Kenwood NEXEDGE NX-700 series User manual

Kenwood U.S.A. Corporation
Land Mobile Radio Division Price Guide
Two

Way Radio Express Products List (EPL) 3657
May 2011
Page 1 of 3 NX-700!800
MODEL LIST EPL
NX-700K 136-174 MHz 30W, 512 CH / 128 Zone 725.00 543.76
NX-700HK
136-174 MHz 50W, 512 CH / 128 Zone 850.00 637.50
NX-800K 450-520 MHz 30W, 512 CH / 128 Zone 725.00 543.76
NX-800K2
400-470 MHz 30W, 512 CH / 128 Zone 725.00 543.76
NX-800HK
450-520 MHz 45W, 512 CH / 128 Zone 850.00 637.50
NX-800HK2
400-470 MHz 45W, 512 CH / 128 Zone 850.00 637.50
Programming Cost: $50.00
Installation Cost: $50.00 Dash Mount / $75.00 Remote Mount
All NX series mobiles include:
• Standard Microphone (KMC-35)
• Mounting Bracket
• DC Cable (KCT-23M)
• Blade Fuse
• Instruction Manual
• Premium Warranty: 3 Years*
* All Accessories / options: 1 Year
GENERAL FEATURES
• 30W / 50W (136-174 MHz) Models
• 30W / 45W (400-470, 450-520 MHz) Models
• 512 CH-GID / 128 Zones
• Dash & Remote Mount
• 14 Character Alphanumeric Aliases
• Backlit Dot Matrix LCD
• Function/Status LCD Icons
• Multi-Language Display
• Date & 12/24 Hour Time Clock
• Transmit/Busy/Call Alert/Warn LED
• On/Off Power Control
• 4 Up/Down Selectors
• 6 Front PF Keys
• Emergency/AUX Key
• 4W Speaker Audio
• DB-25 Accessory Connector
• 9 Programmable AUX I/Os
• 2 Programmable AUX Outputs
• KPG-111D Windows® FPU
• Flash Firmware Upgrading
• MIL-STD-810 C/D/E/F/G
• IP54/55 Water & Dust Intrusion
• PC Serial Interface
• SDM Manual Input
• Transparent Data Mode
• GPS Receiver Option
• VGS-1 Voice Guide
Voice & GPS Data Storage Option
DIGITAL – GENERAL
• NXDN®Digital Air Interface
• AMBE+2™ VOCODER
• 6.25 & 12.5 kHz Channels
• Over-the-Air Alias
• Over-the-Air Programming
• Paging Call
• Emergency Call
• All Group Call
• Status Messaging
• Remote Stun/Kill
• Remote Check
• Short & Long Data Messages
• GPS Location with Voice
• NXDN®Scrambler Included
DIGITAL CONVENTIONAL MODE
• 64 Radio Access Numbers (RAN)
• Individual & Group Selective Call
• Mixed FM/Digital Operation
• Conventional IP Networks
• Site Roaming
DIGITAL TRUNKING MODE
• Individual Private Call
• Group Call & Broadcast Call
• Telephone Interconnect
• Transmission Trunked Mode
• Message Trunked Mode
• Call Queuing with Priority
• Late Entry (UID & GID)
• 4 Priority Monitor ID’s
• Remote Group Add
• Failsoft Mode
MULTI-SITE IP NETWORKS
COMPATIBLE
• Individual Private Call
• Group Call & Broadcast Call
• Transmission Trunked Mode
SCAN
• Single Zone / Multi-Zone / List
Scan
• Dual Priority Scan (Conventional)
ANALOG MODES - GENERAL
• 25 & 12.5 kHz Channels
• Conventional & LTR® Zones
• FleetSync®/II, MDC-1200, DTMF
• QT / DQT & Two-Tone
(Conventional Zones Only)
• Voice Inversion Scrambler
• Analog Scrambler Board
Capability
FleetSync®/II (FM)
• PTT ID ANI / Caller ID
• Selective / Group Call
• Emergency, Status & Text
Messages
MDC-1200
• PTT ID ANI / Caller ID
• Emergency, Radio Check &
Inhibit
NX-700 / 800
NEXEDGE!VHF/UHF Digital & FM Analog Mobile Radios
* TX Power is derated at 490-512 MHz
NX-800K: 450-489 MHz (30 W)
490-512 MHz (25 W)
NX-800HK: 450-489 MHz (45 W)
490-512 MHz (40 W)

