Kenwood XD-DV90 User manual

XD-DV90
XD-DV80
XD-DV70
XD-DV60
XD-DV50
XD-A850DV
DVD COMPACT HIFI SYSTEM
INSTRUCTION MANUAL
KENWOOD CORPORATION
B60-4911-08 01 (K/Y/T/M/X)
OC
01/03
DIGITAL VIDEO
COMPACT
DIGITAL AUDIO
COM PACT
This instruction manual is used to describe multiple models listed above.
Model availability and features (functions) may differ depending on the country and
sales area.
Downloaded from: http://www.usersmanualguide.com/

2
Preparations
XD-DV series (EN/K,M,T,X,Y)
CAUTION:TO REDUCETHERISKOFELECTRICSHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE, REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRI-
ANGLE, IS INTENDED TO ALERT THE USER TO THEPRESENCE OF UNINSULATED “DAN-
GEROUS VOLTAGE” WITHIN THEPRODUCT’S ENCLOSURETHAT MAY BEOFSUFFICIENT
MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
THEEXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLEIS INTENDED TO ALERT
THE USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SER-
VICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.
Units are designed for operation as follows.
Safety precautions
Factory fitted moulded mains plug
1. The mains plug contains afuse. For replacement, use only
a 3-Amp ASTA-approved (BS 1362) fuse.
2. The fuse cover must be refitted when replacing the fuse in
the moulded plug.
3. Do not cut off the mains plug from this equipment. If the
plug fitted is not suitableforthe powerpointsinyourhome
or the cable is too short to reach.
A power point, then obtain an appropriate safety approved
extension lead or adapter, or consult your dealer. If none-
theless the mains plug is cut off, remove the fuse and
dispose of the plug immediately, to avoid apossible shock
hazard by inadvertent.
Connection to the mains supply.
IMPORTANT :
The wires in the mains lead are coloured in accordance
with the following code:
Blue : Neutral
Brown : Live
Donot connect those leads tothe earthterminalof athree-
pin plug.
For the United Kingdom
WARNING :TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
The marking is located on the rear panel and says that
the component uses laser beams that have been clas-
sified as Class 1. It means that the unit is utilizing laser
beams that are of aweaker class. There is no danger of
hazardous radiation outside the unit.
CLASS 1
LASER PRODUCT
The marking of products using lasers
(Except for some areas)
U.S.A. and Canada ...................................................... AC 120 V only
Europe and U.K. ........................................................... AC 230 V only
AC voltage selection
The ACvoltage selector switch on the rear panel is set to the
voltage that prevails in the area to which the unit is shipped.
Before connecting the power cord to your AC outlet, make
sure that the setting position of these switches matches your
linevoltage. If not,it must beset toyourvoltage inaccordance
with the following direction.
* For other countries
AC voltage selector switches
Move switch lever to match your line voltage with a small
screwdriver or other pointed tool.
Note:
Ourwarrantydoesnot coverdamagecausedbyexcessive line
voltage due to improper setting of the AC voltage selector
switch.
Before applying pow er Caution : Read this section carefully to ensure safe operation.
Introduction
Caution : Read this section carefully to ensure safe operation.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AC 110-
120V AC 220- 240V
Australia ....................................................................... AC 240 V only
* Other countries .................... AC 110-120 / 220-240 V sw itchable
Downloaded from: http://www.usersmanualguide.com/

3
Preparations
XD-DV series (EN/K,M,T,X,Y)
Unpacking
Unpack the unit carefully and make sure that all accessories are put aside so they will not be lost.
Examine the unit for any possibility of shipping damage. If your unit is damaged or fails to operate, notify your dealer immediately. If your unit
was shipped to you directly, notify the shipping company without delay. Only the consignee (the person or company receiving the unit) can
file a claim against the carrier for shipping damage.
We recommend that you retain the original carton and packing materials for use should you transport or ship the unit in the future.
Keep this manual handy for future reference.
Accessories
Please confirm that the following accessories are present.
FM indoor antenna (1) Loop antenna (1)
Remote control unit (1) Batteries (R6/AA) (2) *AC plug adaptor (1)
* Use to adapt the plug on the
power cord to the shape of
the wall outlet.
(Accessory only for regions
where use is necessary.)
/
Video cord (1)
System Front speakers Surround Speakers and accessories
XD-DV90 LS-N90V (Left speaker and right speaker) CRS-N90V (Center speaker ×1, surround speakers ×2,
speaker cords×3, speaker stabilizer×12)
XD-DV80 LS-N70V (Left speaker and right speaker) CRS-N90V (Center speaker ×1, surround speakers ×2,
speaker cords×3, speaker stabilizer×12)
XD-DV70 LS-N90V (Left speaker and right speaker) –
XD-DV60 LS-N70V (Left speaker and right speaker) –
XD-DV50 LS-N50V (Left speaker and right speaker) –
XD-A850DV LS-N50V (Left speaker and right speaker) –
The space between radio channels has been set to the one
that prevails in the area to which the system is shipped.
However, if the current channel space setting does not
match the setting in the areawhere the system is to be used,
for instance when you move from area 1 or area 2 shown in
the following table or vice versa, proper reception of AM/FM
broadcasts cannot be expected. In this case, change the
channel space setting in accordance with your area by refer-
ring to the following table.
(Except for the U.S.A., Canada, U.K., Europe and Australia)
CHANNEL
SPACE frequency
Area
1
2
USA, Canada and South
American countries
Other countries
FM : 100 kHz
AM : 10 kHz
FM : 50 kHz
AM : 9 kHz
Setting the CHANNEL SPACE
1Set the POWER key to standby (power off) mode.
2PressandholdtheSTOP(77
77
7)keyformorethan2seconds.
Each press for more than 2 seconds switches the modes
as follows.
1“ FM100/AM10 kHz” STEP
2“ FM 50 /AM 9 kHz” STEP
STOP
7
CHANNEL SPACE setting
Accessories packed w ith the main unit
Speaker model names and accessories packed w ith the speakers
Downloaded from: http://www.usersmanualguide.com/

