Kenwood DPX-5100BT User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
B5A-2111-00 (MN/HN)© 2017 JVC KENWOOD Corporation
DPX-5100BT
DUAL DIN SIZED CD RECEIVER
INSTRUCTION MANUAL
DPX-M3100BT
DUAL DIN SIZED DIGITAL MEDIA RECEIVER
INSTRUCTION MANUAL
JS_KWD_DPX_5100BT_MNHN_C_4.indd 1JS_KWD_DPX_5100BT_MNHN_C_4.indd 1 8/15/2017 9:56:26 AM8/15/2017 9:56:26 AM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
2ENGLISH
BEFORE USE
IMPORTANT
• To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe
Warning and Caution in this manual.
• Please keep the manual in a safe and accessible place for future reference.
WARNING
• Do not operate any function that takes your attention away from safe driving.
• Do not ingest the battery, Chemical Burn Hazard
The remote control supplied with this product contains a coin/button cell battery.
If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
Caution
Volume setting:
•
Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of the output level.
General:
•
Avoid using the external device if it might hinder safe driving.
• Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded data.
• Never put or leave any metallic objects (such as coins or metal tools) inside the unit to prevent a short circuit.
• For : If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to evaporate.
• Depending on the types of cars, the antenna will automatically extend when you turn on the unit with the antenna control wire connected
( 33) . Turn off the unit or change the source to STANDBY when parking at a low ceiling area.
Remote control (RC-406):
•
Do not leave the remote control in hot places such as on the dashboard.
• The Lithium battery is in danger of explosion if replaced incorrectly. Replace it only with the same or equivalent type.
• The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
How to read this manual
• Operations are explained mainly using buttons on the faceplate of .
• English indications are used for the purpose of explanation. You can select the display language from the [FUNCTION] menu. ( 6)
• [XX] indicates the selected items.
• ( XX) indicates references are available on the stated page.
CONTENTS
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Select the display language
and cancel the demonstration
2 Set the clock and date
3 Set the initial settings
RADIO 7
AUX 8
CD/USB/iPod/ANDROID 9
Spotify 12
BLUETOOTH® 13
AUDIO SETTINGS 21
DISPLAY SETTINGS 25
LEARNING STEERING
REMOTE CONTROL 26
REFERENCES 27
Maintenance
More information
TROUBLESHOOTING 29
INSTALLATION/
CONNECTION 31
SPECIFICATIONS 34
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 2JS_KWD_DPX_5100BT_MNHN_EN_4.indd 2 8/15/2017 9:56:45 AM8/15/2017 9:56:45 AM

ENGLISH 3
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BASICS
Faceplate
How to reset
Display
window
Volume knob
Flashes when the unit
enters searching status.
Lights up when
Bluetooth connection
is established.
( 14)
To On the faceplate
Turn on the power Press .
• Press and hold to turn off the power.
Adjust the volume Turn the volume knob.
Select a source Press repeatedly.
Change the display information Press DISP repeatedly.
( 28)
Eject button and loading slot
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 3JS_KWD_DPX_5100BT_MNHN_EN_4.indd 3 8/15/2017 9:56:45 AM8/15/2017 9:56:45 AM

4ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
To On the remote control
Turn on the power Press and hold SRC to turn off the power.
( Pressing SRC does not turn on the power. )
Adjust the volume Press or .
• Press and hold to continuously
increase the volume to 15.
Press ATT during playback to attenuate the
sound.
• Press again to cancel.
Select a source Press SRC repeatedly.
Remote control (RC-406) (supplied for )
Pull out the insulation sheet
when using for the first time.
How to replace the battery
Remote sensor (Do not expose
to bright sunlight.)
: Remote control functions are not available.
BASICS GETTING STARTED
Select the display language and cancel the demonstration
When you turn on the power for the first time (or [FACTORY RESET] is set to
[YES] , 6 ), the display shows: “SEL LANGUAGE” “PRESS” “VOLUME
KNOB”
1 Turn the volume knob to select [ENG] (English) or [TUR] (Turkish),
then press the knob.
[ENG] is selected for the initial setup.
Then, the display shows: “CANCEL DEMO” “PRESS” “VOLUME
KNOB”.
2 Press the volume knob.
[YES] is selected for the initial setup.
3 Press the volume knob again.
“DEMO OFF” appears.
Then, the display shows the selected crossover type: “2-WAY X ’OVER” or
“3-WAY X ’ OVER”
• To change the crossover type, see “Change the crossover type”. (
6 )
1
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 4JS_KWD_DPX_5100BT_MNHN_EN_4.indd 4 8/15/2017 9:56:46 AM8/15/2017 9:56:46 AM

