Kenwood DMX129BT User manual

© 2023 JVCKENWOOD Corporation
3-12, Moriyacho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, Japan
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best performance from your new
receiver.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space
provided below. Refer to the model and serial numbers whenever you call upon your KENWOOD dealer for information or
service on the product.
Model DMX129BT Serial number
US Residence Only
Register Online
Register your KENWOOD product at www.kenwood.com/usa/
DMX129BT
MONITOR WITH RECEIVER
Quick Start Guide
ÉCRAN AVEC RÉCEPTEUR
Guide de démarrage rapide
MONITOR CON RECEPTOR
Guía de inicio rápido
Trim plate
Plaque de garniture
Placa de montaje
Model name indication position
See “Removing the trim plate” (P.13)
Position d’indication du nom du modèle
Reportez-vous à la section « Retrait de la
plaque de garniture »(P.29)
Posición de la indicación del nombre del
modelo
(P.45)
•For detailed operations and information, refer to the INSTRUCTION MANUAL
on the following website:
•Pour plus d’informations et de détails sur les opérations, reportez-vous au
MODE D’EMPLOI sur le site Internet suivant:
•Para obtener información y detalles sobre las operaciones, consulte el
MANUAL DE INSTRUCCIONES en el siguiente sitio web:
<https://www.kenwood.com/cs/ce/>
Consulte “Retirada del marco”
B5K-1096-00b EN (K)

2
Contents Before use
How to read this manual
• The panels shown in this guide are examples used to
provide clear explanations of the operations. For this
reason, they may be dierent from the actual panels.
• In operation procedures, bracket shape indicates the
key or button you should control.
< >: indicates the name of panel buttons.
[ ]: indicates the name of touch keys
! This symbol on the product means there
are important operating and maintenance
instructions in this manual.
Be sure to carefully read instructions in this
manual.
Precautions
#WARNING
Ñ To prevent injury or re, take the following
precautions:
• To prevent a short circuit, never put or leave any
metallic objects (such as coins or metal tools) inside
the unit.
• Do not watch or x your eyes on the unit’s display
when you are driving for any extended period.
• If you experience problems during installation,
consult your KENWOOD dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories, check with
your KENWOOD dealer to make sure that they work
with your model and in your area.
• You can select a language to display menus, audio
le tags, etc. See Getting Started (P.3)
• The Radio Data System or Radio Broadcast Data
System feature won’t work where the service is not
supported by any broadcasting station.
Ñ Protecting the monitor
• To protect the monitor from damage, do not operate
the monitor using a ballpoint pen or similar tool with
the sharp tip.
Ñ Cleaning the Unit
If the front panel of this unit is stained, wipe it with
a dry soft cloth such as a silicon cloth. If the front
panel is stained badly, wipe the stain o with a cloth
moistened with neutral cleaner, then wipe it again
with a clean soft dry cloth.
! CAUTION
• Applaying spray cleaner directly to the unit may aect
its mechanical parts. Wiping the front panel with a hard
cloth or using a volatile liquid such as thinner or alcohol
may scratch the surface or erase screened print.
Ñ How to reset your unit
If the unit or the connected unit fails to operate
properly, reset the unit.
Reset button
Before use................................................................................. 2
How to read this manual................................................................................... 2
Precautions ................................................................................................................ 2
Getting Started....................................................................... 3
Clock settings...........................................................................................................3
Basics .......................................................................................... 4
Functions of the Buttons on the Front Panel...................................... 4
Common operations...........................................................................................4
HOME screen descriptions ..............................................................................4
Source control screen.........................................................................................4
Radio........................................................................................... 5
Radio Basic Operation.........................................................................................5
Presetting stations ................................................................................................5
Radio Setup................................................................................................................ 5
USB .............................................................................................. 6
Preparation................................................................................................................. 6
Playback operations............................................................................................. 6
iPhone........................................................................................ 7
Preparation................................................................................................................. 7
Playback operations............................................................................................. 7
External Components.......................................................... 8
Using external audio/video players........................................................... 8
Rear view camera...................................................................................................8
Reverse with ATT....................................................................................................8
Bluetooth .................................................................................. 9
Register your smartphone to the unit .....................................................9
Receive a phone call............................................................................................ 9
Make a phone call..................................................................................................9
Playing Bluetooth Audio Device................................................................10
Controlling Audio ................................................................10
Controlling General Audio.............................................................................10
Installation.............................................................................. 11
Before Installation................................................................................................11
Installing the unit.................................................................................................12
About this Unit......................................................................16
More information.................................................................................................16
Note for specications......................................................................................16
Copyrights................................................................................................................17