4
Preparations
XD-DV series (EN/K,M,T,X,Y)
Introduction
In regard to demonstration
When this unit is switched on for the first time or after the
power cable has been disconnected for a long time, it will
enter automatically into demonstration mode (only display).
During the demonstration, the display changes in sequence
but the audio does not change. The demonstration can be
canceled with the following procedure.
DISPLAY/DEMODISPLAY/DEMO
This document classifies the applications of each feature using the following marks
DVD
: Description of a feature that can be used with DVD.
VCD
: Description of a feature that can be used with Video CD.
CD
: Description of a feature that can be used with CD.
DVD
DVD
DVD
CD VCD
DVD
DVD
DVD
CD
Higher video quality than S-VHS video and LaserDisc
Higher audio quality than music CD
Graphical user interface (GUI) compatibility
6-Channel independent outputs using built-in Dolby Digital (AC-3) decoder
(only for XD-DV90/XD-DV80)
Versatile DVD playback features
DTS digital output compatibility
1Set the POWER key to ON.
2Press the DISPLAY/DEMO key.
Cancellation of Demonstration mode
To start demonstration:
Press and hold The DISPLAY/DEMO key for more than 2
seconds.
Special features
Downloaded from: http://www.usersmanualguide.com/

5
Preparations
XD-DV series (EN/K,M,T,X,Y)
Caution : Read this page carefully to ensure
safe operation.
IM PORTANT SAFEGUARDS
6. Temperature – The appliance may not function
properly if used at extremely low, or freezing
temperatures. The ideal ambient temperature is
above +5°C (41°F).
7. Heat – The appliance should be situated away from
heat sourcessuch asradiators,heat registers,stoves,
orotherappliances (includingamplifiers)that produce
heat.
8. Electricshock–Careshould be taken so that objects
do not fall and liquid is not spilled into the enclosure
through openings. If a metal objects, such as a hair
pin or aneedle, comes into contact with the inside of
thisappliance, adangerous electricshockmayresult.
For families with children, never permit children to
put anything, especially metal, inside this appliance.
9. Enclosure removal – Never remove the enclosure.
If theinternalpartsaretouchedaccidentally,aserious
electric shock might occur.
10.Magnetic fields – Keep the appliance away from
sources of magnetic fields such as TV sets, speaker
systems, radios, motorized toys or magnetized
objects.
11.Cleaning – Unplug this appliance from the wall
outlet before cleaning. Do not use volatile solvents
such as alcohol, paint thinner, gasoline, or benzine,
etc. to clean the cabinet. Use a clean dry cloth.
12.Accessories – Do not place this appliance on an unstable
cart,stand,tripod,bracket,ortable.Theappliancemayfall,
causing serious injury to a child or adult, and serious
damage to the appliance. Use only with a cart, stand,
tripod,bracket,ortablerecommendedbythemanufacturer,
or sold with the appliance. Any mounting of the appliance
should follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer. An appliance and cart combination should
be moved with care. Quick stops, excessive force, and
uneven surfaces may cause the appliance and cart
combination to overturn.
Please read all of the safety and operating instructions
before operating this appliance. Adhere to all warnings on
the appliance and in the instruction manual. Follow all the
safety and operating instructions. These safety and
operating instructions should be retained for future
reference.
1. Power sources – The appliance should be connected to
apowersupplyonlyof thetypedescribedintheinstruction
manual or as marked on the appliance. If you are not sure
of the type of power supply to your home, consult your
appliance dealer or local power company. For appliances
intended to operate from battery power, or other sources,
refer to the instruction manual.
2. Power-cordprotection–Power-supply cordsshould
be routed so that they are not likely to be walked on
or pinched by items placed upon or against them,
payparticularattentiontocords at plugs,convenience
receptacles, and the point where they exit from the
appliance.
3. CAUTION – Polarization – This appliance may
beequippedwithapolarizedalternating-current lineplug(a
plug having one blade wider than the other). This plug will
fit into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should still fail to
fit,contact yourelectrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.
4. Ventilation – Slots and openings in the cabinet are
provided for ventilation and to ensure reliable operation of
theapplianceandtoprotect it from overheating,andthese
openings must not be blocked or covered. The appliance
should be situated so that its location or position does not
interfere with its proper ventilation.
To maintain good ventilation, do not put records or atable-
cloth on the appliance. Place the appliance at least 10 cm
away from the walls.
Do not use the appliance on a bed, sofa, rug or similar
surface that may block the ventilation openings. This
applianceshouldnot beplacedin abuilt-ininstallationsuch
as abookcase or rack unless proper ventilation is provided
or the manufacturer’s instructions have been adhered to.
5. Water and moisture – The appliance should not be
used near water - for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, etc.
Downloaded from: http://www.usersmanualguide.com/