ENGLISH 5
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Set the clock and date
1 Press the volume knob to enter
[FUNCTION] .
2 Turn the volume knob to select [CLOCK] , then press the knob.
To adjust the clock
3 Turn the volume knob to select [CLOCK ADJUST] , then press the knob.
4 Turn the volume knob to make the settings, then press the knob.
Hour Minute
5 Turn the volume knob to select [CLOCK FORMAT] , then press the knob.
6 Turn the volume knob to select [12H] or [24H] , then press the knob.
To set the date
7 Turn the volume knob to select [DATE FORMAT] , then press the knob.
8 Turn the volume knob to select [DD/MM/YY] or [MM/DD/YY] , then press
the knob.
9 Turn the volume knob to select [DATE SET] , then press the knob.
10 Turn the volume knob to make the settings, then press the knob.
Day Month Year or Month Day Year
11 Press and hold to exit.
To return to the previous setting item, press .
Set the initial settings
1 Press repeatedly to enter STANDBY.
2 Press the volume knob to enter [FUNCTION] .
3 Turn the volume knob to select an item (see the following table),
then press the knob.
4 Repeat step 3until the desired item is selected or activated.
5 Press and hold to exit.
To return to the previous setting item, press .
2
3
Default: XX
AUDIO CONTROL
SWITCH
PREOUT
(For )
(Not applicable if 3-way crossover is selected.)
REAR / SUBWOOFER : Selects whether rear speakers or a subwoofer are
connected to the line out terminals on the rear (through an external
amplifier).
( 34)
DISPLAY
EASY MENU
When entering [FUNCTION] ...
ON :LCD DISPLAY zone illumination changes to white color.;
OFF :LCD DISPLAY zone illumination remains as [COLOR SELECT] color.
( 25)
• KEY zone illumination changes to light blue color when you enter
[FUNCTION] , irregardless of the [EASY MENU] setting.
• Refer to the illustration on page 25 for zone identification.
TUNER SETTING
PRESET TYPE NORMAL
:Memorizes one station for each preset button in each band
(FM1/FM2/FM3/AM/SW1/SW2).;
MIX :Memorizes one station for each
preset button, regardless of the selected band.
SYSTEM
KEY BEEP
(Not applicable if 3-way crossover is selected)
ON :Activates the keypress tone.; OFF :Deactivates.
SOURCE SELECT
SPOTIFY SRC ON
:Enables SPOTIFY in source selection.; OFF :Disables. ( 12)
BUILT-IN AUX ON
:Enables AUX in source selection.; OFF :Disables. ( 8)
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 5JS_KWD_DPX_5100BT_MNHN_EN_4.indd 5 8/15/2017 9:56:46 AM8/15/2017 9:56:46 AM

6ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Change the crossover type
1 Press repeatedly to enter STANDBY.
2 Press and hold number buttons 4and 5to enter crossover select.
The current crossover type appears.
3 Turn the volume knob to select “2WAY” or “3WAY”, then press the
knob.
4 Turn the volume knob to select “YES” or “NO”, then press the knob.
The selected crossover type appears.
• To cancel, press and hold .
• To adjust the selected crossover settings,
( 22, 23) .
Caution
Select a crossover type according to how the speakers are connected.
( 33, 34)
If you select a wrong type:
• The speakers may damage.
• The output sound level may be extremely high or low.
GETTING STARTED
CD READ
(For )
1 : Automatically distinguishes between audio file disc and music CD. ;
2 : Forces to play as a music CD. No sound can be heard if an audio file
disc is played.
USER S.REMO
(For )
See page 26 for details.
F/W UPDATE
UPDATE SYSTEM
F/W UP xxxx YES
:Starts upgrading the firmware.; NO :Cancels (upgrading is not
activated).
For details on how to update the firmware, visit
<www.kenwood.com/cs/ce/>.
FACTORY RESET YES :Resets the settings to default (except the stored station).;
NO :Cancels.
CLOCK
CLOCK DISPLAY ON
:The clock time is shown on the display even when the unit is turned
off.;
OFF :Cancels.
ENGLISH Select the display language for [FUNCTION] menu and music information
if applicable.
By default,
[ENGLISH] is selected.
TURKCE
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 6JS_KWD_DPX_5100BT_MNHN_EN_4.indd 6 8/15/2017 9:56:47 AM8/15/2017 9:56:47 AM

