Kenwood DVR-6200 User manual

DVD / AV RECEIVER
© 2003-8 PRINTED IN KOREA
B51-5872-00 (K/K) 1679
AC DEC cabinet *
(A29-)
AC DEC crystal *
(B10-)
Pun cover
(A09-1294-08)
In compliance with Federal Regulations, following are repro-
duction of labels on, or inside the product relating to laser
product safety.
KENWOOD Corp. certifies this equipment conforms to DHHS
Regulations No.21 CFR 1040. 10, Chapter 1, subchapter J.
DANGER : Laser radiation when open and interlock defeated.
AVOID DIRECT EXPOSURE TO BEAM.
Caution : No connection of ground line if disassemble
the unit. Please connect the ground line on
rear panel, PCBs, Chassis and some others.
AC DEC cap
(K29-8334-08)
AC DEC button
(K29-8266-08)
AC MLD clamp
(J42-0350-08)
Tuner module *
(W02-)
Conn-spe
(E70-0186-08)
Con phono socket
(E63-1331-08)x3
Phone jack
(E11-0957-08)
AC DEC knob
(K29-8335-08)
AC DEC cap
(K29-8331-08)
Wire-MCRDM *
(E30-)
*Refer to parts list on page 24.
AC DEC cap
(K29-8333-08)
AC DEC button
(K29-8332-08)
AC DEC button
(K29-8330-08)
Con phono socket
(E63-1267-05)x2
Con din socket
(E56-0054-08)
Conn-spe
(E70-0185-08)
DVR-6200
KSW-6200
SERVICE MANUAL
(DVT-6200)

Caution on condensation
Before transporting or moving this unit, carry out the
following operations.
1.Set the POWER ON/OFF switch to theON
without loading a disc.
2. Wait a few seconds and verify that the display
shown appears.
3. Set the POWER ON/OFF switch to OFF.
Note related to transportation and movement
Condensation(of dew) may occur inside the unit when there is agreat
difference in temperature between this unit andthe outside. Thisunit
may not function properly if condensation occurs. In this case, leave
the unit for a few hours and restart the operation after the condensa-
tion has dried up.
Be speciallycautious againstcondensation in the following circum-
stances:
When this unit is carried from one place to another across a large
difference in temperature, when the humidity in the room where
this unit is installed increases, etc.
System Speakers
DVR-6200 KSW-6200 (Left speaker, right speaker, center speaker, surround speakers and subwoofer)
Speaker model names
The marking of products using lasers
(For countries other than U.S.A. and U.S.-Military)
Inside this laser product, a laser diode classified as Class 2 laser radia-
tion is contained as alerted by the internal caution label shown above. Do
not stare into beam or view directly with optical instruments.
Location: DVD laser pick-up unit cover inside this product
CAUTION
VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN. DO NOT STARE INTO THE BEAM OR
VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
DO NOT PRESSON THIS SURFACE
The marking this product has been classified as Class 1. It
means that there is no danger of hazardous radiation outside
the product.
Location: Back panel
CLASS 1
LASER PRODUCT
Manufactured under license from Dolby Laboratories.
“DOLBY”, “Pro Logic” and the double-D symbol are
trademarks of Dolby Laboratories.
“DTS” and “DTS Digital Surround” are trademarks of
Digital Theater Systems, Inc.
Operation to reset
1Press the MENU key on the remote to enter SETUP
MENU .
2Select the PREFERENCE, then press the ENTER key.
3Select DEFAULTS, press the Cursoe right (3) key to
select RESET.
4Press the numeric keys as shown below.
Press 1, 3, 9, 7, then press the ENTER key.
When resetting is done according to this method, all set-
tings, including the settings for password and parental level ,
will be reset to the factory defaults .
The microprocessormay fall into malfunction (impos-
sibility to operate erroneous display, etc.) when the
power cord is unplugged while power is ON or due to
an external factor.
In this case,switch off the power, wait for several sec-
onds, and then switch the power on again.
Return to the factory defaults by resetting the micropro-
cessoris done as shown as follows.
FM indoor antenna (1)
(T90-0882-08): MEX
(T90-0907-08): K
Loop antenna (1)
(T90-0896-08)
Remote control unit (1)
(A70-1647-08): KXM
(A70-1648-08): E
Batteries (R6/AA) (2)
Video cord (1)
(E30-1427-05)
SCART plug adaptor (1)
(Europe only)
(E69-0012-05)
Speaker cords (6)
(E30-5480-08): RD
(E30-5962-08): WH
(E30-7005-05): VT
(E30-5482-08): GN
(E30-5483-08): GY
(E30-5963-08): BL
DVR-6200
2
ACCESSORIES / CAUTIONS
Accessories
Cautions
SYSTEM MAIN UNIT SPEAKER
DVT-6200 DVR-6200 KSW-6200
SYSTEM CONFIGURATION