6
Preparations
XD-DV series (EN/K,M,T,X,Y)
13.Lightning –For added protection for this appliance during
alightning storm, orwhenit is left unattendedand unused
for long periods of time, unplug it from the wall outlet and
disconnect the antennaor cable system. This will prevent
damage to the appliance due to lightning and power-line
surges.
14.Abnormal smell – If an abnormal smell or smoke is
detected,immediatelyturnthepowerOFFand unplug
theappliancefrom thewalloutlet.Contact your dealeror
nearest service center.
15.Damage requiring service – The appliance should
be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been
damaged.
B. Objects have fallen, or liquid has been spilled into
the appliance.
C. The appliance has been exposed to rain or water.
D. Theappliancedoesnot appeartooperate normally
by following the instruction manual. Adjust only those
controls that are covered by the instruction manual as an
improperadjustmentofothercontrolsmayresult indamage
and will often require extensive work by a qualified
technicianto restore the appliance to itsnormal operation.
E. Theappliance has been dropped,orthe enclosure
damaged.
F. Theapplianceexhibitsamarkedchangeinperformance.
16.Servicing – The user should not attempt to service
theappliancebeyondthat described in the instruction
manual. All other servicing should be referred to
qualified service personnel.
17.Outdoor antenna grounding–If anoutsideantenna
is connected to the appliance, be sure the antenna
system is grounded so astoprovide someprotection
against voltage surges and built up static charges.
Article 810 of the National Electrical Code ANSI/
NFPA 70,providesinformationwithrespect toproper
grounding of the mast and supporting structure,
grounding of thelead-inwireto anantennadischarge
unit,sizeof groundingconductors,locationof antenna
discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode. See
Figure.
18.Power lines – An outside antennasystem should not be
located in the vicinity of overhead power lines or other
electriclight or powercircuits,orwhereit canfall into such
powerlines orcircuits.Wheninstalling anoutsideantenna
system, extreme care should be taken to keep from
touchingsuchpower lines or circuits as contact with them
might be fatal.
19.AC outlets – Do not connect other audio equipment
with a power consumption larger than that specified
to the AC outlet on the rear panel. Never connect
other electricalappliances, suchasaniron or toaster,
to it to prevent fire or electric shock.
20.Overloading – Do not overload wall outlets, extension
cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.
21.Attachment –Donot useattachmentsnot recommended
bytheappliance manufacturerastheymaycausehazards.
22. Replacement parts–Whenreplacementpartsarerequired,
besuretheservice technicianhasused replacement parts
specified by the manufacturer or have the same
characteristics as the original parts. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
23.Safety check –Upon completion of any service or repairs
to this appliance, ask the service technician to perform
safety checks to determine that the appliance is in proper
operating condition.
Notes:
1. Item 3is not required except for grounded orpolarizedequipment.
2. Item 17 and 18 are not required except for units provided with
antenna terminals.
3. Item 17 complies with UL in the U.S.A.
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL
ELECTRICAL CODE
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC– NATIONAL ELECTRICAL CODE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ANTENNA
LEAD IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMPS
Downloaded from: http://www.usersmanualguide.com/

7
Preparations
XD-DV series (EN/K,M,T,X,Y)
Contents
Introduction ...................................................................... 2
Before applying pow er ..................................................................... 2
Safety precautions ............................................................................. 2
Accessories .............................................................................................. 3
CHANNEL SPACE setting ........................................................................ 3
In regard to demonstration ..................................................................... 4
Special features ....................................................................................... 4
IM PORTANT SAFEGUARDS ...................................... 5
Contents ............................................................................ 7
Region codes ................................................................... 8
Region codes in the w orld ..................................................................... 8
Examples of TV screen display of each video format ....................... 8
Video formats ................................................................... 9
Video formats of DVD discs that can be played on this unit ............ 9
Discs information .......................................................... 10
Recording systems and types of playable discs .............................. 10
Unplayable discs ................................................................................... 10
Icons on the DVD discs ......................................................................... 10
Handling of discs and tapes........................................ 11
System Connections................................................. 12
AM loop antenna .................................................................................... 12
FM antenna ............................................................................................. 12
Connection of the front speakers ........................................................ 13
Connection of the sub woofer or super w oofer (optional) ............. 13
Connection of the surround speaker system .................................... 14
Connection of the TV monitor (optional) and VCR (optional) ......... 15
Connection of the M D recorder/CD recorder (optional) ................. 15
Controls and indicators................................................ 16
M ain unit (1) ............................................................................................ 16
M ain unit (2) ............................................................................................ 17
DISPLAY ................................................................................................... 17
Operation of remote control unit ................................ 18
SM ART M ENU operation/Clock adjustment ............ 19
SM ART M ENU operation ...................................................................... 19
Clock adjustment ................................................................................... 19
Let's put out some sound ............................................. 21
Basic use method .................................................................................. 21
Changing the Tone ................................................................................. 22
Playback of discs .......................................................... 24
Sequential playback from the first track or chapter ....................... 24
Playback from the desired track or chapter ..................................... 25
Repeat play ............................................................................................. 26
A-B repeat play ...................................................................................... 26
Random play ........................................................................................... 27
Program play (Using the On-screen display)(DVD/CD/VCD) .......... 28
Using the On-screen banner display .................................................. 30
Selecting a Title ..................................................................................... 31
Selecting a Chapter or Track ............................................................... 31
Changing the Audio Language ............................................................ 32
Changing the Subtitle Language ......................................................... 32
Changing the Camera angle ................................................................. 33
Using IntroScan function ...................................................................... 33
Using Bookmarks ................................................................................... 34
Receiving broadcast station ................................................................ 35
Storing the broadcast stations (one-by-one presetting) ................ 36
Using RDS function ( for Europe and U.K. only) ................................ 37
Playback of tapes .................................................................................. 39
Normal Recording (TAPE B only) ........................................................ 40
CD Direct Recording (TAPE B only) .................................................... 41
CD Program Recording (TAPE B only) ................................................ 42
TAPE DUBBING ...................................................................................... 43
M enu playback ....................................................................................... 44
Hierarchical structure of VCD menus (P.B.C.) .................................. 44
Enjoying karaoke singing (only for some areas) ............................. 45
Set Up functions ............................................................ 46
Set up menu ............................................................................................ 46
Select Audio Language ......................................................................... 47
Select Subtitle Language ..................................................................... 47
Select M enu Language ......................................................................... 48
Select Rating (Parental Lock) .............................................................. 48
Passw ord ................................................................................................. 49
TV aspect ................................................................................................. 51
Dynamic Range ...................................................................................... 52
Digital Audio Out .................................................................................... 52
Setting up surround mode ........................................... 53
W hat are surround modes? .................................................................. 53
SPEAKER SETUP............................................................ 54
Timer function ................................................................ 58
Sleep timer .............................................................................................. 58
Timer Play ................................................................................................ 59
Timer recording ...................................................................................... 60
AUTO POW ER SAVE function ............................................................... 61
Know ledge ..................................................................... 62
Important items.............................................................. 63
M aintenance ........................................................................................... 63
Reference ................................................................................................ 63
In case of difficulty ....................................................... 64
Specifications................................................................ 68
Preparation section
Operation Know ledge section
Downloaded from: http://www.usersmanualguide.com/