ENGLISH 7
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
Search for a station
1 Press repeatedly to select RADIO.
2 Press repeatedly (or press / on the remote
control) to select FM1/FM2/FM3/AM/SW1/SW2.
3 Press S/T(or press S/ on the remote control) to
search for a station.
• To change the searching method for S/T: Press
repeatedly.
AUTO1 : Automatically search for a station.
AUTO2 : Search for a preset station.
MANUAL : Manually search for a station.
• To store a station: Press and hold one of the number buttons (1to6).
• To select a stored station: Press one of the number buttons (1to6) (or
press one of the number buttons (1to6) on the remote control).
Direct Access Tuning (using the remote control)
1 Press DIRECT to enter Direct Access Tuning.
2 Press the number buttons to enter a frequency.
3 Press to search for a station.
• To cancel, press or DIRECT.
• If no operation is done for 10seconds after step2, Direct Access Tuning
is automatically canceled.
Other settings
1 Press the volume knob to enter
[FUNCTION] .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press and hold to exit.
To return to the previous setting item, press .
Default: XX
TUNER SETTING
LOCAL SEEK ON
: Searches only AM/SW1/SW2 stations with good reception. ;
OFF :Cancels.
• Settings made are applicable only to the selected source/station. Once
you change the source/station, you need to make the settings again.
AUTO MEMORY YES :Automatically starts memorizing 6 stations with good reception.;
NO :Cancels.
• Selectable only if [NORMAL] is selected for [PRESET TYPE] . ( 5)
MONO SET ON
:Improves the FM reception, but the stereo effect may be lost.;
OFF :Cancels.
NEWS SET ON : The unit will temporarily switch to News Programme if available. ;
OFF :Cancels.
REGIONAL ON : Switches to another station only in the specific region using the “AF”
control.;
OFF :Cancels.
AF SET ON : Automatically searches for another station broadcasting the same
program in the same Radio Data System network with better reception
when the current reception is poor.;
OFF :Cancels.
TI ON :Allows the unit to temporarily switch to Traffic Information if
available (“TI” lights up).;
OFF :Cancels.
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 7JS_KWD_DPX_5100BT_MNHN_EN_4.indd 7 8/15/2017 9:56:47 AM8/15/2017 9:56:47 AM

8ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
PTY SEARCH 1 Turn the volume knob to select the available Program Type, then press
the knob.
2 Turn the volume knob to select the PTY language ( ENGLISH / FRENCH /
GERMAN ), then press the knob.
3 Press S / T to start searching.
CLOCK
TIME SYNC ON
:Synchronizes the unit’s time to the Radio Data System station time.;
OFF :Cancels.
Available Program Type for [PTY SEARCH]
SPEECH
: NEWS , AFFAIRS , INFO (information), SPORT , EDUCATE , DRAMA ,
CULTURE , SCIENCE , VARIED , WEATHER , FINANCE , CHILDREN , SOCIAL ,
RELIGION , PHONE IN , TRAVEL , LEISURE , DOCUMENT
MUSIC
: POP M (music), ROCK M (music), EASY M (music), LIGHT M (music),
CLASSICS , OTHER M (music), JAZZ , COUNTRY , NATION M (music),
OLDIES , FOLK M (music)
The unit will search for the Program Type categorized under [SPEECH] or
[MUSIC] if selected.
•
[MONO SET] / [NEWS SET] / [REGIONAL] / [AF SET] / [TI] / [PTY SEARCH] is selectable
only when the band is FM1/FM2/FM3.
• If the volume is adjusted during reception of traffic information or news
bulletin, the adjusted volume is memorized automatically. It will be
applied the next time traffic information or news bulletin is turned on.
AUX
Preparation:
Select
[ON] for [BUILT-IN AUX] for [SOURCE SELECT] . ( 5)
Start listening
1 Connect a portable audio player (commercially available).
2 Press repeatedly to select AUX.
3 Turn on the portable audio player and start playback.
Set the AUX name
While listening to a portable audio player connected to the unit...
1 Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to select [SYSTEM] , then press the knob.
3 Turn the volume knob to select [AUX NAME SET] , then press the knob.
4 Turn the volume knob to select an item, then press the knob.
AUX (default)/ DVD / PORTABLE / GAME / VIDEO / TV
5 Press and hold to exit.
To return to the previous setting item, press .
Auxiliary input jack
3.5mm (1/8") stereo mini plug with “L” shaped
connector (commercially available)
Portable audio player
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 8JS_KWD_DPX_5100BT_MNHN_EN_4.indd 8 8/15/2017 9:56:47 AM8/15/2017 9:56:47 AM