parking guidelines (P.8)
3
English |
Getting Started
1 Turn the ignition key of your car to ACC.
The unit is turned on, please read the warning and
press “Agree” to enter the screen.
2 Press the <8MENU> button.
3 Touch [ ].
4 Touch the corresponding key and set the value.
[System]
[Beep Tone]
Activates or deactivates the key-touch tone.
“ON” (Default), “OFF”
[Language]
Select the language used for the control screen
and setting items. Default is “English”.
[Time/Date]
Adjust the clock time. (P.3)
[Clock Mode]
Select the time display format.
[12hr] (Default) / [24hr]
[Parking Guidelines]
You can display parking guidelines to enable
easier parking when you shift the gear to the
reverse (R) position. Default is “ON”.
[Guidelines SETUP]
If you select [ON] for [Parking Guidelines], you can
adjust the parking guidelines. See To adjust the
.
[Reverse with ATT (-20dB)]
When the gear is shifted to the reverse (R)
position, the volume of the device is adjusted.
Default is “ON”. See To adjust the Reverse with
ATT (P.8).
[System Reset]
Touch [System Reset] and then touch [YES] to set
all the settings to the initial default settings.
[Bluetooth]
Displays the Bluetooth Settings screen. (P.9)
[Screen]
[Dimmer]
Select the dimmer mode.
“High” (Default) / “Mid” / “Low”
[Demo]
Select the demonstration mode. Default is “ON”.
[Information]
Displays the software version and model number
of this unit
5 Touch [6].
Clock settings
Ñ Synchronizing the clock time with FM
RBDS
Activate [RBDS Clock Sync].
See Radio Setup (P.5).
Ñ Adjusting the clock manually
✎NOTE
• Deactivate [RBDS Clock Sync] before adjusting the
clock.
1 Press the <8MENU> button.
2 Touch [ ].
3 Touch [System].
4 Touch [Time/Date].
Clock screen appears.
5 Touch [R] or [S] to set the clock time.
6 Touch [6].

4
Basics
Basics
Functions of the Buttons on the
Front Panel
1
2
3
4
5
6
1Remote Sensor
• Receives the remote control signal.
28MENU
• Displays the HOME screen. (P.4)
• Press and hold second turns the power o.
• When the power o, turns the power on.
3AUD
• Displays the Audio screen.* (P.10)
* The Audio screen is not displayed during SETUP
screen or on the list screen etc,
4+ , – (Volume)
• Adjusts volume. The volume will go up until 15
when you keep pressing [ + ].
5MUTE/ DISP OFF (Display o)
• Mutes/restores the sound.
• Press and hold turns the screen o.
When the screen is o, touch the display to turn
on the screen.
6Reset
• If the unit or the connected unit fails to operate
properly, the unit returns to factory settings
when this button is pressed.
Common operations
Ñ Turning on the power
1 Press the <8MENU> button.
Ñ Turning o the power
1 Press and hold the <8MENU> button.
HOME screen descriptions
1 Press the <8MENU> button.
HOME screen appears.
2
5
3
6
4
71
1Clock display
Touch to displays the Clock screen.
2Switches to the radio broadcast. (P.5)
3[USB]
Plays les on a USB device. (P.6)
[iPhone]
Plays an iPhone. (P.7)
• When iPhone is connected.
4Switches to an external component connected to
the AV-IN input terminal. (P.8)
5Displays the Hands Free screen. (P.9)
6Plays a Bluetooth audio player. (P.10)
7Displays the SETUP screen. (P.3)
Source control screen
1
1[
] : Returns to previous screen.
[ ] : Displays the Audio screen. (P.10)
[Mirroring]
Displays the Mirroring screen.
When android device with “Mirroring OB for
KENWOOD” application installed is connected.