8
Preparations
XD-DV series (EN/K,M,T,X,Y)
Every player of thismodel hasa certain region code assigned to it based on the country where the player isused.
When the player isused to play back DVD discs, it can only play the DVD discscarrying the region codesmatching
the region code of the player.
The region code for this player is described on the rear panel of the player.
Region codes
Region codes in the w orld
The DVD playersare given a region code according to the country or area it ismarketed, asshown in the following
map.
When your TV is compatible only w ith the
PAL format
With certain discs, the playback
picture may have black spaces
above and below it (as shown on
the right). This is because the
disc has been recorded in the
NTSCformat.Thescreenmaybe
somewhat hard to see but this is
not malfunction.
When your TV is sw itchable betw een PAL/
NTSC
Try play adisc. If the picture is black and white or as shown on
the right, stop playback and switch the screen display formats
of this unit and the TV to another format. This will improve the
played picture quality.
Examples of TV screen display of each video format
When your TV is compatible only w ith the
NTSC format
With certain discs, the playback
picture may be cut above and
below it (as shown on the right).
Thisisbecausethedischasbeen
recorded in the PAL or SECAM
format.Thescreenmaybesome-
what hard to see but this is not
malfunction.
1
2
4
1
5
4
5
2
1
2
6
3
Downloaded from: http://www.usersmanualguide.com/

9
Preparations
XD-DV series (EN/K,M,T,X,Y)
Major Countries & Areas
Japan,Taiwan,Korea,U.S.A.,Canada,Mexico,
Philippines, Chile, etc.
China, North Korea, U.K., Germany, Australia,
New Zealand, Kuwait, Singapore, etc.
France, Eastern Europe
Note
Note
The video signalsused to display TV picturesand video disc
pictures are mainly based on two types of signal formats
(PAL, SECAM and NTSC), which are assigned to each coun-
try or area asshown on the right. Asa result, it isrequired to
select discsaccordingtothevideoformat used withyourTV
monitor (in your country or area).
Video formats
TV formats of major countries
Normal video may not be reproduced when a disc recorded with the video format marked * in the above table is played. See
“ Examples of TV screen display of each video format” for details. 8
Set the video formats of the DVD discs to be played on this unit as described below.
Check the video format(s) used by your TV monitor.
÷Refer to the operating instructions of your TV monitor for details.
Select DVD discs or VCD discs recorded w ith the playable video format by referring to the
follow ing table.
÷See the region code table on the bottom of this page for details on districts 1to 6.
1
2
3
When your TV is sw itchable betw een NTSC and PAL,
÷Districts 1, 2-2 and 4-2: Set the TV to NTSC.
÷Districts 2-1, 4-1 and 5: Set the TV to PAL.
÷Districts 2-3, 3and 6: Set the TV according to each disc to be played.
Video formats of DVD discs that can be played on this unit
TV Format
NTSC
PAL
Your TV
format
NTSC only
PAL only
NTSC/PAL
switchable
Playable Disc Formats
District 1
NTSC
NTSC*
NTSC
District 2-1
NTSC*
PAL*
NTSC
PAL
NTSC
PAL
District 2-2
NTSC
NTSC*
NTSC
District 2-3
NTSC
PAL*
NTSC*
PAL
NTSC
PAL
District 3
NTSC
PAL*
NTSC*
PAL
NTSC
PAL
District 4-1
NTSC*
PAL*
NTSC
PAL
NTSC
PAL
District 4-2
NTSC
NTSC*
NTSC
District 5
NTSC*
PAL*
NTSC
PAL
NTSC
PAL
District 6
NTSC
PAL*
NTSC*
PAL
NTSC
PAL
Region code table
Area or
Country
Name,
Region
Code
District 1
North
America
District 2-1
U. K. and
Europe
District 2-2
Japan
District 2-3
Middle East
District 3
Southeast
Asia
District 4-1
Oceania
District 4-2
South
America
District 5
Russia
District 6
China
122234456
Restrictions due to difference betw een discs
Some DVD and VCD discs can be played only in certain playback modes according to the intentions of the software
producers.Asthisplayerplaysdiscsaccordingto theirintentions,some functionsmaynot workasintendedbyyou.
Pleasebesuretoreadtheinstructionsprovidedwitheachdisc.WhenaninhibitioniconisdisplayedontheTVscreen
connected to the player, it indicates that the disc being played is under the restriction as described above.
Inhibition icon
SECAM
Downloaded from: http://www.usersmanualguide.com/

10
Preparations
XD-DV series (EN/K,M,T,X,Y)
Discs information
The system using thisunit does not only play music from CD but can also play the discs listed below to offer you high-quality
entertainment of video of movies and live concerts.
Video + Audio
Audio
Contents
Played sides
Disc size
One side only One side only
Max. 20 min., digital Max. 74 min., digital
One or both One or both
Approx. 41 min.
(1 side, 1 layer)
Approx. 75 min.
(1 side, 2 layers)
Approx. 82 min.
(2 sides, 1 layer)
Approx. 150 min.
(2 sides, 2 layers)
Approx. 133 min.
(1 side, 1 layer)
Approx. 242 min.
(1 side, 2 layers)
Approx. 266 min.
(2 sides, 1 layer)
Approx. 484 min.
(2 sides, 2 layers)
DVD CD
Logo mark on disc
Playable Disc
Recording systems and types of playable discs
12cm
8cm
12cm
8cm
DIGITAL AUDIO
COM PACT
Indicates the region code where the disc can be played.
Numberof voicelanguages recordedwith the audio function.Thenumberintheicon indicatesthenumberof voicelanguages.
(Max. 8 languages)
Number of subtitle languages recorded with the subtitle function. The number in the icon indicates the number of subtitle
languages. (Max. 32 languages)
Number of angles provided by the angle function. The number in the icon indicates the number of angles. (Max. 9 angles)
Aspect ratiosthat canbeselected. “ LB” standsfor LetterBoxand“ PS” forPan/Scan.Intheexample ontheleft,the16:9video
can be converted into letter box video.
9
32
8
16:9 LB
ALL
Icon Description
Icons on the DVD discs
Unplayable discs
This player cannot play back any of the following discs.
÷DVD-ROM discs
÷DVD-R/DVD-RAM discs
÷CD-ROM discs
÷VSD discs
÷CD-EXTRA discs
÷CDV discs (Only the audio part can be reproduced.)
÷CD-G/CD-EG discs (Only the audio can be reproduced.)
÷CD-R/CD-RW discs (Never attempt to play them.)
÷Photo CD discs (Never attempt to play them.)
12cm
VCD
DIGITAL VIDEO
DIGITAL VIDEO
COM PACT
COM PACT
One side only
Max. 74 min.
Downloaded from: http://www.usersmanualguide.com/