ENGLISH 9
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD/USB/iPod/ANDROID
Selectable source:
• : CD/USB/iPod USB/ANDROID
• : USB/iPod USB/ANDROID
To On the faceplate On the remote control
Playback/pause Press . Press .
Reverse/Fast-forward*4Press and hold
S/T.
Press and hold
S/ .
Select a track/file Press S/T. Press S/ .
Select a folder*5Press J/K.Press / .
*1
KCA-iP102 : 30-pin type, KCA-iP103 : Lightning type
*2
Do not leave the cable inside the car when not using.
*3
When connecting an Android device, “Press [VIEW] to install KENWOOD MUSIC PLAY APP” is shown. Follow the
instructions to install the application. You can also install the latest version of KENWOOD MUSIC PLAY application
on your Android device before connecting. For more information, visit <www.kenwood.com/cs/ce/>.
*4
For ANDROID: Applicable only when [BROWSE MODE] is selected. ( 10)
*5
For CD: Only for MP3/WMA/AAC files. This does not work for iPod/ANDROID.
Start playback
The source changes automatically and playback starts.
CA-U1EX (max.: 500mA)
(optional accessory)
USB cable
*2
(commercially available)
KCA-iP102/KCA-iP103
(optional accessory)
*1
or
accessory of the iPod/iPhone
*2
USB
iPod/iPhone
ANDROID*3
USB input terminal
Label side
M Eject disc
CD
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 9JS_KWD_DPX_5100BT_MNHN_EN_4.indd 9 8/15/2017 9:56:47 AM8/15/2017 9:56:47 AM

10 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Select music drive
While in USB source, press 5repeatedly.
Stored songs in the following drive will be played back.
• Selected internal or external memory of a smartphone (Mass
Storage Class).
• Selected drive of a multiple drives device.
Listen to TuneIn Radio/TuneIn Radio Pro
While listening to TuneIn Radio or TuneIn Radio Pro, connect the
iPod/iPhone to the USB input terminal of the unit.
• The unit will output the sound from these applications.
Select a file from a folder/list
For iPod/ANDROID, applicable only when [MODE OFF] / [BROWSE MODE]
is selected.
1 Press .
2 Turn the volume knob to select a folder/list, then press the
knob.
3 Turn the volume knob to select a file, then press the knob.
Quick Search (applicable only for CD, USB and ANDROID source)
If you have many files, you can search through them quickly.
Turn the volume knob quickly to browse through the list
quickly.
Skip Search (applicable only for iPod USB and ANDROID source)
Press S/Tto search at a preset skip search ratio.
( 11, [SKIP SEARCH])
• Pressing and holding S/Tsearches at a 10 % ratio.
CD/USB/iPod/ANDROID
To On the faceplate
Repeat play*6Press repeatedly.
TRACK REPEAT/ALL REPEAT : Audio CD
FILE REPEAT / FOLDER REPEAT / ALL REPEAT : MP3/WMA/AAC/
WAV/FLAC file
FILE REPEAT / FOLDER REPEAT / REPEAT OFF : iPod or ANDROID
Random play*6Press repeatedly.
DISC RANDOM/RANDOM OFF : Audio CD
FOLDER RANDOM / RANDOM OFF : MP3/WMA/AAC/WAV/
FLAC file, iPod or ANDROID
Press and hold to select
ALL RANDOM .*7
*6
For iPod/ANDROID: Applicable only when [MODE OFF] / [BROWSE MODE] is selected.
*7
For CD: Only for MP3/WMA/AAC files.
Select control mode
While in iPodUSB source, press 5repeatedly.
MODE ON : Control iPod using the iPod itself. However, you can still play/
pause, file skip, fast-forward or reverse from this unit.
MODE OFF : Control iPod from this unit.
While in ANDROID source, press 5 repeatedly.
BROWSE MODE : Control Android device from this unit via KENWOOD MUSIC
PLAY application installed in the Android device.
HAND MODE : Control Android device using the Android device itself via
other media player applications installed in the Android device.
However, you can still play/pause and file skip from this unit.
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 10JS_KWD_DPX_5100BT_MNHN_EN_4.indd 10 8/15/2017 9:56:48 AM8/15/2017 9:56:48 AM