Kenwood U.S.A. Corporation
Land Mobile Radio Division Price Guide
Two

Way Radio Express Products List (EPL) 3657
May 2011
Page 2 of 3 NX-700!800
MOBILE INSTALLATION ACCESSORIES LIST EPL
KAP-2
Horn Alert/P.A. Relay Option 63.00 47.25
KCT-46
Ignition sense cable (plugs directly into mobile chassis ignition sense line) 13.70 10.28
KLF-2
Line Filter (suppresses alternator whine, 25dB, 25A max). 42.00 31.50
KMB-10
Key lock adapter 26.30 19.73
KRK-10
Remote Control Kit (a remote control cable (23 ft) is included) 105.00 78.75
KCT-23M
DC Cable (35-50W Dash mount; pos/neg. 10 ft. leads) 31.50 23.63
KCT-23M3
DC Cable (35-50W Remote mount; pos.23 ft.; neg. 3.3. ft. leads) 34.75 26.06
CONTROL STATION INSTALLATION ACCESSORIES LIST EPL
KMC-9C
Control Station Desktop Microphone (8-pin mod. plug) 86.00 64.50
KMB-24
Control Station Mounting Case for KPS-15 Power Supplies
(mobile mounting hardware included)
42.00 31.50
KPS-15
DC Switching Power Supply (117/230 VAC; 23A max. continuous, 25A peak) 173.00 129.75
MICROPHONES AND SPEAKERS LIST EPL
KMC-35 MIL-SPEC Standard electret mobile microphone (8-pin mod. plug) - same as supplied 52.50 39.38
KMC-36 MIL-SPEC Standard electret mobile microphone with 12 keypad (8-pin mod. plug) 94.50 70.88
KMC-9C Control Station Desktop Microphone (8-pin mod. plug) 86.00 64.50
KES-3 External speaker (compact low profile; black case; 3.5 mm phono plug-in) 44.25 33.19
KES-5 External speaker, 40W max input
Note:
requires KAP-2 (PA/HA unit) installed
61.25 45.94
FIRMWARE OPTIONS LIST EPL
KWD-P25C
P25 Flash upgrade; NX-200/300/700/800
Must order L-1663
Note
: KWD-P25C will be Kenwood factory installed only (units must be returned for upgrade)
792.00 594.00
SOFTWARE OPTIONS LIST EPL
KPG-150AP
NEXEDGE OTAP Manager Windows Software.
• License Includes 10 radios / 1 Serial Port*
• To add more radios/serial ports, you must contact Kenwood Systems Division
[1-800-TRUNKING]
550.00 412.50
OPTION MODULES LIST EPL
VGS-1
Voice Guide and Storage Unit
87.50 65.63

Kenwood U.S.A. Corporation
Land Mobile Radio Division Price Guide
Two

Way Radio Express Products List (EPL) 3657
May 2011
Page 3 of 3 NX-700!800
FleetSync®& NEXEDGE®AVL & MESSAGING LIST EPL
KAS-10
FleetSync® & NEXEDGE® AVL & Messaging Software
with NEXEDGE Trunking VoIP Dispatch
Note: Users can chose to operate Messaging, AVL or VoIP or all three if desired. Compatible with
Windows® XP, VISTA & 7 and Microsoft®MapPoint®2006/2009/2010 (certain format bitmap images
can be imported). Refer to KAS-10 product spec sheets and manuals for detials.
434.00 325.50
KGS-3
FleetSync® & NEXEDGE® AVL & Messaging Software (Windows®2000/XP
compatible),
Note: AVL operation /use is not required. Compatible with Microsoft®MapPoint®2004/2006
Software or certain type imported maps (purchase aftermarket separately)
Refer to KGS-3 spec sheet for detailed features & requirements.
347.00 260.25
GPS15XL-W
Garmin Internal GPS Receiver Board for FleetSync ® & NEXEDGE® AVL
Note:
• Conventional & LTR operation
• NEXEDGE® Conventional & Trunking operation
• Requires GA25 MCX GPS antenna
• Refer to 180/NX-Series & KGS-3/KAS-10 In-Depth Technical Manuals for installation,
programming & KGS-3/KAS-10 software setup. Refer to www.garmin.com for GPS-15L-W
technical specifications.
• Option: Order
L-1098
for Kenwood Long Beach installation
130.25 97.69
GA25MCX
Garmin On-dash Style Magnetic base GPS Antenna for GPS15XL-W
Note: shipped loose only; Install GA25MCX antenna to GPS15XL-W before vehicle install; Refer
to 180/NX-Series In-depth Technical Manuals for mobile installation.
62.00 46.50
NEXEDGE®Wireless Image System LIST EPL
KVT-11
NEXEDGE®Image Encoder Unit
Note: • Wireless Image System Monitor Station Operation.
• KAS-11 is required for programming.
• Not include Cameras (purchase aftermarket separately).
• Works with NX-700/800 6.25/12.5Khz Digital mode, Radio to Radio, via Conventional Repeater,
Trunking Repeater and Conventional IP Network.
• Refer to Wireless Image Basic Operation and Installation Guide for detailed features &
requirements.
575.00 431.25
KAS-11
NEXEDGE® Image Viewer Software (Windows® XP/VISTA/7 compatible),
Note: • Wireless Image System Base Station Operation.
• Works with NX-700/800 6.25/12.5Khz Digital mode, Radio to Radio, via Conventional Repeater,
Trunking Repeater and Conventional IP Network.
• Refer to Wireless Image Basic Operation and Installation Guide for detailed features &
requirements.
250.00 187.50
L-1687
NX-700/800 Flow Control Modification 60.00 45.00
SERVICE RELATED ACCESSORIES LIST EPL
KPG-46UM
USB Programming interface cable 158.50 118.88
KPG-111DK
Windows® Programming Software for NX-200/210/300/410/700/800/900 103.25 103.25
INSTALLATION / TUNING CHARGES LIST EPL
L-1085
NX-700/800 Basic TX/RX check 37.50 28.13
L-1087
Install VGS-1 Voice Guide & Storage Unit
Note:
VGS-1 installation precludes any ANI or encryption board installation
25.00 18.75
L-1094
Install KAP-2 (Default) HR1/Internal Sp./PA
25.00 18.75
L-1098
Install Garmin GPS15XL-W in NX-Series mobile for FleetSync® AVL 100.00 75.00
L-1099
Assemble NX-700/800 with KRK-10 Remote Kit 42.00 31.50
L-1663
NX-700/800 P25 Conventional Software Upgrade
Must order a KWD-P25C firmware option
N/C N/C
L-1687
NX-700/800 Flow Control Modification 60.00 45.00