11
Preparations
XD-DV series (EN/K,M,T,X,Y)
Handling of discs and tapes
Label side
Playing side
Cleaning
If fingerprints or foreign matter become
attached to the disc, lightly wipe the
disc with asoft cotton cloth (or similar)
from the center of the disc outwards in
a radial manner.
Storage
When a disc is not to be played for a
long period of time, remove it from the
player and store it in its case.
Handling
Hold the discs so that you do not touch
the playing surface.
Disc handling precautions
Disc accessories
The disc accessories (stabilizer, protection sheet, protection ring,
etc.) which are marketed for improving the sound quality or pro-
tecting discs as well as the disc cleaner should not be used with
this system because they may cause malfunction.
Do not attach paper or tape to either
the playing side or the label side of the
discs.
Sticker
Sticky paste
Never play a cracked or w arped disc
During playback, the disc rotates at high speed in the player.
Therefore, to avoid danger, never use acracked or deformed disc
or a disc repaired with tape or adhesive agent.
Please do not use discs which are not round because they may
cause a malfunction.
2. Endless tapes
Do not use an endless tape, as this could damage the
mechanism of the unit.
To re-record
Safety tab (accidental erasure prevention tab)
After an important recording has been finished, break the safety
tab, to prevent the recorded contents from being erased or
recorded on accidentally.
When there is slack in the tape
In such a case, insert a pencil into the reel hole and wind the
reel hub to remove the slack.
To store cassette tapes
Do not store the tapes in a place which is subject to direct
sunlight, or near equipment that generates heat. Keep the cas-
sette tapes away from any magnetic field.
For A side
For B side
Notes on cassette tape
Apply tape only to the position
where the tab has been removed.
1.Longer tape than 90 minutes cassette tape
Since longer tape than 90 minutes cassette tape is
very thin, the tape could adhere to the pinch roller or
be easilycut.It is recommended that these tapesnot
be used with this unit to prevent possible damage.
Notes
Notes
N
S
Downloaded from: http://www.usersmanualguide.com/

12
Preparations
XD-DV series (EN/K,M,T,X,Y)
System Connections
Caution:
Do not plug in the power lead until all connections
are completed.
Make connections as shown below.
When connecting the related system components, refer also
to the instruction manuals of the related components.
Caution
Be sure to adhere followings. Or proper ventilation will be blocked causing damage or
fire hazard.
÷Do not place any objects impairing heat radiation onto the top of unit.
÷Leave a space around the unit (from the largest outside dimension including pro-
jection) equal or greater than, shown below.
Top panel : 50 cm Side panel : 10 cm Back panel : 10 cm
Malfunction of microcomputer
If operation is not possible or erroneous
display appears even though all connec-
tionshavebeenmadeproperly,reset the
microcomputer referring to “ In case of
difficulty” . ‰
LR
L
L
R
R
VIDEO/AUX
IN
OUT
FRONTSPEAKERS (6Ω)
SPEAKERS S-VIDEO
FM 75ΩAM
GND
ANTENNA
SUB
WOOFER
PREOUT
SURROUND
(8Ω)
COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
CENTER
(6Ω)
+–+–
AC 110-
120V AC 220- 240V
Cr
Cb
Y
FM 75ΩAM
GND
ANTENNA
LR
L
L
R
R
VIDEO/AUX
IN
OUT
FRONTSPEAKERS (6Ω)
SPEAKERS S-VIDEO
FM 75ΩAM
GND
ANTENNA
SUB
WOOFER
PREOUT
SURROUND
(8Ω)
COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
CENTER
(6Ω)
+–+–
AC 110-
120V AC 220- 240V
Cr
Cb
Y
LR
L
L
R
R
VIDEO/AUX
IN
OUT
FRONTSPEAKERS (6Ω)
SPEAKERS S-VIDEO
FM 75ΩAM
GND
ANTENNA
SUB
WOOFER
PREOUT
SURROUND
(8Ω)
COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
CENTER
(6Ω)
+–+–
AC 110-
120V AC 220- 240V
Cr
Cb
Y
FM 75Ω
FM 75Ω
AM loop antenna
FM antenna
AM loop antenna connection
The supplied antenna is
for indoor use. Place it as
far as possible from the
main system, TV set,
speaker cords and power
cord, and set it to adirec-
tion which provides the
best reception.
FM indoor antenna connection
The accessory antennaisfor
temporary indoor use only.
For stable signal reception
werecommendusinganout-
door antenna. Remove the
indoor antenna if you con-
nect one outdoors.
1Connect to the antenna terminal.
2Locate the position providing good
reception condition.
3Fix the antenna.
FM outdoor antenna
(commercially available)
Lead the 75 Ωcoaxial
cable connected to the
FM outdoor antenna
into the room and con-
nect it to the FM 75 Ω
terminal.
Caution : Read this page carefully to ensure
safe operation.
Example of the XD-DV90
Example of the XD-DV90
Downloaded from: http://www.usersmanualguide.com/