ENGLISH 11
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD/USB/iPod/ANDROID
Alphabet search (applicable only for iPod USB and ANDROID source)
You can search for a file according to the first character.
For iPod USB source
1 Turn the volume knob quickly to enter character search.
2 Turn the volume knob to select the character.
• Select “
*” to search for a character other than AtoZ, 0to9.
3 Press S/Tto move to the entry position.
• You can enter up to 3characters.
4 Press the volume knob to start searching.
For ANDROID source
1 Press J/Kto enter character search.
2 Turn the volume knob to select the character.
^A^: Upper case letters (A to Z)
_A_: Lower case letters (a to z)
-0-: Numbers (0 to 9)
***: Character other than AtoZ, 0to9
3 Press the volume knob to start searching.
• To return to the root folder/first file/top menu, press 5.
(Not applicable for
BT AUDIO source.)
• To return to the previous setting item, press .
• To cancel, press and hold .
Direct Music Search (using the remote control)
1 Press DIRECT.
2 Press the number buttons to enter a track/file number.
3 Press to search for music.
• To cancel, press or DIRECT.
• Not available if Random Play is selected.
• Not applicable for iPodUSB and ANDROID source.
Settings to use KENWOOD Remote application
KENWOOD Remote application is designed to control the KENWOOD car
receiver’s operations from the iPhone/iPod (via USB input terminal).
Preparation:
Install the latest version of KENWOOD Remote application on your device
before connecting. For more information, visit
<www.kenwood.com/cs/ce/>.
You can make the settings in the same way as connection via Bluetooth.
( 20)
Other settings
1 Press the volume knob to enter
[FUNCTION] .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
USB
MUSIC DRIVE DRIVE CHANGE
:The next drive ( [DRIVE 1] to [DRIVE 4] ) is selected
automatically and playback starts.
Repeat steps
1 to 3 to select the following drives.
SKIP SEARCH 0.5% / 1% / 5% / 10% : While listening to iPodUSB or ANDROID source, selects
the skip search ratio over the total files.
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 11JS_KWD_DPX_5100BT_MNHN_EN_4.indd 11 8/15/2017 9:56:48 AM8/15/2017 9:56:48 AM

12 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Spotify
Preparation:
Install the latest version of the Spotify application on your device (iPhone/
iPod touch), then create an account and log in to Spotify.
• Select
[ON] for [SPOTIFY SRC] in [SOURCE SELECT] . ( 5)
Start listening
1 Open the Spotify application on your device.
2 Connect your device to the USB input terminal.
3 Press repeatedly to select SPOTIFY.
Broadcast starts automatically.
To On the faceplate On the remote control
Playback/pause Press . Press .
Skip a track Press S*4/ T. Press S*4/ .
Thumbs up or
thumbs down*3
Press J/K.Press / .
Start radio Press and hold 5.( Not available )
USB input terminal KCA-iP102/KCA-iP103 (optional accessory)
*1
or accessory of the iPod/iPhone
*2
To On the faceplate On the remote control
Repeat play*5Press repeatedly.
REPEAT ALL / REPEAT ONE
*4/
REPEAT OFF
(Not available)
Random play*5Press repeatedly.*4
SHUFFLE ON / SHUFFLE OFF
(Not available)
*1
KCA-iP102 : 30-pin type, KCA-iP103 : Lightning type
*2
Do not leave the cable inside the car when not using.
* 3
This feature is available for tracks in Radio only. If thumbs down is selected, the current
track is skipped.
*4
Available for premium account users only.
*5
Available for tracks in Playlists only.
Save favorite song information
While listening to the Radio on Spotify...
Press and hold the volume knob.
“SAVED” appears and the information is stored to “Your Music” or “Your
Library” on your Spotify account.
To unsave, repeat the same procedure.
“REMOVED” appears and the information is removed from “Your Music”
or “Your Library” on your Spotify account.
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 12JS_KWD_DPX_5100BT_MNHN_EN_4.indd 12 8/15/2017 9:56:48 AM8/15/2017 9:56:48 AM

ENGLISH 13
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH — Connection
Supported Bluetooth profiles
– Hands-Free Profile (HFP)
– Advanced Audio Distribution Profile (A2DP)
– Audio/Video Remote Control Profile (AVRCP)
– Serial Port Profile (SPP)
– Phonebook Access Profile (PBAP)
Supported Bluetooth codecs
– Sub Band Codec (SBC)
– Advanced Audio Coding (AAC)
Connect the microphone
Spotify
Search for a song or station
1 Press .
2 Turn the volume knob to select a list type, then press the knob.
The list types displayed differ depending on the information sent
from Spotify.
3 Turn the volume knob (or press J/ Kon the remote control) to
select the desired song or station.
4 Press the volume knob (or press on the remote control) to
confirm.
You can browse through the list quickly by turning the volume knob
quickly.
To cancel, press and hold .
BLUETOOTH®
Adjust the
microphone angle Secure using cord clamps
(not supplied) if necessary.
Microphone input jack
Microphone
(supplied)
Rear panel
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 13JS_KWD_DPX_5100BT_MNHN_EN_4.indd 13 8/15/2017 9:56:48 AM8/15/2017 9:56:48 AM