5
English |
Radio
Radio
Radio Basic Operation
1 Press the <8MENU> button.
2 Touch [Radio].
Ñ Source control screen
2
1
3
1Displays the information of the current station:
PS name, Frequency, PTY Genre, Indicator Items
2[FM] : Switches the FM band.
“FM1”, “FM2”, “FM3”
[AM] : Switches the AM band.
“AM1”, “AM2”
[E][F] : Tunes in a station with good
reception automatically.
Touch and hold to switch to the next
frequency manually.
[ ] : Displays the Radio Setup screen. (P.5)
3Recalls the memorized station.
When touched for 2 seconds, stores the current
receiving station in memory.
Presetting stations
Ñ Auto memory
You can preset 6 stations for the current band (FM1/
FM2/FM3/AM1/AM2).
1 Touch [FM] or [AM] to select the band.
2 Touch [ ].
3 Touch [Auto Store].
The local stations with the strongest signals are
found and stored automatically.
Ñ Manual memory
You can store the current receiving station in
memory.
1 Tune in to a station you want to preset.
2 Touch and hold [#] (#:1-6) in which you want to
store the station.
Ñ Recalling the preset station
1 Touch [#] (#:1-6).
Radio Setup
1 Touch [ ].
2 Set each item as follows.
[Auto Store]
Automatically searches and stores the 6 stations with
the strongest signals for the selected band.
“Auto Store” appears.
[Area]
“N.America” : AM/FM intervals: 10 kHz/200 kHz.
[RBDS] *1
Displays the RBDS Settings screen.
[TA]
Switches to the trac information automatically
when the trac bulletin starts. (TI indicator lights
up.)
“ON”, “OFF” (Default)
[RBDS Clock Sync]
Synchronizing the Radio Broadcast Data System
station time data and this unit’s clock.
“ON” (Default), “OFF”
[PTY]
Select a program type.
[PTY Seek]
Searches for a program by program type.
*1 FM only
3 Touch [6].

(P.6)
(P.6)
6
USB
USB
Preparation
Ñ Connecting a USB device
1 Remove the cap of the USB terminal.
2 Connect the USB device with the USB cable.
The unit reads the device and playback starts.
Ñ To disconnect the USB device:
1 Press the <8MENU> button.
2 Touch a source other than [USB].
3 Detach the USB device.
Ñ Usable USB device
This unit can play MPEG1/ MPEG2/ MPEG4/ H.264/
MKV/ MP3/WMA/ AAC/ WAV/ FLAC/ OGG files stored
in a USB mass storage class device. (P.16)
Playback operations
Ñ Control the music you are listening to on
the source control screen.
1
4
3
2
1The jacket of the currently playing le is displayed.
2Displays the information of the current le.
3Playing time/File number
Play time bar : For conrmation of current playing
position.
4[ ] : Selects Random playback mode.
[ ] : Selects Repeat playback mode.
[U], [H] : Plays or pauses.
[E], [F] : Searches the previous/next
content.
Touch and hold to fast forward or fast
backward.
[1] : Searches le.
Ñ For Video playback
1 When the operation buttons are not displayed
on the screen, touch the display.
5
6
5[ ] : You can adjust image quality in video
screen.
[INITIALIZE] : To clear the adjustment.
6[U], [H] : Plays or pauses.
[E], [F] : Searches the previous/next
content.
Touch and hold to fast forward or fast
backward.
[1] : Searches le.
[NORMAL]/[16:9]/[4:3] : Select a screen mode.
Ñ Selecting a track in a list (Searches le)
1 Touch [1].
2 Select whether you search by audio files [ ],
video files [ ].
3 Touch [ ] to moves to the upper hierarchy.
4 Touch the desired folder.
When you touch a folder its contents are displayed.
• Touch [6] to moves to the upper hierarchy.
5 Touch desired item from the content list.
Playback starts.
✎NOTE
• The source control screen appears when you touch
[6] at the top hierarchy.