13
Preparations
XD-DV series (EN/K,M,T,X,Y)
System Connections
Connection of the front speakers
LR
L
L
R
R
VIDEO/AUX
IN
OUT
FRONT SPEAKERS (6Ω)
SPEAKERS S-VIDEO
FM 75ΩAM
GND
ANTENNA
SUB
WOOFER
PRE OUT
SURROUND
(8Ω)
COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
CENTER
(6Ω)
+–+–
AC 110-
120V AC 220- 240V
Cr
Cb
Y
L
R
FRONT SPEAKERS (6Ω)
+–
Connection of the sub w oofer or super w oofer (optional)
Speaker (Left)
Speaker (Right)
Do not plug the power cord into the power outlet until all of the
required connections have been made.
•Never short-circuit the + and – speaker cords.
•If the left and right speakers are connected inversely or if the
speaker cords are connected with reversed polarity, the
sound becomes unnatural with ambiguous acoustic image
positioning. Be sure to connect the speakers and speaker
cords correctly.
Example of the XD-DV90
123
LR
L
L
R
R
VIDEO/AUX
IN
OUT
FRONTSPEAKERS (6Ω)
SPEAKERS S-VIDEO
FM 75ΩAM
GND
ANTENNA
SUB
WOOFER
PREOUT
SURROUND
(8Ω)
COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
CENTER
(6Ω)
+–+–
AC 110-
120V AC 220- 240V
Cr
Cb
Y
LR
L
R
L
R
VIDEO/AUX
IN
OUT
FRONT
SPEAKERS
(6Ω)
ON
OFF
SURROUND
SPEAKERS (8 –16Ω)
SURROUND S-VIDEO
Cr
Cb
Y
FM 75ΩAM
GND
ANTENNA
SUPER
WOOFER
PREOUT COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
+–
+–
AC 110-
120V AC 220- 240V
SUB
WOOFER
PRE OUT
SUPER
WOOFER
PRE OUT
Example of the XD-DV70 Example of the XD-DV90
Powered Super woofer Powered Sub woofer
For XD-DV90/XD-DV80For XD-DV70/XD-DV60
Downloaded from: http://www.usersmanualguide.com/

14
Preparations
XD-DV series (EN/K,M,T,X,Y)
Connection of the surround speaker system
Surround speaker (right) Surround speaker (left)
Center speaker
LR
L
L
R
R
VIDEO/AUX
IN
OUT
FRONT SPEAKERS (6Ω)
SPEAKERS S-VIDEO
FM 75ΩAM
GND
ANTENNA
SUB
WOOFER
PRE OUT
SURROUND
(8Ω)
COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
CENTER
(6Ω)
+ –+ –
AC 110-
120V AC 220- 240V
Cr
Cb
Y
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
L
R
SPEAKERS
SURROUND
(8Ω)
CENTER
(6Ω)
+–
LR
L
R
L
R
VIDEO/AUX
IN
OUT
FRONT
SPEAKERS
(6Ω)
ON
OFF
SURROUND
SPEAKERS (8 –16Ω)
SURROUND S-VIDEO
Cr
Cb
Y
FM 75ΩAM
GND
ANTENNA
SUPER
WOOFER
PRE OUT COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
+ –
+ –
AC 110-
120V AC 220- 240V
L
R
SURROUND
SPEAKERS (8 –16Ω)
+–
-
+
-
+
-
+
-
+
-
+
-
+
ON
OFF
Surround
speaker (right) Surround
speaker (left)
Example of the XD-DV70
Example of the XD-DV90
For XD-DV90/XD-DV80
For XD-DV70/XD-DV60/XD-DV50/XD-A850
(Optional)
Use of the speaker stabilizer (only for XD-DV90 and XD-DV80)
Please attach this to the rear of the speaker when the center speaker or the surround speaker is not stable.
Surround switch
Set to ON when a surround
speaker is connected.
Downloaded from: http://www.usersmanualguide.com/

15
Preparations
XD-DV series (EN/K,M,T,X,Y)
LR
L
R
L
R
VIDEO/AUX
IN
FRONT
SPEAKERS
(6Ω)
ON
OFF
SURROUND SPEAKERS
(8 –16Ω)
SURROUND S-VIDEO
FM 75ΩAM
GND
ANTENNA
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
+–
+–
AC 110-
120V AC 220- 240V
LR
S-VIDEO
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
VIDEO/AUX
IN
System Connections
Connection of the TV monitor (optional) and VCR (optional)
TV monitor
Video code
Composit video (Supplied)
Connection of the M D recorder/CD recorder (optional)
MD recorder/CD recorder
Optical Record IN
VCR
S-video
Audio code
This product is compatible with the MacroVision type copy protection. Some discs contain the recording of copy inhibit signals,
and the video may be disturbed when the video of such discs is recorded onto a VCR and played back.
LR
L
L
R
R
VIDEO/AUX
IN
OUT
FRONTSPEAKERS (6Ω)
SPEAKERS S-VIDEO
FM 75ΩAM
GND
ANTENNA
SUB
WOOFER
PRE OUT
SURROUND
(6Ω)
COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
CENTER
(6Ω)
+–+–
AC 110-
120V AC 220- 240V
Cr
Cb
Y
LR
VIDEO/AUX
IN
OUT
S-VIDEO
COMPONENT
VIDEO OUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
Cr
Cb
Y
For XD-DV90/XD-DV80/XD-DV70/XD-DV60
Component video
Video code
Composit video (Supplied)
S-video
Audio code
Optical cable
For XD-DV50/XD-A850DV
LR
L
L
R
R
VIDEO/AUX
IN
OUT
FRONTSPEAKERS (6Ω)
SPEAKERS S-VIDEO
FM 75ΩAM
GND
ANTENNA
SUB
WOOFER
PRE OUT
SURROUND
(8Ω)
COMPONENT
VIDEOOUTPUT
VIDEO
OUTPUT DIGITAL
OUT
OPTICAL
CENTER
(6Ω)
+–+–
AC 110-
120V AC 220- 240V
Cr
Cb
Y
DIGITAL
OUT
OPTICAL
Only for some areas
Downloaded from: http://www.usersmanualguide.com/