14 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Pair and connect a Bluetooth device for the first time
1 Press to turn on the unit.
2 Search and select this unit model name (DPX-5 /DPX-M3 ) on
the Bluetooth device.
“PAIRING” “PASS XXXXXX” Device name “PRESS” “VOLUME
KNOB” appears on the display.
• For some Bluetooth devices, you may need to enter the Personal
Identification Number (PIN) code immediately after searching.
3 Press the volume knob to start pairing.
“PAIRING OK” appears when pairing is completed.
Once pairing is completed, Bluetooth connection is established
automatically.
“BT1” and/or “BT2” indicator on the faceplate lights up.
• This unit supports Secure Simple Pairing (SSP).
• Up to five devices can be registered (paired) in total.
• Once the pairing is completed, the Bluetooth device will remain
registered in the unit even if you reset the unit. To delete the paired
device,
18, [DEVICE DELETE] .
• A maximum of two Bluetooth phones and one Bluetooth audio device
can be connected at any time.
However, while in BT AUDIO source, you can connect to five Bluetooth
audio devices and switch between these five devices.
( 19)
• Some Bluetooth devices may not automatically connect to the unit
after pairing. Connect the device to the unit manually.
• Refer to the instruction manual of the Bluetooth device for more
information.
Auto Pairing
When you connect iPhone/iPod touch/Android device to the USB input
terminal, pairing request (via Bluetooth) is automatically activated.
Press the volume knob to pair once you have confirmed the device
name.
Automatic pairing request is activated only if:
– Bluetooth function of the connected device is turned on.
–
[AUTO PAIRING] is set to [ON] . ( 18)
– KENWOOD MUSIC PLAY application is installed on the Android device
( 9) and [BROWSE MODE] is selected. ( 10)
BLUETOOTH®
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 14JS_KWD_DPX_5100BT_MNHN_EN_4.indd 14 8/15/2017 9:56:48 AM8/15/2017 9:56:48 AM

ENGLISH 15
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH — Mobile phone
Receive a call
When there is an incoming call:
• The KEY zone illuminates in green color and flashes.
• The unit answers the call automatically if
[AUTO ANSWER] is set
to a selected time.
( 16)
During a call:
• The LCD DISPLAY zone illuminates according to the settings
made for
[DISPLAY] ( 25) and the KEY zone illuminates in
green color.
• If you turn off the unit, the Bluetooth connection is
disconnected.
The following operations may differ or not available depending
on the connected phone.
BLUETOOTH®
To On the faceplate On the remote control
First incoming call...
Answer a call Press or the volume
knob or one of the number
buttons (1to 6).
Press .
Reject a call Press .Press .
End a call Press .Press .
While talking on the first incoming call...
Answer another
incoming call and
hold the current call
Press .Press .
Reject another
incoming call
Press .Press .
While having two active calls...
End current call and
activate held call
Press .Press .
Swap between the
current call and
held call
Press . Press .
Adjust the phone
volume
[00] to [35]
(Default:
[15] )
Turn the volume knob
during a call.
Press or
.
• This adjustment will not affect the volume of the other
sources.
Switch between
hands-free and
private talk modes
Press during a call.
• Operations may vary
according to the
connected Bluetooth
device.
( Not available )
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 15JS_KWD_DPX_5100BT_MNHN_EN_4.indd 15 8/15/2017 9:56:48 AM8/15/2017 9:56:48 AM

16 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
Improve the voice quality
While talking on the phone...
1 Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
MIC GAIN LEVEL –10 to LEVEL +10 ( LEVEL –4 ):The sensitivity of the microphone
increases as the number increased.
NR LEVEL LEVEL –5 to LEVEL +5 ( LEVEL 0 ):Adjust the noise reduction level until
the least noise is being heard during a phone conversation.
ECHO CANCEL LEVEL –5 to LEVEL +5 ( LEVEL 0 ):Adjust the echo cancellation delay
time until the least echo is being heard during a phone conversation.
Make the settings for receiving a call
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press and hold to exit.
To return to the previous setting item, press .
Default: XX
SETTINGS
AUTO ANSWER 1
to 30 :The unit answers incoming call automatically in the selected time
(in seconds).;
OFF :Cancels.
BATT/SIGNAL* AUTO :Shows the strength of the battery and signal when the unit detects
a Bluetooth device and the Bluetooth device is connected.;
OFF :Cancels.
* Functionality depends on the type of the phone used.
Make a call
You can make a call from the call history, phonebook, or dialing the
number. Call by voice is also possible if your mobile phone has the
feature.
1 Press to enter Bluetooth mode.
“(First device name)” appears.
• If two Bluetooth phones are connected, press again to switch
to another phone.
“(Second device name)” appears.
2 Turn the volume knob to select an item ( 17) , then press the
knob.
3 Repeat step 2until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press and hold to exit.
To return to the previous setting item, press .
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 16JS_KWD_DPX_5100BT_MNHN_EN_4.indd 16 8/15/2017 9:56:49 AM8/15/2017 9:56:49 AM