(P.7)
7
English |
iPhone
iPhone
Preparation
Ñ Connecting iPhone
• For details about connecting iPhone, see page
15 .
1 Remove the cap of the USB terminal.
2 Connect the iPhone.
The unit reads the device and playback starts.
Ñ To disconnect the iPhone
1 Press the <8MENU> button.
2 Touch a source other than [iPhone].
3 Detach the iPhone.
Ñ Connectable iPhone
The following models can be connected to this unit.
Made for
• iPhone 14 Pro Max
• iPhone 14 Pro
• iPhone 14 Plus
• iPhone 14
• iPhone 13 Pro Max
• iPhone 13 Pro
• iPhone 13
• iPhone 13 mini
• iPhone 12 Pro Max
• iPhone 12 Pro
• iPhone 12
• iPhone 12 mini
• iPhone SE (2nd
generation)
• iPhone 11 Pro Max
• iPhone 11 Pro
• iPhone 11
• iPhone XS Max
• iPhone XS
• iPhone XR
• iPhone X
• iPhone 8 Plus
• iPhone 8
• iPhone 7 Plus
• iPhone 7
• iPhone SE
• iPhone 6s Plus
• iPhone 6s
✎NOTE
• If you start playback after connecting the iPhone,
the music that has been played by the iPhone is
played rst.
• Cap the USB terminal whenever not using.
Playback operations
Ñ Control the music you are listening to on
the source control screen.
1
4
3
2
1Artwork (Shown if the track contains artwork)
2Displays the information of the current le.
3Playing time/File number
Play time bar : For conrmation of current playing
position.
4[ ] : Selects Random playback mode.
[ ] : Selects Repeat playback mode.
[U], [H] : Plays or pauses.
[E], [F] : Searches the previous/next
content.
Touch and hold to fast forward or fast
backward.
[1] : Searches content.
Ñ Selecting a content in a list
1 Touch [1].
2 Touch desired item.
When you touch a category its contents are
displayed.
3 Touch desired item from the content list.
Playback starts.
• Touch [6] to moves to the upper hierarchy.
✎NOTE
• The source control screen appears when you touch
[6] at the top hierarchy.

8
External Components
External Components
Using external audio/video players
Ñ Starting playback
1 Connect an external component to the AV-IN
input terminal. (P.14)
2 Press the <8MENU> button.
3 Touch [AV-IN].
4 Turn on the connected component and start
playing the source.
Ñ For Video playback
1 When the operation buttons are not displayed
on the screen, touch the display.
1
1[ ] : You can adjust image quality in video
screen.
[INITIALIZE] : To clear the adjustment.
✎NOTE
• When the picture from the rear view camera is
displayed on the AV-IN screen, the picture output
from the Visual Output terminal disappears.
Rear view camera
To use a rear view camera, the REVERSE lead
connection is required. For connecting a rear view
camera. (P.14)
Ñ Displaying the picture from the rear
view camera
The rear view screen is displayed when you shift the
gear to the reverse (R) position.
• The rst touch removes the Caution, and the
second touch closes the Camera Screen.
Ñ To adjust the parking guidelines
✎NOTE
• Install the rear view camera in the appropriate
position according to the instruction manual
supplied with the rear view camera.
• When adjusting the parking guidelines, make sure
to apply the parking brake to prevent the car from
moving.
1 Press the <8MENU> button.
2 Touch [ ].
3 Touch [System].
4 Touch [T] or [U] of [Parking Guidelines] and set
to [ON].
5 Touch [Guidelines SETUP].
6 Adjust the parking guidelines by selecting the
[ ] mark.
7 Adjusting the position of the selected mark.
A
B
C D
Make sure that lines A and B are horizontally
parallel, and that lines C and D are of the same
length.
✎NOTE
• Touch [Initialize] and then touch [Yes] to set all the
marks to their initial default position.
Reverse withATT（-20dB)
When the gear is shifted to the reverse (R) position,
the volume of the device is adjusted.
1 Press the <8MENU> button.
2 Touch [ ].
3 Touch [System].
4 Touch [Reverse with ATT].
5 Touch [T] or [U] set to [ON/OFF].
✎NOTE
• The setting value is ON (default)