16
Preparations
XD-DV series (EN/K,M,T,X,Y)
Controls and indicators
1STANDBY/TIMER indicator
2POWER ON/STANDBY ( )key (
3DVD/CD play/pause (66
66
6)key ¢
TUNER /BAND key fi
TAPE A play (``
``
`)key / direction key ·
TAPE B play (``
``
`)key / direction key ·
STOP (77
77
7)key ¢
4PHONES jack ¡
5MIC jack (only for some areas) t
MIC LEVEL. control knob (only for some areas) t
6DOLBY DIGITAL indicator
(for XD-DV90/XD-DV80) E
PRO LOGIC indicator (for XD-DV90/XD-DV80) E
VIRTUAL SURROUND indicator (for XD-DV70/
XD-DV60/XD-DV50/XD-A850DV) E
EX. BASS indicator ™
7VOLUME CONTROL knob ¡
8DVD indicator
VCD indicator
CD indicator
9DISC SKIP key
Skipping to a different disc
0OPEN/CLOSE (00
00
0)key ¢
!LISTEN MODE key (for XD-DV90/XD-DV80) E
VIRTUAL SORROUND key
(for XD-DV70/XD-DV60/XD-DV50/XD-A850DV) E
@EQ MODE/EX. BASS key ™
#TUNING MODE key fi
$Display section
%VIDEO/AUX key ¡
^REVERSE MODE key ·
&DISPLAY/DEMO key 4
*DISC SELECTOR keys ¢
(Disc tray ¢
M ain unit (1)
STANDBY mode of ON/STANDBY ( ) sw itch
When the power cable plug of thisunit isinserted into a receptacle, a minute current flowsfor memory protection. Thisstatus
is referred to as the STANDBY mode, and the unit in the STANDBY mode can be turned ON from the remote control unit.
EX.BASS
VOLUME
CONTROL
DISC SELECTOR DISC SKIP 0OPEN/CLOSE
STANDBY
/TIMER DISPLAY/DEMO
REVERSE MODE
VIDEO/AUX
POWER
DVD/CD
TAPE A
PHONES MIC MIC LEVEL
TAPE B STOP DOLBY DIGITAL
PRO LOGIC
TUNER
BAND
ON/STANDBY
LISTEN MODE DVD
VCD
CD
SELECT
ENTER
TUNING MODE
EQ MODE
/EX.BASS
SMART
MENU
M
U
L
T
I
C
O
N
T
R
O
L
/
P
.
C
A
L
L
REC/ARM
4
¢
DISC 1 DISC 2 DISC 3
23 23 7
1
2
3
4
56 7
8
9
0
!@#$%
^*(&
EX.BASS
VIRTUAL SURROUND
for XD-DV70/XD-DV60/
XD-DV50/XD-A850DV
Downloaded from: http://www.usersmanualguide.com/

17
Preparations
XD-DV series (EN/K,M,T,X,Y)
Controls and indicators
)Cassette holder (TAPE A)·
Press the area marked “ PUSH OPEN” to load or
eject a tape.
¡Cassette holder (TAPE B)·
Press the area marked “ PUSH OPEN” to load or
eject a tape.
™REC/ARM key ‚
£SMART MENU key (
¢MULTI CONTROL/P.CALL/44
44
4, ¢¢
¢¢
¢key (
∞SELECT key (
§ENTER key )
¶Remote sensor *
DISPLAY
1CD (DVD or VCD)-related indicators
This section contains the CD (DVD or VCD) play and pause
mode indicators.
2Character information display
Displays the input selection, frequency, volume level etc.
3Tuner-related indicators
4R.D.S., PTY indicators
(Only for Europe and U.K.)
5A.P.S. (Auto Power Save) indicators
6PARENTAL lock indicator
7EQUALIZER indicator
8Timer-related indicators
9Cassette deck-related indicators
This section contains the cassette deck operation indicators.
Theindicatedinformationincludesthetapereversemodeand
tape transport direction.
EX.BASS
VOLUME
CONTROL
REVERSE MODE
VIDEO/AUX
POWER
DVD/CD
TAPE A
PHONES MIC MIC LEVEL
TAPE B STOP DOLBY DIGITAL
PRO LOGIC
TUNER
BAND
ON/STANDBY
VCD
CD
SELECT
ENTER
TUNING MODE
EQ MODE
/EX.BASS
SMART
MENU
M
U
L
T
I
C
O
N
T
R
O
L
/
P
.
C
A
L
L
REC/ARM
4
¢
23 23 7
PUSH
OPEN PUSH OPEN
TAPE
A PLAY PLAY/REC TAPE B
)¡
™
£
¢∞§¶
1 2 3
1
2
34567
89
M ain unit (2)
Downloaded from: http://www.usersmanualguide.com/

18
Preparations
XD-DV series (EN/K,M,T,X,Y)
Thekeysontheremotecontrolunit withthesamenamesasonthe
main unit have the same function as the keys on the main unit.
1Numeric keys ⁄
Disc selector keys (DISC1,
DISC2, DISC3)
KARAOKE keys (only for
some areas)
KEY CONTROL keys
ECHO keys
HIT MASTER key
2Search (1,¡)/TUNING
keys ∞
Skip (44
44
4, ¢¢
¢¢
¢) /P.CALL keys
£
Stop (77
77
7) key ¢
3Cursor Up, Down, Left and
Right keys •
4CLEAR key º
RETURN key y
SELECT key (
ENTER key )
S.MENU (Smart Menu) key
(
OSD (On screen display) key
º
TOP MENU key (PTY key for
only U.K. and Europe) r
MENU key (RDS key for only
U.K. and Europe) y
5DISPLAY/AUDIO key ¤
RANDOM/ANGLE key ‹
REPEAT/SLOW key ∞
A-B (A-B repeat)/STEP key
§
AUX/SUBTITLE key ¤
L.MODE (Listen mode)/
(SUBTITLE) ON/OFF key
¤
EQ (Equalizer)/EX. BASS/
DVD PGM (Program) key •
MUTE key ¡
6SHIFT key
7VOLUME (up/down) keys
¡
8DVD/CD play pause (66
66
6) key
¢
TUNER/BAND key fi
TAPE A play/direction
(™£™£
™£™£
™£) key ·
TAPE B play/direction
(™£™£
™£™£
™£) key ·
9POWER ( ) key
Power ON/OFF switching is
executed.
Loading batteries
2Insert batteries. 3Close the cover.1Remove the cover.
÷Insert two R6/LR6 (“ AA” -size) bat-
teries following the polarity indica-
tions.
÷Align the poles (+ and -) properly
when inserting the batteries
Operation
Plug the power cord into the mains power outlet and
press the on/standby ( POWER) key of the remote
control unit to turn power ON. After the powerhasbeen
turned ON, press the desired key.
To turn power off, press the on/standby ( POWER)
key again.
÷When pressing more than one remote control keys succes-
sively, press the keys securely by leaving an interval of 1
second or more between keys. Operating range (approx.)
Remote sensor
1. The provided batteries are intended for use in operation checking, and their service life may be short.
2. When the remote controllable distance becomes short, replace both of the batteries with new ones.
3. If direct sunlight or the light of a high- frequency fluorescent lamp (inverter type, etc.) is incident to the remote sensor, malfunction
may occur. In such a case, change the installation position to avoid malfunction.
Model : RC-DV90 (for U.S.A., Canada, Australia
and U.S. Military)
RC-DV90E (for Europe and U.K.)
RC-DV90M (for Other countries)
Infrared ray system
Operation of remote control unit
Notes
Notes
/
123
456
789
BAND
0
1¡
4¢ 7 23
23
6
2 2
∞
CLEAR RETURN SELECT ENTER
S.MENU OSD
TOP MENU MENU
DISPLAY RANDOM REPEAT A–B
AUX
L.MODE EQ MUTE
POWER
DVD/CD
TUNER
DISC 1 DISC 2
KEY CONTROL
ECHO
HIT MASTER
–+
DISC 3
TAPE ATUNING
TAPE BSTOP
RDSPTY
STEPSLOWANGLEAUDIO
DVD PGMON/OFF SUBTITLE
EX.BASS
SHIFT VOLUME
P.CALL
1
2
3
4
6
5
7
8
9
23 23 7
30º
30º
6m
/
SHIFT
Blink
Use of the SHIFT key
When a key corresponding to the SHIFT function is pressed within 5 seconds of pressing the SHIFT
key ("S" flashes on the display), a different function from the normal function will operate.
For example, when the REPEAT (SLOW) key is pressed after the SHIFT key, SLOW operation mode
will be reached. While the "S"indication is flashing, operation of the SHIFT function is possible
without pressing the SHIFT key.
Downloaded from: http://www.usersmanualguide.com/

