic oven cooking (bottom main oven only)
Description of the buttons:
Timer
Cooking time
End of cooking time
Simultaneously: Switching to
manual and program reset.
To increase the numbers on
the digital display
To decrease the numbers on
the digital display.
Description of the illuminated
symbols:
Aashing - Programmer in
automatic position but not
programmed
Ailluminated - Programmer in
automatic position with program
inserted.
Automatic cooking taking place
Timer in operation
and A - ashing - Program error.
(The time of day lies between the
calculated cooking start and end
time).
Note:
Select a function by the respective button
and, in 5 seconds, set the required time
with the / buttons (“one-hand”
operation).
After a power cut the display resets to
zero and cancels the set programs.
Caution: If the electricity supply is cut
off (the display numbers will ash), the
clock will reset and all the programs
entered will be cancelled.
A
Fig. 7.1
7 - ELECTRONIC PROGRAMMER (BOTTOM MAIN OVEN ONLY)

20
SETTING TIME OF DAY (g. 7.2)
The programmer is provided with an
electronic clock with luminous gures
showing the hour and minutes.
The rst time the oven is connected up to
the electricity supply and after a power cut,
three zeroes will ash on the programmer
display.
To adjust the time, the two buttons
must be pressed simultaneously and then
the button or until the correct time
is set.
Setting speed automatically increases if
you keep the setting buttons pressed.
MANUAL OPERATION
To use the oven manually, i.e. without the
programmer, you must cancel the ashing
Aby pressing the two buttons
simultaneously (the letter Awill go out and
the symbol will come on).
CANCELLING A PROGRAMME
If the letter A is not ashing (which means
that a cooking program has already been
set) by pressing the two buttons
simultaneously you will cancel the program
and switch to manual.
If the oven is on, you must switch it off
manually.
Fig. 7.2 Fig. 7.3