ENGLISH 17
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
CALL HISTORY (Applicable only if the phone supports PBAP.)
1 Press the volume knob to select a name or a phone number.
• “INCOMING”, “OUTGOING”, or “MISSED” is shown on the lower part of
the display to indicate the previous call status.
• Press
DISP to change the display category (NUMBER or NAME).
• “NO DATA” appears if there is no recorded call history.
2 Press the volume knob to call.
PHONE BOOK (Applicable only if the phone supports PBAP.)
1 Turn the volume knob quickly to enter alphabet search mode (if the
phonebook contains many contacts).
The first menu (ABCDEFGHIJK) appears.
• To go to the other menu (LMNOPQRSTUV or WXYZ1 ), press
J/ K .
• To select the desired first letter, turn the volume knob or press
S/T , then press the knob.
Select “1” to search with numbers and select “ ” to search with
symbols.
2 Turn the volume knob to select a name, then press the knob.
3 Turn the volume knob to select a phone number, then press the knob to
call.
• The phonebook of the connected phone is automatically transferred to
the unit when pairing.
• Contacts are categorized as: HOME, OFFICE, MOBILE, OTHER, GENERAL.
• This unit can display only non-accent letters. (Accent letters such as “Ú”
is shown as “U”.)
NUMBER DIAL 1 Turn the volume knob to select a number (0 to 9) or character
(, #, +).
2 Press S/T to move the entry position.
Repeat steps
1 and 2 until you finish entering the phone number.
3 Press the volume knob to call.
(or using the remote control)
1 Press the number buttons ( 0 to 9 ) to enter the phone number.
2 Press to call.
VOICE Speak the name of the contact you want to call or the voice command to
control the phone functions.
( Make a call using voice recognition)
BATT LOW
/ MID / FULL
*
:Shows the strength of the battery.
NO SIGNAL / LOW / MID / MAX
*
:Shows the strength of the current received signal.
* Functionality depends on the type of the phone used.
Make a call using voice recognition
1 Press and hold to activate the voice recognition of the
connected phone.
2 Speak the name of the contact you want to call or the voice
command to control the phone functions.
• Supported Voice Recognition features vary for each phone. Refer to the
instruction manual of the connected phone for details.
• This unit also supports the intelligent personal assistant function of
iPhone.
Settings in memory
Store a contact in memory
You can store up to 6 contacts into the number buttons (1to 6).
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select [CALL HISTORY] , [PHONE BOOK] , or
[NUMBER DIAL] , then press the knob.
3 Turn the volume knob to select a contact or enter a phone number.
If a contact is selected, press the volume knob to show the phone
number.
4 Press and hold one of the number buttons (1to 6).
“STORED” appears when the contact is stored.
To erase a contact from the preset memory, select
[NUMBER DIAL] in step 2
and store a blank number.
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 17JS_KWD_DPX_5100BT_MNHN_EN_4.indd 17 8/15/2017 9:56:49 AM8/15/2017 9:56:49 AM

18 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
Make a call from memory
1 Press to enter Bluetooth mode.
2 Press one of the number buttons (1to 6).
3 Press the volume knob to call.
“NO MEMORY” appears if there is no contacts stored.
Other settings
1 Press the volume knob to enter
[FUNCTION] .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
BT MODE
PHONE SELECT
Selects the phone or audio device to connect or disconnect.
“
*
” appears in front of the device name when connected.
“” appears in front of the current playback audio device.
• You can only connect a maximum of two Bluetooth phones and one
Bluetooth audio device at any time.
AUDIO SELECT
DEVICE DELETE
1 Turn the volume knob to select a device to delete, then press the
knob.
2 Turn the volume knob to select [YES] or [NO] , then press the knob.
PIN CODE EDIT
(0000)
Changes the PIN code (up to 6 digits).
1 Turn the volume knob to select a number.
2 Press S / T to move the entry position.
Repeat steps
1 and 2 until you finish entering the PIN code.
3 Press the volume knob to confirm.
RECONNECT ON :The unit automatically reconnect when the last connected
Bluetooth device is within range.;
OFF :Cancels.
AUTO PAIRING ON :The unit automatically pair supported Bluetooth device (iPhone/
iPod touch/Android device) when it is connected through USB input
terminal.Depending on the operating system of the connected device,
this function may not work. ;
OFF :Cancels.
INITIALIZE YES :Initializes all the Bluetooth settings (including stored pairing,
phonebook, and etc.).;
NO :Cancels.
Bluetooth test mode
You can check the connectivity of the supported profile between the
Bluetooth device and the unit.
• Make sure there is no Bluetooth device paired.
1 Press and hold .
“PLEASE PAIR YOUR PHONE PIN 0000” appears.
2 Search and select this unit model name (DPX-5***/DPX-M3***)
on the Bluetooth device.
3 Operate the Bluetooth device to confirm pairing.
“TESTING” flashes on the display.
The connectivity result (OK or NG) appears after the test.
PAIRING: Pairing status
HF CNT: Hands-Free Profile (HFP) compatibility
AUD CNT: Advanced Audio Distribution Profile (A2DP) compatibility
PB DL: Phonebook Access profile (PBAP) compatibility
To cancel test mode, press and hold to turn off the unit.
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 18JS_KWD_DPX_5100BT_MNHN_EN_4.indd 18 8/15/2017 9:56:49 AM8/15/2017 9:56:49 AM