9
English |
Bluetooth
Register your smartphone to the unit
You can use your Bluetooth smartphone when
paired to this unit.
1 Turn on the Bluetooth function on your
smartphone/cell-phone.
2 Search the unit (“DMX129BT”) from your
smartphone/cell-phone.
If a PIN code is required, enter the PIN code (“0000”).
• appears when the Bluetooth smartphone is
connected.
Ñ Disconnecting the device
• Turn o the Bluetooth function from your
smartphone/cell-phone.
• Turn o the ignition switch.
Receive a phone call
1 Touch [Û].
• [Ý] : Reject an incoming call.
Ñ Operations during a call
[Ý]Ending a call
[ ]Mute your voice
You can send tones by touching desired keys
on the screen.
• Touch [6] to close the window.
Switches the speaking voice output between
smartphone/cell-phone and speaker.
⿠Adjust the receiver volume
Press the <+> or <–> button.
Make a phone call
1 Press the <8MENU> button.
2 Touch [TEL].
3 See the table below for each operation method.
Call by entering a phone number
1) Enter a phone number with number keys.
2) Touch [Û].
Make a call
• Touch [ ] to delete the last entry.
Call using call records
1) Touch [ ].
2) Touch [ ] (Incoming Calls), [ ] (Outgoing
Calls), [ ] (Missed Calls).
3) Select the phone number from the list.
Make a call
Call using the phonebook
1) Touch [ ].
2) Select the name from the list.
Make a call
• [ ] : Updates the phonebook. Touch this
button after you have made a change
to the phonebook of your smartphone/
cell-phone.
Call Waiting
When you receive a new call while talking on the
phone:
1) Touch [ ] , the current call is put on hold and
you can answer the newly received call.
2) Each time you touch [ ], the caller will change
to the other one.
3) If you touch [ ] during call waiting, reject an
incoming call.
4) If you touch [ ], when someone is on hold, the
current call will end to be swtiched to the call
waitng on hold .
5) Touch [ ] mute your voice
Bluetooth

10
Controlling Audio
Playing Bluetooth Audio Device
1 Press the <8MENU> button.
2 Touch [Bluetooth Audio].
Ñ Source control screen
1
3
2
1Displays the information of the current le.
2Playing time/File number
Play time bar : For conrmation of current playing
position.
3[] : Selects Random playback mode.
[ ] : Selects Repeat playback mode.
[U], [H] : Plays or pauses.
[E], [F] : Searches the previous/next
content.
Touch and hold to fast forward or fast
backward.
[1] : Searches le. (P.10)
✎NOTE
• Operations and display indications may dier
according to their availability on the connected
device.
Ñ Selecting a content in a list
1 Touch [1].
2 Touch desired item.
When you touch a category its contents are
displayed.
3 Touch desired item from the content list.
Playback starts.
• Touch [6] to moves to the upper hierarchy.
✎NOTE
• The source control screen appears when you touch
[6] at the top hierarchy.
You can adjust various settings such as audio
balance or subwoofer level.
1 Press the <AUD> button.
2 See the below for each operation method.
Controlling General Audio
1 Press the <AUD> button.
2 Touch [Fader / Balance].
3 Set each item as follows.
[Fader Balance]
Balance
[T] [U]
Adjust the left and right volume
balance.
15 (left) to 15 (right)
Fader
[R] [S]
Adjust the front and rear volume
balance.
15 (front) to 15 (rear)
[INITIALIZE] To clear the adjustment.
[Listening Position]
[.]Select a listening position from “Front
Left”, “Front All”, “Front Right”, and
“Middle”.
[INITIALIZE] To clear the adjustment.
Bluetooth Controlling Audio