DVR-6200
3
DISASSEMBLY FOR REPAIR
How to open the tray if it does not come out.
1. Insert a flat driver in the drawing through the hole on the loading
chassis bottom and pull the lever down.
2. Pull out the tray frontward by hand when it comes just out.

2
ACEG IBDFHJ
1
3
5
7
4
6
Refer to the schematic diagram for the value of resistors and capacitors.
PC BOARD
56
R8
R2
C8 R10
C5
R4
BE
BE
FIT1
R6
R104
R103
R102
R101
C106
C105
C108 C111
C110
R110
C115
C114
C100
C101
C98
C97
C102
C104
C103
R95
R93
R94
R92
R100
R99
R98
R97
R129 C134 C143
C142
C133
C138
C136 C139 C128
C126
C125
C132
C131
C70
C69
C76 R75
R74
R73
R72
C75
C130
C129 C73 C82
C80 C83
C87
C86
C78
C77
C72 C74
R128
R127
R126
R135
R134
R133
R132
R120
R119
R118
R117
R125
R124
R123
R122
R70
R69
R68
R67
R79
R78
R77
R76
R85
R84
R83
R82
L3
L2
C79
R71
C155
C62
R66
R51
R53
R59
EB
EB
C55
C57
R62
R61
C56
C19
C22
C21
C17
FIT2
C16
81
B3
C12
C14
OG I
L1
C18
C20
C53
TP1
JP1
JP2
R57
C61
C1
R171
C23
C89
C84
R89 R90
C88
R130
R138
R139
C144
C145
R45
R46
R48
R49
R36 R38
R40
R41
R33
R34
R30
R31
C27
R23
R35
R37
R39
R42
R43
R44
R47 R50 R19
R18
R20
C41C42
C43
C48
C49
C50
B6
C47
R32
C35
R27
C26
C25
R172
C140
R140
R115
C117
R14
R16
R12
C112
C116
R114
R113
C58
R64
C60
R65
R60
R63
C59
R52
R54
R55
R56
JP4
JP3
C71
R81
B2
B1
R58
C54
R109
R108
R107
C7
L5
K1
R106
C107
R96 R131
L7
R121
L6
C3
C149
C146
C94
B14
C92
R91
B11
C4
B10
C63
C93
C90
C95
C91
C96
R137 C141
C113
C109
R105
C9
B4
Y1
R24
1
125
75 51
26
50
100
76
7
14 8
R25
C156 R173
C32 R21
C31
C24
C44
C45
C51
TP2
R29
C26
R22
C29
R28
C37 C38 C39 C40
R112
36 19
118
36 19
118
36 19
118
36 19
118
R111
C137
R136
R86
R88
R80
C81
C85
R87
TP3
17
14 8
TP4 TP5 TP6
C13
B5
C46
B7
C34
C28
C33
C36
C15
R17
RST
G
VCC
C30 C52
C64
C65
C66 C67
C68
C99 C135 C127
B15
R141
C2
C148
B12
R11
R116
C120
B13
C122
BE
R13
C119
C124 C123 C152 C151
C147
C150
C118
C121
L4
R3
R15
C6
SPK1
SPK2
D6
Q8
U4
Q5
Q1
D3
Q3
IC6 IC7
IC3
CN3
CN1
Q2
Q4
D1
D2
D4
D5
CN2
U1
U2
IC2
(SIDE-A)
D-AMP
FRONT SURR.
L
FRONT CENTER WOOFER
SUB
SURR.
R
SPEAERS
Q9
IC5 IC4
Q7
U3
Q6
EB
EB
E
EB
1
15
19
218
B
D-AMP (SIDE-B)
FRONTSURR.
L
FRONTCENTERWOOFER
SUB SURR.
R
SPEAERS

KLNPRTMOQS
2
1
3
5
7
4
6
Refer to the schematic diagram for the value of resistors and capacitors.
PC BOARD
87
C728
R744
C726