ENGLISH 19
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
To On the faceplate On the remote control
Repeat play Press repeatedly.
ALL REPEAT , FILE REPEAT ,
REPEAT OFF
( Not available )
Random play Press and hold to
select
ALL RANDOM .
• Press to select
RANDOM OFF .
( Not available )
Select a file from
a folder/list
Refer to “Select a file from
a folder/list” on page 10. ( Not available )
Switch between
connected
Bluetooth audio
device
Press 5.*
( Not available )
*
Pressing the “Play” key on the connected device itself also causes switching of sound output
from the device.
Operations and display indications may differ according to their
availability on the connected device.
BLUETOOTH — Audio
While in BT AUDIO source, you can connect to five Bluetooth audio
devices and switch between these five devices.
Audio player via Bluetooth
1 Press (or press SRC repeatedly on the remote control) to
select BTAUDIO.
2 Operate the Bluetooth audio player to start playback.
To On the faceplate On the remote control
Playback/pause Press . Press .
Select group or folder Press J/ K.Press / .
Reverse/Forward skip Press S/T. Press S/ .
Reverse/Fast-forward Press and hold
S/T.
Press and hold
S/ .
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 19JS_KWD_DPX_5100BT_MNHN_EN_4.indd 19 8/15/2017 9:56:49 AM8/15/2017 9:56:49 AM

20 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
Settings to use KENWOOD Remote application
KENWOOD Remote application is designed to control the KENWOOD
car receiver’s operations from the iPhone/iPod (via Bluetooth or via USB
input terminal) or Android smartphone (via Bluetooth).
Preparation:
Install the latest version of KENWOOD Remote application on your device
before connecting. For more information, visit
<www.kenwood.com/cs/ce/>.
1 Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press and hold to exit.
To return to the previous setting item, press .
Default: XX
REMOTE APP
SELECT
Select the device (IOS or ANDROID) to use the application.
IOS YES :Selects iPhone/iPod to use the application via Bluetooth or connected via
USB input terminal.;
NO :Cancels.
If IOS is selected, select iPod BT source (or iPod USB if your iPhone/iPod is
connected via USB input terminal) to activate the application.
• The connectivity of the application will be interrupted or disconnected if:
– You change from iPod BT source to any playback source connected via the
USB input terminal.
– You change from iPod USB source to iPod BT source.
ANDROID YES :Selects Android smartphone to use the application via Bluetooth.;
NO : Cancels.
ANDROID LIST *:Selects the Android smartphone to use from the list.
* Displayed only when [ANDROID] of [SELECT] is set to [YES] .
STATUS Shows the status of the selected device.
IOS CONNECTED : You are able to use the application using the iPhone/iPod
connected via Bluetooth or USB input terminal.
IOS NOT CONNECTED : No IOS device is connected to use the application.
ANDROID CONNECTED : You are able to use the application using the Android
smartphone connected via Bluetooth.
ANDROID NOT CONNECTED : No Android device is connected to use the
application.
Listen to iPhone/iPod via Bluetooth
You can listen to the songs on the iPhone/iPod via Bluetooth on this unit.
Press repeatedly to select iPodBT.
• You can operate the iPod/iPhone in the same way as iPod/iPhone via
USB input terminal.
( 9)
• If you plug in an iPhone/iPod to the USB input terminal while listening
to iPodBT source, the source automatically change to iPodUSB. Press
to select iPodBT if the device is still connected via Bluetooth.
JS_KWD_DPX_5100BT_MNHN_EN_4.indd 20JS_KWD_DPX_5100BT_MNHN_EN_4.indd 20 8/15/2017 9:56:49 AM8/15/2017 9:56:49 AM