19
Preparations
XD-DV series (EN/K,M,T,X,Y)
Thisunit incorporatesa clock function. Be sure to adjust the
correct time before using the timer function. The time is
displayed only while the power is off.
Sw itching the pow er ON.
Press the SM ART M ENU key.
Select “CLOCK OPTION”,
then press the SELECT key.
Select “ADJUST TIM E”,
then press the SELECT key.
SM ART M ENU operation/Clock adjustment
ThefollowingitemscanbeselectedbypressingtheMULTI
CONTROLkeys.
“RECORDING OPTION”
“TAPEDUBBING”
“AUDIO OPTION”
“CLOCKOPTION”
Adjust the clock before setting the timer.
1
POWER
ON/STANDBY
÷When operating on the remote control unit, Press the
4, ¢keys to select “Clock Option”, then press the
SELECT key.
SELECT
M
U
L
T
I
C
O
N
T
R
O
L
/
P
.
C
A
L
L
4
¢
÷When operating on the remote control unit, Press the
4, ¢keysto select “ADJUST TIME”, then pressthe
SELECT key.
STANDBY
/TIMER
ThefollowingitemscanbeselectedbypressingtheMULTI
CONTROLkeys.
“SLEEPTIMER”
“ADJUST TIME”
“TIMERPLAY”
“AUTO POWERSAVE”
Continued on next page...
2
REMOTEMAIN UNIT
/
POWER
3
REMOTEMAIN UNIT
SMART
MENU
S.MENU
4
Goes off
SELECT
M
U
L
T
I
C
O
N
T
R
O
L
/
P
.
C
A
L
L
4
¢
Clock adjustment
SM ART M ENU operation
23 23 7
/
MULTI CONTROL
SELECT
ENTER
ENTER
SELECT
RETURN
4, ¢/
P.CALL
When one of the MULTI CONTROL keys (44
44
4, ¢¢
¢¢
¢/P.CALL
keys) is pressed after the SMART MENU key (S.MENU key)
has been pressed, various operations can be performed
while watching the display.
SELECT key →Selects an item.
ENTER key →Confirms the selected contents.
RETURN key →Returns to the previous operation.
Downloaded from: http://www.usersmanualguide.com/

20
Preparations
XD-DV series (EN/K,M,T,X,Y)
Display the clock
÷When the DISPLAY/DEMO key is pressed while the power is
off, the present time will be displayed for about 5 seconds.
REMOTE MAIN UNIT
Select “TIM E 24H” or “TIM E 12H”,
then press the SELECT key.
Enter the figure of hour, then press the
SELECT key.
÷When operating remote control unit, Press the Cursor
4, ¢keys to select figure of hour, then press the
SELECT key.
Enter the figure of minute, then press the
ENTER key.
÷When operating remote control unit, Press the Cursor
4, ¢keys to select figure of minut, then press the
ENTER key.
To increase
To decrease
6
To increase
To decrease
÷The time display starts to blink.
Blink
“TIME24H” mode
0:00 j 1:00 j 2:00 j ••••• j 22:00 j 23:00
AM 12:00 j AM 1:00 j AM 2:00 j ••••• j PM11:00
Blink
“TIME12H” mode
÷The minute display starts to blink.
Blink
“TIME24H” mode
Blink
“TIME12H” mode
19:00 j 19:01 j 19:02 j ••••• j 19:58 j 19:59
PM 7:00 j PM 7:01 j PM 7:02 j ••••• j PM 7:59
5
÷When operating on the remote control unit, Press the
4,¢keysto select “TIME24H” or“TIME12H”,then
press the SELECT key.
ThefollowingitemscanbeselectedbypressingtheMULTI
CONTROLkeys.
“TIME24H”
“TIME12H”
Example of the 24
hour display. Example of the 12 hour display.
23:00 11:00
7
To increase
To decrease
M
U
L
T
I
C
O
N
T
R
O
L
/
P
.
C
A
L
L
4
¢
ENTER
SELECT
M
U
L
T
I
C
O
N
T
R
O
L
/
P
.
C
A
L
L
4
¢
SELECT
M
U
L
T
I
C
O
N
T
R
O
L
/
P
.
C
A
L
L
4
¢
DISPLAY/DEMODISPLAY/DEMO
DISPLAY
AUDIO
Clock adjustment
Downloaded from: http://www.usersmanualguide.com/
